Huawei Ascend Y330 User manual

Quick Start Guide
Y330
HUAWEI

Dual card dual standby single pass
Your phone supports only dual card dual standby single
pass, which means you cannot use both SIM cards for
calls or data services simultaneously.
• When you are on a call using SIM card 1, SIM card 2
cannot be used to make or answer calls. If someone calls
SIM card 2, the caller will hear a voice message similar to
"The subscriber you dialed is out of the service area" or
"The subscriber you dialed cannot be connected for the
moment, please try again later."
• When you are using SIM card 1's data service, SIM card
2's data service will be disabled.
Your phone's single pass feature helps reduce power
consumption and increase your phone's standby time.
It may be a good idea to contact your service provider and
subscribe to missed call reminder and related assistance
services to avoid the conflicts mentioned above.

Your phone at a glance
Thank you for choosing the HUAWEI Ascend Y330
smartphone.
Before you start, let's take a look at your new phone.
Earpiece
Headset jack
Home
Micro USB
port
Return
Volume
button
Menu
Power
button

Installation
Caution
When you install a SIM card, make sure you do not mix
up the slots of WCDMA and GSM cards. Otherwise your
phone may fail to detect the SIM card.
Follow the instructions in the following figures to complete
the installation. Then press and hold the power button to
power on your phone.
1Open the battery cover.
2Insert the SIM cards.
Insert the microSD card (optional).
3

Charge the phone.
Install the battery.
Install the battery cover.
4
5
6
ab

Dual-card management
Go to and touch SIM card management to enable or
disable your SIM cards. You can enable the two SIM cards
simultaneously.
Touch Data connection to set the default SIM card for your
data service.

Locking and unlocking the screen
Your phone automatically locks its screen after being idle for
a specified period of time.
Alternatively, you can press the power button to manually
lock the screen. You can go to and touch Display >
Sleep to set the screen timeout period.
If the screen is off, press the power button to turn it on. Slide
your finger in any direction to unlock the screen.
 

Managing contacts
Touch to open Contacts .
Go to the Favorites tab to mark a contact as your favorite or
manage contact groups.
On the Contacts screen, touch > Import/Export to
import contacts from other devices or export contacts on
your phone.
++
Create a
contact

Placing a call
Touch and enter a phone number on the dialer. If you
have existing contacts on your phone, your phone
automatically displays matching results as you type. Touch a
number to place a call.
You can also touch a number from Contacts, Messaging,
Email, or Browser to place a call.
400
1 2

Messaging
Touch to open Messaging .
Attaching a file to a text message converts the message into
a multimedia message. You can save photos, audio clips, or
videos from received multimedia messages.
When you are typing, open the notification panel and touch
to switch the input method.
**********
Hello!
Attach
a file

Camera
Touch to open Camera .
Touch to take a photo.
To shoot a video, frame the scene you want to record and
touch to start shooting.
Switch the
capture
mode
View your
photos

Editing a photo
Touch to open Gallery .
When browsing a photo, touch to edit it. You can then
crop it, adjust its color, apply filters or frames to it, and more.
Edit the

Listening to music
Touch to open Music .
Play your songs by name, artist, or album, and mark your
favorite songs.

Phone Manager
Phone Manager supports system diagnosis and
optimization at the touch of a button. You can configure
your phone's power saving mode, manage application
permissions, clean up your storage, and turn on do not
disturb mode.
Touch to open Phone Manager .
Touch to
scan
Flick left
for more
functions

More information
Encounter any issues while using your phone?
For the full user guide, go to 
http://consumer.huawei.com/en/ and search for 
HUAWEI Ascend Y330.
Want to learn more about Huawei Emotion UI?
Visit http://en.ui.vmall.com/ for the latest information.

Legal Notice
Copyright © Huawei Technologies Co., Ltd. 2014.
All rights reserved.
No part of this manual may be reproduced or transmitted in
any form or by any means without prior written consent of
Huawei Technologies Co., Ltd. and its affiliates ("Huawei").
The product described in this manual may include
copyrighted software of Huawei and possible licensors.
Customers shall not in any manner reproduce, distribute,
modify, decompile, disassemble, decrypt, extract, reverse
engineer, lease, assign, or sublicense the said software,
unless such restrictions are prohibited by applicable laws or
such actions are approved by respective copyright holders.
Trademarks and Permissions
, , and are trademarks or registered
trademarks of Huawei Technologies Co., Ltd.
Android™ is a trademark of Google Inc.
The Bluetooth
®
word mark and logos are registered
trademarks owned by
Bluetooth SIG, Inc. and any use of such
marks by Huawei Technologies Co., Ltd. is under license.
Other trademarks, product, service and company names
mentioned may be the property of their respective owners.
Notice
Some features of the product and its accessories described
herein rely on the software installed, capacities and settings
of local network, and therefore may not be activated or may
be limited by local network operators or network service
providers.

Thus, the descriptions herein may not exactly match the
product or its accessories which you purchase.
Huawei reserves the right to change or modify any
information or specifications contained in this manual
without prior notice and without any liability.
Third-Party Software Statement
Huawei does not own the intellectual property of the third-
party software and applications that are delivered with this
product. Therefore, Huawei will not provide any warranty of
any kind for third party software and applications. Neither
will Huawei provide support to customers who use third-
party software and applications, nor be responsible or liable
for the functions or performance of third-party software and
applications.
Third-party software and applications services may be
interrupted or terminated at any time, and Huawei does not
guarantee the availability of any content or service. Third-
party service providers provide content and services through
network or transmission tools outside of the control of
Huawei. To the greatest extent permitted by applicable law,
it is explicitly stated that Huawei shall not compensate or be
liable for services provided by third-party service providers, or
the interruption or termination of third-party contents or
services.
Huawei shall not be responsible for the legality, quality, or
any other aspects of any software installed on this product,
or for any uploaded or downloaded third-party works in any
form, including but not limited to texts, images, videos, or
software etc. Customers shall bear the risk for any and all
effects, including incompatibility between the software and

this product, which result from installing software or
uploading or downloading the third-party works.
This product is based on the open-source Android™
platform. Huawei has made necessary changes to the
platform. Therefore, this product may not support all the
functions that are supported by the standard Android
platform or may be incompatible with third-party software.
Huawei does not provide any warranty or representation in
connect with any such compatibility and expressly excludes
all liability in connection with such matters.
DISCLAIMER
ALL CONTENTS OF THIS MANUAL ARE PROVIDED "AS IS".
EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO
WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, IN NO EVENT SHALL HUAWEI BE LIABLE FOR ANY
SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, OR LOSS OF PROFITS, BUSINESS, REVENUE,
DATA, GOODWILL SAVINGS OR ANTICIPATED SAVINGS
REGARDLESS OF WHETHER SUCH LOSSES ARE FORSEEABLE
OR NOT.
THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT
APPLY TO LIABILITY FOR PERSONAL INJURY TO THE EXTENT
APPLICABLE LAW PROHIBITS SUCH A LIMITATION) OF
HUAWEI ARISING FROM THE USE OF THE PRODUCT
DESCRIBED IN THIS MANUAL SHALL BE LIMITED TO THE

AMOUNT PAID BY CUSTOMERS FOR THE PURCHASE OF THIS
PRODUCT.
Import and Export Regulations
Customers shall comply with all applicable export or import
laws and regulations and be responsible to obtain all
necessary governmental permits and licenses in order to
export, re-export or import the product mentioned in this
manual including the software and technical data therein.
Privacy Policy
To better understand how we protect your personal
information, please see the privacy policy at

http://consumer.huawei.com/privacy-policy .

Personal Information and Data
Security
The use of some functions or third-party applications on your
device could result in your personal information and data
being lost or becoming accessible to others. Several
measures are recommended to help you protect personal
and confidential information.
• Place your device in a safe area to prevent it from
unauthorized use.
• Set your device screen to lock and create a password or
unlock pattern to open it.
• Periodically back up personal information kept on your
SIM/UIM card, memory card, or stored in your device
memory. If you change to a different device, be sure to
move or delete any personal information on your old
device.
• If you are worried about viruses when you receive
messages or emails from a stranger, you can delete them
without opening them.
• If you use your device to browse the Internet, avoid
websites that might pose a security risk to avoid theft of
your personal information.
• If you use services such as Wi-Fi tether or Bluetooth, set
passwords for these services to prevent unauthorized
access. When these services are not in use, turn them off.
• Install or upgrade device security software and regularly
scan for viruses.
