Hunter Type 3 Models User manual

For Your Records and Warranty
Assistance
Model Name: _____________________
Catalog/Model No.: ________________
Serial No.: ________________________
Date Purchased: ___________________
Where Purchased: _________________
For reference also attach your receipt or a
copy of your receipt to the manual. TYPE 3 Models
installation and
operation manual
for Hunter
Ceiling Fans
 42659-01•02/19/08

2
42659-01•02/19/08•HunterFanCompany
© 2008 Hunter Fan Company
YournewHunter®ceiling fan is an addition to your home or office that
will provide comfort and performance for many years. is installation
and operation manual gives you complete instructions for installing
and operating your fan.
We are proud of our work. We appreciate the opportunity to supply
you with the best ceiling fan available anywhere in the world.
Before installing your fan, for your records and warranty assistance,
recordinformationfromthecartonandHunternameplatelabel
(located on the top of the fan motor housing).
Cautions and Warnings
•READ THIS ENTIRE MANUAL CAREFULLY BEFORE BEGINNING
INSTALLATION. SAVE THESE INSTRUCTIONS.
•UseonlyHunterreplacementparts.
•Toreducetheriskofpersonalinjury,attachthefandirectlytothe
support structure of the building according to these instructions,
and use only the hardware supplied.
•Toavoidpossibleelectricalshock,beforeinstallingyourfan,
disconnect the power by turning off the circuit breakers to the
outlet box and associated wall switch location. If you cannot lock
the circuit breakers in the off position, securely fasten a prominent
warning device, such as a tag, to the service panel.
•Allwiringmustbeinaccordancewithnationalandlocalelectrical
codesandANSI/NFPA70.Ifyouareunfamiliarwithwiring,usea
qualified electrician.
•Toreducetheriskofpersonalinjury,donotbendtheblade
attachment system when installing, balancing, or cleaning the fan.
Neverinsertforeignobjectsbetweenrotatingfanblades.
•Toreducetheriskofre,electricalshock,ormotordamage,donot
useasolid-statespeedcontrolwiththisfan.UseonlyHunterspeed
controls.
Welcome
Table Of Contents
1•GettingReady......................4
2•InstallingtheCeilingPlate . . . . . . . . . . 5
3•SecuringFantoSecondarySupport
System............................6
4•AssemblingtheBlades .............7
5•SettingtheRemoteTransmitterand
Receiver ..........................8
6•WiringtheFan .....................9
7•InstallingtheCanopyandCanopy
TrimRing........................11
8•CompletingYourInstallationWitha
Bowl Light Fixture . . . . . . . . . . . . . . . .12
9•OperatingtheRemoteControland
MountingtheHolder............13
10•OperatingandCleaningYourCeiling
Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
11•Troubleshooting.................16

3
42659-01•02/19/08•HunterFanCompany
Installer’s Choice and Optional Accessories
Understanding Mounting and Installer’s Choice®
Hunter’spatented2-positionmountingsystemprovidesyoumaximum
installationexibilityandease.YoucaninstallyourHunterfaninone
of two ways, depending on ceiling height and your preference: Standard
orAngledmounting.estepsinthismanualincludeinstructionsfor
bothInstaller’sChoicemountingmethods.
Considering Optional Accessories
ConsiderusingHunter’soptionalaccessories,includingawall-mounted
or remote speed control. To install and use the accessories, follow
the instructions included with each product. For quiet and optimum
performanceofyourHunterfan,useonlyHunterspeedcontrols.
Forceilingshigherthan8feet,youcanpurchase
Hunterextensiondownrods.AllHunterfansuse
sturdy 3/4” diameter pipe to assure stability and
wobble-free performance.
Standard Mounting hangs from the
ceiling by a downrod (included).
Angled Mounting recommended for a
vaulted or angled ceiling
Support Brace
Standard
Mounting
Style
Ceiling
OutletBox
Support Brace
Ceiling
OutletBox
Angle
Mounting
Style
8
12
CAUTION: To reduce the risk of personal
injury,attachthefandirectlytothesupport
structure of the building according to these
instructions, and use only the hardware
supplied.

4
42659-01•02/19/08•HunterFanCompany
To install a ceiling fan, be sure you can do the following:
•Locatetheceilingjoistorothersuitablesupportinceiling.
•Drillholesforandinstallwoodscrews.
•Identifyandconnectelectricalwires.
•Lift40pounds.
Ifyouneedhelpinstallingthefan,yourHunterfandealercandirect
you to a licensed installer or electrician.
Gathering the Tools
You will need the following tools for installing the fan:
•Electricdrillwith9/64”bit
•Standardscrewdriver(magnetictiprecommended)
•Phillips-headscrewdriver(magnetictiprecommended)
•Wrenchorpliers
•Ladder(heightdependentuponinstallationsite)
Checking Your Fan Parts
Carefullyunpackyourfantoavoiddamagetothefanparts.Referto
theincludedPartsGuide.Checkforanyshippingdamagetothemotor
orfanblades.Ifanypartsaremissingordamaged,contactyourHunter
dealerorcallHunterTechnicalSupportDepartmentat866-268-1936.
Preparing the Fan Site
Before you begin installing the fan, follow all the instructions in
the pullout sheet called “Preparing the Fan Site.” Proper ceiling fan
location and attachment to the building structure are essential for
safety, reliable operation, maximum efficiency, and energy savings.
Installing Multiple Fans?
If you are installing more than
one fan, keep the fan blades and
blade irons (if applicable) in sets,
as they were shipped.
1 • Getting Ready

5
42659-01•02/19/08•HunterFanCompany
CAUTION: To avoid possible electrical shock, before installing your fan,
disconnect the power by turning off the circuit breakers to the outlet box
and associated wall switch location. If you cannot lock the circuit breakers
in the off position, securely fasten a prominent warning device, such as a
tag, to the service panel.
2-1. Drill two pilot holes into the wood support structure through the
outermost holes in the outlet box. e pilot holes should be 9/64”
in diameter.
For Angled Ceilings: Be sure to orient the ceiling plate so that the
two tabs are pointing toward the ceiling peak.
2-2. Seperate the ceiling plate from the remote control receiver.
2-3. Your fan comes with four preinstalled noise isolators. Check to
make sure all four isolators are in place and were not removed
during shipment.
2-4. Place a flat washer on each of the two 3” wood screws.
2-5. read the supply wires from the outlet box in the ceiling through
the hole in the center of the ceiling plate.
2-6. Aligntheslottedholesintheceilingplatewiththepilotholesyou
drilled in the wood support structure. For proper alignment use
slotted holes directly across from each other.
Note: e isolators should be flush against the ceiling.
2-7. Passthescrewsthroughtheslottedholesintheceilingplateinto
the pilot holes you drilled.
Tighten the screws into the 9/64” pilot holes; do not use lubricants
on the screws. Do not over tighten.
Flat Washer
3” Wood
Screw Steps 2-4 – 2-7
Ceiling
Plate
For Angled Ceilings: Be sure to orient
the ceiling plate so that the two tabs
are pointing toward the ceiling peak.
Toward
Ceiling Peak
2 • Installing the Ceiling Plate

6
42659-01•02/19/08•HunterFanCompany
3-1. Find the looped end of the braided cable and insert it through the
ceiling plate and one of the holes in the outlet box into the ceiling.
3-2.Accessthesupportbraceintheceiling.Youmaynotbeabletodo
this from below the ceiling depending on your installation site.
3-3. Drive a wood screw and washer into the side of the brace that
holdstheoutletbox.Leave3mm(1/8”)ofspacebetweenthe
support brace and the washer.
3-4. Wrap the braided cable around the support brace once creating a
complete circle.
3-5.Hooktheloopedendofthecableoverthewoodscrewsothatthe
braided cable lies between the washer and the support brace.
3-6. Tighten the loop and secure the screw and washer all the way
down to the support brace.
3-7.Coiluptheexcesscable.
3-8.Returntothefansoyoucancompletethefanwiring.
Step 3-1
3mm (1/8")
Steps 3-2 – 3-3 Steps 3-4 – 3-5 Steps 3-6 – 3-7
Support
Brace
Ceiling
OutletBox Braided
Cable
3 • Securing Fan to Secondary Support System

7
42659-01•02/19/08•HunterFanCompany
4-1. Insert blade through housing before installing grommets in
each blade.
4-2. Attacheachbladetothefanusingtwobladeassembly
screws.
Grommet
BladeAssembly
Screw
4 • Assembling the Blades

8
42659-01•02/19/08•HunterFanCompany
CAUTION: e remote control device complies with part 15 of the FCC rules.
ChangesormodicationsnotexpresslyapprovedbyHunterFanCompanycouldvoid
your authority to operate this equipment.
Operationissubjecttothefollowingtwoconditions:
1. is device may not cause harmful interference.
2. is device must accept any interference received, including interference that may
cause undesired operation.
Note:Usewithafanthatincorporatesanairgapswitch(normalon-owallswitch).
WARNING:Maximumfanloadis1Amp;maximumlampis19Watts.Donotuse
any speed control with this product.
Youmustnowsetthejumpersintheremotetransmitterandreceiver
so that they match.
5-1. Changethepositionofthejumpersinthetransmitterandthe
receiver.Besurethepositionofthejumperinthetransmitter
matchesthepositionofthejumperinthereceiver.Iftheydon’t
match, the controller will not function. For instructions on how to
setthejumpers,readtheboxbelow.
5-2. Install the included 12-volt battery into the transmitter.
Setting Jumpers
When two or more fans are located near each other, you may desire to
have the receiver/transmitter for each fan set to a different code, so that
the operation of one fan does not affect the operation of the other fans.
Inthetransmitteryoucanaccessthejumpersfromthebattery
compartment.ejumpersareverysmall.Youcanmovethemmost
easily using a small pair of pliers or tweezers. IMPORTANT! Before
youchangeajumper,makesurethebatteryisnotconnectedtothe
transmitter.
4321
4321
4321
4321
4 = off (apagado)
3 = on (encendido)
2 = on (encendido)
1 = on (encendido)
4 = off (apagado)
3 = on (encendido)
2 = off (apagado)
1 = on (encendido)
Example Jumpers Settings
Receiver1 Receiver2
Transmitter 2Transmitter 1
4321
4321
4321
4321
4 = off (apagado)
3 = on (encendido)
2 = on (encendido)
1 = on (encendido)
4 = off (apagado)
3 = on (encendido)
2 = off (apagado)
1 = on (encendido)
5 • Setting the Remote Transmitter and Receiver

9
42659-01•02/19/08•HunterFanCompany
All wiring must be in accordance with national and local electrical
codes and ANSI/NFPA 70. If you are unfamiliar with wiring, use a
qualified electrician.
Wall switches are not included. Select an acceptable general-use switch
in accordance with national and local electrical codes.
6-1. Before attempting installation, make sure the power is still off.
6-2. Place the receiver inside the canopy, making sure that the
dipswitches and the oval shaped holes in the bottom of the
receiver are facing down toward the bottom of the canopy.
6-3. Spread the receiver lead wires to each side and feed the wires from
the top of the fan through the open slot in the receiver.
6-4. Place the receiver in the canopy. Make sure the slot in the receiver
is aligned with the hook in the ceiling plate.
6-5. To connect the wires, hold the bare metal leads together and
place a wire connector over them, then twist clockwise until tight.
Usingthesmallwireconnectors,connectthefantothereceiveras
follows:
•Connecttheyellowwire(ungrounded)fromthefantothe
yellow wire (ungrounded) from the receiver.
•Connectthewhitewire(ungrounded)fromthefantothe
white wire (ungrounded) from the receiver (marked on white
tag“LIGHTNEUTRALOUT”).
•Connectthepinkwire(ungrounded)fromthefantothepink
wire (ungrounded) from the receiver.
•Connectthegreywire(ungrounded)fromthefantothegrey
wire (ungrounded) from the receiver.
•Connecttheblack/whitewire(ungrounded)fromthefanto
the black/white wire (ungrounded) from the receiver (marked
onwhitetag“LIGHTLIVEOUT”).
•Connecttheredwire(ungrounded)fromthefantothered
wire (ungrounded) from the receiver.
Steps 6-5 – 6-7
Small Wire
connector
Step 6-7
A •Ground/Green
Step 6-6
B •ReceiverBlack:“ACLIVEIN”
 •CeilingBlack
C •ReceiverWhite:“ACNEUTRALIN”
 •CeilingWhite
Step 6-5
D •FanYellow
 •ReceiverYellow
E •FanWhite
 •ReceiverWhite:“LIGHTNEUTRALOUT”
F •FanPink
 •ReceiverPink
G •FanGrey
 •ReceiverGrey
H •FanBlack/White
 •ReceiverBlack/White:“LIGHTLIVEOUT”
I •FanRed
 •ReceiverRed
Receiver
A
B
CDE
F
G
H
I
6 • Wiring the Fan

10
42659-01•02/19/08•HunterFanCompany
6-6. Usingthelargewireconnectors,connectthefanandreceiverto
the power wires as follows:
•Connecttheblackwire(ungrounded)fromthereceiver
(markedonwhitetag“ACLIVEIN”)totheblackwire
(ungrounded) from the ceiling.
•Connectthewhitewire(ungrounded)fromthereceiver
(markedonwhitetag“ACNEUTRALIN”)tothewhitewire
(ungrounded) from the ceiling.
CAUTION: Be sure no bare wire or wire strands are visible after
making connections.
6-7. Connectthegreengroundwires(grounded)fromtheceiling
plate and the downrod to the ground wire from the ceiling.
6-8. Runthethinwhiteantennawirefromthereceiverthroughone
of the slots in the ceiling plate. (For best reception, make sure the
end of the antenna is exposed at the top of the canopy.)
6-9. Turn the splices upward and push them carefully back through
the ceiling plate into the outlet box.
6-10. Spread the wires apart, with the grounded wires on one side of
the outlet box and the ungrounded wires on the other side of the
outlet box.
Large Wire
Connector

11
42659-01•02/19/08•HunterFanCompany
WARNING: Failure to complete the following steps could cause the fan
to fall.
Note: It is recommended you use a magnetic tip screwdriver for the
following steps.
7-1.Rotatethehangerballsothetabinthecanopyissecureinthe
hanger ball groove. Note: Your fan may have multiple tabs and
grooves that must be aligned.
7-2. Swingthefanuptoalignthecanopyscrewholeswiththe
mounting holes on the ceiling plate.
WARNING: e slots in the canopy must remain engaged while
swinging the canopy for alignment.
7-3. Holdingthecanopyupwiththescrewholesaligned,partially
install two canopy screws into the holes opposite the ceiling plate
tabs.
7-4. Partiallyinstallacanopyscrewbetweentheslotsinthecanopy.
When all the holes are properly aligned, securely tighten all three
canopy screws.
7-5.Verifythatthetabsinthecanopyarestillinthegroovesofthe
hanger ball.
7-6.Alignthetabsonthetrimringoppositethegroovesinthehanger
ball.Usingbothhands,pushthecanopytrimringuptothetopof
the canopy. e canopy trim ring will snap and lock into place.
Note: Should you need to remove the trim ring, press firmly on
opposite sides of the trim ring directly above the groove in the
hanger ball. e tabs will flex out releasing the canopy trim ring.
Step 7-1
Step 7-2
Groove
Tab
Step 7-3
Canopy Screw
Canopy
Trim
Ring
Canopy
7 • Installing the Canopy and Canopy Trim Ring

12
42659-01•02/19/08•HunterFanCompany
GlassBowl
Bulb
Installing the Glass Bowl
8-1. Partiallyinstalltwoscrewsintheupperlightkit.
8-2. Alignthekeyholesintheupperlightkitringwith
the partially installed screws and rotate to situate
the screws in the narrow ends of the keyholes.
8-3. Installtheremainingscrewintotheupperlightkit
ring and securely tighten all three screws.
8-4. Installbulb.
8-5. Alignthetabsintheglobeassemblywiththetabs
in the light kit ring, then lift the globe assembly
and rotate to engage the tabs. Make sure all tabs
are properly engaged before releasing the globe.
Steps 8-1 - 8-3
Steps 8-4 - 8-5
Screws
8 • Completing Your Installation With a Bowl Light Fixture

13
42659-01•02/19/08•HunterFanCompany
9-1. e remote transmitter has individual buttons for turning the fan
off and on and controlling the light and fan speed.
9-2. For best operation, start the fan by pressing high, then select your
desired speed.
9-3. e light button turns the light on to full brightness. Push the
light button again to turn off the light.
9-4. e reversing switch reverses the direction of the fan.
9-5. PresstheOFFbuttontoturnthefano.
9-6. Whennecessary,replacethebatterywitha12-volttype23A,
MN-21 battery or equivalent.
9-7. Youcanmounttheremoteholdertoanytoggleswitchplatewith
thescrewsalreadyintheswitchplate.Or,youcansimplymount
the remote holder on the wall.
Step 9-6
Fan Light
Fan Speed
High
Fan Speed
Medium
Fan Speed
Low FanO
ReversingSwitch
Steps 9-1 – 9-5
Step 9-7
9 • Operating the Remote Control and Mounting the Holder

14
42659-01•02/19/08•HunterFanCompany
10-1. Restorepoweratthemainelectricalpanelandturnonthewall
switch.elightkitshouldturnON.
Note: To turn on the light without the remote, turn off the wall
switch for 5 seconds, then back on. e light kit will turn on at
maximum brightness.
10-2. Presstheremotecontrol’sHIGHspeedbutton.efanshould
start and reach its maximum speed.
Note:Foreverydayoperation,leavethewallswitchON.Ifthe
remote control will not be used for 5 days or more, turn the wall
switchOFF.
10-3. Ceiling fans work best by blowing air downward
(counterclockwise blade rotation) in warm weather to cool the
room with a direct breeze. In cold weather, having the fan draw
air upward (clockwise blade rotation) will distribute the warmer
air trapped at the ceiling around the room without causing a
draft.
10-4. For cleaning finishes, use a soft brush or lint-free cloth to prevent
scratching.Avacuumcleanerbrushnozzlecanremoveheavier
dust.Removesurfacesmudgesoraccumulateddirtanddust
using a mild detergent and a slightly dampened cloth. You may
use an artistic agent, but never abrasive cleaning agents as they
will damage the finish.
10-5. Clean wood finish blades with a furniture polishing cloth.
Occasionally,applyalightcoatoffurniturepolishforadded
protection and beauty. Clean painted and high-gloss blades in
the same manner as the fan finish.
In warm weather, use
downward air flow pattern
In cold weather, use upward
air flow pattern
10 • Operating and Cleaning Your Ceiling Fan

15
42659-01•02/19/08•HunterFanCompany
Hunterfanshavethepowertocutyourcoolingcostsupto40%.
Beat the High Cost of Cooling
eairmovementcreatedbyaHunterceilingfanletsyousetyour
thermostat higher and still stay comfortable. Every degree you
raisethethermostatsavesupto7%onenergycosts.So,youcan
cutbackonexpensiveairconditioning...andsaveupto40%*on
cooling.Inwinter,yourHunterfanrecirculateswarmairandsaves
upto10%*onheatingbills.
*Onaverageatlowspeedsettings.Yoursavingsmayvarybased
on climate, building type and thermostat setting.
Save Energy and Money While Protecting the Environment
Congratulations!You’resavingenergyandmoneywhileprotecting
theenvironmentbypurchasingthisENERGYSTARqualied
Hunterceilingfan!Withthispurchase,youaredoingyourpartto
protecttheenvironment.In2010,ENERGYSTARqualiedceiling
fansareprojectedtocutairpollutionbymorethan500million
pounds!
YournewceilingfanhasearnedtheENERGYSTARlabel
because it meets high energy efficiency specifications set by
theEnvironmentalProtectionAgency(EPA).ENERGYSTAR
labeled ceiling fans save energy because they have more efficient
fan motors and air delivery due to more aerodynamic blade
congurations.CeilingfanmodelsbearingtheENERGYSTARlabel
moveair14-20%moreecientlythantypicalceilingfanmodels.
FormoreinformationonENERGYSTARvisitwww.energystar.gov.

16
42659-01•02/19/08•HunterFanCompany
Problem: Nothing happens; fan does not move.
1. Turn power on, replace fuse, or reset breaker.
2. Loosen canopy, check all connections according to the wiring the
fan section.
3. Check the plug connection in the switch housing.
4. Push motor reversing switch firmly left or right to ensure that the
switch is engaged.
5. Pull the pull chain to ensure it is on.
6.Removetheshippingbumpers.
Problem: Noisy operation.
1. Tighten the blade bracket screws until snug.
2. Check to see if the blade is cracked. If so, replace all the blades.
Problem: Excessive wobbling.
1. If your fan wobbles when operating, use the enclosed balancing kit
and instructions to balance the fan.
2. Tighten all blade iron screws.
3. Turn power off, support fan very carefully, and check that the
hanger ball is properly seated.
If you need parts or service assistance, please call
866-268-1936orvisitusatourWebsiteat
http://www.hunterfan.com.
HunterFanCompany
2500FriscoAvenue
Memphis,Tennessee38114
11 • Troubleshooting
