HT Italia HT61 User manual

Copyright HT ITALIA 2017 Version EN 2.00 - 17/07/2017
ENGLISH
User manual

HT61 - HT62
EN - 1
Table of contents:
1.PRECAUTIONS AND SAFETY MEASURES...............................................................2
1.1.Preliminary instructions..................................................................................................... 2
1.2.During use......................................................................................................................... 3
1.3.After use............................................................................................................................ 3
1.4.Definition of Measurement (Overvoltage) category........................................................... 3
2.GENERAL DESCRIPTION...........................................................................................4
2.1.Measuring average values andTRMS values.................................................................... 4
2.2.Definition of true root mean square value and Crest factor............................................... 4
3.PREPARATION FOR USE...........................................................................................5
3.1.Initial checks...................................................................................................................... 5
3.2.Instrument power supply................................................................................................... 5
3.3.Storage.............................................................................................................................. 5
4.NOMENCLATURE........................................................................................................6
4.1.Description of the instrument............................................................................................. 6
4.2.Description of function keys .............................................................................................. 7
4.2.1.HOLD key .............................................................................................................................. 7
4.2.2.RANGE key ................................................................................................................................ 7
4.2.3.MAX MIN key.............................................................................................................................. 7
4.2.4.Hz% key...................................................................................................................................... 7
4.2.5.REL key...................................................................................................................................... 7
4.2.6.MODE key .................................................................................................................................. 7
4.2.7.LoZ feature ................................................................................................................................. 8
4.2.8.Disabling the Auto Power Off function........................................................................................ 8
5.OPERATING INSTRUCTIONS.....................................................................................9
5.1.DC Voltage measurement................................................................................................. 9
5.2.AC Voltage measurement............................................................................................... 10
5.3.AC/DC Voltage measurement with low impedance (LoZ)............................................... 11
5.4.Frequency and Duty Cycle measurement....................................................................... 12
5.5.Resistance measurement and Continuity test................................................................. 13
5.6.Diode test........................................................................................................................ 14
5.7.Capacitance measurement (HT62)................................................................................. 15
5.8.Temperature measurement with K probe (HT62)............................................................ 16
5.9.DC Current measurement............................................................................................... 17
5.10.AC Current measurement ............................................................................................... 18
6.MAINTENANCE .........................................................................................................19
6.1.Replacing the batteries and the internal fuses................................................................ 19
6.2.Cleaning the instrument .................................................................................................. 19
6.3.End of life ........................................................................................................................ 19
7.TECHNICAL SPECIFICATIONS ................................................................................20
7.1.Technical characteristics................................................................................................. 20
7.1.1.Reference standards................................................................................................................ 22
7.1.2.General characteristics............................................................................................................. 22
7.2.Environment.................................................................................................................... 22
7.2.1.Environmental conditions for use ............................................................................................. 22
7.3.Accessories..................................................................................................................... 22
7.3.1.Accessories provided ............................................................................................................... 22
7.3.2.Optional accessories................................................................................................................ 22
8.ASSISTANCE.............................................................................................................23
8.1.Warranty conditions......................................................................................................... 23
8.2.Assistance....................................................................................................................... 23

HT61 - HT62
EN - 2
1. PRECAUTIONS AND SAFETY MEASURES
In this manual, the word “instrument” generically indicates models HT61 and HT62 if not
specified otherwise. The instrument has been designed in compliance with standard
IEC/EN61010-1 relevant to electronic measuring instruments. For your safety and in order
to prevent damaging the instrument, please carefully follow the procedures described in
this manual and read all notes preceded by symbol with the utmost attention.
Before and after carrying out measurements, carefully observe the following instructions:
Do not carry out any measurement in humid environments.
Do not carry out any measurements in case gas, explosive materials or flammables are
present, or in dusty environments.
Avoid any contact with the circuit being measured if no measurements are being
carried out.
Avoid any contact with exposed metal parts, with unused measuring probes or circuits
Do not carry out any measurement in case you find anomalies in the instrument such
as deformation, breaks, substance leaks, absence of display on the screen, etc.
Pay special attention when measuring voltages higher than 20V, since a risk of
electrical shock exists.
In this manual, and on the instrument, the following symbols are used:
Warning: observe the instructions given in this manual; improper use could
damage the instrument or its components.
Double-insulated meter
AC voltage
DC voltage or current
Connection to earth
1.1. PRELIMINARY INSTRUCTIONS
This instrument has been designed for use in environments of pollution degree 2.
It can be used for VOLTAGE and CURRENT measurements on installations with CAT
IV 600V and CAT III 1000V.
We recommend following the normal safety rules devised by the procedures for
carrying out operations on live systems and using the prescribed PPE to protect the
user against dangerous currents and the instrument against incorrect use.
In case the lack of indication of the presence of voltage may represent a danger for the
operator, always carry out a continuity measurement before carrying out the
measurement on the live system, in order to confirm the correct connection and
condition of the leads.
Only the leads supplied with the instrument guarantee compliance with the safety
standards. They must be in good conditions and be replaced with identical models,
when necessary.
Do not test circuits exceeding the specified voltage limits.
Do not perform any test under environmental conditions exceeding the limits indicated
in § 6.2.1.
Check that the battery is correctly inserted.
Make sure that the LCD display and the rotary switch indicate the same function.

HT61 - HT62
EN - 3
1.2. DURING USE
Please carefully read the following recommendations and instructions:
CAUTION
Failure to comply with the caution notes and/or instructions may damage
the instrument and/or its components or be a source of danger for the
operator.
Before activating the rotary switch, disconnect the test leads from the circuit being
measured.
When the instrument is connected to the circuit being measured, do not touch any
unused terminal.
Do not measure resistance in case external voltages are present; even if the
instrument is protected, an excessive voltage may cause malfunction.
While measuring, if the value or the sign of the quantity being measured remain
unchanged, check if the HOLD function is enabled.
1.3. AFTER USE
When measurement is complete, set the rotary switch to OFF to switch off the
instrument.
If the instrument is not to be used for a long time, remove the batteries.
1.4. DEFINITION OF MEASUREMENT (OVERVOLTAGE) CATEGORY
Standard “IEC/EN61010-1: Safety requirements for electrical equipment for measurement,
control and laboratory use, Part 1: General requirements”, defines what measurement
category, commonly called overvoltage category, is. § 6.7.4: Measured circuits, reads:
(OMISSIS)
Circuits are divided into the following measurement categories:
Measurement Category IV is for measurements performed at the source of the low-
voltage installation.
Examples are electricity meters and measurements on primary overcurrent protection
devices and ripple control units.
Measurement Category III is for measurements performed on installations inside
buildings.
Examples are measurements on distribution boards, circuit breakers, wiring, including
cables, bus-bars, junction boxes, switches, socket-outlets in the fixed installation, and
equipment for industrial use and some other equipment, for example, stationary motors
with permanent connection to fixed installation.
Measurement Category II is for measurements performed on circuits directly
connected to the low-voltage installation.
Examples are measurements on household appliances, portable tools and similar
equipment.
Measurement Category I is for measurements performed on circuits not directly
connected to MAINS.
Examples are measurements on circuits not derived from MAINS, and specially
protected (internal) MAINS-derived circuits. In the latter case, transient stresses are
variable; for that reason, the standard requires that the transient withstand capability of
the equipment is made known to the user.

HT61 - HT62
EN - 4
2. GENERAL DESCRIPTION
The instrument carries out the following measurements:
DC Voltage
AC TRMS voltage
DC/AC voltage with low impedance (LoZ)
DC Current
AC TRMS Current
Resistance and Continuity test
Diode test
Capacitance (HT62)
Current and voltage frequency
Duty Cycle
Temperature with K probe (HT62)
Each of these functions can be selected by means of the appropriate switch. The
instrument is also equipped with function keys (see § 4.2), an analogue bargraph and
backlight. The instrument is also equipped with an Auto Power OFF function (which can be
disabled), which automatically switches off the instrument 15 minutes after the last time a
function key was pressed or the rotary switch was turned. To switch on the instrument
again, turn the rotary switch.
2.1. MEASURING AVERAGE VALUES ANDTRMS VALUES
Measuring instruments of alternating quantities are divided into two big families:
AVERAGE-VALUE meters: instruments measuring the value of the sole wave at
fundamental frequency (50 or 60 Hz).
TRMS (True Root Mean Square) VALUE meters: instruments measuring the TRMS
value of the quantity being tested.
With a perfectly sinusoidal wave, the two families of instruments provide identical results.
With distorted waves, instead, the readings shall differ. Average-value meters provide the
RMS value of the sole fundamental wave; TRMS meters, instead, provide the RMS value
of the whole wave, including harmonics (within the instruments bandwidth). Therefore, by
measuring the same quantity with instruments from both families, the values obtained are
identical only if the wave is perfectly sinusoidal. In case it is distorted, TRMS meters shall
provide higher values than the values read by average-value meters.
2.2. DEFINITION OF TRUE ROOT MEAN SQUARE VALUE AND CREST FACTOR
The root mean square value of current is defined as follows: “In a time equal to a period,
an alternating current with a root mean square value of 1A intensity, circulating on a
resistor, dissipates the same energy that, during the same time, would be dissipated by a
direct current with an intensity of 1A". This definition results in the numeric expression:
G= 
Tt
t
dttg
T
0
0
)(
12The root mean square value is indicated with the acronym RMS.
The Crest Factor is defined as the relationship between the Peak Value of a signal and its
RMS value: CF (G)= RMS
p
G
GThis value changes with the signal waveform, for a purely
sinusoidal wave it is 2=1.41. In case of distortion, the Crest Factor takes higher values
as wave distortion increases.

HT61 - HT62
EN - 5
3. PREPARATION FOR USE
3.1. INITIAL CHECKS
Before shipping, the instrument has been checked from an electric as well as mechanical
point of view. All possible precautions have been taken so that the instrument is delivered
undamaged.
However, we recommend generally checking the instrument in order to detect possible
damage suffered during transport. In case anomalies are found, immediately contact the
forwarding agent.
We also recommend checking that the packaging contains all components indicated in §
6.3.1. In case of discrepancy, please contact the Dealer.
In case the instrument should be returned, please follow the instructions given in § 7.
3.2. INSTRUMENT POWER SUPPLY
The instrument is supplied with 1x9V alkaline battery type IEC 6F22, included in the
package. When the battery is flat, the symbol “” appears on the display. o
replace/insert the battery, see § 6.1.
3.3. STORAGE
In order to guarantee precise measurement, after a long storage time under extreme
environmental conditions, wait for the instrument to come back to normal condition (see §
6.2.1).

HT61 - HT62
EN - 6
4. NOMENCLATURE
4.1. DESCRIPTION OF THE INSTRUMENT
CAPTION:
1. LCD display
2. RANGE key
3. MAXMIN key
4. Hz% key
5. REL key
6. MODE key
7. HOLD key
8. Rotary selector switch
9. Input terminal 10A
10.Input terminal
VHz%(HT61) or
Hz%V (HT62).
11.Input terminal mAA
12.Input terminal COM
Fig. 1: Description of the instrument

HT61 - HT62
EN - 7
4.2. DESCRIPTION OF FUNCTION KEYS
4.2.1. HOLD key
Pressing the HOLD key freezes the value of the measured quantity on the display. After
pressing this key, the message “HOLD” appears on the display. Press the HOLD key again
to exit the function. Press and hold the HOLD key for a long time in order to
activate/deactivate the display’s backlight. This function is activated in any position of the
rotary switch and is automatically deactivated after approx. 10s.
4.2.2. RANGE key
Press the RANGE key to activate the manual mode and to disable the Autorange function.
The symbol “AUTO” disappears from the upper left part of the display. In manual mode,
press the RANGE key to change measuring range: the relevant decimal point will change
its position. The RANGE key is not active in Frequency measurement and Duty cycle test
and in positions and (HT62) of the rotary switch. In Autorange mode, the
instrument selects the most appropriate ratio for carrying out measurement. If a reading is
higher than the maximum measurable value, the indication “O.L” appears on the display.
Press and hold the RANGE key for more than 1 second to exit the manual mode.
4.2.3. MAX MIN key
Pressing the MAX MIN key once activates the detection of maximum and minimum values
of the quantity being tested. Both values are constantly updated and are displayed
cyclically every time the same key is pressed again. The display shows the symbol
associated with the selected function: “MAX” for maximum value and “MIN” for minimum
value. The MAX MIN key is not active when the HOLD function is activated. Pressing the
MAX MIN key the “AUTO” and bargraph disappears. The MAX MIN key is not active in
Frequency measurement and Duty cycle test and in positions and (HT62) of the
rotary switch. Press and hold the MAX MIN key for more than 1 second or turn the selector
to exit the function.
4.2.4. Hz% key
Press the Hz% key to select frequency measurement and duty cycle test in positions
VHz%, 10AHz%, mA (AC), A(AC) and Hz% of the rotary switch. The frequency
range is different in the different positions.
4.2.5. REL key
Press the REL key to activate relative measurement. The instrument zeroes the display
and saves the displayed value as a reference value which subsequent measurements will
be referred to. The symbol “REL” appears on the display. This function is not active for the
following measurements: Hz, Duty Cycle, Continuity Test, Diode test and Temperature
(HT62). Pressing the REL key the “AUTO” and bargraph disappears Press the key again
to exit the function.
4.2.6. MODE key
Pressing the MODE key allows selecting a double function on the rotary switch. In
particular, it is active in position and (HT62) to select diode test,
continuity test, capacitance measurement (HT62) and resistance measurement, in position
°C°F (HT62) to select temperature measurement in °C or °F, in positions VHz% and
LoZV for AC or DC voltage selection and mA , Ato select AC or DC
measurements

HT61 - HT62
EN - 8
4.2.7. LoZ feature
This mode permits to perform the AC/DC voltage measurement with a low input
impedance in way to avoid the wrong readings due to stray voltage in capacitive coupled.
CAUTION
Inserting the instrument between phase and ground conductors, the RCDs
protection devices can be tripping out during the test. For phase-PE voltage
measurement after a RCD device preliminarily connect the test leads
between phase and neutral cables at least for 5s, then perform the phase-
PE measurement to avoid unexpected trips-out
4.2.8. Disabling the Auto Power Off function
The instrument switches off automatically approximately 15 minutes after it was last used.
The symbol “” appears on the display. To disable the Auto Power Off function, proceed
as follows:
Switch off the instrument (OFF)
Press and hold the MODE key, switch on the instrument by turning the rotary switch.
The symbol “” disappears from the display
Switch off and then on again the instrument to enable the function.

HT61 - HT62
EN - 9
5. OPERATING INSTRUCTIONS
5.1. DC VOLTAGE MEASUREMENT
CAUTION
The maximum input DC voltage is 1000V. Do not measure voltages
exceeding the limits given in this manual. Exceeding voltage limits could
result in electrical shocks to the user and damage to the instrument.
Fig. 2: Use of the instrument for DC voltage measurement
1. Select position VHz%
2. Press the MODE key until the symbol“DC””is displayed
3. Insert the red cable into input terminal VHz%(HT61) or Hz%V 
(HT62) and the black cable into input terminal COM.
4. Position the red lead and the black lead respectively in the spots with positive and
negative potential of the circuit to be measured (see Fig. 2). The display shows the
value of voltage.
5. If the display shows the message "O.L", select a higher range.
6. When symbol "-" appears on the instrument’s display, it means that voltage has the
opposite direction with respect to the connection in Fig. 2.
7. To use the HOLD, RANGE, MAX MIN and REL functions, see § 4.2.

HT61 - HT62
EN - 10
5.2. AC VOLTAGE MEASUREMENT
CAUTION
The maximum input AC voltage is 1000V. Do not measure voltages
exceeding the limits given in this manual. Exceeding voltage limits could
result in electrical shocks to the user and damage to the instrument.
Fig. 3: Use of the instrument for AC voltage measurement
1. Select position VHz%
2. Press the MODE key until the symbol“AC””is displayed
3. Insert the red cable into input terminal VHz%(HT61) or Hz%V 
(HT62) and the black cable into input terminal COM.
4. Position the red lead and the black lead respectively in the spots of the circuit to be
measured (see Fig. 3). The display shows the value of voltage.
5. If the display shows the message "O.L", select a higher range.
6. Press the Hz% key to select measurements “Hz” or “%” in order to display the values of
frequency and duty cycle of input voltage. The bargraph is not active in these functions.
7. To use the HOLD, RANGE, MAX MIN and REL functions, see § 4.2.

HT61 - HT62
EN - 11
5.3. AC/DC VOLTAGE MEASUREMENT WITH LOW IMPEDANCE (LOZ)
CAUTION
The maximum input AC/DC voltage is 600V. Do not measure voltages
exceeding the limits given in this manual. Exceeding voltage limits could
result in electrical shocks to the user and damage to the instrument.
Fig. 4: Use of the instrument for AC/DC voltage measurement with low impedance (LoZ)
1. Select position LoZV
2. Press the MODE key until the symbol“DC””is displayed
3. Insert the red cable into input terminal VHz%(HT61) or Hz%V 
(HT62) and the black cable into input terminal COM.
4. Position the red lead and the black lead respectively in the desired spots of the circuit
to be measured (see Fig. 4) for AC voltage measurement or in the spots with positive
and negative potential of the circuit to be measured (see Fig. 2) for DC voltage
measurement. The display shows the value of voltage.
5. If the display shows the message "O.L", select a higher range.
6. When symbol "-" appears on the instrument’s display, it means that voltage has the
opposite direction with respect to the connection in Fig. 2.
7. To use the HOLD, RANGE, MAX MIN and REL functions, see § 4.2

HT61 - HT62
EN - 12
5.4. FREQUENCY AND DUTY CYCLE MEASUREMENT
CAUTION
The maximum input AC voltage is 1000V. Do not measure voltages
exceeding the limits given in this manual. Exceeding voltage limits could
result in electrical shocks to the user and damage to the instrument.
Fig. 5: Use of the instrument for frequency measurement and duty cycle test.
1. Select position Hz%.
2. Press the Hz% key to select measurements “Hz” or “%” in order to display the values of
frequency and duty cycle of input voltage.
3. Insert the red cable into input terminal VHz%(HT61) or Hz%V 
(HT62) and the black cable into input terminal COM.
4. Position the red lead and the black lead respectively in the spots of the circuit to be
measured (see Fig. 5). The value of frequency (Hz) or of duty cycle (%) is shown on
the display. The bargraph is not active in these functions.
5. If the display shows the message "O.L", select a higher range.
6. To use the HOLD function, see § 4.2.

HT61 - HT62
EN - 13
5.5. RESISTANCE MEASUREMENT AND CONTINUITY TEST
CAUTION
Before attempting any resistance measurement, cut off power supply from
the circuit to be measured and make sure that all capacitors are discharged,
if present.
Fig. 6: Use of the instrument for resistance measurement and continuity test
1. Select position (HT61) or (HT62).
2. Insert the red cable into input terminal VHz%(HT61) or Hz%V 
(HT62) and the black cable into input terminal COM.
3. Position the test leads in the desired spots of the circuit to be measured (see Fig. 6).
The display shows the value of resistance.
4. If the display shows the message "O.L", select a higher range.
5. Press the MODE key to select “” measurement, relevant to the continuity test, and
position the test leads in the desired spots of the circuit to be measured.
6. The value of resistance (which is only indicative) is displayed in and the instrument
sounds if the value of resistance is <100
7. To use the HOLD, RANGE, MAX MIN and REL functions, see § 4.2.

HT61 - HT62
EN - 14
5.6. DIODE TEST
CAUTION
Before attempting any resistance measurement, cut off power supply from
the circuit to be measured and make sure that all capacitors are discharged,
if present.
Fig. 7: Use of the instrument for diode test
1. Select position (HT61) or (HT62).
2. Press the MODE key to select “” measurement.
3. Insert the red cable into input terminal VHz%(HT61) or Hz%V 
(HT62) and the black cable into input terminal COM.
4. Position the leads at the ends of the diode to be tested (see Fig. 7), respecting the
indicated polarity. The value of directly polarized threshold voltage is shown on the
display.
5. If threshold value is equal to 0mV, the P-N junction of the diode is short-circuited.
6. If the display shows the message “O.L”, the terminals of the diode are reversed with
respect to the indication given in Fig. 7 or the P-N junction of the diode is damaged.

HT61 - HT62
EN - 15
5.7. CAPACITANCE MEASUREMENT (HT62)
CAUTION
Before carrying out capacitance measurements on circuits or capacitors, cut
off power supply from the circuit being tested and let all capacitance in it be
discharged. When connecting the multimeter and the capacitance to be
measured, respect the correct polarity (when required).
Fig. 8: Use of the instrument for Capacitance measurement
1. Select position 
2. Press the MODE key until the symbol “nF” is displayed.
3. Insert the red cable into input terminal Hz%V and the black cable into input
terminal COM.
4. Press the REL button before carrying out measurements.
5. Position the leads at the ends of the capacitor to be tested, respecting, if necessary,
the positive (red cable) and negative (black cable) polarity (see Fig. 8). The display
shows the value of capacitance.
6. The message “O.L.” indicates that the value of capacitance exceeds the maximum
measurable value.
7. To use the HOLD function, see § 4.2.

HT61 - HT62
EN - 16
5.8. TEMPERATURE MEASUREMENT WITH K PROBE (HT62)
CAUTION
Before attempting any temperature measurement, cut off power supply from
the circuit to be measured and make sure that all capacitors are discharged,
if present.
Fig. 9: Use of the instrument for Temperature measurement
1. Select position °C°F
2. Press the MODE key until the symbol “°C” or “°F” is displayed.
3. Insert the provided adapter into input terminals Hz%V (polarity +) and COM
(polarity -) (see Fig. 9)
4. Connect the provided K-type wire probe or the optional K-type thermocouple (see § ) to
the instrument by means of the adapter, respecting the positive and negative polarity
on it. The display shows the value of temperature.
5. The message “O.L.” indicates that the value of temperature exceeds the maximum
measurable value.
6. To use the HOLD function, see § 4.2.

HT61 - HT62
EN - 17
5.9. DC CURRENT MEASUREMENT
CAUTION
Maximum input DC current is 10A (input 10A) or 600mA (input mAA). Do
not measure currents exceeding the limits given in this manual. Exceeding
voltage limits could result in electrical shocks to the user and damage to the
instrument.
Fig. 10: Use of the instrument for DC current measurement
1. Cut off power supply from the circuit to be measured.
2. Select position A, mA or 10AHz%.
3. Insert the red cable into input terminal 10A or into input terminal mAAand the black
cable into input terminal COM.
4. Connect the red lead and the black lead in series to the circuit whose current you want
to measure, respecting polarity and current direction (see Fig. 10).
5. Supply the circuit to be measured. The display shows the value of current.
6. If the display shows the message "O.L", the maximum measurable value has been
reached.
7. When symbol "-" appears on the instrument's display, it means that current has the
opposite direction with respect to the connection in Fig. 10.
8. To use the HOLD, RANGE, MAX MIN and REL functions, see § 4.2.

HT61 - HT62
EN - 18
5.10. AC CURRENT MEASUREMENT
CAUTION
Maximum input AC current is 10A (input 10A) or 600mA (input mAA). Do
not measure currents exceeding the limits given in this manual. Exceeding
voltage limits could result in electrical shocks to the user and damage to the
instrument.
Fig. 11: Use of the instrument for AC current measurement
1. Cut off power supply from the circuit to be measured.
2. Select position A, mA or 10AHz%.
3. Press the MODE key to select “AC” measurement.
4. Insert the red cable into input terminal 10A or into input terminal mAAand the black
cable into input terminal COM.
5. Connect the red lead and the black lead in series to the circuit whose current you want
to measure, respecting polarity and current direction (see Fig. 11).
6. Supply the circuit to be measured. The display shows the value of current.
7. If the display shows the message “O.L”, the maximum measurable value has been
reached.
8. Press the Hz% key to select measurements “Hz” or “%” in order to display the values of
frequency and duty cycle of input current. The bargraph is not active in these functions.
9. To use the HOLD, RANGE, MAX MIN and REL functions, see § 4.2.

HT61 - HT62
EN - 19
6. MAINTENANCE
CAUTION
Only expert and trained technicians should perform maintenance
operations. Before carrying out maintenance operations, disconnect all
cables from the input terminals.
Do not use the instrument in environments with high humidity levels or
high temperatures. Do not expose to direct sunlight.
Always switch off the instrument after use. In case the instrument is not to
be used for a long time, remove the battery to avoid liquid leaks that could
damage the instrument’s internal circuits.
6.1. REPLACING THE BATTERIES AND THE INTERNAL FUSES
When the LCD display shows the symbol “” ”, it is necessary to replace the battery.
Replacing the battery
1. Position the rotary switch to OFF and remove the cables from the input terminals.
2. Turn the fastening screw of the battery compartment cover from position “” to position
“” and remove it.
3. Remove the battery and insert a new battery of the same type (see § ), respecting the
indicated polarity.
4. Restore the battery compartment cover into place and turn the fastening screw from
position “” to position “ ”.
5. Do not scatter old batteries into the environment. Use the relevant containers for
disposal.
Replacement of fuses
1. Position the rotary switch to OFF and remove the cables from the input terminals.
2. Turn the fastening screw of the battery compartment cover from position “” to position
“” and remove it.
3. Remove the damaged fuse and insert a new one of the same type (see § ), respecting
the indicated polarity.
4. Restore the battery compartment cover into place and turn the fastening screw from
position “” to position “ ”.
6.2. CLEANING THE INSTRUMENT
Use a soft and dry cloth to clean the instrument. Never use wet cloths, solvents, water, etc.
6.3. END OF LIFE
WARNING: the symbol on the instrument indicates that the appliance and its
accessories must be collected separately and correctly disposed of.
