HP Compaq nx5000 series Manual

Maintenance and Service
Guide
HP Compaq Business Notebook nx5000
Series
Compaq Presario V1000 Notebook PC
Document Part Number: 349052-001
April 2004
This guide is a troubleshooting reference used for maintaining
and servicing the notebook. It provides comprehensive
information on identifying notebook features, components, and
spare parts; troubleshooting notebook problems; and performing
notebook disassembly procedures.

© Copyright 2004 Hewlett-Packard Development Company, L.P.
Microsoft and Windows are U.S. registered trademarks of Microsoft
Corporation. Intel, Pentium, and Celeron are trademarks or registered
trademarks of Intel Corporation or its subsidiaries in the United States and
other countries. SD Logo is a trademark of its proprietor. Bluetooth is a
trademark owned by its proprietor and used by Hewlett-Packard Company
under license. Adobe and Acrobat are trademarks of Adobe Systems
Incorporated.
The information contained herein is subject to change without notice. HP
shall not be liable for technical or editorial errors or omissions contained
herein.
Maintenance and Service Guide
HP Compaq Business Notebook nx5000 Series
Compaq Presario V1000 Notebook PC
First Edition April 2004
Document Part Number: 349052-001

Maintenance and Service Guide iii
Contents
Contents
1 Product Description
1.1 Models. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2
1.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–33
1.3 Clearing a Password . . . . . . . . . . . . . . . . . . . . . . . . 1–35
1.4 Power Management. . . . . . . . . . . . . . . . . . . . . . . . . 1–36
1.5 External Components . . . . . . . . . . . . . . . . . . . . . . . 1–37
1.6 Design Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . 1–51
2 Troubleshooting
2.1 Computer Setup and Diagnostics Utilities . . . . . . . . 2–1
Using Computer Setup . . . . . . . . . . . . . . . . . . . . . . . 2–2
Selecting from the File Menu . . . . . . . . . . . . . . . . . . 2–3
Selecting from the Security Menu . . . . . . . . . . . . . . 2–4
Selecting from the Tools Menu. . . . . . . . . . . . . . . . . 2–5
Selecting from the Advanced Menu . . . . . . . . . . . . . 2–5
2.2 Using Diagnostics for Windows . . . . . . . . . . . . . . . . 2–8
Obtaining, Saving, or Printing Configuration
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–8
Obtaining, Saving, or Printing Diagnostic
Test Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–9
2.3 Troubleshooting Flowcharts . . . . . . . . . . . . . . . . . . 2–11

iv Maintenance and Service Guide
Contents
3 Illustrated Parts Catalog
3.1 Serial Number Location . . . . . . . . . . . . . . . . . . . . . . 3–1
3.2 Notebook Major Components . . . . . . . . . . . . . . . . . . 3–2
3.3 Miscellaneous Plastics Kit Components . . . . . . . . . 3–10
3.4 Hard Drives and MultiBay Devices . . . . . . . . . . . . 3–12
3.5 Miscellaneous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–13
4 Removal and Replacement Preliminaries
4.1 Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–1
4.2 Service Considerations . . . . . . . . . . . . . . . . . . . . . . . 4–2
Plastic Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–2
Cables and Connectors . . . . . . . . . . . . . . . . . . . . . . . 4–2
4.3 Preventing Damage to Removable Drives . . . . . . . . 4–3
4.4 Preventing Electrostatic Damage . . . . . . . . . . . . . . . 4–4
4.5 Packaging and Transporting Precautions . . . . . . . . . 4–4
4.6 Notebook Precautions . . . . . . . . . . . . . . . . . . . . . . . . 4–5
4.7 Grounding Equipment and Methods . . . . . . . . . . . . . 4–6
5 Removal and Replacement Procedures
5.1 Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–2
5.2 Disassembly Sequence Chart . . . . . . . . . . . . . . . . . . 5–3
5.3 Preparing the Notebook for Disassembly . . . . . . . . . 5–4
5.4 Notebook Feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–10
5.5 Mini PCI Communications Board. . . . . . . . . . . . . . 5–11
5.6 MultiBay Device . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–13
5.7 Bluetooth Wireless Communications Board. . . . . . 5–14
5.8 Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–16
5.9 Switch Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–20
5.10 Modem Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–22
5.11 Memory Module . . . . . . . . . . . . . . . . . . . . . . . . . . 5–24
5.12 Keyboard Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–26
5.13 Fan Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–27

Contents
Maintenance and Service Guide v
5.14 Heat Sink. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–30
5.15 Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–33
5.16 Display Assembly . . . . . . . . . . . . . . . . . . . . . . . . . 5–35
5.17 Top Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–39
5.18 RTC Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–43
5.19 Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–45
5.20 LED Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–48
5.21 Bottom Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–50
5.22 System Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–52
6 Specifications
A Connector Pin Assignments
B Power Cord Set Requirements
3-Conductor Power Cord Set . . . . . . . . . . . . . . . . . . . . . . B–1
General Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . B–1
C Screw Listing
Index

Maintenance and Service Guide 1–1
1
Product Description
The HP Compaq Business Notebook nx5000 Series and the
Compaq Presario V1000 notebook PC offer advanced modularity,
an Intel® Pentium® M or an Intel Celeron® M processor with
64-bit architecture, an Intel Extreme Graphics 2 graphics
controller with up to 64 MB of shared video memory, and
extensive multimedia support.
HP Compaq Business Notebook nx5000 Series (Compaq Presario
V1000 notebook PC appearance varies slightly).

1–2 Maintenance and Service Guide
Product Description
1.1 Models
Notebook models are shown in Table 1-1, Table 1-2, and
Table 1-3.
Table 1-1
HP Compaq Business Notebook nx5000
and Compaq Presario V1000 Notebook PC
Model Naming Conventions
Key
Cnx U P 170 X5 60 y Ci 10 h XXXXXX-XXX
1234 5 6 7 8 910 11
Key Description Options
1Brand/Series
designator
C = HP Compaq
P = Presario
nx5000 (all models)
V10xx
2 Graphics memory U = Shared memory architecture
3 Processor type P = Intel Pentium M
C = Intel Mobile Celeron
4 Processor speed 170 = 1.70 GHz
160 = 1.60 GHz
150 = 1.50 GHz
140 = 1.40 GHz
130 = 1.30 GHz
120 = 1.20 GHz
5 Display type/
size/resolution
X = XGA
Y = SXGA+WVA
5 = 15.0-inch
4 = 14.1-inch
6 Hard drive size 60 = 60 GB
40 = 40 GB
30 = 30 GB
7 Optical drive
designator
Y = 24x DVD+RW/R
and CD-RW Combo
Drive
C = 24x CD-ROM Drive
W = 24x DVD/CD-RW
Combo Drive
D = 8x/24x DVD-ROM
Drive

Product Description
Maintenance and Service Guide 1–3
Key
Cnx U P 170 X5 60 y Ci 10 h XXXXXX-XXX
1234 5 6 7 8 910 11
Key Description Options
8 Integrated
communication/
wireless device
M = Modem
C = Combination
modem + FE NIC
N = None
b = 802.11b
d = 802.11a/b/g
g = 802.11b/g
i = 802.11b +
Bluetooth®
j = 802.11b/g +
Bluetooth
m = 802.11a/b/g +
Bluetooth
N = None
9 RAM 12 = 128-MB
25 = 256-MB
51 = 512-MB
10 = 1,024-MB
10 Operating system P = Microsoft® Windows® XP
Professional
H = Microsoft Windows XP
Home
2 = Microsoft Windows 2000
L = Linux
F = FreeDOS
a = 1-year
warranty on
parts and labor
g= 4-year
warranty on
parts and labor
S = Special
11 SKU#
Table 1-1
HP Compaq Business Notebook nx5000
and Compaq Presario V1000 Notebook PC
Model Naming Conventions
(Continued)

1–4 Maintenance and Service Guide
Product Description
Table 1-2
HP Compaq Business Notebook nx5000 Models
All HP Compaq Business Notebook nx5000 models feature:
■TouchPad pointing device
■Video memory
■8- or 6-cell lithium ion (Li-Ion) battery pack
■1- or 3-year warranty on parts and labor, varying by model
Cnx5000 P 140 X5 30 W Md 25 PaS
United States PD973US ABA
Cnx5000 U C 120 X4 30 C Cb 25 H
Taiwan DY824PA AB0
Cnx5000 U C 120 X4 30 C CN 25 2
Japan PB690PA ABJ
Cnx5000 U C 120 X4 30 C CN 25 H
Japan PB328PA ABJ
Cnx5000 U C 120 X4 30 C CN 25 P
Japan PB688PA ABJ
Cnx5000 U C 120 X4 30 D Cb 25 H
Taiwan DY825PA AB0
Cnx5000 U C 120 X4 30 D Cb 25 P
Taiwan DY826PA AB0
Cnx5000 U C 120 X4 30 W Cb 25 P
Japan PC993PA ABJ
Cnx5000 U C 120 X4 30 W CN 25 P
Japan PB691PA ABJ
Cnx5000 U C 120 X4 40 C Cb 51 H
Asia Pacific PC981PA UUF

Product Description
Maintenance and Service Guide 1–5
All HP Compaq Business Notebook nx5000 models feature:
■TouchPad pointing device
■Video memory
■8- or 6-cell lithium ion (Li-Ion) battery pack
■1- or 3-year warranty on parts and labor, varying by model
Cnx5000 U C 120 X4 40 C CN 25 P
Japan PB689PA ABJ
Cnx5000 U C 120 X4 40 W Cb 51 H
Australia DX925P ABG
Cnx5000 U C 120 X5 30 C CN 25 P
Brazil PA502A AC4
Cnx5000 U C 120 X5 30 D Cb 25 P
French Canada
Latin America
DH946U ABC
DH946U ABM
United States DH946U ABA
Cnx5000 U C 120 X5 40 W Cb 51 H
Australia PB324PA ABG
Cnx5000 U C 130 X4 30 C Cg 25 P
United States DV110U ABA
Cnx5000 U C 130 X4 30 C Cg 25 PgS
United States PE804UC ABA
Cnx5000 U C 130 X4 40 D CN 25 P
Australia PE734PA ABG
Cnx5000 U C 130 X4 40 N Cg 25 P
United States DV137U ABA
Cnx5000 U C 130 X5 40 W Cb 25 P
Australia PE735PA ABG
Table 1-2
HP Compaq Business Notebook nx5000 Models
(Continued)

1–6 Maintenance and Service Guide
Product Description
All HP Compaq Business Notebook nx5000 models feature:
■TouchPad pointing device
■Video memory
■8- or 6-cell lithium ion (Li-Ion) battery pack
■1- or 3-year warranty on parts and labor, varying by model
Cnx5000 U C 130 X5 40 W Cb 51 H
Australia PB707PA ABG
Cnx5000 U C 130 X5 40 W CN 51 P
Brazil PA498A AC4
Cnx5000 U P 140 X4 30 C Cb 12 LS
Thailand PC529PC AKL
Cnx5000 U P 140 X4 30 C Cb 25 H
Asia Pacific DY819PA UUF Taiwan DY827PA AB0
Cnx5000 U P 140 X4 30 C Cb 25 P
Asia Pacific
Hong Kong
DX905P UUF
DV616P AB5
Taiwan DY830PA AB0
Cnx5000 U P 140 X4 30 D Cb 25 F
United States PE776AA ABA
Cnx5000 U P 140 X4 30 D Cb 25 H
Asia Pacific DY822PA UUF Taiwan DY828PA AB0
Cnx5000 U P 140 X4 30 D Cb 25 P
Asia Pacific
French Canada
Latin America
DX373P UUF
DW804AA ABC
DW804AA ABM
Ta i w an
United States
DW804AA AB0
DW804AA ABA
Cnx5000 U P 140 X4 30 W Cb 25 PS
Thailand PA094PC AKL
Table 1-2
HP Compaq Business Notebook nx5000 Models
(Continued)

Product Description
Maintenance and Service Guide 1–7
All HP Compaq Business Notebook nx5000 models feature:
■TouchPad pointing device
■Video memory
■8- or 6-cell lithium ion (Li-Ion) battery pack
■1- or 3-year warranty on parts and labor, varying by model
Cnx5000 U P 140 X4 40 C Cb 25 P
Thailand PA621PA AKL
Cnx5000 U P 140 X4 40 D Cb 25 H
Taiwan DY833PA AB0
Cnx5000 U P 140 X4 40 D Cb 25 P
People’s Republic of
China
DV836P AB2 Taiwan DY872PA AB0
and
DY837PA AB0
Cnx5000 U P 140 X4 40 W Cb 25 H
Taiwan DY835PA AB0
Cnx5000 U P 140 X4 40 W Cb 25 LS
Thailand PC530PC AKL
Cnx5000 U P 140 X4 40 W Cb 25 P
Asia Pacific
Hong Kong
PA244PA UUF
DV617P AB5
People’s Republic
of China
Ta i w an
DV837P AB2
DY839PA AB0
Cnx5000 U P 140 X4 60 W Cb 51 P
Thailand PB703PA AKL
and
PB702PA AKL
Cnx5000 U P 140 X5 30 C Cb 25 H
Asia Pacific DY820PA UUF
Table 1-2
HP Compaq Business Notebook nx5000 Models
(Continued)

1–8 Maintenance and Service Guide
Product Description
All HP Compaq Business Notebook nx5000 models feature:
■TouchPad pointing device
■Video memory
■8- or 6-cell lithium ion (Li-Ion) battery pack
■1- or 3-year warranty on parts and labor, varying by model
Cnx5000 U P 140 X5 30 C Cb 25 P
Asia Pacific
Brazil
Latin America
DZ512PA UUF
PB451A AC4
PA501A ABM
Ta i w an
United States
DY831PA AB0
PA501A ABA
Cnx5000 U P 140 X5 30 C CN 25 2
Japan DV834P ABJ
Cnx5000 U P 140 X5 30 C CN 25 P
Japan DV625P ABJ
Cnx5000 U P 140 X5 30 D Cb 25 H
Asia Pacific DY821PA UUF Taiwan DY829PA AB0
Cnx5000 U P 140 X5 30 D Cb 25 P
Asia Pacific
Latin America
DZ513PA UUF
PA500A ABM
Ta i w an
United States
DY832PA AB0
PA500A ABA
Table 1-2
HP Compaq Business Notebook nx5000 Models
(Continued)

Product Description
Maintenance and Service Guide 1–9
All HP Compaq Business Notebook nx5000 models feature:
■TouchPad pointing device
■Video memory
■8- or 6-cell lithium ion (Li-Ion) battery pack
■1- or 3-year warranty on parts and labor, varying by model
Cnx5000 U P 140 X5 30 W Cb 25 H
Belgium
Czech Republic
Denmark
Europe International
France
Greece/Polish/
English
Germany
Hungary
Iceland
Israel
Italy
DU302A UUG
DU302A AKB
DU302A ABY
DU302A ABB
DU302A ABF
DU302A B1A
DU302A ABD
DU302A AKC
DU302A A2M
DU302A ABT
DU302A ABZ
The Netherlands
Norway
Poland
Portugal
Russia
Saudi Arabia
Slovenia
Spain
Sweden/Finland
Switzerland
Tu r ke y
United Kingdom
DU302A ABH
DU302A ABN
DU302A AKD
DU302A AB9
DU302A ACB
DU302A ABV
DU302A AKN
DU302A ABE
DU302A AK8
DU302A UUZ
DU302A AB8
DU302A ABU
Cnx5000 U P 140 X5 30 W Cb 25 P
Belgium
Czech Republic
Denmark
Europe International
France
Greece/Polish/
English
Germany
Hungary
Iceland
Israel
Italy
DU303A UUG
DU303A AKB
DU303A ABY
DU303A ABB
DU303A ABF
DU303A B1A
DU303A ABD
DU303A AKC
DU303A A2M
DU303A ABT
DU303A ABZ
The Netherlands
Norway
Poland
Portugal
Russia
Saudi Arabia
Slovenia
Spain
Sweden/Finland
Switzerland
Tu r ke y
United Kingdom
DU303A ABH
DU303A ABN
DU303A AKD
DU303A AB9
DU303A ACB
DU303A ABV
DU303A AKN
DU303A ABE
DU303A AK8
DU303A UUZ
DU303A AB8
DU303A ABU
Table 1-2
HP Compaq Business Notebook nx5000 Models
(Continued)

1–10 Maintenance and Service Guide
Product Description
All HP Compaq Business Notebook nx5000 models feature:
■TouchPad pointing device
■Video memory
■8- or 6-cell lithium ion (Li-Ion) battery pack
■1- or 3-year warranty on parts and labor, varying by model
Cnx5000 U P 140 X5 30 W Cb 51 P
Latin America PA497A ABM
and
PA499A ABM
United States PA497A ABA
and
PA499A ABA
Cnx5000 U P 140 X5 30 W Cg 25 P
Latin America PD366L ABM United States PD366L ABA
Cnx5000 U P 140 X5 40 C CN 25 P
Japan DV833P ABJ
Cnx5000 U P 140 X5 40 D Cb 25 H
Korea DZ845PA AB1 Taiwan DY834PA AB0
Cnx5000 U P 140 X5 40 D Cb 25 P
Brazil PB452A AC4 Taiwan DY838PA AB0
Cnx5000 U P 140 X5 40 W Cb 25 H
Asia Pacific
Hong Kong
DY823PA UUF
DV618P AB5
Korea
Ta i w an
DZ846PA AB1
DY836PA AB0
Cnx5000 U P 140 X5 40 W Cb 25 P
Asia Pacific
Australia/New
Zealand
Hong Kong
DX903P UUF
DV614P ABG
PA223PA AB5
Japan
Korea
Ta i w an
DX366AA ABJ
PA217PA AB1
DY840PA AB0
Cnx5000 U P 140 X5 40 W Cb 25 PS
Australia PD642PC ABG
Table 1-2
HP Compaq Business Notebook nx5000 Models
(Continued)

Product Description
Maintenance and Service Guide 1–11
All HP Compaq Business Notebook nx5000 models feature:
■TouchPad pointing device
■Video memory
■8- or 6-cell lithium ion (Li-Ion) battery pack
■1- or 3-year warranty on parts and labor, varying by model
Cnx5000 U P 140 X5 40 W Cb 51 P
Asia Pacific
Belgium
French Canada
DW805AA UUF
DW806AA UUG
DW806AA ABC
Latin America
United States
PA496A ABM
and
DW80AA ABM
PA496A ABA
and
DW806AA ABA
Cnx5000 U P 140 X5 40 W Cb 51 PaS
United States PE688UC ABA
Cnx5000 U P 140 X5 40 W Cg 51 P
Latin America Pd364L ABM United States PD364L ABA
Cnx5000 U P 140 X5 40 W Ci 25 P
Asia Pacific
Europe International
France
PC979PA UUF
DW807AA ABB
DW807AA ABF
Germany
Italy
United Kingdom
DW807AA ABD
DW807AA ABZ
DW807AA ABU
Cnx5000 U P 140 X5 40 W Mg 25 PaS
United States PD931US ABA
Cnx5000 U P 140 Y5 30 D Ci 51 P
Italy DU411A ABZ
Cnx5000 U P 140 Y5 30 W CN 25 P
Japan DV835P ABJ
Cnx5000 U P 140 Y5 40 W Cb 51 H
Table 1-2
HP Compaq Business Notebook nx5000 Models
(Continued)

1–12 Maintenance and Service Guide
Product Description
All HP Compaq Business Notebook nx5000 models feature:
■TouchPad pointing device
■Video memory
■8- or 6-cell lithium ion (Li-Ion) battery pack
■1- or 3-year warranty on parts and labor, varying by model
Korea PB744Pa AB1
Cnx5000 U P 150 S5 60 Y Ci 51 P
Australia/New
Zealand
DX384P ABG
Cnx5000 U P 150 S5 60 Y Ci 51 PS
Australia PD641PC ABG
Cnx5000 U P 150 X4 30 C Cg 25 P
Hong Kong PB721PA AB5
Cnx5000 U P 150 X4 30 C CN 25 P
Japan PD677PA ABJ
Cnx5000 U P 150 X4 30 D Cg 25 P
Asia Pacific PE761Pa UUF
Cnx5000 U P 150 X4 30 D CN 51 H
Taiwan PB696PA AB0
Cnx5000 U P 150 X4 40 D Cb 25 H
People’s Republic of
China
PD664PA AB2
Cnx5000 U P 150 X4 40 D Cb 25 P
People’s Republic of
China
DV838P AB2
Table 1-2
HP Compaq Business Notebook nx5000 Models
(Continued)

Product Description
Maintenance and Service Guide 1–13
All HP Compaq Business Notebook nx5000 models feature:
■TouchPad pointing device
■Video memory
■8- or 6-cell lithium ion (Li-Ion) battery pack
■1- or 3-year warranty on parts and labor, varying by model
Cnx5000 U P 150 X4 40 D CN 25 P
People’s Republic of
China
PD667Pa AB2
Cnx5000 U P 150 X4 40 W Cb 25 H
People’s Republic of
China
PD665PA AB2
Cnx5000 U P 150 X4 40 W Cb 25 P
People’s Republic of
China
PC986PA AB2
Cnx5000 U P 150 X4 40 W Cg 25 P
Thailand PE759PA AKL
Cnx5000 U P 150 X4 40 W CN 25 H
People’s Republic of
China
PD668Pa AB2
Cnx5000 U P 150 X5 30 C Cb 25 P
Brazil PD362L AC4
Cnx5000 U P 150 X5 30 C CN 25 P
Japan PD678PA ABJ
Table 1-2
HP Compaq Business Notebook nx5000 Models
(Continued)

1–14 Maintenance and Service Guide
Product Description
All HP Compaq Business Notebook nx5000 models feature:
■TouchPad pointing device
■Video memory
■8- or 6-cell lithium ion (Li-Ion) battery pack
■1- or 3-year warranty on parts and labor, varying by model
Cnx5000 U P 150 X5 30 W Cg 25 H
Belgium
Denmark
Europe International
France
Germany
Greece/Polish/
English
Hungary
Iceland
Italian
Netherlands
DU396A UUG
DU396A ABY
DU396A ABB
DU396A ABF
DU396A ABD
DU396A B1A
DU396A AKC
DU396A A2M
DU396A ABZ
DU396A ABH
Norway
Poland
Portugal
Russian
Saudi Arabia
Slovenia
South Africa
Spain
Sweden/Finland
Switzerland
United Kingdom
DU396A ABN
DU396A AKD
DU396A AB9
DU396A ACB
DU396A ABV
DU396A AKN
DU396A ACQ
DU396A ABE
DU396A AK8
DU396A UUZ
DU396A ABU
Cnx5000 U P 150 X5 30 W Cg 25 P
Belgium
Denmark
Europe International
France
Germany
Greece/Polish/
English
Hungary
Iceland
Italy
Latin America
Netherlands
DU397A UUG
DU397A ABY
DU397A ABB
DU397A ABF
DU397A ABD
DU397A B1A
DU397A AKC
DU397A A2M
DU397A ABZ
PD367L ABM
DU397A ABH
Norway
Poland
Portugal
Russian
Saudi Arabia
Slovenia
South Africa
Spain
Sweden/Finland
Switzerland
United Kingdom
United States
DU397A ABN
DU397A AKD
DU397A AB9
DU397A ACB
DU397A ABV
DU397A AKN
DU397A ACQ
DU397A ABE
DU397A AK8
DU397A UUZ
DU397A ABU
PD367L ABA
Table 1-2
HP Compaq Business Notebook nx5000 Models
(Continued)

Product Description
Maintenance and Service Guide 1–15
All HP Compaq Business Notebook nx5000 models feature:
■TouchPad pointing device
■Video memory
■8- or 6-cell lithium ion (Li-Ion) battery pack
■1- or 3-year warranty on parts and labor, varying by model
Cnx5000 U P 150 X5 40 C Cb 25 H
Korea PA218PA AB1
Cnx5000 U P 150 X5 40 C CN 25 P
Japan PD679PA ABJ
Cnx5000 U P 150 X5 40 D Cb 25 H
Korea PA219PA AB1
Cnx5000 U P 150 X5 40 D Cb 25 P
Brazil PD361L AC4
Cnx5000 U P 150 x5 40 D Cg 25 P
United States DV111U ABA
Cnx5000 U P 150 X5 40 N Cg 25 P
United States DV138U ABA
Cnx5000 U P 150 X5 40 W Cb 25 H
Korea PA220PA AB1
Cnx5000 U P 150 x5 40 W Cb 25 P
Asia Pacific DX904P UUF
and
DX374P UUF
Korea
Thailand
PA221PA AB1
DY870PA AKL
Table 1-2
HP Compaq Business Notebook nx5000 Models
(Continued)
