HP NetServer LH 3/LH 3r
DIMM Installation Guide
HP Part Number 5967-2105
Printed in May 1998

ii
Notice
The information contained in this document is subject to change without
notice.
Hewlett-Packard makes no warranty of any kind with regard to this
material, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. Hewlett-Packard
shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance,
or use of this material. Hewlett-Packard assumes no responsibility for
the use or reliability of its software on equipment that is not furnished by
Hewlett-Packard.
This document contains proprietary information that is protected by
copyright. All rights are reserved. No part of this document may be
photocopied, reproduced, or translated to another language without the
prior written consent of Hewlett-Packard Company.
Hewlett-Packard Company
Network Server Division
Technical Marketing/MS 49EU-FQ
5301 Stevens Creek Boulevard
P.O. Box 58059
Santa Clara, CA 95052-8059 USA
© Copyright 1998, Hewlett-Packard Company.

iii
Contents
Preface .................................................................................................v
Purpose of This Guide.......................................................................v
Contents of This Guide......................................................................v
Intended Audience............................................................................vi
Related Documentation....................................................................vi
1 Introduction ......................................................................................1
Verifying Contents.............................................................................1
Prepare for Installation ......................................................................1
Tools You Need.............................................................................2
2 Preparation .......................................................................................3
Removing the Cover (NetServer LH 3)..............................................3
Removing the Cover (NetServer LH 3r).............................................5
Removing the System Board (NetServer LH 3r)................................8
3 Installing DIMMs.............................................................................11
Installation Guidelines .....................................................................11
Installing DIMMs..............................................................................13
4 Replacing the Cover.......................................................................15

iv
HP NetServer LH 3......................................................................... 15
HP NetServer LH 3r........................................................................ 15
5 Warranty and Support.................................................................... 17
HP Repair and Telephone Support.................................................. 18

v
Preface
Purpose of This Guide
This guide describes how to install DIMMs (Synchronous Dynamic
Random Access Memory Dual In-Line Memory Modules), HP Product
Numbers D6097A, D6098A, and D6099A, in an HP NetServer LH 3 or
LH 3r.
Contents of This Guide
This guide includes the following topics:
•An Introduction, including verifying the contents of the shipping
box, and important precautionary warnings
•Preparation instructions, such as removing the chassis side cover,
and removing the system board (for NetServer LH 3r only)
•Instructions for installing DIMMs on the system board
•Hardware warranty information

vi
Intended Audience
This guide is intended for the person who installs, administers, and
troubleshoots network servers. Hewlett-Packard Company assumes you
are qualified in the servicing of computer equipment and trained in
recognizing hazards in products with hazardous energy levels.
Related Documentation
The following documents describe the HP NetServer LH 3/LH 3r:
•The HP NetServer LH 3/LH 3r User Guide
•The HP NetServer LH 3 Installation Road Map, or
the HP NetServer LH 3r Installation Road Map
•The HP NetServer LH 3 and LH 3r Technical Reference Card
•The HP NetServer Online Documentation CD-ROM

vii
WARNING Before removing the cover, always disconnect the
power cord and unplug telephone cables. Disconnect
the power cord to avoid exposure to high energy
levels that may cause burns when parts are short-
circuited by metal objects, such as tools or jewelry.
Disconnect telephone cables to avoid exposure to
shock hazard from telephone ringing voltages.
Note that the power switch does not turn off the
standby power. Disconnect the power cord to turn off
standby power. If the backlight on the LCD display
is still on, standby power is still on.
CAUTION Wear a wrist strap and use a static-dissipating work
surface connected to the chassis at all times.

1
1 Introduction
Verifying Contents
The contents of the shipping box include:
•One HP qualified DIMM.
•The HP NetServer LH 3/LH 3r DIMM Installation Guide.
CAUTION To avoid damaging the DIMM with electrostatic
discharge, handle the DIMMs in a static-free
environment only. Hold the module by its edges and
avoid touching its components. When you set down
a DIMM, always place it on its anti-static container.
Prepare for Installation
Gather the tools and the documentation you need to install the DIMMs
before removing them from their packaging.

2
Tools You Need
To install DIMMs, you need an anti-static service kit (3M
8501/8502/8503 or equivalent). This kit includes a static-dissipating
Installation Instructions

3
2 Preparation
This chapter includes guidelines and instructions for installing DIMMs
in the specified sequence on the system board.
Removing the Cover (NetServer LH 3)
To remove a cover:
1. Turn off the HP NetServer and disconnect the power cord and
telephone cord.
2. Unlock the bezel lock with the key from the key bag located on
the rear of the HP NetServer (see Figure 2-1).
3. To remove the front bezel, pull the top of the bezel away from the
chassis, and then lift the bezel up and off of the chassis.
4. Loosen the thumbscrew at the front of cover 3 and pull the cover
forward, using the handle on the cover, and then lift it off the
chassis (see Figure 2-1).

4
Thumbscrews
Tabs and Slots
Cover 3
Figure 2-1. Removing the Cover (NetServer LH 3)

5
Removing the Cover (NetServer LH 3r)
1. Turn off the HP NetServer and disconnect all power and
telephone cords.
2. Remove the bezel, the bezel hinge, and the screws securing the
latch plate to the front-right rack upright (see Figure 2-2).
3. Slide out the NetServer until the rail locks "click" into place.

6
Latch
Plate
Bezel
Hinge
Bezel
Figure 2-2. Sliding Out the NetServer From the Rack

7
4. Loosen the thumbscrew at the front of cover 2 and pull the cover
forward, using the handle on the cover, and then lift it off the
chassis (see Figure 2-3).
Thumbscrew
Cover 2
Figure 2-3. Removing the Cover (NetServer LH 3r)

8
Removing the System Board
(NetServer LH 3r)
To remove the system board from the LH 3r:
1. Rotate the system board retaining latches until they point away
from the chassis, and the system board has come out of its socket
(see Figure 2-4).
2. Slide the system board out of the chassis and place it on a static-
dissipating work surface (see Figure 2-5).
CAUTION Place the NetServer LH 3r system board on the work
surface so that the metal bracket extends off of the
work surface (see Figure 2-5). Failure to orient the
system board this way may result in damage to the
system board when installing memory.

9
Retaining
Latches
System
Board
Figure 2-4. Removing the System Board (NetServer LH 3r)

10
Metal support
must be OFF
work surface;
system board
must lie flat.
Static-dissipating
Work Surface
System Board
Figure 2-5. Orienting the System Board (NetServer LH 3r)

11
3 Installing DIMMs
This chapter includes guidelines and instructions for installing DIMMs
in the specified sequence on the system board.
CAUTION Use only DIMMs acquired from HP. Contact HP
Customer Support for a list of qualified DIMMs. HP
will not warranty or support configurations that use
non-HP DIMMs.
Installation Guidelines
You can use 64 MB, 128 MB, and 256 MB DIMMs for a maximum
capacity of 1 GB of RAM. Note the following installation guidelines
before adding memory:
•The minimum memory configuration for the
NetServer LH 3/LH 3r is one 128 MB DIMM.
•The system board DIMM sockets are numbered from 0 to 3, as
shown in Figure 3-1.

12
•DIMMs may be installed in any quantity and in any DIMM
socket on the system board. DIMMs that differ in capacity can
be mixed.
System Board
DIMM Socket 0
DIMM Socket 1
DIMM Socket 2
DIMM Socket 3
Figure 3-1. DIMM Socket Location
