Huawei PAC3000S12-T1 PSU User manual

PAC3000S12-T1 PSU
Technical Manual
Issue 1.0
Date 2020-05-18
HUAWEI TECHNOLOGIES CO., LTD.

About This Document
Purpose
This document describes the PAC3000S12-T1 power supply unit (PSU), including its electrical
specications, features, applications, and communication.
The gures provided in this document are for reference only.
Intended Audience
This document is intended for:
● Sales personnel
● Technical support engineers
● System engineers
● Software engineers
● Hardware engineers
Symbol Conventions
The symbols that may be found in this document are dened as follows.
Symbol Description
Indicates a hazard with a high level of risk which, if not
avoided, will result in death or serious injury.
Indicates a hazard with a medium level of risk which, if not
avoided, could result in death or serious injury.
Indicates a hazard with a low level of risk which, if not
avoided, could result in minor or moderate injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.
NOTICE is used to address practices not related to personal
injury.
Supplements the important information in the main text.
NOTE is used to address information not related to personal
injury, equipment damage, and environment deterioration.
PAC3000S12-T1 PSU
Technical Manual About This Document
i

Change History
Changes between document issues are cumulative. The latest document issue contains all the
changes made in earlier issues.
Issue 1.0 (2020-05-18)
This issue is the rst release.
PAC3000S12-T1 PSU
Technical Manual About This Document
ii

Contents
About This Document................................................................................................................. i
1 Product Overview.................................................................................................................... 1
2 Electrical Specications......................................................................................................... 3
2.1 Environmental.......................................................................................................................................................................... 3
2.2 Input.............................................................................................................................................................................................4
2.3 Output......................................................................................................................................................................................... 7
2.4 Eciency.................................................................................................................................................................................. 13
2.5 Protection................................................................................................................................................................................ 14
2.6 Detection Precision............................................................................................................................................................... 19
3 Characteristic Curves............................................................................................................ 21
4 Typical Waveforms................................................................................................................ 22
4.1 Turn-on/Turn-o...................................................................................................................................................................22
4.2 Output Voltage Dynamic Response............................................................................................................................... 23
4.3 Output Voltage Ripple........................................................................................................................................................ 25
5 Energy Saving Feature......................................................................................................... 26
5.1 Active/Standby (Hot Standby) Power Supply............................................................................................................. 26
5.2 Deep Sleep.............................................................................................................................................................................. 29
5.3 Cold Standby Energy Saving............................................................................................................................................. 29
6 Hot Swap Requirements...................................................................................................... 31
7 Internal Cooling Fan............................................................................................................. 32
8 Parallel Operation.................................................................................................................34
9 Control Functions.................................................................................................................. 35
9.1 Timing Requirement............................................................................................................................................................ 35
9.2 ORing-FET................................................................................................................................................................................37
9.3 PSON12V................................................................................................................................................................................. 37
9.4 PRESENT...................................................................................................................................................................................38
9.5 INSTALLED............................................................................................................................................................................... 39
9.6 OPOK.........................................................................................................................................................................................39
9.7 IPOK........................................................................................................................................................................................... 41
9.8 IPOK LINK................................................................................................................................................................................ 42
9.9 IP PRESENT..............................................................................................................................................................................43
9.10 CYC_PWR............................................................................................................................................................................... 44
PAC3000S12-T1 PSU
Technical Manual Contents
iii

9.11 I_MON.................................................................................................................................................................................... 44
9.12 PS_INTERRUPT.....................................................................................................................................................................45
9.13 SMART_ON........................................................................................................................................................................... 45
9.14 EFUSEV................................................................................................................................................................................... 46
10 Communication................................................................................................................... 47
10.1 Hardware Specications...................................................................................................................................................47
10.1.1 I2C Signal........................................................................................................................................................................... 47
10.1.2 I2C Address........................................................................................................................................................................47
10.1.3 SCL and SDA..................................................................................................................................................................... 48
10.1.4 Data Transmission Mode.............................................................................................................................................. 48
10.1.5 I2C Bus Timeout.............................................................................................................................................................. 49
10.2 I2C Protocol.......................................................................................................................................................................... 49
10.2.1 Slave Addressing Method.............................................................................................................................................49
10.2.2 Checksum...........................................................................................................................................................................49
10.2.3 Data Transmission...........................................................................................................................................................49
10.3 Data Format......................................................................................................................................................................... 49
10.4 Commands............................................................................................................................................................................ 50
10.5 Command Descriptions.................................................................................................................................................... 53
10.6 Online Upgrade................................................................................................................................................................... 55
10.7 Black Box Function.............................................................................................................................................................55
10.7.1 Runtime Counter............................................................................................................................................................. 55
10.7.2 Calibration......................................................................................................................................................................... 55
10.7.3 Event Log........................................................................................................................................................................... 55
10.7.4 Log Reading Format.......................................................................................................................................................56
11 Mechanical Overview.........................................................................................................57
11.1 Dimensions........................................................................................................................................................................... 57
11.2 Connectors............................................................................................................................................................................ 58
11.3 LED Indicator........................................................................................................................................................................60
A Appendix................................................................................................................................. 61
PAC3000S12-T1 PSU
Technical Manual Contents
iv

1 Product Overview
Features
●Eciency: ≥ 96% (TA = 25°C; Vin = 230 V
AC; 50% load, without fans)
● Dimensions (L x W x H): 188.00 mm x
68.00 mm x 40.30 mm (7.402 in. x 2.677
in. x 1.587 in.), excluding the edge
connector and handle
● Weight: ≤ 2.0 kg
● Input overvoltage/undervoltage
protection, input overcurrent/short-circuit
protection, and input fault alarms
● Output overvoltage protection, output
overcurrent/short-circuit protection, and
overtemperature protection, and output
fault alarms
● Hot swappable
● I2C for control, programming, and
monitoring
● TUV, CE, NRTL, CCC, BSMI, BIS
certication and CB report available
● IEC 60950-1; EN 60950-1; EN 62368-1;
GB 4943.1, and IEC 62368-1 compliant
● 2002/95/EC compliant; RoHS6, REACH,
WEEE compliant
Product Description
The PAC3000S12-T1 supports an AC input of 90 V
to 264 V and a DC input of 180 V to 300 V. The PSU
provides one output and supports three output
modes, that is, MV12, SV12 and MV6. The rated
output power is 3000 W. The PSU supports hot
swap, current sharing, parallel connection (1+1 or
2+2 mode), and forced-air cooling.
The PSU provides an I2C communication function,
and can report information such as the
manufacturer, model, and version. It provides a
black box and supports online upgrade of primary
side and secondary side. The PSU is designed in
strict accordance with safety requirements and
meets the requirements of information technology
equipment safety standards.
PAC3000S12-T1 PSU
Technical Manual 1 Product Overview
1

Model Naming Convention Applications
1 — Embedded power
2 — AC input
3 — Output power: 3000 W
4 — Single output
5 — Output voltage: 12 V DC
6 — Titanium energy eciency certication
7 — Serial number
Servers
PAC3000S12-T1 PSU
Technical Manual 1 Product Overview
2

2 Electrical Specications
2.1 Environmental
Parameter Minimum Typical Maximum Unit Notes & Conditions
Operating temperature
(TA)
5 25 45 °C ● The PSU can start at
a temperature of –
10°C, and there are
no requirements on
its performance.
● The PSU cannot
start at a
temperature lower
than –10°C.
● Rated input of 230 V
AC or 240 V DC,
maximum power of
3000 W
45 - 60 °C The PSU can work for a
long time with half
load.
When the ambient
temperature is 55°C
and the air volume is
25 CFM, the PSU with
230 V AC power input
can work with 2800 W
load for a long time.
See Figure 2-2
Storage temperature –40 25 85 °C -
Relative humidity 5 - 95 % RH Non-condensing, the
PSU can work normally.
PAC3000S12-T1 PSU
Technical Manual 2 Electrical Specications
3

Parameter Minimum Typical Maximum Unit Notes & Conditions
Altitude –60 - 5000 m When the PSU is not
working, it can be
placed at an altitude of
15,000 m.
Atmospheric pressure 61 - 106 KPa The entire PSU
specication meets the
atmospheric pressure
at an altitude of 4000
m.
Low atmospheric pressure - - - kPa 4000 m altitude low
pressure test
conditions: rated input
220 V AC, T = 45℃,
2800 W load.
When the altitude
ranges from 1800 m to
4000 m, high-
temperature derating
applies and the
temperature decreases
by 1°C for each
additional 220 m.
2.2 Input
Parameter Minimum Typical Maximum Unit Notes & Conditions
AC input voltage range 90 - 264 V -
Rated AC input voltage
range
100 115/230 240 V See Figure 2-2
240HVDC input voltage
range
180 240 300 V The live wire and
neutral wire support
reverse connection
input.
See Figure 2-2
AC input voltage frequency 47 50/60 63 Hz -
THDi (MV12) - - - % Vin = 230 V AC/50 Hz,
No requirement at
below 10% load.
PAC3000S12-T1 PSU
Technical Manual 2 Electrical Specications
4

Parameter Minimum Typical Maximum Unit Notes & Conditions
- - 20 % Vin = 230 V AC/50 Hz,
10–20% load
- - 10 % Vin = 230 V AC/50 Hz,
20–30% load
- - 5 % Vin = 230 V AC/50 Hz, ≥
30% load
THDv - - 10 % When the THDv is less
than 10% the PSU
works properly.
Power factor (MV12) 0.99 - - - TA = 25°C, Vin = 230 V
AC/50 Hz, 100% load
0.98 - - - TA = 25°C, Vin = 230 V
AC/50 Hz, 50% load
0.96 - - - TA = 25°C, Vin = 230 V
AC/50 Hz, 20% load
0.94 - - - TA = 25°C, Vin = 230 V
AC/50 Hz, 10% load
Maximum input current - - 16 A Vin = 220 V AC, full
load
AC input DC bias - - 50 mA Vin = 230 V AC, full
load range (take the
average value of the
parallel test)
Input inrush current - - 30 A Complies with ETSI
300132-3
Standby power (TA = 25°C) - - 1 W The PSU works in deep
sleep mode (parallel
connection condition).
- - 5 W The PSU is in cold
standby state.
- - 10 W The PSU is in hot
standby state.
Harmonic current - - - - Meets the test
requirements of class A
equipment.
See Table 2-1
PAC3000S12-T1 PSU
Technical Manual 2 Electrical Specications
5

Parameter Minimum Typical Maximum Unit Notes & Conditions
Input overcurrent or short
circuit protection
- - - - If an internal fault
occurs in the PSU, the
upstream C32 circuit
breaker is not allowed
to trip.
AC input system - - - - Supports the single-
phase three-wire input,
that is, 220 V AC
single-phase input.
Supports the 110 V AC
dual–live wire input. In
this scenario, the live
and neutral wires must
be connected in series
to circuit breakers. The
cable connection is
shown in Figure 2-1
● The PSU can withstand an input voltage of 318 V AC for 48 hours (non-working state is acceptable).
● The inrush current should meet the requirements in ETSI EN 300 132-3.
● Before delivery, the HVDC test (240 V DC) must be performed on the PSU to ensure that it works properly at
240 V DC.
● The THDi and power factor should be measured when the PSU is supplied with the AC source and the
WT1800 power meter is set to 5.5 kHz.
● When testing the maximum input current, ensure that the voltage of the power input port meets the
requirement and that the output is 3000 W.
Table 2-1 Limits for Class A equipment
Type Harmonic order (n) Maximum permissible harmonic current (A)
Odd harmonics 3 2.30
5 1.14
7 0.77
9 0.40
11 0.33
13 0.21
15 ≤ n ≤ 39
PAC3000S12-T1 PSU
Technical Manual 2 Electrical Specications
6

Type Harmonic order (n) Maximum permissible harmonic current (A)
Even harmonics 2 1.08
4 0.43
6 0.30
8 ≤ n ≤ 40
Figure 2-1 Dual-live-wire input
2.3 Output
Parameter Output Minimum Typical Maximum Unit Notes & Conditions
Number of outputs - - - 1 - There is one output.
The output mode can
be MV12, SV12, or
MV6.
If PSON12V is at high
level, the PSU output
mode is MV6.
If PSON12V is at low
level, and IP PRESENT
is at high level, the
PSU enters MV12
mode.
If PSON12V is at low
level, and IP PRESENT
is at low level, the
PSU enters SV12
mode.
Output power MV12 - - 3000 W Vin = 230–264 V AC,
Vin = 230–300 V DC
PAC3000S12-T1 PSU
Technical Manual 2 Electrical Specications
7

Parameter Output Minimum Typical Maximum Unit Notes & Conditions
2500 - 3000 W Vin = 200–230 V AC,
Vin = 200–230 V DC
The output power
increases linearly
with the input
voltage.
see Figure 2-2
- - 2500 W Vin = 180–200 V AC,
Vin = 180–200 V DC
- - 1300 W Vin = 100–180 V AC
1000 - 1300 W Vin = 90–100 V AC
The output power
increases linearly
with the input
voltage.
See Figure 2-2
SV12 - - 540 W Vin = 90–264 V AC,
Vin = 180–300 V DC
MV6 - - 60 W Vin = 90–264 V AC,
Vin = 180–300 V DC
Output voltage
setpoint
MV12 12.27 12.30 12.33 V TA = 25°C, Vin = 230
V AC; current
setpoint: 5 A
MV6 7.30 7.60 7.90 V TA = 25°C, Vin = 230
V AC; current
setpoint: 5 A
Output voltage
range
MV12 11.70 - 12.60 V From no load to full
load; area I
SV12 11.70 - 12.60 V
MV6 6.30 - 8.20 V
Output current MV12 5 - 244 A Vin = 230–264 V AC,
Vin = 230–300 V DC
PAC3000S12-T1 PSU
Technical Manual 2 Electrical Specications
8

Parameter Output Minimum Typical Maximum Unit Notes & Conditions
5 203.3 A Vin = 200–230 V AC,
Vin = 200–230 V DC
The maximum output
current increases
linearly with the
input voltage.
5 203.3 A Vin = 180–200 V AC,
Vin = 180–200 V DC
5 - 105.7 A Vin = 100–180 V AC
5 - 105.7 A Vin = 90–100 V AC
The maximum output
current increases
linearly with the
input voltage.
See Figure 2-2
SV12 3 - 45 A Vin = 90–264 V AC,
Vin = 180–300 V DC
MV6 0.5 - 10 A Vin = 90–264 V AC,
Vin = 180–300 V DC
Line regulation - –1 1 % -
Output ripple and
noise (peak to
peak)
MV12 - - 120 mV The ripple probe is
connected to a 0.1 μF
ceramic capacitor and
a 10 μF electrolytic
capacitor in parallel.
The oscilloscope
bandwidth is 20 MHz.
A minimum
capacitive load of
5000 μF is added.
Full temperature
range, full input
voltage, minimum
load: greater than 60
W
MV6 - - 360 mV
PAC3000S12-T1 PSU
Technical Manual 2 Electrical Specications
9

Parameter Output Minimum Typical Maximum Unit Notes & Conditions
Dynamic overshoot
amplitude
MV12/
SV12
11.4 - 12.6 V Current change rate:
0.5 A/µs, T = 10 ms;
load: 25%–50%–25%;
50%–75%–50%;
50%–100%–50%.
With the minimum
capacitive load 5000
µF, MV12 acceptance
based on the
maximum power of
2800 W
MV12 11.4 - 12.8 V Current change rate:
2 A/µs, T = 1 ms;
load: 65%–100%–
65%; With the
minimum capacitive
load 5000 µF,
acceptance based on
the maximum power
of 2800 W
MV6 6.00 - 8.20 V Current change rate:
0.5 A/s, T = 10 ms;
0.5–10 A load, with
the minimum
capacitive load 5000
µF
12V transient
impact power
- 11.4 - 12.8 V Current change rate:
0.5 A/µs
1s–10 ms–1s (one
pulse cycle)
load: 65%–130%–
65% (1650–3300 W)
With the capacitive
load 5000 µF
12 V startup
overshoot
- –5 - 5 % The PSU can start at
a temperature of –
10°C, and there are
no requirements on
its performance. The
performance must be
ensured at 5°C to
50°C.
Maximum startup
load
- - - 50 % The startup load does
not exceed 50%.
PAC3000S12-T1 PSU
Technical Manual 2 Electrical Specications
10

Parameter Output Minimum Typical Maximum Unit Notes & Conditions
Temperature
coecient
- –0.02 - 0.02 %/°C Rated input voltage
(Vin = 230 V AC/240
V DC), rated load, full
operating
temperature range
Current sharing
imbalance
- –5 - 5 % ≥ 50% load (rated
load of a single PSU
in parallel scenarios)
- –10 - 10 % 600 W to 50% load
(rated load of a
single PSU in parallel
scenarios)
Capacitive load MV12 5000 - 22000 µF Full voltage, load,
and temperature
ranges
MV6 5000 - 22000 µF
Hot swap MV12 11.4 - 12.8 V ● During hot swap,
the backplane
voltage cannot
exceed the
dynamic
specication
requirements for
the PSU.
● During hot swap,
the 12 V busbar
voltage must be
greater than or
equal to 11.4 V.
(There is no
requirement for
the busbar voltage
within 100 ns)
● Hot swap does not
need to be tested
in the case of the
removal of a PSU
with power on.
● In a parallel
system, perform
the test when the
12 V output of
each PSU carries
the minimum
capacitive load.
PAC3000S12-T1 PSU
Technical Manual 2 Electrical Specications
11

Parameter Output Minimum Typical Maximum Unit Notes & Conditions
MV6 6.00 - 8.20 V
Figure 2-2 Derating curve
● During the isolation process for output overvoltage protection failure, the MV12 busbar voltage should not
be lower than 11.4 V DC.
● The current share bus is used for active current sharing (I-MON).
● Test the current sharing imbalance only at room temperature.
● 1+1 parallel system: When the total load is less than or equal to the rated load of a single PSU, the current
sharing formula is [I – (I1 + I2)/2]/(I1 + I2) x 100%.
When the total load is greater than the rated load of a single PSU, the current sharing formula is
[I – (I1 + I2)/2]/IN x 100%, where IN is the rated current of a single PSU.
● In a 2+2 parallel system, the current sharing formula is as follows on the premise that the 1+1 current
sharing requirements are met:
Max [Max(I, I2, I3, I4) – Ave(I1, I2, I3, I4), Ave(I1, I2, I3, I4) – Min (I1, I2, I3, I4)]/IN x 100%, where IN is the rated
current of a single PSU.
PAC3000S12-T1 PSU
Technical Manual 2 Electrical Specications
12

2.4 Eciency
Output Minimum Typical Maximum Unit Notes & Conditions
Eciency (MV12) 90 - - % Vin = 230 V AC, TA =
25°C, 80 Plus Titanium
eciency–certied,
10% rated load
(without fans)
94 - - % Vin = 230 V AC, TA =
25°C, 80 Plus Titanium
eciency–certied,
20% rated load
(without fans)
96 - - % Vin = 230 V AC, TA =
25°C, 80 Plus Titanium
eciency–certied,
50% rated load
(without fans)
92 - - % Vin = 230 V AC, TA =
25°C, 80 Plus Titanium
eciency–certied,
100% rated load
(without fans)
Eciency (MV12) 88 - - % Vin = 240 V DC, TA =
25°C, 10% rated load
(without fans)
92 - - % Vin = 240 V DC, TA =
25°C, 20% rated load
(without fans)
94 - - % Vin = 240 V DC, TA =
25°C, 50% rated load
(without fans)
90 - - % Vin = 240 V DC, TA =
25°C, 100% rated load
(without fans)
Eciency (MV6) 70 - - % Vin = 230 V AC/240 V
DC, TA = 25°C, MV6/4A
(without fans)
PAC3000S12-T1 PSU
Technical Manual 2 Electrical Specications
13

Output Minimum Typical Maximum Unit Notes & Conditions
75 - - % Vin = 230 V AC/240 V
DC, TA = 25°C, MV6/8A
(without fans)
2.5 Protection
AC input
Parameter Minimum Typical Maximum Unit Notes & Conditions
Input overvoltage
protection threshold
280 - - V Self-recovery
Hysteresis ≥ 5 V
Input overvoltage recovery
threshold
275 - - V
Input undervoltage
protection threshold
- - 85 V Self-recovery
Hysteresis ≥ 5 V
Input undervoltage
recovery threshold
- - 90 V
Input overcurrent/short-
circuit protection
- - - - The damage to a power
component of the PSU
cannot cause the
upstream C32 circuit
breaker to trip.
PFC overvoltage protection - - - - PFC overvoltage does
not damage the bus
capacitor (excluding
damage caused by
input overvoltage).
1. If input overvoltage or undervoltage protection is triggered, both MV12 and MV6 are shut down. The input
voltage threshold that causes MV12 to shut down is the same as the input voltage threshold that causes
MV6 to shut down.
2. If input overvoltage or undervoltage is rectied, both MV12 and MV6 recover. The input voltage threshold
that causes MV12 to recover is the same as the input voltage threshold that causes MV6 to recover.
PAC3000S12-T1 PSU
Technical Manual 2 Electrical Specications
14

240HVDC input
Parameter Minimum Typical Maximum Unit Notes & Conditions
Input overvoltage
protection threshold
310 - - V Self-recovery
Hysteresis ≥ 5 V
Input overvoltage recovery
threshold
305 - - V
Input undervoltage
protection threshold
- - 175 V Self-recovery
Hysteresis ≥ 5 V
Input undervoltage
recovery threshold
- - 180 V
PFC overvoltage protection - - - - PFC overvoltage does
not damage the bus
capacitor (excluding
damage caused by
input overvoltage).
1. If input overvoltage or undervoltage protection is triggered, both MV12 and MV6 are shut down. The input
voltage threshold that causes MV12 to shut down is the same as the input voltage threshold that causes
MV6 to shut down.
2. If input overvoltage or undervoltage is rectied, both MV12 and MV6 recover. The input voltage threshold
that causes MV12 to recover is the same as the input voltage threshold that causes MV6 to recover.
Output
Parameter Output Minimum Typical Maximum Unit Notes &
Conditions
Output overvoltage
protection
MV12 13 - 15 V Latch-o mode
MV6 13 - 15 V Latch-o mode
In the MV6 mode, if
the PSU loop is
detected to be
open, protection is
triggered directly
without having to
reach the MV6
overvoltage
protection
threshold.
SV12 13 - 15 V Latch-o mode
PAC3000S12-T1 PSU
Technical Manual 2 Electrical Specications
15
