Hubble Nursery Pal Cloud User manual

USER’S GUIDE
Nursery Pal Cloud, Nursery Pal Cloud Twin
The features described in this user’s guide are subject to modifications without prior notice.
5" Smart HD Baby Monitor with Night Light

Welcome...
to your new Hubble Smart Video Baby
Monitor!
Thank you for purchasing the Smart Video Baby Monitor. Now you can see
and hear your baby sleeping in another room or you can monitor your older
children in their play room. Our Connected Baby Monitor let you see your
baby from the hand-held viewer, or from your smartphone. Watch over and
communicate with your baby from anywhere in the world.
Please keep your original dated sales receipt for your records. For warranty
service of your Hubble product, you will need to provide a copy of your
dated sales receipt to confirm warranty status. Registration is not required
for warranty coverage.
For product related questions, please contact:
Live Chat: hubbleconnected.com
Email: [email protected]
https://hubbleconnected.com/warranty
https://hubbleconnected.com/apps/product-registration
Visit support.hubbleconnected.com to download the User Guide with
instructions, answers to frequently asked questions, and more to help you
get the most from your product.
Inside the Box
• 1 x Parent Unit
• 1 x Baby Unit (Wi-Fi® Camera)
• 1 x Magnetic Mount
• 1 x Power adaptor for Parent Unit
• 1 x Power adaptor for Baby Unit
In multi-camera packs, you will find one or more additional Camera Units
with power adaptors and Magnetic mount units.

Overview of the Parent Unit
1. Display (LCD screen)
2. Parent Unit ON/OFF and
Charging LED
Red when the parent unit is
Charging.
3. Audio Level LEDs (Green, Amber,
Red, Red)
4. Volume Down
Press to decrease Volume level.
5. Volume Up
Press to increase Volume level.
6. VIDEO ON/OFF button
Press to turn the LCD screen ON/
OFF (Note: audio is maintained.)
7. Microphone
8. MENU button
Press to open / close the Menu
options.
9. Navigation button
Move Up/Down/Right/Left menu
options.
Move the image upward/
downward/left/right.
10. OK button
11. TALK button
Press and hold to speak to your
baby.
12. Power button
Press and Hold to turn the Parent
Unit ON/OFF.
13. Antenna
14. RESET button (recessed - use
small pin)
15. Speaker
16. Power Socket
17. Stand
2 3
7
9
8
4 5
10
11
12
6
15
16
17
14
13
1

Parent Unit menu icons
Signal Level (4 Levels)
Night Vision Mode (Video also changes to Black/White).
Talk Mode On.
Indicates the screen off timer is set.
Volume Level Control (8 Levels).
No Baby Unit detected.
Battery Level Indication (4 Levels).
Zoom Level Control (1X, 1.2X, 1.5X, 2X).
Night Light
LCD Brightness Level Control (8 Levels).
Audio Playlist (10 lullabies, 8 audiobooks, Audio Recording and
Volume Control).
Alarm Setting (6h, 4h, 2h, OFF)
On status bar, indicates alarm set, and when ashing, that alarm time
has been reached or missed.
Temperature scale select (°C/°F)
Readings display in WHITE, but turn RED if > 29 °C / 84 °F or < 14 °C
/ 57 °F.
Displays HH °C / °F if >36 °C / 97 °F.
Displays LL °C / °F if < 1 °C / 34 °F.
Camera Control [ - (delete) / + (add) / (view) / (scan) ].
Set Screen Off Timer (Off , 5 mins, 15 mins, 30 mins).
View multiple cameras on screen. Available when you have more than 1
Baby Unit (Camera).
QR code page

Overview of Your Baby Unit
Important guidelines for installing your Digital Video Baby Monitor
• To use your Baby Unit and Parent Unit together, you must be able to establish
a radio link between them, and the range will be affected by environmental
conditions.
• Any large metal object, like a refrigerator, a mirror, a ling cabinet, a metallic door
or reinforced concrete, between the Baby Unit and Parent Unit may block the radio
signal.
• The signal strength may also be reduced by other solid structures, like walls, or by
radio or electrical equipment, such as TVs, computers, cordless or mobile phones,
uorescent lights or dimmer switches.
• Other 2.4GHz products, such as wireless networks (Wi-Fi® routers), Bluetooth™
systems, microwave ovens or other Baby Monitors, may cause interference with
this product, so keep the Baby Monitor at least 5ft (1.5m) away from these types of
product, or switch them off if they appear to be causing interference.
• If the signal is weak, try moving the Parent and/or the Baby Unit to different
positions in the rooms.
1. Light Sensor
2. Camera Lens
3. Infrared LEDs (x 8, for night
vision)
4. High Sense Microphone
5. Magnetic mount
6. Power/Link indicatior
7. PAIR button
8. Night Light
9. Speaker
10. Power Socket
11. Temperature Sensor
1
2
4
5
3
7
6
11
10
9
8

6
Table of contents
Table of contents
1. Safety Instructions ............................................................................... 8
2. Getting Started ................................................................................... 10
2.1 Connecting the Power Supply of the Baby Unit..............................10
2.2 Fixing magnetic mount on the wall .................................................10
2.3 Connecting the Power Supply of the Parent Unit. ..........................11
2.4 Desktop Stand of the Parent Unit.................................................... 11
2.5 Registration (Pairing)........................................................................ 12
3. Using the Baby Monitor ..................................................................... 13
3.1 Setting Up........................................................................................13
3.2 Night Vision Mode...........................................................................13
3.3 Talk Mode.........................................................................................13
3.4 Video ON/OFF.................................................................................13
3.5 Temperature Display (HH °C / °F or LL °C / °F) ...............................13
4. Parent Unit Menu Options ................................................................ 14
4.1 Volume .............................................................................................14
4.2 Brightness ........................................................................................14
4.3 Zoom................................................................................................14
4.4 Audio Playlist ...................................................................................14
4.4.1 Lullaby/Soothing Sounds Playback ....................................... 14
4.4.2 Audio Book Playback ............................................................15
4.4.3 Personal Recording Playback................................................15
4.4.4 Volume Level of Audio Playback...........................................15
4.5 Alarm................................................................................................15
4.6 Camera Control................................................................................16
4.6.1 Add (pair) a camera............................................................... 16
4.6.2 View a camera .......................................................................16
4.6.3 Delete a camera.................................................................... 17
4.6.4 Scan camera ..........................................................................17

7
English
4.7 Temperature.....................................................................................17
4.8 Power Save mode ............................................................................ 18
4.9 View multiple cameras on screen ....................................................18
4.10 Set Night Light ...............................................................................18
5. Wi-Fi® Internet Viewing ..................................................................... 19
5.1 Minimum System Requirements ......................................................19
5.2 Getting started - Connecting Devices .............................................19
5.3 Setup................................................................................................20
5.4 User Account and Camera Setup on Android™ Devices or iPhone®/
iPad® ...............................................................................................20
5.4.1 Power ON and Connect the Camera.................................... 20
5.4.2 Download HubbleClub by Hubble Connected App.............20
5.4.3 Sign up with Hubble on your smart device...........................21
5.4.4 Add the Camera to your account ........................................22
6. Disposal of the Device (environment) ............................................ 25
7. Cleaning ................................................................................................. 25
8. Help.......................................................................................................... 26
9. General Information ........................................................................... 33
10.Technical Specifications .................................................................... 37
Table of contents

8Safety Instructions
1. Safety Instructions
WARNING:
Strangulation Hazard: Children have
STRANGLED on cords. Keep this cord out
of the reach of children (more than 3ft (1m)
away). Never use extension cords with
AC Adaptors. Only use the AC Adaptors
provided.

9
Safety Instructions
English
Wi-Fi®CAMERA UNIT SET UP & USE:
• Choose a location for the Baby Unit that will provide the best view
of your baby in his/her crib.
• Place the Baby Unit on a flat surface, such as a dresser, bureau or
shelf, or mount the Baby Unit on a wall securely using the keyhole
slots in the underside of the stand.
• NEVER place the Baby Unit or cords within the crib.
WARNING
This Baby Monitor is compliant with all relevant standards regarding
electromagnetic fields and is, when handled as described in the User’s
Guide, safe to use. Therefore, always read the instructions in this User’s
Guide carefully before using the device.
• Adult assembly is required. Keep small parts away from children when
assembling.
• This product is not a toy. Do not allow children to play with it.
• This Baby Monitor is not a substitute for responsible adult supervision.
• Keep this User’s Guide for future reference.
• Keep the cords out of reach of children.
• Do not cover the Baby Monitor with a towel or blanket.
• Test this monitor and all its functions so that you are familiar with it prior to
actual use.
• Do not use the Baby Monitor in damp areas or close to water.
• Do not install the Baby Monitor in extreme cold or heat, direct sunlight, or
close to a heat source.
• Only use the chargers and power adaptors provided. Do not use other
chargers or power adaptors as this may damage the device and battery
pack.
• Do not touch the plug contacts with sharp or metal objects.
• Connect the power adaptors to easily accessible electrical sockets.
CAUTION
There is a risk of explosion if the battery is replaced by an incorrect type.
Dispose of used batteries according to their instructions.
Use only the rechargeable battery pack with rating: 3.8V 2100mAh.

10 Getting Started
2. Getting Started
2.1 Connecting the Power Supply of the Baby Unit
• Insert the DC plug of the power
adaptor into the DC socket on the
back of the Baby Unit.
• Connect the other end of the power
adaptor to mains power.
• The baby unit turns on and the power
indicator lights in Green colour.
Note
Only use the supplied power adaptor
(DC5V/1000mA).
2.2 Fixing magnetic mount on the wall
Pair button
• Mark the position of the screw holes on the wall.
• Install wall anchors (Not provided) suitable for the wall type and
mounting screws if needed.
• Fasten the mounting screws (Not provided) on the wall.
• Position the cable behind the base as per image before hooking the
base on the wall.

11
Getting Started
English
2.3 Connecting the Power Supply of the Parent Unit.
• Connect the small plug of the
power adaptor to the parent unit
and the other end to the mains
power. Only use the included
adaptor (5VDC/1000mA).
• Press and hold the POWER button
0to turn ON.
NOTE
• An internal rechargeable battery (Lithium ion battery 2100mAh) allows
portability to the parent unit. The battery provides up to 4 hours operation of
the Parent Unit. We recommend charging the parent unit battery for at least 4
hours before rst use, and when the Parent Unit indicates the battery is low.
• When the battery is low, the battery icon turns RED, and the Parent Unit
will beep every 15 seconds. The battery needs to be recharged; it will take 4
hours to charge fully.
2.4 Desktop Stand of the Parent Unit
• Flip out the stand on the back of the Parent Unit.

12 Getting Started
2.5 Registration (Pairing)
The Baby Unit is pre-registered to your Parent Unit. You do not need to
register it again unless the Baby Unit loses its link with the Parent Unit.
To re-register your Baby Unit, or register a new Baby Unit, follow the
procedure below:
1. Press the button to access the menu.
2. Press the <LEFT button or >RIGHT button until is highlighted, the
- (delete) / + (add) / (view) / (scan) menu will display.
3. Press the +UP button or - DOWN button to select + (add), and press
the button to conrm.
4. Camera 1/ 2/ 3/ 4will display. Press the +UP button or - DOWN
button to select the desired Camera, and press the button to start the
pairing process.
Note: If a camera is currently paired with the Parent Unit, its camera
location (with a * against it) cannot be selected for a new registration.
5. Press and hold the PAIR button on the back of the Baby Unit until
the Parent Unit nds the camera, beeps and PAIR OK appears on the
screen. The video from the camera will then appear.
Note:
A camera can only be registered to one Parent Unit at any one time.

13
Using the Baby Monitor
English
3. Using the Baby Monitor
3.1 Setting Up
Place the Baby Unit in a convenient location (e.g. on a table) and point the
camera lens towards the area you want to monitor. Adjust the angle of the Baby
Unit's camera until you are satised with the image shown on the Parent Unit.
Note:
Do not place the Baby Unit within the baby’s reach! If there is inter-ference
with the picture or sound, try moving the units to different locations, and
ensure they are not close to other electrical equipment.
3.2 Night Vision Mode
The Baby Unit has 8 high-intensity infrared LEDs for picking up clear images
in the dark. When the built-in Light sensor on the top of the Unit detects
a low level of ambient light, the LEDs will automatically activate and the
screen on the Parent Unit will display in black and white. The icon will be
displayed at the top of the screen.
3.3 Talk Mode
Press and hold the TALK button Ton the Parent Unit to talk to your baby
through the Baby Unit’s loudspeaker.
The Ticon will be displayed at the top of the LCD screen.
3.4 Video ON/OFF
Press Display On/Off button to turn the LCD screen on or off, audio will
remain on while screen is off.
3.5 Temperature Display (HH °C / °F or LL °C / °F)
The temperature reading from the temperature sensor at the back of the
Baby Unit will be displayed at the top of the LCD screen. The readings will
turn RED if the temperature goes above 29°C / 84°F or below 14°C / 57°F.
The reading will change to HH °C / °F if the temperature goes above 36°C /
97°F and to LL °C / °F if the temperature goes below 1°C / 34°F.

14 Parent Unit Menu Options
4. Parent Unit Menu Options
4.1 Volume
Press the + or - button to adjust the volume level.
The icon will display and you can select the desired volume from level
0~8. (The default volume level setting is level 4, and level 0 is OFF.)
4.2 Brightness
1. Press the button to access the menu.
2. Press the <LEFT button or >RIGHT button until is highlighted.
3. Press the +UP button or - DOWN button to select the desired
brightness from level 1 ~ 8. (The default brightness is level 4.)
4.3 Zoom
1. Press the button to access the menu.
2. Press the <LEFT button or >RIGHT button until is highlighted
3. Press the +UP button or - DOWN button to select 1X to 2X zoom.
4.4 Audio Playlist
You can playback audio content - Lullabies, Soothing Sounds and Audio
Books on the Baby Unit. The audio content can be downloaded and stored
in the Baby Unit via HubbleClub by Hubble Connected App. You have 10
preloaded lullabies/soothing sounds and 8 audio books in the Baby Unit.
4.4.1 Lullaby/Soothing Sounds Playback
1. Press the button then Scroll Left/Right to select option in the menu.
2. Scroll + Up or - Down to select , and press the button to conrm.
3. Press +UP button or -DOWN button to view the desired Lullaby/
Soothing Sounds. The song names appear on the screen.
4. Press the button to play the selection.

15
Parent Unit Menu Options
English
4.4.2 Audio Book Playback
1. Press the button then Scroll Left/Right to select option in the
menu.
2. Scroll + Up or - Down to select , and press the button to conrm.
3. Press +UP button or -DOWN button to view the desired Audio Book.
The book titles appear on the screen.
4. Press the button to play the selection.
4.4.3 Personal Recording Playback
The unit allows playback of a personal audio recording to soothe your baby,
before playback, please record a personal audio recording via HubbleClub
by Hubble Connected App.
1. Press the button then Scroll Left/Right to select option in the
menu.
2. Scroll + Up or - Down to select >, and press the button to conrm.
3. Press +UP button or -DOWN button to select the desired personal
recording.
4. Press the button to play the selection to soothe your baby.
4.4.4 Volume Level of Audio Playback
1. Press the button then Scroll Left/Right to select option in the
menu.
2. Scroll + Up or - Down to select , and press the button to conrm.
3. Press +UP button or -DOWN button to select the volume level of
audio playback.
4.5 Alarm
1. Press the button to access the menu.
2. Press the <LEFT button or >RIGHT button until is highlighted.
3. Press the +UP button or -DOWN button to select alarm off, after 2
hours, 4 hours or 6 hours.

16 Parent Unit Menu Options
4.6 Camera Control
4.6.1 Add (pair) a camera
1. Press the button to access the menu.
2. Press the <LEFT button or >RIGHT button until is highlighted, the
- (delete) / + (add) / (view) / (scan) menu options will display.
3. Press the +UP button or - DOWN button to select + (add), and press
the button to conrm.
4. Camera 1/ 2/ 3/ 4 will display. Press the +UP button or - DOWN
button to select the desired Camera, and press the button to start
searching for a camera unit.
Note: If a camera is currently paired with the Parent Unit, its camera
location (with a * against it) cannot be selected for a new registration.
5. Press and hold the PAIR button on the back of the Baby Unit until
the Parent Unit nds the camera, beeps and PAIR OK appears on the
screen. The video from the camera will then appear.
Note:
A camera can only be registered to one Parent Unit at any one time.
4.6.2 View a camera
1. Press the button to access the menu.
2. Press the <LEFT button or >RIGHT button until is highlighted, the
- (delete) / + (add) / (view) / (scan) menu will display.
3. Press the +UP button or - DOWN button to select (view), and
press the button to conrm.
4. Camera 1/ 2/ 3/ 4will display, press the +UP button or - DOWN
button to select the desired Camera, and press the button to view the
picture from that camera.
Note:
Only camera locations with a * can be selected.
TIP
You can also press the button repeatedly to select the available camera
options from 1/ 2/ 3/ 4, (scan).

17
Parent Unit Menu Options
English
4.6.3 Delete a camera
1. Press the button to access the menu.
2. Press the <LEFT button or >RIGHT button until is highlighted, the
- (delete) / + (add) / (view) / (scan) menu will display.
3. Press the +UP button or - DOWN button to select - (delete), and
press the button to conrm.
4. Camera 1/ 2/ 3/ 4will display, press the +UP button or - DOWN
button to select the desired Camera, and press the button.
5. Press the +UP button or -DOWN button to select
, then press the
button to delete that registration.
Note:
You are not allowed to delete the camera if there is only one registered
camera.
4.6.4 Scan camera
This function is only available when you have more than 1 Baby Unit
(Camera).
1. Press the button to access the menu.
2. Press the <LEFT button or >RIGHT button until is highlighted, the
- (delete) / + (add) / (view) / (scan) menu will display.
3. Press the +UP button or - DOWN button to select (scan), and
press the button to conrm.
4. The screen will then display images from different registered cameras in
a loop of Camera 1/ 2/ 3/ 4, changing about every 12 seconds.
TIP
You can also press the button repeatedly to select the available camera
options from 1/ 2/ 3/ 4
,
(scan).
4.7 Temperature
1. Press the button to access the menu.
2. Press the <LEFT button or >RIGHT button until is highlighted.
3. Press + UP / - DOWN to select °C or °F.

18 Parent Unit Menu Options
4.8 Power Save mode
1. Press the button to access the menu.
2. Press the <LEFT button or >RIGHT button until Vis highlighted.
3. Press the +UP button or -DOWN button to select auto video off after
5 mins, 15 mins or 30 mins (screen timer active when in battery mode
only).
Note:
The audio is still on, you can press the power key or touch the screen to
resume video feed.
4.9 View multiple cameras on screen
This function is only available when you have more than 1 Baby Unit
(Camera). When the Split Screen function is On, you can view multiple
cameras on the screen.
1. Press the button to access the menu.
2. Press the <LEFT button or >RIGHT button until is highlighted.
3. Press+ UP button or - DOWN button to select Split Screen On /
Off .
4. When the Split Screen function is On, you can press the <LEFT button
/ >RIGHT button / +UP button / -DOWN button to switch between
cameras to hear the audio from the selected camera.
4.10 Set Night Light
1. Press the button and the menu bar will pop up.
2. Press the <LEFT button or >RIGHT button
to scroll to and
press button.
3. Scroll + UP button or - DOWN button to select one of the 7 colours or
auto looping.
4. Press button, there are 3 brightness levels for selection.
5. Press to exit Night Light setup.

19
Wi-Fi® Internet Viewing
English
5. Wi-Fi® Internet Viewing
5.1 Minimum System Requirements
Android™ System
• Version 8.0 or above
iPhone®/iPad® iOS
• Version 12.0 or above
High Speed (Wi-Fi®) Internet
• At least 0.6 Mbps upload bandwidth per camera (you can test your
internet speed on this site: http://www.speedtest.net)
5.2 Getting started - Connecting Devices
How does it work?
Access your
Camera locally
View your Camera from any
compatible device remotely
Wi-Fi RouterWi-Fi®
Camera
Hubble
Service
When a user tries to access the Camera, our Hubble server authenticates
the user’s identity and permits access to the Camera.

20 Wi-Fi® Internet Viewing
5.3 Setup
Connect the Wi-Fi® Camera to the Power Adaptor, then plug into mains power.
The Camera must be within range of the Wi-Fi® router with which you want to
connect. Make sure the password of the router is available for entering during
the in-app setup process.
Status of LED Indication:
- Pair / Setup state: LED is Flashing Green.
- Unconnected state: LED is Flashing Red.
- Connected state: LED is Solid Green.
Note: You can setup via a compatible smartphone or tablet only.
5.4 User Account and Camera Setup on Android™ Devices or
iPhone®/iPad®
What you need
• Wi-Fi® Camera Unit
• Power adaptor for the Camera
• Device with Android™ system version 8.0 and above
• Or iPhone®/iPad® with iOS version 12.0 and above
5.4.1 Power ON and Connect the Camera
• Switch the parent unit off before connect the camera to Wi-Fi®.
• Connect the power adaptor to mains power and insert the plug into the
power socket on the back of the Camera Unit, the unit turns on.
5.4.2 Download HubbleClub by Hubble Connected App
• Scan the QR code with your smart device
and download HubbleClub by Hubble
Connected App from the App Store for iOS
devices or from the Google Play™ Store for
Android™ devices.
• Install HubbleClub by Hubble Connected App
on your device.
