HP 83522A Operating and maintenance manual

83522A
RF PLUG-.IN
(Including Options 002 and 004)
SERIAL NUMBERS
This manual applies directly to HP Model 83522A RF
Plug-ins having serial number prefix 2040A or 2127A.
For additional information about serial numbers,
refer to INSTRUMENTS COVERED
BY MANUAL
in Section I.
@Copyright HEWLETT-PACKARD COMPANY 1980
1400 FOUNTAIN GROVE PARKWAY, SANTA ROSA, CA. 95404 U.S.A.
MANUAL PART NO. 83522-90003
Microfiche
Part No. 83522-90004 Printed:
JULY 1981
I
HEWLETT
PACKARD

SERVICE
83522A-07
NOTE
SUPERSEDES None
83522A RF Plug-in
Serial Numbers: 0000AOOOOO/2528~
HP 83522A Marker Assembly Retrofits
DuplicateSemceNote: 83525A-07
Situation:
HP 83522A RF Plug-inswith serialprefixeslisted above may experience problemswhen
replacingthe marker assemblyif a compatiblemotherboard and
ALC assemblyarenot
currently installed.
Solution/Action:
Marker assemblieswith HPP/N 8352560092 have new logic circuitrywhich will allow
a new signal
'SQ MOD 2' tobe fed tothe ALC assembly 'SQ MODDelayCircuit' to
reduce Band
0 overshoot. However,this capabilityis only availableif thenew marker
assemblyis used with a revised motherboard and new
ALC assembly.
If a new marker assemblyis installedin a unit with theincorrect motherboard and
ALC
assembly, the -40V supplywill be pulled down and the unit will not function properly.
Continued
DATE 15 May 1990
ADMINISTRATIVE INFORMATION
O 1990 HEWLETT-PACKARDCOMPANY
PRINTED
IN U.S.A.
SERVICE NOTE CLASSIFICATION:
INFORMATIONONLY
Pa
HEWLETT
PACKARD
1 of 2
AUTHOR: ENTIN:
JG 4500
ADDITIONAL INFORMATION:

Page 2
Service Note 83522A-07
If marker assembly 83525-60092 is installed in an HP 83522A that does NOT have
motherboard
83522-60084 ANDALC assembly 83522-60098, then removeinterconnect
jumper W1 from the markerassembly. Withjumper
W1 removed,the newmarker
assemblywill functionthe same asprevious markerassemblies.

CERTIFICATION
Hewlett-Packard Companycertrfiesthat thisproduct met itspublished specifications at thetime
ofshipmentfrom thefactory. Hewlett-Packardfurther certrfiesthat itscalibration measurements
are traceable to the United States National Bureau of Standards, to the extent allowed by the
Bureau
S calibrationfacility, and to the calibration facilities of other International Standards
Organization members.
WARRANTY
ThisHewlett-Packard instrumentproduct iswarranted againstdefectsinmaterialandworkmanship fora
period of one year from date of delivery. During the warranty period, Hewlett-Packard
Company will, at its option, either repair or replace products which prove to be defective.
Forwarranty serviceorrepair, this product must be returned toa servicefacility designated by HP. Buyer
shall prepay shipping charges to HPand HPshall pay shipping charges to return the product to Buyer.
However, Buyer shall pay all shippingcharges, duties,andtaxesforproductsreturned toHPfromanother
country.
HPwarrants that its software and firmware designated by HPfor use with an instrumentwill execute its
programming instructions when properly installed on that instrument. HP does not warrant that the
operation of the instrument, or software, or firmware will be uninterrupted or error free.
LIMITATION OFWARRANTY
Theforegoingwarranty shall not apply to defectsresulting from improperor inadequate maintenance by
Buyer,Buyer-supplied softwareorinterfacing,unauthorized modification ormisuse,operationoutsideof
the environmental specifications for the product, or improper site preparation or maintenance.
NO OTHER WARRANTY IS EXPRESSED OR IMPLIED. HP SPECIFICALLY DISCLAIMS THE
IMPLIED WARRANTIES OFMERCHANTABILITY AND FITNESS FOR A PARTICULAR PUR-
POSE.
EXCLUSIVE REMEDIES
THE REMEDIES PROVIDED HEREIN ARE BUYER'S SOLE AND EXCLUSIVE REMEDIES.
HP
SHALL NOT BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSE-
QUENTIAL DAMAGES, WHETHER BASED ON CONTRACT, TORT, OR ANY OTHER LEGAL
THEORY.
ASSISTANCE
Product maintenance agreements and other customer assistance agreements are available.for Hewlett-
Packard products.
For anyassistance,contact your nearest Hewlett-PackardSales and Service Ofice.Addresses areprovided
at the back
of this manual.

Model 83522A
CONTENTS
Table of Contents
Section Page Section Page
I GENERAL INFORMATION
1
. 1 . Introduction .................... 1 . 1
1.7
. Specifications .................. 1 . 1
1.9
. Safety Considerations ........... 1-2
1
. 11 . Instruments Covered by
Manual
........................ 1-2
1
. 16 . Description .................... 1-2
1.25
. Options ........................ 1-6
1.26
. Option002,70 dBAttenuator ... 1-6
1.28 . Option 004, Rear Panel
RF Output ................... 1-6
1.30 . Equipment Required
But Not Supplied
............... 1-6
1.32
. Equipment Available ............ 1-6
1.33
. Service Accessories ........... 1-6
1.37 . Model 8410B18411A
Network Analyzer ............ 1-7
1.39 . Model 8755 Frequency
Response Test Set
............ 1-8
1.41 . Power Meters and
Crystal Detectors
............. 1-8
1.43
. RecommendedTestEquipment ... 1-8
I1 INSTALLATION
2-1
. Introduction .................... 2-1
2.3
. Initial Inspection ............... 2-1
2.5
. Preparation for Use .............. 2-1
..........
2.6 . Power Requirements 2-1
2.8 . RF Plug-in Configuration
....................... Switch 2-1
............. 2-10 . Interconnections 2-1
2-12
. Mating Connectors ........... 2-1
....... .
2.14 Operating Environment 2-1
2-19
. Installation Instructions ....... 2-4
........... 2.21 . Storage and Shipment 2-4
2.22
. Environment ................. 2-4
2.25
. Packaging ................... 2-4
I11 OPERATION
3-1
. Introduction .................... 3-1
3.3
. Operating Characteristics ........ 3-1
......... 3.4 . Frequency Resolution 3-1
3.11
. Panel Features ................. 3-2
3.13
. Operator's Checks .............. 3-2
3-15
. Operating Instructions ........... 3-2
3.16
. Front Panel FREQ CAL ...... 3-2
............. 3-18 . Internal Leveling 3-3
External Crystal Detector
.....................
Leveling 3-3
External Power Meter
.....................
Leveling 3-3
External Frequency
Modulation
.................. 3-3
External Amplitude
..................
Modulation 3-4
............
RF Power Control 3-4
Option 002 Step Attenuator
.... 3-4
Alternate Sweep Mode
.............
With Option 002 3-4
........ Phase-Lock Operation 3-4
Operator's Maintenance
........ 3-11
Plug-in Error Codes
......... 3-11
Fuses
...................... 3-11
Blue Service Tags
........... 3-11
IV PERFORMANCE TESTS
4.1
. Introduction .................... 4-1
............ .
4.4 Equipment Required 4-1
.................... .
4.6 Test Record 4-1
.............
4.9 Related Adjustments 4-1
4-11
. Calibration Cycle ............... 4-2
........... . 4-13 Operation Verification 4-2
4.15
. Performance Tests .............. 4-2
. ........
4-16 Internal Crystal Markers 4-2
V ADJUSTMENTS
5.1
. Introduction .................... 5-1
........... .
5.3 Safety Considerations 5-1
............ . 5.5 Equipment Required 5-1
.... . 5.7 Factory-Selected Components 5-1
5.9
. Related Adjustments ............ 5-1
5-11
. Adjustment Procedure ........... 5-1
5-13
. Configuration Switch A3 S1 ...... 5-8
5.14
. Oscillator Bias on A7 .......... 5-10
5.16 . YO Driver Board A6
.............. DAC Calibration
5-17
. Frequency Accuracy ...........
5-18 . Delay Compensation ...........
5.19 . Frequency Reference 1VIGHz
Output ........................
5.20 . ALC Adjustment ..............
5.21 . Internal Leveled Flatness .......
5.22 . Power Calibration .............
5.23 . Power Meter Leveling
.................... Calibration

Table of Contents
CONTENTS (Cont'd)
Model 83522A
Section Page Section Page
.........
5.24 . ALC Gain Adjustment 5-34
5.25
. Power Sweep .................. 5-37
....................
5.26 . FM Driver 5-38
5.27 . Marker and Sampler
...................
Adjustments 5-42
.... 5.28 . External Marker Adjustment 5-46
VI REPLACEABLE PARTS
....................
6-1 . Introduction 6-1
...........
6.3 . Exchange Assemblies 6-1
..................
6.5 . Abbreviations 6-1
...........
6.7 . Replaceable Parts List 6-1
. ........... 6-12 Ordering Information 6-2
..................
6.15 . Spare Parts kit 6-2
VII MANUAL BACKDATING CHANGES
....................
7-1 . Introduction 7-1
VIII SERVICE
.................... 8-1 . Introduction 8-1
..................
8.3 . Service Sheets 8-1
8.6
. Schematic Diagram Notes ....... 8-1
.................... 8.8 . Mnemonics 8-1
.................... 8.10 . ServiceAids 8-1
................
8-13 . Troubleshooting 8-6
....................... 8-16 . Self-Test 8-6
8.20
. Operator-Initiated Tests ......... 8-6
................... 8.23 . Hexadecimal 8-7
8.27
. Recommended TestEquipment ... 8-9
.........................
8.29 . Repair 8-9
8.30
. Module Exchange Program ... 8-9
3.35 . Replacing YIG Oscillator
A12 or YO Driver A6 ......... 8-9
8.37 . Rear Panel Connector
................
Replacement 8-11
8.40 . After-Service Product
.................
Safety Checks 8-11
ILLUSTRATIONS
Figure Page Figure Page
.
.............
Model 83522A RF Plug-in 1-0 5.4 A6TP3 -10 Volt Reference Test
....................
Typical Serial Number Plate ...........
1-2 Point Location 5-11
Delay Line Discriminator
............. 1-11 5.5 .
YO Driver Board Adjustment
........................
Interface Signals on Connector P1 ...... 2-2 Test Setup 5-12
.........
Interface Signals on Connector P2 ......
2-3 5.6 . YO Driver Board Test Points 5-13
Packaging for Shipment Using 5.7
.
Front Panel Hexadecimal
........................
Factory Packaging Materials ........ 2-5 Entry Keys 5-13
Simplified Tuning Voltage 5.8
. Test Setup for Frequency
.............
Block Diagram ..................... 3-2 Accuracy Adjustments 5-16
Model 83522A AF Sweep Mode 5.9
.
50 MHz Oscillator Output
..................
and Adjustments 5-16
...............
Displayed Resolution 3-3 5-10
. Frequency Calibration Adjustments
..................
Front Panel Features 3-5
..........................
Location 5-17
...................
Rear Panel Features 3-6 5-1 A6S1 and A6S2 Frequency Calibration
Front Panel FREQ CAL
..............
Switch Configuration 5-18
Procedure
......................... 3-7 5.12
. Delay Compensation Offset
External Crystal Detector Adjustment Test Setup
............. 5-20
...........................
Leveling 3-8 5-13 . Delay Compensation Adjustment
......................... ........
External Power Meter Leveling 3-10 Locations 5-21
.................
Configuration Switch 3-12 5-14 . Delay Compensation Adjustment
............. ........................
Crystal Marker Test Setup 4-2 Test Setup 5-21
Configuration Switch A3S1 Location
....
5-8 5.15 . Delay Compensation Adjustment
........................
Oscillator Bias Test Point and Waveform 5-22
..............
Adjustment Location 5-10 5.16 . Frequency Reference Adjustments
..........................
........
-10 Volt Reference Test Setup 5-11 Location 5-24

Model 83522A Table of Contents
ILLUSTRATIONS (Cont'd)
Figure Page Figure Page
ALC Adjustments Test Setup
.......... 5-26
ALC Adjustments Location
........... 5-27
Internal LevelingAdjustment
Setup
............................. 5-29
Internal Leveling Adjustments
Location
.......................... 5-30
.........
Power Calibration Test Setup 5-31
Power Calibration Adjustment
..........................
Location 5-32
Power Meter Leveling Calibration
..... 5-33
Power Meter Leveling
Adjustment Location
.............. 5-34
ALC Gain Adjustment Test
Setup
............................. 5-35
ALC Gain Adjustment Location
...... 5-36
Power Sweep Test Setup
.............. 5-37
Power Sweep Adjustment
Location
.......................... 5-38
Test Setup for FM Driver
Adjustments
...................... 5-39
A5 FM Driver Adjustment Location ... 5-40
FM Flatness Tolerance. DC to MHz
... 5-42
Marker Adjustments Test Setup
....... 5-43
Marker Adjustments on A8
........... 5-44
Marker Envelope
.................... 5-45
50 MHz Birdie ...................... 5-45
Marker Adjustments on A7
........... 5-45
On/Off Pulse of Correctly
Adjusted Circuit
................... 5-46
On/Off Pulse of Misadjusted
Circuit Showing Overlap
........... 5-46
External Marker Adjustments
Test Setup
........................ 5-47
External Marker Adjustments
Location
.......................... 5-48
Major Mechanical Parts
.............. 6-21
Attaching Hardware
.................. 6-23
Cables in
RF Section ................. 6-27
RF Output Connector J1
Exploded View .................... 6-28
Schematic Diagram Notes
............. 8-3
Hex Data Rotation Write
.
Bit Pattern ......................... 8-8
Hex Address Fast Read
.
Timing Diagram ................... 8-8
Hex Entry Keys
....................... 8-9
Module Exchange Procedure
.......... 8-10
Rear Panel Connector
Alignment Diagram
............... 8-11
83522A RF Plug-in Simplified
Block Diagram
.................... 8-25
83522A RF Plug-in Overall
....................
Block Diagram 8-25
.................
Display Test Pattern 8-26
A1 Front PanelIA2 Front Panel
........... Interface. Block Diagram 8-31
A1 Front Panel. Component
.........................
Locations 8-31
A2 Front Panel Interface. Component
............. Locations. Front View 8-31
A2 Front Panel Interface. Component
.............. Locations. Rear View 8-31
.................... Column Strobing 8-31
................... RPG Pulse Trains 8-31
................. YO Drive V (A2TP1) 8-31
Frequency Tracking Voltage
.......................... (A2TP3) 8-31
............................ lV/GHz 8-31
A1 Front PanelIA2 Front Panel Inter-
...........
face. Schematic Diagram 8-31
... A3 Digital Interface. Block Diagram 8-35
A3 Digital Interface. Component
.........................
Locations 8-35
Interval Timer Self-Test
.................. Timing Diagram 8-35
Major Address Decoder Self-Test
..................
Timing Diagram 8-35
A3 Digital Interface.
................ Schematic Diagram 8-35
.......
Simplified ALC Block Diagram 8-36
Typical ALC Troubleshooting
.............................
Setup 8-37
..........
Power Meter Leveling Setup 8-38
...... Simplified Modulator Schematic 8-43
..............
A4 ALC. Block Diagram 8-45
.......
A4 ALC. Component Locations 8-45
Retrace Blanking Waveform
.......... 8-45
............
ALC DAC Test Waveform 8-45
................
Open Loop Procedure 8-45
...............
Open Loop Waveforms 8-45
A4 ALC. Schematic Diagram
......... 8-45
Plot of FM Coil Response Versus
............. Modulation Frequency 8-46
A5 Address Decoder Timing
....................... Waveforms 8-48
Power Sweep DAC Self-Test
........................
Waveform 8-50
........ A5 FM Driver. Block Diagram 8-51
... A5 FMDriver. ComponentLocations 8-51
........ A5 Troubleshooting Test Setup 8-51
....... A5 Troubleshooting Waveforms 8-51
A5 FM Driver. Schematic
..........................
Diagram 8-51

Table of Contents Model 83522A
ILLUSTRATIONS (Cont'd)
Figure Page Figure Page
A9 Reference Resistor.
Component Locations
............. 8-58
A6 YO Driver. Block Diagram
........ 8-59
........ EmitterICoil Voltage (A6TP12) 8-59
.........
YO DRIVE Voltage (A6TP14) 8-59
Delay Compensation (A6TP6)
......... 8-59
A6 YO Driver. Component
Locations
......................... 8-59
Sweep Control and Interrupt
Logic Waveforms
.................. 8-59
........ A6SlIS2 Switch Configuration 8-59
........ A6 Decoder Timing Diagrams 8-59
DAC Test
........................... 8-59
.... A6 YO Driver. Schematic Diagram 8-59
A7 Marker. Block Diagram
........... 8-63
..... A7 Marker. Component Locations 8-63
A7 Marker. Test Points
1Through 3
...................... 8-63
A7 Delay Compensation. Test
Points 4 Through 6
................ 8-63
A7 Address Decoder Timing
Diagram
.......................... 8-63
A7 Marker. Schematic
Diagram
.......................... 8-63
A8 Sampler. Block Diagram
.......... 8-65
....
A8 Sampler. Component Locations 8-66
...... A8 Sampler. Schematic Diagram 8-67
A12Al YO Bias. Component
Locations
......................... 8-70
RF Schematic Diagram .............. 8-71
Interface Signals in
Connector Pl
..................... 8-72
..... Interface Signals in Connector P2 8-72
A10 Motherboard. Component
Locations
......................... 8-72
Major Assemblies Locations
.......... 8-79
TABLES
Table Page Table Page
1.1 . Specifications for Model 83522A 6.2 . Manufacturers Code List, Reference
.....
Installed in Model 8350A ............ 1-3 Designations and Abbreviations 6-2
. .....................
1.2 . Supplemental Performance Characteristics 6.3 Replaceable Parts 6-5
. ................
for Model 83522A Installed in 8.1 Index of Service Sheets 8-2
. ...
Model 8350A ....................... 1-4 8.2 Error Codes Associated With 83522A 8-6
..........
Service Accessories Available 1-7
........
Recommended Test Equipment 1-9
Mating Connectors
.................... 2-2
Input Resolution
...................... 3-1
Related Adjustments
.................. 4-1
Model 83522A Performance Test
Record Card
....................... 4-4
Adjustable Components
............... 5-2
Factory Selected Components
.......... 5-5
HP Part Numbers of Standard
Value Replacement Components
..... 5-6
Related Adjustments
.................. 5-7
Adjustments
.......................... 5-7
Configuration Switch A3S1 on
A3
Digital Interface Board .............. 5-9
Operator Initiated Self Test
Routines Available
................. 8-7
Hexadecimal Equivalents
.............. 8-9
83522A Error Codes .................. 8-24
Plug-in Key Codes
................... 8-31
Digital Interface Address
Decoding
......................... 8-32
Configuration Switch on
A3
Digital Interface Board ............. 8-35
Detector Voltages
.................... 8-41
Leveling Control Lines
............... 8-45
Marker Assembly Address
Decoding
......................... 8-60
Approximate Monostable ~ultivibrator
Pulse Times ......................... 8-62
......
83522A Motherboard Wiring List 8-73
.
6.1 . Exchange Parts ....................... 6-1 8.14 HP 83522A Cable List ................ 8-78
vi

Model 83522A Safety
SAFETY CONSIDERATIONS
GENERAL
This product and related documentation must be reviewed for familiarization with safety
markings and instructions before operation. This product has been designed and tested in
accordance with international standards.
SAFETY SYMBOLS
Instruction manual symbol: the product will be marked with this symbol
when it is necessary for the user to refer to the instruction manual (refer to
Table of Contents).
Indicates hazardous voltages.
I -
Indicates earth (ground) terminal.
The WARNING sign denotes a hazard. It calls attention to a procedure,
1-1 practice, or the like, which, if not correctly performed could result in
personal injury. Do not proceed beyond a WARNING sign until the
indicated conditions are fully understood and met.
The CAUTION sign denotes a hazard. It calls attention to an operating
procedure,practice,orthelike,which,if notcorrectlyperformed oradhered
to, could result in damageto ordestruction of part or all of the product. Do
not proceed beyond a CAUTION sign until the indicated conditions are
fully understood and met.
SERVICING
Any servicing, aq'justment,maintenance, orrepairof thisproduct must bepeflormed only byqualifed
personnel.
Adjustments described in this manual may be performed with power supplied to theproduct while
protective covers are removed. Energy available at manypoints may, $contacted, result in personal
injury.
vii

General Information Model 83522A
Figure 1-1. Model 8352214 R F Plug-in.

I - General Information

Model 83522A
General Information
SECTION I
GENERAL INFORMATION
1-1. INTRODUCTION
1-2. This Operating and Service Manual con-
tains information required to install, operate,
test, adjust, and service the Hewlett-Packard
Model 83522A
RF Plug-in. Figure 1-1 shows the
Model 83522A.
1-3. This manual is divided into eight major
sectionswhich provide the following information:
a. SECTION I, GENERAL INFORMATION,
includes a brief description of the instru-
ment, safety considerations, specifications,
supplemental characteristics, instrument
identification, options available, accessories
available, and a list of recommended test
equipment.
b. SECTION 11, INSTALLATION, provides
information for initial inspection, pyepar-
ation for use, storage, and shipment.
c. SECTION 111, OPERATION, explains the
resolution characteristics of the RFplug-in
in CW and swept frequency modes. Operat-
ing instructions include a front panel
FREQUENCY CALIBRATIONprocedure,
FM switch parameter settings, and crystal
and power meter leveling instructions. A
description of front and rear panel features
and plug-in error codes is also given.
d. SECTION IV, PERFORMANCE TESTS,
presents procedures required to verify that
performance of the RFPlug-in is in accord-
ance with published specifications.
e. SECTION V, ADJUSTMENTS, presents
procedures required to properly adjust and
align the Model 83522A
RF Plug-in after
repair.
f. SECTION
VI, REPLACEABLE PARTS,
provides information required to order all
parts and assemblies.
g. SECTION VII, MANUAL BACKDATING
CHANGES, provides backdating informa-
tion required to make this manual compat-
ible with earlier shipment configurations.
h. SECTION VIII, SERVICE, provides an
overall instrument block diagram with
troubleshooting and repair procedures.
Each assembly within the instrument is
covered on a separate Service Sheet which
contains a circuit description, schematic
diagram, component location diagram, and
troubleshooting information to aid in the
proper maintenance of the instrument.
1-4. Supplied with this manual is anOperating
Information Supplement. This is simply a copy
of the first three sections of the manual which
should be kept with the instrument for use by
the instrument operator.
1-5. On the front cover of this manual is a
"Microfiche" part number. This number may be
used to order 10-by 15-centimeter
(4- by 6-inch)
microfilm transparencies of the manual. Each 4-
by dinch microfiche contains up to 60 photo
duplicates of the manual pages. The microfiche
package also includes the latest Manual
Changes sheet as well as all pertinent Service
Notes.
1-6. Refer any questions regarding this manual,
the Manual Changes sheet, or the instrument to
the nearest HP SalesIService Office. Always
identify the instrument by model number,
complete name, and complete serial number in
all correspondence. Refer to the inside rear
cover of this manual for a worldwide listing of
HP SalesIService Offices.
1-7. SPECIFICATIONS
1-8. Listed in Table 1-1 are the specifications
for the Model 83522A RF Plug-in. These
specifications are the performance standards,or
limits, against which the instrument may be

General Information Model 83522A
tested. Table 1-2 lists the RF Plug-in supple-
mental performance characteristics. Supple-
mental performance characteristics are not
specifications but are typical characteristics
included as additional information for the user.
1-9. SAFETY CONSIDERATIONS
1-10. This product has been manufactured and
tested in accordance with international safety
standards. Before operation, this product and
related documentation must be reviewed for
familiarization with safety markings and in-
structions. A complete listing of Safety Con-
siderations precedes Section I of this manual.
1-11. INSTRUMENTS COVERED BY
MANUAL
1-12. Attached to the rear panel of the instru-
ment is a serial number plate. A typical serial
number plate is shown in Figure 1-2.The serial
number is in two parts. The first four digits
followed by a letter comprise the serial number
prefix. The last five digits form the sequential
suffix that is unique to each instrument. The
content of this manual applies directly to
instruments having the same serial number
prefix as those listed on the title page of this
manual under SERIAL NUMBER.
SERIAL NUMBER
-
PREFIX SUFFIX
--
Figure 1-2. Typical Serial Number Plate
1-13. An instrument manufactured after the
printing of this manual may have a serial prefix
that is not listed on the title page. An unlisted
serial prefix indicates that the instrument is
differentfrom those documented inthis manual.
The manual for the instrument is then supplied
with a Manual Changes supplement that
contains information which documents the
differences.
1-14. In addition to change information, the
Manual Changes supplement contains informa-
tion for correcting errors in the manual. To keep
this manual as current as possible, Hewlett-
Packard recommends that you periodically
request the latest Manual Changes supplement.
The supplement for this manual is keyed to the
manual's print date and part number, both of
which appear on the title page. Complimentary
copies of the Manual Changes supplement are
available on request from Hewlett-Packard.
1-15. For information concerning a serial
number prefix that is not listed on the title page
or in the Manual Changes Supplement, contact
your nearest Hewlett-Packard SalesIService
Office.
1-1 6. DESCRIPTION
1-17. The Model 83522A is an RF plug-in
which has been designed for use with the Model
8350A Sweep Oscillator. The Model 83522A
covers the frequency range of 0.01 to 2.4 GHz.A
YIG oscillator is used as the tunable RF
frequency source and a fixed 3.8 GHz oscillator
is mixed with the YIG oscillator to generate a
0.01 to 2.4 GHz RF output.
1-18. Model 83522A front panel functional
controls, pushbuttons, and the Rotary Pulse
Generator (RPG), are monitored by the Model
8350A via the RF plug-in interface circuits. The
Model 8350A generates a tuning voltage ramp
according to the mode of operation (CW,
STARTISTOP, CFIAF). This voltage ramp is
scaled and offset by the Model 83522A to
provide a voltage ramp which is proportional to
the YIG oscillator frequency in the Model
83522A. The Model 83522A then converts the
tuning ramp voltage to a current which drives
the YIG oscillator tuning coil.
1-19. The Model 83522A offers a maximum
leveled RF output power of +13 dBm. Internal
(INT),External (EXT), and Power Meter (MTR)
leveling is available as selected
by the front
panel pushbuttons. A front panel EXTIMTR
ALC input connector and gain control (CAL)
are provided to use with an external leveling
loop. A front panel LED indicates when the RF
output becomes unleveled. The RF output level
is controlled by the Model 83522A RPG, the
Model 8350A data entry controls (keypad and
step keys), or through HP-IB control via the
Model 8350A.

Model 83522A General Information
Table 1-1. Specifications for Model 83522AInstalled in Model 8350A (1 of2)

General Information Model 83522A
Table 1-1. Specificationsfor Model 83522A Installed in Model 8350A (2 of 21
Table 1-2.
Supplemental Performance Characteristicsfor Model 83522A Installed in Model 8350A (1 of 2)
NOTE
Values in this table are not specifications, but are typical characteristics included for user information.
FREQUENCY CHARACTERISTICS~
~ccuracy~ Stability with Temperature:
k200 kHz/"C
(25°C If: 5°C)
CW Mode, typically:
0.01 to 2.4 GHz: k1.5 MHz
OUTPUT CHARACTERISTICS~
Manual Sweep
Power Output
0.01 to 2.4 GHz: 140MHz Resolution (displayed): 0.1 dB
All Sweep Modes (Sweep time 10
ms to 100 ms): Remote Programming (settable):
k25 MHz Typically k0.01 dB
Sweep Mode
ine ear it^^
Stability with Temperature (at maximum
0.01 to
2.4 GHz: 11MHz specified leveled power):
k0.02 dB/"C

Model 83522A General Information
Table 1-2. Supplemental Performance Characteristicsfor Model 83522A Installed inModel 8350A (2 of 2)
Spurious Signals (in dB below carrier) Pulse In
Harmonics: 0.01 to 2.4 GHz TZTL compatible; Logic HIGH=RF ON
At specified maximum Logic LOW=RF OFF
leveled power, typically: 125dB Square Wave modulation up to
30 kHz is
At power level of allowable.
+lo dBm, typically: 230 dB
Non-Harmonics at
External FM
specified maximum Sensitivity (switch selectable)
leveled power, typically: 130dB FM Mode: Typically -20 MHzN
Phase-Lock Mode: Typically -6 MHz/V
Impedance: 50 Ohms Input Impedance: 2000 Ohms nominal
Power Sweep5 CRYSTAL
MARKER^ (Operation when RF power set
Accuracy (including linearity): between +3 to +13 dBm and 510markers per sweep)
Typically
t 1.0dB
Accuracy of Center Frequencies (at 25OC): f 5~10-~
Resolution (displayed): 0.1 dB
Typical Marker Width Around Center Frequency
1 MHz Markers: f 100 kHz
Slope Compensation5
Linearity: Typically <0.2 dB 10 MHz Markers:
f 200 kHz
50 MHz Markers: +300 kHz
Calibrated ~an~e:~Up to 5 dB/GHz; Up to 15 dB
for full sweep range External Markers:
f 300 kHz
Resolution (displayed): 0.01 dB/GHz
Temperature Stability: Typically t2X10-~/"~
MODULATION CHARACTERISTICS~ GENERAL CHARACTERISTICS~
External AM External Marker Input:
Generates amplitude or Z-axis
marker when sweep frequency equals external
Frequency Response: Typically 100 kHz input frequency.
Input Impedance: Approximately 1OK Ohm
Frequency Range: 0.01 to 2.4 GHz
Range of Amplitude Control:
Frequency Reference Output: IVlGHz + 25 mV (over
Typically 15 dB full sweep range) rear panel
BNC output.
Sensitivity: Typically 1 dB/V
Weight: Net 4.5 kg (10 lb.), Shipping 7.7 kg (17 lb.)
FOOTNOTES
Unless otherwise noted, all characteristics are at the RF OUTPUT connector and at 0" to 55°C.
2~ccuracywhen calibrated using internal crystal markers and FREQ CAL adjustment.
With respect to the SWEEP OUT voltage.
4~ithOption 002, in power sweep or slope functions, power can exceed attenuator step by 5 dB.
Power Sweep and Slope Compensation must not exceed
15 dB.
6~xternalmarker input power typically between -10 dBm and 4-10 dBm (over limited power range).
+

General Information Model
83522A
1-20. Internal crystal referenced frequency
markers are available to provide Z-axis intensity
markers from the Model 8350A rear panel PO2
Z BLANK BNC output or 1 dB amplitude
marker dips on the RF output. Harmonic
markers of 10 and 50 MHz are available up to
2.4 GHz and 1MHz markers are available up to
1GHz. A rear panel BNC connector accepts an
external marker reference frequency. Marker
operation is selected by the front panel controls
or through HP-IB control via the Model 8350A.
1-21. A power sweep function allows the RF
output power to be swept at least 15 dB during
CW mode or swept frequency modes. Power
sweep is selected by the front panel POWER
SWEEP pushbutton. Slope compensation con-
trol is also available by selecting the SLOPE
pushbutton and rotating the Model 83522A
RPG or manipulating the Model 8350A data
entry controls. The power sweep function and
slope compensation may both be selected and
modified through HP-IB control via the Model
8350A.
1-22. The RF output may be internally or
externally amplitude modulated, or externally
frequency modulated. Internal square wave
amplitude modulation frequency is selectable by
a Model 8350A internal jumper to be 1 kHz or
27.8 kHz (for use with the Model 8755 Swept
Amplitude Analyzer). Rear panel BNC con-
nectors accept anexternal
AM or FM frequency.
FM coupling (direct coupled or cross-over) and
sensitivity is selected by an internal configur-
ation switch in the Model 83522A. Refer to
Section 111, Operation, of this manual for
detailed information on the configuration
switch.
1-23. A rear panel IVlGHz signal corresponds
to the RF output frequency. This output voltage
may by used as a reference for pretuning
external equipment in phase locking applica-
tions. (The Model 8410Bl8411A Network
Analyzer utilizes this output in such a
configuration).
1-24. The RF output may be turned off by the
RF ON/OFF pushbutton. RF power on is
indicated by the LED in the center of the
pushbutton. Additionally, in CW mode, the CW
FILTER, when selected, places a capacitor
across the YIG oscillator tuning coil to filter
high frequency noise which would appear at the
RF output. All front panel functions, with the
exception of the FREQ CAL and CAL adjust-
ments, may be set or altered by computer control
via the HP-IB bus connection on the Model
8350A.
1-25. OPTIONS
1-26. Option 002, 70
dB Attenuator
1-27. Option 002 instruments contain a digi-
tally controlled attenuator just before the RF
output. Up to 70 dB of attenuation in 10dB steps
is automatically selected as required to attenuate
the RF output power to the indicated level. The
continuously variable power level function
operates as in a standard instrument with the
data entry controls.
1-28. Option 004, Rear Panel RF Output
1-29. Option 004 instruments have the Type N
RF output connector and the BNC EXTIMTR
ALC input connector on the rear panel instead
of the front panel.
1-30. EQUIPMENT REQUIRED BUT NOT
SUPPLIED
1-31. To have a complete operating sweep
oscillator unit, the Model 83522A RF plug-in
must be installed in a Model 8350A Sweep
Oscillator. Refer to Section I1 Installation inthis
manual for a detailed description of RFplug-in
installation.
1-32. EQUIPMENT AVAILABLE
1-33. Service Accessories
1-34. A Service Accessory Kit (HP Part No.
08350-60020) is available for servicingthe Model
83522A RFPlug-in and the Model 8350A Sweep
Oscillator. HP Part Numbers for the individual
parts of the kit are provided in Table 1-3.
1-35. The Service Accessory Kit includes:
Two 44-pin printed circuit board extenders.
These boards have keyed slots which allow
them to be used in each of the keyed pc
board connectors in the Model 83522A and
in the Model 8350A as well.

Model 83522A General Information
An RF Plug-in extender cable set that
provides all electrical connections to the
RF plug-in when it is removed from the
sweep oscillator. The
RF Plug-in Interface
connector (P2) and the Power Supply
Interface connector (PI) are extended by
separate cables.
One Hex Balldriver for use in Model 8350A
repairs.
One 16-pin and one 20-pin integrated
circuit test clip.
1-36. A listing of sevice accessories available
including service cables, wrenches, adapters,
and extender boards is given in Table 1-3.
1-37. Model841OB/8411 A Network
Analyzer
1-38. The Model 8350A Sweep Oscillator, with
the Model 83522A
RF Plug-in installed, is
compatible with the HP Model 8410B Network
Analyzer system.The combination of the Model
8410B Network Analyzer, the Model 8411A
Frequency Converter, and an appropriate dis-
play plug-in formsa phasemeter and a ratiometer
for direct phase and amplitude ratio measure-
ment on RF voltages. These measurements can
be made on single frequencies and on swept
frequencies from 110 MHz to 18 GHz. The
Model 8350A/83522Acombination is capable of
operation from 110 MHz to 2.4 GHz within this
range.The Model 8410B has anAuto-Frequency
Table 1-3. Service Accessories A vailable
NAME
44-pin printed circuit board extender
RFPlug-in Extender Cables
Adjustment Tool
Wrenches
Service Cables
Adapters
Hex Balldriver
IC Test Clip
*These items are included in
a Service Accessories Kit HP Part No. 08350-60020 (2 board extenders are included in this kit).
HP PART NUMBER
08350-60031 *
08350-60034"
08350-60035"
8830-0024
08555-20097
8710-0946
8120-1578
83525-60019
1250-0777
1250-0082
1250-1404
1250-1158
1250-0674
1250-0675
1250-0069
8710-0523"
1400-0734*
1400-0979 *
DESCRIPTION
Extends printed circuit boards
Extends RFPlug-in Interface connector (P2)
Extends RFPlug-in Power Supply Interface connector (PI)
Fits miniature adjustment slot on potentiometers
5116" slotted box/open end
15/64" open end
18" coax with SMA(m) connector on each end
10" coax with SMB snap on
(f) and SMA (m)
Type N (f) to BNC (m)
Type N (m) to BNC (m)
Type N
(f) to SMA (f)
SMA (f) to SMA (f)
SMA (f) toSMB (m)
SMA
(f) toSMC (m)
SMBsnap on (m) to SMB snap on (m)
Removes front panel hold down plate hex screws in 8350A
16-pin IC test clip
20-pin IC test clip

General Information Model 83522A
range mode which gives it the capability of
automatically tracking the Model 8350A Sweep
Oscillator over octave and multi-octave fre-
quency bands. Two interconnections to the
Model 8350A are necessary to ensure that the
Model 8410B will phase lock properly. The
Model 8410B Source Control Cable (HP
08410-60146) connects the Model 8410B rear
panel SOURCE CONTROL connector to the
Model 8350A rear panel PROGRAMMING
CONNECTOR.Additionally, the Model 83522A
RF Plug-in rear panel lV/GHz output connects
to the Model 8410B rear panel FREQ REF
INPUT.The Model 8410B Source Control Cable
connector pins and signals are illustrated in the
Model 8350A Sweep Oscillator Operating and
Service Manual.
1-39. Model 8755 Frequency Response
Test Set
1-40. The Model 8350A Sweep Oscillator with
the Model 83522A RF Plug-in installed is
compatible with the Model 8755 Frequency
Response Test Set for broadband swept scalar
measurements. The Model 8350A provides
internal 27.8 kHz square wave
AM modulation
of the RF output eliminating unnecessary cable
connections to the Model 8755 or the use of an
external modulator. The Model 8350A can also
produce alternate sweeps through use of the
ALT n function which works in conjunctionwith
the channel switching circuits in the Model
8755C. This permits Channel 1 on the Model
8755C to respond only to the Model 8350A
current state and Channel 2 to the alternate
state. A single cable (HP Part Number 8120-
3174) connects between the Model 8350A rear
panel ALT SWP INTERFACE connector and
the Model 8755C front panelALT SWP INTER-
FACE connector.
1-41. Power Meters and Crystal Detectors
1-42. The RF output can be externally leveled
using the HP Model 432 Power Meter or
negative polarity output crystal detectors. Refer
to Section I11 Operation of this manual for
detailed information on levelingtechniques that
may be used with the Model 8350A/RF Plug-in
combination.
NOTE
The Model 435A and 436A Power Meters
should not be used in Model
8350A/
Model 83522A external leveling systems.
1-43. RECOMMENDEDTEST EQUIPMENT
1-44. Equipment required for testing and
adjusting the instrument is listed in Table 1-4.
Other equipment may be substituted if it meets
or exceedsthe critical specifications indicated in
the table.

Model 83522A General Information
Table 1-4. Recommended Test Equipment (1 of 2)
+
Instrument
Sweep Oscillator
Digital Voltmeter (DVM)
Oscilloscope
Frequency Counter
Spectrum Analyzer
Modulation Analyzer
Swept Amplitude Analyzer
Display Mainframe
Detector
St
orage-Normalizer
RF Marker Source
Frequency Meter
Recommended Model
HP 8350A
HP 3455A
HP 1740A
HP 5343A
HP 8565A or
HP 8566A
HP 8901A
HP 8755C
HP 182T/TR
HP 1 1664A
HP 8750A
HP 8350A183522A
HP 536A
Critical Specifications
No substitute
Range: -50V to +50V
Accuracy: k0.01%
Input Impedance: 210M Ohms
Dual Channel
Bandwidth: dc to 100MHz
Vertical Sensitivity: <5 mV/Div
Horizontal Sweep Rate: GO.1 y S/Div
X vs. Y Display Mode
Frequency Range
: 0.01 to 2.4 GHz
Frequency Range: 0.01 to 18GHz
Residual FM : GI00 Hz
Must have auxiliary IF output when used with
the HP 890
1AModulation Analyzer
(May be used in addition to Spectrum Analyzer).
Frequency Range: Must cover auxiliary IF
Output frequency of SpectrumAnalyzer used.
Residual FM
: <lo Hz
Capable of Transmission and
Reflection measurements.
Power Resolution: G0.25 dB/Div
Compatible with HP 8755CSwept Amplitude
Analyzer and HP 8750A Storage-Normalizer
Compatible with Swept Amplitude Analyzer
Frequency Range: 0.01 to 2.4 GHz
Power Range: - 20 to +10 dBm
Compatible with Display Mainframe and
Swept Amplitude Analyzer
CW Frequency: 1.2 GHz
Output Power Level: 2-1 0 dBm
Frequency Accuracy: a. 17%
Calibration Increments: G2 MHz
Frequency Range: 0.96 to 4.0 GHz
Use1
P,A,T
P,A,T
P,A,T
P,A
P,T
P,T
P,A
P,A
P,A
P
A
P
