Huawei RT-FIC-16ASE User manual

Quidway® AR 46 Router Enhanced Asynchronous Serial Port Module
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved. 1
http://datacomm.huawei.com
Quidway® AR 46 Router Enhanced Asynchronous Serial Port
Module
Overview
The major function of the AR46 router enhanced asynchronous serial port module, FIC-ASE, is to
transmit and process the asynchronous serial port data flow. The largest rate of each
asynchronous serial port reaches 115.2 Kbps. It can support terminal access service and
asynchronous private line. Moreover, the asynchronous serial port can serve as the
middle-/small-sized ISP dialup access server. It can interconnect 8 or 16 LANs through the
asynchronous dialup line.
At present, the AR46 router supports two kinds of enhanced asynchronous serial port modules:
8-port module and 16-port module.
Specifications
The specifications of enhanced asynchronous serial port module of the AR46 router are shown in
the following table.
Product Number Connector
Type Description
RT-FIC-16ASE RJ45
AR46 16-port asynchronous serial interface module (RJ45)
RT-FIC-8ASE RJ45
AR46 8-port asynchronous serial interface module (RJ45)
Interface attribute
The attributes of FIC-8ASE and FIC-16ASE interfaces are shown in the following table:
Description
Attribute FIC-8ASE FIC-16ASE
Connector type RJ45
Connector quantity 8 (FIC-8ASE)
16 (FIC-16ASE)
Interface standard and working
mode RS232

Quidway® AR 46 Router Enhanced Asynchronous Serial Port Module
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved. 2
http://datacomm.huawei.com
Description
Attribute FIC-8ASE FIC-16ASE
Cable type
AUX cable
Ethernet standard network cable
FIC-8ASE/FIC-16ASE dumb terminal cable
Minimum baud rate (bps) 300
Maximum baud rate (bps) 115.2 k
Service supported
Modem dialup
Backup
Terminal access service
Asynchronous private line
