HPE
MSR1000_
MSR2000_MSR3000_MSR4000-
CMW710-R0306P30-US Release Notes
The information in this document is subject to change without notice.
© Copyright 2013, 2016 Hewlett Packard Enterprise Development LP

i
Contents
Version information···········································································1
Version number···························································································································1
Version history ····························································································································2
Hardware and software compatibility matrix ······················································································6
Upgrading restrictions and guidelines·······························································································8
Hardware feature updates··································································8
CMW710-R0306P30-US ···············································································································8
CMW710-R0306P07·····················································································································8
CMW710-R0305P08·····················································································································8
CMW710-R0305P04·····················································································································8
CMW710-R0304P02·····················································································································8
CMW710-R0304··························································································································9
CMW710-E0302P06·····················································································································9
CMW710-E0102··························································································································9
Software feature and command updates ·············································10
MIB updates··················································································10
Operation changes·········································································20
Restrictions and cautions·································································20
Open problems and workarounds ······················································20
List of resolved problems ·································································21
Resolved problems in CMW710-R0306P30-US ··············································································· 21
Resolved problems in CMW710-R0306P12 ···················································································· 24
Resolved problems in CMW710-R0306P11 ···················································································· 25
Resolved problems in CMW710-R0306P07 ···················································································· 28
Resolved problems in CMW710-R0305P08 ···················································································· 31
Resolved problems in CMW710-R0305P04 ···················································································· 37
Resolved problems in CMW710-R0305·························································································· 40
Resolved problems in CMW710-R0304P12 ···················································································· 42
Resolved problems in CMW710-R0304P04 ···················································································· 45
Resolved problems in CMW710-R0304P02 ···················································································· 51
Resolved problems in CMW710-R0304·························································································· 52
Resolved problems in CMW710-E0302P06····················································································· 53
Resolved problems in CMW710-E0102·························································································· 55
Resolved problems in CMW710-E0006P02····················································································· 55
Support and other resources·····························································55
Accessing Hewlett Packard Enterprise Support················································································ 55
Documents ······························································································································· 55
Related documents·············································································································· 56
Documentation feedback ······································································································ 57
Appendix A Feature list ···································································58
Hardware features······················································································································ 58
Software features······················································································································· 65
Appendix B Upgrading software ························································69
Software types ·························································································································· 69
Upgrade methods ······················································································································ 69
Preparing for the upgrade············································································································ 70

ii
Centralized devices upgrading from the CLI···················································································· 71
Saving the running configuration and verifying the storage space················································· 71
Downloading the image file to the router·················································································· 71
Specifying the startup image file····························································································· 72
Rebooting and completing the upgrade ··················································································· 73
Distributed devices upgrading from the CLI····················································································· 74
Display the slot number of the active MPU ··············································································· 74
Save the current configuration and verify the storge space·························································· 74
Download the image file to the router······················································································ 75
Specifying the startup image file····························································································· 75
Reboot and completing the upgrade ······················································································· 77
Distributed devices ISSU············································································································· 78
Disabling the standby MPU auto-update function·······································································79
Saving the running configuration and verifying the storage space················································· 79
Downloading the upgrade image file to the router······································································ 80
Upgrading the standby MPU·································································································· 80
Upgrading the active MPU ···································································································· 82
Upgrading from the BootWare menu······························································································ 84
Accessing the BootWare menu······························································································ 84
Using TFTP/FTP to upgrade software through an Ethernet port ···················································86
Using XMODEM to upgrade software through the console port····················································89
Managing files from the BootWare menu························································································ 93
Displaying all files················································································································ 94
Changing the type of a system software image ·········································································94
Deleting files ······················································································································ 95
Handling software upgrade failures································································································ 96
Appendix C Handling console login password loss ································96
Disabling password recovery capability ·························································································· 96
Handling console login password loss···························································································· 97
Examining the password recovery capability setting···································································97
Using the Skip Current System Configuration option ·································································· 99
Using the Skip Authentication for Console Login option ···························································· 100
Using the Restore to Factory Default Configuration option························································· 100

iii
List of Tables
Table 1 Version history ................................................................................................................. 2
Table 2 HPE product device numbers matrix..................................................................................... 6
Table 3 Hardware and software compatibility matrix ........................................................................ 7
Table 4 MIB updates .................................................................................................................. 10
Table 5 MSR1000 specifications .................................................................................................. 58
Table 6 MSR2000/MSR2000 TAA specifications........................................................................... 58
Table 7 MSR3000/MSR3000 TAA specifications ........................................................................... 59
Table 8 MSR4000 specifications.................................................................................................. 60
Table 9 MSR4000/MSR4000 TAA MPU Specification .................................................................... 60
Table 10 MSR4000 SPU Specification .......................................................................................... 60
Table 11 MSR2004-24 AC power module specifications ...................................................................61
Table 12 MSR2004-48 DC power module specifications ..................................................................61
Table 13 MSR3044/MSR3064/MSR4060/MSR4080 AC power module specifications .......................61
Table 14 MSR3044/MSR3064/MSR4060/MSR4080 DC power module specifications .......................61
Table 15 MSR3044/MSR3064/MSR4060/MSR4080 PoE power module specifications.......................61
Table 16 MSR series routes Module List ..........................................................................................61
Table 17 Sierra Modem Module and Host/card compatibility matrix ................................................. 65
Table 18 MSR Series routers software features................................................................................ 65
Table 19 Storage media ............................................................................................................. 70
Table 20 BootWare menu options................................................................................................ 85
Table 21 Ethernet submenu options............................................................................................... 86
Table 22 Network parameter fields and shortcut keys...................................................................... 87
Table 23 Serial submenu options.................................................................................................. 89
Table 24 File Control submenu options.......................................................................................... 94
Table 25 BootWare options and password recovery capability compatibility matrix............................. 96

1
This document describes the features, restrictions and guidelines, open problems, and workarounds
for version R0306P30 & R0306P30-US. In the interest of brevity, any reference to R0306P30 is also
applicable to R0306P30-US throughout the remainder of this document. See the "Restrictions and
Cautions" section for exceptions. Before you use this version in a live network, back up the
configuration and test the version to avoid software upgrade affecting your live network.
Version information
Version number
HPE Comware Software, Version 7.1.059, Release 0306P30-US
Please see the example below generated by the display version command:
<HPE> display version
HPE Comware Software, Version 7.1.059, Release 0306P30
Copyright (c) 2010-2016 Hewlett Packard Enterprise Development LP
HPE MSR3064 uptime is 0 weeks, 0 days, 0 hours, 2 minutes
Last reboot reason : User reboot
Boot image: cfa0:/msr3000-cmw710-boot-r0306p30.bin
Boot image version: 7.1.059P20, Release 0306P30
Compiled Mar 16 2016 16:00:00
System image: cfa0:/msr3000-cmw710-system-r0306p30.bin
System image version: 7.1.059, Release 0306P30
Compiled Mar 16 2016 16:00:00
Feature image(s) list:
cfa0:/msr3000-cmw710-security-r0306p30.bin, version: 7.1.059
Compiled Mar 16 2016 16:00:00
cfa0:/msr3000-cmw710-voice-r0306p30.bin, version: 7.1.059
Compiled Mar 16 2016 16:00:00
cfa0:/msr3000-cmw710-data-r0306p30.bin, version: 7.1.059
Compiled Mar 16 2016 16:00:00
CPU ID: 0x4
2G bytes DDR3 SDRAM Memory
8M bytes Flash Memory
PCB Version: 2.0
CPLD Version: 2.0
Basic BootWare Version: 1.60
Extended BootWare Version: 1.60
[SLOT 0]AUX (Hardware)2.0, (Driver)1.0, (CPLD)2.0
[SLOT 0]GE0/0 (Hardware)2.0, (Driver)1.0, (CPLD)2.0
[SLOT 0]GE0/1 (Hardware)2.0, (Driver)1.0, (CPLD)2.0
[SLOT 0]GE0/2 (Hardware)2.0, (Driver)1.0, (CPLD)2.0
[SLOT 0]CELLULAR0/0 (Hardware)2.0, (Driver)1.0, (CPLD)2.0
[SLOT 0]CELLULAR0/1 (Hardware)2.0, (Driver)1.0, (CPLD)2.0
[SLOT 6]HMIM-1CE3 (Hardware)2.0, (Driver)1.0, (CPLD)1.0
[SLOT 7]HMIM-2T1 (Hardware)3.0, (Driver)1.0, (CPLD)4.0
[SLOT 9]HMIM-4T1-F (Hardware)3.0, (Driver)1.0, (CPLD)3.0

2
Version history
Table 1 Version history
Version
number
Last version Release
date
Release
type
Remarks
CMW710-R0306
P30 CMW710-R03 06P12 2016-06-0 8 Release version
MSR1000_2000_3000_4000 series,
including MSR1003-8S and
MSR3012 AC
•New feature:
1. SIP compatibility
•Modified feature:
1. OSPF performance
2.Telnet redirect
3.POS terminal access
4.License
5.IP performance optimization
•Fixes bugs
CMW710-R0306
P12 CMW710-R03 06P11 2016-04-2 7 Release version
MSR1000_2000_3000_4000 series,
including MSR1003-8S and
MSR3012 AC
•Modified feature:
1. Configuring an SSH user
2. AAA
3. Configuring a cellularinterface for a
3G/4G modem
4. VXLAN
5. DHCP
•Fixes bugs.
CMW710-R0306
P11 CMW710-R03 06P07 2016-04-1 3 Release version
MSR1000_2000_3000_4000 series,
including MSR1003-8S and
MSR3012 AC
•New feature:
1. Voice VLAN
•Modified feature:
1. MPLS QoS support for matching
the EXP field
2. MPLS QoS support for marking the
EXP field
3. Automatic configuration
•Removed feature
1. Tinyproxy
•Fixes bugs.
CMW710-R0306
P07 CMW710-R03 05P08 2016-03-1 6 Release version
MSR1000_2000_3000_4000 series,
including MSR1003-8S and
MSR3012 AC
•New feature:
1. L2TP-based EAD
2. CFD configuration
•Modified feature:
1. Support using dots in user profile

3
name
2. Default size of the TCP receive and
send buffer
3. Support for obtaining fan tray and
power module vendor information
through MIB
4. Supporting per-packet load sharing
5. Automatic configuration
6. Software image signature
•Fixes bugs.
CMW710-R0305
P08 CMW710-R03 05P04 2016-01-1 0 Release version
MSR1000_2000_3000_4000 series,
including MSR1003-8S and
MSR3012 AC
•New feature:
1. mGRE
2. Disabling transceiver module alarm
•Modified feature:
1. Default user role
2. Debugging
•Fixes bugs.
CMW710-R0305
P04 First release 2015-12-1 8 Release version Only support MSR3012 AC Router
CMW710-R0305
P04 CMW710-R03 05 2015-11-2 5 Release version
MSR1000_2000_3000_4000 series,
including MSR1003-8S
•New feature:
1. Public key management support for
Suite B
2. PKI support for Suite B
3. IPsec support for Suite B
4. SSL support for Suite B
5. FIPS support for Suit B
6. SSH support for Suite B
7. Ignoring the first AS number of
EBGP route updates for a peer or
peer group
•Modified feature:
1. Support for Ethernet link
aggregation on Layer 3 Ethernet
subinterfaces
2. Changing the maximum number of
FIB table entries
3. Enabling CWMP
4. The logo of HP is changed to HPE
•Fixes bugs.
CMW710-R0305 CMW710-R03
04P12 2015-10-2 3 Release version
MSR1000_2000_3000_4000 series,
including MSR1003-8S
•New feature:
1. IKE
•Modified feature:
1. IPsec
•Fixes bugs.

4
CMW710-R0304
P12 CMW710-R03 04P04 2015-09-1 5 Release version
MSR1000_2000_3000_4000 series,
including MSR1003-8S
•New feature:
1. Including vendor information in
PPP accounting requests
2. BFD for an aggregation group
•Modified feature:
1. SSH username
2. IS-IS hello packet sending interval
3. MP-group interface numbering
•Fixes bugs.
CMW710-R0304
P04 CMW710-R03 04P02 2015-08-1 8 Release version
Support MSR1000_2000_3000_4000
series, including MSR1003-8S
•New feature:
1. Media Stream Control (MSC)
logging
•Modified feature:
1. ESP encryption algorithms
•Fixes bugs.
CMW710-R0304
P02 CMW710-R03 04 2015-07-2 2 Release version
Support MSR1000_2000_3000_4000
series, including MSR1003-8S
•New feature:
1. IMSI/SN binding authentication
2. Specifying a band for a 4G modem
3. CFD
4. Using tunnel interfaces as
OpenFlow ports
5. NETCONF support for ACL filtering
6. Specifying a backup traffic
processing unit
7. WAAS
8. Support for the MKI field in SRTP or
SRTCP packets
9. SIP domain name
10. E&M logging
11. Add new cards
•Modified feature:
1. Setting the global link-aggregation
load-sharing mode
•Fixes bugs.
CMW710-R0304 CMW710-E03
02P06 2015-06-2 9 Release version
Support MSR1000_2000_3000_4000
series, added MSR1003-8S
•New feature:
1. Setting the RTC version
2. Setting the maximum size of
advertisement files
3. IRF
4. Frame Relay
5. EVI
6. VPLS

5
7. Multicast VPN support for inter-AS
option B
•Modified feature:
1. 802.1X redirect URL
2. Displaying information about NTP
servers from the reference source to
the primary NTP server
3. Saving, rolling back, and loading
the configuration
4. Displaying information about SSH
users
•Removed feature
1. Displaying fabric utilization
•Fixes bugs
CMW710-E0302
P06 CMW710-E01 02 2015-04-1 3 ESS version
Support MSR1000_2000_3000_4000
series
•New feature:
1. Object policies
2. IPHC
3. Support of PPPoE server for IPv6
4. QSIG tunneling over SIP-T
5. Playout delay
6. BGP L2VPN support for NSR
7. BGP support for dynamic peers
8. ARP PnP
9. Support of Syslog for DNS and
support of customlog&userlog for
IPv6 hosts
10. QoS soft forwarding
11. Filtering by application layer
protocol status
12. ADVPN support for multicast
forwarding
13. MPLS LDP support for IPv6
14. Port security
15. Customizable IVR
16. SRST
17. NEMO
18. Support of MFR and FR for
L2VPN, FR QoS, and FR
compression and fragmentation
19. Support for LLDP on CPOS
interfaces
20. SMS-based automatic
configuration
21. ARP attack protection
22. SIP support for VRF
•Fixes bugs
CMW710-E0102 CMW710-E00
06P02 2013-08-1 0 ESS version Support MSR2000_3000_4000 series
•New feature:
1. Portal authentication

6
2. MSDP
3. IPsec MIB and IKE MIB
4. PoE
5. CoPP software forwarding feature
6. Configuring MPLS LDP FRR
7. Enhanced routing features
8. Python
9. ATM
10. DHCP MIB
•Fixes bugs.
CMW710-E0006
P02 CMW710-E00 06 2013-04-2 3 ESS version Only support MSR3000_4000 series,
not support MSR2000 series
•Fixes bugs.
CMW710-E0006 First release 2013-01-2
8 ESS version None
Hardware and software compatibility matrix
CAUTION:
To avoid an upgrade failure, use
Table 3 to verify the hardware and software compatibility before
performing an upgrade.
Table 2 HPE product device numbers matrix
Product code
HPE Product name
JG402A HPE MSR4080 Router Chassis
JG403A HPE MSR4060 Router Chassis
JG404A HPE MSR3064 Router
JG405A HPE MSR3044 Router
JG406A HPE MSR3024 AC Router
JG407A HPE MSR3024 DC Router
JG408A HPE MSR3024 PoE Router
JG409A HPE MSR3012 AC Router
JG410A HPE MSR3012 DC Router
JG411A HPE MSR2003 AC Router
JG412A HPE MSR4000 MPU-100 Main Processing Unit
JG413A HPE MSR4000 SPU-100 Service Processing Unit
JG414A HPE MSR4000 SPU-200 Service Processing Unit
JG670A HPE MSR4000 SPU-300 Service Processing Unit
JG875A HPE MSR1002-4 AC Router
JH060A HPE MSR1003-8S AC Router
JG861A HPE MSR3024 TAA-compliant AC Router

7
JG734A HPE MSR2004-24 AC Router
JG735A HPE MSR2004-48 Router
JG866A HPE MSR2003 TAA-compliant AC Router
JG869A HPE MSR4000 TAA-compliant MPU-100 Engine
JG409B HPE MSR3012 AC Router
Table 3 Hardware and software compatibility matrix
Item
Specifications
Product
family MSR1000_MSR2000_MSR3000_MSR4000
Boot ROM
version
MSR1002-4_MSR1003-8S: 250 or higher
MSR2003_MSR2004-24_MSR2004-48: 160 or higher
MSR3012_MSR3024_MSR3044_MSR3064: 160 or higher
MSR4060_MSR4080: MPU-100: 161 or higher
SPU-100/200: 140 or higher
Host
software
Hardware software SHA256 Digest File size
MSR1002-4_MS
R1003-8S
MSR100X-CMW7
10-R0306P30-US.
IPE
f9ac658347c31c032a
904a283dc90125ca8d
0873d65c0b2f5b9893
5bf66bca93
66,249,728 bytes
MSR2003_MSR2
004-24_MSR200
4-48
MSR2000-CMW7
10-R0306P30-US.
ipe
cda248e984a4c794ae
f8874954ff052100262
02820b7aa80c876048
f750587e0
71,246,848 bytes
MSR3012_MSR3
024_MSR3044_
MSR3064
MSR3000-CMW7
10-R0306P30-US.
ipe
d302bd06f3406982f34
00f10d21a4970f104c3
0fcbd738d0a2ae775a
b4ccb3af
54,891,520 bytes
MSR4060_MSR4
080
MSR4000-CMW7
10-R0306P30-US.
ipe
5b0476b70a06917894
7cdecb9db994efe1e7
183cd3be0a1deba32d
f1373a6a49
116,921,344 bytes
iMC version
iMC BIMS 7.2 (E0402P02)
iMC EAD 7.2 (E0407)
iMC TAM 7.2 (E0407)
iMC UAM 7.2 (E0407)
iMC IVM 7.2 (E0402H02)
iMC MVM 7.2 (E0402P02)
iMC NTA 7.2 (E0402P02)
iMC PLAT 7.2 (E0403P04)
iMC QoSM 7.2 (E0403H01)
iMC RAM 7.2 (E0402)
iMC SHM 7.2 (E0402l01)
iMC UBA 7.2 (E0401p03)
iMC VFM 7.2 (E0403)
iNode
iNode PC 7.2 (E0407)

8
version
Cards
version
Cards Name Software Version CPLD or FPGA version
SIC-3G-HSPA 280 or higher 200 or higher
SIC-3G-CDMA 280 or higher 200 or higher
Upgrading restrictions and guidelines
1. After the software is upgraded from a version earlier than E0302P06 to E0302P06 or a later
version, the unit of the VRRP preemption delay is changed from seconds to centiseconds.
2. To upgrade from R0305 to R0305P04 or a later version, you must first install the R0305H01 hot
patch.
Hardware feature updates
CMW710-R0306P30-US
Add new hardware:
Add new card:
4-port 100BASE-FX/1000BASE-X(SFP) Ethernet L2/L3 SIC Module-RT-SIC-4GSWF
CMW710-R0306P07
Add new hardware:
SFP-GPON-SM-ONU
USB modem E3533
CMW710-R0305P08
Add new router:
HPE MSR3012 AC Router(JG409B)
Add new card:
1-port E1 / T1 Voice SIC Module(JH240A)
CMW710-R0305P04
The logo of HP is changed to HPE.
CMW710-R0304P02
Add new cards:
HPE MSR 4GLTE SIC Mod for CDMA/WCDMA (JG742B)
HPE MSR 4G LTE SIC Mod for ATT (JG743B)

9
HPE MSR 4GLTE SIC Mod for Global (JG744B)
HPE MSR HSPA+/WCDMA SIC Module (JG929A)
CMW710-R0304
Add new router:
HPE MSR1003-8S AC Router
CMW710-E0302P06
Add new hardware:
8-port E1 / CE1 / T1 / CT1 / PRI HMIM Module (JH169A)
4-port E1 / CE1 / T1 / CT1 / PRI HMIM Module (JH170A)
2-port E1 / CE1 / T1 / CT1 / PRI HMIM Module (JH171A)
8-port E1 / Fractional E1 / T1 / Fractional T1 HMIM Module (JH172A)
4-port E1 / Fractional E1 / T1 / Fractional T1 HMIM Module (JH173A)
2-port E1 / Fractional E1 / T1 / Fractional T1 HMIM Module (JH174A)
8-port 100BASE-FX/1000BASE-X / 4-port 1000BASE-T (Combo) L2/L3 HMIM Module (JH238A)
CMW710-E0102
Add new hardware:
4-port 10/100 Mbps Ethernet L2 switching module-PoE card(SIC-4FSW-POE)
1-port ADSL over POTS SIC interface module (SIC-1ADSL)
1 port E1/CE1/PRI SIC interface module(SIC-1EPRI-V3)
9-port 10/100 Mbps Ethernet L2 switching module -PoE card (DSIC-9FSW-POE)
1-port 8-wire G.SHDSL (RJ45) DSIC Module
2-port 1000BASE-X HMIM Module (HMIM-2GEF)
4-port 1000BASE-X HMIM Module (HMIM-4GEF)
8-port 1000BASE-X HMIM Module (HMIM-8GEF)
24-port Gig-T Switch HMIM Module (HMIM-24GSW)
24-port Gig-T PoE Switch HMIM Module (HMIM-24GSW-POE)
1-port OC-3 / STM-1 CPOS HMIM Module (HMM-1CPOS)
2-port OC-3 / STM-1 CPOS HMIM Module (HMIM-2CPOS)
1-port OC-3c / STM-1c ATM SFP HMIM Module (HMIM-ATMOC3)
1-port dual-pair G.SHDSL interface module (MIM-1SHL-4W)(need to config HMIM-Adapter)
SPU-300 service module
MSR3012-DC
MSR3024-DC
MSR3024-POE

10
300W DCPower(PSR300-12D2)
Support USB modem E303c and E3131
Software feature and command updates
For more information about the software feature and command update history, see HPE
MSR1000_MSR2000_MSR3000_MSR4000-CMW710-R0306P30 Release Notes (Software
Feature Changes).
MIB updates
Table 4 MIB updates
Item
MIB file
Module
Description
CMW710-R0306P30-US
New None None None
Modified None None None
CMW710-R0306P12
New None None None
Modified rfc1213.mib RFC1213-MIB Modified description of
sysDescr and sysObjectID
CMW710-R0306P11
New None None None
Modified rfc1213.mib RFC1213-MIB Modified description of
sysObjectID
CMW710-R0306P07
New None None None
Modified rfc1213.mib RFC1213-MIB Modified description of
sysDescr and sysObjectID
CMW710-R0305P08
New None None None
Modified hh3c-3gmodem.mib HH3C-3GMODEM-MIB
Modified description of
hh3cWirelessCardOnlineTa
ble,
hh3cWirelessCardModemM
ode,
hh3cWirelessCardCurNetCo
nn,
hh3cWirelessCardOnlineTim
e,
hh3cWirelessCardOnlineTyp
e,
hh3cUIMInfoTable,hh3cUIMI
ndex,
hh3cUIMStatus,hh3cUIMIms
i, hh3c3GCdma1xRttBID,
hh3c3GCdma1xRttSID,
hh3c3GCdma1xRttNID,
hh3c3GCdmaEvDoSubNetI
D, hh3c3GGsmMcc,

11
hh3c3GGsmMnc,
hh3cSmsSrcNumberBind,
hh3cSmsTimeBind,
hh3cSmsEncodeBind,
hh3cSmsContentBind,
hh3cSmsRxNotifSwitch and
hh3cSmsRxNotification
CMW710-R0305P04
New None None None
Modified rfc1213.mib RFC1213-MIB
Modified description of
sysDescr, sysContact,
sysName and sysLocation,
sysObjectID
CMW710-R0305
New None None None
Modified rfc1213.mib RFC1213-MIB Modified description of
sysDescr and sysObjectID
CMW710-R0304P12
New None None None
Modified
rfc2925-disman-ping.mib DISMAN-PING-MIB Modified description of
pingCtlTable
hh3c-nqa.mib HH3C-NQA-MIB Modified description of
hh3cNqaCtlTable
hh3c-mplsext.mib HH3C-MPLSEXT-MIB Added
hh3cMplsExtVpnStatsTable
CMW710-R0304
New None None None
Modified hh3c-transceiver-info.mib HH3C-TRANSCEIVER-INF
O-MIB
Modified description of
hh3cTransceiverCurTXPow
er and
hh3cTransceiverCurRXPow
er
CMW710-E0302P06
New
hh3c-stack.mib HH3C-STACK-MIB Added HH3C-STACK-MIB
rfc5060-pim-std.mib PIM-STD-MIB Added PIM-STD-MIB
rfc5240-pim-bsr.mib PIM-BSR-MIB Added PIM-BSR-MIB
hh3c-qinqv2.mib HH3C-QINQV2-MIB Added
HH3C-QINQV2-MIB
rfc3019-ipv6-mld.mibs IPV6-MLD-MIB Added IPV6-MLD-MIB
hh3c-nqa.mib HH3C-NQA-MIB Added HH3C-NQA-MIB
hh3c-posa.mib HH3C-POSA-MIB Added HH3C-POSA-MIB
rfc1473-ppp-ip.mib PPP-IP-NCP-MIB Added PPP-IP-NCP-MIB
rfc1471-ppp-lcp.mib PPP-LCP-MIB Added PPP-LCP-MIB
hh3c-mp-v2.mib HH3C-MP-V2-MIB Added HH3C-MP-V2-MIB
hh3c-mplsext.mib HH3C-MPLSEXT-MIB Added
HH3C-MPLSEXT-MIB

12
hh3c-mplste.mib HH3C-MPLSTE-MIB Added H3C-MPLSTE-MIB
rfc6445-mpls-frr-facility-std.m
ib MPLS-FRR-FACILITY-STD -MIB
Added
MPLS-FRR-FACILITY-STD-
MIB
rfc6445-mpls-frr-general-std.
mib MPLS-FRR-GENERAL-ST D-MIB
Added
MPLS-FRR-GENERAL-STD
-MIB
rfc3812-mpls-te-std.mib MPLS-TE-STD-MIB Added MPLS-TE-STD-MIB
rfc3970-te.mib TE-MIB Added TE-MIB
hh3c-transceiver-info.mib HH3C-TRANSCEIVER-INF
O-MIB
Added
HH3C-TRANSCEIVER-INF
O-MIB
rfc5519-mgmd-std.mib MGMD-STD-MIB Added MGMD-STD-MIB
rfc4560-disman-traceroute.m
ib DISMAN-TRACEROUTE- MIB
Added
DISMAN-TRACEROUTE-MI
B
rfc2925-disman-ping.mib DISMAN-PING-MIB Added DISMAN-PING-MIB
rfc5603-pw-enet-std.mib PW-ENET-STD-MIB Added PW-ENET-STD-MIB
rfc5601-pw-std.mib PW-STD-MIB Added PW-STD-MIB
hh3c-snmp-ext.mib HH3C-SNMP-EXT-MIB Added
HH3C-SNMP-EXT-MIB
hh3c-posa.mib HH3C-POSA-MIB Added HH3C-POSA-MIB
hh3c-bfd-std.mib HH3C-BFD-STD-MIB Added HH3C-BFD-STD-MIB
hh3c-ppp-over-sonet.mib HH3C-PPP-OVER-SONET
-MIB
Added
HH3C-PPP-OVER-SONET-
MIB
rfc3815-mpls-ldp-std.mib MPLS-LDP-STD-MIB Added MPLS-LDP-STD-MIB
rfc4382-mpls-l3vpn-std.mib MPLS-L3VPN-STD-MIB Added
MPLS-L3VPN-STD-MIB
hh3c-license.mib HH3C-LICENSE-MIB Added HH3C-LICENSE-MIB
hh3c-tunnel.mib HH3C-TUNNEL-MIB Added HH3C-TUNNEL-MIB
rfc5643-ospfv3.mib OSPFV3-MIB Added OSPFV3-MIB
rfc2981-disman-event.mib DISMAN-EVENT-MIB Added
DISMAN-EVENT-MIB
hh3c-pvst.mib HH3C-PVST-MIB Added HH3C-PVST-MIB
hh3c-evi.mib HH3C-EVI-MIB Added HH3C-EVI-MIB
hh3c-l2vpn.mib HH3C-L2VPN-MIB Added HH3C-L2VPN-MIB
Modified
rfc4444-isis.mib ISIS-MIB Modified description of
isisSysLevelMinLSPGenI
nt
rfc1213.mib RFC1213-MIB
Modified description of
sysDescr and sysObjectID;
Modified TAA description of
sysObjectID;
Modified index of
ipv6InterfaceTable; Modified

13
description of sysContact
and sysLocation;
Modified Access of
ipAddressStorageType.
rfc4444-isis.mib ISIS-MIB
Modified description of
isisRouterID,
isisSysLevelTEEnabled,
isisNextCircIndex,
isisCirc3WayEnabled,
isisCircExtendedCircID,
isisISAdj3WayState 和
isisISAdjNbrExtendedCirc
ID
rfc2465-ipv6.mib IPV6-MIB Modified description of
ipv6IfDescr
hh3c-splat-mstp.mib HH3C-LswMSTP-MIB Modified description of
hh3cdot1sStpForceVersi
on
rfc2933-igmp-std.mib IGMP-STD-MIB Modified description and
PDS of IGMP-STD-MIB
rfc2863-if.mib IF-MIB Updated the
rfc2863-if.mib from
rfc2233-if.mib
hh3c-dns.mib HH3C-DNS-MIB Modified description of
HH3C-DNS-MIB
hh3c-domain.mib H3C-DOMAIN-MIB Modified description of
HH3C-DOMAIN-MIB
hh3c-sys-man.mib HH3C-SYS-MAN-MIB Modified example of
hh3cSysBtmLoadTable
hh3c-config-man.mib HH3C-CONFIG-MAN-MIB
Modified description of
hh3cCfgLogTerminalUser
and
hh3cCfgLogCmdSrcAddress
rfc2933-igmp-std.mib IGMP-STD-MIB
Modified description of
igmpInterfaceQueryMaxRes
ponseTime,
igmpInterfaceRobustness,
igmpInterfaceLastMembQue
ryIntvl,
mldInterfaceQueryMaxResp
onseDelay,
mldInterfaceRobustness,
mldInterfaceLastListenQuer
yIntvl;
Modified PDS of
igmpCacheAddress,
igmpCacheIfIndex,
igmpCacheSelf,
mldCacheAddress,
mldCacheIfIndex,
mldCacheSelf
rfc2925-disman-ping.mib DISMAN-PING-MIB Modified description of
pingCtlIfIndex;
Added pingProbeFailed,

14
pingTestFailed,
pingTestCompleted,
hh3cNqaProbeTimeOverThr
eshold,
hh3cNqaJitterRTTOverThre
shold,
hh3cNqaProbeFailure,
hh3cNqaJitterPacketLoss,
hh3cNqaJitterSDOverThres
hold,
hh3cNqaJitterDSOverThres
hold,
hh3cNqaICPIFOverThreshol
d,
hh3cNqaMOSOverThreshol
d
rfc4133-entity.mib ENTITY-MIB Modified description of
entPhysicalAlias,
entPhysicalAssetID
hh3c-if-ext.mib HH3C-IF-EXT-MIB Modified description of
HH3C-IF-EXT-MIB
hh3c-config-man.mib HH3C-CONFIG-MAN-MIB Modified description of
HH3C-CONFIG-MAN-MIB
hh3c-trng2.mib HH3C-TRNG2-MIB Modified description of
HH3C-TRNG2-MIB
rfc2925-disman-ping.mib DISMAN-PING-MIB Modified description of
pingCtlTable
hh3c-ntp.mib HH3C-NTP-MIB Modified description of
hh3cNTPSystemMIB
hh3c-entrelation.mib HH3C-ENTRELATION-MIB Modified description of
hh3cEntRelationTable
hh3c-entity-ext.mib HH3C-ENTITY-EXT-MIB
Added
hh3cEntityExtCpuUsageRec
overThreshold,
hh3cEntityExtMemSizeRev,
hh3cEntityExtCpuUsageIn1
Minute,
hh3cEntityExtCpuUsageIn5
Minutes,
hh3cEntityExtVoltageTable;
Modified description and
relationship of
hh3cEntityExtTemperatureT
hreshold,
Modified description of
hh3cEntityExtTemperature.
hh3c-ssh.mib HH3C-SSH-MIB Added hh3cSTelnetServerEnable,
hh3cSCPServerEnable
hh3c-lsw-dev-adm.mib HH3C-LSW-DEV-ADM-MI
B
Added
hh3cLswSlotMemRev,
hh3cLswSlotPhyMemRev
, hh3cLswSlotRunTime
and
hh3cLswSlotMemUsedR
ev

15
hh3c-lsw-dev-adm.mib HH3C-LSW-DEV-ADM-MI
B Added hh3cLswCpuTable
hh3c-3gmodem.mib HH3C-3GMODEM-MIB Added hh3cLteInfoTable
hh3c-trap.mib HH3C-TRAP-MIB Modified description of
hh3cTrapConfigSwitch
rfc2863-if.mib IF-MIB Modified description of
ifOutQLen
hh3c-ip-address.mib HH3C-IP-ADDRESS-MIB Added
hh3cIpAddrFirstTrapTime
fc1471-ppp-lcp.mib PPP-LCP-MIB Modified description of
pppLinkStatusBadFCSs
ieee8023-lag.mib IEEE8023-LAG-MIB Modified title of
IEEE8023-LAG-MIB
hh3c-lag.mib HH3C-LAG-MIB Modified title of
HH3C-LAG-MIB
hh3c-domain.mib HH3C-DOMAIN-MIB Modified description of hh3cDomainDefault and
hh3cDomainName
hh3c-if-ext.mib HH3C-IF-EXT-MIB Added hh3cIfOperStatus
and hh3cIfDownTimes
rfc5603-pw-enet-std.mib PW-ENET-STD-MIB Modified pwEnetTable
rfc5602-pw-mpls-std.mib PW-MPLS-STD-MIB Modified the module of
PW-MPLS-STD-MIB
rfc5603-pw-enet-std.mib PW-ENET-STD-MIB Modified the table of
PW-ENET-STD-MIB
table hh3cPosParamTable HH3C-PPP-OVER-SONET
-MIB Only support POS interfaces
hh3c-acl.mib HH3C-ACL-MIB
Modified
hh3cAclNumberGroupTable,
hh3cPfilterApplyTable,
hh3cPfilterAclGroupRunInfo
Table,
hh3cPfilterStatisticSumTabl
e and added the
hh3cAclNamedGroupTable,
hh3cAclIPAclNamedBscTabl
e,
hh3cAclIPAclNamedAdvTab
le,
hh3cAclNamedMACTable,
hh3cAclIntervalTable
hh3cAclNamedUserTable,
hh3cPfilter2ApplyTable,
hh3cPfilter2,
hh3cPfilter2AclGroupRunInf
oTable,
hh3cPfilter2AclRuleRunInfo
Table,
hh3cPfilter2StatisticSumTab
le,
hh3cAclNamedGroupTable
hh3c-stack.mib HH3C-STACK-MIB Modified description of
hh3cStackTopology

16
rfc2819-rmon.mib RMON-MIB Modified description of
default value in RMON-MIB
rfc4502-rmon.mib RMON2-MIB Modified description of
default value in RMON2-MIB
lldp-ext-dot1-v2.mib LLDP-EXT-DOT1-V2-MIB
Removed
lldpXdot1dcbxConfigETSCo
nfigurationTable
lldpXdot1dcbxConfigETSRe
commendationTable
lldpXdot1dcbxConfigPFCTa
ble
lldpXdot1dcbxConfigApplicat
ionPriorityTable
lldpXdot1dcbxLocETSBasic
ConfigurationTable
lldpXdot1dcbxLocETSConPr
iorityAssignmentTable
lldpXdot1dcbxLocETSConTr
afficClassBandwidthTable
lldpXdot1dcbxLocETSConTr
afficSelectionAlgorithmTable
lldpXdot1dcbxLocETSReco
TrafficClassBandwidthTable
lldpXdot1dcbxLocETSReco
TrafficSelectionAlgorithmTa
ble
lldpXdot1dcbxLocPFCBasic
Table
lldpXdot1dcbxLocPFCEnabl
eTable
lldpXdot1dcbxLocApplicatio
nPriorityAppTable
lldpXdot1dcbxRemETSBasi
cConfigurationTable
lldpXdot1dcbxRemETSCon
PriorityAssignmentTable
lldpXdot1dcbxRemETSCon
TrafficClassBandwidthTable
lldpXdot1dcbxRemETSCon
TrafficSelectionAlgorithmTa
ble
lldpXdot1dcbxRemETSReco
TrafficClassBandwidthTable
lldpXdot1dcbxRemETSReco
TrafficSelectionAlgorithmTa
ble
lldpXdot1dcbxRemPFCBasi
cTable
lldpXdot1dcbxRemPFCEnab
leTable
lldpXdot1dcbxRemApplicatio
