HPE ProLiant DL385 Gen10 Plus Manual

HPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service GuideHPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service Guide
Part Number: 30-3659EF03-004
Published: March 2022
Edition: 3

HPE ProLiant DL385 Gen10 Plus v2 ServerHPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service Guide Maintenance and Service Guide
AbstractAbstract
This document is for the person who installs, administers, and troubleshoots servers and storage systems. Hewlett Packard Enterprise
assumes you are qualified in the servicing of computer equipment and trained in recognizing hazards in products with hazardous energy levels.
Part Number: 30-3659EF03-004
Published: March 2022
Edition: 3
© Copyright 2022 Hewlett Packard Enterprise Development LP
NoticesNotices
The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and
services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as
constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained
herein.
Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession, use, or copying. Consistent with FAR
12.211 and 12.212, Commercial Computer Software, Computer Software Documentation, and Technical Data for Commercial Items are licensed
to the U.S. Government under vendor's standard commercial license.
Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard Enterprise has no control over and is
not responsible for information outside the Hewlett Packard Enterprise website.
AcknowledgmentsAcknowledgments
AMD and the AMD EPYC and combinations thereof are trademarks of Advanced Micro Devices, Inc.
Linux is the registered trademark of Linus Torvalds in the U.S. and other countries.
Microsoft , Windows , and Windows Server are either registered trademarks or trademarks of Microsoft Corporation in the United States
and/or other countries.
Red Hat Enterprise Linux are registered trademarks of Red Hat, Inc. or its subsidiaries in the United States and other countries.
VMware ESXi and VMware vSphere are registered trademarks or trademarks of VMware, Inc. and its subsidiaries in the United States and
other jurisdictions.
All third-party marks are property of their respective owners.
™
®
® ® ®
® ®
™ ®

Table of contentsTable of contents
Illustrated parts catalog
Mechanical components
Air baffle spare part
Access panel spare parts
Secondary and tertiary PCI riser cage spare parts
Primary PCI riser cage spare parts
Chassis ear spare parts
Fan cage spare part
2U bezel spare part
Rack-mounting hardware spare parts
DIMM guard spare part
Miscellaneous mechanical spare parts
Miscellaneous front drive box blanks spare kit
Miscellaneous blanks spare parts
Fan blanks, energy pack latch, and retention clips spare kit
Optical drive blank spare part
System components
DIMM spare parts
Processor spare parts
AMD EPYC 7xx3 processor spare parts
Heatsink spare parts
Power supply spare parts
Storage controller spare parts
PCI riser board spare parts
Network adapter spare parts
Ethernet adapter spare parts
Fibre channel host bus adapter spare parts
Converged network adapter spare parts
OCP NIC 3.0 spare parts
InfiniBand adapter spare parts
System board spare parts
LFF front I/O board spare part
Systems Insight Display spare part
System battery spare part
Server options
Drive spare parts
Hard disk drive spare parts
NVMe solid state drive spare parts
Solid state drive SAS spare parts
Solid state drive SATA spare parts
Optical drive spare parts
Fan spare parts

Drive backplane board spare parts
Chassis Intrusion Detection Switch spare part
Rear serial port interface spare part
Accelerator spare parts
HPE DL38x Gen10 12Gb SAS Expander Card spare part
Energy pack spare parts
Power switch module spare parts
Pensando Distributed Services Platform card spare part
Flex bay spare parts
Midtray drive cage spare part
Cable spare parts
SAS/SATA cable spare parts
NVMe cable spare parts
Power cable spare parts
Miscellaneous cable spare parts
Thermal grease spare part
Customer self repair
Removal and replacement procedures
Safety considerations
Electrostatic discharge
Symbols on equipment
Server warnings and cautions
Preparation procedures
Access the Systems Insight Display
Power down the server
Power up the server
Extend the server from the rack
Remove the server from the rack
Remove the access panel
Removing the air baffle
Release the full-length expansion board retainer
Releasing the cable management arm
Removing and replacing the front bezel
Removing and replacing a hot-plug SAS, SATA or NVMe drive
Removing and replacing a drive blank
Removing and replacing the cable management arm
Removing and replacing a power supply
Power supply warnings and cautions
Removing and replacing a hot-plug AC power supply
Removing and replacing the HPE 800 W Flex Slot -48 VDC hot-plug power supply
Removing and replacing an HPE 1600 W Flex Slot -48 VDC hot-plug power supply
Removing and replacing a power supply blank
Removing and replacing the rack rails
Removing and replacing the hot-plug fan

Removing and replacing the fan cage
Removing and replacing the primary PCIe riser cage
Removing and replacing the secondary and tertiary PCIe riser cages
Removing and replacing the PCIe riser blank
Removing and replacing the PCIe riser board
Removing and replacing an expansion slot blank
Removing and replacing an expansion board
Removing and replacing a GPU enablement board
Removing and replacing the SFF universal media bay
Removing and replacing the LFF power switch module
Removing and replacing the SFF optical drive
Removing and replacing the LFF optical drive
Removing and replacing the 8 SFF drive cage
Removing and replacing the 8 SFF drive backplane
Removing and replacing the 2 SFF front drive cage
Removing and replacing the 2 SFF rear drive bay and riser cage
Removing and replacing the 2 SFF drive cage
Removing and replacing the 2 SFF rear drive backplane
Removing and replacing the NVMe drive backplane
Removing and replacing a midplane drive cage
Removing and replacing the LFF backplane assembly
Removing and replacing a front LFF drive backplane
DIMM-processor compatibility
Removing and replacing a DIMM
Removing and replacing a heatsink
Removing and replacing a processor
Removing and replacing an energy pack
Removing and replacing a Smart Array type-a modular controller
Removing and replacing the Pensando DSP DSC-25 2p SFP28 card
Decommissioning the Pensando DSP DSC-25 2p SFP28 card
Removing the Pensando DSP DSC-25 2p SFP28 card
Replacing the Pensando DSP DSC-25 2p SFP28 card
Removing and replacing the front I/O board in the LFF right chassis ear
Removing and replacing the LFF chassis ear assembly
Removing and replacing an SFF power switch module
Removing and replacing an SFF chassis ear
Removing and replacing the chassis intrusion detection switch
Removing and replacing the OCP NIC 3.0 adapter
Removing and replacing a rear serial port interface (primary)
Removing a rear serial port interface (secondary and tertiary)
System battery replacement
System battery information
Replace the system battery
Removing and replacing the system board

Removing the system board
Replacing the system board
Re-entering the server serial number and product ID
HPE Trusted Platform Module 2.0 Gen10 Plus option
Troubleshooting
Troubleshooting resources
Diagnostic tools
UEFI System Utilities
Selecting the boot mode
Secure Boot
Launching the Embedded UEFI Shell
iLO Service Port
Intelligent Provisioning
HPE Insight Remote Support
HPE InfoSight for servers
USB support
External USB functionality
Smart Storage Administrator
Component identification
Front panel components
Front panel LEDs and buttons
UID button functionality
Front panel LED power fault codes
Systems Insight Display LEDs
Systems Insight Display combined LED descriptions
Rear panel components
Rear panel LEDs
System board components
System maintenance switch descriptions
DIMM label identification
DIMM slot locations
Processor and socket components
Drive box identification
Drive bay numbering
Drive bay numbering: Smart Array controller
Drive bay numbering: SAS expander
Drive bay numbering: NVMe drives
Drives
HPE Basic Drive LED definitions
DSC-25 2-port SFP28 card ports and LEDs
Fan bay numbering
Cabling
HPE ProLiant Gen10 Plus DL Servers Storage Cabling Guidelines
Cabling diagrams

Cable routing: 8 LFF front I/O module to SATA Port
Cable routing: Universal Media Bay to SATA Port
Cable routing: 2 SFF Slim SAS Universal Media Bay in box 1 to system board
Cable routing: 2 SFF side by side SATA to system board
Cable routing: Front 8 SFF drive options (box 3 to HPE Smart Array E208i-a SR Gen10 Controller, ports 1-2)
Cable routing: Front 8 SFF drive options (box 1 to HPE Smart Array P816i-a SR Controller, ports 3-4)
Cable routing: 24 SFF SAS drive options (box 1, box 2, and box 3 to SAS expander)
Cable routing: 24 SFF drive options (box 1, box 2, and box 3 to SAS expander card and HPE Smart Array P816i-a SR
Gen10 Controller, ports 1-2)
Cable routing: 8 NVMe Balanced Direct Solution
Cable routing: 8 NVMe Direct Single Processor Solution
Cable routing: 16 NVMe Balanced Direct Solution
Cable routing: 24 NVMe Balanced Direct Solution
Cable routing: Front 8 LFF to system board
Cable routing: 12 LFF drive options (midtray to system board)
Cable routing: Front 12 LFF drive options (midtray to HPE Smart Array P816i-a SR Gen10 Controller, ports 1-4)
Cable routing: LFF backplane to HPE Smart Array P816i-a SR Gen10 Controller
Cable routing: System board processor 1 (ports 1A and 2A) to slotted expansion board ports 1-2 in the primary riser
Cable routing: SFF Front I/O module to Front power/USB 3.1 Gen1 connector
Cable routing: Systems Insight Display to front power/USB 3.1 Gen1 connector
Cable routing: 12 LFF power switch and thermal sensor to system board
Cable routing: 8 LFF front I/O module display port to system board
Cable routing: Display port to system board
Cable routing: Universal Media bay external USB to dual USB port on system board
Cable routing: Rear serial port interface
Cable routing: Rear serial port interface (tertiary riser)
Cable routing: SFF backplane power cabling to the system board
Cable routing: LFF backplane power cabling to the system board
Cable routing: 4 LFF backplane and 2 SFF side by side LFF power cable connections to the system board
Cabling routing: HPE Smart Array P816i-a Controller
Cable routing: Rear 2 SFF riser power cable
Specifications
Environmental specifications
Mechanical specifications
Power supply specifications
HPE 500 W Flex Slot Platinum Hot-plug Low Halogen Power Supply
HPE 800 W Flex Slot Platinum Hot-plug Low Halogen Power Supply
HPE 800 W Flex Slot Titanium Hot-plug Low Halogen Power Supply
HPE 800 W Flex Slot Universal Hot-plug Low Halogen Power Supply
HPE 800 W Flex Slot -48 VDC Hot-plug Low Halogen Power Supply
HPE 1600 W Flex Slot Platinum Hot-plug Low Halogen Power Supply
HPE 1600 W Flex Slot -48 VDC Hot-plug Power Supply
Websites
Support and other resources

Accessing Hewlett Packard Enterprise Support
Accessing updates
Remote support
Warranty information
Regulatory information
Documentation feedback

Illustrated parts catalogIllustrated parts catalog
Mechanical componentsMechanical components
Hewlett Packard Enterprise continually improves and changes product parts. For complete and current supported parts information,
see the Hewlett Packard Enterprise PartSurfer website (http://www.hpe.com/info/partssurferhttp://www.hpe.com/info/partssurfer).
ItemItem DescriptionDescription
1 Air baffle spare part
2 Access panel spare parts
3 Secondary and tertiary PCI riser cage spare parts
4 Primary PCI riser cage spare parts
5 Chassis ear spare parts
6 Fan cage spare part
7 2U bezel spare part*
8 Rail kit spare parts*
9 DIMM guard spare part*
10 Miscellaneous mechanical spare parts *
*Not shown
For more information, see Removal and replacement procedures.
HPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service Guide 9

Air baffle spare partAir baffle spare part
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
Air baffle
System air baffle
Retainer baffle, PCIe, 2U
Retainer baffle, tertiary, 2U
P24140-001
Access panel spare partsAccess panel spare parts
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
Access panel for the SFF chassis P42652-001
Access panel for the LFF chassis P42651-001
Secondary and tertiary PCI riser cage spare partsSecondary and tertiary PCI riser cage spare parts
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
PCI tertiary butterfly riser cage P24030-001
PCI tertiary riser cage without retainer clip P40013-001
Primary PCI riser cage spare partsPrimary PCI riser cage spare parts
Customer self repair: OptionalOptional
DescriptionDescription Spare part numberSpare part number
PCI riser cage P42325-001
HPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service Guide 10

PCI riser cage without retainer clip (primary/secondary) P40012-001
DescriptionDescription Spare part numberSpare part number
Chassis ear spare partsChassis ear spare parts
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
SFF/LFF left and right chassis ears kit with power cable
SFF, left ear
SFF, right, standard
LFF, right, power/UID
LFF, power
LFF, left, 2U, standard
P24141-001
Fan cage spare partFan cage spare part
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
Fan cage P24029-001
2U bezel spare part2U bezel spare part
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
2U bezel 875065-001
Rack-mounting hardware spare partsRack-mounting hardware spare parts
HPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service Guide 11

Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
SFF easy install rail kit P24098-001
LFF easy install rail kit P24099-001
Cable management arm P24100-001
DIMM guard spare partDIMM guard spare part
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
2U DIMM guard, left/right P24307-001
Miscellaneous mechanical spare partsMiscellaneous mechanical spare parts
Miscellaneous front drive box blanks spare kitMiscellaneous front drive box blanks spare kit
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
2 SFF Flex Bay hard drive blank
Hard drive box, standard blank
Hard drive box blank, NVMe
LFF hard drive box blank
875069-001
Miscellaneous blanks spare partsMiscellaneous blanks spare parts
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
HPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service Guide 12

Tertiary blank
Secondary PCI blank
Rear 2 SFF serial blank
2 SFF rear bracket
OCP NIC 3.0 blank
Drive bay, 2U
P24101-001
Quad NIC blank P19929-001
Fan blanks, HPE Smart Storage Battery latch, retainers 875066-001
Rear 2 SFF serial blank 878510-001
Power supply blank 775423-001
DescriptionDescription Spare part numberSpare part number
Fan blanks, energy pack latch, and retention clips spare kitFan blanks, energy pack latch, and retention clips spare kit
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
Fan blanks (2)
Energy pack latch
Retention clips for the primary riser cage (2)
Retention clip for the secondary/tertiary riser cage
875066-001
Optical drive blank spare partOptical drive blank spare part
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
Optical drive blank 707300-001
System componentsSystem components
Hewlett Packard Enterprise continually improves and changes product parts. For complete and current supported parts information,
see the Hewlett Packard Enterprise PartSurfer website (http://www.hpe.com/info/partssurferhttp://www.hpe.com/info/partssurfer).
HPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service Guide 13

ItemItem DescriptionDescription
1 DIMM spare parts
2 Processor spare parts
3 Heatsink spare parts
4 Power supply spare parts
5 Storage controller spare parts
6 PCI riser spare parts
7 Network adapter spare parts
8 System board spare parts
9 LFF front I/O board spare part *
10 Systems Insight Display spare part*
11 System battery spare part*
* Not shown
For more information, see Removal and replacement procedures.
DIMM spare partsDIMM spare parts
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
HPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service Guide 14

3200 MT/s DIMMs3200 MT/s DIMMs —
8 GB, single-rank x8 PC4-3200AA-R P20499-001
16 GB, dual-rank x4 PC4-3200AA-R P20500-001
16 GB, single-rank x8 PC4-3200AA-R P20501-001
32 GB, single-rank x4 PC4-3200AA-R P39381-001
32 GB, dual-rank x8 PC4-3200AA-R P20502-001
32 GB, dual-rank x4 PC4-3200AA-R P20503-001
64 GB, quad-rank x4 PC4-3200AA-R P20504-001
128 GB, quad-rank x4 PC4-3200AA-L P20505-001
DescriptionDescription Spare part numberSpare part number
Processor spare partsProcessor spare parts
AMD EPYC 7xx3 processor spare partsAMD EPYC 7xx3 processor spare parts
Customer self repair: OptionalOptional
DescriptionDescription Spare part numberSpare part number
3.70 Ghz AMD EPYC 72F3 processor P39063-001
2.90 GHz AMD EPYC 7313 processor P39053-001
3.10 GHz AMD EPYC 7343 processor P39054-001
3.10 GHz AMD EPYC 7373X processor P46981-001
3.50 GHz AMD EPYC 73F3 processor P39064-001
2.55 GHz AMD EPYC 7413 processor P39055-001
2.75 GHz AMD EPYC 7443 processor P39057-001
2.35 GHz AMD EPYC 7453 processor P39056-001
2.80 GHz AMD EPYC 7473X processor P46980-001
3.20 GHz AMD EPYC 74F3 processor P39065-001
2.50 GHz AMD EPYC 7513 processor P39058-001
2.70 GHz AMD EPYC 7543 processor P39059-001
2.80 GHz AMD EPYC 7573X processor P46979-001
3.20 GHz AMD EPYC 75F3 processor P39066-001
2.20 GHz AMD EPYC 7643 processor P39489-001
2.00 GHz AMD EPYC 7663 processor P39060-001
2.00 GHz AMD EPYC 7713 processor P39061-001
2.50 GHz AMD EPYC 7763 processor P39062-001
2.20 GHz AMD EPYC 7773X processor P46977-001
HPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service Guide 15

Heatsink spare partsHeatsink spare parts
Customer self repair: OptionalOptional
DescriptionDescription Spare part numberSpare part number
Standard heatsink 2U P00249-001
High-performance heatsink 1U P24556-001
High-performance heatsink 2U P22547-001
Power supply spare partsPower supply spare parts
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
HPE 500 W Hot-plug Power Supply 866729-001
HPE 800 W HVDC Hot-plug Power Supply 866727-001
HPE 800 W -48VDC Hot-plug Power Supply 866728-001
HPE 800 W Flex Slot Platinum Hot-plug Low Halogen
Power Supply
866730-001
HPE 800 W Hot-plug Power Supply 866793-001
HPE 1600 W Flex Slot Platinum Hot-plug Low Halogen
Power Supply
863373-001
HPE 1600 W Flex Slot -48 VDC hot-plug power supply P18510-001
Storage controller spare partsStorage controller spare parts
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
HPE Smart Array E208e-p SR Gen10 Controller 836267-001
HPE Smart Array E208i-a SR Gen10 Controller 836259-001
HPE Smart Array E208i-p SR Gen10 Controller 836266-001
HPE Smart Array P408e-p SR Gen10 Controller 836270-001
HPE Smart Array P408i-a SR Gen10 Controller 836260-002
HPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service Guide 16

HPE Smart Array P408i-p SR Gen10 Controller 836269-001
HPE Smart Array P816i-a SR Gen10 Controller 836261-001
HPE SR416i-a Gen10 Plus Controller P13928-001
HPE MR216i-a Gen10 Plus Controller P28348-001
HPE MR416i-a Gen10 Plus Controller P28335-001
HPE SR932i-p Gen10 Plus Controller P18875-001
HPE MR216i-p Gen10 Plus Controller P28336-001
HPE MR416i-p Gen10 Plus Controller P17303-001
HPE AROC 1-Port NVMe adapter P18719-001
DescriptionDescription Spare part numberSpare part number
PCI riser board spare partsPCI riser board spare parts
Customer self repair: OptionalOptional
DescriptionDescription Spare part numberSpare part number
3 x16 tri-mode riser P24048-001
x16 tertiary riser P24034-001
x16 cabled riser P24031-001
x8 re-timer PCIe card P40449-001
x16 re-timer PCIe card P40450-001
x16 x16 PCIe slot 1/2 riser P18721-001
x16 x16 PCIe slot 2/3 riser P18720-001
x16 tertiary riser kit P40447-001
2x16 tertiary riser kit P40448-001
Network adapter spare partsNetwork adapter spare parts
Ethernet adapter spare partsEthernet adapter spare parts
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
HPE Ethernet 1Gb 4-port BaseT I350-T4 adapter P22200-001
HPE Ethernet 10Gb 2-port SFP+ QL41132 adapter P22199-001
HPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service Guide 17

HPE Ethernet 10Gb 4-port SFP+ QL41134 adapter P13346-001
HPE Ethernet 10Gb 2-port BaseT QL41132 adapter P11688-001
HPE Ethernet 10/25Gb 2-port SFP28 QL41232 adapter P23451-001
HPE Ethernet 10Gb 2-port SFP+ MCX4121A-XCHT adapter P22202-001
HPE Ethernet 10/25Gb 2-port SFP28 MCX512F adapter P16004-001
HPE Ethernet 10/25Gb 2-port SFP28 X2522-PLUS adapter P22204-001
HPE Ethernet 100G QSFP28 MCX516A adapter P22203-001
DescriptionDescription Spare part numberSpare part number
Fibre channel host bus adapter spare partsFibre channel host bus adapter spare parts
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
HPE SN1600Q 32Gb 1p FC HBA 868140-001
HPE SN1600Q 32Gb 2p FC HBA 868141-001
HPE SN1600E 32Gb 1p FC HBA 869999-001
HPE SN1600E 32Gb 2p FC HBA 870000-001
HPE SN1200E 16Gb 1p FC HBA 870001-001
HPE SN1200E 16Gb 2p FC HBA 870002-001
HPE SN1100Q 16Gb 1p FC HBA 863010-001
HPE SN1100Q 16Gb 2p FC HBA 853011-001
Converged network adapter spare partsConverged network adapter spare parts
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
HPE CN1100R 2P Converged Network Adapter 706801-001
HPE StoreFabric CN1100R-T 10Gb Converged Network Adapter 872605-001
HPE StoreFabric CN1200E 10Gb Converged Network Adapter 767078-001
HPE StoreFabric CN1200E-T 10Gb Converged Network Adapter 827607-001
OCP NIC 3.0 spare partsOCP NIC 3.0 spare parts
HPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service Guide 18

Customer self repair: OptionalOptional
DescriptionDescription Spare part numberSpare part number
HPE 1GbE 4-port BaseT I350-T4 OCP 3.0 adapter P14487-001
HPE 10GbE 2-port SFP+ QL41132 adapter OCP 3.0 adapter P11586-001
HPE 10GbE 2-port BaseT QL41132 OCP 3.0 adapter P13345-001
HPE 10GbE 2-port SFP+MCX4621A OCP 3.0 adapter P12806-001
HPE 25GbE 2-port SFP28 MLX OCP 3.0 adapter P12619-001
HPE 10/25GbE 2-port SFP28 QL41232 OCP 3.0 adapter P11710-001
HPEDL Gen10 Plus OCP cable kit P24128-001
HPE10GbE 2-port BT BCM 57416 OCP3 adapter P13640-001
OCP right and left guide rails P23634-001
InfiniBand adapter spare partsInfiniBand adapter spare parts
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
HPE InfiniBand HDR100/Ethernet 1-port 940QSFP56 x16
Adapter
P08356-001
HPE InfiniBand HDR100/Ethernet 100Gb 2-port 940QSFP56 x16
Adapter
P08355-001
HPE InfiniBand HDR/Ethernet 200Gb 1-port 940QSFP56 x16
Adapter
P08354-001
System board spare partsSystem board spare parts
Customer self repair: OptionalOptional
DescriptionDescription Spare part numberSpare part number
System board with sub-pan P40453-001
LFF front I/O board spare partLFF front I/O board spare part
Customer self repair: OptionalOptional
HPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service Guide 19

DescriptionDescription Spare part numberSpare part number
LFF front I/O board 875088-001
Systems Insight Display spare partSystems Insight Display spare part
Customer self repair: OptionalOptional
DescriptionDescription Spare part numberSpare part number
Systems Insight Display module P24033-001
System battery spare partSystem battery spare part
Customer self repair: MandatoryMandatory
DescriptionDescription Spare part numberSpare part number
System battery 319603-001
Server optionsServer options
Hewlett Packard Enterprise continually improves and changes product parts. For complete and current supported parts information,
see the Hewlett Packard Enterprise PartSurfer website (http://www.hpe.com/info/partssurferhttp://www.hpe.com/info/partssurfer).
HPE ProLiant DL385 Gen10 Plus v2 Server Maintenance and Service Guide 20
