HP StorageWorks NAS e7000 v2 User manual

integration
hp StorageWorks NAS e7000 v2
what’s new
• new server platform based on
HP ProLiant DL 80 G2
• snapshot technology enabled
by Columbia Data Products
Persistent Storage Manager
• new web interface for
easy management
key features and benefits
controllable
• NAS/SAN fusion: integrates file or
block data leads to increase efficiency
of the storage network
• manageable: provides a simpler
management of file or block level
data leads, decreasing costs for
storage management
• affordable: NAS/SAN fusion provides
a more efficient storage architecture
resilient
• reliable: delivers experience critical
a successful, affordable optimized
NAS solution
extensible
• extensive: produces low-end,
remote/workgroup solutions that
consolidate fusion for the enterprise
• optimi ed: offers the right NAS
solution for each customer; there’s
no need to settle for trade-offs
The HP StorageWorks NAS e7000 v2
fuses NAS and storage area network
(SAN) technologies. This innovative
combination provides tremendous gains
in scalability and flexibility.
The NAS e7000 provides the best return
on data center storage investment by
simplifying centralized storage and system
management, saving resources, time,
and lowering the total cost of ownership.
It limits the need for expensive and
complex integration and management
by connecting to the industry’s broadest
range of SAN arrays. The NAS e7000
provides support for: HP StorageWorks
Modular SAN Array 1000 (msa1000),
Virtual Array, Modular Array, Enterprise
Modular Array, Enterprise Virtual Array
(EVA), and Disk Array XP.
With virtually unlimited storage scalability,
the NAS e7000 grows as business needs
grow — without downtime and without
compromising performance. With no
single-point-of-failure, this NAS solution
ensures data is always available,
enabling business continuance through
cluster support, hardware redundancy
and replication.
The NAS e7000 provides the simplicity
of NAS with the scalability of SAN —
a fusion that sets new standards in
performance, flexibility and consolidated
management.
hp StorageWorks NAS e7000 v2

hp StorageWorks
NAS e7000 v2 management
technical specifications
file protocol support CIFS, NFS, NCP, AppleTalk, HTTP, FTP
OS support Microsoft®Windows®2000 Advanced Server
dimensions (HxWxD) 6.94 x 19 x 26. in/17.6 x 48.3 x 67.3 cm
weight 66 lbs/29.9 kg
cache 2 MB battery backed cache
data transfer method Fibre Channel
drives supported 10K RPM universal hot-pluggable 18 GB, 36 GB, 72 GB, 146 GB drives
input requirements • nominal line voltage; 100 to 120 VAC/200 to 240 VAC
• range line voltage; 113 W @ 110 VAC/112 W @ 220 VAC
• line frequency; 0 to 60 Hz
• typical input current; 12A (100 VAC), 9.8A (120 VAC), 4.9A (220 VAC)
maximum number of drives dependent upon SAN array
power 800W/800W (lowline/highline)
reliability features redundant OS, redundant power supplies, hot-plug PCI
relative humidity (non-condensing) • operating; 10% to 70%
• shipping; % to 9 %
temperature range • operating; 0 to 9 ° F/10 to 3 ° C
• shipping; -22 to 122° F/-30 to 0° C
maximum BTUs 4000 BTU
maximum wet bulb temperature 101.7° F/38.7° C
ordering information
product number product name description
322310-001, 421 NAS e7000 v2 NAS head for installation with the SAN array
what’s included
• 2 x 36GB SCSI HD; 2 x Intel®Xeon Processors MP; HP Integrated Lights-Out Standard Management (iLO) on system board; 2048 MB RAM;
HP Advanced Memory Protection; six, full length 64-bit/100 MHz PCI-X slots, 4 hot-pluggable; Integrated NC7770 PCI- X Gigabit Server
Adapter in a slot; Integrated Smart Array i Plus Controller (Dual Channel, Ultra3); battery-backed write cache enabler module
• HP supplied software: Windows Powered OS; HP StorageWorks NAS Data Copy; CDP Persistent Storage Manager; Rapid Launch; Web
Based Configuration Utility; Array Configuration Utility; HP Insight Manager (CIM) WBEM Win32; HP Insight Manager base console;
Smart Start 6.x software drivers; SmartStart 6.x CD (utilities only) and Management 6.x CD; Windows Powered OS drivers, including Array
Controller driver and HBA drivers; Tivoli TME, HP OpenView, IBM Netview, CA Unicenter, BMC agents installed for Enterprise (SNMP)
Management; NIC Teaming Drivers; HP UPS; APC UPS; Quick Restore CD
