HP Metal Jet S100 Operator's manual

HP Metal Jet S100 Powder Removal
Station
Product Documentation
Introductory Information
SUMMARY
Introductory information about your product

About this edition
© Copyright September, 2022 HP
Development Company, L.P.
Edition 1
Legal notices
The information contained herein is subject
to change without notice.
The only warranties for HP products and
services are set forth in the express
warranty statement accompanying such
products and services. Nothing herein
should be construed as constituting an
additional warranty. HP shall not be liable
for technical or editorial errors or omissions
contained herein.

Table of contents
1 HP Metal Jet S100 Powder Removal Station Introductory Information ........................................................................................................ 1
What is it? ............................................................................................................................................................................................................................................ 1
Documentation................................................................................................................................................................................................................................ 1
Safety precautions.......................................................................................................................................................................................................................1
Front panel.......................................................................................................................................................................................................................................18
System errors................................................................................................................................................................................................................................19
Power specifications................................................................................................................................................................................................................19
iii

HP Metal Jet S100 Powder Removal Station
Introductory Information
1
This introductory document includes legal notices and safety instructions, describes the use of the front
panel, explains error messages that you may encounter, and gives power specifications.
What is it?
The HP Metal Jet solution is an integrated system designed to manufacture best-in-class quality metal
parts economically at industrial scale.
Prior to printing, the HP Powder Management Station automatically blends, sieves, and loads metal
powder into HP Build Units according to the user-defined print job and customized parameters. Once
printing and curing are complete, the build unit is manually inserted into the HP Powder Removal Station
where loose powder is automatically removed from the printed parts and collected in the HP Powder
Collector. The powder removal station includes separate vacuum attachments that enable manual
removal of any remaining powder on the printed parts. All reclaimed powder is pneumatically recovered
into the powder collector for storage and reintroduced into the powder management station using HP
Powder Tanks.
Documentation
A full set of manuals is provided with your products.
●Site preparation guide
●Introductory information (this document)
●User guide
●Legal information
●Limited warranty
You can download the documentation from the HP website at:
●http://www.hp.com/go/MetalJetS100/manuals
Further information is available from:
●http://www.hp.com/go/MetalJetS100/support
Safety precautions
Before using the equipment, read the safety precautions and operating instructions to make sure you
can use it safely.
HP Metal Jet S100 Powder Removal Station
Introductory Information
1

Introduction
Perform the recommended maintenance and cleaning tasks to ensure the correct and safe operation of
the equipment.
You are expected to have the appropriate technical training and experience necessary to be aware
of hazards to which you may be exposed in performing a task, and to take appropriate measures to
minimize the risks to yourself and to others.
Operations must be supervised at all times.
The equipment is stationary, and should be located in a restricted-access area, for authorized personnel
only.
General safety guidelines
Follow the advice at all times for your personal safety.
Turn off all equipment, using the branch circuit breakers located in the building's Power Distribution Unit
(PDU), and call your service representative in any of the following cases:
●The electrical supply cable is damaged.
●The equipment has been damaged by an impact.
●Liquid has entered the equipment.
●The heating subsystem and enclosures are damaged, the glass is missing or broken, or the sealing
is defective.
●There is smoke or an unusual smell coming from the equipment.
●The built-in Residual Current Circuit Breaker (Ground Fault Circuit Interrupter) has been repeatedly
tripped.
●Fuses have blown.
●The equipment is not operating normally.
●There is any mechanical or enclosure damage.
Turn off the equipment using the branch circuit breakers in either of the following cases:
●During a thunderstorm.
●During a power failure.
Operate the equipment only within the specified ranges of operating temperature and humidity; see the
site preparation guide.
The equipment should always be kept in the same environmental conditions.
Use HP-certified and HP-branded agents only. Do not use unauthorized third-party agents.
The area in which the equipment is installed should be free from liquid spillage and environmental
condensation.
Users and operators must be trained for explosive atmospheres and associated hazards during
cleaning and maintenance operations, according to local laws and company requirements.
2Chapter 1 HP Metal Jet S100 Powder Removal Station Introductory Information

Ensure that there is no condensation inside the equipment before turning it on.
Take special care with zones marked with warning labels.
Use HP-certified equipment and accessories only. The use of third-party equipment and accessories
can cause safety risks, powder leakages, and malfunctions in the printer; and may affect your system
warranty.
In case of unexpected malfunction, anomaly, ESD (ElectroStatic Discharges), or electromagnetic
interference, press the emergency stop button and disconnect the equipment. If the problem persists,
contact your support representative.
Do not repair or replace any part of the equipment or attempt any servicing unless specifically
recommended in the user-maintenance instructions or in published user-repair instructions that you
understand and have the skills to carry out.
Do not attempt to repair, disassemble, or modify the equipment by yourself; and do not use any part
other than original HP spare parts.
To repair or reinstall the equipment, please contact your nearest service authorized provider; otherwise
you may experience electric shock, fire, problems with the product, or injury.
Final parts/builds
The customer assumes all risk relating to or arising from the 3D printed parts.
The customer is solely responsible for the evaluation of and determination of the suitability and
compliance with applicable regulations of the products and/or 3D printed parts for any use, especially
for uses (including but not limited to medical/dental, food contact, automotive, heavy industry, and
consumer products) that are regulated by US, EU, and other applicable governments.
Explosion hazard
Your product may produce combustible metal dust.
WARNING! Combustible dust clouds and flammable vapors can form explosive mixtures with air. Take
precautionary measures against static charges, and keep away from sources of ignition (hot surfaces,
hot flames or gases, mechanical sparks, electrical equipment, electromagnetic waves, exothermic
reactions including self-combustion of solids).
NOTICE: The equipment is not intended for hazardous locations or ATEX classified zones: ordinary
locations only.
To avoid the risk of explosion, take the following precautions:
●The customer takes full responsibility for assessing the customer's site according to the Explosion
Protection Document (EPD), Dust Hazard Analysis (DHA), or any required document of the local
jurisdiction of the country where the equipment is installed, to avoid the risk of explosion.
●Smoking, candles, welding, and open flames should be forbidden close to the equipment or powder
storage area.
●Hot surfaces, hot flames and gases, and mechanical and electrical sparks, only can be generated
during maintenance or repair operations (use of a permit work system according to the service
manual).
Final parts/builds 3

●Inside and outside the equipment should be cleaned regularly with an explosion-protected vacuum
cleaner to avoid dust accumulation. Do not sweep the dust or try to remove it with a compressed-air
gun.
●An explosion-protected vacuum cleaner certified for collection of combustible metal dust is
required for cleaning. Take measures to mitigate powder spillage and avoid potential ignition
sources such as ESD (ElectroStatic Discharges), flames, and sparks. Do not smoke nearby.
●An explosion-protected vacuum cleaner compliant with the following normative specifications:
–Europe/International Electrotechnical Commission (IEC): Zone 22 or better, temperature Class
200°C (392°F) maximum.
–United States/National Electrical Code (NEC): Class II, division 2 or better, temperature Class
200°C (392°F) maximum.
–Suitable for conductive material.
–Refer to the material safety data sheet (MSDS) and meet local regulations.
–Recommended equipment fitted with wet filter (vacuum with submerged flow inches inert liquid)
or High Efficiency Particulate Air (HEPA) filter grade.
●The equipment and accessories must be properly grounded at mains outlets only; do not
manipulate internal bonding. If static discharges or electrical sparks are noticed, stop operation,
disconnect the equipment, and contact your support representative.
●The auxiliary equipment (i.e. the oven for the rebaking process) must be explosion-protected for
combustible dust and flammable vapors, according to the explosion protection document (EPD)
or explosion hazard analysis covering the probability of an explosive atmosphere and presence
of effective ignition sources as per local laws requirements. Refer to the safety data sheet of the
material being processed.
●The material collector has to be electrically conductive or dissipative, and the material cannot
generate mechanical sparks. In addition, the earthing clamps are necessary to ground the material
collector during use.
●Follow the cooling time and ensure a maximum powder temperature of 70°C (158°F) prior to putting it
inside the load station.
●Ground the portable tank and drums using static earthing clamps during refilling or unloading.
●HP recommends the use of HP equipment for unpacking 3D parts and refilling the build unit. If other
methods are used, read the following notes:
–Dust clouds generated during handling and/or storage can form explosive mixtures with air.
Dust explosion characteristics vary with the particle size, particle shape, moisture content,
contaminants, and other variables.
–Check that all equipment is properly grounded and installed to satisfy electrical classification
requirements. As with any dry powder, pouring this powder or allowing it to fall freely or be
conveyed through chutes or pipes can accumulate and generate electrostatic discharges,
potentially causing ignition of the powder itself, or of any flammable materials which may come
into contact with the powder or its container.
●Powder, agents and solvents storage, handling, and disposal as per local laws. See the Safety Data
Sheets of your processed powder and solvent powder for adequate handling and storage. Follow
your Environmental, Health, and Safety processes and procedures.
4Chapter 1 HP Metal Jet S100 Powder Removal Station Introductory Information

●Do not place the equipment in a hazardous location area, keep it separated from other equipment
that could create a combustible dust cloud or explosive gas atmospheres during its operation.
●Auxiliary post-processing equipment must be suitable for combustible metal dust.
●Stop operation immediately if sparks, flames, or powder and/or liquid spillage is seen and call your
HP service representative before continuing.
●All personnel, when handling combustible dust, should be freed from static electricity by using
conductive or dissipative footwear and clothing, and a dissipative floor.
●Keep the safety lid on top of the build unit at all times when it is outside of host equipment
Use powder complying with HP guidelines, as follows:
●Explosion characteristics acceptance criteria:
–Minimum Ignition Temperature (MIT) 360°C or higher
–Layer Ignition Temperature (LIT) 375°C or higher
–Auto Ignition Temperature (AIT) 375°C or higher
–Minimum Ignition Energy (MIE) 100 mJ or higher at process temperature
–Minimum Explosion Concentration (MEC) 350 g/m³ or higher
–Kst 200 bar·m/s or less
–ST grade 1 or less
●Minimum particle size (d10) > 2 μm
●Non-reactive with other materials or HP agents (see the safety data sheets for the agents on the HP
website at the following link: http://www.hp.com/go/msds), stable
There is no support for the powder removal station, customers takes full responsibility for it.
WARNING! Dust clouds can form explosive mixtures with air. Take precautionary measures against
static charges and keep away from sources of ignition. Unpacking parts can cause dust clouds. Keep a
clear area of at least 2 m (78.7 in) around electric/electronic devices or any source of ignition.
CAUTION: As the build unit operates at a high temperature while curing, you must wait for it to cool
before extracting the it from the cure station to unpack it. An earth connection from the build unit is
required when unpacking parts; you must use static earthing clamps connected to the build unit during
the process.
Electric shock hazard
The internal circuits of the electrical cabinet, motors, ultrasounds converter, heating systems and build
unit operate at hazardous voltages capable of causing death or serious personal injury.
WARNING! High leakage current! The equipment must be connected to earth at all times.
Turn off the equipment using the branch circuit breakers located in the building's Power Distribution Unit
(PDU) before servicing. The equipment must be connected to earth at mains outlets only.
To avoid the risk of electric shock:
Electric shock hazard 5

●Do not attempt to dismantle the internal circuit enclosures, build unit, or electrical cabinet except
during hardware maintenance tasks. In that case, follow the instructions strictly.
●Do not remove or open any other closed system covers or plugs.
●Do not insert objects through slots in the equipment.
●Test the functionality of the Residual Current Circuit Breakers (RCCBs) every year.
NOTICE: A blown fuse may indicate malfunctioning electrical circuits within the system. Call your
service representative, and do not attempt to replace the fuse yourself.
Heat hazard
The vacuum motor enclosure and exhaust, the build unit lid and the portable tanks after rebaking
process can operate at high temperatures and may cause burns if touched.
To avoid personal injury, take the following precautions:
●Use of appropriate personal protective equipment (i.e. heat resistant gloves) when manipulating the
portable tanks after the rebaking process.
●Follow the cooling times before handling.
●Take special care with zones marked with warning labels.
The top heating, fusing, build chamber and Cure station subsystems operate at high temperatures and
can cause burns if touched.
To avoid personal injury, take the following precautions:
●Use of appropriate personal protective equipment (i.e. heat resistant gloves) when extracting the
build unit from host equipment
●Take special care when accessing the printing area. Let the equipment cool down before you open
the covers.
●Take special care with zones marked with warning labels.
●Do not place objects inside the equipment while operating.
●Do not cover enclosures while operating.
●Remember to let the equipment cool down before performing some maintenance operations.
●Take special care when assembling or removing the safety lid on/from the build unit. Let the built unit
cool down before handling the safety lid.
Fire hazard
The motors, ultrasound converter, and frequency inverters of the equipment operate at high power.
The build chamber and curing station subsystems operate at high temperatures. Call your service
representative if the built-in Residual Current Circuit Breaker (Ground Fault Circuit Interrupter) is
repeatedly tripped.
6Chapter 1 HP Metal Jet S100 Powder Removal Station Introductory Information

To avoid the risk of fire, take the following precautions:
●Use the power supply voltage specified on the nameplate.
●Connect the electrical supply cable to a dedicated line, protected by a branch circuit breaker
according to the information detailed in the site preparation guide.
●Call your service representative if the built-in Residual Current Circuit Breaker (Ground Fault Circuit
Interrupter) is repeatedly tripped.
●Do not insert objects through slots in the equipment.
●Take care not to spill liquid on the equipment. After cleaning, make sure all components are dry
before using the equipment again.
●Do not use aerosol products that contain flammable gases inside or around the equipment. Do not
operate the equipment in an explosive atmosphere.
●Do not attempt to modify the electrical cabinet, or any enclosure of the machine.
●Proper maintenance and genuine HP consumables are required to ensure that the equipment
operates safely as designed. The use of non-HP consumables may present a risk of fire.
●Take special care with zones marked with warning labels.
●Do not place objects covering the enclosures or air ventilation.
●Do not leave tools or other materials inside equipment after maintenance or servicing.
CAUTION: Do not use a jet of water, as it could scatter and spread the fire.
WARNING! Depending on the powder used, some unhealthy substances can be released into the air
in case of incidental fire. Wear self-contained pressure-demand breathing apparatus and full
protective gear. Your EHS specialist should consult the safety data sheet (SDS) about each powder,
available on the HP website at the following link: http://www.hp.com/go/msds, and advise on the
appropriate measures for your location.
Mechanical hazard
The equipment has moving parts that could cause injury.
To avoid personal injury, take the following precautions when working close to the equipment.
●Keep your clothing and all parts of your body away from moving parts.
●Avoid wearing necklaces, bracelets, and other hanging objects.
●If your hair is long, try to secure it so that it will not fall into the equipment.
●Take care that sleeves or gloves do not get caught in moving parts.
●Do not operate the equipment with components bypassed.
●Take care when handling the safety lid; take it by the two handles provided and ensure you fix it well
to the build unit or securely store it in its storage position.
For more information see and Personal protective equipment on page 11.
Mechanical hazard 7

Light radiation hazard
Infrared (IR) radiation is emitted from the top heating area.
The enclosures limit radiation in compliance with the requirements of the exempt group in International
Electrotechnical Commission (IEC) 62471:2006 Photobiological safety of lamps and lamp systems . Do
not modify the top cover enclosure, the glass or the windows.
Chemical hazard
Sufficient ventilation needs to be provided to ensure that potential airborne exposure to chemical
substances is adequately controlled. Consult your usual air conditioning or Environmental Health and
Safety (EHS) specialist for advice on the appropriate measures for your location.
Respiratory personal protective equipment may be required throughout the entire operation of these
machines. Refer to the Safety Data Sheet of your metallic powder, and consult your Environmental
Health and Safety (EHS) specialist for advice on the appropriate measures for your location and
application.
To manipulate material (load, unpack, and so on) and green parts, use protective personal equipment
according to the Safety Data Sheets of your processed material.
Use HP-branded agents only. Do not use unauthorized third-party agents.
Take special care in any zones marked with warning labels.
Ventilation
Fresh air ventilation is needed to maintain comfort levels.
Adequate ventilation also needs to be provided to ensure that potential airborne exposure to powders
and agents is adequately controlled according to their safety data sheets.
Air conditioning and ventilation should meet local environmental, health, and safety (EHS) guidelines and
regulations. Please follow these instructions carefully when designing the air-conditioning installation
and placing your equipment in the room.
NOTICE: The ventilation units should not blow air directly onto the equipment.
Air conditioning
As with all equipment installations, to maintain ambient comfort levels, air conditioning in the work area
should take into account that the equipment produces heat.
Typically, the printer's power dissipation is about 4-6 kW/h (13.65-20.47 kBTU/h) and the curing station's
power dissipation is about 3-4 kilowatts per hour (10.24-13.65 kBTU/h). About 70 % of this power is
removed throughout the exhaust connection.
Typically, the load station's power dissipation is 7 kW (23.9 kBTU/h).
Air conditioning should meet local Environmental Health and Safety (EHS) guidelines and regulations.
NOTICE: The air conditioning units should not blow air directly onto the equipment.
Sound pressure level
Declared dual number noise emission values in accordance with ISO 4871, corresponding to the worst
bystander position according to ISO 11202, located at the rear of the product.
8Chapter 1 HP Metal Jet S100 Powder Removal Station Introductory Information

Printer
Sound Pressure Level measured per ISO 11202 at by-standing positions is < 70dB(A).
Curing station
Declared dual-number noise-emission values in accordance with ISO 4871:
●LpA = 71 dB(A)
●KpA = 5 dB
Powder management
The emitted sound pressure level could exceed 70dB(A) when filling the load station's input tanks. The
maximum emitted sound pressure level is below 80 dB(A) (measurements according to ISO 11201).
Hearing protection may be required as per local laws; consult your environmental, health, and safety
(EHS) specialist.
Declared dual-number noise-emission values in accordance with ISO 4871:
●LpA = 73 dB(A)
●KpA = 5 dB
Transport
In case of equipment relocation, remove all material (powder) and consumables.
The customer takes full responsibility for moving equipment, the use of auxiliary lifting/carrying aids,
and providing the required personnel. Refer to the Site Preparation Guide , " Moving equipment " section
for more information.
Build unit transport
Special care must be taken to avoid personal injury when moving the build unit.
●Always wear personal protective equipment including boots and gloves.
●Keep the safety lid on top of the build unit at all times, except when it is inside another equipment.
●Steer the build unit only using the handle.
●Move the build unit over smooth, flat surfaces without steps.
●Move with care and avoid shocks during transport, which could spill the powder.
●Lock the front casters when not moving the build unit. Remember to unlock them before moving it.
●Before transporting the build unit; check that the safety lid is well attached to it, with the two clamps
provided.
●Take care when handling the safety lid; carry it with the two handles provided and ensure to attach it
correctly to the build unit or store it securely in the designated way.
●Move the build unit over smooth flat surfaces without steps. Maximum ramp allowed TBD%.
Transport 9

If moving the build unit between different rooms, bear in mind that it should be kept in constant
environmental conditions.
Portable tank transport
Special care must be taken to avoid personal injury when moving the portable tank.
●Always wear personal protective equipment including boots and gloves.
●Always transport the portable tank with the lid properly placed and the clamp closed to avoid
generating dust clouds.
●Steer the portable tank only using the handle.
If moving the portable tank between different rooms, bear in mind that it should be kept in constant
environmental conditions.
Ergonomic risk
Operation and maintenance tasks require handling heavy loads. For instance, build unit and portable
tank transport, safety lid handling, opening the printer's top cover, consumables, and feedstock material,
among others.
CAUTION: Heavy loads.
CAUTION: Work platform recommended.
To avoid muscle strain or back injury when moving equipment or handling items, follow proper
techniques or use of auxiliary lifting/carrying aids or using more than one person if required.
NOTICE: The build unit, empty or full, is a heavy device. Take into consideration its maximum weight of
552 kg (1217 lb) during daily moving or transport tasks.
The portable tank, empty or full, is a heavy device. Take into consideration its maximum weight of 512 kg
(1129 lb) during daily moving or transport tasks.
During daily operations, the build unit and /or portable tank can be moved on a ramp with no more than
2° of inclination.
In case of equipment relocation, remove all material (powder) and consumables. The customer takes
full responsibility for moving equipment, the use of auxiliary lifting/carrying aids, and providing the
required personnel. Refer to the Site Preparation Guide , " moving equipment " section.
Operation and maintenance tasks may require the use of a ladder or work platform to reach remote
parts. For instance, accessing the print-zone area, mixer, and input tank, among others.
The customer takes full responsibility for room layout, auxiliary equipment, personal protective
equipment (PPE), and working procedures, among other safety aspects, throughout the entire operation
of the equipment. Refer to Site Preparation Guide for more information.
3D part unpacking
Refer to the safety data sheet and meet local regulations in order to use the appropriate personal
protective equipment needed, including heat and chemical resistant gloves when unpacking 3D printed
parts.
10 Chapter 1 HP Metal Jet S100 Powder Removal Station Introductory Information

Personal protective equipment
It is recommended to use heat and chemical resistant gloves, mask, goggles, safety conductive or
dissipative footwear, safety boots, coat, conductive or dissipative clothing, and hearing protection for
maintenance tasks, cleaning and powder handling. Refer to the Safety Data Sheet of the powder and
agent and meet local regulations.
Respiratory personal protective equipment may be required for the whole operation of these machines.
Refer to the safety data sheet instructions of your metallic powder or consult your environmental health
and safety (EHS) specialist for advice on appropriate measures for your location and application.
Use of tools
Maintenance of your product may sometimes require the use of a tool.
●Users: No tools are required except those listed in .
●Maintenance personnel: Hardware maintenance tasks and replacement of Customer Self-
Replaceable (CSR) parts may require a screwdriver.
NOTICE: During installation, the designated personnel receive training for the safe operation and
maintenance of the equipment. The equipment should not be used without this training.
NOTICE: After using the maintenance key to open a door, remember to lock it afterwards, and return
the key to safe and secure storage.
Warnings and cautions
Warning and caution symbols are used in this manual to ensure the proper use of the equipment and to
prevent it from being damaged. Follow the instructions marked with these symbols.
DANGER! Indicates a hazardous situation, that if not avoided, will result in death or serious injury.
WARNING! Indicates a hazardous situation, that if not avoided, could result in death or serious injury.
CAUTION: Indicates a hazardous situation, that if not avoided, could result in minor or moderate
injury.
NOTICE: Indicates information considered important but not hazard related.
Warning labels
Labels are placed on the product for your protection. Familiarize yourself with their meaning and heed
their warning at all times.
Personal protective equipment 11

Warning labels
Label Explanation
Equipment serial label, includes the following information:
●Manufacturer
●Product No.
●Serial No.
●Regulatory Model No.
●Regulatory markings
●Electrical ratings
●Country of origin
WARNING! Equipment must be connected to earthed mains
outlet only.
Configure the building's electrical system used to power
the equipment to meet its electrical requirements and the
Electrical Code requirements of the local jurisdiction of the
country where the equipment is installed.
No operator serviceable parts inside. Refer servicing to
qualified servicing personnel only.
CAUTION: Main power switch.
With emergency switch off function.
Disconnect before servicing.
Enable lockout/tagout before servicing.
WARNING! Push-button energize hazardous subsystem.
Do not operate with guards removed or safety functions
bypassed.
CAUTION: Main power switch
With emergency switch off function.
Enable lockout/tagout before servicing.
WARNING! Emergency stop button.
In case of unexpected malfunction, anomaly, ESD
(ElectroStatic Discharges), or electromagnetic interference,
press the emergency stop button and disconnect the
equipment. If the problem persists, contact your support
representative.
12 Chapter 1 HP Metal Jet S100 Powder Removal Station Introductory Information

Warning labels (continued)
Label Explanation
DANGER! Electric shock hazard
Heating modules operate at hazardous voltage. Disconnect
power source before servicing.
CAUTION: Double pole. Neutral fusing. Refer servicing to
qualified service personnel.
WARNING! High leakage current.
Earth connection essential before connecting supply.
Equipment to be connected to earthed mains only.
IMPORTANT: Read instructions.
Before starting, read and follow the operating and safety
instructions.
IMPORTANT: Read manuals.
See installations instructions before connecting to the
supply.
Read and follow the operating and safety instructions before
starting the equipment.
IMPORTANT: Read instructions.
Read and follow repair, maintenance and safety instructions.
No operator serviceable parts inside. Refer servicing to
qualified servicing personnel only.
DANGER! Electric shock hazard.
Authorized personnel only.
Disconnect before servicing.
Do not operate with guards removed, lockout/tagout before
servicing.
WARNING! Arc flash and electrical shock hazard.
Access restricted to authorized personnel only.
Do not operate controls or open covers without appropriate
personal protection equipment.
Failure to comply may result in injury or death.
CAUTION: Electrical shock hazard.
Orange tagged wiring is not de-energized when the main
switch is in the Off position.
If required turn off all equipment by using the branch circuit
breakers located in the building's power distribution unit
(PDU).
Warning labels 13

Warning labels (continued)
Label Explanation
CAUTION: Risk of fire.
For continued protection against risk of fire, replace ONLY
with same type and rating of fuse.
Lockout/tagout before servicing.
NOTICE: A blown fuse may indicate malfunctioning electrical
circuits within the system, refer servicing to qualified servicing
personnel only.
WARNING! Crush hazard.
Keep hands away from moving or falling parts.
Do not operate with guards removed, lockout/tagout before
servicing.
WARNING! Crush hazard.
Keep hands away from moving or falling parts.
Do not operate with guards removed, lockout/tagout before
servicing.
WARNING! Hand entanglement hazard.
Moving parts can crush and cut.
Keep body parts away from moving parts or rotating gears.
Do not operate with guards removed, lockout/tagout before
servicing.
WARNING! Hazardous moving part.
Moving parts can crush and cut.
Keep hands away from moving parts or rotating gears.
Do not operate with guards removed, lockout/tagout before
servicing.
WARNING! Light radiation hazard.
Light radiation. Do not stare at the top cover's light, it may be
harmful to the eyes.
14 Chapter 1 HP Metal Jet S100 Powder Removal Station Introductory Information

Warning labels (continued)
Label Explanation
WARNING! Moving fan blades.
Hazardous moving parts. Keep hands away from moving fan
blades.
Do not operate with guards removed, lockout/tagout before
servicing.
WARNING! Potentially explosive atmosphere.
Combustible dust clouds or flammable vapors can form
explosive mixtures with air.
Keep the area free from any ignition source, such as static
charges, open flames, electrical equipment, etc.
WARNING! Crush hazard.
Keep body parts away from moving or falling parts or edges.
CAUTION: Hot surface.
Do not touch.
Let equipment cool down or otherwise heat-resistant gloves
required.
CAUTION: Heavy loads.
To avoid muscle strain or back injury while moving equipment
or handling items, follow proper techniques or use auxiliary
handling aids or more than one person when required.
CAUTION: Forklift point right.
Equipment may overbalance resulting in death, severe injury
or damage to the equipment.
WARNING! No ignition sources permitted nearby.
Dust clouds can form explosive mixtures with air. Take
precautionary measures against static charges and keep
away from sources of ignition.
No smoking, matches, sparks, or open flames close to
equipment or material storage area.
Warning labels 15

Warning labels (continued)
Label Explanation
CAUTION: Do not operate with open door. Lockout/tagout
before servicing.
CAUTION: Do not step.
Do not step over any machine part. It is not intended for this
use and could result in broken parts and user injuries.
CAUTION: Do not climb.
Do not climb onto the structure or any other machine part.
CAUTION: Personal protective equipment (PPE) required.
Use of protective gloves for operating and handling machine,
supplies or waste.
Refer to supplies safety data sheets (SDS).
CAUTION: Personal protective equipment (PPE) required.
Use of safety mask for operating and handling machine,
supplies or waste.
Refer to supplies safety data sheets (SDS).
CAUTION: Personal protective equipment (PPE) required.
Use of safety goggles for operating and handling machine,
supplies or waste.
Refer to supplies safety data sheets (SDS).
CAUTION: Safety boots required.
Feet striking or being struck by objects.
Wear anti-static footwear.
16 Chapter 1 HP Metal Jet S100 Powder Removal Station Introductory Information

Warning labels (continued)
Label Explanation
WARNING! An explosion-protected vacuum cleaner certified
for collection of metal combustible dust is required for
cleaning.
Do not sweep the dust or try to remove it with a compressed-
air gun.
Follow maintenance, cleaning tasks and housekeeping to
ensure correct operation and safety. Inside and outside,
the equipment should be cleaned regularly to avoid dust
accumulation.
Refer to the material safety data sheet (SDS) and meet local
regulations. Disposal as per local laws.
In addition, take measures to mitigate material spillage and
avoid potential ignition sources such as ESD (electrostatic
discharges), flames and sparks. Do not smoke nearby.
CAUTION: Work platform recommended.
Operation and maintenance task may require the use of a
ladder or work platform to reach remote parts.
Be careful when you step down.
WARNING! Protective conductor connecting point.
Protective earth terminal marked with PE for qualified
electricians during mains connection.
Earth connection essential before connecting supply.
Ensure proper bonding after a repair.
Protective bonding conductor are identified by bi-color
combination GREEN-AND-YELLOW.
NOTICE: Functional bonding conductor connecting point.
Bonding connection required against maloperation.
Emergency stop buttons
There are emergency stop buttons on the powder management station. If an emergency occurs, push
an emergency stop button to stop all processes.
The emergency stop buttons on the powder management station are located on the e-cabinet and
below the front panel; their effect is to stop the motors, the powder discharge valves, and the station’s
general air pressure.
Emergency stop buttons 17
