HP BladeSystem c-Class Infrastructure User instructions

HP BladeSystem c7000 Enclosure
HP BladeSystem c7000 EnclosureHP BladeSystem c7000 Enclosure
HP BladeSystem c7000 Enclosure
1. Device Bay 1 13. Device Bay 13
2. Device Bay 2 14. Device Bay 14
3. Device Bay 3 15. Device Bay 15
4. Device Bay 4 16. Device Bay 16
5. Device Bay 5 17. Power Supply Bay 1
6. Device Bay 6 18. Power Supply Bay 2
7. Device Bay 7 19. Power Supply Bay 3
8. Device Bay 8 20. Power Supply Bay 4
9. Device Bay 9 21. Power Supply Bay 5
10. Device Bay 9 22. Power Supply Bay 6
11. Device Bay 11 23. Insight Display
12. Device Bay 12
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
Overview
DA - 12517 North America — Version 13 — July 27, 2007 Page 1

HP BladeSystem c7000 Enclosure - Rear View
HP BladeSystem c7000 Enclosure - Rear ViewHP BladeSystem c7000 Enclosure - Rear View
HP BladeSystem c7000 Enclosure - Rear View
1. Active Cool Fans & fan bays 3. Onboard Administrator
2. Interconnect Bays 4. Power Inputs (single phase model shown)
HP ProLiant & Integrity
HP ProLiant & IntegrityHP ProLiant & Integrity
HP ProLiant & Integrity
Server Blades
Server BladesServer Blades
Server Blades
Delivering best-in-class performance, choice and reliability on AMD Opteron™, Intel® Xeon™, Intel®
Itanium 2™ and processors for Windows, Linux, or HP-UX based servers, the HP portfolio of server
blades supports a variety of application requirements for scale-out architectures. HP offers one-, two-,
and four-processor (dual-core or quad-core) server blades, including the widest range of performance,
and form factors, and the most processing density and performance of any other portfolio. This portfolio
of servers is designed for 32-bit and 64-bit applications.
For more information please see:
http://h18000.www1.hp.com/products/quickspecs/North_America/12534.html
What's New
What's NewWhat's New
What's New
Larger 3 inch display for better viewing angle
Insight Control Environment including RDP, Insight Power Manager, iLO Select License and Virtual Machine Manager
PCI Expansion blade to support additional third-part PCI or PCI-E cards.
Zoned cooling support for better power consumption and greater reliability.
7x24 Phone and free upgrade support included for 1 Year with all software products.
At A Glance
At A GlanceAt A Glance
At A Glance
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
Overview
DA - 12517 North America — Version 13 — July 27, 2007 Page 2

This document covers the HP BladeSystem c-Class Infrastructure only. For more information on HP ProLiant Server Blades and HP
BladeSystem c-Class Interconnect Components please see the following QuickSpecs:
HP ProLiant Server Blades: http://h18000.www1.hp.com/products/quickspecs/North_America/11070.html
HP BladeSystem c-Class Interconnect QuickSpecs: http://h18000.www1.hp.com/products/quickspecs/12524_na/12524_na.HTML
HP BladeSystem solutions start with a c7000 Enclosure, with optional c7000 hot-plug power supplies, HP Active Cool Fans, and an
optional redundant Onboard Administrator module. Once the enclosure has been selected, the following components can be
added: networking interconnect modules, HP ProLiant and Integrity Server Blades, and Insight Control management tools. Reference
the QuickSpecs listed above.
For additional information please visit: http://h18004.www1.hp.com/products/blades/components/components.html
Protected by HP Services and a worldwide network of resellers and service providers. Three-year, on-site limited global warranty.
Certain restrictions and exclusions apply. Pre-Failure Notification on processors, memory, and SCSI hard drives.
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
Overview
DA - 12517 North America — Version 13 — July 27, 2007 Page 3

NOTE:
NOTE:NOTE:
NOTE: For a brief, printer friendly data sheet that describes this product and informs you of the essential capabilities and
specifications, please visit: http://h71028.www7.hp.com/ERC/downloads/4AA0-5978ENW.pdf
HP BladeSystem Overview
HP BladeSystem OverviewHP BladeSystem Overview
HP BladeSystem Overview As server, storage and network technologies have changed; traditional rack-mounted infrastructure
solutions have generated increased complexity of both infrastructure management and physical
datacenter deployment.
HP BladeSystem is the evolution of the entire rack-mounted infrastructure. A BladeSystem reduces costs
and simplifies the management, building, and maintenance of the infrastructure behind your multi-server
environment. It consolidates and repackages all the supporting infrastructure elements-compute,
storage, network, and power into a single platform that can accelerate the integration and optimization
of your data center.
With the flexibility to scale from a single enclosure holding up to 16 blades, to a rack containing 4
enclosures holding up to 64 blades, the c-Class infrastructure is designed to meet the needs of today's
businesses.
An HP BladeSystem c-Class infrastructure is made up of several components:
ProLiant and Integrity Server blades for Windows, Linux, and HP UX.
Choice of AMD or Intel processors, including the latest dual-core processors for 32-bit and 64-bit
applications.
HP BladeSystem c-Class enclosure that provides connectivity, power, and cooling options. The c-
Class enclosure is designed for full redundancy and high availability. Redundant power, cooling,
enclosure management, and interconnect modules are part of the standard enclosure design.
Onboard Administrator module which provides a single point of control for intelligent
management of the entire enclosure.
Insight Display powered by the Onboard Administrator provides local management through an
LCD display conveniently sited on the front of the system.
Ethernet, Fibre Channel, InfiniBand, iSCSI, and other interconnect choices
A power subsystem that provides hot-plug redundant power modes and Dynamic Power Saving
mode, which uses up to 22% less power than traditional rack-mounted servers.
PARSEC (Parallel, Redundant, Scaleable, Enclosure Cooling) architecture: for maximum cooling
that consumes less power and reduces datacenter noise.
Zoned cooling that allows only those fans that are required to speed up, reducing power
consumption noise and airflow through the system.
Direct-attach storage blades, tape blades, or future shared storage blades, which will provide
block-based shared storage capacity for the server blades in the enclosure.
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Overview
DA - 12517 North America — Version 13 — July 27, 2007 Page 4

HP BladeSystem c-Class
HP BladeSystem c-ClassHP BladeSystem c-Class
HP BladeSystem c-Class
c7000 Enclosure
c7000 Enclosurec7000 Enclosure
c7000 Enclosure
A BladeSystem c7000 enclosure holds up to 16 server and/or storage blades plus redundant network
and storage switches. It includes a shared, multi-terabit high-speed mid-plane for wire-once connectivity
of server blades to network and shared storage. Power is delivered through a pooled power backplane
that ensures the full capacity of the hot-plug power supplies is available to all blades.
Each c7000 enclosure is built with the following functions:
Up to 16 half-height and/or up to 8 full-height server blades and/or storage blades per
enclosure.
Up to 4 different interconnect fabrics (Ethernet, FC, IB, iSCSI, SAS, etc.) supported simultaneously
within the enclosure.
Choice of a single-phase or a three-phase power subsystem - for flexibility in connecting to
datacenter power.
PARSEC enclosure design - Parallel, redundant and scalable cooling and
airflow design
Four (4) or Six (6) Active Cool fans as standard. For redundancy and improved power
consumption and acoustics; additional Active Cool Fan kits can be added for a maximum of 10
fans
Fully redundant design-redundant interconnections between servers and interconnect modules; a
mid-plane with no active components; redundant cooling using hot-plug Active Cool fans; hot-
plug power supplies.
Best performance per watt - lower wattage per server blade, in comparison to rack-mounted
servers
Full AC redundancy - with no power zones.
Redundant Onboard Administrator management modules (optional active-standby design)
An Onboard Administrator management module is built in to the enclosure with the following functions:
Robust, multiple enclosure setup and control.
Reports asset and inventory information for the devices in the enclosure.
Reports thermal and power information, including real-time actual power usage per server and
per enclosure.
Front-mounted Insight Display for easy management within the datacenter.
Integrated access to all server blade iLOs from a single cable.
Provides integrated access to interconnect bay device management ports from the single Onboard
Administrator cable.
Single sign-on capability for all devices in the enclosure
Role-based security locally and/or with LDAP directory services.
Provides a wizard-based initial setup process for easy configuration.
A BladeSystem c7000 enclosure provides the following benefits:
With local and remote hardware management integrated across the solution, one full enclosure
can be managed as easily as one server.
Scalable: Management and network interconnects extend scalability beyond a single enclosure,
allowing resources to be pooled and shared across multiple enclosures.
Investment protection: Accommodates multiple server and network designs in one enclosure.
Lower costs per server, in comparison to rack-mounted servers
Lower power consumption, in comparison to rack-mounted servers
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Overview
DA - 12517 North America — Version 13 — July 27, 2007 Page 5

HP ProLiant & Integrity
HP ProLiant & IntegrityHP ProLiant & Integrity
HP ProLiant & Integrity
Server Blades
Server BladesServer Blades
Server Blades
Delivering best-in-class performance, choice and reliability on AMD Opteron™, Intel® Xeon™, Intel®
Itanium 2™ and processors for Windows, Linux, or HP-UX based servers, the HP portfolio of server
blades supports a variety of application requirements for scale-out architectures. HP offers one-, two-,
and four-processor (dual-core) server blades, including the widest range of performance, and form
factors, and the most processing density and performance of any other portfolio. This portfolio of servers
is designed for 32-bit and 64-bit applications.
For more information please see:
http://h18000.www1.hp.com/products/quickspecs/North_America/12534.html
HP SB40c Storage Blade
HP SB40c Storage BladeHP SB40c Storage Blade
HP SB40c Storage Blade The StorageWorks SB40c is a half-height c-Class storage blade featuring support for up to six hot-plug
Small Form Factor (SFF) Serial Attached SCSI (SAS) or Serial ATA (SATA) hard disk drives. The SB40c
connects directly to the adjacent server blade to provide up to 876GB additional storage capacity to that
blade. For maximum fault tolerance the SB40c uses supports hardware RAID 0, 1, 1+0, 5, and 6
(ADG), using the onboard Smart Array P400 with up to 256MB of battery-backed write cache.
For more information please see:
http://h18000.www1.hp.com/products/quickspecs/12587_na/12587_na.HTML
HP StorageWorks Ultrium
HP StorageWorks UltriumHP StorageWorks Ultrium
HP StorageWorks Ultrium
448 Tape Blade
448 Tape Blade448 Tape Blade
448 Tape Blade
The HP StorageWorks Ultrium 448c Tape Blade is ideal for HP BladeSystem c-Class customers who
need a data protection solution but are not connected into a Storage Area Network (SAN). This tape
blade provides direct attach data protection for the adjacent server and network backup protection for
all other data within the enclosure. The HP Ultrium 448c Tape Blade is the first HP StorageWorks tape
product developed exclusively for the BladeSystem c-Class enclosures. For more information, please visit
http://h18000.www1.hp.com/products/quickspecs/12729_na/12729_na.HTML .
HP BladeSystem c-Class
HP BladeSystem c-ClassHP BladeSystem c-Class
HP BladeSystem c-Class
Interconnect Options
Interconnect OptionsInterconnect Options
Interconnect Options
HP also offers one of the broadest selections of interconnect fabric options in the industry to provide
network, SAN/network attached storage (NAS), and cluster connectivity.
HP BladeSystem interconnects provide:
Virtual Connect Ethernet and Fibre Channel to simply connections moves and changes in both the
Ethernet and SAN environment.
Seamless integration of Ethernet, FC, InfiniBand, iSCSI, and SAS fabrics: Standard-based switch
options include Cisco, Brocade, and HP (BNT) products that integrate within your existing
standards.
Built-in redundancy: Rear-mounting interconnect modules designed for redundant
interconnections between server blades and switches.
Cable reduction: Interconnect switches provide up to 32-to-1 network cable reductions per server
blade enclosure
For more information HP BladeSystem c-Class Interconnect Components, please visit:
http://h18000.www1.hp.com/products/quickspecs/12524_na/12524_na.HTML
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Overview
DA - 12517 North America — Version 13 — July 27, 2007 Page 6

Factory Express Portfolio
Factory Express PortfolioFactory Express Portfolio
Factory Express Portfolio
for Servers and Storage
for Servers and Storagefor Servers and Storage
for Servers and Storage
HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading, asset
tagging and custom packaging. HP products supported through Factory Express include: a wide array of
servers and storage: HP Integrity, HP ProLiant & HP ProLiant & Integrity Server Blades, HP BladeSystem,
HP 9000 servers as well as the MSA1000, VA7xxx, EVA, XP, rackable tape libraries and configurable
network switches.
For more information on Factory Express services for your specific server model please contact your sales
representative or go to http://www.hp.com/go/factory-express
Insight Control
Insight ControlInsight Control
Insight Control
Environment for
Environment forEnvironment for
Environment for
BladeSystem
BladeSystemBladeSystem
BladeSystem
Starting July 9, 2007, HP Insight Control management suites and most HP ProLiant Essentials will
include one year of 24 x 7 HP Software Technical Support and Update Service ensuring rapid access to
HP support staff and proactive delivery of software updates. From more information about this service,
please visit: http://www.hp.com/services/insight .
Insight Control Environment for BladeSystem delivers foundation management for HP BladeSystem
lifecycles, including hardware resource deployment, health monitoring, software version control,
performance monitoring, vulnerability scanning and patch management.
Installs and licenses the following components by default using a wizard-based integrated installer:
HP Systems Insight Manager
HP iLO Select Pack
HP Insight Power Manager
HP ProLiant Essentials Rapid Deployment Pack
HP ProLiant Essentials Performance Management Pack
HP ProLiant Essentials Vulnerability and Patch Management Pack
HP ProLiant Essentials Virtual Machine Management Pack
Additional ProLiant Essentials software and management tools included on the Insight Control
Management DVD can be installed manually.
Server Migration Pack
HP Open Service Event Manager
HP Instant Support Enterprise Edition
NOTE:
NOTE:NOTE:
NOTE: Server Migration Pack - Physical to ProLiant Edition can be installed from the SMP-P2P CD
included in the Insight Control Management media kit.
NOTE:
NOTE:NOTE:
NOTE: Insight Control Data Center Edition can be installed from the Insight Control Management DVD,
which can be delivered with HP BladeSystem c-Class enclosures with a choice of licensing options.
Licensing options include a free 30 day evaluation license for 8 servers (default option for every
enclosure order), a full purchased license for 8 blade servers or a full purchased license for 16 blade
servers). For additional information on HP c-Class Infrastructure please visit: HP BladeSystem c-Class
Infrastructure QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12517_na/12517_na.HTML
NOTE:
NOTE:NOTE:
NOTE: For additional product and licensing information about Insight Control Environment for
BladeSystem, HP Systems Insight Manager and Essentials software refer to
http://www.hp.com/servers/proliantessentials .
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Overview
DA - 12517 North America — Version 13 — July 27, 2007 Page 7

HP Insight Control Linux
HP Insight Control LinuxHP Insight Control Linux
HP Insight Control Linux
Edition
EditionEdition
Edition
HP Insight Control Linux Edition for HP BladeSystem is a blade-centric Linux management and
deployment software package that provides administration and control of HP BladeSystem servers. It is
the latest version of what was formerly known as HP Control Tower. This software is built on Linux and
open source components and delivers deployment and in-depth management of HP BladeSystem
ProLiant servers.
The HP Insight Control Linux Edition provides these key capabilities:
Easy to use interface that is tailored to the specific tasks and operations unique to blade and Linux
users
Discovery, health monitoring and alerting, and control operations for HP BladeSystem through a
secure, web-based console
Easy to use, flexible task chain operations for deployment and change management tasks
One to many operating system provisioning of HP BladeSystem c-Class and p-Class servers
Detailed blade rack visualization combined with an interface to HP BladeSystem Onboard
Administrator (OA) enclosure management module and HP's Integrated Lights-Out (iLO) and iLO
2 remote management processor
Secure and separate management network unites deployment, monitoring and remote
management for all types of customer networking environments
Modular design provides easy extensibility for future additions and functionality
NOTE:
NOTE:NOTE:
NOTE: Insight Control Linux Edition can be delivered with HP BladeSystem c--Class enclosures with a
choice of licensing options, which include a free 30-day evaluation license for 8 servers (default option
for every enclosure order), a full purchased license for 8 blade servers or a full purchased license for 16
blade servers).
HP Software Support
HP Software SupportHP Software Support
HP Software Support Starting in July 2007, HP Insight Control Environment for BladeSystem and Insight Control Linux Edition
will include one year of 24 x 7 HP Software Technical Support and Update Service. This service provides
access to HP technical resources for help in resolving software implementation or operations problems.
The service also provides access to software updates and reference manuals either in electronic form or
on physical media as they are made available from HP.
With this service, HP Insight Control Environment for BladeSystem and Insight Control Linux Edition
customers will benefit from expedited problem resolution and proactive notification and delivery of
http://www.hp.com/go/ice software updates.
To activate your HP Software Technical Support and Update Service for HP Insight Control Environment
for BladeSystem and Insight Control Linux Edition, you must register your software purchase through the
HP website at http://www.hp.com/services/insight .
Failure to register your service will jeopardize service fulfillment.
Your Service Agreement Identifier (SAID) will be delivered to you after registration. After you have
received your SAID, you can go to the software update manager (SUM) web page to view your contract
online and elect electronic delivery (in addition to standard media-based updates). For more information
about this service, see http://www.hp.com/services/insight .
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Overview
DA - 12517 North America — Version 13 — July 27, 2007 Page 8

Unified Core Services and
Unified Core Services andUnified Core Services and
Unified Core Services and
Flexible
FlexibleFlexible
Flexible
Software Extensions
Software ExtensionsSoftware Extensions
Software Extensions
HP Systems Insight
Manager
HP Systems Insight Manager (HP SIM) provides a unified, secure and
extensible standards-based environment to centrally manage servers, storage
and other infrastructure devices, (both HP and non-HP) across multiple
operating system platforms.
ProLiant Essentials Rapid
Deployment Pack
Rapid Deployment Pack (RDP) extends HP Systems Insight Manager with a
complete deployment solution for HP ProLiant blade servers. RDP provides a
central location to configure server hardware, deploy Windows, Linux and
VMware ESX operating environments and install HP ProLiant Support Pack
drivers using images and scripted profiles.
ProLiant Essentials
Performance Management
Pack
Performance Management Pack (offered exclusively through the Insight
Control suites) - a performance management solution that identifies and
explains hardware performance bottlenecks on ProLiant servers and attached
options enabling users to better utilize their valuable resources.
Insight Management
Agents
The Insight Management Agents should be installed on all HP servers to
present system instrumentation, health and configuration information into HP
Systems Insight Manager and the HP System Management Homepage. The
HP System Management Homepage aggregates systems data from Insight
Management Agents and other HP management tools, providing a
consolidated browser-based interface for managing individual servers.
Insight Management Agents and The HP System Management Homepage
are included on ProLiant Support Packs, and can also be installed using the
server profiles provided with the ProLiant Essentials Rapid Deployment Pack
For additional information about the Management Agents and the HP System
Management Homepage please visit the management Web site at
http://www.hp.com/servers/manage .
Subscriber's Choice Subscriber's Choice Driver and Support Alerts/Notifications is a web-based
email subscription service that provides software and driver change
notifications for ProLiant products. Sign up at
http://www.hp.com/go/subscriberschoice
and customize your profile to receive various new alerts as they become
available, on a weekly or monthly basis.
ProLiant Support Packs
and ROMPaq, software
The latest software, drivers, and firmware fully optimized and tested for your
ProLiant server and options, available through ProLiant Support Packs the
ProLiant Essentials Rapid Deployment Pack, SmartStart or downloaded from
Software and Drivers download pages website at
http://www.hp.com/go/support .
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Overview
DA - 12517 North America — Version 13 — July 27, 2007 Page 9

Optional ProLiant
Optional ProLiantOptional ProLiant
Optional ProLiant
Essentials Value Packs
Essentials Value PacksEssentials Value Packs
Essentials Value Packs
Optional software offerings that selectively extend the functionality of an Adaptive Infrastructure to
address specific business problems and needs:
Integrated Lights-Out Select Pack - upgrades the Integrated Lights-Out processor with scripted and
command line virtual media, Power Regulator reporting and enterprise security
Virtualization Management Software - Get the most out of server virtualization by unifying the
management of physical and virtual servers in HP Systems Insight Manager. The Virtual Machine
Management Pack plug-in provides central management and control of VMware and Microsoft
virtual machines and provides physical host to virtual machine association. The Server Migration
Pack plug-in automates the manual task of migrating servers between physical or virtual
platforms.
NOTE:
NOTE:NOTE:
NOTE: Flexible and volume quantity license kits are available for ProLiant Essentials Value Packs. Refer
to http://www.hp.com/servers/proliantessentials or the various ProLiant Essentials Value Pack product
QuickSpecs for more information.
HP Enterprise
HP EnterpriseHP Enterprise
HP Enterprise
Configurator
ConfiguratorConfigurator
Configurator
The HP eCo-Enterprise Configurator now provides factory default racking for our HP hardware portfolio.
This approach is aligned with our strategic direction to meet the needs and expectations of our valued
customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or
an Authorized Partner for assistance.
HP BladeSystem Power
HP BladeSystem PowerHP BladeSystem Power
HP BladeSystem Power
Sizer
SizerSizer
Sizer
The HP BladeSystem Power Sizer helps in sizing the power infrastructure needed for a HP BladeSystem
solution. This sizer enables effective planning for the power consumption and heat load of the
BladeSystem at its site.
The sizer enables you to:
Select the type and number of components within each Blade Server and Blade Enclosure.
View the effect of component changes on the power consumption and heat loading.
Review server loading and determine power supply and power subsystem requirements.
Approximate electrical and heat load for facilities planning purposes.
The sizing estimate is based on component level power measurements for a system stressed to maximum
capability.
Values obtained from the BladeSystem Sizer tool are measured with all components stressed to 100%
load and are intended for facilities planning purposes only. Actual power consumption varies with
application type, application utilization, and ambient temperature.
The p-class BladeSystem and the c-Class BladeSystem solutions are supported in the BladeSystem Power
Sizer.
Available at http://www.hp.com/go/bladesystem/powercalculator
Service and Support
Service and SupportService and Support
Service and Support This product is covered by a global limited warranty and supported by HP Services and a worldwide
network of resellers and service providers. Hardware diagnostic support and repair is available for three
years from date of purchase. Support for software and initial setup is available for 90 days from date of
purchase. Additional support may be covered under the warranty or available for an additional fee.
Enhancements to warranty services are available through HP Care Pack services or customized service
agreements.
NOTE:
NOTE:NOTE:
NOTE: Server Blade Limited Warranty includes 3 year Parts, 3 year Labor, 3-year on-site support. This
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Overview
DA - 12517 North America — Version 13 — July 27, 2007 Page 10

warranty supports the HP ProLiant BL460c, BL465c, BL480c and BL685c Server Blades.
NOTE:
NOTE:NOTE:
NOTE: Server Blade Enclosure Limited Warranty includes 3 year Parts, 3 year Labor, 3-year on-site
support.
NOTE:
NOTE:NOTE:
NOTE: Server Blade Interconnect Limited Warranty includes 1 year Parts, 1 year Labor, 1-year on-site
support
NOTE:
NOTE:NOTE:
NOTE: Server Warranty includes 3 year Parts, 3 year Labor, 3-year on-site support. Additional
information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
The HP Care Pack service part numbers below for ProLiant BL c-Class (or p-Class) server blades, cover
the server blade and all HP branded hardware options qualified for the server, purchased at the same
time or afterwards, internal to the server.
HP Care Pack services for the c7000 Enclosure cover the enclosure, power supplies and fans. HP
qualified rack options are covered by these services when installed within the same rack. HP supported
c-Class enclosure devices including pass thru, Ethernet interconnect and virtual connect modules are
also covered by the c7000 enclosure Care Pack services.
HP services provide continuous care and support expertise with committed response designed to meet
your IT and business needs.
To fully capitalizing on your HP BladeSystem servers' capabilities requires a service partner who
thoroughly understands your server technology and systems environment. HP Services, an industry leader
in provision of multi vender support solutions provides a range of support services designed to meet the
varying needs of business. Whether an SMB or large global corporation HP has a HP BadeSystem server
support offer to help you speedily deploy and maximize system uptime.
Enhanced Care - Minimum recommended service support offer designed to ensure customers have
access to expert assistance, whenever they need it.
4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years.
Continuance Care - Recommended service delivering cost-effective support options designed to extend
HP Services committed response and guaranteed fix times, designed to speed problem identification and
resolution.
4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years.
Total Care - Highest HP Support service level recommend to help increase IT performance and
availability with comprehensive, integrated hardware and software services
Support Plus 24 - Onsite HW support 24x7, 4hr response and Microsoft O/S SW Tech support
offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays.
Deployment Services - HP Installation and Start Up services designed to take time, risk, and worry out of
the deployment of HP BladeSystem servers - and free customers IT support staff to focus on what they do
best, their business.
Installation & Start-Up service for HP BladeSystem Infrastructure plus HP BladeSystem Enhanced
Network Installation and Start-UP as per the Customer Description and/or Data Sheet. To be
delivered on a scheduled basis 8am-5pm, M-F, excl. HP holidays
For a complete listing of service offerings and information visit:
http://www.hp.com/services/bladesystemservices
http://www.hp.com/go/proliant/carepack
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Overview
DA - 12517 North America — Version 13 — July 27, 2007 Page 11

For a complete configuration of the HP BladeSystem, please do the following:
Step 1: Select desired model, configuration and quantity of HP ProLiant server and Storage blades
Step 1: Select desired model, configuration and quantity of HP ProLiant server and Storage bladesStep 1: Select desired model, configuration and quantity of HP ProLiant server and Storage blades
Step 1: Select desired model, configuration and quantity of HP ProLiant server and Storage blades
NOTE:
NOTE:NOTE:
NOTE: For server blade information, please visit: http://h18000.www1.hp.com/products/quickspecs/North_America/12534.html
NOTE:
NOTE:NOTE:
NOTE: For Storage Blade information, please visit:
http://h18000.www1.hp.com/products/quickspecs/12587_na/12587_na.HTML
Step 2: Determine quantity of HP BladeSystem c-Class Enclosures to purchase and choose Required Options
Step 2: Determine quantity of HP BladeSystem c-Class Enclosures to purchase and choose Required OptionsStep 2: Determine quantity of HP BladeSystem c-Class Enclosures to purchase and choose Required Options
Step 2: Determine quantity of HP BladeSystem c-Class Enclosures to purchase and choose Required Options (One of the
following from each list unless otherwise noted):
NOTE:
NOTE:NOTE:
NOTE: Each HP BladeSystem c-Class Server Blade Enclosure holds up to 16 half-height blades. Server blanks will be shipped in all
empty bays.
Base Server Blade Enclosure Configuration
Base Server Blade Enclosure ConfigurationBase Server Blade Enclosure Configuration
Base Server Blade Enclosure Configuration
HP BladeSystem BLc7000
HP BladeSystem BLc7000HP BladeSystem BLc7000
HP BladeSystem BLc7000
c-Class Server Blade
c-Class Server Bladec-Class Server Blade
c-Class Server Blade
Enclosures
EnclosuresEnclosures
Enclosures
HP BLc7000 CTO Enclosure
NOTE:
NOTE:NOTE:
NOTE: CTO model includes 1x Onboard Administrator, 4x Active Cool Fans and 0x
power supplies.
412152-B22
Required Options (one of the following from each category unless otherwise noted)
Required Options (one of the following from each category unless otherwise noted)Required Options (one of the following from each category unless otherwise noted)
Required Options (one of the following from each category unless otherwise noted)
c-Class Power Modules (1
c-Class Power Modules (1c-Class Power Modules (1
c-Class Power Modules (1
per enclosure)
per enclosure)per enclosure)
per enclosure)
HP BLc7000 Single Phase Power Module, FIO 413379-B21
HP BLc7000 Three Phase Power Module, FIO 413380-B21
c-Class Power Supply
c-Class Power Supplyc-Class Power Supply
c-Class Power Supply HP c7000 Enclosure Hot-Plug Power Supply Option Kit (supplied with IEC C20 - C19
jumper cord)
NOTE:
NOTE:NOTE:
NOTE: If Three Phase Power Module selected, a minimum of 3 Power Supply Option
Kits are needed. For full redundancy 6 Power Supply Option Kits are required
412138-B21
c-Class Active Cool Fan
c-Class Active Cool Fanc-Class Active Cool Fan
c-Class Active Cool Fan HP Active Cool Fan Option Kit
NOTE:
NOTE:NOTE:
NOTE: A minimum of 4 Active Cool fans is required, 8 Active Cool fans can support
a full blade enclosure, 10 Active Cool fans should be ordered for reduced power
consumption and noise reduction.
NOTE:
NOTE:NOTE:
NOTE: Single-Phase models may require additional power supplies. Fans should be
added to provide redundancy, reduce power consumption and reduce noise.
NOTE:
NOTE:NOTE:
NOTE: Three-Phase models require a minimum of 6 Active Cool fans.
412140-B21
Step 2A: Select other factory integratable enclosure options:
Step 2A: Select other factory integratable enclosure options:Step 2A: Select other factory integratable enclosure options:
Step 2A: Select other factory integratable enclosure options:
Enclosure Options
Enclosure OptionsEnclosure Options
Enclosure Options HP BLc7000 Insight Control Linux Edition 16 License, including 1 year of 24x7
Technical Support and Updates, FIO
441604-B22
HP BLc7000 Insight Control Environment For BladeSystem 16 License, including 1
year of 24x7 Technical Support and Updates, FIO
417688-B22
HP BLc7000 Insight Control Environment For BladeSystem 8 License, including 1 year
of 24x7 Technical Support and Updates, FIO
439034-B22
Step 3: Select an interconnect kit.
Step 3: Select an interconnect kit.Step 3: Select an interconnect kit.
Step 3: Select an interconnect kit.
A pair of interconnects must be order if redundancy is required. For additional information on Interconnect Options, please visit:
HP BladeSystem c-Class Interconnect QuickSpecs: http://h18000.www1.hp.com/products/quickspecs/12524_na/12524_na.HTML
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
Configuration Information Factory Integrated Models
DA - 12517 North America — Version 13 — July 27, 2007 Page 12

HP BladeSystem
HP BladeSystemHP BladeSystem
HP BladeSystem
c-Class Ethernet
c-Class Ethernetc-Class Ethernet
c-Class Ethernet
Interconnects
InterconnectsInterconnects
Interconnects
HP 4Gb Virtual Connect Fibre Channel Module for c-Class BladeSystem 409513-B21
HP 1Gb Virtual Connect Ethernet Module for c-Class BladeSystem 399593-B22
Ethernet Pass-Through Module for HP BladeSystem 406740-B21
Cisco Catalyst Blade Switch 3020 for HP c-Class BladeSystem 410916-B21
GbE2c Ethernet Blade Switch for HP c-Class BladeSystem 410917-B21
GbE2 Layer 2/3 Ethernet Blade Switch for HP c-Class BladeSystem 438030-B21
HP 1:10 Gb Ethernet BL-c Switch 438031-B21
HP 10Gb Ethernet BL-c Switch
NOTE:
NOTE:NOTE:
NOTE: The purchase the HP 10Gb Ethernet BL0c Switch, also requires the purchase
of one (1) HP NC512m Dual Port 10GbE Multifunction BL-c Adapter (P/N 440910-
B21) per server blade that requires 10Gbit support.
445860-B21
NOTE:
NOTE:NOTE:
NOTE: The HP BladeSystem c-Class Network Interconnects ship as single units. The
above interconnects must be ordered in quantities of two for redundancy support.
HP BladeSystem
HP BladeSystemHP BladeSystem
HP BladeSystem
c-Class FC SAN
c-Class FC SANc-Class FC SAN
c-Class FC SAN
Interconnects
InterconnectsInterconnects
Interconnects
HP 4Gb Virtual Connect Fibre Channel Module for c-Class BladeSystem 409513-B21
16 port FC Pass-thru Module for c-Class BladeSystem 403626-B21
HP Brocade 4/12 SAN Switch AE370A
HP Brocade 4/24 SAN Switch Power Pack AE371A
HP Brocade 4/24 SAN Switch AE372A
HP Brocade 4/12 SAN Switch Upgrade LTU AE373A
Cisco MDS 9124e 12-port Fabric Switch AG641A
Cisco MDS 9124e 24-port Fabric Switch AG642A
Cisco MDS 9124e 12-port Upgrade LTU T5169A
HP BladeSystem
HP BladeSystemHP BladeSystem
HP BladeSystem
InfiniBand Interconnects
InfiniBand InterconnectsInfiniBand Interconnects
InfiniBand Interconnects
HP 4X DDR IB Switch Module for HP c-Class BladeSystem 410398-B21
Step 4: Select rack power distribution for single-phase models
Step 4: Select rack power distribution for single-phase modelsStep 4: Select rack power distribution for single-phase models
Step 4: Select rack power distribution for single-phase models
NOTE:
NOTE:NOTE:
NOTE: A pair of PDUs must be ordered for AC Feed redundancy.
HP Monitored Power
HP Monitored PowerHP Monitored Power
HP Monitored Power
Distribution Unit
Distribution UnitDistribution Unit
Distribution Unit
HP 17.3 kVA S348 Monitored PDU- single input, 3-phase, 60A AF916A
HP Modular Power
HP Modular PowerHP Modular Power
HP Modular Power
Distribution
DistributionDistribution
Distribution
Units
UnitsUnits
Units
HP 8.6 kVA Modular PDU 24A 3Ø Core Only** AF512A
HP 8,3k VA Modular PDU 40 Amp Core Only** 252663-D75
HP 4.9kVA Modular PDU 24 Amp Core Only** 252663-D74
**The Modular Distribution Unit Kits excludes the extension bars as they are not
required with the HP BladeSystem
HP Two C-13 PDU Extension Bars AF500A
NOTE:
NOTE:NOTE:
NOTE: Each extension bar has a C19 input and 7 C13 receptacles. The option is
ideal for model S348, and, model S332, which both have only C19 outlets (12) and
for all Core Only Modular PDUs.
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
Configuration Information Factory Integrated Models
DA - 12517 North America — Version 13 — July 27, 2007 Page 13

HP BladeSystem
HP BladeSystemHP BladeSystem
HP BladeSystem
c-Class Server Blade
c-Class Server Bladec-Class Server Blade
c-Class Server Blade
Enclosures
EnclosuresEnclosures
Enclosures
HP BLc7000 Single Phase Enclosure with 2 Power Supplies and 4 Fans with 16 Insight
Control Linux Edition Licenses
441908-B22
HP BladeSystem c7000 Enclosure, Single-Phase with 2 Power Supplies, 4 Fans with
16 Insight Control Environment Licenses
403321-B22
HP BladeSystem c7000 Enclosure, Three-Phase with 6 Power Supplies, 6 Fans with 16
Insight Control Environment Licenses
412136-B22
HP BladeSystem c7000 Enclosure, Single-Phase with 2 Power Supplies, 4 Fans with 8
Insight Control Environment 30 Day Trial Licenses
403320-B22
HP BladeSystem c7000 Enclosure, Three-Phase with 6 Power Supplies,6 Fans with 8
Insight Control Environment 30 day Trial Licenses
412133-B22
NOTE:
NOTE:NOTE:
NOTE: All c7000 BTO enclosures will ship with 12 server blanks. Additional server
blanks may be purchased if required. CTO enclosures will ship with the required
number of server blanks.
c7000 Enclosure Options
c7000 Enclosure Optionsc7000 Enclosure Options
c7000 Enclosure Options
HP Redundant Onboard Administrator Option 412142-B21
HP c7000 Enclosure 10K Rack Ship Bracket Option Kit
NOTE:
NOTE:NOTE:
NOTE: The shipping bracket is required when shipping a c7000 enclosure when
installed in a rack. It is not required for normal operation.
433718-B21
HP c7000 Replacement Enclosure Miscellaneous Blanks kit (contains 1 each of Power
Supply Blank, Interconnect Module Blank, Onboard Administrator Blank, Active Cool
Fan Blank)
NOTE:
NOTE:NOTE:
NOTE: This kit should only be ordered to replace lost or damaged blanks.
412148-B21
HP c-Class Server Blank and Coupler Option Kit (contains 1 x half-height server blank
with coupler)
NOTE:
NOTE:NOTE:
NOTE: The coupler allows half-height server blanks to be coupled together to create
a full-height server blank.
NOTE:
NOTE:NOTE:
NOTE: This kit should only be ordered to replace lost or damaged blanks.
412150-B21
c-Class Power Supply
c-Class Power Supplyc-Class Power Supply
c-Class Power Supply HP c7000 Enclosure Hot-Plug Power Supply Option Kit (supplied with IEC C20 - C19
jumper cord)
412138-B21
c-Class Active Cool Fan
c-Class Active Cool Fanc-Class Active Cool Fan
c-Class Active Cool Fan HP Active Cool Fan Option Kit
NOTE:
NOTE:NOTE:
NOTE: A minimum 4 Active Cool fans is required, 8 Active Cool fans can support a
full blade enclosure, 10 Active Cool fans should be ordered for reduced power
consumption and noise reduction.
412140-B21
HP BladeSystem
HP BladeSystemHP BladeSystem
HP BladeSystem
c-Class Ethernet
c-Class Ethernetc-Class Ethernet
c-Class Ethernet
Interconnects
InterconnectsInterconnects
Interconnects
HP 1Gb Virtual Connect Ethernet Module for c-Class BladeSystem 399593-B22
Ethernet Pass-Through Module for HP BladeSystem 406740-B21
Cisco Catalyst Blade Switch 3020 for HP c-Class BladeSystem 410916-B21
HP GbE2c Ethernet Blade Switch for HP c-Class BladeSystem 410917-B21
HP GbE2c Layer 2/3 Ethernet Blade Switch 438030-B21
HP 10Gb SR XFP Module 443756-B21
HP 10Gb LR XFP Module 443757-B21
HP 1:10 Gb Ethernet BL-c Switch 438031-B21
HP 10Gb Ethernet BL-c Switch
NOTE:
NOTE:NOTE:
NOTE: The purchase the HP 10Gb Ethernet BL0c Switch, also requires the purchase
of one (1) HP NC512m Dual Port 10GbE Multifunction BL-c Adapter (P/N 440910-
B21) per blade that requires 10Gbit support
445860-B21
NOTE:
NOTE:NOTE:
NOTE: The HP BladeSystem c-Class Network Interconnects ship as single units. The
above interconnects must be ordered in quantities of two for redundancy support.
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
Related Options
DA - 12517 North America — Version 13 — July 27, 2007 Page 14

HP BladeSystem
HP BladeSystemHP BladeSystem
HP BladeSystem
c-Class FC SAN
c-Class FC SANc-Class FC SAN
c-Class FC SAN
Interconnects
InterconnectsInterconnects
Interconnects
HP 4Gb Virtual Connect Fibre Channel Module for c-Class BladeSystem 409513-B21
16 port FC Pass-thru Module for c-Class BladeSystem 403626-B21
HP Brocade 4/12 SAN Switch AE370A
HP Brocade 4/24 SAN Switch Power Pack AE371A
HP Brocade 4/24 SAN Switch AE372A
HP Brocade 4/12 SAN Switch Upgrade LTU AE373A
Cisco MDS 9124e 12-port Fabric Switch AG641A
Cisco MDS 9124e 24-port Fabric Switch AG642A
Cisco MDS 9124e 12-port Upgrade LTU T5169A
HP BladeSystem
HP BladeSystemHP BladeSystem
HP BladeSystem
InfiniBand Interconnects
InfiniBand InterconnectsInfiniBand Interconnects
InfiniBand Interconnects
HP 4X DDR IB Switch Module for HP c-Class BladeSystem 410398-B21
Insight Control
Insight ControlInsight Control
Insight Control
Environment for
Environment forEnvironment for
Environment for
BladeSystem
BladeSystemBladeSystem
BladeSystem
HP Insight Control Environment for BladeSystem, No Media, 8 Licenses including 1
year of 24x7 Technical Support and Updates
NOTE:
NOTE:NOTE:
NOTE: For use with up to 8 HP BladeSystem server blades. Contains an 8-server
Insight Control license with one unique activation key, an 8-server RDP license and
documentation.
436747-B22
HP Insight Control Environment for BladeSystem, No Media, Flexible Quantity License
including 1 year of 24x7 Technical Support and Updates
NOTE:
NOTE:NOTE:
NOTE: For use with multiple HP BladeSystem server blades. This part number can be
used to purchase multiple licenses (minimum quantity of 5). The quantity ordered of
this part number will be the quantity of licenses provided in the form of a
corresponding Insight Control activation key, RDP license and documentation.
436749-B22
HP Insight Control Environment for BladeSystem RDP Upgrade, No Media 8 Licenses
including 1 year of 24x7 Technical Support and Updates
NOTE:
NOTE:NOTE:
NOTE: For use with up to 8 HP BladeSystem servers in environments where the
ProLiant Essentials Rapid Deployment Pack is already installed and sufficiently
licensed. Contains an 8-server Insight Control license with one unique activation key
and documentation.
NOTE:
NOTE:NOTE:
NOTE: This option does not include an RDP license.
436751-B22
HP Insight Control Environment for BladeSystem RDP Upgrade, No Media, Flexible
Quantity License including 1 year of 24x7 Technical Support and Updates
NOTE:
NOTE:NOTE:
NOTE: For use with multiple HP BladeSystem server blades in environments where the
ProLiant Essentials Rapid Deployment Pack is already installed and sufficiently
licensed. This part number can be used to purchase multiple licenses (minimum
quantity of 5). The quantity ordered of this part number will be the quantity of licenses
included in the kit in the form of a corresponding Insight Control activation key and
documentation.
NOTE:
NOTE:NOTE:
NOTE: This option does not include an RDP license.
436753-B22
HP Insight Control Environment for BladeSystem, Tracking License including 1 year of
24x7 Technical Support and Updates
NOTE:
NOTE:NOTE:
NOTE: For use with signed and implemented Activation Key Agreements (AKA) only.
Purchase of this part number entitles the customer to deploy additional licenses of the
product under the terms of the existing Activation Key Agreement. No physical
components are delivered in conjunction with the purchase of this part number. For
more information on Activation Key Agreements please visit the follow URL
http://h18004.www1.hp.com/products/servers/proliantessentials/license/akalic.html
437786-B22
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
Related Options
DA - 12517 North America — Version 13 — July 27, 2007 Page 15

HP c-Class Storage
HP c-Class StorageHP c-Class Storage
HP c-Class Storage
Blades
BladesBlades
Blades
HP StorageWorks SB40c storage blade 411243-B21
HP PCI Express Mezzanine pass-thru card for HP BladeSystem 431643-B21
NOTE:
NOTE:NOTE:
NOTE: The mezzanine card is needed to support the SB40c storage blade (P/N
411243-B21) with HP c-Class BladeSystem full-height server blades.
HP PCI Expansion Blade
HP PCI Expansion BladeHP PCI Expansion Blade
HP PCI Expansion Blade PCI Expansion Blade 448018-B21
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding the HP PCI Expansion Blade, please visit:
http://h18000.www1.hp.com/products/quickspecs/12753_div/12753_div.HTML
HP c-Class Tape Blades
HP c-Class Tape BladesHP c-Class Tape Blades
HP c-Class Tape Blades HP Ultrium 448c Tape Blade 440947-B21
NOTE:
NOTE:NOTE:
NOTE: The HP PCI Express Mezzanine Pass-Thru Card for HP BladeSystem (431643-
B21) is required when installing a tape blade adjacent to a full-height server blade.
HP Rack 5000 Series
HP Rack 5000 SeriesHP Rack 5000 Series
HP Rack 5000 Series
(Metallic Carbonite)
HP 5642 Rack - Unassembled
NOTE:
NOTE:NOTE:
NOTE: Please see the HP Rack 5642 QuickSpecs for additional part numbers and
Technical Specifications such as height, width, depth, weight, and color:
http://h18000.www1.hp.com/products/quickspecs/12074_na/12074_na.HTML
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding Rack Cabinets, please see the following
URL: http://www.hp.com/go/rackandpower
358254-B21
HP Rack 10000 G2
HP Rack 10000 G2HP Rack 10000 G2
HP Rack 10000 G2
Series
SeriesSeries
Series (Graphite Metallic)
10622 G2 (22U) Rack Cabinet Shock AF022A
10622 G2 (22U) Rack Cabinet Pallet AF021A
10642 G2 (42U) Rack Cabinet - Pallet AF001A
10642 G2 (42U) Rack Cabinet - Shock Pallet AF002A
10642 G2 (42U) Rack Cabinet - Crated AF003A
10642 G2 (42U) Rack Cabinet, with Extension - Shock Pallet AF004A
10642 G2 (42U) Rack Shock Pallet- for field racking AF007A
10636 G2 (36U) Rack Cabinet - Shock Pallet AF011A
10636 G2 (36U) Rack Cabinet - Crated AF012A
10636 G2 (36U) Rack Cabinet, with Extension - Shock Pallet AF013A
10636 G2 (36U) Rack Cabinet, without door - Shock Pallet AF014A
10647 G2 (47U) Rack Cabinet - Pallet AF031A
10842 G2 (42U) Rack Cabinet Shock AF042A
10842 G2 (42U) Rack Cabinet Pallet AF041A
NOTE:
NOTE:NOTE:
NOTE: Please see the Rack 10000 G2 QuickSpecs for additional part numbers and
Technical Specifications such as height, width, depth, weight, and color:
http://h18000.www1.hp.com/products/quickspecs/12402_na/12402_na.HTML
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding Rack Cabinets, please see the following
URL: http://www.hp.com/go/rackandpower .
Tape Libraries
Tape LibrariesTape Libraries
Tape Libraries The following options are supported in an Enterprise Backup Solution (EBS)
environment with the HP BladeSystem c-Class enclosure. Please visit
http://www.hp.com/go/ebs for complete compatibility details.
HP StorageWorks MSL2024 Tape Library
HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library
HP StorageWorks MSL2024 Tape Library
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
Related Options
DA - 12517 North America — Version 13 — July 27, 2007 Page 16

HP StorageWorks MSL2024 1 Ultrium 960 Drive Library AG115A
HP StorageWorks MSL2024 1 Ultrium 960 4GB FC Drive Library AG326B
HP StorageWorks MSL2024 1 Ultrium 920 SAS Drive Library AH559A
HP StorageWorks MSL2024 1 Ultrium 920 Drive Library AH169A
HP StorageWorks MSL2024 2 Ultrium 920 Drive Library AH170A
HP StorageWorks MSL2024 1 Ultrium 448 Drive Library AG116A
HP StorageWorks MSL2024 2 Ultrium 448 Drive Library AG117A
HP StorageWorks MSL4048 Tape Library
HP StorageWorks MSL4048 Tape LibraryHP StorageWorks MSL4048 Tape Library
HP StorageWorks MSL4048 Tape Library
HP StorageWorks MSL4048 1 Ultrium 448 Drive Library AG320A
HP StorageWorks MSL4048 2 Ultrium 448 Drive Library AG321A
HP StorageWorks MSL4048 1 Ultrium 920 SAS Drive Library AH560A
HP StorageWorks MSL4048 1 Ultrium 920 Drive Library AH171A
HP StorageWorks MSL4048 2 Ultrium 920 Drive Library AH172A
HP StorageWorks MSL4048 1 Ultrium 960 Drive Library AG322A
HP StorageWorks MSL4048 1 Ultrium 960 4GB FC Drive Library AG324B
HP StorageWorks MSL4048 2 Ultrium 960 Drive Library AG323A
HP StorageWorks MSL4048 2 Ultrium 960 4GB FC Drive Library AG325B
HP StorageWorks MSL8096 Tape Library
HP StorageWorks MSL8096 Tape LibraryHP StorageWorks MSL8096 Tape Library
HP StorageWorks MSL8096 Tape Library
HP StorageWorks MSL8096 2 Ultrium 920 SAS Drive Library AH561A
HP StorageWorks MSL8096 2 Ultrium 960 4GB FC Library AH218A
HP StorageWorks MSL8096 2 Ultrium 960 Drive Library AH219A
HP StorageWorks MSL6000 Tape Library
HP StorageWorks MSL6000 Tape LibraryHP StorageWorks MSL6000 Tape Library
HP StorageWorks MSL6000 Tape Library
Ultrium 960 technology
Ultrium 960 technologyUltrium 960 technology
Ultrium 960 technology
HP StorageWorks MSL6030 1 Ultrium 960 Dr LVDS Library AD606B
HP StorageWorks MSL6030 1 Ultrium 960 Dr FC Library AD608B
HP StorageWorks MSL6030 2 Ultrium 960 Dr LVDS Library AD607B
HP StorageWorks MSL6030 2 Ultrium 960 Dr FC Library AD609B
NOTE:
NOTE:NOTE:
NOTE: Please reference the MSL2024, MSL4048 and MSL6000 Tape Library
QuickSpecs at http://www.hp.com/go/automation for additional information needed
to create a complete solution; reference current compatibility information at
http://www.hp.com/go/ebs
HP StorageWorks Virtual Library Systems
HP StorageWorks Virtual Library SystemsHP StorageWorks Virtual Library Systems
HP StorageWorks Virtual Library Systems
HP StorageWorks 300 Virtual Library System Gateway Base Unit AH138A
HP StorageWorks 1002i 2TB Virtual Library System AG124A
HP StorageWorks 6105 Virtual Library System AF728A
HP StorageWorks 6510 Virtual Library System AF729A
HP StorageWorks 6840 Virtual Library System AG051A
HP StorageWorks 6109 Virtual Library System AG167A
HP StorageWorks 6518 Virtual Library System AG168A
HP StorageWorks 6870 Virtual Library System AG169A
NOTE:
NOTE:NOTE:
NOTE: Please reference the Virtual Library Systems QuickSpecs at
http://www.hp.com/go/automation for additional information needed to create a
complete solution. Reference current compatibility information at
http://www.hp.com/go/ebs
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
Related Options
DA - 12517 North America — Version 13 — July 27, 2007 Page 17

Rack Options for Rack
Rack Options for RackRack Options for Rack
Rack Options for Rack
10000 G2 Series
10000 G2 Series10000 G2 Series
10000 G2 Series
HP 10642 G2 Front Door ALL AF009A
HP 10636 G2 Front Door ALL AF019A
10642 G2 (42U) Side Panels (set of two) (Graphite Metallic) AF054A
10636 G2 (36U) Side Panels (set of two) (Graphite Metallic) AF056A
10642 Rear Extension Kit AF058A
10636 G2 Rear Extension Kit AF060A
600mm G2 Stabilizer Option Kit (Graphite) AF062A
600mm G2, Heavy Duty Stabilizer Option Kit (Graphite) AF064A
800mm G2, Heavy Duty Stabilizer Option Kit (Graphite)
NOTE:
NOTE:NOTE:
NOTE: Supports 10000 G2 Series only.
AF068A
HP 10000 G2 Rack Grounding Kit AF074A
600W 10K G2 Rack Tie Down AF076A
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding Rack Options, please see the following
URL: http://www.hp.com/go/rackandpower .
HP Modular Cooling
HP Modular CoolingHP Modular Cooling
HP Modular Cooling
System
SystemSystem
System
HP Modular Cooling System AF098A
HP Rack 10000 Series
HP Rack 10000 SeriesHP Rack 10000 Series
HP Rack 10000 Series
(Graphite Metallic)
HP S10614 (14U) Rack Cabinet - Shock Pallet 292302-B22
HP Rack 10647 (47U) Cabinet - Crated 245160-B23
HP Rack 10622 (22U) Cabinet - Crated 245163-B23
Monitors and Keyboards
Monitors and KeyboardsMonitors and Keyboards
Monitors and Keyboards TFT7210R Rack Mounted 17" Monitor 348373-B21
TFT7600 Rackmount Keyboard Monitor AG052A
1U Rackmount Keyboard with USB AG072A
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding Rack Options, please see the following
URL: http://www.hp.com/go/rackandpower
HP KVM Switch Options
HP KVM Switch OptionsHP KVM Switch Options
HP KVM Switch Options 2x1x16 IP Console Switch with Virtual Media AF601A
4x1x16 IP Console Switch with Virtual Media AF602A
2x16 Server Console Switch with Virtual Media AF600A
PS/2 Virtual Media Interface Adapter, 1 pack
NOTE:
NOTE:NOTE:
NOTE: Requires PS/2 and one USB port on server.
AF604A
BladeSystem c-Class KVM Interface Adapter - 1 pack AF605A
HP 1x8 Server Console Switch 336044-B21
HP 2x16 Server Console Switch 336045-B21
PS/2 Interface Adapter, 1-pack 262588-B21
PS/2 Interface Adapter, 8-pack 262587-B21
USB Interface Adapter, 1-pack 336047-B21
Serial Interface Adapter, 1-pack with power supply 373045-B21
NOTE:
NOTE:NOTE:
NOTE: Cat5e cables are required to connect Interface Adapters to Consoles
Switches. Cat52 cables can be found at the following URL:
http://www.hp.com/go/kvm
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
Related Options
DA - 12517 North America — Version 13 — July 27, 2007 Page 18

HP 1x4 Console Switch AF611A
HP PS2 Server Console Cable, 6 foot, 2-Pack AF612A
HP USB Server Console Cable, 6 foot, 2-Pack
NOTE:
NOTE:NOTE:
NOTE: required for supporting USB peripherals.
AF613A
HP USB KVM Cable with audio, 6'-2-pack 371729-B21
NOTE
NOTENOTE
NOTE For additional information regarding KVM switches, Serial Console servers,
rack mount monitors, keyboards and all related options please see the following URL:
http://www.hp.com/go/kvm
HP Serial Console Server
HP Serial Console ServerHP Serial Console Server
HP Serial Console Server
Options
OptionsOptions
Options
HP 16 Port Serial Console Server AF101A
HP 48 Port Serial Console Server AF102A
Serial Adapter, RJ45-DB9 DCE Female, 1 Pack AF103A
Serial Adapter, RJ45-DB9 DCE Female, 8 Pack AF110A
NOTE:
NOTE:NOTE:
NOTE: Cat5e cables are required to connect Serial Adapters to Serial Console
Servers. Additional Serial Adapters and Cat5e cables can be found at the following
URL: http://www.hp.com/go/kvm .
NOTE:
NOTE:NOTE:
NOTE: For additional information regarding KVM switches, Serial Console servers,
rack mount monitors, keyboards and all related options please see the following URL:
http://www.hp.com/go/kvm .
Service and Support
Service and SupportService and Support
Service and Support
Offerings
OfferingsOfferings
Offerings (HP Care Pack
Services)
NOTE:
NOTE:NOTE:
NOTE: The HP Care Pack service part numbers below for ProLiant BL c-Class server
blades, cover the server blade and all HP branded hardware options qualified for the
server, purchased at the same time or afterwards, internal to the server.
Hardware Services On-site Service
Hardware Services On-site ServiceHardware Services On-site Service
Hardware Services On-site Service
4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic UE458E
4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic UE459E
6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years,
Electronic
UE460E
Support Plus 24
Support Plus 24Support Plus 24
Support Plus 24
Onsite HW support 24x7, 4hr response and Microsoft O/S SW Tech support offsite,
onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic
UE473E
NOTE:
NOTE:NOTE:
NOTE: HP Care Pack services for the c7000 Enclosure cover the enclosure, power
supplies and fans. HP qualified rack options are covered by these services when
installed within the same rack. HP supported c-Class enclosure devices including pass
thru, Ethernet interconnect and virtual connect modules are also covered by the
c7000 enclosure Care Pack services.
NOTE:
NOTE:NOTE:
NOTE: SAN/Fabric switches for the HP c-Class BladeSystem are not covered under
the c7000 enclosure Care Packs, SAN/Fabric switches carry separate Care Packs.
SAN/Fabric Switch Care Pack service level support should always be uplifted to match
existing storage or server service level.
Hardware Services On-site Service
Hardware Services On-site ServiceHardware Services On-site Service
Hardware Services On-site Service
Next Business Day On-site Service, 5-Day x 9-Hour Coverage, 3 Years, Electronic
NOTE:
NOTE:NOTE:
NOTE: Uplifts the Ethernet devices to the same level of warranty as the c-class
enclosure
UE477E
4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic UE478E
4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic UE479E
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
Related Options
DA - 12517 North America — Version 13 — July 27, 2007 Page 19

6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years,
Electronic
UE480E
Installation & Start-up Services
Installation & Start-up ServicesInstallation & Start-up Services
Installation & Start-up Services
HP BladeSystem c-Class Infrastructure Installation and Startup Service, Electronic UE602E
HP BladeSystem Enhanced Network Installation and Startup Service, Electronic UE603E
ProLiant BL c-Class Blade Server Hardware Installation, Electronic UE493E
ProLiant BL c-Class Enclosure and Server Blade Hardware Installation, Electronic UE494E
NOTE:
NOTE:NOTE:
NOTE: For more information, customer/resellers can contact
http://www.hp.com/services/bladesystemservices
NOTE:
NOTE:NOTE:
NOTE: The HP Care Pack service part numbers below covers the HP Brocade 4Gb,
12 Port SAN Switch and Brocade 4/24 SAN Switch.
Hardware Services On-site Service
Hardware Services On-site ServiceHardware Services On-site Service
Hardware Services On-site Service
Next Business Day On-site Service, 5-Day x 9-Hour Coverage,
3 Years, Electronic
UE436E
4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic UE437E
4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic UE438E
6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years,
Electronic
UE439E
Hardware Installation, Electronic U5988E
NOTE:
NOTE:NOTE:
NOTE: The HP Care Pack service part numbers below covers the Brocade 4/24 SAN
Switch Power Pack.
Hardware Services On-site Service
Hardware Services On-site ServiceHardware Services On-site Service
Hardware Services On-site Service
Support Plus
Support PlusSupport Plus
Support Plus
Onsite HW support, 8am-9pm, M-F, 4hr response and SW Tech support offsite,
onsite at HP's discretion, 8am-9pm, M-F 2hr response time excl. HP holidays, 3 Years,
Electronic
UE728E
Support Plus 24
Support Plus 24Support Plus 24
Support Plus 24
Onsite HW support 24x7, 4hr response and SW Tech support offsite, onsite at HP's
discretion, 24x7 2hr response time incl. HP holidays, 3 Years, Electronic
UE729E
Software Installation and StartUp Services
Software Installation and StartUp ServicesSoftware Installation and StartUp Services
Software Installation and StartUp Services
Provides for the Installation and Start-up of ProLiant Essentials Rapid Deployment
Pack, Electronic
NOTE:
NOTE:NOTE:
NOTE: Provides installation on a Customer supplied server designated as a
Deployment Server. Includes the deployment of a single server. This new server will be
deployed using either one of the pre-configured scripts or an image. In addition, the
service will provide for the capture and storage of the configuration of the newly
deployed server and orientation on product usage. To be delivered during standard
office ours, standard office days.
U5683E
Provides for the Installation and Start-up of Rapid Deployment Pack Implementation of
Rapid Deployment Pack (Basic) (Electronic)
UA042E
HP ProLiant Essentials Vulnerability and Patch Management Pack Installation and
Startup Service, Electronic
NOTE:
NOTE:NOTE:
NOTE: Service coverage: onsite installation of the Vulnerability and Patch
Management (VPM) software on a customer designated server, configuration of the
VPM software to acquire security patches, enabling the VPM software to scan up to
five (5) systems, applying the security patches to the designated servers, generating a
report from VPM that shows the vulnerability assessment results, and providing
customer with an orientation to the software.
UC929E
QuickSpecs
HP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class InfrastructureHP BladeSystem c-Class Infrastructure
HP BladeSystem c-Class Infrastructure
Related Options
DA - 12517 North America — Version 13 — July 27, 2007 Page 20
