HP FP1707 User manual

17" LCD Color Monitor HP FP1707
1
Service
Service
Service
Horizontal Frequency
24-83kHz
TABLE OF CONTENTS
Description Page Description Page
SAFETY NOTICE
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
Table Of Contents.......…..............................…........1
Revision List.…..................................……......2
1. Monitor Specification............................………........3
2. LCD Monitor Description……………………….......4
3. Operation Instruction…………..............……...........5
3.1.General Instructions.........................…...........5
3.2. Control Button…………….….........……...............5
3.3 Adjusting the Picture...........................…............6
4. Input/Output Specification......……………............9
4.1. Input Signal Connector............……….................9
4.2. Factory Preset Display Modes......…..................10
4.3. Power Supply Requirements..............................10
5. Panel Specification.....………………..................11
5.1.General Feature…..........................................11
5.2. Optical Characteristics…………………………12
6. Block Diagram……...................………................13
6.1 Software Flow Chart……………………………...13
6.2. Electrical Block Diagram……………..….......15
7. Schematic……………......................................17
7.1 Main Board..……….......................................17
7.2 Power Board.…….……....................................23
7.3 Key Board.……..……....................................25
8.PCB Layout…...…….......................................26
8.1.Main Board………........................................26
8.2.Power Board……….........................................28
8.3.Key Board………............….......................30
9. Maintainability……….......................................31
9.1.Equipments and Tools Requirement..............31
9.2.Trouble Shooting………..............................32
9.2.1 Main Board………………..............................32
9.2.2 Power Board……….……..............................34
9.2.3 Key Board………….……..............................36
10.White-Balance, Luminance adjustment...37
11.Mechanical Instructions………….…...….......39
12.Monitor Exploded View…….…………....….......45
13.BOM List……………….…………………………46
14.Different Parts List….........................................62

17" LCD Color Monitor HP FP1707
2
Revision List
Version Date Revision History TPV Model Name
A00 Dec.-24-06 Initial release T76CMKMLH7CPDP
T76AMKMLH7CPDP
A01 Apr.-02-07 Second release
T76AMKMLH7CPDF
T76AMKMLH7CPDP
T76AMKMMH7CPDP
T76CMKMCH7CPDP
T76CMKMLH7CPDF
T76CMKMMH7CPDP
A02 Jun.-18-07 Third release T76AMKMCH7CPDP

17" LCD Color Monitor HP FP1707
3
1. Monitor Specification

17" LCD Color Monitor HP FP1707
4
2. LCD Monitor Description
The LCD Monitor will contain main board, power board, and a key board which house the flat panel control logic,
brightnesscontrollogicandDDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each
voltage.
Video signal, DDC
Power Board
(
Include ada
p
ter board
)
Flat Panel and
CCFL backlight
Main Board RS232 Connector
For white balance
adjustment in
factory mode
HOST Computer
CCFT Drive.
AC-IN
110V-240V
Monitor Block Diagram
Key board

17" LCD Color Monitor HP FP1707
5
3. Operation Instructions
3.1 General Instructions
Press the power button to turn the monitor on or off. The other control buttons are located at front of the panel. By
changing these settings, the picture can be adjusted to your personal performance.
-The power cord should be connected and insert to adaptor.
- Connect the video cable from the monitor to the computer VGA card.
- Press the power button to turn on the monitor, the power indicator will light up to Green.
3.2 Control Button

17" LCD Color Monitor HP FP1707
6
3.3 Adjust the Picture

17" LCD Color Monitor HP FP1707
7

17" LCD Color Monitor HP FP1707
8

17" LCD Color Monitor HP FP1707
9
4. Input/Output Specification
4.1 Input Signal Connector
Pin Signal Pin Signal
1 Red Video 9 3.3/+5 V (from PC)
2 Green Video 10 Sync Ground
3 Blue Video 11 None
4 None 12 DDC Data
5 Ground (DDC Return) 13 Horizontal Sync
6 Red GND 14 Vertical Sync
7 Green GND 15 DDC Clock
8 Blue GND
VGA connector layout
PIN 1 PIN 5
PIN 11
Pin Signal Pin Signal Pin Signal
1 TMDS Data 2 - 9 TMDS Data 1 - 17 TMDS Data 0 -
2 TMDS Data 2 + 10 TMDS Data 1 + 18 TMDS Data 0 +
3 TMDS Data 2 / 4 Shield 11 TMDS Data 1 / 3 Shield 19 TMDS Data 0 / 5 Shield
4 TMDS Data 4 - 12 TMDS Data 3 - 20 TMDS Data 5 -
5 TMDS Data 4 + 13 TMDS Data 3 + 21 TMDS Data 5 +
6 DDC Clock 14 +3.3/+5V Power (from PC) 22 TMDS Clock Shield
7 DDC Data 15 Ground (Return for +5V) 23 TMDS Clock +
8 No Connect 16 Hot Plug Detect (connect internally
to pin-14) 24 TMDS Clock -
DVI-D digital connector layout

17" LCD Color Monitor HP FP1707
10
4.2 Factory Preset Display Modes
4.3 Power Supply Requirements
Parameter Range
AC Input Voltage 90 to 265V
AC Input Frequency 45 to 63 Hz
Inrush Current 50A MAX AT 220VAC and 30A AT 120VAC
Leakage Current 5 mA MAX at 120VAC

17" LCD Color Monitor HP FP1707
11
5. Panel Specification
5.1 General Feature
Absolute Maximum Ratings

17" LCD Color Monitor HP FP1707
12
5.2 Optical Characteristics
Ta=25℃，VCC=5.0V

17" LCD Color Monitor HP FP1707
13
6. Block diagram
6. 1 Software Flow Chart
1
2
N
Y
5
Y
N
10
Y
N
12
Y
N
7
Y
N
6
4
3
8
9
14
11
13
Y
N
15
Y
N
16
17
19
Y
N
18

17" LCD Color Monitor HP FP1707
14
REMARK:
1) MCU initialize.
2) Is the EEprom blank?
3) Program the EEprom by default values.
4) Get the PWM value of brightness from EEprom.
5) Is the power key pressed?
6) Clear all global flags.
7) Are the AUTO and SELECT keys pressed?
8) Enter factory mode.
9) Save the power key status into EEprom.
Turn on the LED and set it to green color.
Scalar initialize.
10) In standby mode?
11) Update the lifetime of back light.
12) Check the analog port, are they’re any signals coming?
13) Does the scalar send out an interrupt request?
14) Wake up the scalar.
15) Are there any signals coming from analog port?
16) Display "No connection Check Signal Cable" message. And go into standby mode after the message
disappear.
17) Program the scalar to be able to show the coming mode.
18) Process the OSD display.
19) Read the keyboard. Is the power key pressed?

17" LCD Color Monitor HP FP1707
15
6.2 Electrical Block Diagram
6.2.1 Scalar Board
LCD Interface
Scalar TSUM56AWHK-LF
(Include: MCU, ADC, OSD etc)
OSD Control
Interface (Keypad)
D-SUB
Connector
EEPROM
24C02
Crystal
14.318MHZ
EEPROM
PM25LV010-25
DVI-SIGNAL
Connector
EEPROM
24C02

17" LCD Color Monitor HP FP1707
16
6.2.2 Inverter / Power Board
CN902
DIM
EMI filter Bridge
Rectifier
and Filter
Start Circuit
PWM
Control IC
Transformer Rectifier
diodes
AC input
12V
ON/OFF
Control
PWM
Control IC
Feedback
Circuit
LC
Resonance
Transformer MOSFET
Over
Voltage
Lamp
ON/OFF
Feedback
Circuit
Over
Voltage
Protect
5V

17" LCD Color Monitor HP FP1707
17
7. Schematic
7.1 Main Board
VLCD
B6
7.AUDIO
OUT-R-
OUT-R+
OUT-L+
OUT-L-
VCC5V
DGND
VOLUME
AUDIO_SD
VCC5V
VCC1.8
+5V
+5V
VLCD
VCC3.3 +5V
VCC3.3
LVDS OUTPUT
B4
5.SCALER
RIN
GIN
SOG
BIN
GNDR
GNDG
GNDB
HSYNC
VSYNC
Adj_BACKLIGHT
VCC1.8
Vcc3.3
VCTRL
R+
R-
G-
G+
B+
B-
CLK+
CLK-
DDCD_SDA
DDCD_SCL
DET_DVI
DDCA_SDA
DDCA_SCL
DET_VGA
on_BACKLIGHT
on_Panel
+5V
DDC_WP
PA[0..9]
HPD_CTRL
OUT-R-
OUT-R+
OUT-L+
OUT-L-
VOLUME
AUD IO_SD
PA[0..9]
VCC5V
XGA/SXGA
B2
3.POWER
on_Panel
on_BACKLIGHT
Adj_BACKLIGHT
VCC1.8
VLCD
+5V
VCTRL
VCC3.3
VCC5V
DGND
G2252-1-X-X-2-070313
F
TOP
AOC (Top Victory) Electronics Co., Ltd.
B
17 Wednesday , March 14, 2007
Tit le
Size Document Number Rev
Date: Sheet of
VCC1.8
B3
4.INPUT
RIN
GIN
BIN
VSYNC
GNDR
GNDG
GNDB
DET_VGA
HSYNC
SOG
B+
CLK-
DET_DVI
CLK+
R+
G+
R-
B-
G-
DDCA_SDA
DDCA_SCL
DDCD_SDA
DDCD_SCL
DDC_WP
+5V
HPD_CTRL
B5
6.PANEL INTERFACE
VLCD
PA[0..9]

17" LCD Color Monitor HP FP1707
18
+
C710
100uF/25V
TO-252
VCC5V
VCC5V
C709
0.1uF
FTD9
NC/FD Mark
VLCD 6
R706 NC VCC3.3 5
R721
NC
+5V
CN701
CONN
2
4
6
8
10
12
1
3
5
7
9
11
+3V3
FTD8
NC/FD Mark
VCC3.3 5
VCC1.8
DGND
+5V
C701
0.1uF
Q706
MMBT3906
+3V3
R707
4.7KΩ1/10W
Q703
MMBT3904
C718
0.1uF
R71410KΩ1/10W
H1
NC/TP
1 2 3
4
5
6 7 8
9
1 2 3
4
5
6 7 8
9
R704
100Ω1/10W
VCC3.3
R708
10KΩ1/10W
U702
AIC1084-33PE
1
23
ADJ
Vo2Vin
D704
SR24
DGND 4,5,6,7
+3V3
R727
10KΩ1/10W
H3
NC/TP
1 2 3
4
5
6 7 8
9
1 2 3
4
5
6 7 8
9
VCC5V
VCC3.3
VCC5V
VCC5V
VLCD
Reserved for 15'' panel power
R702
51Ω1/10W
+5V
DGND
C719
0.1uF
Modified by Cakor 8/18 2006
+
C702
4.7uF 50V
+3V3
Q702
PZT2907A
VCC1.8 5
R705 120 OHM
+
C712
100uF/25V
C714
0.1uF
C713
0.1uF
BL_ON
R712 4.7KΩ1/10W
C711
NC
Cakor 8/9
+5V4,5
+
C717
10uF/50V
U701 AIC1117-33PY
3 2
1
VI VO
GND
FTD7
NC/FD Mark
D702
LL4148
R711
10KΩ1/10W
VCC5V7
C704
0.1uF
R703
2KΩ1/10W
C715
NC
DGND
R710 NC
Cakor
9/28
H2
NC/TP
1 2 3
4
5
6 7 8
9
1 2 3
4
5
6 7 8
9
R723 51KΩ1/10W
VCTRL 5
C708
NC
+5V
DGND
+
C703
100uF/25V
R722
0Ω1/10W
R725 4.7KΩ1/10W
on_BACKLIGHT 5
R701
1KΩ1/10W
D701
MLL4148
Adj_BACKLIGHT 5
DGND
DGND
R716
NC
Q701
MMBT3904
+5V
VCC5V7
G2252-1-X-X-2-070313
F
POWER
AOC (Top Victory) Electronics Co., Ltd.
B
37 Wednesday , March 14, 2007
Ti t le
Size Document Number Rev
Date: Sheet of
BL_ADJ
R715
NC
R717
10KΩ1/10W
Q704
AO3401
on_Panel5
SOT-223

17" LCD Color Monitor HP FP1707
19
G2252-1-X-X-2-070313
F
INPUT
AOC (Top Victory) Electronics Co., Ltd.
B
47 Wednesday , March 14, 2007
Title
Size Document Number Rev
Date: Sheet of
C457
NC
HSYNC 5
DVI5V
+5V
C439
0.1uF
SDA_DVI
R451
4.7KΩ1/10W
DCLK-
R437 470Ω1/10W
D409
MLL5232B 5.6V
D422
NC
3
1 2
DDC_WP 5
D418
NC
3
1 2
C458
NC
R435 56Ω1/10W
R448
2.2KΩ1/10W
FB409 120 OHM
DAT0+
R468 NC
R466 NC
FB410 0Ω1/10W
R454 33Ω1/10W
R455 NC
G- 5
RED-
R440
75Ω1/10W
R444
10KΩ1/10W
CN405
DB15
1
6
2
7
3
8
4
9
5
11
12
13
14
15
10
1716
R+ 5
DDC_WP 5
DVI5V
FB412 0Ω1/10W
R463 NC
C446
NC
D416
NC
R- 5
DAT1+
C454
NC
R458 NC
VSI
C444
0.1uF
C435 0.047uF
C453
NC
+5V
D407
BAV70
3
1 2
+5V 3,5
D406
MLL5232B 5.6V
C433 0.047uF
R464 NC
R471
NC
D415
NC
VGA_CON
C448
NC
R472
NC
C459
NC
D425
MLL5232B 5.6V
U404
M24C02-WMN6TP
1
2
3
45
6
7
8A0
A1
A2
VSSSDA
SCL
WP
VCC
C450
NC
R447 1KΩ1/10W
G+ 5
GREEN+
D413
NC
3
1 2
GIN 5
C449
NC
D419
NC
3
1 2
R434 56Ω1/10W
DDCD_SCL5
D426
NC
DDCD_SDA5
BLUE-
SDA_VGA
ESD_5V
PC5V
HSI
R452
10KΩ1/10W
C445
NC
R459
NC
D414
NC
R469 NC
B+ 5
C451
NC
C452
NC
D412
MLL5232B 5.6V
GNDB 5
SCL_DVI
R473
NC
C460
NC
C438 0.047uF
HPD_CTRL 5
GNDR 5
PC5V
U405
NC
1
2
3
45
6
7
8A0
A1
A2
VSSSDA
SCL
WP
VCC
+5V
RED+
SCL_VGA
DET_DVI 5
C447
NC
D410
MLL5232B 5.6V
+5V
DAT2-
R453 33Ω1/10W
D417
NC
3
1 2
RIN 5
GNDG 5
DAT0-
DDCA_SCL5
R450
4.7KΩ1/10W
R449
2.2KΩ1/10W
D405
BAV99
3
1 2
R462 NC
D404
BAV99
3
1 2
CLK- 5
DVI5V
R457 NC
ESD_5V
R441 100Ω1/10W
R443 100Ω1/10W
C443
220pF
C441
0.1uF
R438
75Ω1/10W
C436 0.047uF
DAT2+
VSY NC 5
SOG 5
R439
75Ω1/10W
C442
33pF
D408
MLL5232B 5.6V
R470
10KΩ1/10W
FB413
120Ω
1 2
R456 NC
R446 1KΩ1/10W
R445 100Ω1/10W
DAT1-
DDCA_SDA5
R494 NC
D403
BAV99
3
1 2
HPD
C437 0.047uF
CN406
NC
1
2
3
4
5
6
7
8
25
28
9
10
11
12
13
14
15
16
26
29
17
18
19
20
21
22
23
24
27
32 31
DAT2-
DAT2+
2/4shield
DAT4-
DAT4+
DDC SCL
DDC SDA
VSY NC
R
HSYNC
DAT1-
DAT1+
1/3shield
DAT3-
DAT3+
+5V
SYNC GND
HPD
G
RGB GND
DAT0-
DAT0+
0/5shield
DAT5-
DAT5+
clk shield
clk+
clk-
B
GND GND
C440
0.1uF
BLUE+
D420
NC
3
1 2
D411
MLL5232B 5.6V
D421
NC
3
1 2
C432 0.047uF
D424
NC
3
1 2
DET_VGA 5
+5V
R467 NC
R461
NC
D423
NC
3
1 2
R436 56Ω1/10W
R442 100Ω1/10W
CLK+ 5
B- 5
PC5V
GREEN-
R460
NC
C434 0.047uF BIN 5
DCLK+
FB411 0Ω1/10W
R465 NC
Q408
NC

17" LCD Color Monitor HP FP1707
20
WP
OUT-R+
R496 0Ω1/10W
POWER
FB405
120Ω
R421 56Ω1/10W
DET_DVI 4
D427
NC
R493
NC
C430
0.1uF
VCC3.3
+5V
POWER
GNDR4
VDDC
C461
1uF/16V
R407 N C
VCC3.3
LED_ORAN GE
D402
UDZS5.6B
VDDP
G-4
Volume_out
VSY NC4
VDVI
FB403
120Ω
+5V
PA2
C411
0.1uF
WP
R474
3.9KΩ1/10W
C419
0.1uF
C416
0.1uF
R477 1KΩ1/10W
Reset
Circuit
change KEY Function
Select<->Left
Menu<->Right
AVDD
C421 22pF
KEY_LEFT
R428 100Ω1/10W
C425
220nF16V
SOG4
on_PANEL 3
U407
NC
4
8
5
6
1
2
3
7
GND
VCC
SDA
SCL
A0
A1
A2
WP
KEY_RI GHT
POWER
U403
M24C04-WMN6TP
1
2
3
45
6
7
8NC
E1
E2
VSSSDA
SCL
WC
VCC
FB402
120Ω
GIN4
KEY_RIGHT
C431
NC
+
C403
4.7uF 50V
C427
0.1uF
R497 0Ω1/10W
LED_GRN/BLUE
R416
10KΩ1/10W
OUT-L+ 7
LED_ORANGE
R425
10KΩ1/10W
C429
0.1uF
VCC3.3
C420 0.1uF
LED_ORAN GE
C414
0.1uF
VDDP
PA8
+
C418
10uF/50V
PA4
FB406
120Ω
D429
UDZS5.6B
VCC3.33
R422 4.7KΩ1/10W
R476 1KΩ1/10W
KEY _MENU
MAX810STRG
R410 N C
R430 2KΩ1/10W
BIN4
R403 390Ω1/10W
R489
NC
C407
0.1uF
C404
0.1uF
VCC3.3
VPLL
LED_GRN/BLUE
R+4
CLK+4
+5V 3,4
DET_VGA 4
+5V
+5V
KEY2
U401
TSUM16AWK-LF
59
56
57
54
58
55
53
63
64
51
62
61
70
72
71
73
79
21
108
32
33
109
110
111
112
113
114
118
119
120
121
122
123
124
125
126
127
107
106
105
41 47
39
40
42
43
44
45
46
48
49
38 96 116
67 12
104
102
11
14 68
65
66
36
37
29
50 97
69
78
20
22
23
24
27
28
30
31
35
76
77
19
100
101
98
99
93
94
91
92
89
90
9
10
15
16
17
18
2
3
5
6
7
8
128
1
80
81
88
87
86
85
84
83
82
25
26
75
74
52 34 4 95 103 115 117 60
13
RIN0P
GIN 0P
SOGIN0
BIN0P
RIN0M
GIN 0M
BIN0M
HSYNC0
VSYNC 0
REXT
REFP
REFM
SDO
SCK
SCZ
SDI
GPIO_P27/PWM1
PWM1/GPIO_P25
NC/LVACKM/NC
XI N
XO U T
RA1P/LVA2P/R A2
RA1N/LVA2M/RA3
RA2P/LVA1P/R A4
RA2N/LVA1M/RA5
RA3P/LVA0P/R A6
RA3N/LVA0M/RA7
CLKAP/LVB3P/LHSY NC
CLKAN /LVB3M/LVSY N C
CLKBP/LVBCKP/LCK_OD D
CLKBN/LVBC KM/LDE
NC/LVB2P/NC
NC/LVB2M/NC
BB1P/LVB1P/BB2
BB1N/LVB1M/BB3
BB2P/LVB0P/BB4
BB2N/LVB0M/BB5
NC/LVAC KP/N C
GA3N/LVA3M/GA7
GA3P/LVA3P/GA6
GND GND
NC
NC
NC
NC
AVDD_ADC
NC
NC
NC
NC
GND GND GND
VDDP
VDDC
MOD E [ 1]
MOD E [ 0]
VCTRL
VDDP
VDDC
DDCA_SDA
DDCA_SCL
NC
NC
PWM0/GPIO_P26
AVDD_ADC
VDDC
GPIO_P15
PWM2/GPIO_P24
GPIO_P12
RSTN
GPIO_P00/SAR1
GPIO_P01/SAR2
GPIO_P06
GPIO_P07
GPIO_P13
GPIO_P14
GPIO_P16
GPIO_P11/I2C_MDA
GPIO_P10/I2C_MCL
RST
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
RB1P/NC/RB2
RB1N/NC/RB3
RB2P/NC/RB4
RB2N/NC/RB5
RB3P/NC/RB6
RB3N/NC/RB7
GB1P/NC /GB2
GB1N/NC/GB3
GB2P/NC /GB4
GB2N/NC/GB5
GB3P/NC /GB6
GB3N/NC/GB7
BB3P/NC/ BB6
BB3N/NC /BB7
NC
NC
NC
NC
NC
NC
NC
NC
NC
GPIO_P02/SAR3
GPIO_P03
GPIO_P22
GPIO_P23
AVDD_PLL
AVDD_MPLL
BYPASS
VDDP VDDP VDDP
VDDC
AVDD_ADC
GND
VCC3.3
PA9
R412
10KΩ1/10W
R406
10KΩ1/10W
C410
0.1uF
VCC3.3
VOLUME 7
OUT-L+
R405
22KΩ1/10W
VMPLL
R420 100Ω1/10W
PA1
R404
10KΩ1/10W
DDC_WP 4
VCC3.3
D428
NC
C401
0.1uF
B+4
C423 22pF
DDCD_SDA4
R-4
VCC3.3
+5VA
PA0
+
C408
10uF/50V
KEY _LEFT
Q401
PMBS3906
OUT-L- 7
R427 100Ω1/10W
U406
NC
1
2
3GND
RESET
VCC
VCC3.33
OUT-R-7OUT-L-
R487
10KΩ1/10W
G+4
R424
10KΩ1/10W
G2252-1-X-X-2-070313
F
SCALER
AOC (Top Victory) Electronics Co., Ltd.
C
57 Wedn esday , Marc h 14, 2007
Tit le
Size Document Number Rev
Dat e: Sheet of
VCC3.33
Cakor 8/9
PA[0..9]
R498
10KΩ1/10W
R486
NC
VMPLL
VCC3.3
Q403
PMBS3906
VCC1.83
R432 10KΩ1/10W
R423 4.7KΩ1/10W
R414
0Ω1/10W
VCTRL 3
R429 100Ω1/10W
D401
UDZS5.6B
R417
20 KOHM +-5% 1/10W
C402
0.1uF
R490
NC
C412
0.1uF
C409
0.1uF
OUT-R+7
AVDD
R475
3.9KΩ1/10W
DDCD_SCL4
adj_BACKLIGHT 3
VCC3.33
R495
NC
R418 100Ω1/10W
FB404
120Ω
Add by Cakor 8/8 2006
VPLL
PA3
C417
220nF16V
VCC3.3
+5V
KEY1
DDCA_SCL4
AUDIO_SD 7
KEY_MENU
C456
1uF/16V
GNDB4
VCC3.3
KEY_SEL
AUDIO_SD
R415
10KΩ1/10W
VDVI
X401
14.318MHz
1 2
R419 75Ω1/10W
VCC1.8
R488 100Ω1/10W
R484
10KΩ1/10W
C428
0.1uF
B-4
C424 0.1uF
FB401
120Ω
AVDD
R492
NC
PA[0. .9] 6
C455
NC
R480 10KΩ1/10W
RIN4
VDDC
OUT-R-
C406
0.1uF
R408
10KΩ1/10W
C405
0.1uF
PA5
C415
0.1uF
LVDS
KEY2
U402
SST25VF010A-33-4C-SAE
1
2
3
4 5
6
7
8
CE#
SO
WP#
VSS SI
SCK
HOLD#
VDD
on_BACKLIGHT 3
LED_GRN/BLUE
KEY_SEL
Modified by Cakor 8/11 2006
VCC3.3
CLK-4
R409
0Ω1/10W
HPD_CTRL 4
R413
10KΩ1/10W
GNDG4
C422
0.1uF
VCC3.33
CN403
CONN
2
4
6
8
10
12
14
16
1
3
5
7
9
11
13
15
R411 100Ω1/10W
C426
0.1uF
KEY1
Q402
PMBS3904
VCC3.3
C413
0.1uF
PA7
R491
NC
PA6
R426
10KΩ1/10W
HSYNC4
DDCA_SDA4
