Quidway® AR 46 Router E3/T3 Interface Module
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved. 1
http://datacomm.huawei.com
Quidway® AR 46 Router E3/T3 Interface Module
Overview
The E3/T3 interface module of the AR46 router includes four types: FIC-1CE3, FIC-1CT3,
FIC-1AE3 and FIC-1AT3.
The major functions of E3 interface module, FIC-1CE3, of the AR46 router are:
In the E3 working mode, it can transmit and process one-channel E3 high-speed data flow and
provide the access service for E3 data flow.
z
z
z
z
z
z
z
z
In the CE3 working mode, it can provide N × 64 Kbps (N is no more than 128) lower-rate
access service for users.
The major functions of T3 interface module, FIC-1CT3, of the AR46 router are:
In the T3 working mode, it can transmit and process one-channel T3 high-speed data flow and
provide the access service for T3 data flow.
In the CT3 working mode, it can provide N × 64 Kbps or 56 Kbps (N is no more than 128)
lower-rate access service for users.
FIC-1AE3 is the abbreviation of 1-port 34.368 Mbps ATM-E3 interface card. FIC-1AT3 indicates
1-port 44.736 Mbps ATM-T3 interface card. Where, ATM stands for Asynchronous Transfer Mode.
They have the following function features in the system:
Support two ATM cell mapping modes: ATM Direct Mapping (ADM) and Physical Layer
Convergence Protocol (PLCP).
Allow scrambling transmission in data sending.
Support two clock modes: line clock (when serving as DTE interface) and internal clock (when
serving as DCE interface).
Support four self-loop test modes: local cell loop, local loop, remote load loop and remote line
loop.
Specifications
The specifications of E3/T3 interface module of the AR46 router are shown in the following table.
Product Number Connector Type Description
RT-FIC-1AE3 SMB AR46 1-portATM Over E3 module
RT-FIC-1AT3 SMB AR46 1-port ATM Over T3 module
RT-FIC-1CE3 SMB AR46 1-prot E3/CE3 compatible interface module
RT-FIC-1CT3 SMB AR46 1-port T3/CT3 compatible interface module
Quidway® AR 46 Router E3/T3 Interface Module
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved. 2
http://datacomm.huawei.com
Interface attribute
The interface attributes of E3/T3 interface module of the AR46 router are shown in the following
tables.
FIC-1AE3 interface attribute
Attribute FIC-1AE3
Connector type SMB
Connector quantity 2
Interface standard G.703,G.751,G.832,G.823
Interface rate 34.368 Mbps
Interface cable type E3/T3 cable (75Ωcoaxial cable)
Service supported ATM Traffic CBR (Constant Bit Rate), rt_VBR (Variable Bit Rate-Real Time),
nrt_VBR (Variable Bit Rate-Non Real Time), UBR (Unspecified Bit Rate)
FIC-1AT3 interface attribute
Attribute FIC-1AT3
Connector type SMB
Connector quantity 2
Interface standard G.703, G.704, G.823
Interface rate 44.736 Mbps
Interface cable type E3/T3 cable (75Ωcoaxial cable)
Service supported ATM Traffic CBR (Constant Bit Rate), rt_VBR (Variable Bit Rate-Real Time),
nrt_VBR (Variable Bit Rate-Non Real Time), UBR (Unspecified Bit Rate)
FIC-1CE3 interface attribute
Attribute Description
Connector type SMB
Connector quantity 2/4
Interface standard G.703,G.704,G.751
Interface rate 34.368 Mbps
Interface cable type E3 cable (75Ωcoaxial cable)
Working mode E3
CE3
Service supported E3
Quidway® AR 46 Router E3/T3 Interface Module
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved. 3
http://datacomm.huawei.com
FIC-1CT3 interface attribute
Attribute Description
Connector type SMB
Connector quantity 2
Interface standard
G.703
G.704
G.752
AT&T TR 54014
AT&T TR 62415
ANSI T1.107
Interface rate 44.736 Mbps
Interface cable type T3 cable (75Ωcoaxial cable)
Working mode T3
CT3
Service supported T3 leased line
