1. Dual Microphone Array 3. 18.5 in diagonal widescreen LCD HD anti-glare display
2. Low-light webcam 4. Stereo Speakers
QuickSpecs
HP 1155 All-in-One Desktop PC
Overview
DA - 14569 North America — Version 1 — May 6, 2013 Page 1

1. Power Button 5. Media Card Reader
2. Optical Disk Drive 6. (2) USB 3.0 Ports
3. Hard Disk Drive LED Indicator 7. Microphone Port
4. Media Card Reader LED Indicator 8. Headphone Port
QuickSpecs
HP 1155 All-in-One Desktop PC
Overview
DA - 14569 North America — Version 1 — May 6, 2013 Page 2

1. Adjustable Tilt Stand 5. Security Lock Slot
2. Power Connector LED Indicator 6. Line Out Port
3. Power Connector 7. RJ45 Ethernet Port
4. (4) USB 2.0 Ports
QuickSpecs
HP 1155 All-in-One Desktop PC
Overview
DA - 14569 North America — Version 1 — May 6, 2013 Page 3

At A Glance
Windows® 8 Professional 64-bit, Windows® 8 64-bit, and FreeDOS
18.5-inch diagonal widescreen HD LED-backlight anti-glare LCD Display
Integrated All-in-One form factor
Adjustable tilt stand
AMD A68 FCH chipset supporting E1-1500 processor featuring AMD Radeon HD 7310 Integrated Graphics
Integrated Realtek 8175EH-VB-CG 10/100 Ethernet Controller
Wireless connectivity - HP WLAN/Bluetooth Combo NIC 802.11b/g/n Mini Card
Optional Integrated 1.0 MP 720p low-light webcam with dual microphone array
Integrated HD audio card and stereo speakers
Up to 8GB of DDR3 SDRAM supported
Up to 1 TB hard drive
Optional HP Slim-Tray SuperMulti DVD+RW SATA 8X Optical Drive
Media Card Reader
USB Keyboard and Mouse
ENERGY STAR® (for Windows OS only)
EPEAT Silver certification*
Protected by HP Services. Terms and conditions vary by country. Certain restrictions and exclusions apply.
* Where HP registers commercial desktop products. See epeat.net for registration status in your country.
QuickSpecs
HP 1155 All-in-One Desktop PC
Overview
DA - 14569 North America — Version 1 — May 6, 2013 Page 4

Processors AMD E-Series Dual-Core Processor:
AMD Dual-Core E1-1500 Processor Graphics
(1.48 GHz, 1 MB L2 cache, 2 cores)
Operating System Preinstalled Windows® 8 Professional 64-bit
Windows® 8 64-bit
FreeDOS
Not all features are available in all editions of Windows 8. Systems may require upgraded and/or
separately purchased hardware, drivers and/or software to take full advantage of Windows 8 functionality.
See http://www.microsoft.com .
Chipset AMD A68 FCH (Fusion Controller Hub)
Graphics Integrated AMD Radeon HD 7310 Graphics
Shared system memory
DirectX 11 capable
Display 18.5-inch WLED Non-Glare TN LCD Panel
Resolution 1366 x 768 resolution (16:9)
Contrast ratio 600:1 typical
Image brightness 200 nits typical
Refresh rate 5ms
Viewing angle (typical) Up to 90º horizontal/50º vertical (10:1 minimum contrast ratio)
NOTE: All performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
Adjustable Tilt Stand Tilt adjustments +10 to +25 degrees
Memory Standard DDR3 1600 MT/s
Two SODIMM slots
2 GB (1 x 2 GB)
4 GB (1 x 4 GB)
4 GB (2 + 2 GB)
6 GB (4 + 2 GB)
8 GB (2 x 4 GB)
NOTE: All performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
Communications Realtek 8175EH-VB-CG Integrated 10/100 NIC
HP 802.11 PCIe Minicard
Wireless Module
Support for 802.11 b, g, and n
WLAN/BT Combo
1X1 Mini PCIe Card
QuickSpecs
HP 1155 All-in-One Desktop PC
Standard Features (availability varies by configuration and by country)
DA - 14569 North America — Version 1 — May 6, 2013 Page 5

I/O Devices HP USB Keyboard 104 keys plus special keys for Mute, Volume Up, Volume Down. Separate
numeric keypad.
Cable length 51 in (130 cm)
HP USB Optical Scroll
Mouse
Two buttons with scroll wheel acting as third button.
Cable length 69 in (175 cm)
Storage Hard Drive 3.5-inch, 7200 rpm NCQ, Smart IV SATA Hard Drive:
500 GB
1 TB
Slim Optical Drive Tray-load HP Slim SATA 8X SuperMulti Drive
Read: 8x max DVD-ROM, 24x max CD-ROM
Write: 8x max DVD±R, 6x max DVD±R DL, 8x max DVD+RW,
6x max DVD-RW, 5x max DVD-RAM, 24x max CD-R,
24x max CD-RW
I/O Slots Half Height Mini PCIe x1 One (Wireless LAN module)
Ports Side I/O Ports Two (2) USB 3.0 ports
One (1) microphone in
One (1) headphone out
One (1) 6 in 1 Card reader
Rear I/O Ports Four (4) USB 2.0 ports
One (1) RJ45 network connection
One (1) Stereo audio line out
One (1) DC in power
Audio/Visual Integrated HD Audio card with RTK ALC269-VC codec
Integrated stereo speakers
Integrated 1.0MP, 720p HD low-light Webcam with Dual Microphone Array (optional)
SMBIOS System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
Security Security Lock Slot
Norton Internet Security (60 Day Trial)
Preinstalled
software
Preinstalled (varies by country)
(Buy Office)
Browser and Toolbars
Internet Explorer 10
Norton Toolbar
Security and Protection
HP Client Security
QuickSpecs
HP 1155 All-in-One Desktop PC
Standard Features (availability varies by configuration and by country)
DA - 14569 North America — Version 1 — May 6, 2013 Page 6

Productivity
Buy Office
Optical Disc Drive Playback and TV Tuners
CyberLink PowerDVD
Avermedia TV app
Hauppauge TV app
Windows® Live™
Movie Maker
Writer
Photo Gallery
Windows 8 applications
Mail
Calendar
People
SkyDrive
Photos
Messaging
Photos and Videos
CyberLink YouCam
CyberLink Media Suite
CyberLink Power2Go
CyberLink Label Print
A/V Integration
HP Connected Remote
Audio Post Processing
Beats Audio™
Games
HP Games by WildTangent
Communication
Broadband connection utility
Utilities and Support
HP Online User Guide
HP Recovery Manager
HP Support Assistant
QuickSpecs
HP 1155 All-in-One Desktop PC
Standard Features (availability varies by configuration and by country)
DA - 14569 North America — Version 1 — May 6, 2013 Page 7

HP MyDisplay
HP ePrint (driver)
Power Supply External 87% efficient 90watt power adapter: 19V/4.7A
Service and Support On-site Warranty: One-year (1-1-1) limited warranty delivers one year of on-site, next business-day
service for parts and labor and includes free telephone support
Note 1
24 x 7. To choose the right level of
service for your HP product, use the HP Care Pack Services Lookup Tool at: hp.com/go/lookuptool .
Additional HP Care Pack Services information by product is available at: hp.com/hps/carepack .
NOTE 1: Technical telephone support applies only to HP-configured Compaq and third-party HP-qualified
hardware and software.
QuickSpecs
HP 1155 All-in-One Desktop PC
Standard Features (availability varies by configuration and by country)
DA - 14569 North America — Version 1 — May 6, 2013 Page 8

System Unit Dimensions (WxDxH) 18.74 x3.94x14.92 in
476.00 x100.00x379.00 mm
Weight 13.23 lbs / 6.00 kg
Shipping Carton
Dimensions (WxDxH)
24.37 x6.30x19.49 in
619.00 x160.00x495.00 mm
Shipping Carton Weight 19.27 lbs / 8.74 kg
Pallet (32 units)
Dimensions (WxDxH)
47.24x39.39x82.95 in
1200.00 x1000.00x2107.00 mm
Pallet (32 units) Weight 479.01 lbs / 217.24 kg
Stand-Alone Power
Requirements
Electrical Ratings 100-240 V, 50/60 Hz, 2.0 A
Idle Operating Power 30W
Max Operating Power <90W
Temperature Operating 41° to 95° F (5° to 35° C)
Non-operating -22° to 149° F (-30° to 65° C)
Relative Humidity Operating 15% to 80% @ 26º C
Altitude
(unpressurized)
Operating 0 to 6,500 ft (0 to 2000 m)
Non-operating 0 to 15,000 ft (0 to 4,572 m)
Industry Standard
Certification
UL Yes
CUL Yes
FCC Compliance Yes
ENERGY STAR® Yes (for Windows OS only)
EPEAT Silver** (for Windows OS only)
Environmental Low Halogen Yes ( External accessories, including power
supplies, power cords, and peripherals may not be
Low Halogen.)
Arsenic-free display Yes
For accessibility information on HP products, please visit: hp.com/accessibility.
* Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level,
no direct sustained sunlight. Maximum rate of change is 10 deg C/Hr. The upper limit may be limited by the
type and number of options installed.
** Where HP registers commercial desktop products. See epeat.net for registration status in your country.
QuickSpecs
HP 1155 All-in-One Desktop PC
Technical Specifications
DA - 14569 North America — Version 1 — May 6, 2013 Page 9

Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:
US ENERGY STAR®
IT ECO declaration
EPEAT® Silver where HP registers Integrated desktop products. See http://www.epeat.net for
registration status in your country.
System Configuration The configuration used for the Energy Consumption and Declared Noise Emissions data for the All in One
Desktop model is based on a typically configured product.
Energy Consumption 115 VAC 230 VAC 100 VAC
Normal Operation 15.9270 W 16.5927 W 17.4918 W
Sleep (Energy Star low
power mode)
1.0332 W 1.1256 W 1.0272 W
Off 0.4920 W 0.5568 W 0.4872 W
NOTE: Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the model
family. HP computers marked with the ENERGY STAR® Logo are compliant with the applicable U.S.
Environmental Protection Agency (EPA) ENERGY STAR® specifications for computers. If a model family
does not offer ENERGY STAR® compliant configurations, then energy efficiency data listed is for a typically
configured model.
Heat Dissipation * 115 VAC 230 VAC 100 VAC
Normal Operation 54 BTU/hr 57 BTU/hr 60 BTU/hr
Sleep 4 BTU/hr 4 BTU/hr 4 BTU/hr
Off 2 BTU/hr 2 BTU/hr 2 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one
hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
System Fan Off Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Idle 2.9 26
Fixed Disk
(random writes)
3.1 26
Longevity and Upgrading This product can be upgraded, possibly extending its useful life by several years. Upgradeable features
and/or components contained in the product may include:
Intel LGA775 processor socket
8 USB ports
1 empty PCI slot (w/ optional PCI riser card), or
1 empty PCIe x16 slot (w/optional PCIe riser card)
1 internal drive slot
1 Slimline optical drive slot
3 memory slots
1 Serial/Parallel Port (optional)
Spare parts are available throughout the warranty period and or for up to "5" years after the end of
production
QuickSpecs
HP 1155 All-in-One Desktop PC
Technical Specifications
DA - 14569 North America — Version 1 — May 6, 2013 Page 10

Batteries This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
Battery size: CR2032 (coin cell)
Battery type: Lithium
Additional
information
This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive -
2002/95/EC.
This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water
and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the Silver where HP registers
commercial desktop products. See http://www.epeat.net for registration status in your country.
Plastics parts weighing over 25 grams used in the product are marked per ISO 11469 and ISO1043.
This product contains 2.8% post-consumer recycled plastic (by wt.)
This product is 95.1% recyclable when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Cardboard & misc 920 g
PAPER/Corrugated 129 g
Internal:
PLASTIC/EPE-Expanded Polyethylene 372 g
The PAPER/Cardboard & misc packaging material is made from 25% recycled content.
The PAPER/Corrugated packaging material is made from 25% recycled content.
The PLASTIC/EPE-Expanded Polyethylene packaging material is made from 0% recycled content
RoHS Compliance Hewlett-Packard is committed to compliance with all applicable environmental laws and regulations,
including the European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to exceed
compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis. By July 1,
2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for all HP
electronic products subject to the RoHS Directive, except where it is widely recognized that there is no
technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
MATERIAL USAGE
This product does not contain any of the following substances in excess of regulatory limits (for reference of these limits please refer
to the HP General Specification of the Environment
( http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/gen_specifications.html ):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
QuickSpecs
HP 1155 All-in-One Desktop PC
Technical Specifications
DA - 14569 North America — Version 1 — May 6, 2013 Page 11

Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been voluntarily removed from most
applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Nickel finishes that release greater than 0.5 µgrams/cm
2
/week, measured according to EN 1811:1998, are not used on any
product surface designed to be frequently handled or touched by users.
END-OF-LIFE MANAGEMENT AND RECYCLING
Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product,
please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office. Products returned to HP will be recycled,
recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by
treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at:
http://www.hp.com/go/recyclers . These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
HEWLETT-PACKARD CORPORATE ENVIRONMENTAL INFORMATION
For more information about HP's commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Environment website
http://www.hp.com/environment
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/operations/envmanagement.html
QuickSpecs
HP 1155 All-in-One Desktop PC
Technical Specifications
DA - 14569 North America — Version 1 — May 6, 2013 Page 12

Copyright © 2013 Hewlett-Packard Development Company, L.P.
All rights reserved. Microsoft, Windows and Windows 7 are registered trademarks or trademarks of Microsoft Corporation in the U.S.
and/or other countries. Intel and Core are registered trademarks or trademarks of Intel Corporation in the U.S. and/or other countries.
Bluetooth is a registered trademark of Bluetooth SIG, Inc., in the U.S. and other countries. All other product names mentioned herein
may be trademarks of their respective companies.
The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The
warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein
should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions
contained herein.
QuickSpecs
HP 1155 All-in-One Desktop PC
Technical Specifications
DA - 14569 North America — Version 1 — May 6, 2013 Page 13
