With its revolutionary new architecture and
power that will redene multi-tasking, the
HP Z400 Workstation helps you accomplish more
with every minute of your time and every dollar of
your investment.
Innovation that will transform the way you work
With a smart new chassis that is easy to service,
optional liquid cooling, and quiet operation to
blend unobtrusively into your work environment,
the HP Z400 Workstation showcases HP
innovation—inside and out.
• Minimize power and cooling costs with
ENERGY STAR® qualied congurations
featuring 85% efcient power supplies and
HP WattSaver which, when activated, lowers
energy consumption to less than 1 Watt in
off mode
• See, share, and show your work across the
world with built-in HP SkyRoom collaboration
solution which combines real-time 3D graphics
sharing and video conferencing
Performance to help you accomplish more with
every minute
Take on bigger computing challenges with the
new Intel® QuickPath Technology and your choice
of the latest dual- or quad-core Intel® Xeon®
processors.
1
• Run more tasks, processes, and applications
simultaneously with a workstation that brings
together and optimizes the latest processors,
memory, graphics, and storage technologies
• Choose from a wide range of professional
graphics from NVIDIA and ATI as well as from
a breadth of OS options.
Reliability derived from our legendary,
condence-inspiring quality
• Close relationships with ISVs help ensure
that HP Workstations are fully certied and
optimized for your applications
• In-depth testing and quality assurance keep you
productively up-and-running
• HP Performance Tuning Framework helps ease
conguration and updates while optimizing a
range of applications
• Quickly capture complete system conguration
data and share it with IT personnel with
HP Vision Field Diagnostics, an easy-to-use
system diagnostics tool that runs outside the OS
• Comprehensive, lifetime HP Total Care options,
easy HP nancing solutions, and an array of
monitors and other accessories make
HP Workstations easy to own and use
Raising the bar
for entry
workstations
HP z400 Workstation
Windows®. Life without Walls™. HP recommends Windows 7.

HP z400 Workstation
Form factor Convertible minitower
Operating systems Genuine Windows® 7 Professional 32-bit*
Genuine Windows® 7 Professional 64-bit*
Genuine Windows® XP Professional 32-bit available through downgrade rights from Windows® 7 Professional 32-bit*,=,==
Genuine Windows® XP Professional 64-bit available through downgrade rights from Windows® 7 Professional 64-bit*,=,==
Genuine Windows® XP Professional 32-bit available through downgrade rights from Windows Vista® Business**,=
Genuine Windows® XP Professional 64-bit available through downgrade rights from Windows Vista® Business**,=
Genuine Windows Vista® Business 32-bit**
Genuine Windows Vista® Business 64-bit**
Genuine Windows Vista® Home Basic 32-bit=
HP Installer Kit for Linux (includes drivers for both 32-bit and 64-bit OS versions of Red Hat Enterprise Linux WS4 and WS5)
Novell Suse SLED 11 Linux
Red Hat Enterprise Linux WS5 (as drop-in-the-box only)
Available processors Intel® Xeon® processor1,2 W35033, 2.40 GHz, 4 MB cache, 1066 MHz memory, 4.8GT/s QPI, Dual-Core
Intel Xeon processor1,2 W35053, 2.53 GHz, 4 MB cache, 1066 MHz memory, 4.8GT/s QPI, Dual-Core
Intel Xeon processor1,2 W35203, 2.66 GHz, 8 MB cache, 1066 MHz memory, 4.8GT/s QPI, Quad-Core, HT, Turbo
Intel Xeon processor1,2 W35503, 3.06 GHz, 8 MB cache, 1066 MHz memory, 4.8GT/s QPI, Quad-Core, HT, Turbo
Intel Xeon processor1,2 W35653, 3.20 GHz, 8 MB cache, 1066 MHz memory, 4.8GT/s QPI, Quad-Core, HT, Turbo
Intel Xeon processor1,2 W35803, 3.33 GHz, 8 MB cache, 1333 MHz memory, 6.4GT/s QPI,Quad-Core, HT, Turbo
HP Liquid Cooling Solution (optional)
Chipset Intel® X58 Express
Memory46 DIMM slots, up to 24 GB DDR3 1333 MHz** (**actual memory speed dependent on processor capability)
Drive controllers5Integrated SATA 3 GB/s controller, RAID 0, 1, 5, 10 capable; Optional SAS controller, LSI 3041E 4-port SAS/SATA, RAID 0, 1, 10 capable
Hard drive(s)6Up to (4) 3.5-inch 7200 rpm SATA drives: 160, 250, 320, 500 GB, 1, 1.5 TB, 6 TB max; Up to (4) 2.5-inch 10K rpm SATA drives: 160, 300 GB SFF, 1.2
TB max; Up to (4) 3.5-inch 15K rpm SAS drives: 146, 300, 450 GB, 1.8 TB max
Optical drives7,8 DVD-ROM, DVD+/-RW, Blu-Ray Writer
Drive bays 3 external 5.25-inch bays, 2 internal 3.5-inch HDD bays (4 max with converter)
Slots 2 PCI Express Gen2 x16, 1 PCI Express Gen2 x8 mechanical/x4 electrical, 1 PCI Express Gen1 x8 mechanical/x4 electrical, 2 PCI
Graphics
(dual graphics on selected
cards)
Professional 2D: NVIDIA Quadro NVS 295 (256 MB), NVIDIA Quadro NVS 450 (512 MB)
Entry 3D: NVIDIA Quadro FX 380 (256 MB), ATI FirePro V3700 (256 MB), NVIDIA Quadro FX 580 (512 MB)
Midrange 3D: NVIDIA Quadro FX 1800 (768 MB), ATI FirePro V5700 (512 MB)
High-end 3D: NVIDIA Quadro FX 3800 (1 GB), ATI FirePro V7750 (1 GB), NVIDIA Quadro FX 4800 (1.5 GB), Elemental Accelerator
Software for NVIDIA Quadro
Audio High Denition Integrated Realtek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB Powered Speakers
Network Integrated Broadcom 5764 LAN, Inneon TPM 1.2 controller, optional Broadcom NIC, optional Intel NIC
Ports Front: 2 USB 2.0, IEEE 1394a standard, or IEEE 1394b optional via add-in card; 1 microphone in, 1 headphone out, HP 22-in-1 Media
Card Reader
Rear: 6 USB 2.0, 2 optional IEEE 1394a or IEEE 1394b ports via add-in PCI card; 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 1 RJ-45
to integrated Gigabit LAN, 1 serial (optional)
Internal: 4 USB 2.0; supports up to two HP Internal USB Port Kits (one port on each Kit), up to two USB Media Card Readers, or one
Internal Port kit and one USB Media Card Reader
Input devices PS/2 standard keyboard, USB standard keyboard, USB Smart Card Keyboard, PS/2 optical scroll mouse, USB 2-button optical scroll mouse,
USB 3-button optical mouse, USB SpaceExplorer, USB SpacePilot, USB Laser Scroll Mouse
Dimensions (H x W x D) 17.7 x 6.6 x 17.9 in (45.02 x 16.79 x 45.53 cm)
Power supply 475-Watt 85% efcient power supply
Monitors (screen size
diagonally measured)
HP LP1965 19-inch LCD Monitor, HP LP2065 20-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch
Widescreen LCD Monitor, HP DreamColor LP2480zx Professional Display (24-inch diagonal widescreen), HP LP3065 30-inch Widescreen
LCD Monitor
Warranty Limited three-year next business day9, parts, labor and 24 x 7 phone support; Terms and conditions may vary.
* Windows 7 systems may require upgraded and/or separately purchased hardware and/or a DVD drive to install the Windows 7 software and take full advantage of Windows 7 functionality.
See http://www.microsoft.com/windows/windows-7/ for details.
**Certain Windows Vista product features require advanced or additional hardware. See http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and www.microsoft.com/windowsvista/getready/capable.mspx
for details. Windows Vista Upgrade Advisor can help you determine which features of Windows Vista will run on your computer. To download the tool, visit http://www.windowsvista.com/upgradeadvisor.
= Windows Vista Business disk may also be included for future upgrade if desired. To qualify for this downgrade an end user must be a business (including governmental or educational institutions) and is expected to order at
least 25 customer systems with the same custom image.
== Windows XP Professional is preinstalled on this system and includes end user rights and media for Windows 7 Professional. You may only use one version at a time. You must back up all data (files, photos, etc.) before
uninstalling operating systems to avoid loss of your data.
1 Dual-Core and Quad-Core technologies are designed to improve performance of multithreaded software products and hardware-aware multitasking operating systems and may require appropriate operating system software for
full benets; check with software provider to determine suitability; Not all customers or software applications will necessarily benet from use of these technologies.
2 64-bit computing on Intel architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers and applications enabled for Intel® 64 architecture. Processors will not operate (including
32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary depending on your hardware and software congurations. See http://www.intel.com/info/em64t for more information.
3 Intel’s numbering is not a measurement of higher performance.
4 Each processor supports up to 3 channels of DDR3 memory. To realize full performance at least 1 DIMM must be inserted into each channel.
5 SATA hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software RAID, provides excellent functionality and performance. It is a good alternative to hardware-based RAID. Please visit
http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf for RAID capabilities with Linux.
6 For hard drives, 1 GB = 1 billion bytes. 1 TB = 1 trillion bytes. Actual formatted capacity is less. Up to 8 GB of hard drive (or system disk) is reserved for the system recovery software for Windows XP and XP Pro, up to 12 GB
for Windows Vista, and up to 20 GB for Windows 7.
7 Actual speeds may vary. Does not permit copying of commercially available DVD movies or other copyright protected materials. Intended for creation and storage of your original material and other lawful uses. Double Layer discs
can store more data than single layer discs. However, double-layer discs burned with this drive may not be compatible with many existing single-layer DVD drives and players.
8 As Blu-Ray is a new format containing new technologies, certain disc, digital connection, compatibility and/or performance issues may arise, and do not constitute defects in the product. Flawless playback on all systems is not
guaranteed. In order for some Blu-ray titles to play, they may require a DVI or HDMI digital connection and your display may require HDCP support. HD-DVD movies cannot be played on this workstation.
9 HP Care Pack Services extend service contracts beyond the standard warranties. Service starts from date of hardware purchase. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup
Tool at http://www.hp.com/go/lookuptool. Additional HP Care Pack Services information by product is available at http://www.hp.com/hps/carepack. Service levels and response times for HP Care Packs may vary
depending on your geographic location.
© 2009 – 2010 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP
products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as
constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Intel, Xeon, and QuickPath are
trademarks of Intel Corporation in the U.S. and other countries. Microsoft, Windows, and Windows Vista are trademarks of the Microsoft group of companies.
4AA2-4396ENW, February 2010
