HP NR3610 User instructions

1. Wide-area Network Antennas 7. Power/Wireless Modem Indicators
2. Display Latches 8. Speakers
3. GPS and/or Bluetooth antenna 9. Touchpad
4. Power Button 10. Activity Indicators
5. Scrolling Button 11. Activity Indicators
6. Touchpad Buttons
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Overview
DA - 12077 Canada — Version 8 — June 19, 2006 Page 1

1. Cooling Fan 6. PS2 Port
2. Power Jack 7. RJ-11 Modem Jack
3. 15-Pin VGA Port 8. RJ-45 Network Jack
4. 68-Pin Multi-IO Port 9. IEEE 1394 Port
5. 9-Pin Serial Port 10. USB 2.0 Port
NOTE:
NOTE:NOTE:
NOTE: This document covers features which could potentially be found in this notebook platform, please see sku specific
information on what specific features are found in the standard models that HP offers.
At A Glance
At A GlanceAt A Glance
At A Glance
Genuine Windows XP Professional Edition.
Die-cast magnesium for all structural components.
12.1" TFT XGA Outdoor transmissive display with Touchscreen.
Shock mounted standard 40GB Ruggedized removable hard disk drive.
Mobile Intel® Pentium® -M Processor 745 (1.8 GHz clock speed, 2MB L2 cache, and 400MHz FSB.)
Up to 3 RF modems can be integrated at one time. Combinations of GPRS, Wireless WAN (CDMA, EDGE), Wireless LAN, or
Bluetooth.
512 up to 2048MB PC2700DDR SDRAM supported in two SODIMM slots.
GPS optional - mounted in the top edge of the display for optimum performance.
Swappable media bay accepts internal 24X CD-ROM, 8X DVD-ROM, DVD/CDRW combo, second battery or 3.5" floppy disk
drive.
ATI MOBILITY™ RADEON™ 9000 with on chip 64MB DDR SDRAM and 128 bit memory bandwidth.
56K Kbps high speed fax/modem MDC module and 10/100M bit Ethernet LAN standard.
Complete set of system ports.
Multi I/O port allows for system expansion with docking solutions (parallel, serial, USB, 10/100Mb LAN.)
Weighs 8.2 lb (3.7 kg) (Base Configuration.)
Protected by a three-year warranty - certain restrictions and exclusions apply.
What's Special
What's SpecialWhat's Special
What's Special
Meets the rigid military standard (MIL STD 810F) and complies with Ingress Protection rating of IP54 for dust and rain.
Common Radio Module Architecture (CRMA™) with fully integrated, rugged, user replaceable radio modules. Supports
PCMCIA and OEM radio modules.
Fully waterproof NiteVue® glow-in-the-dark keyboard, constructed from phosphorescent plastic.
Vehicle docking, power, and antenna solutions.
Two integrated pointing devices include passive Touchscreen and Touchpad.
Backlit keyboard with adjustable brightness (optional.)
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Overview
DA - 12077 Canada — Version 8 — June 19, 2006 Page 2

Processors
ProcessorsProcessors
Processors Mobile Intel Pentium-M Processor 745 (1.8 GHz clock speed, 2MB L2 cache, and 400MHz FSB)
NOTE:
NOTE:NOTE:
NOTE: Intel's numbering is not a measurement of higher performance.
Operating System
Operating SystemOperating System
Operating System Pre-installed Genuine Windows XP Professional Edition
Display
DisplayDisplay
Display Internal 12.1" TFT XGA Outdoor transmissive display with Touchscreen. XGA LCD
supports XGA resolution with a 768 vertical by 1024 horizontal pixel array, a
pixel pitch of 0.24mm and presents a palette of more than 262,144 colours.
Memory
MemoryMemory
Memory 512 to 2048MB PC2700 (333MHz) DDR SDRAM Standard
Maximum 2048MB DDR (333MHz) SDRAM (with two slots of 1024MB)
NOTE:
NOTE:NOTE:
NOTE: Due to the non-industry standard nature of some third-party memory modules, we strongly
recommend using only HP branded memory modules to ensure compatibility.
Graphics
GraphicsGraphics
Graphics ATI MOBILITY™ RADEON™ 9000 with 64MB dedicated on chip memory
AGP 4X platform
Support for Direct X 8.1 and Open GL
Integrated MPEG-2 decode including iDCT, motion compensation, and hardware sub-picture
decoder
ATI VIDEO IMMERSION™ II deinterlacing and frame rate conversion algorithms
SMOOTHVISION™ Anti Aliasing for sharper more detailed video images
ATI FULLSTREAM™ removes blocky artifacts from streaming video
ATI POWERPLAY™ III enables advanced notebook power management supports external VGA
display: 640x480, 800x600, 1024x768, 1152x864, 1280x800, 1280x1024, 1680x1050,
1600x1200, 1792x1344, 1800x1440, 1920x1200, 1920x1440, 2048x1536 resolutions up to
160-Hz refresh rate, dependent upon monitor capability, resolution and colour depth settings.
Audio
AudioAudio
Audio 18-bit full duplex stereo ADC, DACs
Communications
CommunicationsCommunications
Communications Standard 56K Kbps high-speed fax/modem MDC module with 10/100Mbit Ethernet LAN
NOTE:
NOTE:NOTE:
NOTE: Designed only to allow faster downloads from 56K high speed modem compliant sources.
Maximum achievable download transmission rates currently do not reach 56 KB/s, and will vary with line
conditions.
NOTE:
NOTE:NOTE:
NOTE: Communication availability is subject to country regulatory approval.
Keyboard
KeyboardKeyboard
Keyboard Fully waterproof NiteVue® glow-in-the-dark keyboard, constructed from phosphorescent polymer.
Backlit keyboard option. Available for US.
Pointing Device
Pointing DevicePointing Device
Pointing Device Ships standard with two integrated pointing devices. The first is a resistive touch screen that can be
operated with the included stylus which resides in the left side of the display or other non-abrasive
devices such as a clean finger. The second integrated pointing device is a touchpad with standard 3
button mouse controls.
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Standard Features
DA - 12077 Canada — Version 8 — June 19, 2006 Page 3

Storage
StorageStorage
Storage Optional Diskette Drives
Optional Diskette DrivesOptional Diskette Drives
Optional Diskette Drives 3.5" floppy disk drive
Hard Drive
Hard DriveHard Drive
Hard Drive Shock mounted 2.5" 40GB (standard) ruggedized removable hard disk drive.
Optional shock mounted 2.5" 80GB ruggedized removable hard disk drive
available with optional heater for cold environments.
NOTE:
NOTE:NOTE:
NOTE: The Software recovery partition utilizes approximately 1.4GB hard
drive space.
NOTE:
NOTE:NOTE:
NOTE: The Software recovery partition utilizes approximately 1.4GB hard drive space.
Optional Optical Drives
Optional Optical DrivesOptional Optical Drives
Optional Optical Drives 24x24x24x + 8x DVD/CDRW combo Drive
Supports 24x Write, 24x Rewrite, 24x Read, and 8x DVD-ROM Read Speed
8X DVD-ROM Drive
Multimedia
MultimediaMultimedia
Multimedia External volume controls via keystroke combination
Internal microphone and (2) speakers. PCI Audio with AC-97 compliance.
Optional optical drives:
24x24x24x + 8x DVD/CDRW combo Drive
24X CD-ROM Drive
8X DVD-ROM Drive
ATI MOBILITY RADEON 9000 with 64MB dedicated on chip memory
Integrated MPEG-2 decode including iDCT, motion compensation, and hardware sub-picture
decoder
Includes ATI's VIDEO IMMERSION™ II deinterlacing and SMOOTHVISION™ Anti Aliasing for
sharper more detailed video images
Includes ATI's FULLSTREAM™ for sharper image quality during streaming video playback
Interfaces
InterfacesInterfaces
Interfaces PC Card Slot PC card slot for (1) Type I, II, or III card with 32-bit card bus
Parallel Port Optional adapter for parallel port connector
Serial Port 9-pin high speed serial port
External Monitor Standard VGA 15-pin high density D-sub
Headphone/Line-out 2.5mm receptacle
Microphone in 2.5mm receptacle
AC Power 2.5mm centre pin
NIC RJ-45
Modem RJ-11
USB Port 1 external series A connector
LED Status Indicators 11
IEEE 1394 Firewire 400 1
Security
SecuritySecurity
Security Setup Password
Power-On Password
Removable Hard Disk Drive
Kensington Lock
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Standard Features
DA - 12077 Canada — Version 8 — June 19, 2006 Page 4

Software
SoftwareSoftware
Software Pre-installed Software
Pre-installed SoftwarePre-installed Software
Pre-installed Software Preinstalled with Windows Logo Compliance
HP Online Help
Radio Drivers and Software (where applicable)
Synaptics Touchpad Driver
Semtech Touchscreen Driver
Hard Disk Recovery Utility
Device drivers also available online
System Recovery
System RecoverySystem Recovery
System Recovery Restore to original factory image from Hard Disk Drive Recovery partition or from optional Recovery
CDs.
Power Supply
Power SupplyPower Supply
Power Supply External AC 90 Watt Adapter (only 0.83 lb/0.38 kg, 6-foot/1.8 metre). Power cord included based on
country of destination. Total length including External AC adapter is 12 feet/3.66 metres.
Battery
BatteryBattery
Battery Standard 9-cell 6600mAh Lithium Ion battery pack. Short circuit, overcharge, over-discharge protected
and integrated Gas Gauge IC with SMBus interface. Utilizes SMBus to communicate smart battery
parameters with the system. Gas gauge can be calibrated through system via CMOS set-up screen
application.
NOTE:
NOTE:NOTE:
NOTE: Actual results may vary with product model, configuration, and individual usage. Runtime results
of 5:04 hours were achieved running the BatteryMark™ Test version 4.0 LifeTest on a nr3610 with a
1.8GHz Mobile Intel® Pentium® M, 12.1-inch XGA panel, 2 x 512-MB DDR SDRAM, 80-GB-HDD,
standard 9-cell Lithium-Ion battery. System parameters were set according to Ziff Davis
recommendations: panel brightness 50%, hard drive, standby and video idle time set to never, laptop
power management scheme.
NOTE:
NOTE:NOTE:
NOTE: This test was performed without independent verification by eTesting Labs Inc. eTesting Labs Inc.
makes no representations or warranties as to the result of the test. BatteryMark is a trademark of Ziff
Davis Publishing Holdings Inc., and affiliate of eTesting Labs Inc., in the U.S. and other countries.
Battery Life (hrs:min) up to 5:04 on standard main pack. Up to 7:40 hours can be achieved using the
second media bay battery.
Battery Re-Charge Time
Battery Re-Charge TimeBattery Re-Charge Time
Battery Re-Charge Time System in OFF mode or Standby 3:50 to 100% from 0%
System ON (depending on system power
consumption)
4:05 to 100% from 0%
Power Conservation
Power ConservationPower Conservation
Power Conservation Enhanced Intel SpeedStep technology (Real-time dynamic switching of voltage and frequency between
maximum performance and battery-optimized operation, based on CPU demand, for longer battery life)
Hibernation
Instant-on via Standby
Energy saving setting available via Microsoft Windows Control Panel 'Power Options'
ACPI compliant
Performance
PerformancePerformance
Performance Ziff Davis 3D Winbench 2000 = 208
FutureMark 3DMark = 1069
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Standard Features
DA - 12077 Canada — Version 8 — June 19, 2006 Page 5

Media Bay
Media BayMedia Bay
Media Bay Media Bay devices may be swapped with the system powered on (hot) under Microsoft Windows XP
Professional. Media Bay devices can be swapped with system power off under any supported operating
system.
Vehicle & Office
Vehicle & OfficeVehicle & Office
Vehicle & Office
Docking/System
Docking/SystemDocking/System
Docking/System
Expansion
ExpansionExpansion
Expansion
Optional 70W Vehicle power supply available.
Optional Vehicle dock: Semi-permanently mounted dock in vehicles such as service vans, emergency
and utility vehicles with mechanical key lock for security. Vehicle dock is wired into the automobile's
electrical system to provide adequate power to run and charge the unit simultaneously. Allows for
expanded I/O space with (2) externally available USB interconnects. Also contains an RF coaxial
connection to the laptop for external vehicle-mounted antennas.
Service and Support
Service and SupportService and Support
Service and Support 3-Year Warranty: Case Parts, Electrical Components, Connectors
1-Year Warranty: Consumables: Battery, Chargers, Carrying straps
90-Day Software Warranty: Media
Warranty Extensions: Return Service, Return Service Plus and Statement of Work
NOTE:
NOTE:NOTE:
NOTE: Certain restrictions and exclusions apply.
Naming Convention
Naming ConventionNaming Convention
Naming Convention The Etymology of a Model name:
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Standard Features
DA - 12077 Canada — Version 8 — June 19, 2006 Page 6

Configuration: #1
Configuration: #1Configuration: #1
Configuration: #1
683AW#ABA
Processor
ProcessorProcessor
Processor 1.8 GHz Intel Pentium M processor
Operating System
Operating SystemOperating System
Operating System Genuine Windows XP Professional
Display
DisplayDisplay
Display 12.1" Transmissive XGA Outdoor display with Touchscreen
Media Bay
Media BayMedia Bay
Media Bay Swappable media bay: Empty
Second battery, FDD, CD, DVD, Combo (See media bay options)
Cache Memory
Cache MemoryCache Memory
Cache Memory 2048 K L2 Cache
Memory
MemoryMemory
Memory Standard
StandardStandard
Standard 512-MB SDRAM
Maximum
MaximumMaximum
Maximum 2048-MB SDRAM
Hard Drive
Hard DriveHard Drive
Hard Drive Shock mounted 2.5" 40GB Ruggedized removable hard disk drive
Audio
AudioAudio
Audio Internal microphone and (2) speakers. PCI Audio with AC-97 compliance
Graphics
GraphicsGraphics
Graphics ATI MOBILITY RADEON 9000 with 32 bpp colour rendering and 3D
graphics and integrated 64MB DDR SDRAM
Communications WLAN
Communications WLANCommunications WLAN
Communications WLAN None
Communications WWAN
Communications WWANCommunications WWAN
Communications WWAN None
Input Device
Input DeviceInput Device
Input Device NiteVue glow-in-the-dark keyboard
Modem
ModemModem
Modem 56K Kbps high-speed fax/modem MDC module with 10/100M bit Ethernet
LAN
Configuration: #2
Configuration: #2Configuration: #2
Configuration: #2
684AW#ABA
Processor
ProcessorProcessor
Processor 1.8 GHz Intel Pentium M processor
Operating System
Operating SystemOperating System
Operating System Genuine Windows XP Professional
Display
DisplayDisplay
Display 12.1" Transmissive XGA Outdoor display with Touchscreen
Media Bay
Media BayMedia Bay
Media Bay Swappable media bay: Empty
Second battery, FDD, CD, DVD, Combo (See media bay options)
Cache Memory
Cache MemoryCache Memory
Cache Memory 2048 K L2 Cache
Memory
MemoryMemory
Memory Standard
StandardStandard
Standard 512-MB SDRAM
Maximum
MaximumMaximum
Maximum 2048-MB SDRAM
Hard Drive
Hard DriveHard Drive
Hard Drive Shock mounted 2.5" 80GB Ruggedized removable hard disk drive
Audio
AudioAudio
Audio Internal microphone and (2) speakers. PCI Audio with AC-97 compliance
Graphics
GraphicsGraphics
Graphics ATI MOBILITY RADEON 9000 with 32 bpp colour rendering and 3D
graphics and integrated 64MB DDR SDRAM
Communications WLAN
Communications WLANCommunications WLAN
Communications WLAN Wireless LAN 802.11 b/g (See wireless options)
Communications WWAN
Communications WWANCommunications WWAN
Communications WWAN None
Input Device
Input DeviceInput Device
Input Device NiteVue glow-in-the-dark keyboard
Modem
ModemModem
Modem 56K Kbps high-speed fax/modem MDC module with 10/100M bit Ethernet
LAN
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Standard Features
DA - 12077 Canada — Version 8 — June 19, 2006 Page 7

Configuration: #3
Configuration: #3Configuration: #3
Configuration: #3
685AW#ABA
Processor
ProcessorProcessor
Processor 1.8 GHz Intel Pentium M processor
Operating System
Operating SystemOperating System
Operating System Genuine Windows XP Professional
Display
DisplayDisplay
Display 12.1" Transmissive XGA Outdoor display with Touchscreen
Media Bay
Media BayMedia Bay
Media Bay Swappable media bay: Empty
Second battery, FDD, CD, DVD, Combo (See media bay options)
Cache Memory
Cache MemoryCache Memory
Cache Memory 2048 K L2 Cache
Memory
MemoryMemory
Memory Standard
StandardStandard
Standard 512-MB SDRAM
Maximum
MaximumMaximum
Maximum 2048-MB SDRAM
Hard Drive
Hard DriveHard Drive
Hard Drive Shock mounted 2.5" 40GB Ruggedized removable hard disk drive
Audio
AudioAudio
Audio Internal microphone and (2) speakers. PCI Audio with AC-97 compliance
Graphics
GraphicsGraphics
Graphics ATI MOBILITY RADEON9000 with 32 bpp colour rendering and 3D
graphics and integrated 64MB DDR SDRAM
Communications WLAN
Communications WLANCommunications WLAN
Communications WLAN Wireless LAN 802.11 b/g (See wireless options)
Communications WWAN
Communications WWANCommunications WWAN
Communications WWAN None
Input Device
Input DeviceInput Device
Input Device Backlit keyboard with adjustable brightness
Modem
ModemModem
Modem 56K Kbps high-speed fax/modem MDC module with 10/100M bit Ethernet
LAN
Configuration: #4
Configuration: #4Configuration: #4
Configuration: #4
686AW#ABA
Processor
ProcessorProcessor
Processor 1.8 GHz Intel Pentium M processor
Operating System
Operating SystemOperating System
Operating System Genuine Windows XP Professional
Display
DisplayDisplay
Display 12.1" Transmissive XGA Outdoor display with Touchscreen
Media Bay
Media BayMedia Bay
Media Bay Swappable media bay: Empty
Second battery, FDD, CD, DVD, Combo (See media bay options)
Cache Memory
Cache MemoryCache Memory
Cache Memory 2048 K L2 Cache
Memory
MemoryMemory
Memory Standard
StandardStandard
Standard 512-MB SDRAM
Maximum
MaximumMaximum
Maximum 2048-MB SDRAM
Hard Drive
Hard DriveHard Drive
Hard Drive Shock mounted 2.5" 80GB Ruggedized removable hard disk drive
Audio
AudioAudio
Audio Internal microphone and (2) speakers. PCI Audio with AC-97 compliance
Graphics
GraphicsGraphics
Graphics ATI MOBILITY RADEON 9000 with 32 bpp colour rendering and 3D
graphics and integrated 64MB DDR SDRAM
Communications WLAN
Communications WLANCommunications WLAN
Communications WLAN Wireless LAN 802.11 b/g, Bluetooth, GPS (See wireless options)
Communications WWAN
Communications WWANCommunications WWAN
Communications WWAN None
Input Device
Input DeviceInput Device
Input Device Backlit keyboard with adjustable brightness
Modem
ModemModem
Modem 56K Kbps high-speed fax/modem MDC module with 10/100M bit Ethernet
LAN
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Standard Features
DA - 12077 Canada — Version 8 — June 19, 2006 Page 8

Configuration: #7
Configuration: #7Configuration: #7
Configuration: #7
PR540AW#ABA
Processor
ProcessorProcessor
Processor 1.8 GHz Intel Pentium M processor
Operating System
Operating SystemOperating System
Operating System Genuine Windows XP Professional
Display
DisplayDisplay
Display 12.1" Transmissive XGA Outdoor display with Touchscreen
Media Bay
Media BayMedia Bay
Media Bay Swappable media bay: Empty
Second battery, FDD, CD, DVD, Combo (See media bay options)
Cache Memory
Cache MemoryCache Memory
Cache Memory 2048 K L2 Cache
Memory
MemoryMemory
Memory Standard
StandardStandard
Standard 512-MB SDRAM
Maximum
MaximumMaximum
Maximum 2048-MB SDRAM
Hard Drive
Hard DriveHard Drive
Hard Drive Shock mounted 2.5" 80GB Ruggedized removable hard disk drive
Audio
AudioAudio
Audio Internal microphone and (2) speakers. PCI Audio with AC-97 compliance
Graphics
GraphicsGraphics
Graphics ATI MOBILITY RADEON 9000 with 32 bpp colour rendering and 3D
graphics and integrated 64MB DDR SDRAM
Communications WLAN
Communications WLANCommunications WLAN
Communications WLAN Wireless LAN 802.11 b/g (See wireless options)
Communications WPAN
Communications WPANCommunications WPAN
Communications WPAN
(Bluetooth)
(Bluetooth)(Bluetooth)
(Bluetooth)
Yes
Communications WWAN
Communications WWANCommunications WWAN
Communications WWAN Aircard Ready
Global Positioning System
Global Positioning SystemGlobal Positioning System
Global Positioning System
(GPS)
(GPS)(GPS)
(GPS)
YES
Input Device
Input DeviceInput Device
Input Device Backlit keyboard with adjustable brightness
Modem
ModemModem
Modem 56K Kbps high-speed fax/modem MDC module with 10/100M bit Ethernet
LAN
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Standard Features
DA - 12077 Canada — Version 8 — June 19, 2006 Page 9

Memory
MemoryMemory
Memory Combinations of the following upgrades may be used up to a maximum of 2048 in
two 1024MB SODIMM modules.
RAM 512MB 266DDR 1DM Memory Upgrade PR784AA
RAM 1024MB 266DDR 1DM Memory Upgrade PR785AA
NOTE:
NOTE:NOTE:
NOTE: Due to the non-industry standard nature of some third-party memory modules,
we strongly recommend using only HP branded memory modules to ensure
compatibility.
Media Bay Drives
Media Bay DrivesMedia Bay Drives
Media Bay Drives 3.5" floppy diskette drive DW382A
8X DVD-ROM Drive DW380A
24X CD-ROM Drive DW379A
24x24x24x + 8x DVD/CD-RW Combo Drive. Supports 24x Write, 24x Rewrite, 24x
Read, and 8x DVD-ROM Read Speed
DW381A
Secondary 6-cell media bay battery pack (see Power section below) PA054A
Power
PowerPower
Power Platform battery, 9-cell 6600 mAh Lithium-Ion battery. Additional primary batteries
provide the ability to double your work time on the Rugged PC
PR783AA
Common Power Solutions
Common Power SolutionsCommon Power Solutions
Common Power Solutions Optional Vehicle Dock/Cradle DW390A
Cases
CasesCases
Cases Cases Cargo Pouch DW389A
HP Care Pack Services
HP Care Pack ServicesHP Care Pack Services
HP Care Pack Services HP CPe 1 Yr Emerald Service FP-NREEC-12
HP CPe 3 Yr Emerald Service FP-NREEC-36
HP CPe 1 Yr Ruby Service FP-NREEC-12
HP CPe 3 Yr Ruby Service FP-NREEC-36
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Options
DA - 12077 Canada — Version 8 — June 19, 2006 Page 10

HP nr3610 Rugged Notebook
HP nr3610 Rugged NotebookHP nr3610 Rugged Notebook
HP nr3610 Rugged Notebook
Standard Memory
Standard MemoryStandard Memory
Standard Memory
0-MB of memory on system board
2 SODIMM slots total
Default configuration:
1 - 512-MB SODIMM installed in Slot 1
1 - Additional open Memory Slot
Memory
MemoryMemory
Memory Slot 1
Slot 1Slot 1
Slot 1 Slot 2
Slot 2Slot 2
Slot 2
512-MB
512-MB512-MB
512-MB Empty
EmptyEmpty
Empty
Standard Memory with Optional Memory Upgrades
Standard Memory with Optional Memory UpgradesStandard Memory with Optional Memory Upgrades
Standard Memory with Optional Memory Upgrades
Support for up to 2048MB of PC2700 (333MHz) DDR SDRAM is available with the installation of optional memory module
upgrades.
Up to
Up toUp to
Up to Slot 1
Slot 1Slot 1
Slot 1 Slot 2
Slot 2Slot 2
Slot 2
512MB
512MB512MB
512MB 512MB
512MB512MB
512MB Empty
EmptyEmpty
Empty
1024MB
1024MB1024MB
1024MB 512MB
512MB512MB
512MB 512MB
512MB512MB
512MB
1024MB
1024MB1024MB
1024MB 1024MB
1024MB1024MB
1024MB Empty
EmptyEmpty
Empty
1536MB
1536MB1536MB
1536MB 1024MB
1024MB1024MB
1024MB 512MB
512MB512MB
512MB
2048MB
2048MB2048MB
2048MB 1024MB
1024MB1024MB
1024MB 1024MB
1024MB1024MB
1024MB
NOTE:
NOTE:NOTE:
NOTE: This chart does not represent all possible memory configurations. Due to the non-industry standard nature of some third-
party memory modules, we strongly recommend using only HP branded memory modules to ensure compatibility.
Following are memory options available from HP:
512-MB PC2700 (333-MHz) DDR SDRAM Memory module Upgrade PR784AA
1024-MB PC2700 (3333MHz) DDR SDRAM Memory module Upgrade PR785AA
NOTE:
NOTE:NOTE:
NOTE: Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only HP
branded memory modules to ensure compatibility.
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Memory
DA - 12077 Canada — Version 8 — June 19, 2006 Page 11

Drive Support
Drive SupportDrive Support
Drive Support
System Drive Support
System Drive SupportSystem Drive Support
System Drive Support
Removable Media
Removable MediaRemovable Media
Removable Media Quantity
QuantityQuantity
Quantity
Supported
SupportedSupported
Supported
Drive Bay Supported
Drive Bay SupportedDrive Bay Supported
Drive Bay Supported
DVD/CD-RW Combo Drive Up to 1 Media Bay
DVD-ROM Drive Up to 1 Media Bay
CD-ROM Drive Up to 1 Media Bay
1.44-MB Diskette Drive (optional) Up to 1 Media Bay
NOTE:
NOTE:NOTE:
NOTE: Only one media device may be plugged in at one time.
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Storage
DA - 12077 Canada — Version 8 — June 19, 2006 Page 12

System Unit
System UnitSystem Unit
System Unit Dimensions
DimensionsDimensions
Dimensions (LxWxD) 12.1-inch panel display 12 x 9.8 x 2.36 in (30.5 x 24.9 x 6 cm)
Weight
WeightWeight
Weight Minimum 8.2 lb (3.7 kg)
Stand-Alone Power
Stand-Alone PowerStand-Alone Power
Stand-Alone Power
Requirements
RequirementsRequirements
Requirements
Nominal Operating
Voltage
19VDC
Average Operating Power 22W while running aggressive test software not
charging battery
Peak Operating Power 39W not charging battery
Temperature
TemperatureTemperature
Temperature Operating -10° to 140° F (-23° to 60° C)
Non-operating (Storage) -67° to 167° F (-55° to 75° C)
Relative Humidity
Relative HumidityRelative Humidity
Relative Humidity Operating, disk accessing MIL-STD-810F, Method 507.4: Humidity cycles
between 30° C @ 85%RH non-condensing and
60° C @ 95%RH non-condensing for ten 24
hour cycles
Non-operating 5% to 90% relative humidity, 140° F (75° C)
maximum wet bulb temperature
Shock
ShockShock
Shock (vehicle) Operating SAE J1455, pothole shock; 22G top and bottom,
15G front to back, 7G side to side, 20 msec
durations.
Shock
ShockShock
Shock (drop) Non-operating Drop Testing to MIL-STD-810F Method 516.5,
Procedure IV Modified -twenty-six 3 Foot drops
to 2-inch plywood over concrete. 2 units to pass.
Vibration
VibrationVibration
Vibration Operating ASTM 4169-99 Truck Assurance Level II
Schedule E. 90 mins each axis. With disk access.
Non-operating MIL-STD-810F Method 514.5 Procedure I
Category 24 Figure 17 and Figure 18.
Maximum Altitude
Maximum AltitudeMaximum Altitude
Maximum Altitude
(unpressurized)
Operating 0 to 10,000 ft (3,048 m) 14.7 to 10.1 psia
Non-operating 0 to 30,000 ft (9,144 m) 14.7 to 4.4 psia
Industry Standard
Industry StandardIndustry Standard
Industry Standard
Certifications
CertificationsCertifications
Certifications
Bi-Nat CSA 60950-00/ UL - 60950, 3rd Edition Design Manual, Version
3.1
EN 55022:1994+A1:1995 +A2:1997, Class B
CISPR 22:1993 +A1:1995 +A2:1996, Class B
AS/NZS 3548: 1995 +A1:1997 +A2:1997, Class B
FCC Part 15, subpart B, Class B
ANSI C63.4-1992
ICES-003:1997, Class B
Modems: FCC Part 68, Industry Canada CS03, and European TBR 21
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Technical Specifications
DA - 12077 Canada — Version 8 — June 19, 2006 Page 13

12.1-inch TFT XGA
12.1-inch TFT XGA12.1-inch TFT XGA
12.1-inch TFT XGA
Outdoor Enhanced
Outdoor EnhancedOutdoor Enhanced
Outdoor Enhanced
Transmissive Colorvue®
Transmissive Colorvue®Transmissive Colorvue®
Transmissive Colorvue®
display with Touchscreen
display with Touchscreendisplay with Touchscreen
display with Touchscreen
Dimensions
DimensionsDimensions
Dimensions (H x W) 10.3 x 7.8 in (26.1 x 19.9 cm)
Diagonal Size
Diagonal SizeDiagonal Size
Diagonal Size 12.1 in (30.7 cm)
Mounting
MountingMounting
Mounting Internal
Number of Colours
Number of ColoursNumber of Colours
Number of Colours 262,144
Contrast Ratio
Contrast RatioContrast Ratio
Contrast Ratio 150:1 Minimum, 400:1 Typical
Refresh Rate
Refresh RateRefresh Rate
Refresh Rate 60 Hz
Brightness
BrightnessBrightness
Brightness 300 nit typical
Pixel Resolution
Pixel ResolutionPixel Resolution
Pixel Resolution Pitch 0.24 x 0.24 mm
Format 1024 x 768
Configuration RGB Stripe
Backlight
BacklightBacklight
Backlight CCFL
Character Display
Character DisplayCharacter Display
Character Display 80 x 25
Total Power Consumption
Total Power ConsumptionTotal Power Consumption
Total Power Consumption 4.4 W
Viewing Angle
Viewing AngleViewing Angle
Viewing Angle ±30° degrees Horizontal, +10°/-20° Vertical (typical)
External AC Adapter
External AC AdapterExternal AC Adapter
External AC Adapter Dimensions
DimensionsDimensions
Dimensions 6 ft (1.8 m) Adapter length
Total length including power cord is 12 ft (3.66 m).
Weight
WeightWeight
Weight 0.83 lb (0.38 kg)
Input Characteristics
Input CharacteristicsInput Characteristics
Input Characteristics Operating Voltage 90 to 264 VAC RMS Single Phase
Operating Current 1.5 ARMS @ 90VAC, 0.75ARMS @ 180VAC
Operating Frequency
Range
47 to 63 Hz AC
Efficiency 85% min @ 115VAC, Full load
Output Characteristics
Output CharacteristicsOutput Characteristics
Output Characteristics Output Voltage 19 VDC
Maximum load 4.74A max
Minimum load 0A
Regulation ±5%
Main Internal Lithium-Ion
Main Internal Lithium-IonMain Internal Lithium-Ion
Main Internal Lithium-Ion
Battery Pack
Battery PackBattery Pack
Battery Pack
Weight
WeightWeight
Weight 1.04 lb (0.47 kg)
Cells
CellsCells
Cells 9-cell Lithium-Ion
Energy
EnergyEnergy
Energy Voltage 11.1 V
Amp-hour capacity 6600 mAh
Watt-hour capacity 73.2 Wh
Temperature
TemperatureTemperature
Temperature Operating
Discharging -4° to 140° F (-20° to 60° C)
Charging 32° to 113° F (0° to 45° C)
Non-operating -4° to 140° F (-20° to 60° C)
Battery Re-Charge Time
Battery Re-Charge TimeBattery Re-Charge Time
Battery Re-Charge Time System in OFF mode or
Standby
4:10 (hrs:min) from 0% to 100%
System ON (depending on
system power
consumption)
4:10 (hrs:min) from 0% to 100%
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Technical Specifications
DA - 12077 Canada — Version 8 — June 19, 2006 Page 14

Lifecycle
LifecycleLifecycle
Lifecycle 80% capacity after 300 full charge/discharge cycles, or 600 half discharge
followed by a full charge cycles.
Media Bay Lithium-Ion
Media Bay Lithium-IonMedia Bay Lithium-Ion
Media Bay Lithium-Ion
Battery Pack
Battery PackBattery Pack
Battery Pack (6-cell)
(Optional)
Weight
WeightWeight
Weight 0.8 Ib (0.36 Kg)
Energy
EnergyEnergy
Energy Voltage 11.1 V
Amp-hour capacity 3200mAh
Watt-hour capacity 35.5 Wh
Temperature
TemperatureTemperature
Temperature Operating
Discharging -4° to 140° F (-20° to 60° C)
Charging 32° to 113° F (0° to 45° C)
Non-operating -4° to 140° F (-20° to 60° C)
Battery Re-Charge Time
Battery Re-Charge TimeBattery Re-Charge Time
Battery Re-Charge Time System in OFF mode or
Standby
2.5 hours
System ON (depending on
system power
consumption)
2.5 hours
Lifecycle
LifecycleLifecycle
Lifecycle 80% capacity after 300 full charge/discharge cycles, or 600 half discharge
followed by a full charge cycles.
24X/24X/24X/8X
24X/24X/24X/8X24X/24X/24X/8X
24X/24X/24X/8X
DVD/CD-RW Combo
DVD/CD-RW ComboDVD/CD-RW Combo
DVD/CD-RW Combo
Drive
DriveDrive
Drive
Media Bay Drive
Media Bay DriveMedia Bay Drive
Media Bay Drive Dimensions (H x W x D) 0.82 x 5.21 x 5.27 in (2.08 x 13.23 x 13.39 cm)
Weight 0.59 lb (269 g)
Centre Hole Diameter
Centre Hole DiameterCentre Hole Diameter
Centre Hole Diameter 1.5 cm
Disk Diameter
Disk DiameterDisk Diameter
Disk Diameter 12 cm/8 cm
Access Times
Access TimesAccess Times
Access Times
(typical reads, including
settling)
Random CD < 150 ms
Full-Stroke CD < 280 ms
Audio Output Level
Audio Output LevelAudio Output Level
Audio Output Level Line-out 0.7 Vrms
Data Buffer
Data BufferData Buffer
Data Buffer 2MB
Data Transfer Rate
Data Transfer RateData Transfer Rate
Data Transfer Rate
(typical, including settling)
CD-R (24X) 3600 KB/s (150 KB/s at 1X CD rate)
CD-RW (24X) 3600 KB/s (150 KB/s at 1X CD rate)
CD-ROM (24X) 3600 KB/s (150 KB/s at 1X CD rate)
DVD (8X) 10,800 KB/s (1352 KB/s at 1X DVD rate)
Normal PIO Mode 4
(single burst)
16.6 MB/s
Start-up Time
Start-up TimeStart-up Time
Start-up Time < 14 seconds
Stop Time
Stop TimeStop Time
Stop Time < 8 seconds
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Technical Specifications
DA - 12077 Canada — Version 8 — June 19, 2006 Page 15

8X DVD-ROM Drive
8X DVD-ROM Drive8X DVD-ROM Drive
8X DVD-ROM Drive Media Bay Drive
Media Bay DriveMedia Bay Drive
Media Bay Drive Dimensions (H x W x D) 0.82 x 5.21 x 5.27 in (2.08 x 13.23 x 13.39 cm)
Weight 0.59 lb (269 g)
Centre Hole Diameter
Centre Hole DiameterCentre Hole Diameter
Centre Hole Diameter 1.5 cm
Disk Diameter
Disk DiameterDisk Diameter
Disk Diameter 12 cm/8 cm
Access Times
Access TimesAccess Times
Access Times
(typical reads, including
settling)
Random (typical) < 130 ms DVD Media
Full-Stroke (typical) < 200 ms DVD Media
Random (typical) < 95 ms CD Media
Full-Stroke (typical) < 180 ms CD Media
Data Buffer
Data BufferData Buffer
Data Buffer 512 KB
Data Transfer Rate
Data Transfer RateData Transfer Rate
Data Transfer Rate
(typical, including settling)
Max 24X CD 3600 KB/s (150 KB/s at 1X CD rate)
Max 8X DVD 10,800 KB/s (1352 KB/s at 1X DVD rate)
Normal PIO Mode 4
(single burst)
16.6 MB/s
Start-up Time
Start-up TimeStart-up Time
Start-up Time < 19 seconds
Stop Time
Stop TimeStop Time
Stop Time < 6 seconds
24X CD-ROM Drive
24X CD-ROM Drive24X CD-ROM Drive
24X CD-ROM Drive Media Bay Drive
Media Bay DriveMedia Bay Drive
Media Bay Drive Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in (1.27 x 13.25 x 12.61 cm)
Weight 0.50 lb (0.22 kg)
Applicable Disk
Applicable DiskApplicable Disk
Applicable Disk CD-ROM (Mode 1, 2 and 3), CD-XA ready (Mode 2, Form 1 and 2), CD-I
ready (Mode 2, Form 1 and 2), CD-R (read only), CD Plus, Photo CD (Single
and Multi-session), CD-Extra, Video CD, CD-WO (fixed packets only), CD-
Bridge
Centre Hole Diameter
Centre Hole DiameterCentre Hole Diameter
Centre Hole Diameter 15 mm
Disk Diameter
Disk DiameterDisk Diameter
Disk Diameter 12 cm/8 cm
Disk Thickness
Disk ThicknessDisk Thickness
Disk Thickness 1.2 mm
Track Pitch
Track PitchTrack Pitch
Track Pitch 1.6 µm
Access Times
Access TimesAccess Times
Access Times
(typical reads, including
settling)
Random (typical) < 150 ms
Full-Stroke (typical) < 300 ms
Audio Output Level
Audio Output LevelAudio Output Level
Audio Output Level Line-out 0.7 Vrms
Cache Buffer
Cache BufferCache Buffer
Cache Buffer 128 KB
Data Transfer Rate
Data Transfer RateData Transfer Rate
Data Transfer Rate
(typical, including settling)
Sustained (16X) 2400 KB/s
Variable 1500 to 3600 KB/s (10X to 24X)
Normal PIO Mode 4
(single burst)
16.66 MB/s
Start-up Time
Start-up TimeStart-up Time
Start-up Time < 8 seconds
Stop Time
Stop TimeStop Time
Stop Time < 4 seconds
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Technical Specifications
DA - 12077 Canada — Version 8 — June 19, 2006 Page 16

Media Bay 3.5-inch
Media Bay 3.5-inchMedia Bay 3.5-inch
Media Bay 3.5-inch
Diskette Drive
Diskette DriveDiskette Drive
Diskette Drive
Media Bay Drive
Media Bay DriveMedia Bay Drive
Media Bay Drive Dimensions (H x W x D) 0.82 x 5.21 x 5.27 in (2.08 x 13.23 x 13.39 cm)
Weight 0.59 lb (269 g)
Diskette Size
Diskette SizeDiskette Size
Diskette Size 3.5 in
Bytes per Sector
Bytes per SectorBytes per Sector
Bytes per Sector 512
Sectors per track
Sectors per trackSectors per track
Sectors per track High density 18 (1.44 MB)/15 (1.2 MB)
Low density 9
Tracks per side
Tracks per sideTracks per side
Tracks per side High density 80 (1.44 MB)/80 (1.2 MB)
Low density 80
Read/Write heads
Read/Write headsRead/Write heads
Read/Write heads 2
Access Times
Access TimesAccess Times
Access Times Track-to track (high/low) 3 ms/6 ms
Average (high/low) 94 ms/174 ms
Settling time 15 ms
Audio
AudioAudio
Audio Features:
Features:Features:
Features:
SigmaTel Audio Stereo
SigmaTel Audio StereoSigmaTel Audio Stereo
SigmaTel Audio Stereo
Codec
CodecCodec
Codec
18-bit full duplex stereo ADC, DACs
High performance åD technology
Conforms to Audio Codec 97 Component Specification Rev 2.1
I/O
I/OI/O
I/O Mono Inputs
Mono InputsMono Inputs
Mono Inputs Internal Microphone
External Mic input – 20K Impedance
Stereo Outputs
Stereo OutputsStereo Outputs
Stereo Outputs Analog
Audio Output Amplifier
Audio Output AmplifierAudio Output Amplifier
Audio Output Amplifier
Quality
QualityQuality
Quality
Frequency Response
Frequency ResponseFrequency Response
Frequency Response 20 Hz – 20 kHz
Signal to Noise Ratio
Signal to Noise RatioSignal to Noise Ratio
Signal to Noise Ratio >94dB
Total Harmonic Distortion
Total Harmonic DistortionTotal Harmonic Distortion
Total Harmonic Distortion 0.01%
Noise Floor
Noise FloorNoise Floor
Noise Floor -120dB
Play/Record Sampling
Play/Record SamplingPlay/Record Sampling
Play/Record Sampling
Rate
RateRate
Rate (s)
7 kHz – 48 kHz
AD/DA Resolution
AD/DA ResolutionAD/DA Resolution
AD/DA Resolution 18 bit
Speaker
SpeakerSpeaker
Speaker Amplifier Power
Amplifier PowerAmplifier Power
Amplifier Power 2-Watts RMS
Speaker Impedance
Speaker ImpedanceSpeaker Impedance
Speaker Impedance 4-Ohms
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Technical Specifications
DA - 12077 Canada — Version 8 — June 19, 2006 Page 17

Video
VideoVideo
Video Features:
Features:Features:
Features:
ATI MOBILITY RADEON 9000, model S64
Highly optimized 128-bit engine
AGP 4X bus interface
Support for Direct X 8.1 and Open GL
Integrated MPEG-2 decode including iDCT, motion compensation, and hardware sub-picture decoder
ATI VIDEO IMMERSION II deinterlacing and frame rate conversion algorithms
SMOOTHVISION Anti Aliasing for sharper more detailed video images
ATI FULLSTREAM removes blocky artifacts from streaming video
ATI POWERPLAY III enables advanced notebook power management
Dedicated on chip 64MB DDR SDRAM with 128-bit memory interface
32-bit per pixel colour rendering
Support for two asynchronous display paths
Acceleration in 8/15/16/32bpp modes
Supports external VGA display: 640x480, 800x600, 1024x768, 1152x864, 1280x800, 1280x1024,
1680x1050, 1600x1200, 1792x1344, 1800x1440, 1920x1200, 1920x1440, 2048x1536 resolutions
up to 160-Hz refresh rate, dependent upon monitor capability, resolution and colour depth settings.
Supports up to QXGA resolution (2048X1536) through external VGA connector
WLAN Intel PRO/Wireless
WLAN Intel PRO/WirelessWLAN Intel PRO/Wireless
WLAN Intel PRO/Wireless
802.11b/g
802.11b/g802.11b/g
802.11b/g
Form Factor
Form FactorForm Factor
Form Factor MiniPCI Type III
Antenna
AntennaAntenna
Antenna Internal
Wi-Fi Alliance
Wi-Fi AllianceWi-Fi Alliance
Wi-Fi Alliance Wi-Fi CERTIFIED* for 2.4 GHz band and WPA
WLAN Standard
WLAN StandardWLAN Standard
WLAN Standard IEEE 802.11g and IEEE 802.11b
Architecture
ArchitectureArchitecture
Architecture Infrastructure or ad hoc (peer-to-peer)
Roaming
RoamingRoaming
Roaming 802.11g and 802.11b compliant for seamless roaming between respective
access points (802.11b, 802.11g, 802.11b/g)
Security
SecuritySecurity
Security Authentication LEAP, WPA, 802.1X, EAP-TLS
Encryption CKIP, TKIP, 128-bit and 64-bit WEP, Cisco-
Compatible Extensions (CCX) v1
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Technical Specifications
DA - 12077 Canada — Version 8 — June 19, 2006 Page 18

GPS
GPSGPS
GPS Form Factor
Form FactorForm Factor
Form Factor Integrated serial module
Antenna
AntennaAntenna
Antenna Display-mounted, internal quadrifilar helix
Frequency
FrequencyFrequency
Frequency L1, 1575.42 MHz
C/A code
C/A codeC/A code
C/A code 1.023 MHz chip rate
Channels
ChannelsChannels
Channels 12
Position
PositionPosition
Position 10 metres, 2D RMS
7 metres 2D RMS, WAAS corrected
Altitude
AltitudeAltitude
Altitude <+ 35m Vertical in term of 95%
Velocity
VelocityVelocity
Velocity 0.1 metres/second
Default
DefaultDefault
Default WGS-84
Reacquisition
ReacquisitionReacquisition
Reacquisition 0.1 sec., average
Snap start
Snap startSnap start
Snap start 2 sec., average
Hot start
Hot startHot start
Hot start 8 sec., average
Warm start
Warm startWarm start
Warm start 38 sec., average
Cold start
Cold startCold start
Cold start 45 sec., average
Altitude
AltitudeAltitude
Altitude 18,000 metres (60,000 feet) max.
Velocity
VelocityVelocity
Velocity 515 metres/second (1000 knots) max
Acceleration
AccelerationAcceleration
Acceleration 4g, max
Jerk
JerkJerk
Jerk 20 metres/second3, max
Protocol messages
Protocol messagesProtocol messages
Protocol messages SiRF binary and NMEA-0183, version 2.20 with baud rate selection.
SiRF binary-position, velocity, altitude, status and control NMEA
- GGA, GLL, GSA, GSV, RMC and VTG
Standard internal high
Standard internal highStandard internal high
Standard internal high
speed 56K modem
speed 56K modemspeed 56K modem
speed 56K modem
Form Factor
Form FactorForm Factor
Form Factor MDC (Mobile Daughter Card) per Intel Audio/Modem Daughter Card
Specification Version 1.0
OS Support
OS SupportOS Support
OS Support
(with all released Service
Packs)
Windows XP (Home, Professional), DOS Application Support under Windows
Power Management
Power ManagementPower Management
Power Management
Support
SupportSupport
Support
ACPI and wake on ring
Approvals/
Approvals/Approvals/
Approvals/
Certifications
CertificationsCertifications
Certifications
UL, CSA, Industry Canada, FCC Part 68, CTR21, FCC Part 15 Class B,
C.I.S.P.R.22, CE Mark, Other Countries
Modem Device Driver
Modem Device DriverModem Device Driver
Modem Device Driver
Name
NameName
Name
Lucent Win Modem Smart Link 56k Voice Modem
Data Mode Capabilities
Data Mode CapabilitiesData Mode Capabilities
Data Mode Capabilities 56kbps (K56Flex and high-speed 56K modem (a-law, mu-law))
V.44, V.42bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)
V.34 (file date: 10/964.8kbps to 33.6kbps)
Virtual com port with a throughput of up to 460.8kbps
Synchronous primary channel data signaling rates:
Synchronous primary channel data signaling rates:Synchronous primary channel data signaling rates:
Synchronous primary channel data signaling rates:
3600, 31200
Automatic rate re-negotiation
V.32bis (4.8kbps to 14.4kbps)
V.22bis (50bps to 2.4kbps)
V.32, V.23, V.22, V.21
Bell 212A, Bell 103J
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Technical Specifications
DA - 12077 Canada — Version 8 — June 19, 2006 Page 19

Fax Modem Standard
Fax Modem StandardFax Modem Standard
Fax Modem Standard Send and receive rates up to 14.4kbps, V.17, V.29, V.27ter
Bluetooth
BluetoothBluetooth
Bluetooth Form Factor
Form FactorForm Factor
Form Factor Integrated USB
Frequency Band
Frequency BandFrequency Band
Frequency Band 2402 to 2480 MHz
Carrier Spacing
Carrier SpacingCarrier Spacing
Carrier Spacing 1 MHz
Channel
ChannelChannel
Channel 79
Duplexing
DuplexingDuplexing
Duplexing TDD
Symbol Rate
Symbol RateSymbol Rate
Symbol Rate 1 Mbps
Modulation method
Modulation methodModulation method
Modulation method GFSK, 1 Mbps, 0.5 BT Gaussian
Maximum data rate
Maximum data rateMaximum data rate
Maximum data rate Asynchronous: 723.2 kbps / 57.6 kbps
Transmission power
Transmission powerTransmission power
Transmission power (Max +18) +16 to -12 dBm (Power control 6 stage).
Hopping
HoppingHopping
Hopping 1600 hops/s, 1 MHz channel space
Receiving signal range
Receiving signal rangeReceiving signal range
Receiving signal range -82 to -20 dBm
Receiver IF frequency
Receiver IF frequencyReceiver IF frequency
Receiver IF frequency 1.5 MHz centre frequency
Compliance
ComplianceCompliance
Compliance Bluetooth Specification Ver 1.1
USB specification
USB specificationUSB specification
USB specification Ver 1.1
Sierra Wireless AirCard
Sierra Wireless AirCardSierra Wireless AirCard
Sierra Wireless AirCard ®
750 GSM/GPRS
750 GSM/GPRS750 GSM/GPRS
750 GSM/GPRS
Form Factor
Form FactorForm Factor
Form Factor Type II PC Card (not extended)
Connectivity support
Connectivity supportConnectivity support
Connectivity support EDGE MS Class 12 capability (up to 4Tx, 4Rx, 5 total-network service
dependent)
Command Set
Command SetCommand Set
Command Set EDGE, GPRS, SMS circuit switched data
SMS
(send and receive)
Support for multiple APN's
NDIS driver host interface
Dial-up networking
Voice and fax support
Quad-Band EDGE/GPRS
Quad-Band EDGE/GPRSQuad-Band EDGE/GPRS
Quad-Band EDGE/GPRS GSM 850 MHz band
GSM 850 MHz bandGSM 850 MHz band
GSM 850 MHz band Transmit Frequency 824 to 849 MHz
Receive Frequency 869 to 894 MHz
Output power 500mW (+27dBm) 2W
(+33 dBm)
GSM 900 MHz band
GSM 900 MHz bandGSM 900 MHz band
GSM 900 MHz band Transmit Frequency 880 to 915 MHz
Receive Frequency 925 to 960 MHz
Output power 500mW (+27 dBm)
2W (+33 dBm)
DCS 1800 MHz band
DCS 1800 MHz bandDCS 1800 MHz band
DCS 1800 MHz band Transmit Frequency 1710 to 1785 MHz
Receive Frequency 1805 to 1880 MHz
Output power 400mW (+26dBm)
1000mW (+30dBm)
PCS 1900MHz band
PCS 1900MHz bandPCS 1900MHz band
PCS 1900MHz band Transmit Frequency 1850 to 1910 MHz
Receive Frequency 1930 to 1990 MHz
Output power 400mW (+26 dBm)
1000mW (+30 dBm)
QuickSpecs
HP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PCHP nr3610 Rugged Notebook PC
HP nr3610 Rugged Notebook PC
Technical Specifications
DA - 12077 Canada — Version 8 — June 19, 2006 Page 20
