Hunter 23347 User manual

For Your Records and Warranty
Assistance
Model Name: _____________________
Catalog/Model No.: ________________
Serial No.: ________________________
Date Purchased: ___________________
Where Purchased: _________________
For reference also attach your receipt or a
copy of your receipt to the manual. Model 23347
installation and
operation manual
for Hunter
Ceiling Fans
 42832-01•06/04/08

2
42832-01•06/04/08•HunterFanCompany
© 2008 Hunter Fan Company
YournewHunter®ceiling fan is an addition to your home or office that
will provide comfort and performance for many years. is installation
and operation manual gives you complete instructions for installing
and operating your fan.
We are proud of our work. We appreciate the opportunity to supply
you with the best ceiling fan available anywhere in the world.
Before installing your fan, for your records and warranty assistance,
recordinformationfromthecartonandHunternameplatelabel
(located on the top of the fan motor housing).
Cautions and Warnings
•READ THIS ENTIRE MANUAL CAREFULLY BEFORE BEGINNING
INSTALLATION. SAVE THESE INSTRUCTIONS.
•UseonlyHunterreplacementparts.
•Toreducetheriskofpersonalinjury,attachthefandirectlytothe
support structure of the building according to these instructions,
and use only the hardware supplied.
•Toavoidpossibleelectricalshock,beforeinstallingyourfan,
disconnect the power by turning off the circuit breakers to the
outlet box and associated wall switch location. If you cannot lock
the circuit breakers in the off position, securely fasten a prominent
warning device, such as a tag, to the service panel.
•Allwiringmustbeinaccordancewithnationalandlocalelectrical
codesandANSI/NFPA70.Ifyouareunfamiliarwithwiring,usea
qualified electrician.
•Toreducetheriskofpersonalinjury,donotbendtheblade
attachment system when installing, balancing, or cleaning the fan.
Neverinsertforeignobjectsbetweenrotatingfanblades.
•Toreducetheriskofre,electricalshock,ormotordamage,donot
useasolid-statespeedcontrolwiththisfan.UseonlyHunterspeed
controls.
Welcome
Table Of Contents
1•GettingReady......................4
2•InstallingtheHangerBracket . . . . . . . 5
3•AssemblingandHangingtheFan ...6
4•WiringtheFan......................7
5 •InstallingtheMotorHousing .......8
6•AssemblingtheBlades .............9
7•InstallingtheSwitchHousing.......10
8•OperatingandCleaningYourCeiling
Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
9•Troubleshooting..................12

3
42832-01•06/04/08•HunterFanCompany
Mounting and Optional Accessories
Understanding Mounting
Hunter’spatentedmountingsystemprovidesyoumaximumeasein
installing your fan. is fan was designed to be mounted only on flat
ceilings and can be used on ceilings less than 8 feet high.
Considering Optional Accessories
ConsiderusingHunter’soptionalaccessories,includingawall-mounted
orremotespeedcontrol.Toinstallandusetheaccessories,follow
the instructions included with each product. For quiet and optimum
performanceofyourHunterfan,useonlyHunterspeedcontrols.
Low Profile Mounting fits close to the
ceiling, recommended for ceilings less
than 8 feet high
Support Brace
Low Profile
Mounting
Style
Ceiling
OutletBox
CAUTION: Toreducetheriskof
personalinjury,attachthefandirectly
to the support structure of the building
according to these instructions, and use
only the hardware supplied.

4
42832-01•06/04/08•HunterFanCompany
Toinstallaceilingfan,besureyoucandothefollowing:
•Locatetheceilingjoistorothersuitablesupportinceiling.
•Drillholesforandinstallwoodscrews.
•Identifyandconnectelectricalwires.
•Lift40pounds.
Ifyouneedhelpinstallingthefan,yourHunterfandealercandirect
you to a licensed installer or electrician.
Gathering the Tools
You will need the following tools for installing the fan:
•Electricdrillwith9/64”bit
•Standardscrewdriver(magnetictiprecommended)
•Phillips-headscrewdriver(magnetictiprecommended)
•Wrenchorpliers
•Ladder(heightdependentuponinstallationsite)
Checking Your Fan Parts
Carefullyunpackyourfantoavoiddamagetothefanparts.Referto
theincludedPartsGuide.Checkforanyshippingdamagetothemotor
orfanblades.Ifanypartsaremissingordamaged,contactyourHunter
dealerorcallHunterTechnicalSupportDepartmentat888-830-1326.
Preparing the Fan Site
Before you begin installing the fan, follow all the instructions in
thepulloutsheetcalled“PreparingtheFanSite.”Properceilingfan
location and attachment to the building structure are essential for
safety, reliable operation, maximum efficiency, and energy savings.
Installing Multiple Fans?
If you are installing more than
one fan, keep the fan blades and
blade irons (if applicable) in sets,
as they were shipped.
1 • Getting Ready

5
42832-01•06/04/08•HunterFanCompany
CAUTION: Toavoidpossibleelectricalshock,beforeinstallingyourfan,
disconnect the power by turning off the circuit breakers to the outlet box
and associated wall switch location. If you cannot lock the circuit breakers
in the off position, securely fasten a prominent warning device, such as a
tag, to the service panel.
2-1. Drill two pilot holes into the wood support structure through the
outermostholesintheoutletbox.epilotholesshouldbe9/64”
in diameter.
2-2. Partially install two canopy screws in the holes on each end of the
hanger bracket, as shown in the figure to the right.
2-3. Your fan comes with four mounting isolators. Position the
isolators between the hanger bracket and ceiling by inserting the
raised areas on each isolator into the holes in the hanger bracket.
2-4. read the lead wires from the outlet box down through the hole
in the middle of the hanger bracket.
2-5. Aligntheslottedholesinthehangerbracketwiththepilotholes
you drilled in the wood support structure.
Note: e isolators should be flush against the ceiling.
2-6. Placeaatwasheroneachofthetwo3”woodscrewsandpass
the screws through the slotted holes in the hanger bracket into
the pilot holes you drilled.
  Tightenthescrewsintothe9/64”pilotholes;donotuselubricants
on the screws. Do not over tighten.
Step 2-2
Flat Washer
3”WoodScrew
Steps 2-4 – 2-6
Hanger
Bracket
Step 2-3
Canopy Screw
Canopy
Screw
Isolator
2 • Installing the Hanger Bracket

6
42832-01•06/04/08•HunterFanCompany
Step 3-2
#8-32x1”Screw
Green
GroundWire
3-1. Position the square hanger so that the green ground wire attached
to the square faces out of the large opening in the metal bracket.
3-2.Holdingthewiresoutoftheway,liftthemotorassemblyand
place the square hanger into the opening in the ceiling plate.
WARNING: Make sure the square hanger can not rotate in the
metal bracket. Failure to do so could result in the fan falling.
3-3. Install two locking screws through the holes in the side of the
metal bracket to secure the square hanger.
Step 3-1
Motor
Assembly
Square
Hanger
Step 3-3
Locking Screw
Green
GroundWire
3 • Assembling and Hanging the Fan

7
42832-01•06/04/08•HunterFanCompany
All wiring must be in accordance with national and local electrical
codes and ANSI/NFPA 70. If you are unfamiliar with wiring, use a
qualified electrician.
4-1. Disconnect the power by turning off the circuit breakers to the
outlet box and associated wall switch location.
4-2.Toconnectthewires,holdthebaremetalleadstogetherandplacea
wire connector over them, then twist clockwise until tight.
CAUTION: Be sure no bare wire or wire strands are visible after
making connections.
4-3. Connect the wires as follows:
 • egreenorbaregroundwirefromtheceilingtothegreenground
wire from the ceiling plate and the green ground wire from the fan
 • ewhite(common)powerwirefromtheceilingtothewhitewire
from the fan
 • eblackpowerwirefromtheceilingtoboththeblackwirefrom
the fan and the black/white wire from the fan
4-4. Push all wires and wire connectors back through the ceiling plate hole
into the outlet box.
Step 4-3
Wire
Connector
4 •Wiring the Fan

8
42832-01•06/04/08•HunterFanCompany
5-1. Place the fan housing over the motor.
5-2.Alignthekeyholesinthefanhousingwiththetwopartially
installedcanopyscrewsinthehangerbracket.Rotatethefan
housing to situate the screws in the narrow ends of the keyholes.
5-3. Install the two remaining canopy screws into the holes in the fan
housing and into the hanger bracket. Securely tighten all screws.
Canopy
Screw
Step 5-1
Motor
Step 5-3
FanHousing
5 • Installing the Motor Housing

9
42832-01•06/04/08•HunterFanCompany
Hunterfansuseseveralstylesoffanbladeirons(bracketsthatholdthe
blade to the fan).
6-1. Yourfanmayincludebladegrommets.Ifyourfanhasgrommets,
insert them by hand into the holes on the blades.
6-2. Attacheachbladetoabladeironusingthreebladeassembly
screws. If you used grommets, the blades may appear slightly loose
after screws are tightened. is is normal.
6-3. Removetheblademountingscrewsandrubbershippingbumpers
from the motor. Note: Some blade mounting screws are installed
in the motor to secure shipping blocks.
6-4. Foreachblade,insertoneblademountingscrewthroughthe
blade iron, and attach lightly to the fan. Insert the second blade
mounting screw, then securely tighten both mounting screws.
Step 6-1 (Detail)
BladeAssembly
Screws
Usewithgrommet
Usewithoutgrommet
Grommet
Blade
Mounting
Screw
Steps 6-1 – 6-2
Step 6-4
6 • Assembling the Blades

10
42832-01•06/04/08•HunterFanCompany
7-1. Toattachtheupperswitchhousing,partiallyinstalltwohousing
assembly screws into the switch housing mounting plate.
7-2. Feed the upper plug connector through the center opening of the
housing.
7-3. Alignthekeyholeslotsinthehousingwiththehousingassembly
screws.
7-4. Turnthehousingcounterclockwiseuntilthehousingassembly
screws are firmly situated in the narrow end of the keyhole slots.
Installtheremainingscrewintothehousing.Tightenallthree
screws firmly.
CAUTION: Make sure the upper switch housing is securely attached
to the switch housing mounting plate. Failure to properly attach and
tighten all three assembly screws could result in the switch housing
fixture falling.
7-5. Toattachthelowerswitchhousing,connecttheupperplug
connector from the motor to the lower plug connector in the
lower switch housing assembly.
Note: Both plug connectors are polarized and will only fit together
one way. Make sure the connectors are properly aligned before
connecting them. Incorrect connection could cause improper
operation and damage to the product.
7-6. Placethelowerswitchhousingassemblyovertheupperswitch
housing.Alignthesidescrewholesintheupperandlowerswitch
housings.Attachthelowerswitchhousingtotheupperswitch
housing with three housing assembly screws.
Note:YoucancustomizeyourHunterfanwithanumberofaccessory
light kits.
Steps 7-1 – 7-4
Housing
Assembly
Screw
Upper
Switch
Housing
Housing
Assembly
Screw
Lower
Switch
Housing
Steps 7-5 – 7-6
Plug
Connector
7 • Installing the Switch Housing

11
42832-01•06/04/08•HunterFanCompany
In warm weather, use
downward air flow pattern
In cold weather, use upward
air flow pattern
8-1. Turnonelectricalpowertothefan.
8-2. e fan pull chain controls power to the fan. e pull chain has
foursettingsinsequence:High,Medium,LowandO.
• Pullthechainslowlytochangesettings.
• Releaseslowlytopreventthechainfromrecoilingintothe
blades.
• echainusesabreakawayconnectorthatseparatesifthe
chainisjerked.Ifthishappens,simplyreinsertthechaininto
the connector.
8-3. Ceiling fans work best by blowing air downward (counterclockwise
blade rotation) in warm weather to cool the room with a direct
breeze. In winter, having the fan draw air upward (clockwise blade
rotation) will distribute the warmer air trapped at the ceiling
around the room without causing a draft.
8-4. For cleaning finishes, use a soft brush or lint-free cloth to prevent
scratching.Avacuumcleanerbrushnozzlecanremoveheavier
dust.Removesurfacesmudgesoraccumulateddirtanddustusing
a mild detergent and a slightly dampened cloth. You may use
an artistic agent, but never abrasive cleaning agents as they will
damage the finish.
8-5. Clean wood finish blades with a furniture polishing cloth.
Occasionally,applyalightcoatoffurniturepolishforadded
protection and beauty. Clean painted and high-gloss blades in the
same manner as the fan finish.
To Change Airflow Direction
Turnthefanoandletitcometoacomplete
stop. Slide the reversing switch on the fan to the
oppositeposition.Restartfan.
Reversing
Switch
8 • Operating and Cleaning Your Ceiling Fan

12
42832-01•06/04/08•HunterFanCompany
Problem: Nothing happens; fan does not move.
1.Turnpoweron,replacefuse,orresetbreaker.
2. Loosen canopy, check all connections according to the wiring the
fan section.
3. Check the plug connection in the switch housing.
4. Push motor reversing switch firmly left or right to ensure that the
switch is engaged.
5. Pull the pull chain to ensure it is on.
6.Removetheshippingbumpers.
Problem: Noisy operation.
1.Tightenthebladebracketscrewsuntilsnug.
2.Tightenthebladescrewsuntilsnug.
3. Check to see if the blade is cracked. If so, replace all the blades.
4. Change to an approved speed control.
5. Be sure that the glass is secure.
6.Checkandtightenthescrewsintheswitchhousingmounting
plate and in the upper and lower switch housing.
Problem: Excessive wobbling.
1. If your fan wobbles when operating, use the enclosed balancing kit
and instructions to balance the fan.
2.Tightenallbladeand/orbladeironscrews.
If you need parts or service assistance, please call
888-830-1326orvisitusatourWebsiteat
http://www.hunterfan.com.
HunterFanCompany
2500FriscoAvenue
Memphis,Tennessee38114
9 • Troubleshooting
