HP ProCurve 1600M User manual

installation and
getting started guide
www.hp.com/go/hpprocurve
hp procurve routing switches
9304m, 9308m, and 9315m
(software release
7. 5. X or greater )

Installation and Getting Started Guide
for the HP ProCurve Routing Switches
9304M, 9308M, and 9315M
(Software Release 7.5. X or Greater)

ii
Copyright 2000 – 2002
Hewlett-Packard Company
All rights reserved. Reproduction, adaptation or
translation without prior written permission is
prohibited, except as allowed under the copyright
laws.
Publication number
5990-3041
May 2002
Applicable Products
HP J4138A, HP J4139A, HP J4874A
Trademark Credits
Microsoft®, Windows®, Microsoft Windows NT®and
Internet Explorer®are U.S. trademarks of Microsoft
Corporation. Netscape®Navigator is a U.S.
trademark of Netscape Communications
Corporation. Cisco®is a trademark of Cisco
Systems Inc.
Disclaimer
The information contained in this document is
subject to change without notice.
HEWLETT-PACKARD COMPANY MAKES NO
WARRANTY OF ANY KIND WITH REGARD TO
THIS MATERIAL, INCLUDING BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
Hewlett-Packard shall not be liable for errors
contained herein or for incidental or consequential
damages in connection with the furnishing,
performance or use of this material.
Hewlett-Packard assumes no responsibility for the
use or reliability of its software on equipment that is
not furnished by Hewlett-Packard.
A copy of the specific warranty terms applicable to
your HP product and replacement parts can be
obtained from your HP Sales and Service Office or
authorized dealer.
Warranty
See the Customer Support and Warranty booklet
included with the product.
A copy of the specific warranty terms applicable to
your Hewlett-Packard products and replacement
parts can be obtained from your HP Sales and
Service Office or authorized dealer.
Safety Considerations
Prior to the installation and use of this product,
review all safety markings and instructions.
Instruction Manual Symbol.
If the product is marked with the above symbol, refer
to the product manual to protect the product from
damage.
WARNING Denotes a hazard that can cause injury.
CAUTION Denotes a hazard that can damage
equipment or data.
Do not proceed beyond a WARNING or CAUTION
notice until you have understood the hazard and
have taken appropriate precautions.
Use of control, adjustments or performance
procedures other than those specified herein may
result in hazardous radiation exposure.
Grounding
This product provides a protective earthing terminal.
There must be an uninterrupted safety earth ground
from the main power source to the product’s input
wiring terminals, power cord or supplied power cord
set. Whenever it is likely that the protection has
been impaired, disconnect the power cord until the
ground has been restored.
If your LAN covers an area served by more than one
power distribution system, be sure their safety
grounds are securely interconnected.
LAN cables may occasionally be subject to
hazardous transient voltages (such as lightning or
disturbances in the electrical utilities power grid).
Handle exposed metal components of the network
with caution.
For more safety information, see “Safety and EMC
Regulatory Statements”, beginning on page v.
Servicing
There are no user-serviceable parts inside the user-
installable modules comprising the product. Any
servicing, adjustment, maintenance or repair must
be performed only by service-trained personnel.

iii
Organization of Product Documentation
Read Me First
The “Read Me First” document includes software release information, a brief “Getting Started” section, an
accessory parts list, troubleshooting tips, operating notes, and other information that is not included elsewhere in
the product documentation.
NOTE: HP periodically updates Read Me First . The latest version is available at
http://www.hp.com/go/hpprocurve. (Click on Technical Support, then Manuals.)
Main Product Coverage
The main product documentation for your Routing Switch includes:
•
HP ProCurve Quick Start Guide – a printed guide you can use as an easy reference to the installation and
product safety information needed for out-of-box setup, plus the general product safety and EMC regulatory
statements of which you should be aware when installing and using a Routing Switch.
•
HP ProCurve Installation and Getting Started Guide – an electronic (PDF) guide containing product safety
and EMC regulatory statements as well as installation and basic configuration information. This guide is
included on the CD shipped with your HP product, and is also available on the HP ProCurve website.
•
HP ProCurve Advanced Configuration and Management Guide – contains advanced configuration
information for routing protocols and Quality of Service (QoS). In addition, appendixes in this guide contain
reference information for network monitoring, policies and filters, and software and hardware specifications.
This manual is included in a PDF (Portable Document Format) file on the CD shipped with your HP product,
and also on the HP ProCurve website.
•
HP ProCurve Command Line Interface Reference – provides a dictionary of CLI commands and syntax. An
electronic copy of this reference is included as a PDF (Portable Document Format) file on the CD shipped
with your HP product, and is also available on the HP ProCurve website.
•
HP ProCurve Security Guide – provides procedures for securing management access to HP devices and for
protecting against Denial of Service (DoS) attacks. An electronic copy of this guide is included as a PDF
(Portable Document Format) file on the CD shipped with your HP product, and is also available on the HP
ProCurve website.
These documents also are available in PDF file format on HP's ProCurve website.
Product Documentation CD: A Tool for Finding Specific Information and/or Printing Selected Pages
This CD is shipped with your HP product and provides the following:
•AREADME.txt file (or README.pdf file) describing the CD contents and use, including easy instructions on
how to search the book files for specific information
•Acontents.pdf file to give you easy access to the documentation on the CD
• Separate PDF files of the individual chapters and appendixes in the
Installation and Getting Started Guide ,
Advanced Configuration and Management Guide , and the Security Guide , enabling you to easily print
individual chapters, appendixes, and selected pages
• Single PDF files for each of the books, enabling you to use the Adobe® Acrobat® Reader to easily search for
detailed information
• Additional files. These may include such items as a copy of the device software (OS), additional Readme
files, and release notes.
Release Notes
These documents describe features that became available between revisions of the main product documentation.
New releases of such documents will be available on HP's ProCurve website. To register to receive email notice
from HP when a new software release is available, go to
http://www.hp.com/go/hpprocurve and click on Technical Support, then Software, and click on Subscriber’s
Choice web page.

iv

v
Safety and EMC Regulatory Statements
Safety Information
Grounding
These are safety class I products and have protective earthing terminals. There must be an uninterruptible safety
earth ground from the main power source to the product's input wiring terminals, power cord, or supplied power
cord set. Whenever it is likely that the protection has been impaired, disconnect the power cord until the ground
has been restored.
For LAN cable grounding:
• If your LAN covers an area served by more than one power distribution system, be sure their safety grounds
are securely interconnected.
• LAN cables may occasionally be subject to hazardous transient voltages (such as lightning or disturbances in
the electrical utilities power grid). Handle exposed metal components of the network with caution.
Servicing
There are no user-serviceable parts inside these products. Any servicing, adjustment, maintenance, or repair
must be performed only by service-trained personnel.
These products do not have a power switch; they are powered on when the power cord is plugged in.
Documentation reference symbol. If the product is marked
with this symbol, refer to the product documentation to get
more information about the product.
WARNING A WARNING in the manual denotes a hazard that can
cause injury or death.
CAUTION A CAUTION in the manual denotes a hazard that can
damage equipment.
Do not proceed beyond a WARNING or CAUTION notice
until you have understood the hazardous conditions and
have taken appropriate steps.
!

Installation and Getting Started Guide
vi
