INSTALLATION INSTRUCTIONS FOR
HUNTER ORIGINAL®CEILING FANS
! WARNINGS !
• To avoid possible electrical shock, before wir-
ing fan, disconnect power by turning off the cir-
cuit breakers both to the outlet box and to its
associated wall switch location. If you cannot
lock the circuit breakers in the “OFF” position,
securely fasten a prominent warning device,
such as a tag, to the service panel.
• All wiring must be in accordance with national
and local electrical codes. If you are unfamiliar
with wiring, you should use a qualified electri-
cian.
• To reduce the risk of personal injury, install the
fan to the building structure according to these
instructions and use only the hardware sup-
plied.
IMPORTANT!
READ AND SAVE THESE
INSTRUCTIONS!
! CAUTIONS !
• NEVER REST THE FAN ON THE SWITCH HOUS-
ING. As you prepare the fan for installation, rest
the motor in the liner in which it was packed.
• Be sure to put full contents of the oil tube into
the fan according to the instructions.
• If this fan is used as a replacement for an Origi-
nal®Old-Tyme non-reversible fan, it must be in-
stalled per the instructions included with this
fan. Failure to do so could result in the fan fall-
ing. DO NOT HANG THIS FAN ON A SINGLE
“J” HOOK.
• To reduce the risk of noise and to ensure proper
fan operation, do not use a solid-state speed
control with this fan. Use Hunter speed con-
trols for Hunter Original®ceiling fans only.
• Do not use an abrasive cleaner on the fan. A
mild detergent will clean and restore most units
to their original beauty.
Installing Your Hunter®Ceiling
Fan
Note To Installers: Please leave this manual with
the home owner.
Tools needed:
• Pliers • 3/8” Socket Wrench
• Flat blade screwdriver • Phillips screwdriver
• Electric drill • 11/64” drill bit
• 4” x 1-1/2” standard octagon electrical box
Step 1: Pre-Installation
1. Select the installation site: Normally this is
near the center of the room, often replacing a light
fixture. Make certain that ample clearance is left
for the rotating fan blades. For maximum effi-
ciency, no obstructions (walls, posts, etc.) should be
within 24” of the tips of the blades. See Figure 1.
NOTE: Mounting should also meet the precautions listed
in Step 3.
Read this entire manual thoroughly before begin-
ning installation.
24”
Minimum
Clearance
7’ Minimum
Clearance To
Floor
8’Minimum
to Ceiling
Figure 1
2. Fan mounting height: Your Hunter fan
comes with the proper hardware to hang the fan
from a standard 8 foot ceiling so that the fan blades
will be 12” from the ceiling and approximately 7
feet from the floor. See Figure 1.
NOTE: On vaulted ceilings, up to 45° pitch, you must
use the Hunter Vaulted Ceiling Mounting Kit.

© 2003 HUNTER FAN CO. 41556-01 8/08/03
2
Step 2: Inspect the Fan
1. Unpack the fan carefully to avoid any damage to components.
Figure 2
! CAUTION !
• Never lift the motor by the wires. Let the motor rest in the carton liner for protection.
2. Check the sack parts. See Figure 2.
Blade Assembly
Screw
Armature Screw
Pull Chain
1/4-10 Lag Screw
Mounting Bracket
Pipe Nipple
Oil Tube
Motor / Housing Assembly
Blade Set
Blade Iron Set
Hardware
(Drawn to Scale)
Fan Parts
(Not Drawn to Scale)
Canopy
Rubber Bushing / Pin
Hanger Bracket
Assembly
Canopy
Insert
Wire Nut
Canopy Screw
Mounting Isolator

3
41556-01 8/08/03 © 2003 HUNTER FAN CO.
Step 3: Installation of Ceiling Mounting
Hardware
2” x 4” Wood Brace
Outlet Box
Ceiling
Joist
Ceiling
M4 Wood Screw &
Washer (2) Required
Figure 3
2. Drill two (2) 1/4” diameter holes 2-9/16”
apart through the back of the outlet box into the
cross brace. There may be two holes at the correct
spacing, but they will probably have to be enlarged.
3. Use the two (2) bracket screws to secure the
hanger bracket and canopy plate to the joist as
shown in Figure 4. Install the rubber bumpers into
the canopy plate and the rubber bushing in the
hanger bracket before assembling the parts to the
ceiling joist.
Rubber
Bumpers
Figure 4
Step 4: Hanging the Fan
• When inspecting or preparing the installation
site where wiring is available, to avoid possible
electrical shock, disconnect power by turning off the
circuit breakers both to the outlet box and to its
associated wall switch location. If you cannot lock
the circuit breakers in the off position, securely
fasten a prominent warning device, such as a tag, to
the service panel.
• All wiring must be in accordance with na-
tional and local electrical codes. If you are unfamil-
iar with wiring, you should use a qualified electri-
cian.
• Do not mount directly to an unsupported
ceiling or to an electrical outlet box.
• The wood joist chosen for mounting the fan
must be sound and of sufficient size. In no case
should it be smaller than standard 2”x4” lumber.
1. Secure a metallic outlet box 4” x 1-1/2” or
4” x 1/2” deep to a 2” x 4” cross brace between two
ceiling joists as shown in Figure 3. The outletbox
must be recessed in the ceiling by 1/16” minimum.
Secure the outlet box to the cross brace by drilling
two (2) pilot holes no larger than the minor diameter
of the woodscrews (5/64”) and use two #8 x 1-1/2”
woodscrews and washers. Use the innermost holes
for securing the box. Orient the box so the outer-
most holes are aligned with the 2” x 4” brace. The
outermost holes will be use in Step 3 sub-step 2.
! CAUTION !
• Your Hunter ceiling fan weighs up to 50 lbs. The
following precautions must be taken for safety,
and to ensure that your fan is securely mounted
to the ceiling.
! CAUTION !
• Do not use a lubricant on the screws.
! CAUTION !
• Do not use a lubricant on the screws.
! CAUTIONS !
• Be sure to tighten the pipe nipple shown in Fig-
ure 2 into the fan, tighten the hanger bracket
onto the pipe, and tighten the two set screws
as described in sub-step 2 to prevent the fan
from falling.
• Your fan may weigh up to 50 lbs. All of the fol-
lowing steps must be followed in order to en-
sure a secure mounting. Perform sub-steps 1-
4 with the motor resting in the liner for protec-
tion.
1. Take the hanger bracket from the sack parts
and locate the pipe nipple (See Figure 2.). Feed the
wires from the top of your motor through the pipe.
2. Back out the set screw in the neck of the
motor housing and the hanger bracket so the pipe
can be screwed in. Screw the pipe into the fan until
tight (at least 4-1/2 turns). Feed the wire through
the canopy and the canopy insert and let the canopy
rest on the neck of the motor. Slide the canopy
insert over the pipe.Feed the wire through the
hanger bracket and screw the hanger bracket onto
the pipe until tight (at least 3 turns). Then use pliers
to tighten both the hanger bracket and the pipe
together. Tighten the set screw in the motor housing
with pliers. Securely tighten the set screw in the
hanger bracket. See Figure 5.

© 2003 HUNTER FAN CO. 41556-01 8/08/03
4
Set
Screws
Figure 5
3. Be sure the pin is centered in the rubber
bushing. See Figures 6 and 7.
4. Lift the fan by the motor housing and hook
the hanger bracket onto the pin in the rubber bush-
ing. Make sure both ends of the pin are outside
the hanger bracket. See Figure 7.
Figure 6
Figure 7
Bushing Pin
Step 5: Wiring Instructions
NOTE: Before you do the final wiring, you should decide
Figure 8
a lighting accessory, connect the black wire with the
white stripe to the wall switch lead, following the wiring
instructions included with the accessory. The wall
switch must be a listed general-use switch.
4. After making the wire connections, the wires
! WARNING !
• Failure to perform these steps in the correct
order may result in the fan falling.
! WARNING !
• To avoid possible electrical shock, before wir-
ing fan, disconnect power by turning off the cir-
cuit breakers both to the outlet box and to its
associated wall switch location. If you cannot
lock the circuit breakers in the “OFF” position,
securely fasten a prominent warning device,
such as a tag, to the service panel.
how you want to control your fan - with a pull cord, a
wall switch or a speed control. At this point, you should
also decide if you want to add a light adapter kit.
Separate wiring instructions for Hunter accessories are
included in the accessory packages.
• All wiring must be in accordance with na-
tional and local electrical codes. If you are unfamil-
iar with wiring, you should use a qualified electri-
cian.
1. Connect the black electrical supply lead to
the black motor lead and the black with white stripe
motor lead. (See Note below.)
2. Connect the white electrical supply lead to
the white motor lead.
3. Connect the ground wire to the green screw
on the side of the hanger bracket. See Figure 8.
NOTE: If a separate wall switch will be used to control
! CAUTION !
• No bare wires or wire strands should be vis-
ible after making connections.
should be spread apart with the white and green
wires on one side of the outlet box, and the black
and black with white stripe wires on the other side
of the box.
5. The splices should be turned upward and
pushed carefully up into the outlet box.
Canopy
Insert
Canopy

5
41556-01 8/08/03 © 2003 HUNTER FAN CO.
Step 6: Lubrication
1. Your fan has been shipped without oil in the
motor. A tube of high grade SAE 10 non-detergent
oil is packed in the sack parts. All of the oil in the
tube must be put into the fan.
2. Unscrew the oil hole screw on the side of
the switch housing. See Figure 9.
Canopy
Screws
Figure 11
Canopy Installation
1. Lift the canopy off the neck of the motor.
2. Slide the canopy and canopy insert up until
the three holes in the side of the canopy can be
aligned with the three threaded holes in the canopy
plate.
3. Insert and tighten the three screws that hold
the canopy in place. See Figure 11.
Oil Hole Screw
Figure 9
Figure 10
Step 7: Fan Blade Assembly and
Installation
3. Cut the tip off the tube, tilt the fan motor as
shown and place the tube into the oil hole of the
switch housing. See Figure 10.
4. Slowly put oil into the fan. All of the oil in the
tube must be put into the fan.
5. Reinstall the oil hole screw securely before
moving the fan from the current (tilited) position to
prevent oil from spilling from the oil hole..
This Lubrication System does not normally “use
up” or require the addition of extra oil once the oil
reservoir has been filled to the correct level. This
unique lubrication system is one reason your Original
Hunter Ceiling Fan will last a lifetime.
1. Attach the wood blades to the blade brackets
using three screws for each blade. See Figure 12.
! CAUTION !
• Do not turn the fan on until lubrication has been
added. To operate the fan without oil or with
low oil will void your warranty.
! WARNINGS !
• To reduce the rist of personal injury, do not bend
the blade brackets when installing the blade
brackets, balancing the blades, or cleaning the
fan.
• Do not insert foreign objects in between rotat-
ing fan blades.
Figure 12
2. If your blades have large holes, you must first
insert the rubber grommets into the holes. See Figure
13.
3. Make sure that all screws are tight to pre-
vent vibration or wobbling. A cavity in the
styrofoam packaging has been provided to nest the
parts in during assembly to assure correct alignment
of parts.
Canopy
Canopy
Insert

© 2003 HUNTER FAN CO. 41556-01 8/08/03
6
NOTE: Grommets are usually assembled by hand. If
you use a tool, make certain you do not damage the
grommet or blade when inserting the grommets.
4. With some fans you have an option to install
Figure 15
four or five blades. For five blades, mount to the outer
row of holes on the motor. For four blades, use the
inner row. See Figure 14.
Figure 14
5. To install the blades to the motor, insert the
blade iron screw through the hole in the blade iron.
Use a screwdriver to hold in place.
6. Fasten the screw onto the motor, but do not
overtighten. See Figure 15.
7. Line up the other hole on the motor and fasten
the second screw.
NOTE: Before tightening the screws, make sure they are
not cross-threaded in the mounting holes.
8. Tighten both screws securely. Repeat for the
remaining blades.
3. Reversing your fan is controlled by a small
switch located on the switch housing. See Figure
17.
NOTE: Ceiling fans are usually adjusted once in the fall
and again in the spring to blow upward in the winter
and downward in the summer. You may run them in
either direction at anytime, however, as you prefer.
Experiment as you like to obtain maximum comfort from
your fan.
Figure 16
Figure 17
G
rommet
Fan
Blade
Figure 13
! CAUTION !
• Do not attempt to run the fan until all screws
have been tightened securely.
9. A blade balancing kit has been provided
with your fan. Should the fan wobble in operation,
you may use this kit to correct the balance per the
instructions supplied with the kit.
Step 8: Operation of Your Hunter Fan
1. The operation of your fan is controlled with
a pull-chain switch, which has four (4) positions:
Off -- High -- Medium -- Low. Pull the chain gently
to obtain the speed you desire.
2. The Break-A-Way Connector is designed to
separate from the chain at a predetermined force. If
this separation occurs, simply reinsert the connector.
It can be used again and again. See Figure 16.

7
41556-01 8/08/03 © 2003 HUNTER FAN CO.
Lubrication
Once properly installed, your fan needs little
attention, beyond checking the oil level. The oil is
checked by unscrewing and removing the oil hole
screw. If oil comes out of the hole, the oil level is
within proper levels.
If no oil comes out, complete the following
steps:
• Reinstall the oil hole screw.
• Remove one blade iron/blade assembly from
the motor housing by uninstalling the two blade
armature screws.
• Rotate the motor so that the open area where
the blade iron/blade assembly you just removed is
directly above the oil hole screw. This is done so
that there is enough room to properly position the
tube of oil when refilling.
• Complete the steps in STEP 6: LUBRICA-
TION to properly complete adding oil into the
motor.
Cleaning
Take care when cleaning your fan. Never use
an abrasive cleanser or brass polish. Use a damp
cloth or sponge. Do not drip water or soap into the
motor.
Blades should be wiped clean periodically to
prevent dust buildup. Be careful not to bend the
blade irons.
If blades are cracked or blade irons bent, do not
attempt to repair them. Order replacement parts
from your Hunter dealer.
Installation on Pitched Ceilings
Your Hunter Fan can be mounted onto a
pitched ceiling (up to 34 degrees) using the same
method as mounting on a flat ceiling, except that the
hanger bracket and bushing must be aligned so they
are pointing up the sloped of the ceiling. You will
also need an extension pipe, which is available from
your Hunter dealer.
Care and Maintenance
Figure 18
Hanger Bracket
(Furnished with Fan)
Expansion
Shield Anchor
Set Flush with
Ceiling
(Anchor Not
Furnished)
Concrete
Ceiling
Refer to Figure 18 for the steps below.
• For concrete mounting, the drilled hole must be
recommended by the manufacturer of the anchor and it
must be drilled at least 1/2” deeper than the length of
the anchor.
NOTE: The drilled hole is usually marked on the anchor.
! CAUTION !
• Before performing any maintenance on the fan,
disconnect the power to the fan.
! CAUTION !
• Your Hunter ceiling fan weighs up to 50 lbs. The
following precautions must be taken for safety,
and to ensure that your fan is securely mounted
to the ceiling.
• The holes must be made with a suitable
carbide-tipped masonry drill bit.
• The anchors must be new and unused.
• The concrete ceiling must be sound and free
of cracks or voids in the vicinity of the mounting
holes.
• The anchors must be set in flush with the
surface of the concrete.
• The bracket screws must never be backed
out. If the bracket screws can be turned easily (by
hand), do not hang the fan.
Installation
1. Drill holes 2” deep in concrete ceiling to
receive 1/4” x 1-1/2” expansion shield anchor,
“Rawl No. 1055” or equal. (Not furnished.)
2. Install shield in holes, observing all cautions
above.
3. Proceed with the installation of the fan per
the basic installation instructions.
Installation in Concrete Ceilings

© 2003 HUNTER FAN CO. 41556-01 8/08/03
8
TROUBLESHOOTING
Nothing happens; fan does not move.
Noisy operation.
Excessive Wobbling
1. Power turned off, fuse blown, or cir-
cuit breaker tripped.
2. Loose wire connections or wrong
connections.
3. Motor reversing switch not engaged.
4. Pull chain switch not “on.”
5. No oil or low oil level.
1. Blade brackets screwed loosely to
motor.
2. Blade screwed loosely to blade iron.
3. Blade cracked.
4. Canopy contacting ceiling.
5. No oil or low oil level.
1. Unbalanced blades.
2. Inadequate blade clearance.
3. Loose blades or blade irons.
4. Fan not secure on hanger assembly.
PROBLEM PROBABLE CAUSE SOLUTION
1. Turn power on, replace fuse, or reset breaker.
2. Loosen canopy, check all connections according to
STEP 5 - WIRING INSTRUCTIONS (turn power
off before checking).
3. Push switch firmly up or down.
4. Pull switch chain.
5. Check the oil level according to STEP - CARE
AND MAINTENANCE (turn fan off before
checking.)
1. Tighten screws until snug.
2. Tighten screws until snug.
3. Replace all blades.
4. Lower canopy.
5. Check the oil level according to STEP - CARE
AND MAINTENANCE (turn fan off before
checking.)
1. Rebalance. (See Step 7 sub-step 4.)
2. Relocate Fan.
3. Tighten all screws.
4. Turn power off. Support fan very carefully.
Loosen canopy and hang correctly.
Note: If blades will not turn by hand, contact your nearest service representa-
tive or dealer for assistance.
If you have tried these troubleshooting solutions and still have trouble,
call 901-248-2222 or visit our Web site at http://www.hunterfan.com.
Hunter Fan Company
2500 Frisco Avenue
Memphis, TN 38114
USA
© 2001 Hunter Fan Co.
The Inside Story
Oil is constantly pumped up the spiral groove
to lubricate the rotor and the shaft. The oil is
returned to the reservoir where the bearings are
submerged in a bath of oil.
This unique lubrication system is built into all
Original®Hunter Ceiling Fans. That’s one reason
Hunters last so long, and why we can offer a
Limited Lifetime Warranty.
Should you move you fan to another location,
it is a good idea to check the oil reservoir. Hunter
has developed an accessory “Original®Relocation
Kit” that includes all mounting hardware and a
fresh tube of oil for this reason. The model number
is 22360.
We appreciate the opportunity to supply you with the best ceiling fan available anywhere in the world.
Record the following information for your records and warranty assistance. Please refer to the carton and the
Hunter nameplate (located on the top outside fan motor housing) for the proper information.
Model Name ______________ Catalog No. _________________ Serial No.______________
Date Purchased ____________ Where Purchased ________________________
Figure 19
