HP ProCurve 10Base-T 12 User manual

Less Work, More Network
HP Networking
HP ProCurve
10Base-T Hubs
Installation Guide
HP 10Base-T Hub 12
HP 10Base-T Hub 12M
HP 10Base-T Hub 24
HP 10Base-T Hub 24M
For world-wide support on all
HP Network Connectivity Products
visit our web site at:
http://www.hp.com/go/procurve

,QVWDOOEN3DJH0RQGD\2FWREHU30

HP ProCurve 10Base-T Hubs
Installation Guide
,QVWDOOEN3DJHL0RQGD\2FWREHU30

© Copyright 1998 Hewlett-Packard Company
All Rights Reserved.
This document contains information which is protected by
copyright. Reproduction, adaptation, or translation without
prior permission is prohibited, except as allowed under the
copyright laws.
Publication Number
5967-6861
June 1998
Applicable Product
HP ProCurve 10Base-T Hub 12 (J3300A)
HP ProCurve 10Base-T Hub 12M (J3301A)
HP ProCurve 10Base-T Hub 24 (J3302A)
HP ProCurve 10Base-T Hub 24M (J3303A)
Trademark Credits
MS-DOS® and Microsoft® are U.S. registered trademarks of
Microsoft Corporation. Ethernet is a registered trademark of
Xerox Corporation.
Disclaimer
The information contained in this document is subject to
change without notice.
HEWLETT-PACKARD COMPANY MAKES NO WARRANTY
OF ANY KIND WITH REGARD TO THIS MATERIAL,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not
be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing,
performance, or use of this material.
Hewlett-Packard assumes no responsibility for the use or
reliability of its software on equipment that is not furnished
by Hewlett-Packard.
Warranty
See the warranty booklet and the registration form included
with the product.
A copy of the specific warranty terms applicable to your
Hewlett-Packard products and replacement parts can be
obtained from your HP Sales and Service Office or
authorized dealer.
,QVWDOOEN3DJHLL0RQGD\2FWREHU30

iii
HP ProCurve 10Base-T Hubs
HP ProCurve 10Base-T Hubs
The HP ProCurve 10Base-T Hubs are a family of multiport repeaters. With
these hubs, you can connect computers, printers, and servers together for file
sharing. These hubs are compliant with the IEEE 802.3 Type 10Base-T
standard and support both 802.3 and Ethernet networks. The HP ProCurve
10Base-T Hubs follow these two standards by providing these features:
■lighting the hub’s port LED when it detects the connected device is
powered on and cable is good.
■retransmitting data that did not successfully arrive at the destination
device (collision detection).
A sample hub from the family is shown here to indicate common features.
Figure 1. The HP ProCurve 10Base-T Hub 24M (J3303A): Front and Rear Views
Twisted Pair
port LEDs
Twisted-pair
ports
MDI/MDI-Xswitch
for port 1.
Activity
LED
Collision
LED
Fault LED
Power
LED
AUI/
Xcvr
LED
AUI/Xcvr
Slot
Clear
Button
Reset
Button
Console
Port
F
ront
View
AUI/XcvrSlot
10 Mbps Xcvr Port
MDI-X
(out) (In)
MDI
Por t 1 On ly
113X
7X 19X
2X 14X
8X 20X
3X 15X
9X 21X
4X 16X
10X 22X
5X 17X
11 X 23X
6X 18X
12X 24X
1
Xcvr
Reset
ConsoleFault
Powe r
Clear
7
2
8
3
9
4
10
5
11
6
12
13
19
14
20
Act
15
21
16
22
Col
17
23
18
24
ProCurve 10Base-T Hub 24M
HP J3303A
Rear
View
Power
Receptacle
110/220 VAC
,QVWDOOEN3DJHLLL0RQGD\2FWREHU30

iv
HP ProCurve 10Base-T Hubs
The following illustrations show each of the four hubs in the HP ProCurve
10Base-T Hubs family.
Figure 2. The HP ProCurve 10Base-T Hub 12 (J3300A)
Figure 3. The HP ProCurve 10Base-T Hub 12M (J3301A)
Figure 4. The HP ProCurve 10Base-T Hub 24 (J3302A)
Figure 5. The HP ProCurve 10Base-T Hub 24M (J3303A)
AUI/XcvrSlot
10 Mbps Xcvr Port
MDI-X
(out) (In)
MDI
Por t 1 Onl y
1
7X
2X
8X
3X
9X
4X
10X
5X
11 X
6X
12X
1
Xcvr
Reset
Fault
Powe r
7
2
8
3
9
4
10
5
11
6
12
Act C ol
ProCurve 10Base-T Hub 12
HP J3300A
AUI/XcvrSlot
10 Mbps Xcvr Port
MDI-X
(out) (In)
MDI
Por t 1 Onl y
1
7X
2X
8X
3X
9X
4X
10X
5X
11 X
6X
12X
1
Xcvr
Reset
ConsoleFault
Powe r
Clear
7
2
8
3
9
4
10
5
11
6
12
Act C ol
ProCurve 10Base-T Hub 12M
HP J3301A
AUI/XcvrSlot
10 Mbps Xcvr Port
MDI-X
(out) (In)
MDI
Por t 1 Onl y
113X
7X 19X
2X 14X
8X 20X
3X 15X
9X 21X
4X 16X
10X 22X
5X 17X
11 X 23X
6X 18X
12X 24X
1
Xcvr
Reset
Fault
Powe r
7
2
8
3
9
4
10
5
11
6
12
13
19
14
20
Act
15
21
16
22
Col
17
23
18
24
ProCurve 10Base-T Hub 24
HP J3302A
AUI/XcvrSlot
10 Mbps Xcvr Port
MDI-X
(out) (In)
MDI
Por t 1 Onl y
113X
7X 19X
2X 14X
8X 20X
3X 15X
9X 21X
4X 16X
10X 22X
5X 17X
11 X 23X
6X 18X
12X 24X
1
Xcvr
Reset
ConsoleFault
Powe r
Clear
7
2
8
3
9
4
10
5
11
6
12
13
19
14
20
Act
15
21
16
22
Col
17
23
18
24
ProCurve 10Base-T Hub 24M
HP J3303A
,QVWDOOEN3DJHLY0RQGD\2FWREHU30

v
HP ProCurve 10Base-T Hubs
Features
The following tables detail information about features on the HP ProCurve
10Base-T Hubs.
Feature Description
The following table provides descriptive information about features on the HP
ProCurve 10Base-T Hubs.
Table 1. HP ProCurve 10Base-T Hub Feature Descriptions
Feature Type Feature Description
Network Connections •12 or 24 twisted-pair ports to connect to end nodes or other
devices.
•An MDI/MDI-X (Media Dependent Interface) switch for Port 1
which allows you to connect either an end node (MDI-X position)
or to cascade a hub (MDI position) to the port, using a “straight-
through” twisted-pair cable in both cases. Port 1 has a factory
default of MDI-X, but can be toggled to an MDI state with the
adjacent push-button. All other ports are always MDI-X for
connection to computers and other end nodes through a twisted-
pair “straight-through” cable.
• An AUI/Xcvr slot for installing one of the HP Transceiver modules:
• HP Fiber-Optic Transceiver Module (HP J2606A) -- for 10Base-FL.
Allows you to connect your hub to a fiber-optic backbone.
• HP Twisted-Pair Transceiver Module (HP J2607A) -- for 10Base-T.
Adds another RJ-45 port for a total of 13 twisted-pair ports on the
J3300A and the J3301A hubs.
• HP ThinLAN Transceiver Module (HP J2608A)-- for 10Base2.
• HP AUI Port Module (HP J2609A) -- to attach external transceivers.
Easy-to-Use Design •Hub Status LEDs showing power, activity, collisions, fault and Xcvr,
each providing quick, easy-to-read hub status information and
troubleshooting help.
• Port Status LEDs showing transceiver and port status, providing
quick, easy-to-read port status information and troubleshooting
help.
•Metal brackets (included with the hub) that can be easily attached
to the hub for mounting the hub in a standard 19-inch telco rack or
on a rack. Also, table and wall mounting is supported.
Standards-Based
Compatibility
•IEEE 802.3 Type 10Base-T standard compatibility to support both
802.3 and Ethernet networks.
,QVWDOOEN3DJHY0RQGD\2FWREHU30

vi
HP ProCurve 10Base-T Hubs
•Advanced embedded SNMP agent code in both the HP J3301A
and HP J3303A, enabling these hubs to be managed remotely from
a network management station using SNMP over IP (using the
configured IP address). The agent code also provides HP EASE
(Embedded Advanced Sampling Environment), which samples
network data for enhanced diagnostics from a network
management station. Also, the hubs support the RMON MIB. The
HP J3301A and HP J3303A both can be managed in any of these
three ways:
– using a Simple Network Management Protocol application that
runs in Microsoft Windows and Unix (HP ASA).
– using a World Wide Web browser application that runs in
Netscape Navigator or Microsoft Internet Explorer (the
Browser Interface).
– using an ASCII Console Interface.
Reliable Operation •A self-test for fault identification when the hub is powered on or
when it is reset. (The hub can be reset from a network
management station or by pressing the Reset button.)
Other Features •Password setting capability on both the HP J3301A and HP
J3303A, enabling you to add and remove passwords, as needed,
for selective entry into the hub management environment.
Passwords can be set from a World Wide Web browser, a network
management station, through an ASCII Console session. If you
forget your password, and are locked out of the hub’s management
environment, you can remove the password by pressing the Clear
button.
•An RS-232 serial port on both the HP J3301A and HP J3303A that
provides out-of-band management access including:
– An ASCII console to configure, monitor, and troubleshoot the
hub.
– Variable baud rates on the hub’s out-of-band management RS-
232 port, and automatic sensing of the selected baud rate when
connecting to a terminal device.
– Full V.22bis modem line control for remote out-of-band
management access to the hub.
– Updatable firmware that enables enhancements to be
downloaded either from a computer attached to the out-of-
band management port via Xmodem or over the network via
TFTP.
Feature Type Feature Description
,QVWDOOEN3DJHYL0RQGD\2FWREHU30

vii
HP ProCurve 10Base-T Hubs
Feature Comparison
The following table details what features are present on the managed and the
unmanaged hubs.
Table 2. Feature Comparison Between Managed and Unmanaged Hubs
Feature HP J3300A/HP J3302A
(Unmanaged)
HP J3301A/HP J3303A
(Managed)
IEEE 802.3 10Base-T ports á á
Transceiver Slot á á
MDI/MDI-X Selection Button á á
Rack Mounting Capability á á
Wall Mounting Capability á á
World Wide Web management
interface
á
HP EASE á
SNMP á
RMON -- 9 Groups á
ASCII Console Management á
Telnet Console Management á
Modem Support á
Out of Band Management for remote
console connection
á
Eavesdrop Prevention á
Intruder Prevention á
Backup Links á
IP Configuration á
Community Name Management á
Alarms á
MIB II á
MAU Connectivity á á
Link Test á
Ping Test á
ThinLAN support á á
Fiber Optic support á á
Console Password Protection á
Mounting Brackets for Rack á á
Transceiver Module Support á á
RS-232 download á
,QVWDOOEN3DJHYLL0RQGD\2FWREHU30

viii
HP ProCurve 10Base-T Hubs
Factory Default Settings
The following table details the factory defaults for all of your hub settings.
Table 3. Factory Default Settings on HP ProCurve 10Base-T Hubs
Feature J3300A/J3302A J3301A/J3303A
Port Status Enabled Enabled
MDI/MDI-X Port Status MDI-X (Button not
depressed)
MDI-X (Button not
depressed)
Power (when power cord is connected) On On
Port Counters -- All 0
Link Beat detection Enabled Enabled
,QVWDOOEN3DJHYLLL0RQGD\2FWREHU30

ix
Contents
1 Installing the Hub
Installing Your Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1. Verify included parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
2. Install the transceiver module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
3. Verify the hub operates correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
4. Mount the hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Rack or Cabinet Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Table Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
5. Connect the hub to your network . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
Connecting Hubs Together . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Twisted-Pair Cascade Connections . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
ThinLAN Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
ConnectingtheHPProCurve10Base-THubstoaFiber-OpticBackbone
1-12
2 Troubleshooting
Troubleshooting Approaches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Diagnosing with the LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Interpreting LED Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Interpreting Hub Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Interpreting Port Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
LED Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Hub Maintenance Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Testing the Hub Only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Clearing a Password for the ASCII Console . . . . . . . . . . . . . . . . . . 2-6
Running Connectivity Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Obtaining Firmware Enhancements . . . . . . . . . . . . . . . . . . . . . . . . 2-8
,QVWDOOEN3DJHL[0RQGD\2FWREHU30

x
A Specifications
B Cables and Connectors
Straight-ThroughTwisted-PairCableforHub-to-ComputerNetworkConnection
B-1
Twisted-Pair Straight-Through Cable . . . . . . . . . . . . . . . . . . . . . . B-3
Twisted-Pair Crossover Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-3
RS-232 Connector and Cable Pin-Outs . . . . . . . . . . . . . . . . . . . . . B-3
Minimum Cable Pinout for ASCII Console Connection . . . . . . . B-4
C Safety and Regulatory Statements
Mounting Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
Power Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3
Informations concernant la sécurité . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4
Hinweise zur Sicherheit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-5
Considerazioni sulla sicurezza . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-6
Consideraciones sobre seguridad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-7
Safety Information (Japanese) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-8
Regulatory Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-9
Index
,QVWDOOEN3DJH[0RQGD\2FWREHU30

1-1
Installing the Hub
1
Installing the Hub
This chapter describes how to install the hub. Topics in this chapter include
■verifying included parts
■installing the transceiver module
■verifying the hub operates correctly
■mounting the hub
■connecting the hub to your network
■connecting hubs together
,QVWDOOEN3DJH0RQGD\2FWREHU30

1-2
Installing the Hub
Installing Your Hub
Installing the HubInstalling the Hub
Installing Your Hub
To install and configure your hub, you must complete six basic tasks. They are:
■locating and verifying the necessary parts
■installing a transceiver module
■connecting the hub to a power source
■mounting the hub
■connecting the hub to your network
1. Verify included parts
Each HP ProCurve 10Base-T Hub has the following components shipped with it:
■This manual. The HP J3301A and HP J3303A both come with the HP
ProCurve 10Base-T Hubs Management and Configuration guide
(5967-6862).
■A power cord, one of the following:
■accessory kit (5183-7210):
• bumper feet (4)
• bracket-to-rack screws 12-24 (7/16") (4)
• bracket-to-hub screws M4 (5/16") (4)
• mounting brackets for 44.55mm (1.75")-height hub (5183-1381)
2. Install the transceiver module
You may want to install the transceiver module and any external transceiver
you may want to attach to it before installing the hub. Transceiver modules
may require more lengthy protrusions created by the greater widths of the
different cables and connectors you may attach to a module (for example, an
Australia/New Zealand
Denmark
Europe
Israel
South Africa
Switzerland
United Kingdom
U.S./Canada/Mexico
(8120-6803)
(8120-6806)
(8120-6802)
(8120-6799)
(8120-6807)
(8120-6807)
(8120-6801)
(8120-6805)
,QVWDOOEN3DJH0RQGD\2FWREHU30

1-3
Installing the Hub
Installing Your Hub
Installing the Hub
external transceiver). Because of these widths, clearance in front of your hub
may be a factor in the placement of the device or stack that contains
protruding transceiver connectors, for example, a BNC connectors.
Inspect your installation site and identify whether enough room will be
available for the installed transceiver to be connected. Then see the guide that
shipped with your external transceiver for installation instructions. For HP
external transceivers, see the HP Recessed Transceivers Installation Guide
(p/n 5962-0066) for specific instructions.
Your transceiver modules can be one of the following:
■HP J2606A Fiber-Optic Transceiver Module
■HP J2607A Twisted-Pair Transceiver Module
■HP J2608A ThinLAN Transceiver Module
■HP J2609A AUI Port Module
3. Verify the hub operates correctly
Before mounting the hub, connect it to a power source and verify that the hub
will operate correctly.
1. Plug the power cord into the hub’s power cord receptacle and into an AC
power source.
Notes The hub does not have a power switch; it is powered on when the power cord
is plugged in.
Connect female end of included power cord
into male receptacle here and male end of
power cord to an alternating current power
source.
,QVWDOOEN3DJH0RQGD\2FWREHU30

1-4
Installing the Hub
Installing Your Hub
Installing the HubInstalling the Hub
2. Check the LEDs on the hub’s front panel. When the hub is powered on, it
performs a power-on self test. See the table below for the LED self test
time that occurs during the self test. Note the upper number is for the HP
J3300A/HP J3302A and the lower number is for the HP J3301A/HP J3303A.
Figure 1-1. Self Test times for LEDs.
If the hub passes self test, the LEDs behave as described in the following
table. If the LEDs behave in a different way, the hub may failed self test.
See the LED operation table in chapter 2, “Troubleshooting” for a
complete description of the LED behavior.
Table 1-1. Self Test times for LEDs
LED HP J3300A/HP J3302A HP J3301A/HP J3303A
Port LEDs,
Fault,
5 seconds 10 seconds
Activity,
Collision
5 seconds 3 seconds
Xcvr Stays on if module installed.
Off if no module installed.
Stays on if module installed.
Off if no module installed.
Power Stays On Stays On
Fault LED
5 seconds
10 seconds
Collision LED
5 seconds
3 seconds
Power LED on
indefinitely
Activity LED
5 seconds
3 seconds
Port LEDs
5 seconds
10 seconds
Xcvr LED on
indefinitely.
,QVWDOOEN3DJH0RQGD\2FWREHU30

1-5
Installing the Hub
Installing Your Hub
Installing the Hub
Note that once you have connected cables to the hub, an AUI transceiver
LED or twisted pair Port LED stays on if link beat has been detected at
the port from an incoming device and the port is enabled. A Port LED turns
off if link beat is not detected.
When the self test completes successfully, the LEDs go into their normal
operational states. If a hub hardware fault exists, the hub will not
complete self test. This will be indicated by an abnormal LED pattern,
such as all port LEDs staying lit indefinitely. Note that the normal
operational state could include indefinitely blinking LEDs in the event of
a detected intruder. For managed HP ProCurve 10Base-T Hubs, see your
HP ProCurve 10Base-T Hubs Management and Configuration guide for
more information on Intruder Detection and flashing LEDs associated
with it.
If the self test time range elapses and the Fault LED continues to stay on
instead of turning off, the hub may have an error condition. If repeating
the self test does not correct the problem and the Fault LED still stays
continuously on, contact your HP authorized reseller for replacement
information. After the hub has passed its self test, you are ready to mount
the hub. Unplug the hub and proceed to the next step.
4. Mount the hub
Before mounting the hub, unplug it. The HP ProCurve 10Base-T Hubs can
be mounted in three ways:
1. in a rack or cabinet
2. on the wall
3. on a table
The hardware for mounting the hub is included in the accessory kit
(5064-2053) packed with the hub. See Appendix C, “Safety and Regulatory
Statements,” for general mounting precautions.
Rack or Cabinet Mounting
Warning The rack or cabinet should be adequately secured to prevent it from
becoming unstable and/or falling over. Please see Appendix C, “Safety
and Regulatory Statements,” for precautions and warnings associated with
rack mounting.
,QVWDOOEN3DJH0RQGD\2FWREHU30

1-6
Installing the Hub
Installing Your Hub
Installing the HubInstalling the Hub
1. Using a Phillips Crosshead No. 2 screwdriver, attach the mounting
brackets to the hub with No. M4 (5/16") silver screws (included in the
accessory kit).
Figure 1-2. Hub-to-Bracket Assembly
2. Position the hub in the rack or cabinet and slide it up or down until the
rack holes line up with the bracket holes.
3. Then attach the bracket to the rack with the No. 12-24 (7/16") screws and
black nylon washers included in the accessory kit with a Phillips Cross-
head No. 2 screwdriver. A flatblade screwdriver will also work in assem-
bling the hub to the rack. Make sure you have screws that fit your cabinet
or rack before mounting the hub.
,QVWDOOEN3DJH0RQGD\2FWREHU30

1-7
Installing the Hub
Installing Your Hub
Installing the Hub
Figure 1-3. Hub-to-Rack Assembly
Wall Mounting
Using a Phillips (crosshead) No. 2 screwdriver, attach the mounting brackets
to the hub with 8-mm (approximately 5/16") M4 screws included in the
accessory kit. Then attach the hub to a wood surface (minimum 1/2-inch
plywood or equivalent) with No. 12 (5/8") wood screws with a Phillips Cross-
head No. 2 screwdriver.
HP recommends that the bottom of the hub should be flush with the wall. The
brackets should be positioned at the front of the hub. The face of the hub
should be pointing up.
Note that the wood screws are not included in the accessory kit. Wood screws have
a pointed and for boring into the wood, unlike rack screws which are flat on the end.
Table Mounting
To place the hub on a table or other horizontal surface, no special tools are
necessary. Apply the four feet included in the accessory kit onto the bottom
of the hub. Be certain to pick a sturdy table in an uncluttered area. You may
want to secure the hub’s cables to the leg of the table to prevent people from
tripping over them.
,QVWDOOEN3DJH0RQGD\2FWREHU30

1-8
Installing the Hub
Installing Your Hub
Installing the HubInstalling the Hub
5. Connect the hub to your network
Connect the hub to an AC power source. With the hub mounted, you are now
ready to connect the hub to your network. Typical hub connections are:
■hub-to-device connections. Connecting to network devices such as
computers, and printers.
■hub-to-hub and hub-to-switch connections. Connecting to another
Ethernet hub.
■hub-to-network backbones. Connecting to a network backbone.
This section describes the different ways you can connect your hub to your
network.
To connect a device to the hub, using unshielded twisted-pair (UTP) cable,
push the RJ-45 plug at one end of the cable into the RJ-45 jack on the hub until
the tab on the plug clicks into place.
Figure 1-4. The RJ-45 Connector
unshielded twisted-pair cable
Category 3, 4, or 5
Cat 3, 4 maximum distance: 100 meters
Cat 5 maximum distance: 150 meters
RJ-45
Connector
AUI/XcvrSlot
10 Mbps Xcvr Port
MDI-X
(out) (In)
MDI
Por t 1 Onl y
113X
7X 19X
2X 14X
8X 20X
3X 15X
9X 21X
4X 16X
10X 22X
5X 17X
11 X 23X
6X 18X
12X 24X
1
Xcvr
Reset
ConsoleFault
Powe r
Clear
7
2
8
3
9
4
10
5
11
6
12
13
19
14
20
Act
15
21
16
22
Col
17
23
18
24
ProCurve 10Base-T Hub 24M
HP J3303A
,QVWDOOEN3DJH0RQGD\2FWREHU30
