1 Placing the Device
NO TE
● Do not install the ONT outdoors or in an outdoor cabinet.
● The ONT can be mounted onto a wall or placed on a desk. Do not install the ONT in
other modes, such as ceiling.
● Keep 10 cm clearance on all sides to ensure adequate ventilation.
● It is recommended that the computer and ONT be put far away from electric appliances
that generate strong magnetic or electric elds, such as microwave ovens.
Mounting an ONT on the desk
The gure below shows an ONT that is horizontally placed on a desk.
NO TE
The appearance shown in this document may be dierent from the actual appearance of
the product. The actual product prevails.
Huawei OptiXstar HG8140H5
Quick Start for QR code 1 Placing the Device
Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd. 1

Mounting an ONT onto the wall
1. Mark two positions with the same spacing as that between the two mounting
holes of the ONT using a marker on a wall.
2. Select a proper drill bit according to the outer diameter of the screws. Use a
hammer drill to drill the marked positions on the wall. Then clean the holes
and install two expansion bolts.
3. Use a screwdriver to fasten the screws into the expansion bolts, reserving 5
mm ends out of the wall, and mount the ONT onto the screws.
NO TE
It is recommended that the screw be about 4 mm in diameter and longer than 20 mm. The
screw head should be between 6mm and 9mm in diameter.
Huawei OptiXstar HG8140H5
Quick Start for QR code 1 Placing the Device
Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd. 2

2 Connecting Cables
Huawei OptiXstar HG8140H5
Quick Start for QR code 2 Connecting Cables
Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd. 3

NO TE
● The ber connector connected to the optical port on the wall varies depending on
actual conditions.
● To ensure normal use of bers, make sure that the ber bending radius is larger than 30
mm.
No. Item Description
1On/O Powers the ONT on or o.
2 Power Connects to a power adapter.
3 TEL Connects to the ports on a telephone or fax machine.
4 LAN1-
LAN4
Connects to PCs or IP set-top boxes (STBs).
5 Reset Press the button for a short time to reset the device; or press
the button for a long time (longer than 10s) to restore the
device to the default settings and reset the device.
NOTE
Reset Huawei ONTs with caution. Otherwise, the ONTs may fail to
access the Internet. If an ONT cannot access the Internet after a
reset, contact your Internet service provider.
6 Optical
port
The optical port is equipped with a rubber plug and
connected to a ber for upstream transmission.
The type of the optical connector connected to the optical
port can be SC/APC.
Huawei OptiXstar HG8140H5
Quick Start for QR code 2 Connecting Cables
Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd. 4

3 Indicator Description
Indicator Status Description
Power Steady on The ONT is powered on.
O The power supply is cut o.
PON/LOS See the following table.
LAN1-
LAN4
Steady on The Ethernet connection is in the normal state.
Blinking Data is being transmitted over the Ethernet port.
O The Ethernet connection is not set up.
TEL Steady on The ONT is registered with the softswitch but no
service ows are transmitted.
Blinks twice
a second
The ONT is registered with the softswitch, and data is
being transmitted on the port.
Blinks once
every 2
seconds
The ONT fails to be registered with the softswitch.
O The POTS port is disabled.
Status
No.
PON
Status
LOS
Status
Description
1O O The ONT is prohibited by the upper-layer
device or blinks abnormally. Contact the
service provider for help.
Huawei OptiXstar HG8140H5
Quick Start for QR code 3 Indicator Description
Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd. 5

Status
No.
PON
Status
LOS
Status
Description
2 Blinks
twice a
second
Blinks
twice a
second
3 Blinks
twice a
second
O The ONT attempts to set up a connection
with its upper-layer device.
4 Steady
on
O A connection is set up between the ONT and
its upper-layer device.
5O Blinks
once every
2 seconds
The ONT is not connected to bers or does
not receive optical signals.
6 Blinks
once
evey 2
seconds
Blinks
once every
2 seconds
The hardware is faulty.
Huawei OptiXstar HG8140H5
Quick Start for QR code 3 Indicator Description
Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd. 6

4 Technical Specications
Product Function
Huawei OptiXstar
HG8140H5
● 4 Ethernet ports
● 1 POTS port
● Power adapter input: See the nameplate on the adapter.
● System power supply: See the nameplate on the device.
● Ambient temperature: 0ºC to +40ºC
● Ambient humidity: 5%–95% (non-condensing)
● Dimensions (H x W x D): 30 mm x 168 mm x 115 mm (without pads)
● Weight: About 230g
● Maximum system power consumption: 7 W
Huawei OptiXstar HG8140H5
Quick Start for QR code 4 Technical Specications
Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd. 7

5 FAQs
NO TE
The following web page is only for reference. The actual web page of the product prevails.
How do I log in to the Huawei ONT web page?
NO TE
You are advised to use the latest browser to log in to the web conguration page. Chrome
58/Edge 14/Firefox 54/Safari 10/Opera 55 or later is recommended. If the browser of an
earlier version is used, compatibility issues may occur.
1. Use a network cable to connect a PC to the Huawei ONT.
2. Set the IP address of the PC in the same subnet as the web address of the
Huawei ONT.
For example, if the web address of the Huawei ONT is
192.168.100.1 (for the web address of the Huawei ONT, see the product
nameplate), set the IP address of the PC to 192.168.100.100.
NO TE
The preceding cable connection diagram and login pages are only for reference, and those
of the actual product prevail.
3. Log in to the web conguration page.
a. Open a browser. In the address box, enter the web address (printed on
the nameplate of the Huawei ONT). Press Enter.
b. Enter the login user name and password (printed on the nameplate of
the Huawei ONT). Click Log In.
Huawei OptiXstar HG8140H5
Quick Start for QR code 5 FAQs
Issue 01 (2022-12-08) Copyright © Huawei Technologies Co., Ltd. 8

NO TE
● If you do not perform any operations after logging in to the system within five
minutes, you will be logged out, and the system automatically returns to the login
interface.
● The system will be locked for one minute if you input incorrect user name and
password for three consecutive times.
● Change the initial password after logging in to the web page for the rst time.
What can I do if the network speed is slow?
1. Check whether network cables are properly connected. Remove and then
insert the network cables. Then, check whether the network speed is normal.
2. Check whether downloading, network video watching, or other operations
occupy a large amount of bandwidth. Due to bandwidth restrictions, if some
network applications occupy a large amount of network bandwidth, the
network speed is slow.
3. Use another PC, mobile phone, or pad to check whether the network speed is
normal.
A phone does not ring upon an incoming call but communication is in
normal state when the phone is in o-hook state.
The ONT supports a maximum of 60 V AC ringing current voltage. Check whether
the ringing current voltage of the phone is higher than 60 V AC. If it is higher than
60 V AC, replace the phone.
How do I restore the Huawei ONT to factory setting?
Press Reset by using a needle-type object for longer than 10s to restore factory
defaults and reset the Huawei ONT. If the indicator is o and then is lit, the
system restarts successfully.
NO TE
Exercise caution when restoring factory settings. This function may cause the loss of ONT
conguration information and further cause an Internet access failure. If this problem
occurs, contact your service provider for help.
How can I download Huawei ONT rmware or ONT software?
Huawei ONT is used with an OLT and NMS of a required version. If the versions
are not the required ones, the ONT may not work.
If required, contact your internet service provider to obtain the correct ONT
rmware or software.
