Hunter 22926 Manual

Hardware
(Drawn to Scale)
Fan Parts
(Not Drawn to Scale)
PARTS GUIDE
PARTS GUIDE
Using this Parts Guide, make sure all
parts are included in the box.
If parts are missing, DO NOT RETURN
THIS ITEM TO THE STORE, call 888-830-1326 for assistance.
THIS PARTS GUIDE IS FOR REFERENCE ONLY.
REFER TO THE INSTALLATION MANUAL FOR FULLASSEMBLY INSTRUCTIONS.
R
SINCE 1886
Parts List
Model # 22926
Asm. Dwg. # 98246-01
Finish Brushed Nickel
Item Name Qnty Part #
* Canopy Assembly 1 98026-09
Ceiling Plate
Canopy
Canopy Trim Ring
Canopy Screw
Wood Screw
Flat Washer
Mounting Isolator
* Locking Screw
Setscrew
Hanger Ball / Downrod Assembly 1 87942-03
Blade Set 1 75539-99
Screw, Blade Iron Armature 10 63755-05
Light Kit Assembly 1 88137-01
Hardware Kit 1 98246-00-860
Blade Grommet
Blade Assembly Screw
Screw, Machine, 6-32
Wire Connector
Screw, Switch Housing Assembly
Balancing Kit 1 07570-01
Remote Control Transmitter 1 64131-01
Heat Shield 1 88136-01
Decorative Screw 3 76426-01
Globe/Shade 1 98128-01
Hunter Fan Company • 2500 Frisco Avenue • Memphis, TN 38114 • www.hunterfan.com • 98000-01-842 11-29-2007 • ©2007
Hanger
Bracket
Assembly
Blade
Assembly
Switch
Housing
Assembly
Screw,
Machine, 6-32
Setscrew
Canopy Screw
Flat Washer
Screw, Blade
Assembly
Decorative
Screw
3” Wood Screw
Balancing
Kit
Wire
Connector
1.5” Wood Screw
x 2
x 4
x 2
x 3
x 1
x 10
x 6
x 3
x 1
x 4

Materiales
(no dibujados a escala)
Piezas del ventilador
(no dibujadas a escala)
GUÍA DE PIEZAS
GUÍA DE PIEZAS
Consulte esta Guía de partes para
asegurarse de que todas las partes
estén incluidas en la caja.
Si falta alguna parte, NO DEVUELVA ESTE PRODUCTO A LA TIENDA. Solicite ayuda al
888-830-1326. ESTA GUÍA DE PARTES SOLAMENTE ES REFERENCIAL. CONSULTE LAS
INSTRUCCIONES COMPLETAS DE ENSAMBLAJE EN EL MANUAL DE INSTALACIÓN
R
SINCE 1886
PARADA
Lista de piezas
No. del modelo 22926
No. del dibujo de ensamblaje 98246-01
Acabado Níquel pulido
Nombre del ítem Cantidad No. de la pieza
* Canopy Assembly 1 98026-09
Ceiling Plate
Canopy
Canopy Trim Ring
Canopy Screw
Wood Screw
Flat Washer
Mounting Isolator
* Locking Screw
Setscrew
Hanger Ball / Downrod Assembly 1 87942-03
Blade Set 1 75539-99
Screw, Blade Iron Armature 10 63755-05
Light Kit Assembly 1 88137-01
Hardware Kit 1 98246-00-860
Blade Grommet
Blade Assembly Screw
Screw, Machine, 6-32
Wire Connector
Screw, Switch Housing Assembly
Balancing Kit 1 07570-01
Remote Control Transmitter 1 64131-01
Heat Shield 1 88136-01
Decorative Screw 3 76426-01
Globe/Shade 1 98128-01
Hunter Fan Company • 2500 Frisco Avenue • Memphis, TN 38114 • www.hunterfan.com • 98000-01-842 11-29-2007 • ©2007
Conjunto del
soporte de
suspensión
de conjunto
de paleta
Conjunto del
interruptor/
alojamiento
Tornillo,
mecánico, 6-32
Tornillo Decorativo
Tornillo prisionero
Tornillo, de campana
Arandela, plana
Tornillo, de conjunto
de paleta
3” Tornillo, de madera
Kit de
equilibrado
Empalme
plástico
1.5” Tornillo,
de madera
Tornillo,
mecánico, 6-32
x 2
x 4
x 2
x 3
x 1
x 10
x 6
x 1
x 4
x 3
