HP Compaq Presario Manual

1-98 Volume Two
Presario 1200
System/Processor Boards Assembly Spare Part System
Processor Board w/ 32 MB 356877-001 1234, 35, 36,
37, 38, 40,
42, 50, 52
Processor Board w/ 32 MB 330938-001 1230
Processor Board w/ 32 MB
SDRAM 142646-001 1272, 73, 74, 75
System Board 586/200GXM,
Processor 203716-001 1220, 1220ES
System Board 586/180GXM,
Processor 203718-001 1215
System Board, I/O w/ 1M w/ 64
MB LVD 50M102D83-S0 173539-001 1200XL
System Board, I/O w/ 1M w/ 64
MB TFT 50M102D81-S0 169608-001 1200XL
System Board, I/O w/ 32 MB
SDRAM 102246-001 1255, 60, 66, 67
System Board, I/O w/ 512K
Cache w/ 32 MB HPA 50M102D79-S0 169606-001 1200XL
System Board, I/O w/ 512K
Cache w/ 32 MB RAM 158793-001 1246, 47
System Board, I/O w/ 512K
Cache w/ 64 MB HPA 50M102D80-S0 169607-001 1200XL
System Board, I/O w/ 512K
Cache w/ 64 MB RAM 158794-001 1246, 77, 78
System Board w/ 32 MB
SDRAM w/o FMDM 102247-001 1255, 60, 66, 67
System Board w/ Cache, w/o
Processor 293785-001 1207, 10
System Board, w/o Processor 203731-001 1220
System Board, w/o Processor 327715-001 1215
Configuration Code System Board Spare Part Model
BQH2 293785-001 1210
BQH3 293785-001 1207
BQH4 293785-001 1207
BQH5 293785-001 1207
BVL2 203716-001 1220
BVL4 203716-001 1220
BXN2 203731-001 1215
BY44 330938-001 1230
BY86 356877-001 1235
BY87 356877-001 1238
BY88 356877-001 1237
BY8B 356877-001 1235
BY8H 356877-001 1234
BY8K 356877-001 1236
BYG2 356877-001 1240
BYG3 356877-001 1240
BYG4 356877-001 1242
BYG5 356877-001 1240
CF42 356877-001 1252
CF43 356877-001 1250
Continued

Volume Two 1-99
Presario 1200
Configuration Code System Board Spare Part Model
CFK2 102246-001 1255
CFK3 102246-001 1255
CFK4 102246-001 1255
CFK5 102246-001 1260
CFK6 102246-001 1255
CFK7 102246-001 1260
CFK8 102246-001 1266
CFKB 102246-001 1267
CFKC 102246-001 1260
CFKD 102246-001 1260
CLR3 142646-001 1275
CLR4 142646-001 1273
CLR5 142646-001 1272
CLR7 142646-001 1275
CLR8 142646-001 1274
CLRG 142646-001 1275
CTS1 158793-001 1246
CTS3 158794-001 1277
CTS6 158793-001 1246
CTS7 158794-001 1278
CTS9 158793-001 1247
CTSD 158794-001 1277
DCH1 169607-001 1200XL
DCH2 169608-001
173539-001 1200XL
DCH3 169608-001
173539-001 1200XL
DCH5 169607-001 1200XL
DCH6 169608-001
173539-001 1200XL
DCH7 173539-001 1200XL
Microprocessors Assembly Spare Part System
233 GXM Processor 330937-001 1230
586/200 GXM w/ Processor
Board 203734-001 1220, 1220ES
686/150 w/ Heat Sink 293828-001 1207, 10
686/180 GXM 203718-001 1215
686/266 MMX Processor 332216-001 1234, 35, 36, 37,
38
K6/300 Processor 356886-001 1250, 52
K6II/333 Processor 400442-001 1255, 60, 66, 67
K6II/366 Processor 142647-001 1272, 73, 74, 75
K6II/400 Processor, AMD,
2.2V 134079-001 1246, 47
K6II/433 Processor, AMD 158851-001 1277, 1278
K6II/450 Processor, 2.1V 50M102D42-S0 159548-001 1200XL
K6II/475 Processor, 2V 50M102D44-S0 161064-001 1200XL
K6II/500 Processor, 2.1V 50M102D82-S0 173534-001 1200XL
P/266 MAX Processor 356885-001 1240, 42

1-100 Volume Two
Presario 1200
Memory Modules/Boards Spare Part System
16 MB Memory, SODIMM 293726-001 All
32 MB Memory, SODIMM 293727-001 All
64 MB Memory, SODIMM 332208-001 All
Hard Drives Assembly Spare Part System
1.4 GB, IDE 293779-001 1207, 10
1.4 GB, IDE 203740-001 1215
2.1 GB, IDE 298764-001 1220
2.1 GB, IDE 330933-001 1230
3.2 GB, IDE 330968-001 1230
4.0 GB, IDE 330969-001 1260, 66, 67
4.3 GB, IDE 144410-001 1246, 47, 72, 74,
75, 77, 78
4.8 GB, IDE 50M101D81-S0 142310-001 1246, 77, 78, 79;
1200XL
5.0 GB 50M102D77-S0 169609-001 1200XL
6.0 GB 50M101Z23-S0 170087-001 1200XL
6.4 GB, IDE 347548-001 1250, 60, 66
6.4 GB, IDE 142651-001 1273
Diskette Drives Assembly Spare Part System
1.44 MB 293784-001 All
1.44 MB 330947-001 1230, 34, 35, 36,
37, 38, 40, 42,
50, 52, 55, 60,
66, 67
1.44 MB 50M101D99-S0 141847-001 1246, 47, 72, 73,
74, 75, 77, 78;
1200XL
CD-ROM Assembly Spare Part System
6X DVD-ROM, 1C 50M102D76-S0 169799-001 1200XL
14X Max 203741-001 1215
14X Max CD-ROM (Black) 297657-001 1207, 10
20X Max CD-ROM 203736-001 1220
24X CD-ROM 330934-001 1230, 34, 35, 36,
37, 38, 40, 42,
50, 52
24X CD-ROM 386891-001 1255, 60, 66, 67
24X Max CD-ROM, IDE, 2C 50M101D78-S0 142307-001 1246, 47, 77, 78;
1200XL
24X CD-ROM, 2C 142650-001 1272, 73, 74, 75
Cables Assembly Spare Part System
Flat Panel, Cable to
Interface Board 50M102D15-S0 152186-001 1246, 77, 78, 79; 1200XL
Misc. Cable Kit 293759-001 All
Misc. Cable Kit 203714-001 1215, 20, 20ES
Misc. Cable Kit 293759-001 All
Misc. Cable Kit 50M101F23-S0 330946-001 1230, 34, 35, 36,
37, 38, 40, 42,
46, 47, 50, 52,
55, 60, 66, 67,
72, 73, 74, 75,
77, 78, 79;
1200XL

Volume Two 1-101
Presario 1200
Miscellaneous Internal Assembly Spare Part System
Audio Board w/ Jacks –
Lite 293756-001 1207, 10
Fan 346863-001 1234, 35, 36, 37, 38,
40, 42, 50, 52, 55,
60, 66, 67
Fan 293747-001 All
Fan 102249-001 1272, 73, 74, 75
Fan, 5500 rpm 50M102D35-S0 158801-001 1246, 47, 77, 78, 79;
1200XL
Fan, 7000 rpm 50M102D34-S0 158800-001 1246, 47, 77, 78, 79;
1200XL
Heat Spreader, 2000 50M102D36-S0 158802-001 1246, 47, 77, 78, 79;
1200XL
LCD Interface Board w/
Header 293746-001 All
Voltage Converter
Board 293748-001 All
Voltage Converter
Board 330962-001 1230
Voltage Converter
Board, 3C 50M101F43-S0 352891-001 1234, 35, 36, 37, 38, 40, 42, 46, 47, 50,
52, 55, 60, 66, 67,
1272, 73, 74, 75, 77,
78, 79; 1200XL
Miscellaneous
External Assembly Spare Part System
AC Adapter 50M101P23-S0 298239-001 All (new smaller
size)
AC Adapter 293787-001 All
Base Enclosure 50M102D32-S0 158798-001 1246, 47, 77, 78;
1200XL
CPU Cover, Upper 203739-001 1215, 1220
CPU Cover w/ Cable &
Power Switch 293739-001 All
CPU Cover w/ Power
Switch 330963-001 1255, 60, 66, 67
CPU Cover w/ Power
Switch 50M102D33-S0 158799-001 1200XL
Hardware Kit, Misc. 50M101F37-S0 346853-001 1234, 35, 36, 37, 38,
40, 46, 47, 50, 52,
55, 60, 66, 67, 1272,
73, 74, 75, 77, 78,
79; 1200XL
Keyboard 102250-001 1260
Keyboard 141706-XXX 1246, 47, 72, 73, 74,
75, 77, 78, 79
Keyboard 50M102D58-S0 171003-001 1200XL
Keyboard - ARAB 50M102D66-S0 171003-171 1200XL
Keyboard - BEL 50M102D74-S0 171003-381 1200XL
Keyboard - BR 50M102D86-S0 171003-201 1200XL
Keyboard - DK 50M102D59-S0 171003-081 1200XL
Keyboard - FCAN 50M102D73-S0 171003-121 1200XL
Keyboard - FR 50M102D60-S0 171003-051 1200XL
Keyboard - IT 50M102D62-S0 171003-061 1200XL
Keyboard - JP 50M102D71-S0 171003-291 1200XL Continued

1-102 Volume Two
Presario 1200
Miscellaneous
External Assembly Spare Part System
Keyboard - LA 50M102D65-S0 171003-161 1200XL
Keyboard - NL 50M102D72-S0 171003-331 1200XL
Keyboard - NO 50M102D63-S0 171003-091 1200XL
Keyboard - UK 50M102D68-S0 171003-031 1200XL
Keyboard - PT 50M102D69-S0 171003-131 1200XL
Keyboard - SE 50M102D67-S0 171003-101 1200XL
Keyboard - SG 50M102D64-S0 171003-AF1 1200XL
Keyboard - TW 50M102D70-S0 171003-AB3 1200XL
Keyboard - UK 50M102D68-S0 171003-031 1200XL
Keyboard, US 293776-001 1210, 1620
Keyboard, US 330956-001 1230, 34, 35, 36, 37,
38, 40, 50, 52
Modem, 33.6+Data/Fax [phone], 20, 07
Modem, 56.6+Data/Fax [phone], 10, 07
Modem, 56K Data/Fax [phone], 20, 30
Modem, 56K Data/Fax [phone], 34, 40, 42, 55,
60
Modem, 56K Data/Fax
w/o SRAM 138659-001 1235, 36, 37, 38, 40, 50, 52, 55, 60, 66,
67, 72, 73, 74, 75
Modem, K-56K
Data/Fax w/o SRAM 50M101D48-S0 400445-001 1246, 47, 77, 78; 1200XL
Modem, K-56K
Data/Fax w/o SRAM -
International
50M102D02-S0 143848-001 1200XL
Palm Rest w/ Board &
Cables 293716-001 All
Palm Rest 203737-001 1215, 1220
Palm Rest 330965-001 1230
Palm Rest 352888-001 1234, 35, 36, 37, 38,
40, 42, 50, 52
Palm Rest w/
Touchpad/Button Board 387540-001 1255, 60, 66, 67
Palm Rest w/
Touchpad/Button Board 50M101D96-S0 142653-001 1272, 73, 74, 75; 1200XL
Palm Rest w/
Touchpad/Button Board 50M101D95-S0 142654-001 1200XL
Palm Rest w/
Touchpad/Button Board
w/o Soft Paint
161416-001 1278
Plastic Kit,
Miscellaneous 50M102D01-S0 142657-001 1246, 47, 77, 78; 1200XL
Port Replicator 102270-001 1270
Speakers, Left and
Right 293757-001 1215, 1220
Speakers, Left and
Right 293782-001 All ex 1207, 10
Speakers, Lite 293883-001 1207, 10
Speakers, w/ Enclosure
and Cable 330960-001 1230
Speakers, w/ Enclosure
and Cable 352889-001 1234, 35, 36, 37, 38, 40, 42, 50, 52, 55,
60, 66, 67
Speakers, w/ Enclosure
and Cable 50M102D06-S0 148108-001 1246, 47, 1272, 73, 74, 75, 77, 78;
1200XL

Volume Two 1-103
Presario 1200
Modem Cables Spare Part
APD 137256-001
Brazil 137256-001
Canada 137256-001
Hong Kong 137256-001
Japan 137256-001
Latin America 137256-001
Switzerland 304398-111
Taiwan 137256-001
United Kingdom 165224-031
US 137256-001
Modem Cable/Adapters Cable Spare Part
APD 304398-371
Australia 304398-011
Belgium 304398-181
France 304398-051
Germany 304398-041
Netherlands 304398-331
New Zealand 304398-011
Sweden 304398-101
United Kingdom 304398-031
Video Assembly Spare Part System
Display Assy , 11.3”DSTN 293781-001 1207
Display Panel, 12.1”DSTN 50M102D24-S0 158795-001 1277, 78, 79;
1200XL
Display Assy, 12.1”HC 332209-001 1220 (BVL4)
Display Assy, 12.1”HPA 203735-001 1220 (BVL2),
1215
Display Assy, 12.1”HPA 330939-001 1230, 34, 35,
38, 40
Display Assy, 12.1”HPA 142648-001 1272, 73, 74, 75
Display Assy, 12.1”STN-Lite 293881-001 1210
Display Assy, 12.1”TFT 352890-001 1235, 36, 37,
40, 42, 50, 52,
60, 66, 67
Display Assy, 12.1”TFT 50M102D84-S0 173540-001 1200XL
Display Panel, 12.1”HPA II 102248-001 1255
Display Panel, 12.1”
TFT/LVDS 159038-001 1246, 77, 78, 79,
Display Assy, 13.0”HPA 142649-001 1275
Display Panel, 13.0”DSTN 50M102D25-S0 158796-001 1246, 78, 79;
1200XL
Display Panel, 13.3”
TFT/LVDS 50M102D85-S0 173665-001 1200XL
Display, Status w/ Cables 293737-001 All
ROM Information Spare Part System
ROMPaq 261922-001 All

1-104 Volume Two
Presario 1200
Power Supply/Battery Assembly Spare Part System
Battery Pack, E.D. NiMH 330935-001 1230, 34, 35, 40
Battery Pack, E.D. NiMH,
Enhanced 50M101D26-S0 388648-001 1246, 55, 72, 73, 74, 75, 77, 78, 79;
1200XL
Battery Pack, Li-Ion,
Enhanced 50M101X13-S0 138184-001 1200XL
Battery, Li-Ion 292560-001 All
Battery, Li-Ion 330936-001 1234, 35, 36, 37,
38, 40, 42, 50, 52
Battery, Li-Ion, Enhanced 388647-001 1246, 47, 55, 60,
66, 67, 75, 77, 78,
79
Battery, NiMH 293861-001 All
Clock/Battery 117099-001 All

Volume Two 1-105
Presario 1200
PRESARIO 1207, 1210, 1215, 1220, 1220ES, 1230
MEMORY UPGRADE CHART
16-MB MEMORY MODULE, SODIMM - OPTION PN 293820-001
ADD ANY ONE OF THE FOLLOWING
MEMORY MODULES:
MAXIMUM MEMORY IS 96 MB
32-MB MEMORY MODULE, SODIMM - OPTION PN 293821-001
64-MB MEMORY MODULE, SODIMM - OPTION PN 293822-001

1-106 Volume Two
Presario 1200
PRESARIO 1234, 35, 36, 37, 38, 40, 42, 50, 52
MEMORY UPGRADE CHART
16-MB MEMORY MODULE - OPTION PN 293820-001
ADD ANY ONE OF THE FOLLOWING
MEMORY MODULES:
32-MB MEMORY MODULE - OPTION PN 293821-001
64-MB MEMORY MODULE - OPTION PN 293822-001
MAXIMUM MEMORY IS 96 MB

Volume Two 1-107
Presario 1200
PRESARIO 1255, 60
MEMORY UPGRADE CHART
ADD ANY ONE OF THE FOLLOWING MEMORY BOARDS
32-MB SDRAM OPTION PN 293821-002
64-MB SDRAM OPTION PN 293822-002
128-MB SDRAM OPTION PN 401040-B21
