HPE SimpliVity 2600 Gen10 Product manual

Hewlett Packard
Enterprise
HPE SimpliVity 2600 Gen10 Installation
and Maintenance Guide
Part number: P07987-002
Published: September 2018

2
© 2018 Hewlett Packard Enterprise Development LP
Notices
The information contained herein is subject to change without notice. The only warranties for Hewlett Packard
Enterprise products and services are set forth in the express warranty statements accompanying such products
and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard
Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession, use,
or copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software
Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under vendor's
standard commercial license.
Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard
Enterprise has no control over and is not responsible for information outside the Hewlett Packard Enterprise
website.

Contents 3
Contents
Chapter 1: Component identification.................................................... 5
HPE SimpliVity 2600 Gen10 server components......................................................................... 5
Front panel components..................................................................................................... 6
Back panel components - HPE SimpliVity 170 Gen10 server............................................8
Back panel components - HPE SimpliVity 190 Gen10 server............................................9
Specifications...............................................................................................................................11
Vibration and shock.......................................................................................................... 11
Agency compliance........................................................................................................... 11
Component upgrades.................................................................................................................. 11
Firmware revisions...................................................................................................................... 11
Chapter 2: Install the chassis components........................................12
Electrostatic discharge................................................................................................................ 12
Shipping carton contents.............................................................................................................12
Components not supplied in the shipping carton....................................................................... 13
Rack requirements...................................................................................................................... 14
Rack installation guidelines.........................................................................................................14
Install the chassis in a rack........................................................................................................ 14
Connect the power cables.......................................................................................................... 16
Connect the network cables....................................................................................................... 16
Power up the server....................................................................................................................17
Chapter 3: Configure the iLO port for remote management.............19
Configure the iLO port on each server to access the iLO remote console.................................19
Connect to iLO and launch the Integrated Remote Console (IRC)............................................ 20
Chapter 4: Server troubleshooting......................................................22
Diagnostic indicators................................................................................................................... 22
Drive monitoring.......................................................................................................................... 23
Front drive numbering.......................................................................................................24
Power supply monitoring.............................................................................................................25
Network interface monitoring...................................................................................................... 25
Chapter 5: Drive maintenance............................................................. 28
Drive maintenance guidelines..................................................................................................... 28
Replace a drive........................................................................................................................... 28

Contents 4
Chapter 6: Power supply maintenance...............................................30
Power supply maintenance guidelines........................................................................................30
Replace a power supply............................................................................................................. 30
Chapter 7: Network cabling options................................................... 32
10 GbE-only network configuration.............................................................................................32
Switch-connected network configuration.....................................................................................33
Appendix A: Support and other resources........................................ 35
Support and other resources...................................................................................................... 35
Accessing Hewlett Packard Enterprise Support............................................................... 35
Accessing updates............................................................................................................ 35
Customer self repair..........................................................................................................36
Remote support.................................................................................................................36
Warranty information......................................................................................................... 36
Regulatory information...................................................................................................... 37
Documentation feedback.............................................................................................................37

Chapter 1: Component identification 5
Chapter 1: Component identification
This section contains the following topics:
•HPE SimpliVity 2600 Gen10 server components
•Specifications
•Component upgrades
•Firmware revisions
The HPE SimpliVity 2600 Gen10 system consists of a 2U rack-mountable chassis containing up to 4 individual
servers based on application requirements.
Support services are available through the Hewlett Packard Enterprise Support Center website:
support.hpe.com. Additional product documentation is available through the Hewlett Packard Enterprise
Information Library: http://www.hpe.com/info/simplivity2600-Gen10-docs.
HPE SimpliVity 2600 Gen10 server components
The HPE SimpliVity 2600 Gen10 chassis accomodates up to four 1U HPE SimpliVity 170 Gen10 servers or two
2U HPE SimpliVity 190 Gen10 servers based on storage and processor requirements.
Model Intel® Xeon® Scalable processorsProcessor
Processor count HPE SimpliVity 170 Gen10: 1 or 2 per server
HPE SimpliVity 190 Gen10: 2 per server
Quantity 6 per server
Dimension 2.5" (2.5" carrier)
RAID type Tiered storage consisting of:
• RAID 1+0
• RAID 5
Front SSD drives
Capacity 1.92 TB per drive
Quantity 1 required per server (although two are
provided per server, the second boot drive is
unused in this configuration)
Capacity 480 GB
Boot drives
Interface SATA M.2
Effective storage capacity Total raw storage capacity
without compression and
deduplication effects.
6.9 TB per node

Chapter 1: Component identification 6
Memory options Memory is provided in kits per
CPU and kits must be the same
when multiple CPUs are used.
128 GB to 384 GB per CPU.
128 GB not available for VDI configurations.
Dual CPU configuration requires two memory
kits.
Power supply Two required, model based
on power and input voltage
requirements.
Two 800 W (limited configurations), or
Two 1600 W (200-240 VAC), or
Two 1800 - 2200 W (200-240 VAC).
Required devices per server PCI slot 1: Smart Array P408i-p Controller.
Media Module Adapter: Provides a 1 GbE
2-port interface for the HPE SimpliVity
Management network.
PCI slot 2: 10 GbE 2-port NIC for storage, HPE
SimpliVity Federation network, and optionally
HPE SimpliVity Management. An optional 4-
port 1 GbE NIC is available.
Expansion slots No PCI slots are available for expansion for the
HP SimpliVity 170 server.
The HPE SimpliVity 190 Server allows the
following option:
• PCI slot 3: GPU accelerator or one 10 GbE
NIC.
Remote server management iLO Integrated Lights-Out processor and network port for remote, out-of-band,
web-based management.
Front panel components
The front panel provides server controls, diagnostic indicators, and contains the data drives.

Chapter 1: Component identification 7
Callout Item Description
1 Quick access cover Provides access to internal components.
2 Locking cover latch Lock/unlock the quick access cover.
3 Power On/Standby button
and system power LED for
each server (1-4).
• Solid green = System on
• Flashing green (1 Hz/cycle per sec) = Performing power on
sequence
• Solid amber = System in standby
• Off = No power present
• Servers 1 and 2 are powered on/off by the buttons on the left side
of the chassis (server 1 is on the bottom). Servers 3 and 4 are
powered on/off by the buttons on the right side of the chassis.
NOTE:
Power LED off can indicate facility power is not present, power cord is
not attached, no power supplies are installed, power supply failure has
occurred, or the power button cable is disconnected because the server
is not installed.
4 Health LED for each server
(1-4)
• Solid green = Normal
• Flashing green (1 Hz/cycle per sec) = iLO is rebooting
• Flashing amber = System degraded
• Flashing red (1 Hz/cycle per sec) = System critical
NOTE:
If the Health LED indicates a degraded or critical state, review the
system IML or use iLO to review the system health status.
5 UID button/LED • Solid blue = Activated
• Flashing blue:
• ◦ 1 Hz/cycle per sec = Remote management or firmware upgrade
in progress.
◦ 4 Hz/cycle per sec = iLO manual reboot sequence initiated.
◦ 8 Hz/cycle per sec = iLO manual reboot sequence in progress.
6 Drives for servers 1-4 The chassis accomodates 2 to 4 servers based on model and size
requirements. Each server has a capacity of up to 6 drives.
7 System Information Card Provides server identification information that might be required when
contacting Customer Support (support.hpe.com).
8 Drive position diagram Provides the front drive numbering and location.

Chapter 1: Component identification 8
Back panel components - HPE SimpliVity 170 Gen10 server
The HPE SimpliVity 2600 Gen10 chassis supports up to four HPE SimpliVity 170 Gen10 servers. Each server
requires management and data connections and provides LED status indicators. The following graphic shows the
components for one server, but the components are identical for all four.
Callout Item Description
1, 2, 3, 4 Servers 1-4 Up to four HPE SimpliVity 170 servers, each containing six
drives, are supported in the HPE SimpliVity 2600 Gen10
chassis.
5 USB 3.0 connector USB 3.0 connector that enables you to connect a USB device,
such as a mouse or keyboard.
6 Pull tab Provides server serial number and iLO label.
7 Media Module Adapter 1 GbE Media Module Adapter containing two ports numbered
1 and 2, from left to right for the HPE SimpliVity Management
network.
8 Power button/LED Solid green = System on
Flashing green = Performing power on sequence
Solid amber = System in standby
Off = No power present
9 UID button/LED Solid blue = Activated
• 1 flash per second = Remote management or firmware
upgrade in progress
• 4 flashes per second = iLO manual soft reboot sequence
initiated
• 8 flashes per second = iLO manual hard reboot sequence in
progress
Off = Deactivated

Chapter 1: Component identification 9
Callout Item Description
10 iLO service port Use to download the Active Health System Log to a supported
USB flash drive. Also provides a connection for a client (such
as a laptop) with a supported USB to Ethernet adapter to
access the iLO web interface, remote console, CLI, iLO
RESTful API, or scripts.
11 iLO management port Dedicated port for remote, out-of-band, web-based
management using Integrated Lights-Out (iLO), an HPE
proprietary embedded server management technology.
12 PCIe Slot 2 Two 10 GbE ports numbered 1 and 2, from right to
left. Use interfaces 1 and 2 for the HPE SimpliVity
Management,federation, and storage networks.
13 SUV connector Provides serial, USB, and a video port connection for
maintenance purposes.
14 Power supplies Two redundant hot plug power supplies with fans. Each power
supply has a status indicator LED for AC power present
(green).
If you need to replace a power supply, always disconnect the
power cord before removing the power supply.
Back panel components - HPE SimpliVity 190 Gen10 server
The HPE SimpliVity 2600 Gen10 chassis supports two HPE SimpliVity 190 Gen10 servers. Each server requires
management and data connections. Each server is 2U in height and has the capability to accommodate an
optional NIC or GPU accelerator.
Callout Item Description
1, 3 Server 1 and 3 Two HPE SimpliVity 190 2U servers, each containing six drives,
are supported in the HPE SimpliVity 2600 Gen10 chassis.
2 PCI slot 3 Optional NIC or GPU accelerator for each server.
4 USB 3.0 connector USB 3.0 connector that enables you to connect a USB device,
such as a mouse or keyboard.

Chapter 1: Component identification 10
Callout Item Description
5 Pull tab Provides server serial number and iLO label.
6 Media Module Adapter 1 GbE Media Module Adapter containing two ports numbered
1 and 2, from left to right for the HPE SimpliVity Management
network.
7 Power button/LED Solid green = System on
Flashing green = Performing power on sequence
Solid amber = System in standby
Off = No power present
8 UID button/LED Solid blue = Activated
• 1 flash per second = Remote management or firmware
upgrade in progress
• 4 flashes per second = iLO manual soft reboot sequence
initiated
• 8 flashes per second = iLO manual hard reboot sequence in
progress
Off = Deactivated
9 iLO service port Use to download the Active Health System Log to a supported
USB flash drive. Also provides a connection for a client (such
as a laptop) with a supported USB to Ethernet adapter to
access the iLO web interface, remote console, CLI, iLO
RESTful API, or scripts.
10 iLO management port Dedicated port for remote, out-of-band, web-based
management using Integrated Lights-Out (iLO), an HPE
proprietary embedded server management technology.
11 PCIe Slot 2 Two 10 GbE ports numbered 1 and 2, from right to left. Use
interfaces 1 and 2 for HPE SimpliVity Management, federation,
and storage networks.
12 SUV connector Provides serial, USB, and a video port connection for
maintenance purposes.
13 Power supplies Two redundant hot plug power supplies with fans. Each power
supply has a status indicator LED for AC power present
(green).
If you need to replace a power supply, always disconnect the
power cord before removing the power supply.

Chapter 1: Component identification 11
Specifications
This section provides environment and technical specifications for HPE SimpliVity 2600 Gen10 servers.
The specifications help you when planning the appropriate installation location, environmental conditions,
and resources such as power and cooling. See the product QuickSpec for the latest information on system
specifications.
Vibration and shock
The server configured for deployment in a HPE OmniStack federation does not exceed the vibration and shock
limit specifications for a fully-configured server.
Agency compliance
HPE SimpliVity 2600 Gen10 servers, when configured for deployment in an HPE OmniStack federation, meet the
same compliance standards as standard HPE Apollo Gen10 servers.
Component upgrades
If you need to upgrade the server components, contact Customer Support (support.hpe.com).
WARNING:
Never install additional options other than those approved for installation by Customer Support
(support.hpe.com). Doing so will void your warranty and might cause serious server instability and
potential data loss.
Firmware revisions
HPE OmniStack software requires that each supported platform is running a specific firmware revision.
To avoid compatibility issues, contact Customer Support (support.hpe.com) before making any firmware
changes.
NOTE:
If your server, or any management software, has automatic software updates enabled, disable this feature to
avoid installing unsupported firmware revisions.

Chapter 2: Install the chassis components 12
Chapter 2: Install the chassis components
This section contains the following topics:
•Electrostatic discharge
•Shipping carton contents
•Components not supplied in the shipping carton
•Rack requirements
•Rack installation guidelines
•Install the chassis in a rack
•Connect the power cables
•Connect the network cables
•Power up the server
To install the chassis components, you must unpack all components, install the chassis in a rack, connect the
power and network cables, and power on the system.
Electrostatic discharge
You must protect sensitive components from electrostatic discharge (ESD).
To protect components from ESD:
• Ensure the component is fully grounded at all times to prevent damage from electrostatic discharge.
• When not installed in a rack, store server components in the original packaging or place on a sturdy surface
that is protected from electrostatic discharge.
• When handling server components, always use the electrostatic wrist strap provided or a similar form of ESD
protection.
Shipping carton contents
The shipping carton contains standard items and other items based on your configuration.
Part Description
Chassis HPE SimpliVity 2600 chassis.
Servers (two, three, or four) Provide processing power and storage capacity.
Power cords • Two standard power cords that meet one of the following
specifications based on power requirements:
• Two IEC C13/C14 (PDU) cords.
• Two IEC C15/16 (PDU) cords - for customers ordering an
1800W-2200W power supply.

Chapter 2: Install the chassis components 13
Part Description
Rack-mounting hardware (optional) Contains the left and the right rails and detailed installation
documentation.
Serial USB VGA Dongle kit (optional) Provides Serial, USB and VGA connectivity to the servers.
HPE Apollo 2000 RCM-module kit (optional) Rack control management module kit.
HPE Gen10 2U Bezel and Lock (optional) Bezel and Bezel Lock.
Printed documentation • Safety, Compliance, and Warranty Information.
• Start Here Options Installation Information.
• Start Here information for the HPE SimpliVity 2600 Gen10
system.
Components not supplied in the shipping carton
Your network environment might require additional components not supplied in the shipping carton.
Component Description Application
Rack 19 inch (48.3 cm), four-post, tool-
free rack.
Provides easy access to the server
components in your computing
environment.
1 GbE data cables Two Category 5e or Category 6
cables with RJ45 connectors.
An optional third cable is required to
use the iLO port for remote console
access.
Connects the 1 GbE network
interfaces on each server to a 1
GbE switch. This is required only
if you are connecting the 1 GbE
network interfaces on each server
to a switch, such as in a direct
connected or switch-connected
network configuration, for example.
10 GbE data cables Two SFP+ Direct Attach cables
or Cat 5e/6 cables depending on
FlexLOM selection.
Connects the 10 GbE interfaces on
each server to a 10 GbE switch.
Network switches Required number of switches. Connects devices to a network. The
number of switches depends on
your network configuration.
Redundant Uninterruptible Power
Supply (UPS)
Required number of UPS devices. Provides temporary power to the
server in the event of a complete
power outage.

Chapter 2: Install the chassis components 14
Rack requirements
Each chassis ships with rack-mounting hardware. The sliding rails allow you to fully extend the system out of the
rack for service.
Caution:
See the Rack Installation Instructions supplied with the rack mount kit for safety and installation
instructions.
The racks you use for each chassis must meet these requirements:
• The sliding rails support tool-free mounting in 19-inch, EIA-310-E compliant square-hole, 4-post racks, and
also support tooled mounting in threaded 4-post racks.
• Ensure the rack has sufficient space for all systems.
• For full power redundancy across all servers, you need a rack with two power distribution units (PDU) feeding
separate outlet strips, with sufficient vacant outlets on each strip.
• Ensure the rack is installed and stabilized or bayed according to the manufacturer's instructions.
WARNING:
When servicing a server in a chassis, extend only one chassis at a time to prevent the rack from tipping.
NOTE:
For more information, refer to the HPE Apollo 2000 Gen10 Chassis User Guide.
Rack installation guidelines
There are guidelines to help you successfully install each chassis in a rack.
• Follow all safety guidelines stated in the documentation that came with the rack, particularly when installing
components into the locations at the top of the rack.
• Ensure the rack meets the requirements.
• Install multiple chassis in the same rack when possible.
• Install the chassis in a rack starting from the bottom of the rack.
• Always install the chassis in a horizontal position, or you void your warranty and support contract.
Install the chassis in a rack
Before you begin
• Before installing the chassis into the rack, Hewlett Packard Enterprise recommends removing the servers
and drives. Because a fully populated chassis is heavy, removing these components facilitates moving and
installing the chassis. For instructions, refer to the HPE Apollo 2000 Gen10 Chassis User Guide available from
the http://support.hpe.com website.
• You have read the Rack Installation Instructions, included in the rack mount kit in the shipping carton, for
installing the left and right rails in the rack. The rack mount kit instructions also explain how to stabilize the
rack, install devices, and configure power distribution.
WARNING:
The chassis is very heavy. To reduce the risk of personal injury or damage to the equipment:

Chapter 2: Install the chassis components 15
• Observe local occupational health and safety requirements and guidelines for manual material handling.
• Remove all servers from the chassis before installing or moving the chassis.
• Use caution and get help to lift and stabilize the chassis during installation or removal, especially when
the chassis is not fastened to the rack.
WARNING:
To avoid risk of personal injury or damage to the equipment, do not stack anything on top of railmounted
equipment or use it as a work surface when extended from the rack.
WARNING:
To reduce the risk of personal injury or damage to the equipment, be sure that:
• The rack is bolted to the floor using the concrete anchor kit.
• The leveling feet extend to the floor.
• The full weight of the rack rests on the leveling feet.
• The racks are coupled together in multiple rack installations.
• Only one component is extended at a time. If more than one component is extended, a rack might
become unstable.
WARNING:
To reduce the risk of personal injury or equipment damage, be sure that the rack is adequately stabilized
before installing the chassis.
Caution:
Always plan the rack installation so that the heaviest item is on the bottom of the rack. Install the heaviest
item first, and continue to populate the rack from the bottom to the top.
Caution:
Be sure to keep the product parallel to the floor when installing the chassis. Tilting the product up or down
could result in damage to the slides.
Caution:
Hewlett Packard Enterprise has not tested or validated this chassis with any third-party racks. Before
installing the chassis in a third-party rack, be sure to properly scope the limitations of the rack. Before
proceeding with the installation, consider the following:
• You must fully understand the static and dynamic load carrying capacity of the rack and be sure that it
can accommodate the weight of the chassis.
• Be sure sufficient clearance exists for cabling, installation and removal of the chassis, and actuation of
the rack doors.
IMPORTANT: When installing each chassis into the rack, be sure that the HPE Apollo Platform Manager is
at the top of the chassis to ensure proper orientation in the rack. Start installing the chassis at the lowest
available U space in the rack. Work up from the bottom of the rack to add additional chassis.
Procedure overview
This procedure provides the high-level steps for installing chassis in a rack. For detailed instructions, refer to the
HPE Apollo 2000 Gen10 Chassis User Guide available from the http://support.hpe.com website.

Chapter 2: Install the chassis components 16
Caution:
Two people are required to safely install the chassis hardware in a rack. The Rack Installation Instructions
included in the rack mount kit box contains important safety and procedural information.
Procedure
1. Unpack the system.
2. Prepare the chassis for installation by removing the servers and drives.
3. Install the rail kit.
4. Install the chassis.
5. Install the system components you removed in step 2 above.
Next steps
You can now connect the power cables to the server.
Connect the power cables
Procedure overview
Each system includes two hot plug power supplies, numbered PS1 and PS2, from bottom to top. You connect
both power supplies to power sources.
For high availability, you connect each power supply to a different circuit. You can also use redundant,
Uninterruptible Power Supply (UPS) systems to protect against a complete power outage.
Procedure
1. Obtain the two power cables from the shipping carton.
2. Connect the power cables to power supply units on each system.
3. Connect the other end of each power cable to a power source, preferably on different circuits.
4. Use the cable strain relief on each power supply to secure the power cable and prevent an accidental
disconnection.
Connect the network cables
Procedure overview
Each of the HPE SimpliVity 2600 Gen10 servers in the HPE SimpliVity 2600 Gen10 chassis provide 10 GbE and
1 GbE network interfaces for the Federation, Storage, and Management network traffic.
You can access the following network interfaces at the back of the servers:
• 2-port 1 GbE Media Module adapter (1). Use ports 1 and 2, numbered from left to right for the Management
network.
• 2-port 10 GbE interface (2). Use ports 1 and 2, numbered from right to left for the HPE OmniStack Federation
and Storage networks. An optional 4-port NIC is available.

Chapter 2: Install the chassis components 17
Procedure
1. Connect the cables according to the guidelines for the HPE SimpliVity 2600 Gen10 networks only.
2. Ensure that no other network interfaces, such as optional 10 GbE interfaces, are connected to your network
before deploying the server to a federation.
Connect the optional network interfaces after deployment.
Caution:
If the optional interfaces are connected when you deploy the server, the ports for the Federation
network might not be configured correctly. For help with resolving this error, contact Customer Support
(support.hpe.com).
3. Repeat steps 1 and 2 for each server in the chassis.
Power up the server
Procedure overview

Chapter 2: Install the chassis components 18
Procedure
1. Go to the front of the system.
2. Press the Power On/Standby button (1) to power up the server.
3. Watch the health indicator (2) on the front panel to make sure it changes from flashing green to steady green.
NOTE:
If an error occurs during server start-up, contact Customer Support (support.hpe.com).
4. Repeat the above steps for each server in the chassis.

Chapter 3: Configure the iLO port for remote management 19
Chapter 3: Configure the iLO port for
remote management
This section contains the following topics:
•Configure the iLO port on each server to access the iLO remote console
•Connect to iLO and launch the Integrated Remote Console (IRC)
Configure the iLO port on each server to access the iLO
remote console
Before you begin
• Your environment meets the requirements for configuring iLO (Integrated Lights-Out) for out-of-band web-
based management.
• You have the following information and items:
◦ A Windows client laptop computer with a Web browser. You can use a MAC or Linux OS; however, this
procedure describes Windows.
◦ An Ethernet cable to connect between the laptop and the iLO port on the server.
◦ An IP address. The address can be static or assigned by DHCP.
◦ A static address for the gateway, subnet mask, and, optionally, up to two DNS servers, which can be static
or assigned by DHCP.
NOTE:
If you prefer to configure iLO at a later time, you can skip this task and deploy the server using Deployment
Manager. See the HPE OmniStack 3.7.6 for vSphere Deployment Guide for deployment instructions.
Procedure overview
You configure the iLO port on each server in the chassis to access the iLO console through a web browser. The
iLO console provides out-of-band remote server management and access to advanced management options.
Your configuration steps may include configuring IPv4, modifying the default static IP address, enabling DHCP, or
changing the default user name and password.
The server is pre-configured with a default, static IP address to access iLO (192.168.0.120). The iLO default
user name and password are found on the pull tab attached to the rear of the chassis. The user name is
Administrator and the password is an eight-character alphanumeric string.
Procedure
1. Connect an Ethernet cable from the Ethernet port on the laptop to the iLO Ethernet port on the rear of the
server.

Chapter 3: Configure the iLO port for remote management 20
2. If necessary, change the IPv4 address of the Ethernet port on your Windows laptop:
a) Open Network and Sharing Center in the Control Panel and click Change adapter settings.
b) Locate the icon for the Ethernet adapter, right-click it, and then select Properties. This is typically a Local
Area Connection.
c) Select Internet Protocol Version 4 (TCP/IPv4) and click Properties.
d) Record the current settings on the General tab so that you can restore them later.
e) Check the button labeled Use the following IP address.
f) Enter an IP address in the range 192.168.0.[0-255], excluding 192.168.0.120.
g) Enter a subnet mask of 255.255.0.0.
h) Close the dialogs and exit from Network and Sharing Center.
3. Enter the default iLO IP address to access the server:
http://192.168.0.120
4. Use the default user name and password found on the pull tab on the rear of the chassis to log in.
5. If prompted to do so, change the default iLO password according to your site-specific security requirements.
6. Select Network > iLO Dedicated Network Port or Network > Dedicated Network Port.
7. Select the IPv4 tab.
8. On the IPv4 tab, enable DHCP or specify a static IP address, subnet mask, default gateway, and so on
based on your network environment.
9. Click Submit to save the network settings.
10. Connect the iLO port to a switch in the rack.
11. Repeat the previous steps for each server in the chassis.
Connect to iLO and launch the Integrated Remote Console
(IRC)
Before you begin
Ensure you have configured the iLO port.
Procedure overview
You connect to iLO through a web browser to launch the remote console. iLO supports Java, .NET IRC, HTML5,
and the HPE iLO Mobile application for remote access.
Procedure
