HP 5384A Service manual

--0 E R A T I N G A. N D S E R V I C E M A N U A L
)
5384A
5385A
Frequency Counters
HEWLETT
PACKARD
J:J:
,,
UIUI
c.> c.>
011011
Ul-""
>>
'
'

CERTIFICATION
Hewlett-Packard Companycertifies that this product met its publishedspecifications at the time of shipment
from the factory. Hewlett-Packard further certifies that its calibration measurements are traceable to the
United States National Bureau of Standards, to the extent allowed by the Bureau's calibration facility, and to
the calibration facilities of other International Standards Organization members.
WARRANTY
This Hewlett-Packard instrument product is warranted against defects in material and workmanship for a
period
of one year from date of shipment. Duringthe warranty period, Hewlett-Packard Company will, at its
option, either repair or replace products which prove to be defective.
For warranty service or repair, this product must be returned to aservice facility designated by HP. Buyershall
prepay shipping charges to HP and HP shall pay shipping charges to return the product to Buyer. However,
Buyer shall
pay all shipping charges, duties, and taxes for products returned to HP from another country.
HP warrants that its software and firmware designated by HP for use with an instrument will execute its
programming instructions when properly installed on that instrument. HP does not warrant that th~
operation of the instrument, or software, or firmware will be uninterrupted or error free. '
LIMITATION OF WARRANTY
The foregoing warranty shall not apply to defects resulting from improper or inadequate maintenance by
Buyer, Buyer-supplied software or interfacing, unauthorized modification
or misuse,operation outside of the
environmental specifications for the product, or improper site preparation or maintenance.
NO OTHER WARRANTY IS EXPRESSED OR IMPLIED. HP SPECIFICALLY DISCLAIMS THE IMPLIED
WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
EXCLUSIVE REMEDIES
THE REMEDIES PROVIDED HEREIN ARE BUYER'S SOLE AND EXCLUSIVE REMEDIES. HP SHALL NOT BE
LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, ORCONSEQUENTIAL DAMAGES, WHETHER
BASED ON CONTRACT, TORT, OR ANY OTHER LEGAL THEORY.
ASSISTANCE
Product maintenance agreements and other customer assistance agreements are available for Hewlett-
Packard products.
For any assistance, contact yournearest Hewlett-Packard Sales andService Office. Addresses are provided at
the back
of this manual.
):
l I
( } )

OPERATING AND SERVICE MANUAL
HP 5384A and HP 5385A
Frequency Counters
SERIAL PREFIX: 2436A
This manual applies to Serial prefix 2436A, unless
accompanied by a Manual change Sheet indicating
otherwise.
©Copyright HEWLETT-PACKARD COMPANY 1985
5301 STEVENS CREEK BOULEVARD, SANTA CLARA, CA 95051
OTS LIBRARY
111111111111111111111111111111111111111111111111111111111111
2400011436
AOND
Printed: FEB 1987
MANUAL PART NUMBER 05384-90006
~ ·-----~•Microfiche Part Number 05384-90007
FJ/o- HEWLETT
~~PACKARD

HP 5384A and HP 5385A
Table of Contents
II
TABLE OF CONTENTS
Section Title
GENERAL INFORMATION
1-1 . Introduction ............................ . . .. ........ .... .. .
1-2 . Manual Summary ........ . ........ .. .. . ........ .. ... ... ... .
1-5 . Specifications ............. .... . .. .. ................. .. .... .
1-7. Safety
Considerations ..... .... .......... ..... ........ .. .... .
1-10. Desc ription .... . . .. ........ . .............. .. . . .. ... .. .. .. . .
1-27.
Option s .................................................. .
1- 33. In s trument Identifi ca tion ................ . ... . ........... . .. .
1-35.
Acce sso ries ........................ . .......... ... ....... . . .
1- 3 9. Recommended T es t Equipment .......................... . .. .
Page
1-1
1-1
1-1
1-1
1-1
1-1
1-2
1-2
1-2
1-2
II INSTAllATION . . . . . . .. . . . . .. . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . .. .. 2-1
2-1 . Intr od u ct ion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2-3. . U npacking and In spec tion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2-5. Prepa ration for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2-6. Power Requirement s .. .. . . . . . . . . . . . . . . . . .. . . . . . . . . .. . . . . .. . 2-1
2 -B. Line Voltage Selection . .. . . . . .. . . . . . . . . . . . . . . . . . . . . .. . . . . .. . 2-1
2-10. AC Line Fuse Selection . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . 2-1
2-12.
DC Fuse Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2-15.
Power Cable . .. . . . . . . .. . . . . . .. . . . . . . . . . . . . . . . . . . . . . .. . . . . 2-1
2-17. HP-IB Interconne ct ions .. . . . . .. . . . . . . . . . . . . . . .. . . . . . . . . . . . 2-2
2-21. HP-IB Talk/Listen Address Switch . . . . . . . . . . . . . .. . . . . . . . . . . . 2-2
2-
23. HP-IB Description . . . . .. . . . . . . . . . . . . . .. . . . . . . . . . . . . . .. . . . . 2-4
2-25. HP-IL
Interconn ec tions t Option 00 3) . . . . . . . . . . . . . . . . . . . . . . . 2-4
2-27. HP-IB
De scri ption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2-29. C
hannel B Input Fu se .. . . . . . . .. . . . . .. . . . . . . . . . . . . . . . . . . . . . 2-4
2-31.
Operating Environment .. . . . . .. . . . . . . .. . . . . . . . . . . . . . . . . . . . 2-4
2-
35. Storage and Shipment . . .. . . . . . .. . . . . . .. . . . . . . . . . . . . . . . . . . . . 2-4
2-36.
En v ironment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2-39. Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . .. . . . 2-5
2-42.
Wh ere to Ship Your Unit for Re pair . . . . . .. . . . . . . . .. . . . . . .. . . . 2-5
2-44.
Fi e ld In sta llation of Options .. . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . 2-6
2-
48. Option 001 (TCXO ) Installation . . . . . . . .. . . . . . . .. . . . . . . .. . . . 2-6
2-50. Option 003 HP-IL Installation . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . 2-6
2-52.
Option 004 Oven Oscillator In sta llation . . . . . . . . . . . . . . . . . . . . 2-7
2-
54 . Option 005 Battery Pack In sta llation . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Ill OPERATION AND PROG RAMMING . . . .. . . . . . .. . . . . . . . .. . . . . . .. . . . . 3-1
3-1.
Intr o du c tion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 -1
3-3. Op e rating Characteristics . . . . . . .. . . . . . . .. . . . . . . . . . . . . . . .. . . . 3-1
3-6.
Operating In s tru c tions . . . . .. . . . . .. . . . . . . .. . . . . . . . . . . . . . . .. . . 3-1
3-10. Operator's Maint e nance . . . . . . . . .. . . . . . .. . . . . . . . .. . . . . . . . . . . 3-1
3
-1 3. General Operation Information . . . . . . . . . . .. . . . . . . . . .. . . . . .. . 3-1
3-14.
Introduction . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . 3-1
3-16. Display . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3-19. K
ey b oar d . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3
-22. Input s . .. . . . . . . . . . . . .. . .. . . . . . .. . . . . . .. . . . . . . . . . . . . . . . . . . . . 3-2
3-24.
Power-Up /Self- Check .. . . . . . .. . . . . . .. . . . . . . . . . . . . . . . . . . . . 3-2
3
-28 . Error Messages . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . .. . . . . . . .. . . . 3-2
3-35.
Front Panel Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
3-
38. ON -ST BY . . . . . . . . . . . . . . . . .. . . . . .. . . . . . . .. . . . . . . . . . . . . . . . . . . 3-3

•
•
•
TABLE OF CONTENTS (Continued)
Section Title
HP 5384A and HP 5385A
Table
of Contents
Page
Ill OPERATION AND PROGRAMMING (Continued)
IV
v
3-40. A Channel . . .. .. . . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . . .. . . . . .. . . . 3-3
3-50. B Channel and A&B . . . .. . . . . . . . . . . . . . .. . . . . . .. . . . . . . . . . . . 3-4
3-56. Gate and Display Digits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
3-67. Reset/Local and Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
3-73. Inputs . . . .. . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . . . . . 3-6
3-81. Rear Panel Features . .. . . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . . . 3-6
3-91.
3-93.
3-95.
3-96.
3-101.
3-102.
3-104.
3-107.
3-111.
3-113.
3-118.
3-121.
3-125.
3-130.
3-131 .
3-136.
3-138.
3-140.
3-143.
3-147.
3-149.
3-152.
3-159.
3-161.
3-163.
3-165.
3-167.
External DC
Operation .. . . . . . . . . . . . . . . .. . . . . . . . . . . .. . . . . . . . 3-7
Making Frequency and Period Measurements . . . . . . . . . . . . . . . . 3-7
Remote Programming
...................................... 3-11
Introduction ............................................. 3-11
Interface Description . . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . 3-11
Hewlett-Packard Interface Bus (HP-IB) ..................... 3-11
Hewlett-Packard Interface Loop (HP-IL) .................... 3-11
Interface Functional Overview . . .. . . . . . . . . . . . . . . .. . . . . . . . . . . . 3-12
Interface Systems Terms ..................................... 3-12
Address Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Interface Commands . . .. . . . . . . . . . . . . . . .. . . . . . . . . . . .. . . . . . . . 3-13
Interface Capabilities ....................................... 3-14
Meta Messages . .. . . . . . . . . . . . . . .. . . . . . . . . . . .. . . . . . . . . . . .. . . . 3-14
SRQ, SRQ Mask, and Status Byte
............................ 3-15
SRQ and Status Byte . . .. . . . . . . . . . . . . . . .. . . . . . . . . . . .. . . . . . . 3-15
Service Request Mask . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . 3-16
Device
Dependent Commands .............................. 3-16
Output Formats . .. . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . . . . . . 3-16
Numeric Entry ........................................... 3-17
IN Initialize . .. . . . . . . . . . . . . .. . . . . . . . . . . . .. . . . . . . . . . . . .. . . . 3-17
WAO and WA1 Wait to Send Mode Off/On ................. 3-17
DR (string) Remote Display ............................... 3-18
DL Display Local . .. . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . . . . . 3-18
ID and Sl Send Device ID ................................. 3-18
SE Send Error . . .. . . . . . . . . . . . . .. . . . . . . . . . . .. . . . . . . . . . . . . .. 3-18
LCD Character
Set . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . . . 3-18
Program Examples .. . . . . . . . . . . . . . . .. . . . . . . . . . . . .. . . . . . . . . . . . 3-18
PERFORMANCE TESTING
4-1
4-1. Introduction . . . .. . . . . . . . . . . . .. . . . . . . . . . . . .. . . . . . . . . . . . .. . . . 4-1
4-3. Equipment Required . . . .. . . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . 4-1
4-5. Test Record . . . . .. . . . . . . . . . . . .. . . . . . . . . . . . .. . . . . . . . . . . . . .. . . 4-1
4-7. Error Messages . . .. . . . . . . . . . . . . .. . . . . . . . . . . . .. . . . . . . . . . . . .. . 4-1
4-9. Performance Test . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . .. . . . 4-1
ADJUSTMENTS . . . .. . . . . . . . . . . . .. . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . . 5-1
5-1. Introduction . . . .. . . . . . . .. . . . . . . .. . . . . . . . . . . . . . . .. . . . . . . . . . . 5-1
5-4. Equipment Required . . .. . . . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . 5-1
5-6. Adjustment Locations . . .. . . . . . . . . . . . . . . .. . . . . . . . . . . . .. . . . . . . 5-1
5-8. Safety Considerations . . .. . . . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . 5-1
5-10. HP 5384A/HP 5385A Adjustment Procedures . . . . . . . . . . . . . . . . . . 5-1
5-11. HP 5384A/HP 5385A +3 Volt DC Adjustment Procedure . . . . .. 5-1
5-13. HP 5384A/HP 5385A Channel A Input Amplifier
Adjustment Procedure . . . . .. . . . . . . . . . . . . . . . . . . . . . .. . . . . . . 5-2
iii

HP 5384A and HP 5385A
Table of Contents
Section
IV
VI
VII
VIII
iv
TABLE OF CONTENTS (Continued)
Title Page
ADJUSTMENTS
(Continued)
5-15. HP 5384A Channel B Input Amplifier Adjustment
5-17.
5-19.
5-21.
5-25.
5-26.
Procedure ............................................. .
HP 5385A Channel B Input Amplifier Adjustment
Procedure ............................................. .
Standard Oscillator
Adjustment Procedures ................ .
TCXO Adjustment Procedure ............................. .
Oven Oscillator Adjustment Procedure ................... .
HP 5384A/HP 5385A Battery Charger Adjustment
Procedure ............................................. .
5-3
5-3
5-5
5-5
5-7
5-7
REPLACEABLE PARTS
6-1
6-1
6-1
6-1
6-1
6-1
6-1. Introduction .............................................. .
6-3. Abbreviations
............................................. .
6-5. Replaceable Parts
Lists ..................................... .
6-9.
Ordering Information ..................................... .
6-12.
Direct Mail Order System .................................. .
MANUAL CHANGES .............................................. . 7-1
7-1
7-1
7-1. Introduction ............................... ~ .............. .
7-3.
Manual Changes .......................................... .
SERVICE . . . . .. . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . .. . . . . . . . . 8-1
8-1.
8-3.
8-5.
8-7.
8-11.
8-16.
8-18.
8-20.
8-21.
8-23.
8-25.
8-27.
8-32.
8-35.
8-37.
8-39.
8-40.
8-45.
8-52.
8-65.
8-125.
8-129.
8-137.
8-139.
8-144.
8-151.
8-152.
8-167.
Introduction . . . .. . . . . . . .. . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . 8-1
Schematic Diagram Symbols and Reference Designators . . . . . . . 8-1
Reference Designations . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . .. . . . 8-1
Identification Markings on Printed Circuit Boards .............. 8-1
Safety Considerations . . .. . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . .. . . . 8-2
Safety Symbols . . . . . .. . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . .. . . . . 8-2
Recommended Test Equipment .. . . . . . . . . . . . . . . . . . . . . . . .. . . . . 8-2
Service Aids . . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . .. . . 8-2
Pozidriv Screwdrivers . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . .. . . 8-2
Nut Drivers . . . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . .. . . . 8-2
Service Aids
on Printed Circuit Boards . . . .. . . . . . . . . . . . . . . . . 8-3
After Service Safety Checks . . .. . . . . . . . . . . . . . . . . . . . . . . .. . . . 8-3
HP 5384A and HP 5385A Disassembly Procedures . . . . . . . . . . . . 8-3
Assembly Identification . . . . . . .. . . . . . . . .. . . . . . . . . . . . . . . . . . . 8-3
Logic Symbols . . .. . . . . . . .. . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . 8-5
Explanation of New Logic Symbols . . . . .. .. . . . . . . .. . . . . . . . . . . . 8-5
Introduction . . . . . .. . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . .. 8-5
Symbol Composition . .. . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . 8-5
Qualifying Symbols . .. . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . 8-7
Dependency Notation . . . .. . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . 8-10
Bistable Elements . . . .. . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . 8-17
Coders . . . .. . . . . . . . .. . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . 8-18
Use of Binary Grouping to Produce Affecting Inputs . . . . . . . . 8-19
Sequence
of Input Labels . . . . .. . . . . . . . . . . . . . . . . . . . .. . . . . . . 8-20
Sequence of Output Labels . . .. . . . . . . . . . . . . . . . . . . . . . . .. . . . 8-20
Theory of Operation . . .. . . . . . . .. . . . . . . . .. . . . . . . . . . . . . . . . . . . 8-21
Overall Counter Operation . .. . . . . . . . . . . . . . . . . . . . .. . . . . . . . 8-21
Signal Descriptions . . . . .. . . . . . .. . . . . . . . . . . . . . . . . . . . . .. . . . . . . 8-23
•
•

•
•
•
TABLE OF CONTENTS (Continued)
Section Title
HP 5384A and HP 5385A
Table
of Contents
Page
VIII SERVICE (Continued)
8-169. Detailed Theory of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-23
8-177.
HP 5384A Channel B ...................................... 8-24
8-182. HP 5385A
Channel B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-25
8-193. HP
3870 Microcomputer ........................... , ...... 8-25
8-200. Interpolator Technique ................................... 8-26
8-207. HP-IB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-27
8-213. HP-IL
...................................................... 8-28
8-230.
8-246.
8-258.
8-259.
8-263.
8-265.
8-269.
8-272.
8-275.
8-278.
8-283.
8-286.
8-288.
8-289.
8-293.
8-301.
8-303.
8-309.
8-311.
8-313.
8-315.
8-318.
8-320.
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-30
Battery Pack Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-31
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-32
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-32
Built-1n Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-33
Accessing
the Built-In Diagnostics ......................... 8-33
Power-Up Self-Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-33
CPU
Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-33
1/0 Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-33
Interpolator, Long and Short Calibration ................... 8-34
Microprocessor Port Check . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . 8-34
Manual Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-34
Power Supply
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-35
Oscillator Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . 8-35
Input Amplifier Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-36
Battery Pack
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-41
Battery Charger Board Troubleshooting . . . . . . . . . . . . . . . . . . . . 8-41
Battery Load Current Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-41
Shut-Down Voltage Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-42
Battery
Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-42
Charge State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-42
Capacity
Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-42
HP-IB Interface Assembly (AS Board) Troubleshooting ....... 8-43
v

HP 5384A and HP 5385A
List of Tables
LIST OF TABLES
Title Title
1-1. Models HP 5384A and HP 5385A Specifications ...................... .
1-2.
Recommended Test Equipment .................................... .
2-1. HP-IB
Cable Descriptions ......................................... .
2-2. HP-Il
Cable Descriptions .......................................... .
3-1.
Power-Up Initialize States ......................................... .
3-2. Error Messages
................................................... .
3-3. Units Display Format
.............................................. .
3-4. Address Selection
................................................. .
3-5.
Interface Capabilities ............................................. .
3-6.
Meta Messages ................................................... .
3-7.
Meta Messages and Controller Commands ......................... .
3-8.
HP 5384A and HP 5385A Status Byte ................................ .
3-9.
Instrument Command Set ......................................... .
3-10.
LCD Character Set ................................................ .
4-1.
Performance Test ................................................. .
5-1.
Adjustments ..................................................... .
S-2.
Approximate Offset Determination Table ........................... .
6-1.
Abbreviations and Reference Designations ......................... .
6-2.
HP 5384A Replaceable Parts ....................................... .
6-3.
HP 5384A with TCXO Replaceable Parts ............................. .
6-4.
HP 5384A with Oven Oscillator Replaceable Parts ................... .
6-5. Front Panel Display Assembly
Replaceable Parts ..................... .
6-6. Battery Pack
Replaceable Parts ..................................... .
6-7.
HP-Il Replaceable Parts ........................................... .
6-8. HP-IB
Replaceable Parts ........................................... .
6-9.
HP 5385A Replaceable Parts ....................................... .
6-10. HP 5385A with
Oven Oscillator Replaceable Parts ................... .
6-11.
Manufacturers Code list .......................................... .
6-12.
HP 5384A Replaceable Mechanical Parts ............................ .
6-12.
HP 5385A Replaceable Mechanical Parts ............................ .
7-1.
Manual Backdating ............................................... .
8-1. Assembly Usage
.................................................. .
8-2.
General Qualifying Symbols ....................................... .
8-3.
Qualifing Symbols for Inputs and Outputs .......................... .
8-4. Symbols Inside
the Outline ........................................ .
8-5.
Summary of Dependency Notation ................................. .
8-6. Signal Descriptions
............................................... .
8-7.
Power Supplies and Associated Assemblies ......................... .
8-8. Battery Pack
Troubleshooting ...................................... .
8-9. Battery
State-of-Charge ........................................... .
vi
•
Page
1-3
1-5
2-2
2-4
3-2
3-3
3-7
3-13
3-14
3-15
3-15
3-16
3-17
3-25
4-1
5-1
5-6
6-2 •
6-3
6-8
6-13
6-18
6-19
6-20
6-21
6-22
6-28
6-33
6-34
6-36
7-1
8-3
8-6
8-7
8-9
8-10
8-23
8-35
8-41
8-43 •

HP 5384A and HP 5385A
List of Figures
Figure
1-1.
2-1.
2-2.
2-3.
2-4.
2-5.
3-1.
3-2.
3-3.
3-4.
3-5.
3-6.
3-7.
3-8.
3-9.
3-10.
3-11.
3-12.
LIST OF FIGURES
Title
Models HP 5384A a nd HP 5385A Fr equency Counters
and Accessories ...................................... .
Line Voltage Selection . ... .. . .. ....... ... ......................... .
Power Cable HP Part Number versus Mains Plugs Available ... .. .... ..
Hewl ett -Packard Interfa ce Bus Conn ect io ns ......................... .
Typi ca l HP-IL In terface Connection ..... .... .................. . .... .
Details
of Input Co nnector J2 a nd Fu se Mounting .......... .. ....... .
Front Panel ON /ST BY Switch ..................... . ................ .
Front Panel A Ch anne l Fu nctio n Keys . .... ....... .................. .
Front Panel Band A& B Function Keys ... ................... .. ...... .
Front Panel Gate Se lection Display Digits Keys ...... .. ... ..... ... ... .
Front Panel R eset/Loc al and Check Keys ............ ... ....... . .... .
Front Panel Input s Sec ti on ....... . ..... ... ..... ....... . ...... ... . .. .
Front Panel Indicator s ...................... .. ....... .... ..... . .... .
Front Panel Controls ................................ . .. ... . ..... .. .
Rear Panel Featur
es ............................................... .
HP 5384A and HP 5385A Address Switches Shown in Addre ss 31 ..... . .
Typical HP-IL S ys tem Addre ss ing ................. ..... ............. .
Example 5
Set-Up ....... .......... . . ...... .... .... ...... .... .. . . .. .
Page
1-0
2-1
2-2
2-3
2-4
2-5
3-3
3-3
3-4
3-5
3-5
3-6
3-8
3-9
3-10
3-12
3-13
3-22
5-1. Assembly
Adjustment Lo cato r . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5-2. Channel A Input Amp lfi er Adjustm e nt Setup .. . . . . . . . . . . . . . .. . . . . . . . . 5-3
5-3.
Input Amplifier Adjustment Waveform . .. . . . . . .. . . . . . . . . . . . . . . .. . . . . 5-3
5-4. HP 5384A
Channel B Input Amplifier Adjustment Setup . . . .. . . . . . .. . . . 5-4
5-5. HP 5385A
Channel B Inpu t Amplifier Adjustm ent Se tup . . . . . . . . . . . . . . . 5-4
5-6.
Standard, TCXO and Oven Osci ll ato r Test Setup .. . . . . . . .. . . . . . . . . . . . . 5-5
5-7. TCXO and Standard Oscillator Adju st ment . . . . . . .. . . . . . . .. . . . . . . .. . . . 5-6
5-8. Standard
Oscillator Coarse and F in e Adjustment Location . .. . . . . . .. . . . 5-6
5-9.
Fas t Charge C urr ent Adju s tm ent Setup . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
5-10. Fast Charge Thr es hold Adju s tmen t Setup .. .. . . . . . . .. . . . . . . . . . . . . .. . . 5-8
6-1.
6-2. HP 5384A
Exploded View
HP 5385A Exploded View
6-35
6-37
8-1. Schematic Di agram Not es . . . . . .. . . . . . .. . . . . .. . . . . . . . . .. . . . . . . . . . . . . 8-4
8-2. Test Setup for A3C37 and C23 Selection .. . . . . . . . . . . . . . . . . . . . . . .. . . . . 8-5
8-3. Illu s trati on of Commo n- Contro l Block . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . 8-6
8-4. Illu s tration of Common - Ou tpu t Element . . . . . . . . . . . . . . . . . . .. . . . . . . . . . 8-6
8-5. G D epende ncy Between Input s .... .... ...... .... .. ...... .... ...... . 8-11
8-6. G Dep e ndency Between Output s and Input s . . ... . .................. 8- 11
8-7. G Dep e ndency wit h A Dynamic Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-11
8-8.
OR 'e d Affecting Input s ....... . ......... . .......... . .... ..... ...... 8-12
8-9. Substi
tution for Number s ......... . ... . .. .... .. . ........... ..... ... 8-12
8-10. V i ORl Dependency ............................................... 8 -1 2
8-11. N [Negate, X-ORI
Dependency .... .... ..... .. ............... ...... . 8-12
8-12. Z ( Int erconnectio n) D epe nd ency .. ... ............... .. . ............ 8-13
8-1 3. X {Transmi ss ion) Dependency ............................... ..... ... 8-14
8-14. C ( Co nt ro l! Dependency .....................• . . . . ... ..... .... .... . 8-14
vii

HP 5384A and HP 5385A
List
of Figures
LIST OF FIGURES (Continued)
Figure
Title
Page
viii
8-15.
8-16.
8-17.
8-18.
8-19.
8-20.
8-21.
8-22.
8-23.
8-2
4.
8-25.
8-26.
8-2
7.
8-28.
8-29.
8-30.
8 -3 1.
8-32.
8-33.
8-34.
8-35.
8-36.
8-37.
8- 38 .
8-
39.
8-40.
8-41.
8-42.
8-4
3.
8- 44.
8- 45 .
B-46.
8-4 7.
B- 48.
B-4
9.
8-50.
8-50.
8-51.
8-51.
8-52.
8-
53.
8- 54 .
S iSet) and R (Reset) Dep e ndencies .... .. ...... . ....... . ...... .. .... 8-14
EN (Enable) D epende ncy ............ ... ... ... ... .... . . ........ .. .. . 8-15
M (
Mod e) Dep ende ncy ........................ , ........... .. . . .... 8- 15
Type of Flip-Flop Determin ed by Mode ........... ... ... .. . ..... .. . . 8-16
Di s abling an Output of the Common Contro l Bl ock . .............. ... 8-16
Determining an Ou tput Function . ..... .. .... ... . .... ... .... ... . .... 8-16
Dependent Relat io nship Affected by M ode ... , .. . . . . . . . .. . . . . . .. . . . . 8-16
A (
Addre ss ) De pend en cy ..... . .... .... .. .... ..... .... ... ; . . . .... ... 8-17
RAM E xa mple ..... .... ... ... .... , ... . ... . ... ... .... .. . ............ 8-17
Four Types of Bi sta ble Cir cuits .. .... ... ...... .... ... .. . .... . .. ..... . 8-18
Co de Ge ner al Symbo l . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-18
An X- Y Code Converter . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8- 18
An X-Octal Cod e Co nv erter ... . .. ..... . .... ..... ...... . ... ..... ... . 8-19
Cod er P rod ucin g Sev eral Dependen c ie s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8- 19
Co de P rodu cing One Type of Dependen cy .. ..... ... ..... .... ....... 8-19
Use
of Binary Grouping Sy mbol . . ..... ... ..... . , .... .. . . .... ........ 8-19
Input Lables . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-20
Fac torin g Inpu t Lables . .. .... . .. ..... ... ... ..... ... ...... . ..... ... . 8-20
Placement of Thr ee-State Sy mbol s .. . ..... .... , . .. . . .. . ..... , .. . . . . . 8-20
Output Labels . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . .. . . . . 8-21
Fac torin g Output Labels . . . . . . . . . . .. . . . . . . . . . . . .. . . . . . . . . . . . . •.. . . . . 8-21
HP 5384A/HP 5 385 A Block Diagram ......... .. .............. ... ... .. 8-22
lnt erplator T im ing Diagr am ................... , , ............. . .. . . . . 8-26
Ex pand ed Inte rpo lat or Error Pul se . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8- 26
Sho rt and Long C alibrati on Puls es Example . . . . .. ... . . .. . ..... .... .. . 8-27
Sa mple HP-IL Fra me . . .. . . . . . . . .. . . . . . .. . . . . . . . . . . . . . . .. . . . . . .. . . . . 8-29
HP-IL Bit E ncoding ........ ....... ... ... .. ..... . .... ............ .... 8- 29
Ope n Circuit Output Wavefo rm ...... . ........ . . ...... . .... , ..... .. 8- 30
Sta ndard O sc illator Waveform . . .. . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . 8-35
Opti on 001 (T CXO ) Oscillator Wa ve form . . . . . . . . . . . . . . . . . . . . . . . •. . . . 8- 36
HP 5384A/ HP 538SA Chann el A Waveform s ... . . .. .... . ..... ... ...... 8-37
HP 5384A C hann el B Waveform s .. ........ ..... . .............. .. ... . 8-38
HP 5385A Channel B Wav efo rm s . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . 8-40
All Signatures for the HP 5384A a nd HP 8385A M ot herb oa rd .. . . . .... . 8-44
T
ro ubl esh oot in g F lowch a rt .... ..... .. . ... ... ..... . . .... . .. . ........ 8-45
HP 5384A A1 Mothe rboard Assembly (Sheet 1 of 21 ... . .......•......• 8-47
HP 5384A A1 Moth e rbo ard As se mbl y ( Sh eet 2 of 2) ... . ...... .. ... .... 8-49
HP 5385A A1 M othe rb oard Assembly ( Sh eet 1 of 2) ..• ..... ...•• • •.... 8-51
HP 5385A A1 M o therboard As se mbl y (Sh ee t 2 of 2) .. . ... .. ... ... ..... 8- 53
A4 HP-IB Interface Assembly . .. . ..... ... . .. . . .. .... . .. ..... .... .. .. 8- 55
AS HP-1L Interf ace Assembly .. .. . . . . . . . . . . . . . . . . . . .. . . . . . . .. . . . . .. . . 8- 57
A3 Battery Pack A ss embl y . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-59

•
•
•
SAFETY CONSIDERATIONS
GENERAL
HP 5384A and HP 5385A
Safety Considerations
This product and related documentation must be reviewed for familiarization with safety markings and
instructions before operation.
This product is a Safety Class I instrument (provided with a protective earth terminal).
BEFORE APPLYING POWER
Verify that the product is set to match the available line voltage and the correct fuse is installed. Refer
to Section II, Installation.
SAFETY EARTH GROUND
An uninterruptible safety earth ground must be provided froni the mains power source to the product
input wiring terminals or supplied power cable.
m OR.L
SAFETY SYMBOLS
Instruction manual symbol; the
product will be marked with this
symbol when it is necessary for the
user to refer to the
instruction
manual.
Indicates hazardous voltages.
Indicates terminal is connected
to chassis when such connection
is not apparent.
Alternating current.
Direct current.
I I The WARNING sign denotes a
WARNING haz&rd. It calls attention to a
procedure, practice,
or the like,
which, if not correctly performed or adhered to,
could result in personal injury. Do not proceed
beyond a WARNING sign until the indicated
con-
ditions are fully understood and met.
~ ~::ar~~~T~~~~ ~i~~nt~~~~:~s a~
operatmg procedure, pract1ce, or
the like, which, if not correctly performed or
adhered to, could result in damage to or destruc-
tion
of part or all of the product. Do not proceed
beyond a CAUTION sign until the indicated con-
ditions are fully understood and met.
SAFETY INFORMATION
I WARNING I
Any interruption of the protective grounding conductor (inside or outside the instrument) or discon-
necting the protective earth terminal will cause a potential shock hazard that could result in personal
injury. (Grounding one conductor of a two conductor outlet is not sufficient protection.)
Whenever it is likely that the protection has been impaired, the instrument must be made inoperative
and be secured against any unintended operation.
If this instrument is to be energized via an autotransformer (for voltage reduction) make sure the common
terminal is connected to the earthed pole terminal (neutral) of the power source.
Instructions for adjustments while covers are removed and for servicing are for use by service-trained
personnel only. To avoid dangerous electricshock, do not perform such adjustments or servicing unless
qualified to
do so.
For continued protection against fire, replace the line fuse(s) only with 250V fuse(s) of the same current
rating and type (for example, normal blow, time delay). Do not use repaired fuses or short circuited
fuseholders.

HP 5384A and HP 5385A
General Information
Model HP 5384A
Model HP 5385A
Power Cord
~
" .. ~ ....
'"""'
,.,..,.;,,,.,, ''"'!'''
Figure 1-1. Models HP 5384A and HP 5385A Frequency Counters and Accessories
1-0
•
•
•

•
•
•
HP 5384A and HP 5385A
General Information
SECTION I
GENERAL INFORMATION
1-1. INTRODUCTION
1-2. This manual provides you with information
pertaining to the installation, operating, program-
ming, performance tests, adjustments, and main-
tenance of the Hewlett-Packard Models 5384A and
5385A Frequency Counters, shown
in Figure 1-1. ·
1-3. MANUAL SUMMARY
1-4. The manual is divided into eight sections, each
covering a particular
topic for the operation of the HP
5384A and HP 5385A Frequency Counters. The topics
by section
number are:
Section
II
Ill
IV
v
VI
VII
VIII
Topic
General Information
Installation
Operation and Programming
Performance
Tests
Adjustments
Replaceable Parts
Manual Changes
Service
1-5. SPECIFICATIONS
1-6. The instrument specifications and option speci-
fications are listed
in Table 1-1. These specifications
are performance standards or limits against which the
instrument may be tested.
1-7. SAFETY CONSIDERATIONS
1-8. This is a Safety Class I instrument. This instru-
ment has been designed and tested according to
international safety requirements.
1-9. This manual contains
information, cautions,
and warnings
which must be followed by operating
and service personnel to ensuresafe operation and to
retain the instrument in safe condition.
1-10. DESCRIPTION
1-11. The Hewlett-Packard Models 5384A and 5385A
are
frequency counters that make frequency and
period measurements. The HP 5384A has a frequency
range of 10 Hz to 225 MHz, and the HP 5385A has a
frequency range of 10Hz to 1000 MHz. Bothcounters
are microcomputer based instruments with adata bus
port for remote operation through either HP-IL or
HP-IB.
1-12. Both counters have "A" and "B" input chan-
nels with BNC type connectors.
1-13.
Above the "A" and "B" input connectors is a
dual purpose control that allows you to either set the
trigger level of Channel A or adjust the input attenu-
ation of Channel B.
1-14. A 100 kHz low pass filter can be toggled in or
out of the Channel A signal path on either counter.
1-15. Measurement display and mode annunciators
are shown
on a 12-character alphanumeric liquid
crystal display (LCD). Frequencyand period measure-
ments are displayed
in engineering format, with three
alpha characters used to designate units, e.g., MHz.
The display will also give you brief messages and
diagnostic prompts.
1-16. The
HP 5384A and HP 5385A are designed so
you may either rack mount or stack them.
1-17. A 10 MHz reference oscillator output is in-
cluded in both counters. The connector for the 10
MHz output may also be used as an external10 MHz
reference oscillator input connection.
1-18. Option 001 is a temperature compensated
crystal oscillator (TCXO). TheTCXO is an option in the
HP 5384A and standard in the HP 5385A.
1-19. A jack
for connecting external de power is pro-
vided on the rear panel and Option 005 battery pack
can be installed
to provide mobility.
1-20. Option 003 is the Hewlett-Packard Interface
Loop (HP-IL) for remote control of the counters by
battery operated controllers such
as the HP41C/CV
hand held controller.
1-21. Option 004 is an ovenized oscillator that
provides a high stability
time base giving substan-
tially higher accuracy over variations in time and
temperature.
1-22.
Option 005 is a battery pack that provides
portable operation of the HP 5384A or HP 5385A.
1-23. HP-IB is the Hewlett-Packard Interface Bus for
remote control of the counters by computers and
controllers. It is a standard feature in the instrument.
1-1

HP 5384A and HP 5385A
General
Information
1-24. The HP-IB, (Hewlett-Packard Interface Bus) is
Hewlett-Packard's implementation of IEEE Standard
488-1978 and ANSI Standard
MC 1.1. HP-IB is a high-
speed parallel interface bus. All devices on the bus are
capable
of being addressed at one time. However,
only one device mayrespond atatime. A controller is
used to command which device responds. (The HP
5384A
or HP 5385A with HP-IB would make measure-
ments and
return data upon commands from a
controller.)
1-25. The counter can be configured for either
HP-IB or HP-IL, not both.
1-26. HP-IB or HP-IL allows the HP 5384A and HP
5385A to output data to other devices or, on a more
complex level, respond to remote programming in-
structions to make a specific type of measurement,
trigger that measurement, then read the result and
send the reading back
to the controller, or to another
device on the interface.
1-27. OPTIONS
1-28. Option 001 is a Temperature Compensated
Crystal Oscillator (TCXO)
for HP 5384A. The TCXO is a
10 MHz oscillator, capable of making minor fre-
quency corrections to compensate for temperature
variations.
1-29.
Option 003 is HP-IL, (Hewlett-Packard Inter-
face Loop). HP-IL is a low cost, two-wire serial inter-
face that permits communications from one device to
another. As the name implies, the HP 5384A or HP
5385A is connected in a serial loop structure. Data or
information, in the form of digital messages, travels
from one device to the next in the loop. If the
information is not intended for the counter, the
counter merely passes the information on to the next
device in the loop. If the information is intended for
the counter, the counter responds as directed by the
information.
1-30. Option 004 is an ovenized oscillator that gives
the HP 5384A and HP 5385A increased accuracy by
providing a more stable time base reference signal.
The oven maintains
the crystal at a constant elevated
temperature for increased stability over the ambient
temperature range.
1-31.
Option 005 Battery Pack is a lead acid type
battery that provides at least 3 hours of operation
while the counter is disconnected from the power
line. Operation time is reduced to approximately
1-hour when operated with HP-IB.
1-2
NOTE
If an instrument contains an Option 005 Battery
Pack as well as the ovenized oscillator, the
ovenized oscillator
will draw power from the
battery pack if no external ac or de power is
applied. Power will be drawn from the battery
pack
continuously with the instrument in either
ON or STBY (standby) positions.
1-32. The battery pack
will be recharged in 16 hours
if the counter is in the standby mode and either the
line cord is attached or external de is applied through
the rear panel jack. The battery will trickle charge
while the counter is being used and is connected to
either an ac power line or external de.
1-33. INSTRUMENT IDENTIFICATION
1-34. Hewlett-Packard instruments have a 2-section,
10-character serial number (OOOOAOOOOO), which is
located on the rear panel. The four-digit serial prefix
identifies the instrument changes.
If the serial prefix of
your instrument differs from thatlisted on thetitlepage
of this manual, there are differences between this
manual and
your instrument. Instruments having
higher serial prefixes are covered with a
"Manual
Changes" sheet included with this manual. If the
change sheet
is missing, contact the nearest Hewlett-
Packard Sales and Support Office listed at the back of
this manual. Instruments having a lower serial prefix
than that listed
on the title page are covered in Section
VII.
1-35. ACCESSORIES
1-36. The accessory supplied is a detachable power
cord 229 em long (71/2 feet), part number 8120-1378.
1-37. Side
Handle: 5061-1171
1-38. Rack Mount Kits:
Rack
Mount Kit, HP Part Number 5060-0173.
Locking Rack Mount Kit for two HP 5384A/
HP 5385A modules, HP Part Number 5060-0174.
1-39. RECOMMENDED TEST
EQUIPMENT
1-40. The test equipment listed in Table 1-2 is recom-
mended for use
during performance tests, adjustments,
and troubleshooting. Substitute test
equipment may be
used if it meets the required characteristics listed in
the table.
•
•
•

•
•
•
HP 5384A and HP 5385A
General Information
Table 1-1. Models HP 5384A and HP 5385A Specifications
GENERAL
Check: 10 MHz Self-test
Gate Times: 0.1, 1,
or 10 seconds, (NOMINAL).
Display: 12-digit alphanumeric liquid crystal.
Display Digits (variable): Frequency, 3 to 11;
Period, 3
to 8.
Timebase Output: 10 MHz, 25 mV pk-pk (NOMINAL)
into 50 ohm load.
External Timebase Input: 10 MHz, .5V rms into
500 ohms; 15V (de- ac pk) max.
Operating Temperature: 0° to 50°C
Power Requirements:
AC Operation: Selectable 18 VA max.
115V + 10%, -25%, 48-66 Hz
230V + 10%,-15%48-66 Hz
115V ±10%, 380-420 Hz
DC Operation: 9- 15V de, 1.0 A max.
Weight: Net, 2.2 kg (4.8 lbs.); Shipping, 4.1 kg (9 lbs.)
Dimensions: 216 mm W X 88 mm H X 276 mm D
(8:}'a X 3V2 X 10¥4 in.)
INPUT CHARACTERISTICS
(Channel A HP 5384A/HP 5385A)
Range: 10 Hz to 100 MHz
Sensitivity: (MAN LEVEL) off
15 mV rms sine wave 50 Hz to 100 MHz
25 mV rms sine wave 10 Hz to 50 Hz
45 mV pk-pk 5 ns minimum pulse width
Dynamic Range: 45 mV to 4V pk-pk X attenuator
setting.
Coupling: AC
lmpedence:
X1: 1 Mn NOMINAL II< 25 pF
X20: 500 kn NOMINAL II < 25 pF
Attenuator: X1 or X20 NOMINAL,
X20 increases to X40 NOMINAL below 50 Hz.
Low
Pass Filter: 100kHz NOMINAL 3 dB point
Trigger Level:
(MAN LEVEL) ON: variable from -0.1V to +0.1V X
attenuator setting
about average signal value.
(MAN LEVEL) OFF: automatically set to average
A value of signal.
.A. Damage Level:
X1:
10- 200 Hz 350V (de+ ac peak)
0.2- 420 kHz 170V (de+ ac peak)
0.42 - 10 MHz (5 X 107V rms Hz)/FREQ
>10 MHz 5V rms
X20:
<1 MHz, Same as X1
>1 MHz, 50V rms
(Channel B HP 5384A)
Range: 50 to 225 MHz
Sensitivity: 10 mV rms 50 to 200 MHz
15 mV rms 200 to 225 MHz
Dynamic Range: 10 mV to 1V rms
Coupling: AC
Impedance: 50 ohm NOMINAL
Attenuator Level:
Manual: variable from X1 to X5
(0 to 14 dB) NOMINAL.
Auto: AGC mode for improved noise
suppression.
Damage Level:
350V de + 5V rms ac
(Channel B HP 5385A)
Fuse protected. Front panel accessible.
Range:
90 to 1000 MHz
Sensitivity: 15 mV rms sine wave 90-100 MHz
10 mV rms sine wave 100-1000 MHz
Dynamic Range: 10 mV to 7V rms (-27 to +30 dBm)
Coupling: AC
Impedance: 50 ohm NOMINAL
Attenuator Level:
Manual: variable from X1 to X18
(0 to 25 dB) NOMINAL.
A Auto: AGC mode for improved noise suppression.
.A. Damage Level:
AC >1 MHz +30 dBm (7V rms)
AC
<1 MHz 2V rms
DC ±5V
A TIMEBASE HP 5384A
Frequency: 10 MHz
Aging Rate: <3 X 10-7/mo.
Temperature: ±5 X 10-6, 0° to 50°C.ref. to 25°C.
Line Voltage: <1 X 10-7 for ±10% variation.
A TIMEBASE HP 5385A (TCXO)
Frequency: 10 MHz
Aging Rate: <1 X 10-7/mo.
Temperature: ±1 X 10-6, 0° to 40°C. ref. to 25°C.
Line Voltage: <5 X 10-8 for ±10% variation.
FREQUENCY A and B
Range Channel A: 10Hz- 100 MHz
Range Channel 8:
5384A: 50 MHz- 225 MHz
5385A: 90 MHz- 1.0 GHz
LSD Displayed: 10 Hz to 1 nHz
LSD
4 ns
X FREQ
Gate Time
Resolution: ±1
LSD
± -'-(1_.4_X_T_ri..:::g.:::ge_r_Er_ro_r_+_1_n_s_r_m_s~) X Freq
Gate Time
Accuracy: ± Resolution ± Time
Base
Error X Frequency
1-3

HP 5384A and HP 5385A
General Information
1-4
Table 1-1. Models HP 5384A and HP 5385A Specifications (Continued)
PERIOD A
Range: 10 ns to 0.1 s
LSD Displayed: .001 fs to 10 ns
LSD:
__
4
_n_s
__ X period
Gate Time
Resolution: ± LSD
± (1.4 X Trigger Error + 1 ns rms)
Gate Time X Per
Accuracy: ± Resolution ± Time Base Error X Period
OPTIONS
Option 001 (HP 5384A), TXCO Timebase
Frequency: 10 MHz
Aging Rate: <1 X 1Q-7/mo.
Temperature: ±1 X 10-6, oo to 40°C ref. to 25°C.
Line Voltage: <5 X 10-8 for ±10% variation.
Option 003, HP-IL
All HP-Il programmable functions, controls, and operations
are the same as those for HP-IB except for interface functions
Auto Address and Parallel Poll, which are also included.
R, AH, SH1, D, l1, (T1-S), CO, DC2, DT1, PP1, SR2, AA 1, Rl2,
PDO, DD1.
Option 004, Oven Timebase
Frequency: 10 MHz
Aging Rate: <3 .x 10-8/mo. (2)
Temperature: ±1 X 10-7, 0° to 50°C ref. to 25°C.
Line Voltage: <2 X 10-9 for a ±10% variation.
Battery
Operation: The instrument operates for 3 hours
(typical) with option 004.
Option 005, Battery
Type: Sealed lead-acid; not covered under instrument
warranty.
Capacity: Typically 4 hours of operation at 25°C (1).
Recharge Time: Typically 16 hours to 98% of full charge
in instrument STBY (Standby) mode.
Battery Low Annunciator: Enabled 20 minutes prior to
instrument shutdown nominally.
Line Failure
Protection: Instrument automatically switches
to battery in case of line failure.
Weight: Option 005 adds 1.4 kg. (3 lbs.) to weight of
instrument. (1) without Option 004 installed. HP-Il
replaces HP-IB when Option 005 is ordered from
the factory.
HP-18 1/0 Interface
Programmable Functions: Frequency A, Frequency B,
Period A.
Programmable Controls: X20 Attn A, FILTER A, MAN
LEVEL A/B, Gate Time.
Display: Normal, Increment, Decrement, Remote, local
Miscellaneous Functions and Operating Commands:
Diagnostics, 10 MHz Check, reset, initialize, Wait To
Send ON/OFF Device ID.
Interface Functions: Device Clear, Group Execute Trigger
Interface Clear, local, local lockout, Send Status, Remote,
Service Request.
SH1, AH1, TS, TEO, l4, LEO, SR1, Rl1, PPO, DC1,
DT1, CO, E1.
Data Output:
Output will be maximum resolution for the gate time
selected and is not affected by the front panel Display
Digits keys.
Format: 17
characters plus CR and LF (blanks may be
inserted).
Rate: 4 readings/s maximum at .1 s gate.
Talk only: Set with address switch=31.
DEFINITIONS
Measurement Gate Time: Selected value ±15% + up
to 1 period of input.
Dynamic Range: Minimum to maximum input voltage
swing allowed for correct frequency counting.
LSD Displayed: Dependent on gate time, input signal, and
DISPLAY DIGITS control. In NORM mode, 8 digits are
displayed. Using the display control, up to 11 digits may
be present for frequency measurements, 8digits maximum
for
period.
LSD: Unit value of least significant digit rounded to the
nearest decade, i.e., 4 Hz -1 Hz, 6 Hz -10 Hz.
Trigger Error:
Channel A:
y,..,.( e-:-i ):-;;:2--:+-(-:-e-n ):-;;:2-
----,------'------ s rms,
Input slew rate at trigger point
where ei and en are input noise voltages (rms) for
the counter and signal, respectively, for a 100 MHz
bandwidth.
ei ::; 100 11-V rms,
Channel B: negligible due to high signal slew rate at
the trigger point.
Best
Case Resolution for 1 second gate (±Hz)
Amplitude
Frequency (Hz)
mVrms
10 100 lK
lOK lOOK
1M 10M lOOM 200M l.OG
so
.0003 .0003 .0003 .0003 .0008 .004 .04 0.4 0.8 4.0
100 .0002 .0002 .0002 .0003 .0007 .004 .04 0.4 0.8 4.0
500 .0002 .0002 .0002 .0003 .0006 .004 .04 0.4 0.8 4.0
1000 .0001 .0001 .0001 .0001 .0005 .004 .04 0.4 0.8 4.0
Th1s chart shows best case frequency resolution vs sine wave input voltage (rms). Noise from the signal source is assumed to be
zero and tngger error produced only by the counter's noise (i.e., 100 11-V rms).
LSD DISPLAYED: Unit value of least significant digit rounded to the nearest decade, i.e., 4Hz-1Hz, 6Hz-10Hz.
•
•
•

•
•
•
HP 5384A and HP 5385A
General Information
Table 1-2. Recommended Test Equipment
Instrument Critical specifications Recommended Model Use
50 Ohm Feedthrough BNC Type
HP 10100C
P,A,T
Tee Connector BNC Type HP 1250-0781
P,A,T
Cables BNC
50 ohm
HP 11170C
P,A,T
Oscilloscope
100 MHz Bandwidth
HP 1740A A,T
Synthesized
Generator
90-1000 MHz HP 8660C /86602A
P,T
Signal Generator
50-225 MHz HP 8656A P,A,T,
Signal Generator 90-1000
MHz HP 804A
P,T
Synthesized Function
10 Hz to 20 MHz
HP 3325A
P,A,T
Generator
DC Voltmeter 20V Range, 0.05V resolution
HP 3465
A,T
Power Splitter
90 MHz-1 GHz Cal. output
HP 11667A A,T
Power Meter/Sensor 90 MHz-1 GHz, -9 to -24 dBm
HP 436A/8481A p
10 dB Attenuator
HP 8491A p
Adapter, Coaxial Type N(male)-to-BNC(female) 1250-07680 p
(2 required)
Adapter, Coaxial Type N(male)-to-BNC(male) 1250-0082 p
Controller
HP-IB Compatible
HP-85F*
Controller
HP-IL Compatible HP-41CV p
Interface HP-IL
Compatible
HP 82938A
Resistor 10!1 20W 0811-1655 A
*HP-85F consists of the following:
Controller ................................................... HP-85A
1/0 ROM . . .. . . . . . .. . . . . . . . . . . .. . . . .. . . . . . .. . . . . .. . . . . . 00085-15003
ROM Drawer ............................................. HP 82936A
HP-IB Interface Card/Cable ................................ HP 82937A
1-5

•
•
HP 5384A and HP 5385A
Installation
SECTION II
INSTALLATION
2-1. INTRODUCTION
2-2. This section contains information for unpack-
ing, inspection, storage, and installation.
2-3. UNPACKING AND INSPECTION
2-4. If the shipping carton is damaged, inspect the
instrument for visible damage (scratches, dents, etc.).
If the instrument is damaged, notify the carrier and
the nearest Hewlett-Packard Sales and Service Office
immediately (offices are listed at the back of this
manual). Keep
the shipping and packing material for
the carrier's inspection. The Hewlett-Packard Sales
and Service Office will arrange for repair or replace-
ment of your instrument without waiting for the claim
against
the carrier to be settled.
2-5. PREPARATION FOR USE
[~
Before connecting the instrument to ac
power lines, be sure that the voltage selector
is properly positioned as described below.
2-6. POWER REQUIREMENTS
2-7. The counter has the following ac power
requirements:
115V, +10%, -25%, 48-66 Hz single phase
230V, +10%, -15%, 48-66 Hz single phase
115V, +10%, -10%, 380-420 Hz single phase
A2-8. LINE VOLTAGE SELECTION
2-9. The power line voltage is selected by the
position of the LINE SELECT switch on the rear panel.
Sliding the switch
to the left selects 115V operation,
sliding the switch to the right selects 230V operation.
The voltages available are printed on the switch. The
specific voltage selected
will be visible on the LINE
SELECT switch, as shown in Figure 2-1. Before
applying
power, verify that the LINE SELECT switch is
properly set for the desired acsupplyvoltageand that
the correct fuse is installed.
2-10. AC Line Fuse Selection
2-11. The ac line fuse is not accessible from the
outside of the cabinet. The cabinet should be opened
only by qualified service personnel. The correct fuse
value
is 250 mAT/250V Slow Blow for 115V or 230V
operation.
-LINE INPUT
18 VA r.1AX
f
f ! I
® ~~~ ~~sg~:z~~~~6
PERSONNEL
A LINE SELECT FUSE
e
2A
LINE SELECT
SWITCH
Figure 2-1. Line Voltage Selection
2-12. DC Fuse Selection
2-13. To replace the de fuse use a small flat-bladed
screwdriver
to remove the fuse from the fuseholder.
Press in slightly and turn counterclockwise, until the
fuse carrier springs free. Replace the fuse in the fuse
carrier and reinstall byinserting and
turning clockwise.
Be sure to install the correct fuse value; 2 N250V fast
blow.
2-14. The de fuse is the main protective device for the
instrument. The de fuse will
blow whether the de
current source
is theoptional batterypack, power from
the external de power jack, or the built-in ac power
supply.
2-15. Power Cable
2-16. The counter is shipped with athree-wire power
cable. When the cable is connected to an appropriate
ac power source, this cable connects the instrument
chassis to earth ground. The type of power cable plug
shipped with each instrument depends on the country
2-1

~!f:Jji'. HP 5384A and HP 5385A
svsTEMs Installation
of destination. Refer to Figure 2-2 for the part numbers
of the power cable and plug configurations available.
I WARNING I
BEFORE ENERGIZING THIS INSTRUMENT, THE
PROTECTIVE EARTH TERMINAL OF THIS
INSTRUMENT MUST BE CONNECTED TO THE
PROTECTIVE CONDUCTOR OF THE (MAINS)
POWER CORD. THE MAINS PLUG SHALL ONLY
BE INSERTED IN A SOCKET OUTLET PROVIDED
WITH A PROTECTIVE EARTH CONTACT. THE
PROTECTIVE ACTION MUST NOT BE NEGATED
BY THE USE OF AN EXTENSION CORD (POWER
CABLE) WITHOUT A PROTECTIVE EARTH
(GROUNDING) CON-DUCTOR.
2-2
E
8120-0698
8120-1351
N
8120-1369
N
8120-1378
L
N
8120-1689
~-
L E
8120-2104
POWER-INPUT
SOCKET
Figure 2-2. Power Cable HP Part Number versus
Mains Plugs Available
2-17. HP-18 Interconnections
2-18. HEWLETT-PACKARD INTERFACE BUS.The
counter with HP-IB is compatible with the Hewlett-
Packard Interface Bus. Interconnection data concern-
ing the rear panel HP-IB connector is provided in
Figure 2-3. This connector is compatible with the HP
10833A/B/C/D cables. (See Table 2-1 for cable de-
scriptions).The HP-IB system allows interconnection
of up to 15 (including the controller) HP-IB
compatible instruments.
Table 2-1. HP-18 Cable Descriptions
HP Model Cable Length
10833A 1
metre (3.3 feet)
108338 2 metres (6.6 feet)
10833C 4 metres (13.2 feet)
108330 0.5 metres (1.6 feet)
2-19. The HP-IB cables have identical "piggy-back"
connectors on both ends so that several cablescan be
connected to a single source without special adapters
or switch boxes. System components and devices may
be
connected in virtually any configuration desired.
There must,
of course, be a path from the calculator
(or other controller) to every device operating on the
bus. As a practical matter, avoid stacking more than
three or four cables on any one connector. If the stack
gets
too large, the force on the stack produces great
leverage
which can damage the connector mounting.
Be sure each connector is firmly (finger tight) screwed
in place to keep it from working loose during use.
2-20. CABLE LENGTH RESTRICTIONS. To achieve
design performance with the HP-18, the proper voltage
levels and
timing relationships must be maintained. If
the system cable is too long, the lines cannot be driven
properly, and the system will fail
to perform properly.
Therefore, when interconnecting
an HP-IB system, it is
important to observe the following rules.
a. The total cable length for the system must be less
than or equal to 20 metres (65.6 feet).
b. The total cable length for thesystem must be
less
than or equal to 2 metres (6.6 feet) times the total
number of devices connected to the bus.
c. The total number of instruments connected to
the bus must not exceed 15.
2-21. HP-18 Talk/Listen Address Switch
2-22. The HP 5384A and HP 5385A provide a rear
panel HP-IB instrument address selection switch. This
switch determines the
mode of remote operation as
•
•
•

•
•
•
HP 5384A and HP 5385A~!j:J!i'.
Installation svSTEMS
PIN LINE
1
DI01
2
DI02
3 DI03
4
DI04
13
DI05
14 DI06
15
DI07
16 DI08
5 EOI
17 REN
6 DAV
7 NRFD
8 NDAC
9 IFC
10 SRQ
11
ATN
12 SHIELD-CHASSIS GROUND
18
P/0 TWISTED PAIR WITH PIN 6
19 P/0 TWISTED PAIR WITH PIN 7 THESE PINS
20
P/0 TWISTED PAIR WITH PIN 8 ARE
21
P/0 TWISTED PAIR WITH PIN 9 INTERNALLY
22
P/0 TWISTED PAIR WITH PIN 10 GROUNDED
23
P/0 TWISTED PAIR WITH PIN 11
24
ISOLATED DIGITAL GROUND
LONG MOUNTING SHORT MOUNTING
STUD STUD
LOCKSCREW
1390-0360 0380-0643 0380-0644
The HP 5384A/HP 5385A contains metlc threaded HP-18 cable
mounting studs as opposed to English threads. Metric threaded
HP 10833A,
8, C, or D HP-18 cable lockscrews must be used to
secure thecable to the Instrument. Identification of the two types
of
mounting studs and lockscrewsIs made by their color.English
threaded fasteners are colored sliver and metric threaded
fasteners are colored black. DO
NOT mate sliver and black
fasteners to each other or the threads of either or both will be
destroyed. Metric threaded HP-18 cable lockscrew
lllus-trallon
and part number follows.
Logic Levels
-----r
6.5mm
~
The Hewlett-Packard Interface Bus logic levels are TTL compatible, i.e., the true (1) state is
O.OV de to 0.4V de and the false (0) state is +2.5V de to +5.0V de.
Programming and
Output Data Format
Refer to Section
Ill, Operation
Mating Connector
HP 1251-0293; Amphenol 57-30240.
Mating Cables Available
HP 10833A, 1 metre (3.3 ft.), HP 10833B, 2 metres (6.6 ft.),
HP 10833C, 4 metres (13.2 ft.), HP 108330, 1/2 metre (1.6 ft.).
Cabling Restrictions
1. A Hewlett-Packard Interface Bus System may contain no more than 2 r:netres (6.6 ft.) of
connecting cable per instrument.
2. The maximum accumulative length of connecting cable for any Hewlett-Packard Inter-
face Bus System is 20.0 metres (65.6 ft.).
3. The maximum number of instruments in one system is fifteen.
Figure 2-3. Hewlett-Packard Interface Bus Connections
-.
4.9mm
___l_
2-3
