Huskee 5328 Series User manual

Cordless Electric Broom
5328 Series
December 2013
Version 2.05

Model 5328 Owners Guide
2
General Warnings
IMPORTANT SAFETY INSTRUCTIONS!
When using an electrical appliance, basic precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS ELECTRIC BROOM
WARNING To reduce the risk of fire, electric shock, or injury:
• Do not use outdoors or on wet surfaces.
• Use only as described in this manual.
• Do not use with damaged cord or plug. If appliance is not working as it should,
has been dropped, damaged, left outdoors, or dropped into water, return it to a
service center or call customer service at: : 1-800-353-9991
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings. Do not use with any opening blocked;
keep free of dust, lint, hair and anything that may reduce air flow.
• Keep hair, loose clothing, fingers and all parts of body away from openings
and moving parts.
• Turn off all controls before unplugging.
• Do not use appliance in an enclosed space where oxygen, flammable, explosive or
toxic vapors are given off or in an area where flammable dust is present.
• Do no allow to be used as a toy. Close attention is necessary when used by children.
• Do not use extension cords or outlets with inadequate current carrying capacity.
• Do not incinerate or mutilate batteries as they will explode at high temperatures.
• Do not pick up anything that is burning or smoking such as cigarettes, matches
or hot material.
• Do not allow the battery to run down completely before charging. In doing so,
serious problems may occur in the battery life cycle.
• Do not pick up flammable or combustible liquids such as gasoline or use in
areas where they are present.
• Store the adapter indoors in a cool dry area not exposed to the weather to avoid
electrical shock and/or cleaner damage.
• Only use the adapter provided by the manufacturer to recharge the appliance.
• Always disconnect cord from electrical outlet before servicing appliance.
• Only charge the unit indoors.
SAVE THESE INSTRUCTIONS

Model 5328 Owners Guide
3
Contents.
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . 4
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . 5
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Emptying Dirt Container . . . . . . . . . . . . . . . . . . . . . . . 5
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cleaning Standard Carpet Brushroll . . . . . . . . . . . . . . 6
Cleaning Monster Pet Brushroll . . . . . . . . . . . . . . . . . 6
Troubleshooting . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . 7
Battery Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 8
To assist you in identifying your vacuum’s components, the parts have been
Numbered as follows.

Model 5328 Owners Guide
4
Assembly Instructions
1. Attach wall mount to a flat surface using the screws provided.
2. Insert the round end of the brush roll against the side-intake. Push the end
card of the opposite end of the brush roll into the channel until the end
card “snaps” into place.
3. Attach handle to the end of strut with the telescopic wand adjustment.
Pressing down the locking tab, slide shorter strut over longer strut until
locking tab catches. Insert assembled handle into base until it locks in place.
4. Loosen the telescopic wand adjustment to lengthen or shorten the handle
to the desired length and then tighten telescopic wand adjustment. Insert
battery into battery compartment until it “snaps” in place. Connect the power
adapter and allow the unit to charge for 14 hours.
The LED charging display will light red when charging. If the LED does not
light when charging, check to make sure the unit is in the OFF position.
When the LED on the power adapter changes to green, the battery is fully
charged.
NOTE: The unit will not charge if left in the ON position.
It is recommended that you remove the power adapter from the unit once
the unit has completely charged

Model 5328 Owners Guide
5
Operating Instructions
5. Press the ON/OFF switch on top of power head when ready to operate.
6. Place foot on power head and lean handle back gently to release lock for
vacuum use. Return handle to the full upright position to engage lock.
NOTE: Do not operate the unit while in the upright and locked position.
Do not let the unit run while in any one stationary position for any period of time.
Keep the unit moving while in operation.
Emptying Dirt Container:
7. Firmly grasp the unit at handle base and with the other hand, press the dirt
container release. Note: Make sure to have a firm grasp on the handle base and
carefully lay the handle flat.
8. Lift the dirt container out of the unit and dump contents into wastebasket.
Reinsert the dirt container into the unit. Grasp the handle base and carefully
rotate it forward until it locks into place.

Model 5328 Owners Guide
6
Storage:
9. Attached the lip of the brush roll chamber over the hooks of the wall mount.
Rotate handle upwards until it snaps into the handle lock.
Cleaning Standard Carpet Brush Roll:
10.Press the Brush roll Release to remove the brush roll from the brush roll
chamber. Remove any wound up debris using a knife or scissors. Cut debris
along patented cleaning grooves in the brush roll for easier cleaning. Reinstall
brush roll into brush roll chamber.
Cleaning Monster Pet Brush roll:
11.Press the Brush roll Release to remove the brush roll from the brush roll
chamber. Pull the round end of the brush roll to remove it from the cleaning
cover. All debris to be discarded will be left on the brush roll cover. Remove any
wound up debris using a knife or scissors. After cleaning brush roll, insert it back
into the cleaning cover. Reinstall brush roll into brush roll chamber.

Model 5328 Owners Guide
7
Maintenance: Troubleshooting:
Service problems that appear to be major can often be solved easily. You can be your
own troubleshooter by reviewing this guide.
Customer Service Hotline USA: 1-800-353-9991
website: www.vacshopusa.com
Battery Disposal
To preserve natural resources, please recycle or dispose of expired battery pack properly.
THIS PRODUCT CONTAINS A NICKEL-CADMIUM BATTERY. IT MUST BE DISPOSED
OF PROPERLY. LOCAL, SATE, OR FEDERAL LAWS MAY PROHIBIT DISPOSAL OF
NICKEL-CADMIUM BATTERIES IN ORDINARY TRASH. CONSUL YOUR LOCAL
WASTE AUTHORITY FOR INFORMATION REGARDING AVAILABLE RECYCLING
AND/OR DISPOSAL OPTIONS. FOR DISPOSAL INFORMATION, CALL THE
RECHARGEABLE BATTERY RECYCLING CORPORATION AT 1-800-8-BATTERY.

Model 5328 Owners Guide
8
Warranty:
Huskee: (Huskee gives you the following limited warranty for this product only if it was
originally purchased for use, not resale, from an Huskee Authorized Retail Dealer.)
Huskee will repair or replace, free of charge, to the original purchaser, any part which is
found to be defective in material or workmanship within one (1) year of the date of
purchase. This limited warranty applies to normal domestic or commercial use of this
product will void this limited warranty.
This limited warranty does not cover the replacement of expendable or consumable
parts such as belts, brushes, bulbs and other parts subject to normal wear. This limited
warranty does not apply to any part subjected to accident, abuse, alteration, misuse,
damage caused by fire or act of God, the use of voltages other than indicated on the
serial number plate of this product.
Huskee does not authorize any person or representative to assume or grant any other
warranty obligation with the sale of this product. This limited warranty is valid only if
you retain proof of purchase. If you purchase this product from any other source, your
purchase is “AS IS,” which means Huskee grants you no warranty, and that you, not
Huskee, assume the entire risk of the quality and performance of this product, including
the entire cost of any necessary servicing
or repairs of any defects.
Huskee’s liability for damages to you for any costs whatsoever arising out of this
statement of limited warranty shall be limited to the amount paid for this product at the
time of original purchase, and Huskee shall not be liable for any direct, indirect,
consequential or incidental damages arising out of the use or inability to use this
product. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you.
ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT, INCLUDING IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED IN DURATION TO THE WARRANTY PERIOD, AND NO WARRANTIES, WHETHER
EXPRESS OR IMPLIED, WILL APPLY AFTER THIS PERIOD.
Some states do not allow limitations on the duration of implied warranties, so the above
limitation may not apply to you. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state.
Total Cleaning System
