HPE FlexNetwork MSR954 User manual

The installation tools are not provided with the router. Prepare them yourself.
Installation tools
Wall-mounting the router
!
!
Part number:5998-8749
HPE FlexNetwork MSR954 Routers Quick Start-6W103
4G antenna
Wall anchor kit
(user supplied)
WLAN antenna Grounding cable Rubber feet
Cage nut
(user supplied)
M6 screw
(user supplied)
M4 screw
(user supplied) Mounting brackets
Ruler Wire-stripping pliers Rubber hammer
Drill MarkerDiagonal pliers
Flathead screwdriver
Phillips screwdriver
ESD wrist strap
When you mount the router on a wall, make sure the Ethernet ports face
downwards and the two sides with ventilation holes are perpendicular to the
ground.
Applicable products
HPE MSR954 Routers (JH296A/JH297A/JH298A/JH299A/JH373A).
!
≥22 mm (0.87 in)
≥1.5 mm
(0.06 in)
1
2
3 4
5 6
1
2
160 mm (6.30 in)：JH296A/JH297A/JH298A/
JH299A
240mm(9.45in)：JH373A
Introduction to installation accessories

Installing SIM cards for the JH373A router
Use standard SIM cards for the router.
!
The SIM1 slot is associated with the antenna
connectors on the front panel.
The SIM2 slot is associated with the antenna
connectors on the rear panel.
SIM2 SIM1
Attach the 4G antennas to the router
and change the antenna orientation
from horizontal to vertical.
Installing 4G antennas
Only the JH298A, JH299A and JH373A routers support 4G antennas. You can
install two 4G antennas on the JH298A/JH299A router and four 4G antennas
on the JH373A router.
!
Installing two 4G antennas on the JH298A/JH299A router .
Installing four 4G antennas on the JH373A router .
Correct installation:
1 2 3
4 5 6
Incorrect installation:
5
6
Attach the 4G antennas to the router
and change the antenna orientation
from horizontal to vertical.

Installing WLAN antennas
Attach the WLAN antennas to the router and change the antenna orientation from
horizontal to vertical.
Connecting the grounding cable to the router
Correctly connecting the grounding cable is crucial to lightning protection and
EMI protection. Attach the ring terminal provided with the router to the
grounding cable. Make sure the grounding cable is reliably grounded.
!
1 2
You can install two WLAN antennas for the JH297A, JH298A, and JH299A routers.
The JH296A and JH373A routers do not support WLAN antennas.
!
7
8
Connecting an Ethernet cable
Connecting the router to a configuration terminal by using
a console cable
If the configuration terminal does not have an RS-232 serial port, a
serial adapter is required to connect the console cable to a USB port on
the terminal.
!
