Hunter FSQ-MF06I-E User manual

Electric Fan
English
Owner’s Guide
Model
FSQ-MF06I-E
61803-01
20150328
Electric FanElectric Fan

2
CONTENTS
........................................................................ 3
............................................................................... 3
Safety Precautions ........................................................................ 4
Operating Instructions .................................................................. 6
Care and Maintenance................................................................. 7
Technical Support......................................................................... 7
FCC Warning ................................................................................ 8
61803-01 20150328
Parts Identification
Specifications
Fused Plug................................................................................... 5
Warranty..................................................................................... 9
Products .....................................................................................10

3
SPECIFICATIONS
PARTS IDENTIFICATION
(Control Panel)
61803-01 20150328
INPUT VOLTAGE
POWER RATING 45W
FAN BLADE SIZE 6 in.
120V / 60Hz

4
SAFETY PRECAUTIONS
61803-01 20150328
READ AND SAVE THESE INSTRUCTIONS! Read this entire manual
before operating this product. When using electrical appliances, basic safety
precautions should always be followed to reduce the risk of fire, electric shock
and personal injury, including the following:
2. To protect against electric shock, do not place fan on windowsills, immerse unit,
plug or cord in water. Do not spray with liquid or use near water sources.
3. This product is intended for residential use ONLY. DO NOT use outdoors.
4. This appliance has a polarized plug (one blade is wider than the other).
See figure 1. To reduce the risk of shock, this plug is intended to fit in a
polarized outlet one way only. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician. DO NOT
attempt to bypass this safety feature.
5. WARNING: To reduce the risk of fire or electric shock, do not use this fan
with any solid-state speed control device.
6. This product employs overload protection (fuse). A blown fuse indicates an
overload or short-circuit situation. If the fuse blows, unplug the product from the
outlet. Replace the fuse as per the user servicing instructions (follow product
marking for proper fuse rating) and check the product. If the replacement fuse
blows, a short-circuit may be present and the product should be discarded or
returned to an authorized service facility for examination and/or repair.
7. Close supervision is necessary when any appliance is used by or near children.
8. Turn the fan OFF and unplug from the outlet when not in use, before moving
and before cleaning.
10. DO NOT operate any fan with a damaged cord or plug. Discard fan or
return to an authorized service facility for examination and/or repair.
11. DO NOT run cord under carpeting. Do not cover cord with throw rugs,
runners, or similar coverings. Do not route cord under furniture or appliances.
Arrange cord away from traffic area and where it will not be tripped over.
13. Always use the fan on a dry leveled surface.
15. DO NOT place or operate the fan near open flame or sources of heat (stove,
fireplace, etc.).
1. Use this fan only as described in this manual. Improper usage may
cause fire, electric shock or personal injury.
14. DO NOT operate the fan in the presence of explosive and/or flammable fumes.
9. To unplug the fan, first turn the unit OFF, grip the plug and pull from outlet.
Never pull or tug by the cord to remove from the outlet.
16. The use of unauthorized attachments is not recommended. This may cause
fire, electrical shock, or injury.
12. DO NOT operate the fan if fan housing is damaged.

5
61803-01 20150328
17. This unit is designed for use on a 120V/60Hz outlet only.
18. DO NOT insert fingers or any objects through the grill during use. Avoid
contact with moving parts.
WARNING:
1. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the
appliance.
20. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid hazard.
21. The plastic feet on this product may interact with wood and cause damage to
furniture. DO NOT place on fine wood furniture.
19. A loose fit between the AC outlet and plug may cause overheating and distortion
of the plug. If it occurs, contact a qualified electrician to replace worn outlet.
FUSED PLUG
Figure 2.
This plug is a safety feature. It contains a safety
device (fuse) that should not be removed. Discard
the product if the attachment plug is damaged. To
reduce the risk of re, electric shock and personal
injury, DO NOT remove, replace, repair or tamper
with the originally supplied plug. If the fan does
not function properly, it may be due to the safety
device incorporated in this plug.
If the fuse fails, it is generally due to a short circuit
or circuit overload. Replace the fuse as per the
instructions below. If the replacement fuse fails,
immediately unplug the unit and contact our
technical support department for assistance.
Fuse Replacement:
User Servicing Instructions:
2. Slide the door on top of the plug towards the
blades. Figure 2.
1. To replace the fuse, first turn the unit off and
unplug it from the wall. Locate the door on top
of the plug. Figure 1.
Figure 1.

6
61803-01 20150328
3. Carefully remove the fuse from the clips holding
it on the top and bottom. Figure 3.
Warning! Electrical Hazard! Only replace
with a fuse type and rating matching what was
removed from the product. If the product fails a
second time, immediately unplug it and contact our
technical support at 1-888-880-3267.
OPERATING INSTRUCTIONS
Figure 3.
4. Gently push the fuse back into the pins that will
hold it in place.
Note: If the fuse is not seated properly, the unit
will not function.
5. Slide the door back over the fuse box in the plug.
6. Plug the fan back in and resume use.
Functions of the Keys and Symbols
Fan Operation
• Plug cord into any standard
120 volt AC outlet.
• You can operate the appliance
by pressing the buttons on the
control panel. Contol Panel
Osc
(L/R)
Osc
(U/D)
Left/Right Up/Down
Speed Button:
Select the desired speed by pressing the Speed button which will adjust
the fan speed to Speed 1, 2, 3, Turbo and back to 1 as a sequence.
The LED will light up accordingly to show the speed selected.
Power Button:
Press the button once, the fan will start at Speed 1 (Low speed). The
LED "1" will light up. Press again to switch the fan off.

Left/Right OSC Button:
To activate the Left/Right Oscillation feature, press the button once.
Press again to cancel.
Timer Button:
This fan is equipped with an automatic shut off feature. To select
desired length of operation, press the Timer button a number of
times until the LED indicates the desired operation time: 1-hour,
2-hour or 4-hour.
7
61803-01 20150328
Up/Down OSC Button:
To activate the Up/Down Oscillation feature, press the button once.
Press again to cancel.
Up/Down
CARE AND MAINTENANCE
TECHNICAL SUPPORT
If you have any additional questions or problems with your Hunter Portable Fan,
please call:
We open 24 hours a day, 7 days a week. You may also reach us online at
www.HunterHomeComfort.com.
An electronic copy of this user manual can also be obtained online at
www.HunterHomeComfort.com.
USA: 1-888-880-3267
• Always unplug the appliance before cleaning.
• Do not immerse the fan in water or other liquids and never allow water to drip
onto the motor housing.
• Use only a soft, damp cloth to gently wipe the outer surfaces of the fan.
• Do not use gasoline, paint thinner or any other corrosive cleaning solutions.
• If the fan will not be in use for an extended period of time, you may leave the
fan assembled. Cover to protect from dust. Store in a cool, dry place.
• To clean between grills, we recommend using a pipe cleaner, flexible dust
wand, vacuum cleaner or compressed air to gently remove dust.
Left/Right

8
61803-01 20150328
FCC WARNING
FCC WARNING:
Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
NOTE :
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help

9
61803-01 20150328
If your Hunter Portable Fan motor fails at any time within one year after the date
of sale to you due to a defect in material or workmanship, labor to repair the
defect will be provided free of charge at our nearest service center or our Service
Department in Marietta, Georgia. You will be responsible for labor costs after
this one-year period. The foregoing limited warranty applies only to the motor
itself, and does not apply to electronic controls such as remote controls, remote
control receivers or transmitters used in conjunction with the motor. These
electronic control items are included in the one year limited warranty below.
If any part of your Hunter Portable Fan other than the motor fails at any time
within one year after the date of sale to you due to a defect in material or
workmanship, we will repair or, at our option, replace the defective part free
of charge for parts and labor performed at our nearest service center or at our
Service Department in Marietta, Georgia.
This warranty is voided if your Hunter Fan is not purchased and used in the USA.
This warranty excludes and does not cover defects, malfunctions or failures of
any Hunter Portable fan which were caused by repairs by persons not authorized
by us, use of parts or accessories not authorized by us, mishandling, improper
installation, modifications, or damage to the Hunter Portable fan while in your
possession, or unreasonable use, including failure to provide reasonable and
necessary maintenance.
To obtain servicing, contact the nearest Hunter authorized service center or the
Hunter Home Comfort Service Department, 1831-A West Oak Parkway,
Hunter Home Comfort makes the following limited warranty to the user or
consumer purchaser of this Hunter Portable fan:
IF THE USER OR CONSUMER PURCHASER CEASES TO OWN THE FAN,
THIS WARRANTY AND ANY IMPLIED WARRANTY WHICH THEN REMAINS
IN EFFECT, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE VOIDED.
NO WARRANTY, EXPRESSED OR IMPLIED, INCLUDING ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IS MADE IN
RESPECT TO THE GLASS GLOBES OR LIGHT BULBS OR THE FINISH ON ANY
METAL PORTION OF THE FAN. THIS WARRANTY IS IN LIEU OF ALL OTHER
EXPRESS WARRANTIES. THE DURATION OF ANY IMPLIED WARRANTY,
INCLUDING, BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IN RESPECT
TO ANY HUNTER FAN MOTOR OR OTHER FAN PART, IS EXPRESSLY LIMITED
TO THE PERIOD OF THE EXPRESS WARRANTY SET FORTH ABOVE FOR SUCH
MOTORS AND OTHER PARTS.
WARRANTY

10
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES SO THE ABOVE LIMITATION MAY NOT APPLY TO
YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO
HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
PRODUCTS
1831-A West Oak Parkway, Marietta, GA 30062
Hunter is a trademark of the Hunter Fan Company and
is used under license to Hunter Home Comfort.
Printed in China
Marietta, GA 30062. Please contact us before shipping your fan to us. If we
authorize you to ship it to us, you will be responsible for all insurance and freight
or other transportation charges to our factory service center. We will return your
Hunter Fan freight prepaid. Your portable fan should be properly packed to avoid
damage in transit since we will not be responsible for any such damage. Proof of
purchase is required when requesting warranty service. The purchaser must present
sales receipt or other document that establishes proof of purchase.
IN NO EVENT SHALL HUNTER HOME COMFORT BE LIABLE FOR CONSEQUENTIAL
OR INCIDENTAL DAMAGES.
www.HunterHomeComfort.com
To learn more about Hunter Home Comfort products, please see our Web page at:
61803-01 20150328
