Runtime Power Management
v1.0
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
What is EIST? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
What is Cool’n’Quiet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Why are EIST and Cool’n’Quiet needed? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
What are the required components for EIST and Cool’n’Quiet to function? . . . . . . . . . . . . . .2
How will EIST and Cool’n’Quiet impact HP Customers? . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Advantages of using EIST/Cool’n’Quiet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Disadvantages of using EIST/Cool’n’Quiet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Known Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Resources for EIST and Cool’n’Quiet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2
Introduction
Computer processor manufacturers are incorporating the ability to manage power use directly into their
newer processors. Processors recently released by both Intel and AMD include features that work with the
BIOS and operating system to lower power consumption. Along with being more environmentally friendly,
reduced power consumption results in reduced heat production. Less heat means lower fan speed require-
ments, thereby providing quieter, more efficient computers.
What is EIST?
Enhanced Intel SpeedStep Technology (EIST) is the term Intel uses for its processor power management
technology. This processor feature allows the system to dynamically adjust processor voltage and core fre-
quency as often as is required to decrease power consumption and decrease heat production. The pro-
cessor alters performance by changing bus-to-core frequency ratio and voltage. Only the internal core
frequency is altered - the front side bus (FSB) is not affected. To run at reduced power consumption, the
voltage is changed in step with the bus ratio.
What is Cool’n’Quiet
Cool’n’Quiet is the term AMD uses for its processor power management technology. This processor fea-
ture dynamically adjusts the operating frequency and voltage of a processor up to 30 times per second
depending on the CPU load. When full processor performance is not needed, the processor slows its fre-
quency, resulting in significant power savings, which results in cooler and quieter performance.
While Cool’n’Quiet technology is new to desktop processors, a similar technology from AMD has been
used in mobile processors for several years. This mobile processor technology is known as PowerNow!
Why are EIST and Cool’n’Quiet needed?
EIST and Cool’n’Quiet were created to lower power consumption when software activity does not require
the full capabilities of the processor. Reduced power consumption means reduced operating costs and
reduced heat production. Reduced heat production means reduced fan speed requirements. Reduced fan
speed requirements also mean reduced system noise.
This technology is also especially useful for portable computers, as reduced power consumption leads to
increased battery life.
What are the required components for EIST and Cool’n’Quiet to function?
For a system to take advantage of EIST or Cool’n’Quiet, the following system components must support the
feature:
•Processor
•Chipset
•System BIOS
•Operating system
•Processor driver

3
Processor
Intel’s 600 and 800 series processors support EIST. AMD’s Athlon 64 line of processors support
Cool’n’Quiet. Both technologies may become a standard feature for future processors.
Chipset
EIST requires the Intel 915 or later chipset. Current HP business desktop systems with qualifying chipsets
include:
Intel 915:
•dc5100
•dc7100
•dx6100 (not available in North America)
Intel 945:
•dc7600
•dx7200 (not available in North America)
Cool’n’Quiet requires the ATI RS480/SB400 (Radeon Xpress) chipset. Current HP business desktop sys-
tems with qualifying chipsets include:
ATI RS480/SB400:
•dx5150
System BIOS
You can enable or disable the Runtime Power Management (RTPM) option in the BIOS of Intel 915 and
945-based systems. This option is located in F10 Setup in the Power/OS Power Management sec-
tion. The default EIST BIOS support setting depends on several factors:
Thermal Monitor 2 (TM2) is an older Intel processor feature that allows CPU throttling to slow down the
processor. EIST will replace TM2. Some older processors support TM2, but do not support EIST, while
even older processors do not support either TM2 or EIST. All processors shipped with HP i915 and i945
systems support both EIST and TM2.
You can enable Runtime Power Management (RTPM) on systems that only support TM2. This setup allows
the BIOS to control processor throttling. EIST uses the operating system to control throttling.
EIST Support TM2 Support Default Runtime Power Management (RTPM) Setting
Yes Yes RTPM Option Shown in F10 Setup - Enabled
No Yes RTPM Option Shown in F10 Setup - Disabled
No No RTPM Option Not Shown in F10 Setup

4
For processors that support both EIST and TM2, CPU throttling is controlled by EIST and the operating sys-
tem. The HP BIOS controls CPU throttling on TM2-only processors, resulting in support for RTPM. See
“Known Issues” on page 9 for possible compatibility issues. There is no RTPM capability for processors
that do not support EIST or TM2.
You can enable or disable the AMD Cool’n’Quiet option in the BIOS of the HP dx5150. This option is
located in F10 Setup in the Power Management Options section. The default Cool’n’Quiet support
for HP dx5150 systems is set to Auto (enabled).
Operating System
Microsoft implemented EIST support in Windows XP Service Pack 2. All future Microsoft operating systems
will include EIST support.
Several Microsoft operating systems support Cool’n’Quiet, including Windows XP, Windows 2000, and
Windows ME. All future Microsoft operating systems will include Cool’n’Quiet support.
Processor Driver
Microsoft Windows controls the performance of a processor with the kernel power policy manager, a pro-
cessor driver, and the system BIOS. The kernel power policy manager sets the rules for using the correct
performance state at a given time. Once the performance state is determined, Windows uses the proces-
sor driver or system BIOS to make the changes. The processor driver changes the performance state if the
processor is not Hyper-Threaded (HT). The system BIOS changes the performance state if the processor is
HT-enabled.
The use of a processor driver, such as the generic processr.sys, allows Windows to interact and control
different processors - for example, Intel, AMD, and Transmeta. Vendor-specific processor drivers are also
available, such as intelppm.sys for Intel processors in Windows XP Service Pack 2. You can add support
for future processors, if needed.
The processor performance control policy is linked to the power management scheme. See the table in
the Power Management Scheme section for detailed information about the relationship between power
management scheme and control policy.
There are four control policies:
•Constant - Always runs at lowest performance state.
•Adaptive - CPU usage determines performance state.
•Degrade - Starts at lowest performance state and slowly reduces performance as battery discharges
(notebooks only).
•None - Always runs at highest performance state.

5
Power Management Scheme
EIST will function only if the operating system is using an adaptive power management scheme. The fol-
lowing table shows the relationship between power scheme and the control policy used.
For more information about processor performance control, go to:
http://www.microsoft.com/whdc/system/pnppwr/powermgmt/ProcPerfCtrl.mspx
Power Scheme - Adaptive or Not
An adaptive power scheme allows the operating system to dynamically adjust performance of a processor
(frequency and voltage) according to the amount of processor usage. You can determine whether a
power management scheme is adaptive. If a power management scheme has not been modified, it will
have the default processor performance control policy. However, a modified power scheme will not pro-
vide external notification regarding its current control policy.
To verify processor performance control policy, perform the following steps:
1. Click Start > Run.
2. Type CMD.
3. Type powercfg /query.
The system displays the current power configuration. Processor Throttle <AC> and Processor
Throttle <DC> indicate which control policy is implemented when the system is using AC power or bat-
tery power.
Power Scheme AC Power DC Power
Home/Office Desk None Adaptive
Portable/Laptop Adaptive Adaptive
Presentation Adaptive Degrade
Always On None None
Minimal Power Management Adaptive Adaptive
Max Battery Adaptive Degrade

6
Home/Office Desk in default state
Home/Office Desk in adaptive state

7
System Properties - EIST
The System Properties window displays current processor speed on computers installed with an EIST-capa-
ble processor and Windows XP Service Pack 2 that are using an adaptive power scheme. The following
images illustrate a drop in processor speed for an Intel Pentium 4 system (3.4 GHz) under throttled condi-
tions with EIST both enabled and disabled.
Maximum Processor Speed
You can check the maximum speed setting for systems with EIST or Cool’n’Quiet enabled by performing
the following steps:
1. Click Start > All Programs > Accessories > System Tools > System Information.
2. Locate the Processor listing.
The maximum speed of the processor (listed in MHz) displays in the right pane next to Processor.
The System Information screen reports only the maximum speed of the processor.

8
System Properties - Cool’n’Quiet
The System Properties window displays current processor speed on computers installed with a
Cool’n’Quiet-capable processor and Windows XP Service Pack 2 that are using an adaptive power
scheme. The following images illustrate a drop in processor speed for an AMD Athlon 64 3800+ system
(2.4-GHz) under throttled conditions with Cool’n’Quiet enabled and disabled.
How will EIST and Cool’n’Quiet impact HP Customers?
HP tests its images and deliverables for EIST and Cool’n’Quiet compatibility. These tests include:
•Applications bundled with HP bPC computers
•Operating system images bundled with HP bPC computers
•Peripheral drivers bundled with HP bPC computers
•Samples of popular applications and games
By default, the Home/Office Desk power scheme that is shipped with the HP image is non-adaptive.
This means that under normal circumstances, a system will not see any power saving benefits with an EIST
or Cool’n’Quiet capable processor. HP resolves this issue by making the Home/Office Desk power
scheme adaptive using the Microsoft supplied powercfg.exe utility. During unbundling, if the system con-
tains an EIST or Cool’n’Quiet- capable processor, the Home/Office Desk power scheme is modified.

9
Advantages of using EIST/Cool’n’Quiet
Enabling EIST/Cool’n’Quiet provides the following benefits:
•Increased power savings.
•Lower operating costs.
•Less heat production.
•Potential for less noise from slow fan speeds.
Disadvantages of using EIST/Cool’n’Quiet
There are no known disadvantages to using EIST/Cool’n’Quiet if you use the latest HP BIOS and/or the
latest service packs for Microsoft operating systems.
Known Issues
•There are known EIST compatibility issues for i915/i945 systems using older Intel processors, older
HP BIOS, and older Windows XP service packs. These problems may include both Windows blue
screens and operating system hangs/delays. These issues have been fixed in the following:
• HP BIOS for DDR i915 systems - 786C1 v2.14 or later
• HP BIOS for DDR2 i915 systems - 786C2 v1.06 or later
• Windows XP Service Pack 2
• Windows Server 2003 Service Pack 1
Systems running Windows XP Service Pack 2 with older Intel processors that only support TM2 do not
provide RTPM capability. Windows XP Service Pack 2 supports RTPM for only EIST processors.
•Windows XP may report inaccurate processor speed. For more information about this issue, as well
as information about determining processor speed, see the following Microsoft Knowledge Base arti-
cles:
http://support.microsoft.com/default.aspx?scid=kb;en-us;316965&Product=winxp
http://support.microsoft.com/default.aspx?scid=kb;en-us;888282
•Windows XP on portable computers may display the following message: STOP 0x000000D1. For
more information about this error message, see the following Microsoft Knowledge Base article:
http://support.microsoft.com/default.aspx?scid=kb;en-us;888399

10
Resources for EIST and Cool’n’Quiet
The following web sites provide additional information about EIST and Cool’n’Quiet.
http://www.intel.com/cd/channel/reseller/asmo-na/eng/products/box_processors/desktop/
proc_dsk_p4/technical_reference/203838.htm
http://www.amd.com/us-en/Processors/ProductInformation/0,,30_118_9485_9487%5E10272,00.html
http://www.amd.com/us-en/Processors/TechnicalResources/0,,30_182_871_9706,00.html
Frequently Asked Questions
Q: How can I verify if my electricity bill is actually lower?
A: To perform an isolated test, you can hook the system up to a power meter to see how much power a
computer uses when EIST is on or off.
Q: Does the “speedstep” or “Cool’n’Quiet” feature cost more?
A: These features are incorporated into newer processors and have minimal affect on processor pricing.
Q: What will the lower power do to the performance of my system?
A: The lower power consumption has no affect on perceived system performance. While the system does
operate at a reduced speed, it only does so for applications that require lesser speeds, so the actual
performance of these applications is not affected. You will not see a performance drop since the
processor only throttles down when the extra speed would have been wasted anyway.
Q: If an application requires more performance, how long will it take the system to return to full
performance state?
A: When the processor determines that greater performance is required, it can return to full performance
state immediately. The user will perceive no loss in performance.
Q: Does the constant variation in processor speed reduce the quality of the product?
A: No. In actuality, the added functionality provided by the ability to vary processor speed increases the
quality of the product.

11
Q: Does the integration of this functionality imply that the processor speeds available are really too great
for standard needs?
A: No. This functionality simply provides more flexibility when you use applications that require less
processor performance. Today’s world constantly offers more applications that require greater
processor performance. And while you may use these resource-intensive applications, you will likely
also use applications, such as email, that do not require full processor capability.
Q: If I have a system that supports this – can I turn it off in the BIOS without disrupting the system
configuration or the software image?
A: Yes, you can turn off EIST/Cool’n’Quiet support in the BIOS at any time with no software impact.
Doing so simply means you will not conserve power.
Q: If after the feature is turned on and runs for a while, if the system performance worsens, should I turn
the feature off before calling support?
A: Turning off the feature can be a good debug step before calling support. However, if performance
worsens after a significant amount of time, the chances of a relation to EIST is low. Testing has
indicated no noticeable performance degradation.
© copyright 2005 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without
notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for
technical or editorial errors or omissions contained herein.
HP, Hewlett Packard, and the Hewlett-Packard logo are trademarks of Hewlett-Packard Company in the U.S. and other countries.
Microsoft, MS-DOS, Windows, and Windows NT are trademarks of Microsoft Corporation in the U.S. and other countries.
Intel, Pentium, Intel Inside, and Celeron are trademarks of Intel Corporation in the U.S. and other countries. AMD and Cool 'n'
Quiet are trademarks of Advanced Micro Devices, Inc.
This document contains proprietary information that is protected by copyright. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written consent of Hewlett-Packard Company.
398598-001, 07/2005
