Hubbell 58-GC5026 Manual

Replacement Parts
Hubbell Industrial Controls • 4301 Cheyenne Drive, Archdale, NC 27262 • [phone] • FAX [phone]
58-GC5026
Cam S itch
Reversing - 2 Speed - 3 Phase
C5026
November 2003
INTERNAL CONNECTIONS
FORWAR OFF REVERSE
Item Part Name No. Req’d Part Number
A Rotor Assembly 1 D50078001
B Roller Lever Assembly 1 D10288001
C Index Spring 1 D06171002
D Lever Assembly 1 D17811001
E Contact Board - 2 Pole 3 D50542001
NOTE: When ordering replacement parts, give catalog number of control and part number.
FOR.
L1- T1
L2- T2
L3- T3
REV.
L1- T3
L2- T2
L3- T1
(For Engineering Reference Only - Rev. B)
