HP BladeSystem c-Class
Solutions Overview
Abstract
This document describes setup requirements and procedures for HP BladeSystem c-
Class servers. HP assumes you are qualified in the servicing of
computer equipment and trained in recognizing hazards in products with hazardous energy levels.
Part Number: 413339-006
March 2012
Edition: 6

© Copyright 2006, 2012 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall
not be liable for technical or editorial errors or omissions contained herein.

Contents 3
Contents
Overview..................................................................................................................................... 4
Document overview ......................................................................................................................................4
Before you begin .......................................................................................................................... 5
Researching and developing a solution ..........................................................................................................5
Unpacking the system...................................................................................................................................5
Compiling the documentation........................................................................................................................5
Determining power and cooling configurations ...............................................................................................6
Planning device and interconnect mappings....................................................................................................6
Hardware installation.................................................................................................................... 8
Locating hardware instructions.......................................................................................................................8
Installing the enclosure..................................................................................................................................8
Installing the components ..............................................................................................................................8
Connecting the Onboard Administrator module cabling...................................................................................8
Installing the interconnect modules and connecting cables................................................................................9
Powering up the enclosure ............................................................................................................................9
Enclosure configuration ............................................................................................................... 10
Locating configuration instructions................................................................................................................10
Running the Insight Display wizard ..............................................................................................................10
Running the Onboard Administrator First Time Setup wizard...........................................................................10
Configuration............................................................................................................................. 11
Configuring interconnect modules ................................................................................................................11
Firmware ................................................................................................................................... 12
Managing firmware ...................................................................................................................................12
Operating systems ...................................................................................................................... 13
Preinstalled operating systems .....................................................................................................................13
Choosing a supported operating system.......................................................................................................13
Installing an operating system using Intelligent Provisioning ............................................................................13
Management software................................................................................................................. 14
Deploying the management software............................................................................................................14
Discovering and provisioning new devices....................................................................................................14
For more information................................................................................................................... 15
Additional information................................................................................................................................15
Documentation feedback ............................................................................................................. 16

Overview 4
Overview
Document overview
This document provides an overview of the complete installation process of an HP BladeSystem c-Class
solution.
In this document, the term "blade" can include server blades, storage blades, or workstation blades.

Before you begin 5
Before you begin
Researching and developing a solution
To begin researching the HP BladeSystem solution, see the HP BladeSystem technical resources website
(http://www.hp.com/go/bladesystem/documentation). The website includes white papers, technical
briefs, instructions, best practices, helpful hints, useful links, and suggestions for setting up and configuring
the solution.
The website includes the following tabs:
•Planning
Use this tab to plan and learn about the information and tools required to select the optimal
BladeSystem solution.
•Installing
This tab provides procedures for completing a quick installation or for executing a comprehensive
installation of your BladeSystem solution. This section also includes detailed port mapping information.
•Maintenance and Troubleshooting
Maintenance and troubleshooting information are provided. This tab also includes useful links to HP
BladeSystem c-Class firmware and software upgrades and driver downloads.
•Functionality & Value
Learn about the functionality and value of HP BladeSystem technologies and the value of BladeSystem
solutions.
Unpacking the system
The enclosure and components ship with hard copy installation instructions. When unpacking, be sure to
locate all hard copy installation instructions.
Compiling the documentation
The documentation, while delivered individually and in various formats, works as a system. Consult these
documents before attempting installation. These documents provide required important safety information
and decision-making steps for configuration.
•The enclosed documentation includes the following:
oThe printed rack template
oThis document
oHP BladeSystem c3000 or c7000 Enclosure Quick Setup Instructions
oHP BladeSystem c3000 or c7000 Enclosure Documentation CD, including safety information, the
HP BladeSystem c3000 or c7000 Enclosure Setup and Installation Guide, and other useful links

Before you begin 6
•The following items are available on the HP BladeSystem documentation website
(http://www.hp.com/go/oa):
oUseful links to BladeSystem technical information such as Quick Specs and Customer advisories
oThe installation checklist, used to collect information needed for installation and configuration
oUser documentation, such as user guides, quick install cards, and troubleshooting information
oCopies of all the material included with the enclosure
oNumerous white papers and technical briefs on various BladeSystem components.
•For detailed information on ProLiant Gen8 servers and software, see the HP ProLiant Gen8 Server
Information Library (http://www.hp.com/go/proliantgen8/docs).
•For the latest software and firmware drivers, see the HP Service Pack for ProLiant (SPP) website
(http://www.hp.com/go/spp/download).
Determining power and cooling configurations
Validate power and cooling requirements, based on location and installed components.
Planning device and interconnect mappings
•Onboard Administrator to iLO port mappings
The blade iLO ports and interconnect module ports can obtain IP addresses on the management
network in three ways: a DHCP server, static IP address assignment, or Enclosure Bay IP Address
(EBIPA). In addition, the iLO Management Engine is available on Gen8 server blades.
For more information about Onboard Administrator, see the HP BladeSystem Onboard Administrator
User Guide on the HP website (http://www.hp.com/go/oa). For more information about the iLO
Management Engine, see the iLO Management Engine Information Library on the HP website
(http://www.hp.com/go/ilomgmtengine/docs).
•Mezzanine slot to interconnect bay mappings

Before you begin 7
Blade mezzanine slots correspond to specific interconnect bays. Plan mezzanine-to-interconnect
mapping before installing interconnect modules and blade mezzanine options.
For more information, see the appropriate HP BladeSystem c3000 or c7000 Enclosure setup and
installation guide on the HP website (http://www.hp.com/go/bladesystem/documentation).
•Interconnect bay to physical cable mappings
Determine and acquire the appropriate number of cables, cable types, and lengths for the interconnect
devices being installed.
For more information, see the documentation that ships with the interconnect devices.

Hardware installation 8
Hardware installation
Locating hardware instructions
For detailed instructions, see the HP BladeSystem c3000 or c7000 Enclosure Quick Setup Instructions, rack
template, and applicable installation instructions on the HP website
(http://www.hp.com/go/bladesystem/documentation).
Installing the enclosure
The enclosure can be installed either in a rack or rack-free environment. For rack installations, install the rack
rails, and then install the enclosure and other components.
Installing the components
Before installing front or rear components into the enclosure, review enclosure bay numbering for each
component.
Install any options such as processor, memory, mezzanine card, or hard drive, into each blade.
Based on the total number ordered and the planned configuration, install the following components:
•Power supplies
•Blades
•Active Cool fans
•Onboard Administrator modules
For installation instructions, see the HP BladeSystem c3000 or c7000 Enclosure Setup and Installation Guide
on the HP website (http://www.hp.com/go/bladesystem/documentation).
Connecting the Onboard Administrator module
cabling
Use the appropriate cables to connect each installed Onboard Administrator module to the external
connections. The connectors on the Onboard Administrator module provide a connection to the iLO
management network and the capability to link multiple enclosures.
IMPORTANT: For proper management of enclosure devices there must be an Ethernet
connection from the Onboard Administrator module to the external management network. For
information on Onboard Administrator module cabling, see the HP BladeSystem Onboard
Administrator User Guide.

Hardware installation 9
Installing the interconnect modules and connecting
cables
Install the interconnects based on the type of fabric in the configuration and the planned installation location
of each mezzanine card. Use the appropriate cables to connect each installed interconnect module to the
network.
Powering up the enclosure
Connect the AC or DC power cables, depending on the power configuration.
When the circuit breakers are powered, the enclosure and HP BladeSystem Insight Display have power. By
default, each installed component also powers up. Examine the HP BladeSystem Insight Display for any
errors that might prevent installed components from powering up.

Enclosure configuration 10
Enclosure configuration
Locating configuration instructions
For specific instructions on configuring your enclosure, see the HP BladeSystem Onboard Administrator User
Guide on the HP website (http://www.hp.com/go/oa).
Running the Insight Display wizard
When the enclosure is powered up for the first time, the HP BladeSystem Insight Display launches an
installation wizard to guide the rack technician through the initial configuration process.
Be sure to have the Installation Checklist available to record important information, such as the Onboard
Administrator IP address, gathered while running the installation wizard. By default, the Onboard
Administrator obtains an IP address using DHCP. Read the Insight Display and write the IP address for the
active and standby Onboard Administrator on the checklist. This IP address is needed for remote connection
and subsequent setup with a browser. If DHCP is not used, a static IP address can be configured on the Insight
Display Settings screen. For specific instructions, see the HP BladeSystem Onboard Administrator User Guide
on the HP website (http://www.hp.com/go/oa).
The Insight Display verifies that no installation or configuration errors exist and indicates configuration check
progress. If configuration errors are indicated, then follow the on-screen instructions to correct the problem.
When the screen display stays green, no configuration errors or device failures exist and hardware
installation is complete.
Running the Onboard Administrator First Time Setup
wizard
After all hardware is installed and the hardware configuration has been verified in the Insight Display, use
one of the following methods to complete the enclosure configuration setup:
•Use the Insight Display to determine the address received by DHCP, and then use the Onboard
Administrator First Time Setup Wizard to complete the installation and configuration at the assigned
address.
•If no DHCP server is present on the customer management network, do one of the following:
oUse the Insight Display to set the address, and then use the Onboard Administrator First Time Setup
Wizard to complete the installation and configuration at the assigned address.
oUse the Onboard Administrator First Time Setup Wizard or the CLI to configure EBIPA and assign IP
addresses for iLO and interconnect management ports. This method simplifies the required setup for
interconnect management network settings.
•Use the Insight Display to set the IP address and complete the Onboard Administrator First Time Setup
Wizard from the Insight Display. This method enables configuration without the use of an external
browser.

Configuration 11
Configuration
Configuring interconnect modules
Each interconnect module ships with a default configuration. For customized configuration or advanced port
mapping, see the installation instructions that ship with each interconnect module.
To configure HP Virtual Connect modules, see the HP Virtual Connect for c-Class BladeSystem Setup and
Installation Guide on the HP website (http://www.hp.com/go/bladesystem/documentation).

Firmware 12
Firmware
Managing firmware
To determine recommended updates and download the latest firmware, see the HP Service Pack for ProLiant
(SPP) website (http://www.hp.com/go/spp/download).
SPP is a release set that contains a comprehensive collection of firmware and system software components,
all tested together as a single solution stack for HP ProLiant servers, their options, BladeSystem enclosures,
and limited HP external storage.
SPP has several key features for updating HP ProLiant servers. Using HP SUM as the deployment tool, SPP can
be used in an online mode on a Windows or Linux hosted operating system, or in an offline mode where the
server is booted to the ISO so that the server can be updated automatically with no user interaction or
updated in interactive mode.
For more information or to download SPP, see the HP website (http://www.hp.com/go/spp).
If you are operating the enclosure in a VMware ESX environment, use an offline utility such as ROMPaq to
update and verify the firmware. The ROMPaq utility checks the system and provides a choice (if more than
one exists) of available firmware revisions. For more information about the ROMPaq utility, see the HP
website (http://www.hp.com/support).

Operating systems 13
Operating systems
Preinstalled operating systems
If the blade has an operating system that is preinstalled, proceed to "Management software (on page 14)."
Choosing a supported operating system
For the latest operating system support information, see the HP website
(http://www.hp.com/go/supportos).
Installing an operating system using Intelligent
Provisioning
Intelligent Provisioning is a single-server deployment tool embedded in HP ProLiant Gen8 servers. Intelligent
Provisioning prepares the system for installing leading operating system software and automatically
integrating optimized ProLiant server support software from SPP.
To install an operating system on a single Gen8 server:
1. If needed, access Intelligent Provisioning by rebooting the server and pressing F10.
2. If you are running Intelligent Provisioning for the first time, in the application, complete step 1, Set
Intelligent Provisioning preferences and step 2, Activation.
3. From the Home screen, click Perform Maintenance, and then click Firmware Update.
4. Ensure the latest drivers are available for installation. From the list of firmware, select Intelligent
Provisioning Software, and then click Update. If the check box is not selected, the latest drivers are
already installed.
5. From the Home screen, click Configure and Install.
6. Follow the on-screen prompts to finish the installation.
To update your drivers and system software:
Intelligent Provisioning automatically integrates optimized ProLiant server support software from the SPP. For
more information on using SPP, see the HP Service Pack for ProLiant User Guide on the Documentation CD
or the SPP Information Library (http://www.hp.com/go/spp/documentation).

Management software 14
Management software
Deploying the management software
The HP BladeSystem c3000 or c7000 Enclosure ships with the Insight Management DVD, an integrated suite
of software used to simplify HP BladeSystem provisioning and management.
Use the wizard-based installer to configure and license HP Systems Insight Manager (HP SIM) and Insight
Control software rapidly and consistently, which reduces manual procedures and enables faster production
deployment of HP BladeSystem servers.
If previous enclosures have been installed, you do not have to deploy the management software. New
devices are discovered and can be managed by the previously installed management system.
Before deploying the management software and creating provisioning policies:
•Complete the Insight Management Preinstallation Checklist
(http://www.hp.com/go/insightmanagement/docs).
•Be sure that the HP BladeSystem c3000 or c7000 Enclosure, switches, and associated storage
resources are configured.
•Verify that a supported operating system is installed. If the operating system has not been installed, see
the operating system installation documentation.
Launch the Insight Management DVD and use the installation wizard to deploy and configure HP Systems
Insight Manager (HP SIM) and Insight Control software. After installation completes, log in to HP SIM using
the credentials supplied during the installation process, and complete configuration.
For more information, see the HP Insight Control Management Software portfolio at the HP website
(http://www.hp.com/go/insightcontrol).
Discovering and provisioning new devices
Use HP SIM to discover HP BladeSystem resources and view those resources through the integrated
BladeSystem manager. For further information, see the HP Insight Management Quick Installation Guide on
the HP website (http://www.hp.com/go/insightmanagement/docs).

For more information 15
For more information
Additional information
The HP ProLiant Gen8 Troubleshooting Guide, Volume I: Troubleshooting provides procedures for resolving
common problems and comprehensive courses of action for fault isolation and identification, issue resolution,
and software maintenance on ProLiant servers and server blades. The HP ProLiant Gen8 Troubleshooting
Guide, Volume II: Error Messages provides a list of error messages and information to assist with interpreting
and resolving error messages on ProLiant servers and server blades. The documents are on the
Documentation CD and on the HP website (http://www.hp.com/go/proliantgen8/docs).
For definitions of the acronyms used in this document, refer to "Acronyms and abbreviations" on the
Documentation CD.
To download the latest user documentation and drivers, including safety and regulatory notices, see the HP
website (http://www.hp.com/support).

Documentation feedback 16
Documentation feedback
HP is committed to providing documentation that meets your needs. To help us improve the documentation,
send any errors, suggestions, or comments to Documentation Feedback (mailto:[email protected]).
Include the document title and part number, version number, or the URL when submitting your feedback.
