HP Model 748 - VME Workstation User manual

1
Installation Guide for Model A4350A
Mass Storage Module Upgrade Kit
THIS KIT IS TO BE INST ALLED BY QUALIFIED
SER VICE PERSONNEL ONL Y
Workstation Systems Group
Order N0. A1658–90673
Edition E0895
Printed in U.S.A.

2
Introduction
These instructions document how to install the A4350A upgrade kit in the Model 748i/64 or 748i/100
Ruggedized W orkstation (Kit A4309–70006) or TELEPACE (Kit A4350–70008).
Kit Contents
The tray in each kit come preassembled. The following are parts checklists for tray assemblies in Kit
numbers A4309–70006 for Model 748i/64 or 748i/100 and A4350–70008 for TELEPACE.
Kit A4309–70006 Kit A4350–70008
Tray Tray
SE Cable SE Cable
FW Cable 14 inch FW Cable 50 inch
Power Cable Power Cable
FW Bracket and screw FW Bracket and screw
Bracket Plug Bracket Plug
FW Tray Trim and screw FW Tray Trim and screw
Terminators (SE and FW) Terminators (SE and FW)
Installation Guide Installation Guide
Wrist Strap Wrist Strap
Bag Bag
Static Note Static Note
Tie wraps Tie wraps
Field Replaceable Units
The following are the spare part numbers for the tray assemblies
Description Part Number
Tray Assembly (Short Cable) A4309–60003
Tray Assembly (Long Cable) A4350–60007

3
Installation Procedures
Following are the procedures to install the HP A4350A Mass Storage Module upgrade in the Model
748i/64 or 748i/100 Ruggedized Workstation. or TELEPACE.
Prerequisites
The HP A4268A Fast Wide Differential SCSI Adapter must be installed on the Model 743 CPU board.
Refer to the Model A4268A Fast/Wide Differential SCSI Adapter Installation and Service Guide
(A4268–90600)
for installation instructions.
The Operating System must be HP–UX 9.05 or later.
Installation Procedures Overview
Installing the HP A4350A Mass Storage Module upgrade consists of the following procedures:
Prepare to install the mass storage module.
Power off the system.
Remove the existing mass storage module.
Install mass storage devices in the new mass storage module
Install the new mass storage module into the system, connect cables, and config-
ure system to include the FastWide SCSI devices.
Verify system operation.
Prepare to Install the Mass Storage Module Upgrade
Before upgrading the mass storage module, you should perform the following:
Unpack and verify kit contents. (See Kit Contents on previous page)
Observe Electrostatic Discharge (ESD) precautions.
Gather tools and accessories.
Observe Electr ostatic Discharge Precautions
Electrostatic charges can damage the integrated circuits. To prevent such damage from occurring,
observe the following precautions when unpacking and installing the upgrade.
Stand on a static–free mat.
Wear a static strap to ensure that any accumulated electrostatic charge discharges
from your body to ground.
Connect all equipment together, including the static–free mat, static straps, and
all computer hardware.
Keep uninstalled printed circuit boards in their protective antistatic bags.
Handle printed circuit boards by their edges once you have removed them from
their protective antistatic bags.
Gather T
ools and Accessories
The tools required for the installation of the mass storage module upgrade kit are:
Flat–bladed screwdriver and Phillips Head screwdriver (not supplied with kit).
Grounding wrist strap supplied in the kit.
Anti–Static Bag supplied in the kit.

4
Mass Storage Module Configuration and Installation
The following provides the information for configuring and installing the new mass storage module.
Before configuring the new mass storage module, you need to know the type and location of the SCSI
devices that are going into the new module.
Mass Storage Module Configuration Guidelines
The following are guidelines on how to configure the mass storage module. The guidelines are divided
into two groups. The first group applies to all considerations of installing mass storage devices in the
mass storage module. If a CD–ROM drive is to be installed in the mass storage module, the second group
of guidelines also applies.
All Mass Storage Module Configurations
Ensure all the drives have their SCSI ID jumpers set prior to installation.
Attach the power and SCSI cable to the device before attaching the device to the
module.
A maximum of two fast wide devices and two single–ended devices can go into
the mass storage module
Mass Storage Module Configurations With CD–ROM Drive
Observe the guidelines stated above along with the following guidelines
A CD–ROM can only be put in the position diagonally opposite the F/W cable
entry into the mass storage module.
If a fast wide hard disk is located behind the CD–ROM drive, it must be turned
90 degrees, with the cable connectors toward the center of the mass storage mod-
ule, to allow proper clearances.
A DDS Tape drive or Floppy drive can only be positioned next to the CD–ROM.
Mass Storage Device Configurations
The following shows the positions of single–ended and fast wide mass storage devices in the mass stor-
age module.
Depending on your system, the entry point of the FW SCSI cable is at the front or the rear of the mass
storage module. Figure 2 shows the entry of the FW SCSI cable at the rear of the mass storage module
(Model 748). Figure 3 shows the entry of the FW SCSI cable at the front of the mass storage module
(TELEPACE).

5
FW Cable
SE Cable
FW External Connector
SE External Connector
with Terminator
with Terminator
CD ROM
*SE Device
FW Drive
FW Drive
SE Hard Drive
FW Drive
or
or
*DDS T ape Drive or Floppy Disk Drive
The FW drive behind the
is turned 90
with the cable connector
of the chassis
o
CD–ROM drive
turned toward the center
All devices are mounted in
the chassis as shown for the
Cable connector
SE Device or FW Drive
except for the FW drive
mounted behind the CD–ROM
drive.
Figure 1 Configurations for the Mass Storage Module in Model with Short Cable
FW Cable
SE Cable
FW External Connector
SE External Connector
The FW drive behind the
is turned 90
with the cable connector
of the chassis
FW Drive
o
with Terminator
with Terminator
*DDS T ape Drive or Floppy Disk Drive
*SE Device
FW Drive
or
FW Drive
SE Hard Drive
or
CD ROM
CD–ROM drive
turned toward the center
Cable connector
All devices are mounted in
the chassis as shown for the
SE Device or FW Drive
except for the FW drive
mounted behind the CD–ROM
drive.
Figure 2 Configurations for the Mass Storage Module with Long Cable

6
   
Before performing this upgrade procedure, observe the following precautions:
1. Please refer to your system’s Owner’ s Guide for the procedures to power off the system.
2. Unplug the system unit power cord and the power cords of any peripheral devices from the
power source
3. Unplug the system unit power cord from the power connector at the back of the power
supply.
WARNING: Failure to properly shut down and remove power from the system may create
a personal hazard, or may result in hardware damage or data corruption.
Remove the Existing Mass Storage Module
To remove the existing mass storage module follow these steps (See Figure 3):
CAUTION: Use care when handling the mass storage module. The mass storage
module can be heavy and awkwardly balanced.
1. Disconnect the SCSI interface cables connected to the mass storage module.
2. Unscrew both mass storage module handle screws until they pop out.
3. Pulling on the handles, slide the mass storage module out of the chassis.
4. Disconnect the DC power cables connected to the mass storage devices.
5. Disconnect the SCSI cables connected to the mass storage devices.
Mass Storage
Module Handle
Screws
SCSI Interface
Cable
Figure 3 Removing the Mass Storage Module

7
Installing Devices in the New Mass Storage Module
Follow these steps to install the mass storage devices in the new mass storage module. Figure 4 shows
the cabling scheme for the new mass storage module.
1. Remove the mass storage devices from the old mass storage module.
2. Install the mass storage devices into the new mass storage module. Refer to the Mass Storage
Module Configuration Guidelines for the configurations of mass storage devices allowed.
FW SCSI Cable
SE SCSI Cable
DC Power Cable
T o External FW SCSI Devices
T o External SE SCSI Devices
From FW SCSI Adapter
From SE SCSI Adapter
Figure 4 Mass Storage Module Cabling
CAUTION: The new mass storage module has a power cable, single–ended SCSI
cable and a fast wide SCSI cable. Be sure that the cables are secured to
their connectors on the drives and not pinched or pulled too tight before
installing the mass storage module back into the chassis.

8
3. Attach the mass storage devices to the appropriate slotted mounting holes in the new mass
storage module as shown in Figure 5.
Stand–offs
Mounting Screws
Slotted Mounting
Holes
Figure 5 Typical Mass Storage Device Attachment to the New Mass Storage Module
4. Secure loose cables with the tie–wraps provided to prevent damage to the cables while
sliding the tray in or out of the chassis.
5. Slide the new mass storage module into the chassis, secure the screws, and connect the SCSI
interface cables.
System V erification
Please refer to your Owners Guide for information on running the appropriate diagnostics to verify
your system’ s operation.
