Huawei PDC-0038V4ACIOA User manual

HUAWEI TECHNOLOGIES CO., LTD.
PDC-0038V4ACIOA
V100R001
Quick Installation Guide
Issue: 01
Part Number: 31505549
Date: 2013-05-15

1
Safety Precautions
To ensure safety of humans and the equipment, pay attention to the safety symbols on the equipment and all the
safety instructions in this document. The "NOTE", "CAUTION", and "WARNING" marks in this document do not
represent all the safety instructions. They are only supplements to the safety instructions. When operating
Huawei equipment, in addition to following the general precautions in this document, follow the specific safety
instructions given by Huawei. Huawei will not be liable for any consequences that are caused by the violation of
safety regulations and design, production, and usage standards.
Local Safety Regulations
When operating Huawei equipment, you must follow the local laws and regulations.
Personnel Requirements
1. Only trained and qualified personnel are allowed to install, operate, and maintain Huawei equipment, and they
must understand basic safety precautions.
2. You can modify default parameters only after being granted approval from Huawei technical support.
Symbols
■
Alerts you to a potentially hazardous situation that could, if not avoided, result in equipment damage,
data loss, performance deterioration, or unanticipated results.
Provides additional information to emphasize or supplement important points in the main text.
■
■
Precautions
Human Safety
1. To prevent electric shocks, get tools insulated and wear insulation gloves when connecting cables.
2. In case of fire, use a dry power fire extinguisher to put out the fire. Using a fluid fire extinguisher may cause
electric shocks.
■
■
Copyright © Huawei Technologies Co., Ltd. 2013. All rights reserved.

2
Appearance
1 2 3 4 5 6 7 8
1. UPS 1 mains input
circuit breaker
2. UPS 2 mains input circuit
breaker
3. UPS 1 bypass input circuit
breaker
4. UPS 2 bypass input circuit
breaker
5. UPS 1 output circuit
breaker
6. UPS 2 output circuit
breaker
7. Maintenance bypass circuit
breaker
8. Maintenance bypass circuit
breaker cover
1. Maintenance bypass
ports
2. Dual in-line package (DIP)
switch
3. Control area network (CAN)
communications ports
4. Output ports
5. Bypass input ports 6. Mains input ports 7. Output socket group 1 (250 V
AC, 15 A)
8. Output socket group 1
fuses
9. Output socket group 2
fuses
10. Output socket group 2
(250 V AC, 10 A)
11. UPS 1 mains input port 12. UPS 2 mains input port
13. UPS 1 bypass input
port
14. UPS 2 bypass input port 15. UPS 1 output port 16. UPS 2 output port
PDC is short for power distribution cabinet.
UPS is short for uninterruptible power system.
PDU Model PDC-0038V4ACIOA
Applicable UPS UPS2000-G-15KRTL/20KRTL
Weight 15 kg
Dimensions
(H x W x D) 130 mm x 430 mm x 585 mm
PDC-0038V4ACIOA
Front panel (under the cover)
Rear panel
1
2
4 5 6 7
3
89101112
13141516

3
Preparations
Tools
a
Unpacking and Checking
b
Do not move the PDU by holding its mounting brackets, front panel, or terminal cover.When you move it, see the movement
regulations.
No. Item
1 Visually inspect the PDU appearance for shipping damage. If any shipping damage is found, report it to the carrier
immediately.
2 Check the PDU bar code and ensure that it complies with the order. Check against the delivery list that the types of
fittings are complete and correct. If there is any discrepancy, contact your local Huawei office immediately.
< 18 kg (< 40 lb) 18–32 kg (40–70 lb) 32–55 kg (70–120 lb) > 55 kg (> 120 lb)
Device Movement Regulations
c
Wire stripper Polyvinyl chloride
(PVC) insulation tape Heat gun
Cable tie
Protective gloves Insulation gloves
Cotton cloth
Hydraulic pliers
Heat shrink tubing
(Φ6)
Electrician's knife
Multimeter
Phillips screwdriver
(PH2 x 150 mm or
PH3 x 250 mm) Torque screwdriver Crimping tool
Flat-head screwdriver
Get installation tools insulated to prevent electric shocks.

4
Mechanical Installation
Rack-mounting the PDU
a
Install mounting brackets.
Install adjustable guide rails and floating nuts.
1. Install adjustable guide rails when you rack-mount a device. For a 2 U device, install only adjustable guide rails and secure it
with screws. For a 3 U device, install adjustable guide rails and two floating nuts and secure them with screws. The floating nuts
are delivered with the adjustable guide rails.
2. Before you install guide rails, accurately calculate the distance (3 U) between the upper and lower guide rails.
A. Attach the mounting brackets for the adjustable guide rails to mounting bars.
B. Install floating nuts by using a flat-head screwdriver.
Mounting bracket notch
Mounting bar
Floating nut
Flat-head screwdriver
B
A
Adjustable guide rail
This document uses a 19-inch rack as an example. For other racks, see the related UPS quick installation guide.

5
Place the PDU on the guide rails. Secure the PDU to the rack using M6x16TM screws through the holes in the mounting
brackets.
(Optional) 1 U STS
3 U UPS 1
(Optional) 3 U battery
pack 1
3 U PDC-
0038V4ACIOA
3 U UPS 2
(Optional) 3 U battery
pack 2
(Optional) 3 U battery
pack 3
(Optional) 3 U battery
pack 4
Do not move the PDU by holding its mounting brackets, front panel, or terminal cover.When you move it, see the movement
regulations.
Tower-mounting the PDU
b
When you change from rack mounting to tower mounting, rotate the logo anticlockwise 90 degrees.
1. The support base length is adjustable. You can add components to increase the length.
2. Exert force to disassemble components in the reverse directions of assembling.

6
After the PDU is tower-mounted, seal the four screw holes on the top with rubber plugs that are delivered with the PDU.
b
Install two support bases for each group of devices. Place the support bases on the floor, determine the distance (greater
than or equal to 280 mm) between the support bases, place devices on the support bases, and secure them.
Assemble support bases. When you assemble two support bases, align connecting buckles with holes and insert the
buckles vertically, as shown in the following figure.
Support
base
Connecting
buckle
Components
installed
between
support
bases
3 U battery packs
3 U UPSs
3 U PDC-
0038V4ACIOA
Rubber plugs
Cable Installation
Remove the front panel from the PDU and open the circuit breakers.
OFF

7
Loosen screws to remove the busbar cover.
Connect cables.
1. The table lists only the cables directly connected to the PDU. For details about other cables and cable types, see the quick installation
guides for related devices.
2. Configure colors for the cables prepared onsite in accordance with the local regulations.
3. If customers purchase input and output power cables by themselves, use the cables that comply with standards proposed by
Underwriters Laboratories (UL) or International Electrotechnical Commission (IEC).
Device Tool Screw Torque
UPS2000-G-15 kVA M5x0.8p 1.5 N·m
UPS2000-G-20 kVA M5x0.8p 1.5 N·m
PDU M5x0.8p 1.5 N·m
Torque
screwdriver
Torque for tightening power cables
Cable list
Connecting Cables to the PDU for a 1+1 UPS2000-G-15 kVA/20 kVA Parallel System (Three-Phase Input Three-
Phase Output)

8
No. Item Appearance Specifications Remarks
1 PDU AC output
power cable 6 mm² Prepared
onsite
2
PDU bypass
input power
cable
6 mm² Prepared
onsite
3 PDU mains input
power cable 6 mm² Prepared
onsite
4
UPS 1 bypass
input power
cable
N/A
Delivered
with the
PDU
5
UPS 1 mains
input power
cable
N/A
Delivered
with the
PDU
6 UPS 1 AC output
power cable N/A
Delivered
with the
PDU
7
UPS 2 bypass
input power
cable
N/A
Delivered
with the
PDU
8
UPS 2 mains
input power
cable
N/A
Delivered
with the
PDU
9
UPS 2 AC output
power cable N/A
Delivered
with the
PDU
10
Maintenance
bypass port
cable
RVV 4x0.5
Prepared
onsite
(connectors
provided)
11
CAN
communications
port cable
SBYV-100 4x2x0.5 Prepared
onsite

9
3. Power-On Procedure
For details, see the UPS2000-G-(15 kVA–20 kVA) V100R001 Quick Installation Guide.
The preceding figure shows how to connect cables when there are two mains inputs. In the case of one mains input, connect the mains
input power cables to the AC BYPASS INPUT ports (the AC MAINS INPUT ports are not connected).
Cable connection diagram
10
3
MBS is short for maintenance bypass switch.
21
9 6 7 4 8 5
11
Mapping between cable connectors for CAN communications ports.

10
Appendix
Maintenance bypass usage
Procedure to view the alarm:
1 2 3 4 5 6 7
1. UPS 1 mains input circuit
breaker
2. UPS 2 mains input circuit
breaker
3. UPS 1 bypass input circuit breaker 4. UPS 2 bypass input circuit
breaker
5. UPS 1 output circuit
breaker
6. UPS 2 output circuit breaker 7. Maintenance bypass circuit
breaker
8. Maintenance bypass circuit
breaker cover
8
Hot-swap terminals
ON
OFF
The procedure is as follows:
Open the maintenance bypass circuit breaker cover on the PDU front panel.
The UPS generates the "Maint. Breaker close" alarm (the Alarm indicator is on and the buzzer buzzes) and transfers
to bypass mode.
Close the maintenance bypass circuit breaker on the PDU front panel.
Open the UPS input and output circuit breakers on the PDU front panel and the battery switch (if the battery pack
does not have a switch, disconnect the battery pack hot-swap terminal).
Disconnect the hot-swap terminals between the PDU and the UPS.
Use a multimeter to check that the UPS input and output voltages are 0.
You can maintain the UPS.
