HP 14s Installation instructions

EL-MF877-00 Page 1
Template Revision C
Last revalidation date 04-01-2018
HPI instructions for this template are available at EL-MF877-01
Product End-of-Life Disassembly Instructions
Product Category: Notebooks and Tablet PCs
Marketing Name / Model
[List multiple models if applicable.]
HP 14s Laptop PC
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the
disassembly of HPI products to remove components and materials requiring selective treatment, as defined by EU directive
2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
NOTE: Recyclers should sort plastic materials into resin streams for recycling based on the ISO 11469 plastic marking code on the
plastic part. For any questions on plastic marking, please contact HP’s Sustainability Contact.
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as applicable.
Item Description
Notes
Quantity of
items
included in
product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
Batteries, excluding Li-Ion batteries.
All types including standard alkaline, coin or button style
batteries
0
Li-Ion batteries. Include all Li-Ion batteries if more than
one is provided with the product (such as a detachable
notebook keyboard battery, RTC coin cell, etc.)
Battery(ies) are attached to the product by (check all
that apply with an “x” inside the “[ ]”):
[ X ] screws
[ ] snaps
[ ] adhesive
[ ] other. Explain
NOTE: Add detailed removal procedures including
required tools in the sections 3.1/3.2.
1
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
0
Liquid Crystal Displays (LCD) with a surface greater than
100 sq cm
Includes background illuminated displays with gas
discharge lamps (14”)
1
Cathode Ray Tubes (CRT)
0
Capacitors / condensers (Containing PCB/PCT)
0
Electrolytic Capacitors / Condensers measuring greater
than 2.5 cm in diameter or height
0
External electrical cables and cords
DC Cable for External Power Supply
1
Gas Discharge Lamps
0
Plastics containing Brominated Flame Retardants
0

EL-MF877-00 Page 2
Template Revision C
Last revalidation date 04-01-2018
HPI instructions for this template are available at EL-MF877-01
Item Description
Notes
Quantity of
items
included in
product
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
0
Components and waste containing asbestos
0
Components, parts and materials containing refractory
ceramic fibers
0
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components and
materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Electric screwdriver (Cross)
Cross, #1
Suction cup
Tweezers
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment
including the required steps to remove the external enclosure:
1. Follow steps described in disassembly instruction (ref to the attachments)
2. If parts can be removed without using a tool, remove it first
3. Use correct screwdriver and torque value when unlocking the screws
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items contained in the
product that require selective treatment (with descriptions and arrows identifying locations).

制表：
審核：
MANUFACTURING PROCESS INSTRUCTIONS
MECHANICAL ASSEMBLY
1.00
Station
Version
Station
Version
Station
Version
Station
Version
Station
Version
Station
Version
1 1.00 9 1.00
2 1.00 10 1.00
3 1.00 11 1.00
4 1.00 12 1.00
5 1.00 13 1.00
6 1.00
7 1.00
81.00
Station
Ver.
ALL 1.**
Page:
1 of 15
Sub-assembly name:
Hawking LCM 拆机 SOP
Document No.:
Hawking LCM 拆机 SOP
A.Current station version list:
B.Version Modify list:
Date
Content
Design
Written by:
杨金波
Revision:
Date:
2020/1/8
2020/1/8
首份拆机SOP
杨金波
MODEL : Hawking
周 红 朱 亚

Operation Procedure
Document No. : Hawking LCM Disassembly SOP Station:
Work Name : Ver. : Date :
Fixture List(Fixture Specification) QTY Fixture List(Fixture Specification) QTY
Step：
Attention︰if an exception occurs, please contact foreman or assistant immediately.
Department：Auditor：Huang.Ya-jun IE
1(1/1)
Disassemble Hinge cover 1.00 2018/03/12
1. Press down Hinge cover.

Operation Procedure
Document No. : Hawking LCM Disassembly SOP Station:
Work Name : Ver. : Date :
Fixture List(Fixture Specification) QTY Fixture List(Fixture Specification) QTY
Step：
Attention︰if an exception occurs, please contact foreman or assistant immediately.
Department：Auditor：Huang.Ya-jun IE
2(1/1)
Disassemble Bezel 1.00
1. First disassemble the left Bezel and
pull it inward to disassemble.
2. Follow pic as below 1→2→3 →4
❖Note：please be slow when
disassemble the bezel and can use
cards to be help.
1
2
3
4
2018/03/12

Operation Procedure
Document No. : Hawking LCM Disassembly SOP Station:
Work Name : Ver. : Date :
Fixture List(Fixture Specification) QTY Fixture List(Fixture Specification) QTY
Step：
Attention︰if an exception occurs, please contact foreman or assistant immediately.
Department：Auditor：Huang.Ya-jun IE
3(1/1)
Disassemble LCD 1.00
1: Remove the Bonding at bottom
left and right with tweezers and
pull down to separate the
bonding from the LCD
2018/03/12
tweezer 1

Operation Procedure
Document No. : Hawking LCM Disassembly SOP Station:
Work Name : Ver. : Date :
Fixture List(Fixture Specification) QTY Fixture List(Fixture Specification) QTY
Step：
Attention︰if an exception occurs, please contact foreman or assistant immediately.
Department：Auditor：Huang.Ya-jun IE
4(1/1)
Disassemble LCD 1.00
1. Return LCD over back，pull out
off EDP cable CNTR
2. Need recycle LCD, Put LCD
carefully in box
2018/03/12

Operation Procedure
Document No. : Hawking LCM Disassembly SOP Station:
Work Name : Ver. : Date :
Fixture List(Fixture Specification) QTY Fixture List(Fixture Specification) QTY
Step：
Attention︰if an exception occurs, please contact foreman or assistant immediately.
Department：Auditor：Huang.Ya-jun IE
5(1/2)
Disassemble Hinge 1.00
1. Remove screws of left and right
on hinge
M2.5x2.5(6052A0047401)*6.
❖Screwdriver N0 #1
❖Torsion：2.5±0.3 Kg/cm
2. Disassemble hinge need recycle
2018/03/12
电动起子 1

Operation Procedure
Document No. : Hawking LCM Disassembly SOP Station:
Work Name : Ver. : Date :
Fixture List(Fixture Specification) QTY Fixture List(Fixture Specification) QTY
Step：
Attention︰if an exception occurs, please contact foreman or assistant immediately.
Department：Auditor：Huang.Ya-jun IE
5(2/2)
Disassemble Hinge 1.00
1. Disassemble left and right Hinges
need to be recycled.
2018/03/12

Operation Procedure
Document No. : Hawking LCM Disassembly SOP Station:
Work Name : Ver. : Date :
Fixture List(Fixture Specification) QTY Fixture List(Fixture Specification) QTY
Step：
Attention︰if an exception occurs, please contact foreman or assistant immediately.
Department：Auditor：Huang.Ya-jun IE
1.Disassemble wlan from left to right side, as
shown in the picture.
Disassemble downside of WLANAUX
6(1/2)
Important
2019/12/15
PIC 1
PIC 2
Wlan-tidy Bar 1
0.30
PIC 3

Operation Procedure
Document No. : Hawking LCM Disassembly SOP Station:
Work Name : Ver. : Date :
Fixture List(Fixture Specification) QTY Fixture List(Fixture Specification) QTY
Step：
Attention︰if an exception occurs, please contact foreman or assistant immediately.
Department：Auditor：Huang.Ya-jun IE
1. Disassemble the wwan from right to left side,
as shown in the pictures.
7(1/1)
Important
Wlan-tidy Bar 1
2019/12/15
PIC 1
Disassemble downside of WWANAUX
PIC 2
PIC 3
0.30

Operation Procedure
Document No. : Hawking LCM Disassembly SOP Station:
Work Name : Ver. : Date :
Fixture List(Fixture Specification) QTY Fixture List(Fixture Specification) QTY
Step：
Attention︰if an exception occurs, please contact foreman or assistant immediately.
Department：Auditor：Huang.Ya-jun IE
1.Disassemble left attenna by the way marked
in picture.
8(1/1)
Important
Wlan-tidy Bar 1
2019/12/15
PIC 1
Disassemble left attenna
PIC 2
0.30

Operation Procedure
Document No. : Hawking LCM Disassembly SOP Station:
Work Name : Ver. : Date :
Fixture List(Fixture Specification) QTY Fixture List(Fixture Specification) QTY
Step：
Attention︰if an exception occurs, please contact foreman or assistant immediately.
Department：Auditor：Huang.Ya-jun IE
Disassemble left attenna 9(1/1)
Wlan-tidy Bar 1
PIC 1
Important
2019/12/15
0.30
1. Bend copper foil of WWAN and WLAN away
from cover.

Operation Procedure
Document No. : Hawking LCM Disassembly SOP Station:
Work Name : Ver. : Date :
Fixture List(Fixture Specification) QTY Fixture List(Fixture Specification) QTY
Step：
Attention︰if an exception occurs, please contact foreman or assistant immediately.
Department：Auditor：Huang.Ya-jun IE
1.Disassemble right side attenna by the way
marked in the pictures.
Disassemble right side attenna
10(1/1)
Important
2019/12/15
PIC 1
PIC 2
Wlan-tidy Bar 1
0.30

Operation Procedure
Document No. : Hawking LCM Disassembly SOP Station:
Work Name : Ver. : Date :
Fixture List(Fixture Specification) QTY Fixture List(Fixture Specification) QTY
Step：
Attention︰if an exception occurs, please contact foreman or assistant immediately.
Department：Auditor：Huang.Ya-jun IE
1. Bend copper foil of WWAN and WLAN away
from cover.
Disassemble right side attenna
11(1/1)
Important
2019/12/15
PIC 1
Wlan-tidy Bar 1
0.30

Operation Procedure
Document No. : Hawking LCM Disassembly SOP Station:
Work Name : Ver. : Date :
Fixture List(Fixture Specification) QTY Fixture List(Fixture Specification) QTY
Step：
Attention︰if an exception occurs, please contact foreman or assistant immediately.
Department：Auditor：Huang.Ya-jun IE
Disassemble camera
1. Disassemble EDP cable by the way marked in
pictures..
2. Tear down camera gum, disassemble the
camera for recycle.
PIC 1
12(1/1)
2019/12/15
PIC 2
0.30

Operation Procedure
Document No. : Hawking LCM Disassembly SOP Station:
Work Name : Ver. : Date :
Fixture List(Fixture Specification) QTY Fixture List(Fixture Specification) QTY
Step：
Attention︰if an exception occurs, please contact foreman or assistant immediately.
Department：Auditor：Huang.Ya-jun IE
13(1/1)
Save A cover for recycle 1.00
1. Save A cover in bag for recycle.
2018/03/12

制表：
審核：
MANUFACTURING PROCESS INSTRUCTIONS
MECHANICAL ASSEMBLY
1.00
Station Version Station Version Station Version Station Version
Station
Version
Station
Version
1 1.00 9 1.00
2 1.00 10 1.00
3 1.00 11 1.00
4 1.00 12 1.00
5 1.00 13 1.00
6 1.00 14 1.00
7 1.00
81.00
Station
Ver.
ALL 1.**
Page:
1 of 20
Sub-assembly name:
Hawking FA 拆机 SOP
Document No.:
Hawking FA 拆机 SOP
A.Current station version list:
B.Version Modify list:
Date
Content
Design
Written by:
杨金波
Revision:
Date:
2019/1/6
2019/1/6
首份拆机SOP
杨金波
MODEL : Hawking
周 红 朱 亚

Standard Operation Process
Document No. : Hawking FA disassembly SOP Station:
Process Name : Ver. : Date :
Fixture list(fixture specifications) Qty Fixture list(fixture specifications) Qty
Step：
Department：Tabulator：Ya Zhu IE
1(1/1)
Dismantle Base Bottom rubber 1.00 2018/03/12
1. Get rubber*2 below marked
as red
Electric
screwdriver 1

Standard Operation Process
Document No. : Hawking FA disassembly SOP Station:
Process Name : Ver. : Date :
Fixture list(fixture specifications) Qty Fixture list(fixture specifications) Qty
Step：
Department：Tabulator：Ya Zhu IE
2(1/1)
Dismantle Base Bottom Screws 1.00
1. Get screws
M2.5x4(6052B0424501Silver) *2.（
number 1&2）
❖Dismantle sequence 1 →2
2. Get screwsM2.5x6
(6052A0029201)*4
❖screwdriver :#1
❖Torque：2.0 ±0.30 Kgf．cm
❖Dismantle sequence 3 →4→5→6
❖Separate the recycling screw
12
2018/03/12
Electric
screwdriver 1
