•HPStorageWorksEnterprise Modular Library
Getting Started Poster
•DocumentationCD–User guide and Web
links for product registration, drivers, and
technicalsupport
•Warranty Booklet –Information about
accessing product warrantydetails
•Safety Booklet– Important productsafety
information
•Serial Cable– Used in conjunction with EMLUtil
diagnostic software
The EML is available in three HP rack configurations:
Model 103e –A 12U designconsisting of a base
module that contains a robot,an operator control
panel (OCP),load port, card cage (with alibrary
robotics controller andInterface Manager card), and
mounting space for up to fourtape drives.Tape drives
and Fibre Channel (FC) interface controllers are
ordered separately.
Model 103e bundlewith drives andmedia– Thesame
as the model described above with fourHP Ultrium tape
drives, FCinterface controller,media, cables, and
cleaning cartridgeincluded. The tape drives and
interface controller come preinstalled in the rack.
Model245e–A24Udesignconsisting of the
componentsin theModel 103e configuration,plus an
8Udrive expansion module withloadport,anda4U
cardcage expansion module.Tape drivesand FC
interface controllers are orderedseparately.
HP provideskits that enable you to expandthelibrary configuration to 42U (with 2U atthe topof the rack
reserved for customer use).Anadditionalpower distribution unit (PDU) andredundantpower supplies can be
added to the EML to provide failsafe power features.
Getting
Started
Model 103e
Model 245e
2
1
•HP StorageWorks Enterprise Modular Library
Getting Started Poster
•Documentation CD – User guide, Web links
for product registration, drivers, component
animations, and technical support information
•Warranty Booklet – Information about
accessing product warranty details
•Safety Booklet – Important product safety
information
•Serial Cable
The EML is available in three HP rack configurations:
Model 103e – A 12U design consisting of a base
module that contains a robot, an operator control
panel (OCP), load port, card cage (with a library
robotics controller and Interface Manager card), and
mounting space for up to four tape drives. Tape drives
and Fibre Channel (FC) interface controllers are
ordered separately.
Model 103e bundle with drives and media – The same
as the model described above with four HP Ultrium tape
drives, FC interface controller, media, cables, and
cleaning cartridge included. The tape drives and
interface controller come preinstalled in the rack.
Model 245e – A 24U design consisting of the
components in the Model 103e configuration, plus an
8U drive expansion module with load port, and a 4U
card cage expansion module. Tape drives and FC
interface controllers are ordered separately.
HP provides kits that enable you to expand the library configuration to 42U (with 2U at the top of the rack
reserved for customer use). An additional power distribution unit (PDU) and redundant power supplies can
be added to the EML to provide failsafe power features.
Getting
Started
Model 103e
Model 245e

1
2
3
4
56
9
10
11
12
12
13
14
15
7
8
Front and rear view Model 103e
1. Base module
2. Robotics unit (parked)
3. Viewing window
4. Operator control panel
5. Load port (5-cartridge capacity)
6. Redundant module power supply (optional)
7. Module primary power supply
8. Customer reserved space (2U)
9. Library main power switch
10. Library fans
11. Base module card cage
12. Tape drives
13. Cable management features
14. Extension bars (power strips)
15. Power distribution unit
3
3
9
1
2
3
569
10
11
7
48
Front and rear view Model 245e
1. See Model 103e figure
2. Tape drive expansion module
3. Card cage expansion module
4. Viewing window
5. Load port (10-cartridge capacity)
6. Module primary power supply
7. Redundant module power supply (optional)
8. Tape drives
9. Cable management features
10. Card cage module fans
11. Redundant card cage power supplies
4
Expansion Module: Tape Drive
The tape drive expansion module is an 8U chassis
containing 94 LTO slots.
The tape drive expansion module has three
windows on the front for viewing the robotic motion
inside the library. To the right is a 10-cartridge
configurable load port that holds two 5-cartridge
magazines.
On the back, the module contains one primary
power supply with a slot provided for another
optional redundant power supply. Refer to the
HP StorageWorks EML User Guide for additional
information and installation procedures.
5
1. Viewing windows
2. 10-cartridge capacity load port
3. Power supplies (redundant power supply shown)
4. Tape drives
5. Cable management features
1243 5

Component Installation
Expansion Module: Card Cage
The card cage expansion module is a 4U chassis
that contains 48 permanent LTO slots and space for
additional interface controllers. This module must be
located directly below the 8U tape drive expansion
module in a 24U library configuration.
The front of the chassis has one window for viewing
robotic motion inside the library. On the back, six
PCI card slots are available for additional e2400-
FC 2G interface controllers to expand the library
tape drive capacity. Refer to the HP StorageWorks
EML User Guide for additional information and
installation procedures.
6
7
NOTE: Refer to each component installation poster for specific installation information.
You may also refer to the HP StorageWorks EML User Guide for additional information
and installation procedures.
Verify that you have the following equipment and accessories available
before beginning the installation process. For a native Fibre Channel (FC)
environment, you need the following:
1. One or more Ultrium tape drives (these come preinstalled in one
configuration)
2. One HP StorageWorks e2400-FC 2G interface controller for every four
tape drives (comes preinstalled in one configuration)
3. Four FC drive cables and one Ethernet cable for each e2400-FC 2G
interface controller
NOTE: Only use Ethernet cables provided with the library. If the
library uses a LAN extension connector, plug into it, and not
directly to a card.
4. One Interface Manager card (preinstalled in EML)
5. One library robotics controller (preinstalled in EML)
6. One FC cable for each interface controller connection to a host or
switch (not included)
7. One Ethernet cable for an Interface Manager card connection to the
management station
8. One Ethernet cable for an Interface Manager card connection to the
library robotics controller (preinstalled)
9. Tape cartridges for appropriate tape drives
10. Power source
1. Viewing window
2. Blank facade
3. Card slot
4. Redundant power supply
5. Fans
1 2 4
35
1
2
3
4
5
6
7
8
9
10

Powering on the Library
Configuration through the
Operator Control Panel (OCP)
After all componenets have been installed and
cabled, power on the library.
a. Close and latch the library front door.
b. Open the back doors of the library rack and
press the main power switch to the 1(On)
position.
c. Close the library rack back doors.
The library requires several minutes to power on.
Nothing displays on the operator control panel
(OCP) for the first few minutes of this process.
The OCP is used to configure library settings before first use. After
the library is powered up, configure these settings as described in
the HP StorageWorks EML User Guide.
The first screen displayed after library initialization is the Home
screen. After the library status is determined (ready, warning, or
error), that status is displayed on the Home screen, and you can
touch the screen to access other functional and operational screens.
After touching the Home screen, you are
presented with a screen containing a status
bar to the left of an HP logo, two rows of
tabs, and an area for detailed screen
information in the center.
1. Top-level menu tabs
2. Status bar
3. HP Logo
4. Detailed screen information area
5. Navigation tabs
8
9
Select anywhere on the screen to continue.
Ready
Ready
Open
Help BackPage DownPage Up
Configuration Operation Support
1
4
5
2 3

OCP icons
Critical error—A condition when a
component failure makes the library
inoperable.
Warning—A condition when a component
failure degrades library activity, but the
library is still operable.
Ready—The library is online and ready for
operation.
Thumbtack out—Indicates that the screen
is eligible to be selected for display after a
period of inactivity.
Thumbtack in—Indicates the screen has
been selected for display after a period of
inactivity. Only one screen at a time can
be thumbtacked.
Item selection—Indicates that the item can
be selected from a menu list.
Password required—Denotes that a
password is required to access this feature.
After you install and configure the library, complete the following setup tasks.
Refer to the HP StorageWorks EML User Guide for more information.
Change Password
The library ships with a null password.
Passwords must be set to exactly eight
characters consisting of the numbers
0 through 9 and the period character.
Configure Load Ports
This GUI shows the number of installed
load ports and enables you to toggle
between using each as a load port or for
tape slots. Configure it as a Load Port to
move tapes in and out of the library.
Configure as Slots to increase the number
of storage slots in the library. Changing a
load port configuration will cause a library
reboot.
Change Network Settings
This configures the network settings for the
Interface Manager card, which can be set
automatically with DHCP (the default), or
manually with a static IP address. Use the
Address Config: button to toggle between
these two options. If you are setting the
network addresses manually, touch each
address element separately to set the
network configuration.
Configure Barcode Reporting Formats
This defines how bar codes are displayed
on the OCP and sent to the host. Bar code
reporting can be configued as 6 to 8
characters and left or right aligned. If 6
characters with left alignment is chosen,
any characters after the six are truncated.
With 6 characters and right alignment, only
the last six characters are shown with the
beginning characters truncated.
Configure Reserve Slots
Up to nine slots can be reserved for special
purposes, such as cleaning tapes. The
default is none. Select the number you want
to reserve and press Save.
Configure Inventory Mode
This allows you to require bar codes on
tape cartridges, or to make them optional.
Requiring bar codes significantly improves
inventory time.
10

Navigating the GUI Menu
11
Home Screen
Status Screen
Support Screen
Identity Screen
HP Support Info
Unlock Load Ports
Unlock Door
Reboot Library
Media Operations
Run Admin Tests
Service Menu >
Health Summary >
Component Status >
Event Log Type
Selection
View Library
Inventory
Library Robotics >
- Library Status
- Robotics Status
- Power Supply Status
- Power Supply 1-6
Load Ports
- Load Ports 1-4
Drives
- Drive 1-16
Interface Controllers
- Interface Controller 1-4
Interface Manager
Change Password
Configure Load Ports
Change Network Settings
Configure Barcode
Reporting Formats >
- Format for front ppanel
reporting
- Format for host
reporting
Configure Reserve Slots
Configure Inventory Mode
Reset Library Robotics
Defaults
Cancel Inventory Prompt
Move Tape
Operator Control Panel
- Align Touch Screen
- Panel Colors
- Panel Pixel Test
- Panel Firmware Version
- Turn Backlight Off
Run Demo
Library and Robotics Status >
- Library Status
- Robotics Status
- Drive Odometers
Individual Drive Status
All Drive Summary
Interface Controller Status >
- Interface Controller 1-4
Interface Manager Status
Configuration
Screen Operations Screen
Library
Configuration >
Contact
Information
Display Library
Time
Adjust Screen
Contrast

Configuring and using
HP StorageWorks
Command View TL
Installing HP StorageWorks
Command View TL
1. Find the Command View Media Kit in your
library accessory kit.
2. Insert the Command View TL software CD into
the CD-ROM drive of the designated
management station.
3. If autorun is disabled on the CD-ROM drive,
locate and double-click setup.exe on the CD.
4. Follow the instructions on the screen to complete
the installation.
If you need to stop Command View TL from running
on the management station, use the Services applet
that is included with Windows.
To access the Services applet:
1. Select Start > Settings > Control Panel >
Administrative Tools > Services and locate the
Command View TL service in the list.
2. Use the Services applet to start and stop services,
and to set whether the service is started
automatically when the computer is booted.
NOTE: See the Windows online help for more
information. See the HP StorageWorks Interface
Manager and Command View TL User Guide
for detailed information on using Command
View TL
12
Getting help
• HP product information:
http://www.hp.com/go/storage
• HP technical support and phone numbers:
http://www.hp.com/support
• HP StorageWorks Library and Tape Tools
(L&TT) diagnostic software:
http://www.hp.com/support/tapetools
See the HP StorageWorks Interface Manager and
Command View TL User Guide for detailed information
on Command View TL. This guide is available on
the Documentation CD found in the Command View
media bundle in your library accessory kit, and is
also available at http://www.hp.com/support/cvtl/.
13

© Copyright 2005 Hewlett-Packard Development Company, L.P.
First Edition (May 2005)
Part Number: AD560-96006
*AD560-96006*
AD560-96006
