HP StorageWorks 70 Modular Smart Array
Enclosure
user guide
Part number: 434893–002
First edition: February 2007

Legal and notice information
© Copyright 2007 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth
in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting
an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation.

Contents
Aboutthisguide .......................... 7
Intendedaudience...................................... 7
Documentconventionsandsymbols .............................. 7
HPtechnicalsupport..................................... 8
Customerselfrepair ..................................... 8
Productwarranties...................................... 8
Subscriptionservice ..................................... 8
HPwebsites......................................... 8
Documentationfeedback ................................... 9
1Identifyingthecomponents..................... 11
Frontpanelcomponents ................................... 11
FrontpanelLEDs....................................... 11
Rearpanelcomponents................................... 12
RearpanelLEDsandbuttons ................................ 13
Harddrivebaynumbers .................................. 14
HarddriveLEDs...................................... 14
HarddriveLEDcombinations ................................ 14
7-segmentdisplayboard .................................. 15
2Poweringupandpoweringdowntheenclosure ............ 17
Poweringup ....................................... 17
Poweringdown ...................................... 17
3Settinguptheenclosure ..................... 19
Environmentalrequirements................................. 19
Space and airflowrequirements............................. 19
Rackplanningresources ................................ 20
Temperaturerequirements................................ 20
Powerrequirements .................................. 20
Electricalgroundingrequirements ............................ 21
Rackwarnings ...................................... 21
Shippingcontents ..................................... 21
Rackmountinghardwarekitcontents............................. 22
Convertingrailsforround-holeracks ............................. 22
Installingtheenclosureintotherack ............................. 23
Installinghardwareoptions ................................. 24
Installingservers...................................... 24
Choosing a configuration.................................. 24
Single-enclosure configuration.............................. 25
Cascading (1+1) configuration.............................. 25
Cablingtheenclosure ................................... 26
SAScablingguidelines................................. 26
Supportedcables ................................... 26
Powercords...................................... 26
Updating firmware..................................... 27
4 Installing hard drives ....................... 29
user guide 3

Harddriveoptions..................................... 29
Harddriveguidelines ................................. 29
Installingaharddrive ................................. 29
5Configuringtheenclosure ..................... 31
Configurationtools..................................... 31
Array ConfigurationUtility ............................... 31
Option ROM ConfigurationforArrays .......................... 31
SmartComponentsforROMFlash ............................ 31
Managementtools..................................... 32
HPSystemsInsightManager .............................. 32
ManagementAgents.................................. 32
Diagnostictools...................................... 32
IntegratedManagementLog............................... 32
ArrayDiagnosticUtility................................. 33
Remotesupportandanalysistools .............................. 33
OpenServicesEventManager.............................. 33
Keepingthesystemcurrent ................................. 33
Change control and proactive notification......................... 33
Naturallanguagesearchassistant ............................ 33
CarePack ...................................... 33
6 Troubleshooting . . ....................... 35
Whentheenclosuredoesnotstart .............................. 35
Diagnosticsteps...................................... 35
Arethepowersupply/fanmoduleLEDsgreen? ...................... 35
IsthesystempowerLEDgreen? ............................. 36
Recognizingharddrivefailure................................ 36
Effectsofaharddrivefailure .............................. 36
Compromisedfaulttolerance .............................. 37
Recoveringfromcompromisedfaulttolerance ....................... 37
Factorstoconsiderbeforereplacingharddrives ........................ 37
Automaticdatarecovery(rebuild) .............................. 38
Timerequiredforarebuild ............................... 38
Failureofanotherdriveduringrebuild .......................... 38
DrivefailureinaNetWareenvironment............................ 39
Faileddrivesorinterimrecoverymode .......................... 39
Handlingharddrivefailures............................... 39
ARegulatorycompliancenotices ................... 41
Regulatory compliance identificationnumbers ......................... 41
FederalCommunicationsCommissionnotice.......................... 41
FCCratinglabel.................................... 41
ClassAequipment................................... 41
ClassBequipment................................... 41
Declaration of conformity for products marked with the FCC logo, United States only . . . . . . . . . 42
Modifications....................................... 42
Cables.......................................... 42
Canadiannotice(AvisCanadien) .............................. 42
EuropeanUnionregulatorynotice .............................. 42
DisposalofwasteequipmentbyusersinprivatehouseholdsintheEuropeanUnion ......... 44
Japanesenotice...................................... 44
BSMInotice........................................ 44
Koreannotice....................................... 44
PowercordstatementforJapan ............................... 45
B Electrostatic discharge ...................... 47
4

Preventingelectrostaticdischarge............................... 47
Groundingmethodstopreventelectrostaticdischarge...................... 47
CSpecifications ......................... 49
Environmental specifications................................. 49
Storage enclosure specifications............................... 49
AcronymsandAbbreviations ..................... 51
Index .............................. 53
user guide 5

Tables
1..Documentconventions............................... 7
2..LEDFailure/FaultAlerts ............................. 15
6

About this guide
This guide provides information about the HP StorageWorks 70 Modular Smart Array Enclosure.
Intended audience
This guide is intended for use by system administrators and technicians who are experienced with the
following:
•SAN management
•Network administration
•Network installation
Document conventions and symbols
Table 1 Document conventions
Convention Element
Blue text: Table 1 Cross-reference links and e-mail addresses
Blue, underlined text: http://www.hp.com website addresses
Bold text •Keys that are pressed
•Text typed into a GUI element, such as a box
•GUI elements that are clicked or selected, such as
menu and list items, buttons, tabs, and check boxes
Italic text Text emphasis
Monospace text •File and directory names
•System output
•Code
•Commands, their arguments, and argument values
Monospace, italic text •Code variables
•Command variables
Monospace, bold text Emphasized monospace text
WARNING!
Indicates that failure to follow directions could result in bodily harm or death.
CAUTION:
Indicates that failure to follow directions could result in damage to equipment or data.
IMPORTANT:
Provides clarifying information or specific instructions.
user guide 7

NOTE:
Provides additional information.
TIP:
Provides helpful hints and shortcuts.
HP technical support
For worldwide technical support information, see the HP support website: http://www.hp.com/support.
Before contacting HP, collect the following information:
•Product model names and numbers
•Technical support registration number (if applicable)
•Product serial numbers
•Error messages
•Operating system type and revision level
•Detailed questions
Customer self repair
HP customer self repair (CSR) programs allow you to repair your StorageWorks product. If a CSR part
needs replacing, HP ships the part directly to you so that you can install it at your convenience. Some
parts do not qualify for CSR. Your HP-authorized service provider will determine whether a repair can be
accomplished by CSR.
For more information about CSR, contact your local service provider. For North America, see the CSR
website: http://www.hp.com/go/selfrepair.
Product warranties
For information about HP StorageWorks product warranties, see the warranty information website:
http://www.hp.com/go/storagewarranty.
Subscription service
HP recommends that you register your product at the Subscriber’s Choice for Business website:
http://www.hp.com/go/e-updates.
After registering, you will receive e-mail notification of product enhancements, new driver versions,
firmware updates, and other product resources.
HP websites
For additional information, see the following HP websites:
•h
ttp://www.hp.com
•http://www.hp.com/go/storage
•http://www.hp.com/service_locator
•http://www.hp.com/support/manuals
•http://www.hp.com/support/downloads
8About this guide

Documentation feedback
HP welcomes your feedback.
To make comments and suggestions about product documentation, please send a message to
[e-mail]. All submissions become the property of HP.
user guide 9

10 About this guide

1 Identifying the components
Front panel components
15486
12
Item Description
1Hard drive bays
2FrontunitID(UID)module
Front panel LEDs
15460
Item Description Status
1Heartbeat LED Green = System activity
Off=Nosystemactivity
2Fault LED Amber = Fault condition
Off=Nofaultcondition
3UID button/LED Blue = Identified
Blue flashing = Active remote management
Off = No active remote management
user guide 11

Rear panel components
15461
Item Description
1Power supply 1
2Fan module 1
37-segment display board
4SAS in connector
5SAS out connector
6I/O module
7Futureuse
8Fan module 2
9Power supply 2
12 Identifying the components

Rear panel LEDs and buttons
15462
Item Description Status
1I/O module LED Green = System activity
Amber = Fault
Off=Nosystemactivity
2UID button/LED Blue = Identified
Blue flashing = Active remote management
Off=Noacti
ve remote management
3Heartbeat LED Green = System activity
Amber = Fault
Off=Nosystemactivity
4Fan module LED Green = Normal operation
Amber = Fault condition
Off=Fanunseatedformconnectororfailed
5System faultLED Amber = Fault condition
Off=Nofaultcondition
6Power On/Standby
button/system power
LED
Green = On
Amber = Standby (power present)
Off=Off
7Power supply LED Green = Power turned on and power supply functioning properly
Amber = Standby (auxiliary power present)
Blinking amber = Power to this power supply not present
Off = One or more of the following conditions exists:
•A/C power unavailable
•Power supply failed
•Power supply exceeded current limit
user guide 13

Hard drive bay numbers
5
4
3
2
1
10
9
8
7
6
15
14
13
12
11
20
19
18
17
16
25
24
23
22
21
15463
Hard drive LEDs
1
2
15464
Item Description
1Fault/UID LED (amber/blue)
2Online/activity LED (green)
Hard drive LED combinations
NOTE:
Predictive failure alerts can occur only when the enclosure is connected to a Smart Array controller.
14 Identifying the components

Table 2 LED Failure/Fault Alerts
Online/activity LED (green) Fault/UID LED (amber/blue) Interpretation
On,off,orflashing Alternating amber and blue The drive has failed, or a predictive
failure alert has been received for
this drive; it also has been selected
by a management application.
On,off,orflashing Steadily blue The drive is operating normally,
and it has been selected by a
management application.
On Amber, flashing regularly (1 Hz) Apr
edictive failure alert has been
received for this drive. Replace the
drive as soon as possible.
On Off The drive is online, but it is not
currently active.
Flashing regularly (1 Hz) Amber, flashing regularly (1 Hz) Do not remove the drive. Removing
a drive may terminate the current
operation and cause data loss.
The drive is part of an array that
is undergoing capacity expansion
orastripesizemigration,buta
predictive failure alert has been
received for this drive. To minimize
the risk of data loss, do not replace
the drive until the expansion or
migration is complete.
Flashing regularly (1 Hz) Off Do not remove the drive.
Removing a drive may terminate
the current operation and cause
data loss. The drive is rebuilding,
or it is part of an array that is
undergoing capacity expansion or
astripesizemigration.
Flashing irregularly Amber, flashing regularly (1 Hz) The drive is active, but a predictive
failure alert has been received for
this drive. Replace the drive as
soon as possible.
Flashing irregularly Off The drive is active, and it is
operating normally.
Off Steadily amber A critical fault condition has been
identified for this drive, and the
controller has placed it offline.
Replace the drive as soon as
possible.
Off Amber, flashing regularly (1 Hz) A predictive failure alert has been
received for this drive. Replace the
drive as soon as possible.
Off Off The drive is offline, a spare, or not
configured as part of an array.
7-segment display board
The 7-segment display board allows you to identify the following:
•The port on the host controller to which the MSA70 is connected. There are two external ports on
the host controller; each port allows you to connect up to two MSA70s to the controller. Because
user guide 15

one additional MSA70 can be attached to each of the MSA70s, a total of four MSA70s can be
connected to the host controller. See Cascading (1+1) configuration.
•The box ID number assigned to the MSA70 based on how it is connected to the host controller.
If there are multiple MSA70s attached to the controller, the box ID number identifies the order
in which they are attached.
When the MSA70 is connected to the host controller, the controller automatically assigns the port and
box ID numbers to the enclosure. The following table shows MSA70 enclosures and their associated
port and box ID assignments:
Storage Enclosure Port Box ID
MSA70 enclosure 1 P1 B1
MSA70 enclosure 2 P1 B2
MSA70 enclosure 3 P2 B3
MSA70 enclosure 4 P2 B4
To view the port to which the MSA70 is connected, press the up arrow button on the 7-segment display
board. To view the box ID number, press the down button.
15487
You can also view the port and box ID numbers within Array Configuration Utility (ACU), HP Systems
Insight Manager (HP SIM), and Array Diagnostic Utility (ADU).
16 Identifying the components

2 Powering up and powering down
the enclosure
IMPORTANT:
Before installing this product, read the
Important Safety Information document provided.
Powering up
Observe the following guidelines before powering up the enclosure:
•Install all components of the enclosure.
•Install hard drives in the enclosure so the connected host controller can identify and configure
them at powerup.
•Always power up the enclosure first, and then the server. This ensures that the servers, during
their discovery, see the enclosure as an operational device. If you do not power up the enclosure
before powering up the servers, you will need to power down the servers, ensure that the
enclosure is powered up, and then power back up the servers.
To power up the enclosure:
1. Complete server hardware installation and cabling. See the server documentation.
2. Connect the SAS cables and power cords to the enclosure. See Choosing a configuration.
3. Press and hold the Power On/Standby button. Wait and observe the system power LED and fan
modules. When the enclosure powers up, the system power LED illuminates solid green and the
fans spin to a high speed, and then spin down to a low speed.
4. Power up the servers. See the server documentation.
Powering down
CAUTION:
Be sure that the server is the first unit to be powered down and the last to be powered back up. Taking
this precaution ensures that the system does not erroneously mark the drives as failed when the server is
powered up.
IMPORTANT:
If installing a hot-plug device, it is not necessary to power down the enclosure.
To power down the enclosure:
1. Power down any attached servers. See the server documentation.
2. Press the Power On/Standby button on the enclosure. Wait for the system power LED to change
from green to amber.
3. Disconnect the power cords.
The system is now without power.
user guide 17

18 Powering up and powering down the enclosure

3 Setting up the enclosure
Environmental requirements
When installing the enclosure in a rack, select a location that meets the environmental standards
described in this section.
Space and airflow requirements
To allow for servicing and adequate airflow, observe the following space and airflow requirements
when deciding where to install a rack:
•Leave minimum clearance of 63.5 cm (25 in) in front of the rack.
•Leave minimum clearance of 76.2 cm (30 in) behind the rack.
•Leave minimum clearance of 121.9 cm (48 in) from the back of the rack to the back of another
rack or row of racks.
HP enclosures draw in cool air through the front door and expel warm air through the rear door.
Therefore, the front and rear rack doors must be adequately ventilated to allow ambient room air to
enter the cabinet, and the rear door must be adequately ventilated to allow the warm air to escape
from the cabinet.
CAUTION:
To prevent improper cooling and damage to the equipment, do not block the ventilation openings.
CAUTION:
When a vertical space in the rack is not filled by a server or rack component, the gaps between the
components cause changes in airflow through the rack and across the servers. Always use blanking
panels to fill empty vertical spaces in the rack. This arrangement ensures proper airflow. Using a rack
without blanking panels results in improper cooling that can lead to thermal damage.
The 9000 and 10000 Series racks provide proper server cooling from flow-through perforations in the
front and rear doors that provide 64 percent open area for ventilation.
CAUTION:
When using a Compaq-branded 7000 Series rack, you must install the high airflow rack door insert
[P/N 327281-B21 (42U) or P/N 157847-B21 (22U)] to provide proper front-to-back airflow and cooling.
CAUTION:
If a third-party rack is used, observe the following additional requirements to ensure adequate airflow
and to prevent damage to the equipment:
•Front and rear doors—If the 42U rack includes closing front and rear doors, you must allow 5,350 sq
cm (830 sq in) of holes evenly distributed from top to bottom to permit adequate airflow (equivalent
to the required 64 percent open area for ventilation).
•Side—Theclearancebetweentheinstalledrackcomponentandthesidepanelsoftherackmustbea
minimum of 7 cm (2.75 in).
user guide 19

Rack planning resources
The rack resource kit ships with all HP-branded or Compaq-branded 9000, 10000, and H9 Series racks.
For more information on the content of each resource, see the rack resource kit documentation.
If you intend to deploy and configure multiple servers in a single rack, see the white paper on high-density
deployment at the HP website: http://www.hp.com/products/servers/platforms.
Temperature requirements
To ensure continued safe and reliable equipment operation, install or position the enclosure in a
well-ventilated, climate-controlled environment.
The maximum recommended ambient operating temperature (TMRA) for most enclosure products is 35°C
(95°F). The temperature in the room where the rack is located must not exceed 35°C (95°F).
CAUTION:
To reduce the risk of damage to the equipment when installing third-party options:
•Donotpermitoptionalequipmenttoimpedeairflow around the enclosure or to increase the internal
rack temperature beyond the maximum allowable limits.
•Do not exceed the manufacturer’s TMRA.
Power requirements
Installation of this equipment must comply with local and regional electrical regulations governing the
installation of IT equipment by licensed electricians. This equipment is designed to operate in installations
covered by NFPA 70, 1999 Edition (National Electric Code) and NFPA-75, 1992 (code for Protection
of Electronic Computer/Data Processing Equipment). For electrical power ratings on options, see the
product rating label or the user documentation supplied with that option.
WARNING!
To reduce the risk of personal injury, fire, or damage to the equipment, do not overload the AC supply
branch circuit that provides power to the rack. Consult the electrical authority having jurisdiction over
wiring and installation requirements of your facility.
CAUTION:
Protect the enclosure from power fluctuations and temporary interruptions with a regulating UPS. This
device protects the hardware from damage caused by power surges and voltage spikes and keeps the
enclosure in operation during a power failure.
When installing more than one enclosure, you may need to use additional power distribution devices to
safely provide power to all devices. Observe the following guidelines:
•Balance the enclosure power load between available AC supply branch circuits.
•Do not allow the overall system AC current load to exceed 80 percent of the branch circuit
AC current rating.
•Do not use common power outlet strips for this equipment.
•Provide a separate electrical circuit for each power supply in the enclosure.
20 Setting up the enclosure
