HP ProLiant DL360e Generation 8 User instructions

Essential features packed in a 1U footprint to deliver the key elements for file and print and single application workloads. Value,
performance, flexible storage, enhanced management and superior serviceability makes the DL360e the 2P system right-sized for both
SMB and enterprise customers.
Front View: Rear View:
1. Access Panel 1. PCIe 3.0 Full-height/half -length (250mm) x16 expansion
slot
2. Redundant Hot Plug Power Supplies (upgradeable option) 2. PCIe 2.0 Low Profile x8 expansion slot
3. Removable Riser Cage assembly for 1 x PCIe 3.0 x16 + 1 x
PCIe 2.0 x8
3. Power supply bay 1 (Primary Power Supply)
4. 12 DIMM slots: DDR3 Registered (RDIMM), Load Reduced
(LRDIMM) or Unbuffered (UDIMM) memory
4. Power supply bay 2 (Shown populated: Optional)
5. Removable hot-plug fan modules for easy serviceability 5. Unit ID LED/button
6. Optical Disk Drive Bay 6. HP Ethernet 1Gb 4-port 366i Adapter
7. Video connector 7. Serial connector
8. USB Connectors 8. Video connector
9. Unit ID LED/button 9. USB connectors
10. Health LED 10. iLO connector
11. NIC activity LED 11. USB connectors
12. Power On/Standby button
13. Drive Bays
14. Up to two Intel® E5-2400/ E5-2400v2 Series processors
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Overview
DA - 14327 North America — Version 36 — January 22, 2014 Page 1

NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory
Integrated Models" section.
Processor
One of the following
depending on Model
Entry Processors - E5-2400v2 series Processors
NOTE: All support up to 1333MHz DDR3 memory speeds.
Intel® Xeon® E5-2407v2(2.4GHz/4-core/10MB/6.4GT/s QPI/80W, DDR3-1333,)
Intel® Xeon® E5-2403v2(1.8GHz/4-core/10MB/6.4GTs QPI/80W, DDR3-1333,)
Base Processors - E5-2400v2 series Processors
NOTE: All support up to 1600MHz DDR3 memory speeds.
Intel® Xeon® E5-2430v2(2.5GHz/6-core/15MB/7.2GT/s QPI/80W, DDR3-1600,HT, Turbo2- 3/3/4/4/5/5)
Turbo
Intel® Xeon® E5-2430Lv2(2.4GHz/6-core/15MB/7.2GT/s QPI/60W, DDR3-1600,HT, Turbo2- 3/3/4/4/5/5)
Turbo
Intel® Xeon® E5-2420v2(2.2GHz/6-core/15MB/7.2GT/s QPI/80W, DDR3-1600,HT, Turbo2- 3/3/4/4/5/5)
Turbo
Intel® Xeon® E5-2440v2(1.9GHz/8-core/20MB/7.2GT/s QPI/95W, DDR3-1600,HT, Turbo2- 3/3/4/4/5/5)
Turbo
Performance Processors - E5-2400v2 series Processors
NOTE: All support up to 1600MHz DDR3 memory speeds.
Intel® Xeon® E5-2450v2(2.5GHz/8-core/20MB/8.0GT/s QPI/95W, DDR3-1600,HT, Turbo2-
5/5/6/6/7/7/8/8) Turbo +
Intel® Xeon® E5-2470v2(2.4GHz/10-core/25MB/8.0GT/s QPI/95W, DDR3-1600,HT, Turbo2-
5/5/6/6/7/7/8/8) Turbo+
Intel® Xeon® E5-2450Lv2(1.7GHz/10-core/25MB/8.0GT/s QPI/60W, DDR3-1600, HT, Turbo2-
5/5/6/6/7/7/8/8) Turbo+
Entry Processors - E5-2400 series Processors
NOTE: All support up to 1066MHz DDR3 memory speeds.
Intel® Xeon® E5-2407(2.2GHz/4 -core/10MB/6.4GT-s QPI/80W, DDR3-1066)
Intel® Xeon® E5-2403(1.8GHz/4 -core/10MB/6.4GT-s QPI/80W, DDR3-1066)
Base Processors - E5-2400 series Processors
NOTE: All support up to 1333MHz DDR3 memory speeds.
Intel® Xeon® E5-2440(2.4GHz/6 -core/15MB/7.2GT-s QPI/95W, DDR3-1333, HT, Turbo2- 3/3/4/4/5/5)
Turbo
Intel® Xeon® E5-2430(2.2GHz/6 -core/15MB/7.2GT-s QPI/95W, DDR3-1333, HT,Turbo2- 3/3/4/4/5/5)
Turbo
Intel® Xeon® E5-2430L(2.0GHz/6 -core/15MB/7.2GT-s QPI/60W, DDR3-1333,HT, Turbo2- 3/3/4/4/5/5)
Turbo
Intel® Xeon® E5-2420(1.9GHz/6 -core/15MB/7.2GT/s QPI/95W, DDR3-1333, HT, Turbo2- 3/3/4/4/5/5)
Turbo
Performance Processors - E5-2400 series Processors
NOTE: All support up to 1600MHz DDR3 memory speeds.
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Standard Features
DA - 14327 North America — Version 36 — January 22, 2014 Page 2

Intel® Xeon® E5-2470(2.3GHz/8-core/20MB/8.0GT-s QPI/95W, DDR3-1600,HT, Turbo2- 5/5/6/6/7/7/8/8)
Turbo+
Intel® Xeon® E5-2450(2.1GHz/8 -core/20MB/8.0GT-s QPI/95W, DDR3-1600,HT, Turbo2- 5/5/6/6/7/7/8/8)
Turbo+
Intel® Xeon® E5-2450L(1.8GHz/8 -core/20MB/8.0GT-s QPI/70W, DDR3-1600,HT, Turbo2-
2/2/3/3/4/4/5/5) Turbo+
Cache Memory
One of the following
depending on Model
25MB (1x25MB) Level 3 cache
NOTE: for Ten-core processors.
20MB (1 x 20MB) Level 3 cache
NOTE: for Eight-core processors.
15MB (1 x 15MB) Level 3 cache
NOTE: For Six-core processors
10MB (1 x 10MB) Level 3 cache
NOTE: For Quad-core processors.
NOTE: All processor models above list the L3 Cache associated with that particular processor.
Chipset Intel® C600 Series Chipset
Intel® E5-2400 Processor Family
Intel® E5-2400v2 Processor Family
NOTE: For more information regarding Intel® chipsets, please see the following URL:
http://www.intel.com/products/server/chipsets/ .
Upgradeability
One of the following
depending on Model
Upgradeable to 2 processors (16 Cores)
NOTE: Processor upgrade available from Intel® Xeon® Processors E5-2400 to E5-2400 v2. Please contact
HP Technology Sales ( http://www.hp.com/support ), your local HP Re-seller, or reference the following
Customer Advisory: ProLiant Servers-Instructions for Upgrading an HP ProLiant Gen8 Server from an Intel
Xeon Processor E5-2400 to an Intel Xeon Processor E5-2400v2 , regarding critical details before
upgrading. An explanation of requirements and limitations are provided.
On System Management
Chipset
One of the following
depending on Model
HP iLO (Firmware: HP iLO 4)
NOTE: For more information, visit: http://www.hp.com/go/ilo .
Memory Protection
One of the following
depending on Model
Advanced ECC
Online Spare
Lock-step
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Standard Features
DA - 14327 North America — Version 36 — January 22, 2014 Page 3

Memory
One of the following
depending on Model
Type HP SmartMemory
DDR3 Load Reduced (LRDIMM), Registered (RDIMM) or Unbuffered (UDIMM)
Standard (Entry Models -
SAS)
4GB (1 x 4GB) Registered DIMMs PC3L-10600R (1333MHz) or 4GB (1 x 4GB)
Registered DIMMs PC3L-12800R (1600MHz)
Standard (Entry Models -
SATA)
4GB (1 x 4GB) Registered DIMMs PC3L-10600R (1333MHz) or 4GB (1 x 4GB)
Registered DIMMs PC3L-12800R (1600MHz)
Standard (Base Models) 8GB (2 x 4GB) Registered DIMMs PC3L-10600R (1333MHz) or 8GB (1 x 8GB)
Registered DIMMs PC3L-12800R (1600MHz)
Maximum Capacity
(LRDIMM)
384GB (12 x 32GB LRDIMM @1333MHz)
Maximum Capacity
(RDIMM)
192GB (12 x 16GB RDIMM @1600MHz or 1333MHz)
Maximum Capacity
(UDIMM)
96GB (12 x 8GB UDIMM @1333MHz)
NOTE: HP memory from previous generation servers are not fully compatible with the HP ProLiant DL360e
Gen8 Server.
NOTE: To realize the performance memory capabilities listed in this document, HP SmartMemory is
required. For additional information, please see the HP SmartMemory QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/14225_div/14225_div.html
NOTE: If only one processor is installed, only 6 DIMM slots are available. When populating with two
processors 12 DIMM slots are available
NOTE: Depending on the memory configuration and processor model, the memory speed may run at
1600MHz, 1333MHz, or 1066MHz. Please see Memory Population Table or the Online Memory
Configuration Tool at: www.hp.com/go/ddr3memory-configurator .
Network Controller HP Ethernet 1Gb 4-port 366i Adapter
NOTE: The HP ProLiant DL360e Gen8 server offers the customer a quad-port NIC standard with the option
to upgrade with a variety of networking options.
Expansion Slots Expansion
Slots #
Technology Bus
Width *
Connector
Width
Form Factor Notes
1 PCIe 3.0 x16 x16 Full-height, half-
length slot
(250mm)
2 PCIe 2.0 x4 x8 Low profile slot
*Indicates the number of physical electrical lanes running to the connector.
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Standard Features
DA - 14327 North America — Version 36 — January 22, 2014 Page 4

HP Server ROM HP ROM (Read Only Memory) is now digitally signed using HP's Corporate Signing Service. This signature is
verified before the flash process starts, reducing accidental programming and preventing malicious efforts
to corrupt system ROM.
HP ROM provides for essential initialization and validation of hardware components before control is
passed to the customer-installed operating system. The ROM also provides the capability of booting from
various fixed media (HDD, CD-ROM) and removable media (USB), to continue operation to the operating
system.
HP ROM performs very early configuration of the video controller, to allow monitoring of initialization
progress via an attached monitor. If configuration or hardware errors are discovered during this early
phase of hardware initialization, suitable messages are now displayed on the connected monitor.
Additionally, these configuration or hardware errors are logged to the Integrated Management Log (IML) to
assist in diagnosis.
HP's ProLiant ROM is used to configure the following:
Processor and chipset status registers
System memory, memory map, and memory initialization
System hardware configuration (Integrated PCI devices and optional PCIe cards).
Customer-specific BIOS configuration (using the HP ROM-Based Setup Utility (RBSU).
NOTE: For further information, please refer to HP's RBSU (ROM based setup utility) user guide:
www.hp.com/support/rbsu .
Storage Controller
One of the following
depending on Model
Entry Model - SAS HP Dynamic Smart Array B320i Controller
NOTE: Provides support for up to 8 SAS or SATA drives and includes SAS
license key.
Entry Model - SATA HP Dynamic Smart Array B120i Controller
NOTE: Provides data transmission speeds up to 3Gb/s.
Base Models HP Dynamic Smart Array B320i/512MB FBWC Controller
NOTE: Provides support for up to 8 SAS or SATA drives and includes SAS
license key.
Performance Models HP Smart Array P420/1GB FBWC Controller (RAID 0/1/1+0/5/5+0+6/6+0)
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Standard Features
DA - 14327 North America — Version 36 — January 22, 2014 Page 5

Internal Storage Devices
One of the following
depending on Model
Diskette Drive None
Optical Drive Optional
DVD-ROM, DVD-RW
NOTE: This option available with all 8SFF or 4LFF drive bay models.
Hard Drives None ship standard
Hard Drive Bays 8 SFF drive bays total with Optical drive bay
4 LFF drive bays total with Optical drive bay.
NOTE: HP ProLiant DL360e Gen8 server offers both SFF and LFF versions in
CTO. The Optical Drive bay is available with both models.
NOTE: Drive cage changes are not supported.
NOTE: All Pre-configured Models come populated with some hard drive blanks
installed. Should the customer need additional hard drive blanks, they can
order more using either P/N 666987-B21: HP SFF Gen8 Hard Drive Blank Kit or
P/N 666986-B21: HP LFF Gen8 Hard Drive Blank Kit. These part numbers for
single HDD blanks below are also provided should the customer require
replacement HDD blanks for their server.
Maximum Internal
Storage
One of the following
depending on Model
Hot Plug SFF SAS 9.6TB 8 x 1.2TB
Hot Plug SFF SATA 8.0TB 8 x 1TB
Hot Plug LFF SAS 16.0TB 4 x 4TB
Hot Plug LFF SATA 16.0TB 4 x 4TB
Hot Plug SFF SAS SSD 6.4TB 8 x 800GB
Hot Plug SFF SATA SSD 6.4TB 8 x 800GB
Hot Plug LFF SATA SSD 3.2TB 4 x 800GB
Interfaces Serial 1
Video 1 Front Mini-Video connector/ 1 Rear standard video (not active
simultaneously)
NOTE: Mini-video connector requires Front Video Adapter Kit (PN 655915-
B21).
HP iLO Remote
Management Network Port
1Gb Dedicated
SD slot 1 Internal secure
NOTE: The SD slot is not a hot-pluggable device. Customers should not
attempt to plug an SD card into the SD slot while the server is powered.
USB 2.0 Ports 7 total: 4 rear, 2 front, 1 internal (secure)
Network Ports 4x1GbE ports
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Standard Features
DA - 14327 North America — Version 36 — January 22, 2014 Page 6

Industry Standard
Compliance
ACPI 2.0b Compliant
PCIe 3.0
PXE Support
WOL Support
Microsoft® Logo certifications
USB 2.0 Compliant
Server Power Cords All Pre-configured Models servers ship with a high voltage server to PDU power cord.
NOTE: HP ProLiant DL servers no longer ship standard with a 12-foot NEMA 5-15P to C13 power cord that
connects to 110V US wall outlets in a home or office. ProLiant DL servers are primarily connected to power
distribution units (PDUs) in data center racks and now ship standard with a PDU 6-foot C-14 to C13 power
cord (A0K02A). If a user wishes to power a ProLiant DL server using a 110V receptacle (NEMA-15), the 6-
foot NEMA 5-15 to C13 power cord must be ordered separately (AF556A). See Power Cords section for
Power Cord options.
Power Specifications To review typical system power ratings use the HP Power Advisor which is available via the online tool
located at URL: www.hp.com/go/hppoweradvisor .
NOTE: Power Specification and Technical Content for supported power supplies can be found at:
http://h18000.www1.hp.com/products/quickspecs/14209_div/14209_div.html
Common Slot Power
Supply
NOTE: Mixing of power supplies in the same server is not supported. All power supplies inside a server
must be exactly the same model. Mixing Gold, Platinum, and Platinum Plus certified power supplies is not
supported.
HP's Common Slot (CS) power supplies allow for commonality of power supplies across a wide range of
ProLiant and Integrity servers, as well as HP Storage solutions, and are designed to provide the highest
power supply efficiency without degrading system performance. HP CS power supplies are tested by the
Electric Power Research Institute (EPRI) and certified through the ECOS 80 Plus power supply program. HP
CS power supply options provide efficiency ratings of up to 94% (80 Plus Platinum) and are available in
three power output options - 460W, 750W, and 1200W - allowing the customer to "right-size" a power
supply for their specific server configuration. All HP Common Slot power sources are UL, CE Mark
Compliant, hot-plug and support redundant configurations.
NOTE: Mixing of power supplies in the same server is not supported. All power supplies must be of the
same output and efficiency rating. If non-matched power supplies are inserted you will get errors and
operation will fail.
HP CS Platinum Plus power supplies are required when enabling HP's Power Discovery Services, a solution
that creates an automated, energy-aware network between IT systems and facilities. This allows your
company to reclaim millions of dollars in wasted power capacity and downtime costs across data centers.
For more information on HP's Power Discovery Services, go to: www.hp.com/go/ipd .
It is highly recommended that you use the HP Power Advisor in defining the "Right-Size" power supply for
your needs. HP Power Advisor can be accessed at: www.hp.com/go/hppoweradvisor .
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Standard Features
DA - 14327 North America — Version 36 — January 22, 2014 Page 7

NOTE: The 80 PLUS program is a unique forum that unites electric utilities, the computer industry, and
consumers in an effort to bring energy efficient technology solutions to the marketplace. 80 Plus
independently tests power supply efficiency and publicly posts the results on www.80Plus.org .
Redundant Power: Optional (1+ 1 or n+n redundant) power supplies can be purchased through power
supply option kits (see Power Supplies for part numbers).
NOTE: Power Specification and Technical Content for supported power supplies can be found at:
http://h18000.www1.hp.com/products/quickspecs/14209_div/14209_div.html
System Fans
One of the following
depending on Model
4 Hot-Plug Non-redundant Fans ship standard in 1P Models
1P: 4 fans - non-redundancy
1P: 5 fans - redundancy
8 Hot-Plug Redundant Fans ship standard in 2P Models
NOTE: Customers may separately purchase a redundant fan with the 661530-B21 option kit. Additional
fans to support redundancy are also included in -B21 processor option kits when upgrading from a one
processor to a two processor model.
Required Cabling For required cabling information, refer to the Web site at:
www.hp.com/servers/DL360e-gen8
Operating Systems and
Virtualization Software
Support for ProLiant
Servers
Microsoft Windows Server
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
Oracle Solaris
VMware
NOTE: For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization
Software and latest listing of software drivers available for your server including how to purchase from
HP, please visit our OS Support Site at: http://www.hp.com/go/ossupport and our driver download page
http://www.hp.com/support/DL360eGen8 .
Graphics Integrated Matrox G200 video standard
Form Factor
One of the following
depending on Model
1U Rack form factor
8 SFF Drive Bay Version:
1.7" (4.32cm) Height x 17.1" (43.46cm) Width x 27.5" (69.9cm) Length
4 LFF Drive Bay Version:
1.7" (4.32cm) Height x 17.1" (43.46cm) Width x 29.5" (75cm) Length
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Standard Features
DA - 14327 North America — Version 36 — January 22, 2014 Page 8

On System Management HP iLO Management
Engine
HP iLO Management Engine is a comprehensive set of embedded management
features supporting the complete lifecycle of the server, from initial
deployment, through ongoing management, to service alerting and remote
support. HP iLO Management Engine comes standard on all HP ProLiant Gen8
servers. The HP iLO Management Engine portfolio includes:
HP iLO: The HP iLO (Integrated Lights-Out) management processor is
the core foundation for the HP iLO Management Engine
HP Agentless Management: Provides built in server health monitoring
and alerting capability without OS agents, that starts working the
moment a power cord and an Ethernet cable are connected.
HP Active Health System: Always on, continuous monitoring for
increased stability and shorter downtimes; 100% configuration history;
Health and service alerts and easy export and upload to Service and
Support.
HP Intelligent Provisioning: Lets customers provision and configure a
single server without any separate media. No more SmartStart CDs or
Smart Update Firmware DVD are needed.
To start Intelligent Provisioning:
Press the F10 key during the ProLiant Gen8 server boot
process (also known as power on self-test or POST).
Please go to the Intelligent Provisioning website at
www.hp.com/go/intelligentprovisioning for additional
information and to view usage videos.
Use the Service Pack for ProLiant (SPP) at
www.hp.com/go/spp to get firmware and software
updates.
HP iLO Mobile App: Enables the ability to access, deploy, and manage
your server anytime from anywhere from select smartphones and
mobile devices. For additional information please visit:
www.hp.com/go/ilo/mobileapp
NOTE: For more information, visit: http://www.hp.com/go/ilo or HP iLO
Management Engine technologies whitepaper
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Standard Features
DA - 14327 North America — Version 36 — January 22, 2014 Page 9

HP Insight Management HP Service Pack for
ProLiant (SPP)
HP Service Pack for ProLiant (SPP) and HP Smart Update Manager (HP SUM)
provide a comprehensive approach to firmware and system software
maintenance. Together they provide better operating stability and ensure
maximum uptime. The SPP will be updated at a predictable cadence, typically
coinciding with new HP server hardware launches. By enabling firmware to be
updated online and integrating firmware and system software updates in one
operation, HP SUM and the SPP offer faster updates of individual servers and
dramatically faster updates of entire BladeSystem enclosures. Further
improving system uptime and stability is the fact that HP provides 12 months
of support for each Service Pack for ProLiant release.
The user experience around HP SUM and the SPP has been improved in several
ways, starting with the web download. A single web page provides access to a
single download containing both the latest version of HP SUM and the latest
SPP. Optional smaller subsets with only specific types of servers or specific
operating systems are offered to save on download time. The HP SUM
application provides a straightforward, intuitive user interface that guides the
user through the steps of discovery, analyses and update, providing
comprehensive information on available updates, criticality and
interdependencies. This information is also available in reports. By providing
the option of multiple local or shared repositories which can be easily updated
from hp.com, HP SUM provides the tools to optimize stability and consistency
throughout the company. While HP SUM and the SPP recommend the
combinations of firmware and system software that HP has found to be the
best practice, the application gives customers the flexibility to set their own
specific baseline.
The Service Pack for ProLiant has been rigorously tested with specific
attention for interaction between firmware, drivers and agents both within the
server as well as in interaction with the BladeSystem enclosure components
(Onboard Administrator and Virtual Connect). This testing ensures the highest
quality as well as providing the input for HP SUM to deploy updates taking into
account all interdepencies, when determining the correct updates and order of
update deployment.
NOTE: The Service Pack for ProLiant (which includes HP SUM) can be
downloaded from www.hp.com/go/spp/download . More information can be
found: http://www.hp.com/go/SmartUpdate , www.hp.com/go/spp and
http://www.hp.com/go/hpsum
Security Power-on password
Serial interface control
Administrator's password
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Standard Features
DA - 14327 North America — Version 36 — January 22, 2014 Page 10

Warranty This product is covered by a global limited warranty and supported by HP Services and a worldwide
network of HP Authorized Channel Partners resellers. Hardware diagnostic support and repair is available
for three years from date of purchase. Support for software and initial setup is available for 90 days from
date of purchase. Enhancements to warranty services are available through HP Care Pack services or
customized service agreements. Hard drives have either a one year or three year warranty; refer to the
specific hard drive QuickSpecs for details.
NOTE: Server Warranty includes 3-Year Parts, 1-Year Labor, 1-Year Onsite support with next business day
response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts.
These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel
and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR
parts are also designed for easy replacement but may involve added complexity. Customers may choose
to have HP replace Optional CSR parts at no charge. Additional information regarding worldwide limited
warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Standard Features
DA - 14327 North America — Version 36 — January 22, 2014 Page 11

HP Insight Management HP Insight Control HP Insight Control, a product option, delivers essential infrastructure
management that can help save time and money by making it easy to deploy,
migrate, monitor, remote control, and optimize your IT infrastructure through
a single, simple management console. HP Insight Control also supports
Location and Power Discovery Services to automate many configuration, asset
tracking, and power management tasks to speed implementation and prevent
downtime. For more information, see http://www.hp.com/go/insightcontrol .
HP Insight Control includes one year of 24 x 7 HP Software Technical Support
and Update Service ensuring rapid access to HP support staff and proactive
delivery of software updates. For more information about this service, see:
http://www.hp.com/services/insight .
HP iLO Essentials HP iLO Essentials license ideal for small and medium business customers. The
specially created HP iLO Essentials (a subset of iLO Advanced functionality)
saves SMB customers time and money, by ease of remote server set up
through the interactive virtual media, lowering operational costs with remote
access via the Integrated Remote Console, and faster time to resolution with
email-based proactive notifications. With this newly designed HP iLO
Essentials license SMB customers now have the option of a server
management package solely design and priced just right for their IT
environments. HP iLO Essentials is available on all HP ProLiant Gen8 e-series
making this an ideal solution for small business owners. For more
information, see: http://www.hp.com/go/iLO/essentials
HP iLO Advanced HP Integrated Lights-Out Advanced License a product option, providing smart
remote server management without compromise. iLO Advanced unlocks the
full set of remote administration functionality for all HP ProLiant servers by
activating the full Virtual Keyboard Video and Mouse remote console, multi-
user collaboration, console record and replay, GUI-based and scripted virtual
media and virtual folders, and enhanced security and power management
functionality. For more information, see: http://www.hp.com/go/iloadvance
HP Matrix Operating
Environment
The HP Matrix Operating Environment (Matrix OE) for ProLiant and Integrity
servers is an integrated command center that helps you instantly adjust to
dynamic business demands. This advanced infrastructure management
software lets you reduce the cost of common data center tasks by up to 40
percent while keeping pace with your changing business.
The HP Matrix OE includes the automated provisioning, optimization, and
recovery management capabilities for HP CloudSystem Matrix, the ideal
platform for private cloud and Infrastructure as a Service (IaaS).
NOTE: For more information, visit: http://www.hp.com/go/matrixoe
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Optional Features
DA - 14327 North America — Version 36 — January 22, 2014 Page 12

High Performance
Clusters
HP Cluster Platforms HP Cluster Platforms are specifically engineered, factory-integrated large-
scale ProLiant clusters optimized for High Performance Computing, with a
choice of servers, networks and software. Operating system options include
specially priced offerings for Red Hat Enterprise Linux and SUSE Linux
Enterprise Server, as well as Microsoft Windows HPC Server. A Cluster
Platform Configurator simplifies ordering. http://www.hp.com/go/clusters .
HP HPC Interconnects High Performance Computing (HPC) interconnect technologies are available
for this server as part of the HP Cluster Platform portfolio. These high-speed
InfiniBand and Gigabit interconnects are fully supported by HP when
integrated within an HP cluster. Flexible, validated solutions can be defined
with the help of configuration tools.
http://www.hp.com/techservers/clusters/ucp/index.html
HP Insight Cluster
Management Utility
HP Insight Cluster Management Utility (CMU) is an HP-licensed and HP-
supported suite of tools that are used for lifecycle management of hyperscale
clusters of Linux ProLiant systems. CMU includes software for the centralized
provisioning, management and monitoring of nodes. CMU makes the
administration of clusters user friendly, efficient, and effective.
http://www.hp.com/go/cmu
Storage Software Whether you need to solve a specific data protection, archiving, or storage command and control
challenge, or deliver on strategic consolidation, compliance, or continuity initiatives, look no further than
HP storage software. Our storage software helps you reduce costs, simplify storage infrastructure,
protect vital assets and respond faster to business opportunities.
Storage software that gets the job done:
Data Protection and Recovery Software
Whether you're a large enterprise or a smaller business, HP data protection and recovery software
will cost-effectively protect you against disaster and ensure business continuity.
Data Archive and Migration Software
HP's storage software enables you to comply with data retention and retrieval requirements,
improve application performance, and reduce costs by efficiently migrating infrequently accessed
or less valuable data to lower cost storage.
Storage Resource Management Software (SRM)
HP's storage resource management software reduces operational costs and provides the command
and control foundation you need to efficiently manage and visualize your physical and virtual
environments.
Data Replication Software
HP offers array-based and host-based replication software for use in disaster recovery, testing,
application development and reporting.
Storage Device Management Software
Maximize your investment in HP storage and networking with software that enables hardware-
specific configuration, performance tuning and connectivity management.
HP StoreVirtual VSA
With HP StoreVirtual VSA you can use the power of virtualization to turn a set of heterogeneous and
disconnected physical disk drives in your servers and storage devices into a single pool of logical
storage capacity.
NOTE: For more information available Storage Software including QuickSpecs, please see:
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Optional Features
DA - 14327 North America — Version 36 — January 22, 2014 Page 13

www.hp.com/go/storage/software .
HP Insight Online HP Insight Online is a new addition to the HP Support Center for one stop, secure access to product and HP
support information personalized to your IT environment. Insight Online can automatically display devices
remotely monitored by HP Insight Remote Support. With Insight Online's easy navigation you can
efficiently track your IT support contracts and device status from anywhere and at anytime.
www.hp.com/go/insightonline
HPC Interconnects NOTE: High Performance Computing (HPC) interconnect technologies are available for this server under
the HP Cluster Platform product portfolio. These high-speed interconnects are fully supported by HP when
they are part of these configure to order clusters. Solutions can be defined with a lot of flexibility with the
help of configuration tools. Please visit the following URL to configure HPC Clusters with InfiniBand
Interconnects: http://www.hp.com/techservers/clusters/ucp/index.html
InfiniBand PCI-Express Generation 2 adapters
Factory Express Portfolio
for Servers and Storage
HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading, asset
tagging, and custom packaging. HP products supported through Factory Express include a wide array of
servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000
servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries and configurable network
switches.
For more information on Factory Express services for your specific server model please contact your sales
representative or go to: http://www.hp.com/go/factory-express .
HP Proactive Insight
experience
Prevent problems with innovative, automated monitoring tools and proactive services. The HP Proactive
Insight experience consist of using Insight Online, Insight Remote Support, and Proactive Care Support
Service as one integrated solution. The Proactive Insight experience provides you with expert advice and
personalized, cloud-based automated IT support, helping to prevent unplanned down time and solve
problems quickly. For more information, visit: www.hp.com/go/proactiveinsightexperience
HP Simple Configurator SCE is a guided self-service tool to help sales and non-technical people provide customers with initial
configurations in 3 to 5 minutes. You may then send the configuration on for configuration help, or use in
your existing ordering processes. If you require "custom" rack configuration or configuration for products
not available in SCE, please contact HP's Customer Business Center or an Authorized Partner for
assistance. http://www.hp.com/products/configurator
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Optional Features
DA - 14327 North America — Version 36 — January 22, 2014 Page 14

Service and Support HP Technology Services for Industry Standard Servers and BladeSystem
Capitalizing on HP ProLiant server and HP BladeSystem capabilities requires a service partner who
understands your increasingly complex business technology environment. That's why it makes sense to
team up with the people who know HP infrastructure hardware and software best - the experienced
professionals at HP Services.
What HP ProLiant and BladeSystem Services can do for you
HP ProLiant and BladeSystem Services can help you design, deploy, test, integrate, support, and manage
IT and infrastructure solutions. This way, HP proposes services solutions that include more than just uplift
of base warranty. Foundation Care services deliver scalable support-packages for HP industry-standard
servers and software. You can choose the type and level of service that is most suitable for their business
needs. New to this portfolio is HP Collaborative Support. If you are running business critical environments,
HP offers Proactive Care or Critical Advantage. These services help deliver high levels of application
availability through proactive service management and advanced technical response
You can get the support you need by choosing from one of a number of service packaged solutions we
have designed to address wider set of customer support needs.
HP Technology Services meets business challenges with services offered in three support
recommendations - Optimized Care, Standard Care, and Basic Care - available for each product group.
Such support solutions enable customers to optimize technology operations, minimize risk and drive
better business outcomes with easy-to-buy, easy-to-use scalable support recommendations for servers,
storage, networking and software designed to meet your specific needs.
All three service recommendations include support services from the broader portfolio of Foundation Care
and Proactive Care services.
Optimized Care Optimized Care: Supports maintaining servers at optimum performance availability
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
HP Installation and Startup for Insight Control Software / HP SIM
Provides for the deployment and basic configuration of HP Insight Control or HP SIM (Systems Insight
Manager) on HP ProLiant ML and DL series servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
3-Year HP 24x7 4 hour Response, Proactive Care or Critical Advantage
Helps optimize your systems and delivers high levels of application availability through proactive service
management and advanced technical response. A skilled Technical Manager will own your query or issue
end to end until resolved, delivering a single point of contact for you
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-2140ENW.pdf
Additional Services: Data Center Transformation Services
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Service and Support
DA - 14327 North America — Version 36 — January 22, 2014 Page 15

Standard Care Standard Care: Service recommendation that maintains high level of server availability
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
HP Installation and Startup for Insight Control Software / HP SIM
Provides for the deployment and basic configuration of HP Insight Control or HP SIM (Systems Insight
Manager) on HP ProLiant ML and DL series servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
3-Year HP 24x7 4 hour Response, Collaborative Support
Offers customers a single point of contact for server problem diagnosis, hardware problem resolution, and
basic software problemdiagnosis, fault isolation, and resolution if available to HP. If the problem is with
HP HW, the representative will arrive on site any time and day of the year to begin hardware maintenance
service within 4 hours of the service request being logged. In case, the issue is with HP or supported third-
party software product and cannot be resolved by applying known fixes, HP will contact the third-party
vendor and create a problem incident on your behalf.
Additional Services: Software OS (Microsoft, Linux (SUSE/Red Hat) & VMware) Installation & Start Up and
Software Support; Microsoft or Linux or VMware education courses; +60 Proactive Select Credits
Basic Care Basic Care: delivers minimum recommended support service level
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
3-Year HP 24x7 4 hour Response, Hardware Support Onsite Service
Provides for the deployment and basic configuration of HP Insight Control on HP ProLiant ML and DL series
servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
Additional Services: Software OS (Microsoft, Linux (SUSE/Red Hat) & VMware) Installation & Start Up and
Software Support; +30 Proactive Select Credits, Factory Express.
Insight Remote Support Provides 24 X 7 remote monitoring, proactive notifications, and problem resolution. Learn more
http://www.hp.com/go/insightremotesupport
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Service and Support
DA - 14327 North America — Version 36 — January 22, 2014 Page 16

HP Support Center Personalized online support portal with access to information, tools and experts to support HP business
products. Submit support cases online, chat with HP experts, access support resources or collaborate with
peers. Learn more http://www.hp.com/go/hpsc
HP's Support Center Mobile App * allows you to resolve issues yourself or quickly connect to an agent for
live support. Now, you can get access to personalized IT support anywhere, anytime.
HP Insight Remote Support and HP Support Center are available at no additional cost with a HP warranty,
HP Care Pack or HP contractual support agreement.
*HP' Support Center Mobile App is subject to local availability
Warranty / Service
Coverage
For ProLiant servers and storage systems, the services cover HP-branded hardware options qualified for
the server, purchased at the same time or afterward, internal to the enclosure, as well as external
monitors up to 22" and tower UPS products; these items will be covered at the same service level and for
the same coverage period as the server unless the maximum supported lifetime and/or the maximum
usage limitation has been exceeded. Coverage of the UPS battery is not included; standard warranty terms
and conditions apply.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives
replaced by HP due to malfunction. It does not apply to any exchange of Disk or SSD/Flash Drives that
have not failed. SSD/Flash Drives that are specified by HP as consumable parts and/or that have exceeded
maximum supported lifetime and/or the maximum usage limit as set forth in the manufacturer's operating
manual or the technical data sheet are not eligible for the defective media retention service feature option.
For more information To learn more on HP ProLiant servers and HP BladeSystem servers, please contact your HP sales
representative or HP Authorized Channel Partner. Or visit: http://www.hp.com/services/proliant
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Service and Support
DA - 14327 North America — Version 36 — January 22, 2014 Page 17

NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory
Integrated Models" section.
NOTE: Pre-configured models ship with the configurations below. Options can be selected from the Core or Additional options section
of this QuickSpecs.
NOTE: HP does not allow factory integration of options into pre-configured models. Any additional options purchased will be shipped
separately.
NOTE: If you desire a custom configuration please see "Configuration Information - Factory Integrated Models" section of this
QuickSpecs.
NOTE: All Pre-configured Models come populated with some hard drive blanks installed. Should the customer need additional hard
drive blanks, they can order more using either P/N 666987-B21: HP SFF Gen8 Hard Drive Blank Kit or P/N 666986-B21: HP LFF Gen8
Hard Drive Blank Kit.
NOTE: When the SAS FIO riser kit (PN 661387-B21) which includes HP Dynamic Smart Array B320i controller is installed in the server,
the embedded Smart Array B120i controller is automatically disabled. In the absence of another storage controller or an expander
backplane, drives operate in ACHI or Legacy mode. In these two modes, the drives are not part of a hardware RAID or a member of a
logical drive. The Locate, Drive status, and Do not remove LEDs in the drive carrier are disabled.
Entry Models - SAS
HP ProLiant DL360e Gen8
E5-2403 1P 4GB-R Hot
Plug 8 SFF 460W PS Entry
Server
668813-001
Processor (1) Intel® Xeon® E5-2403 (1.8GHz/4-core/10MB/80W, DDR3-1066) Processor
Cache Memory 10MB (1 x 10MB) L3 cache
Memory 4GB (1 x 4GB) Registered DIMMs PC3L-10600R (1333MHz)
NOTE: Memory runs at 1066MHz speed due to processor.
Network Controller HP Ethernet 1Gb 4-port 366i Adapter
Storage Controller HP Dynamic Smart Array B320i Controller
NOTE: Provides support for up to 8 SAS or SATA drives and includes SAS
license key (PN BC393A).
Hard Drive None ship standard; includes 7 SFF hard drive blanks
Internal Storage 8 SFF HDD Bays
Power Supply (1) HP 460W CS Gold Hot Plug Power Supply (92% Efficient)
Fans 4 Hot-Plug Non-redundant Fans
Form Factor Rack (1U)
NOTE: Includes Rack Mounting Gen8 non-telescoping Friction Rail Kit which
does not allow for in rack serviceability. The HP 1U Gen8 Cable Management
Arm is not available when using Friction Rails. To assist in the installation of
the server into the rack an optional installation tool is available by contacting
your local services representative (p/n 695539-001). Caution: HP recommends
that a minimum of two people is required for all Rack Server installations.
Please refer to your installation instructions for proper tools and number of
people to use for any installation.
Warranty Server Warranty includes 3-Year Parts, 1-Year Labor, 1-Year Onsite support
with next business day response.
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Pre-configured Models
DA - 14327 North America — Version 36 — January 22, 2014 Page 18

HP ProLiant DL360e Gen8
E5-2403v2 1P 4GB-R
B320i Hot Plug SAS 8 SFF
460W PS Svr
747089-001
Processor (1) Intel® Xeon® E5-2403v2 (1.8GHz/4-core/10MB/80W, DDR3-1333066)
Processor
Cache Memory 10MB (1x10MB) L3 cache
Memory 4GB (1x4GB) DDR3 RDIMM PC3L-12800R (1600MHz)
NOTE: Memory runs at 1333MHz speed due to processor.
Network Controller HP Ethernet 1Gb 4-port 366i Adapter
Storage Controller HP Dynamic Smart Array B320i Controller
NOTE: Provides support for up to 8 SAS or SATA drives and includes SAS
license key (PN BC393A).
Hard Drive None ship standard; includes 7 SFF hard drive blanks
Internal Storage 8 SFF HDD Bays
Power Supply (1) HP 460W CS Gold Hot Plug Power Supply (92% Efficient)
Fans 4 Hot-Plug Non-redundant Fans
Form Factor Rack (1U)
NOTE: Includes the Easy Install Rail kit which does allow for in-rack
serviceability. The Easy Install Cable Management Arm is optional.
Caution: HP recommends that a minimum of two people are required for all
Rack Server installations. Please refer to your installation instructions for
proper tools and number of people to use for any installation.
Warranty Server Warranty includes 3-Year Parts, 1-Year Labor, 1-Year Onsite support
with next business day response.
Entry Models - SATA
HP ProLiant DL360e Gen8
E5-2403 1P 4GB-R Hot
Plug 4 LFF 460W PS Entry
Svr
668812-001
Processor (1) Intel® Xeon® E5-2403 (1.8GHz/4-core/10MB/80W, DDR3-1066) Processor
Cache Memory 10MB (1 x 10MB) L3 cache
Memory 4GB (1 x 4GB) Registered DIMMs PC3L-10600R (1333MHz)
NOTE: Memory runs at 1066MHz speed due to processor.
Network Controller HP Ethernet 1Gb 4-port 366i Adapter
Storage Controller HP Dynamic Smart Array B120i Controller
NOTE: Provides data transmission speeds up to 3Gb/s
Hard Drive None ship standard; includes 3 LFF hard drive blanks
Internal Storage 4 LFF HDD Bays
Power Supply (1) HP 460W CS Gold Hot Plug Power Supply (92% Efficient)
Fans 4 Hot-Plug Non-redundant Fans
Form Factor Rack (1U)
NOTE: Includes Rack Mounting Gen8 non-telescoping Friction Rail Kit which
does not allow for in rack serviceability. The HP 1U Gen8 Cable Management
Arm is not available when using Friction Rails. To assist in the installation of
the server into the rack an optional installation tool is available by contacting
your local services representative (p/n 695539-001). Caution: HP recommends
that a minimum of two people is required for all Rack Server installations.
Please refer to your installation instructions for proper tools and number of
people to use for any installation.
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Pre-configured Models
DA - 14327 North America — Version 36 — January 22, 2014 Page 19

Warranty Server Warranty includes 3-Year Parts, 1-Year Labor, 1-Year Onsite support
with next business day response.
HP ProLiant DL360e Gen8
E5-2403v2 1P 4GB-R
B120i Hot Plug SATA 4 LFF
460W PS Svr
747088-001
Processor (1) Intel® Xeon® E5-2403 v2 (1.8GHz/4-core/10MB/80W, DDR3-1333)
Processor
Cache Memory 10MB (1 x 10MB) L3 cache
Memory 4GB (1x4GB) DDR3 RDIMM PC3L-12800R (1600MHz)
NOTE: Memory runs at 1333MHz speed due to processor
Network Controller HP Ethernet 1Gb 4-port 366i Adapter
Storage Controller HP Dynamic Smart Array B120i Controller
NOTE: Provides data transmission speeds up to 3Gb/s
Hard Drive None ship standard
Internal Storage 4 LFF HDD Bays
Power Supply (1) HP 460W CS Gold Hot Plug Power Supply (92% Efficient)
Fans 4 Hot-Plug Non-redundant Fans
Form Factor Rack (1U)
NOTE: Includes the Easy Install Rail kit which does allow for in-rack
serviceability. The Easy Install Cable Management Arm is optional.
Caution: HP recommends that a minimum of two people are required for all
Rack Server installations. Please refer to your installation instructions for
proper tools and number of people to use for any installation
Warranty Server Warranty includes 3-Year Parts, 1-Year Labor, 1-Year Onsite support
with next business day response.
Base Models
HP ProLiant DL360e Gen8
E5-2407 1P 8GB-R Hot
Plug 8 SFF 460W PS Base
Server
668814-001
Processor (1) Intel® Xeon® E5-2407 (2.2GHz/4-core/10MB/6.4GT-s QPI/80W, DDR3-
1066, HT) Processor
Cache Memory 10MB (1 x 10MB) L3 cache
Memory 8GB (2 x 4GB) Registered DIMMs PC3L-10600R (1333MHz)
NOTE: Memory runs at 1066MHz speed due to processor.
Network Controller HP Ethernet 1Gb 4-port 366i Adapter
Storage Controller HP Dynamic Smart Array B320i/512 MB FBWC Controller
NOTE: Provides support for up to 8 SAS or SATA drives and includes SAS
license key (PN BC393A).
Hard Drive None ship standard; includes 7 SFF hard drive blanks
Internal Storage 8 SFF HDD Bays
Power Supply (1) HP 460W CS Gold Plus Hot Plug Power Supply (92% Efficient)
Fans 4 Hot-Plug Non-redundant Fans
Form Factor Rack (1U)
NOTE: Includes Rack Mounting Gen8 telescoping SFF Ball Bearing Rail Kit
which does allow for in rack serviceability. Due to the size and weight of the
server two people are required to install the server into the rack. The HP 1U
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Pre-configured Models
DA - 14327 North America — Version 36 — January 22, 2014 Page 20
