Huawei E5 User manual

1
Wi-Fi Router Huawei E5
User Guide

2
Content
•Modem Description
•Specification
•SW installation guide
•User manual
•Troubleshooting
•Terms

3
Modem Description
Huawei E5830 HSDPA Wifi-router and a USB modem combined in one
device (hereinafter ‘Е5’) that supports 3G and allows users to access
the Internet and send/receive short text messages direct from their PC
or multimedia devices connected to the Е5 through WiFi.
The modem is connected to the USB port on the computer or through a
WiFi connection. The MicroSD slot allows using the modem both as
external storage and file depot.

4
Modem Description
The E5 support the following standards:
•High-Speed Downlink Packet Access (HSDPA)
•High-Speed Uplink PacketAccess (HSUPA)
•UniversalMobile TelecommunicationsSystem (UMTS)
•Enhanced Data Rates for GSM Evolution (EDGE)
•General Packet Radio Service (GPRS)
•Global System for Mobile communications (GSM)
The E5 supports:
•HSDPA/UMTS data service
•EDGE/GPRS data service
•WCDMA/GSM short message service

5
•The E5 supports Plug and play (PnP), i.e. there is not need to have
setup disks as the device is installed automatically.
•USB (2.0) standard connector
•Supports up to 32GB memory. Insert a memory card to use the
modem as an external storage.
•Wi-Fi 802.11.b/g, encoding type WEP, WPA, WPA2
•OS supported Windows 2000/ Windows XP/ Windows Vista/
Windows7/ Mac OS X 10.4 and higher
Modem Description

6
Content
•Modem Description
•Specification
•SW installation guide
•User manual
•Troubleshooting
•Terms

7
Standard
WCDMA/HSDPA
R5
GSM/GPRS/EDGE
R99
Data rate
HSUPA 5.76Mbps;
HSDPA 7.2Mbps
EDGE
–236.8
Kbps
Indication
OLED display
Dimensions
(L х W х H)
95 mm
×48 mm ×13
mm
Weight
<90g
Temperature
Operating
temperature
10°;+45°
Storage temperature
:
–
20°;+70°
Humidity
5%
-95%
System
requirements
CPU: Pentium4, 1 GHz or above
Memory: 128 MB RAM or above
Hard Disk: 50 MB or above
Operating System : Windows
2000/ХР/Vista/7, Mac OS X10.4 and
10.5 with latest updates
USB Modem Interface: USB2.0 high
speed
Display Resolution: 800 x 600 or above
(1024 x 768 is recommended)
Specification
Main Features

8
Kcell Connect features
SMS
Sending / receiving short text messages.
Sending long messages
.
Copying SMS from SIM card and vice versa
.
Visual notification of new and unread messages
.
Sending / receiving short text messages
.
SD card
Editing SD card content.
Direct connection as external storage.
Access to files on the SD card through Wi
-Fi
USSD
Sending / receiving USSD commands
Specification

9
Data transmission
•
Enabling / disabling data transmission
(Internet).
•
Creating, editing, removing user’s connection
settings (APN). Data transmission is enabled
automatically.
•
Automatic data transmission is enabled by
default.
SW installation
Automatic SW installation when connected to PC
(Plug and Play)
Other
Network settings:
•
Automatic registration mode
•
Manual registration mode
Status: network signal strength, operator, mode
.
Specification
Kcell Connect features

10
Status indicator
1
Signal indicator
2
•
Network type –2G
•
Network type –3G
3
•
Wi-Fi indicator
•
Number of connections
4
Connection status
5
•
New SMS
•
Number of new SMS
6
Battery indicator
7
Roaming indicator
8
•
Automatic mode
•
Manual mode

11
Content
•Modem Description
•Specification
•SW installation guide
•User manual
•Troubleshooting
•Terms

12
Procedure for installing the management program depends on the
operating system (OS) installed on your PC. The following section
takes Windows XP as an example.
SW installation guide
1. Power on the E5.
2. Connect the E5 and PC with the compatible
data cable.
3. The OS automatically detects and
recognizes new hardware and starts the
installation
wizard.
Note: If the auto-run program does not respond, find the installation
file in the driver path.
Then double-click the installation file to run the program. Follow the
onscreen instructions of the installation wizard.

13
After the program is installed, the shortcut icon of the program is
displayed on the desktop. Once the device is installed, the program
starts automatically. Every time the E5 is connected to the PC with a
compatible data cable, the program is launched automatically.
Note: You can also double-click the shortcut icon on the desktop to
launch the program.
SW installation guide

14
Access the Web Management Page
Access the Web Management Page
»Make sure that the connection between
the E5 and the Wi-Fi device or computer is proper..
»Start the Internet browser and enter
http://192.168.1.1 or http://e5.home/index.asp
in the address bar..
»Enter the password, and then click Login.
Admin: This user is authorized to view and change configurations.
The default password is admin.
Note: If the page is unavailable while the E5 is being connected with
PC through the compatible data cable, launch the management
program and then access the web page.
.

How to remove the E5
•To remove the E5 use the Remove Windows Software feature.
•Double-click the task bar . The ‘Safely Remove Hardware’ tip will
appear o the screen.
•Select ‘Eject CD Drive (E:) Web Partner’ to disconnect it.
•Follow the tips to disconnect the E5.
How to remove the ‘Web Partner’ program.
•Click on ‘Start’.
•Select ‘Control Panel’.
•Click ‘Add/Remove a Program’ to remove Web Partner.
15
SW installation guide

16
•Modem Description
•Specification
•SW installation guide
•User manual
•Troubleshooting
•Terms
Content

17
User manual
SMS
To manage SMS, open the ‘SMS’ tab in Kcell Connect interface.
Supported features:
•Receiving SMS
•Creating SMS
•Deleting SMS
Shared access to files
Supports shared access to files stored on the MicroSD through a Wi-Fi
connection.
USSD
To send a USSD command, open the USSD tab in Kcell Connect
interface.
•Supported features:
•Sending USSD commands
•Switching between USSD commands

18
User manual
Everyday Use
Charging the Battery
Note: If you have not used the battery for a long time, please charge it
first.
Caution:
Use the charger (5.3 V, 650 mA) compatible the E5 model and provided
by a designated manufacturer. If a charger incompatible with the device
model or provided by other manufacturers or vendors is used, the E5
may fail to work and dangers may be caused as well as the warranty
applicable to the E5 and other rights may be cancelled.
If the charger is not provided in the package, you can contact your local
dealer to buy one yourself.
.
- Method 1: Charging by Using the charger

19
–Method 2: Charging by Connecting to a PC
»Power off the E5.
»Connect the E5 and PC with a compatible data cable.
•Saving Power mode
•If no operation is performed on the E5 for a while, the indicators are
off.
•If the E5 has not been accessed for 30 minutes by default, the E5
goes to the sleep mode.
•When the E5 is in the sleep mode, you can press any key to
activate the E5. Then the indicators become lightened.
•When the E5 is in the sleep mode, the Wi-Fi is automatically
disabled.
•Enabling/Disabling the Wi-Fi Function
•Press and hold until the indicator is on.
•The Wi-Fi connection is enabled.

20
•Note: To disable Wi-Fi, press and hold the button until indicator is
off..
•Establishing a WPS Connection
•If the Wi-Fi Clients are connected with the E5 that supports WPS,
the E5 can generate a network key without manual input. To
establish a WPS connection, do as follows:
»Power on the E5. .
»Start the Clients connected with the E5.
»Enable the WPS function of the E5.
•Note: After the Wi-Fi is enabled, press and hold Connect.
»Enable the WPS function of the Clients.
•Note: For the Wi-Fi operations of the Clients see the Clients’ user
guide.
User manual
