1. INTRODUCTION AND SAFETY
1. Introduction and safety
1.1 Introduction
Congratulations on your choice of an exceptionally
high quality product. To get the best results from your
Husqvarna Automower
®
requires knowledge of its
function. This Operator's manual contains important
information about the mower, how you install it and
how you use it.
The following system is used in the Operator's manual
to make this easier:
• Italic content indicates one of the following:
• It is shown in the mower's display
• It is an SMS via a mobile phone
• It is a reference to a another section in the
operator's manual.
• Words written in bold are one of the buttons on
the mower's keypad.
• Words written in UPPERCASE and italics refer to
the position of the main switch and the different
operating modes on the mower.
Husqvarna AB has a policy of continuous product
development and therefore reserves the right to modify
the design and appearance and function of products
without prior notice.
IMPORTANT INFORMATION
Read through the Operator’s Manual carefully
and understand the content before using
your Automower
®
.
WARNING
Automower
®
can be dangerous if
incorrectly used.
WARNING
Never use the robotic lawnmower
when persons, especially children, or
pets, are in the cutting area.
1001-003
1001 0
1157068-26,265ACX_GB.book Page 5 Friday, November 28, 2014 9:06 AM

6 - English
1. INTRODUCTION AND SAFETY
1.2 Symbols on Automower
®
These symbols can be found on the lawn mover. Study
them carefully so you understand their significance.
• Read through the Operator’s Manual carefully
and understand the content before using your
Automower
®
.
• The warnings and safety instructions in this
Operator’s Manual must be carefully followed if
the mower is to be used safely and efficiently.
• Automower
®
can only start when the main switch
is moved to the ON position and the correct PIN
code has been entered. Inspection and/or
maintenance must be carried out with the main
switch set to OFF .
• Keep your hands and feet away from the rotating
blades. Never place your hands or feet close to
or under the body when Automower
®
is in
operation.
• Do not ride on Automower
®
.
• Noise emission to surroundings. The machine's
emission is specified in chapter Technical data
and on label.
• This product conforms to the applicable
EU Directives.
• This product contains components tested
according to FCC (complete system not tested).
• It is not permitted to dispose of this product as
normal household waste when it has reached the
end of its useful life. Ensure that the product is
recycled in accordance with local legal
requirements.
• Never use running water to clean the robotic
lawn mower.
1001-003
1001-002
3012-1085
3012-663
3012-665
1001-153
b
6001-024
3012-1108
3012-689
3012-577
1157068-26,265ACX_GB.book Page 6 Friday, November 28, 2014 9:06 AM

English - 7
1. INTRODUCTION AND SAFETY
• The low voltage cable must not be shortened,
extended or spliced.
• Do not use a trimmer nearby the low voltage
cable. Be careful when trimming edges where
the cables are placed.
1.3 Symbols in the Operator’s
Manual
These symbols can be found in the Operator’s
Manual. Study them carefully so you understand their
significance.
• Inspection and/or maintenance must be carried
out with the main switch set to OFF .
• Always wear protective gloves when working
with the mower’s underframe.
• Never use a high-pressure washer or even
running water to clean Automower
®
.
• A warning box indicates a risk of personal injury
exist, especially when the stated instructions are
not followed.
• An information box indicates a risk of material
damage exist, especially when the stated
instructions are not followed. The box is also
used where there is a risk of user error.
3012-1351
OFF
3012-288
3012-272
3012-271
WARNING
Xxxxxx xxxxx xxxx xxxx xxxxx xxx.
IMPORTANT INFORMATION
Xxxxxx xxxxx xxxx xxxx xxxxx xxx.
1157068-26,265ACX_GB.book Page 7 Friday, November 28, 2014 9:06 AM

8 - English
1. INTRODUCTION AND SAFETY
1.4 Safety instructions
Use
• This robotic lawn mower is designed to mow
grass in open and level ground areas. It may only
be used with the equipment recommended by
the manufacturer. All other types of use are
incorrect. The manufacturer’s instructions with
regard to operation, maintenance and repair
must be followed precisely.
• Never use the robotic lawnmower when persons,
especially children, or pets, are in the cutting area.
If there are persons, or pets, in the cutting area it is
recommended that the lawnmower be
programmed for use during hours when the area is
free from persons, e.g. at night. See Timer (2) .
• The robotic lawn mower may only be operated,
maintained, and repaired by persons that are fully
conversant with its special characteristics and
safety regulations. Please read the Operator’s
Manual carefully and make sure you understand
the instructions before using the robotic lawn
mower.
• It is not permitted to modify the original design of
Automower
®
. All modifications are made at your
own risk.
• Check that there are no stones, branches, tools,
toys or other objects on the lawn that can
damage the blades and cause the mower to
stop.
• Start Automower
®
according to the instructions.
When the main switch is in the ON position;
make sure you keep your hands and feet away
from the rotating blades. Never put your hands
and feet under the mower.
• Never lift up Automower
®or carry it around when
the main switch is in the ON position.
• Do not let persons who do not know how
Automower®works and behaves use the mower.
• The robotic lawnmower must never be allowed to
collide with persons or other living creatures. If a
person or other living creature comes in the
lawnmower's way it shall be stopped
immediately. See Stopping Automower®.
• Do not put anything on top of Automower®or its
charging station.
• Do not allow Automower®to be used with a
defective blade disc or body. Neither should it be
used with defective blades, screws, nuts or cables.
• Do not use Automower®if the main switch does
not work.
• Always switch off Automower®using the main
switch when you do not intend to use the mower.
1001-003
3012-396
3012-663
1157068-26,265ACX_GB.book Page 8 Friday, November 28, 2014 9:06 AM

English - 9
1. INTRODUCTION AND SAFETY
Automower®can only start when the main switch
is moved to the ON position and the correct PIN
code has been entered.
• Automower®must never be used at the same time
as a sprinkler. In this case use the timer function,
see 6.4 Timer (2) on page 52, so the mower and
sprinkler never run simultaneously.
• The built-in alarm is very loud. Be careful,
especially if the robotic lawnmower is handled
indoors.
Transport
The original packaging should be used when
transporting Automower®over long distances.
To safely move from or within the working area:
1. Press the STOP button to stop the mower.
If the anti-theft alarm (see page 62) is activated;
enter the first digit of the PIN code.
You select the four digit PIN code when you start
the mower for the first time, see page 34.
2. Move the main switch to the OFF position if you
intend to carry the mower.
3. Carry the mower by the handle at the rear under
the mower. Carry the mower with the blade disc
away from the body.
Maintenance
WARNING
When the mower is turned upside
down the main switch must always
be set to the OFF position.
The main switch should be set to the
OFF position during all work on the
mower’s underframe, such as
cleaning or replacing the blades.
3012-388
3012-395
ON
OFF
3012-409
1157068-26,265ACX_GB.book Page 9 Friday, November 28, 2014 9:06 AM

10 - English
1. INTRODUCTION AND SAFETY
• Inspect Automower®each week and replace any
damaged or worn parts.
Check especially that the blades and blade disc
are not damaged. Replace all blades and screws
at the same time if necessary so that the rotating
parts are balanced, see 8. Maintenance on
page 68.
1157068-26,265ACX_GB.book Page 10 Friday, November 28, 2014 9:06 AM

English - 11
2. PRESENTATION
2. Presentation
This chapter contains information you should be aware
of when planning the installation.
An installation of Husqvarna Automower®includes four
main components:
Automower®, an automatic lawn mower that mows
the lawn by moving in essentially an irregular pattern.
The mower is powered by a maintenance-free
battery.
Charging station, where your Automower®returns
when the charge level in the battery becomes too
low.
The charging station has three functions:
• To send control signals along the boundary wire.
• To send out signals so Automower®finds the
charging station.
• To charge Automower®battery.
Transformer, which is connected between the
charging station and a 230V wall socket. The
transformer is connected to the wall socket via an
integrated power cord and to the charging station via
a 20 m long low voltage cable. The low voltage cable
must not be extended. The low voltage cable must
not be shortened nor extended.
Wire, laid in a loop around Automower®’s working
area. The boundary wire is laid around the edges of
the lawn and around objects and plants that the
mower must not run into. The wire is also used for
any guide wires. Contact your dealer to purchase a
cable with the right length.
3012-900
3012-860
3012-102
9
3012-221
1157068-26,265ACX_GB.book Page 11 Friday, November 28, 2014 9:06 AM

12 - English
2. PRESENTATION
2.1 Automower®, what’s what?
The numbers in the picture correspond to:
1. Charging strip
2. Cutting height adjustment cover
3. Catch button to open the cutting height adjustment
cover
4. Ultrasonic sensors
5. Drive wheel
6. Body
7. Stop button
8. Keypad
9. Display
10. Main switch
11. Front wheel
12. Handle
13. Chassis box with electronics, battery and motors
14. Skid plate
15. Blade disc
16. Charging station
17. Contact strips
18. LED for operation check of the boundary wire
19. Loop wire for the boundary wire and guide wire
20. Transformer with power cord
21. Low voltage cable
22. Staples
23. Connector for the loop wire
24. Screws for securing the charging station
25. Measurement gauge for help when installing the
boundary wire
26. Solderless coupler for the loop wire
27. Operator’s Manual
28. Extra blades
29. Alarm decal
8
9
10
12
13
14 15
16
17
20
21 23 26 27
7
1
2
3
4
6
7
25
24
5
18
19
22
11
3012-1030
1157068-26,265ACX_GB.book Page 12 Friday, November 28, 2014 9:06 AM

English - 13
2. PRESENTATION
2.2 Function of Automower®
Capacity
Automower®is recommended for lawns up to 6000 m2
+/-20%.
How large an area is mown depends primarily on the
condition of the blades and the type of grass, growth
rate and humidity. The shape of the garden is also
significant. If the garden mainly consists of open
lawns, Automower®can mow more per hour than if the
garden consists of several small lawns separated by
trees, flower beds and passages.
How long Automower®mows and recharges can vary
depending on, among others, the ambient
temperature. Up to around 25 ˚C, a fully charged
Automower®will mow for approx. 80 minutes,
depending on the age of the battery and how thick the
grass is. Then the mower will charge for approx. 40
minutes
Above 25 °C both the mowing and charging times
gradually drop.
Mowing technique
The mowing system used by Automower®is based on
an effective and energy efficient principle. Unlike
normal lawn mowers, Automower®cuts the grass
instead of striking it off.
We recommend you allow Automower®to mainly mow
in dry weather to obtain the best possible result.
Automower®can even mow in the rain, however, wet
grass easily collects on the mower and the risk of
slipping on steep slopes is greater.
If there is risk for thunder, the transformer should be
disconnected from the power, and the boundary wire
and the guide wire from the charging station.
The blades must be in good condition to obtain the
best mowing result. In order to keep the blades sharp
for as long as possible it is important to keep the lawn
free from branches, small stones and other objects.
Replace the blades regularly for the best mowing
result. It is very easy to replace the blades. See 8.6
Replacing the blades.
3020-002
1157068-26,265ACX_GB.book Page 13 Friday, November 28, 2014 9:06 AM

14 - English
2. PRESENTATION
Working method
Automower®automatically mows the lawn.
It continuously combines mowing and charging.
The charging station sends out a signal that
Automower®can sense at a distance of 6 - 7 metres.
The mower starts to search for the charging station
when the battery charge becomes too low.
Automower®does not mow when it is searching for
the charging station.
When Automower®searches for the charging station
it uses one or more of three different search methods:
Irregular, Follow boundary wire and Follow guide
wire.For more information about the search methods,
see 2.3 Search method on page 16 and Follow loop
in (3-2-2) on page 56.
When the battery is charged the mower reverses,
turns around and leaves the charging station in a
randomly selected direction within the exit sector
90° - 270°.
To make it easier for Automower®to reach all parts of
the garden you can manually set how the mower will
leave the charging station, see 6.5 Installation (3) on
page 54.
Automower®is equipped with ultrasonic sensors that
effectively sensor both fixed and moving obstacles
that the mower is subjected to. When faced with an
obstacle, the mower slows down to avoid
unnecessarily hard collisions. When Automower®
body hits an obstacle, the mower reverses and
selects a new direction.
Two additional sensors, one on the front and one on
the back of the Automower®, will sense when the
mower is approaching the boundary wire.
Automower®overruns the wire by up to
27 centimetres before it turns. The overrun length can
be set, see Drive past wire (3-4-2) on page 60.
The STOP button on the top of Automower®is mainly
used to stop the mower when it’s running. When the
STOP button is pressed a cover opens, behind which
there is a control panel. The STOP button remains
depressed until the cover is closed again. This acts
as start inhibitor.
3012-510
3012-902
3012-903
3012-38
8
1157068-26,265ACX_GB.book Page 14 Friday, November 28, 2014 9:06 AM

English - 15
2. PRESENTATION
The control panel on the top of Automower®is where
you manage all the mower settings. The main switch
is also located on the control panel. Open the control
panel cover by pressing down the STOP button.
When the main switch is turned ON for the first time,
a start-up sequence begins which includes: selection
of the language, time format, date format and four
digit PIN code, plus setting of the time and date, see
page 34.
The selected PIN code must then be entered each
time the main switch is moved to the ON position.
This theft-prevention function is called Time
lock(4-1-2) and Automower®has this function activated
as a default setting. The function also means that the
mower stops mowing after a set number of days and
will not continue until the correct PIN code has been
entered. The function can be deactivated or changed
as required. For more information about Time
lock(4-1-2), see page 61.
Automower®can enter a sleep mode to save power.
The display on the control panel is then completely
dimmed.
The sleep mode is activated 25 minutes after the
STOP button has been pressed and then not reset to
the operating mode. Automower®is then activated by
switching the main switch off and on.
The sleep mode can also be activated in the event of
a fault occurring during mowing or charging and
which is not rectified within 25 minutes. Automower®
is then activated by pressing the STOP button.
Movement pattern
The mower’s movement pattern is irregular and is
determined by Automower®itself. A movement
pattern is never repeated. This mowing system
means the lawn is mown equally without any mowing
lines.
If Automower®enters an area where it senses the
grass is longer than earlier, it can change the
movement pattern. It can then mow in a square
pattern to cover the area of longer grass more
systematically.
When Automower®mows in a square pattern, this is
known as square mode cutting. The mower must
have been operational for more than 6 hours in order
for Automower®to start square mode cutting.
3012-904
3012-400
3012-695
3012-696
1157068-26,265ACX_GB.book Page 15 Friday, November 28, 2014 9:06 AM

16 - English
2. PRESENTATION
2.3 Search method
Automower®can be set to search for the charging
station in three different ways. Using the setting
options the three search methods can be combined to
optimise the search for the charging station. The
required search method or methods depends on the
shape of the garden.
Search method 1: Irregular
Automower®runs irregularly until it finds the charging
station.
This search method is best for an installation that has
an open lawn and no narrow passages (narrower
than about 3 metres).
The advantage of this search method is that there is
no risk of leaving tracks in the grass after the mower.
The disadvantage is that the search times can be
somewhat longer.
Search method 2: Follow boundary wire
Automower®runs irregularly until it reaches the
boundary wire. The mower then follows the boundary
wire in to the charging station.
This search method is best for an installation that has an
open lawn with wide passages (wider than about
3 metres) and no, or only a small, island.
The advantage of this search method is that the search
times are generally short.
The disadvantage is that tracks can be formed to a
certain extent in the grass behind the mower. Problems
can also arise if there are narrow passages or a large
number of islands, for example, bushes. Automower®
circles an island roughly twice, which can take a long time
and create tracks.
Search method 3: Follow guide wire
Automower®runs irregularly until it reaches the guide
wire. The mower then follows the guide wire in to the
charging station.
The guide wire is an extra wire that is laid from the
charging station, out towards a remote part of the
working area or through a narrow passage and is then
connected to the boundary wire. Up to two guide wires
can be installed for 265 ACX. For more information, see
3.8 Installation of the guide wire on page 35.
This search method is best for an installation that has
numerous or large islands, narrow passages or steep
slopes.
The advantage of this search method is that the search
times are generally short.
The disadvantage is that the mower can leave tracks in
the grass along the length of the guide wire.
3012-483
3012-484
3012-677
1157068-26,265ACX_GB.book Page 16 Friday, November 28, 2014 9:06 AM

English - 17
2. PRESENTATION
2.4 More than one Automower®in
a garden
If you install more than one Automower®in the same
area of lawn, each mower must have its own PIN code.
A complete installation, including charging station, is
required for each mower. The boundary wires for the
different installations can be routed next to each other.
Contact your dealer for further information.
2.5 One Automower®in several
gardens
One Automower®can easily be used for more than one
garden, where each garden has its own charging
station and boundary wire. The mower can then have
the same PIN code for all gardens.
Contact your dealer for further information.
2.6 GPS communication unit
Automower®GPS communication unit contains two
main functions;
1. The SMS feature allows you to communicate with
the Automower®via SMS. In this way, one can
alter settings as well as start and stop the mower
remotely and as required. The mower sends an
SMS if it should stop working.
2. GPS anti-theft protection offers increased
protection and control of the Automower®. If the
mower is moved outside the preset protection
area, an SMS alert message is sent. New SMS
are sent with updated location details as the
Automower®is moved. The movement can be
followed using an online map service by entering
the positioning data provided in the SMS.
1157068-26,265ACX_GB.book Page 17 Friday, November 28, 2014 9:06 AM

18 - English
3. INSTALLATION
3. Installation
This chapter describes how you install Husqvarna
Automower®. Before starting the installation read the
previous chapter 2. Presentation.
Read the whole of this chapter too before starting the
installation. How the installation is made also affects
how well Automower®will work. It is therefore important
to plan the installation carefully.
Planning is simplified if you make a sketch of the
working area, including all obstacles. This makes it
easier to see the ideal positions for the charging
station, boundary wire and guide wire, if used. Draw on
the sketch how the boundary wire and the guide wire, if
used, should be routed.
Carry out the installation in the following steps:
3.1 Preparations.
3.2 Installation of the charging station.
3.3 Charging the battery.
3.4 Installation of the boundary wire.
3.5 Connecting the boundary wire.
3.6 Checking the installation.
3.7 Linking Automower® to the charging station.
3.8 Installation of the guide wire.
To carry out a complete start-up of Automower®the
charging station must be in position and connected, the
boundary wire connected, and the mower connected to
the charging station. If you would like to start the
mower without having completed the full boundary
installation, you can connect a temporary short loop
around the mower.
3.1 Preparations
1. If the lawn in the proposed working area is taller
than 10 cm, mow it using a normal lawn mower.
Then collect the clippings.
2. Read carefully through all the steps before the
installation.
3. Check that all parts for the installation are
included:
The numbers in brackets refer to the detail
diagram 2.1 Automower®, what’s what? on
page 12.
• Operator’s Manual (27)
• Automower®
• Charging station (16)
• Transformer (20)
• Low voltage cable (21)
3012-1028
1157068-26,265ACX_GB.book Page 18 Friday, November 28, 2014 9:06 AM

English - 19
3. INSTALLATION
• Screws for the charging station (24)
• Measurement gauge (25)
• Connector for the loop wire (23)
• Solderless coupler for the loop wire (26)
Contact your dealer to purchase the following
installation material:
• Loop wire for the boundary wire and guide wire
(19)
• Staples (22)
During installation you will also need:
• Hammer/plastic mallet to simplify putting the
staples in the ground.
• Combination pliers for cutting the boundary
wire and pressing the contact units together.
• Polygrip (for pressing the couplers together).
• Edge cutter/straight spade if the boundary wire
must be buried.
3.2 Installation of the charging
station
Best charging station location
Take the following aspects into consideration when
identifying the best location for the charging station:
• Allow for 3 metres of free space in front of the
charging station
• Close to a wall socket. The supplied low voltage
cable is 20 metres long.
• A level surface to place the charging station on.
• Protection from water spray for instance from
irrigation
• Protection from direct sunlight
• Place in the lower part of a working area that
has a major slope
• Possible requirement to keep the charging
station out of sight for outsiders
• Any aesthetic preferences
For examples of where best to install the charging
station, see 7. Garden example on page 64.
If you are going to install a guide wire, read 3.8
Installation of the guide wire, see page 35, before
choosing the position of the charging station.
3018-057
1157068-26,265ACX_GB.book Page 19 Friday, November 28, 2014 9:06 AM

20 - English
3. INSTALLATION
The charging station must be positioned with a great
deal of free area in front of it (at least 3 metres). It
should also be positioned centrally in the working
area so that Automower®can easily find the charging
station and quickly reach all parts of the working area.
It is a good idea to place the charging station in the
shadow. The battery is spared if it is charged in the
lowest possible ambient temperature.
The charging station must be positioned on relatively
level ground. The height difference must not differ
more than 5 cm between the front and rear of the
charging station.
The charging station must not be positioned so that
its plate bends.
Consider the distance to a wall socket when choosing
the position. The charging station should be
connected to a 230V wall socket via the low voltage
cable and transformer. The supplied low voltage
cable is 20 metres long.
Tip! It is possible to let the low voltage cable cross
the working area. It must then be either stapled down
or buried. In some cases there is a better positioning
option for the charging station than close to a house
wall or by the closest wall socket.
The transformer must be placed where it is well
ventilated and is not exposed to direct sunlight. It is
also beneficial if the transformer can be placed under a
roof.
It is recommended to use an earth fault-breaker when
connecting the transformer to the wall socket.
IMPORTANT INFORMATION
The low voltage cable must not under any
circumstances be shortened or extended.
IMPORTANT INFORMATION
The mains cable on the transformer must not
be replaced. In those cases the mains cable
has been damaged, the transformer must be
discarded and replaced by a new one.
3012-510
3012-554
3012-532
3012-1029
3012-223
1157068-26,265ACX_GB.book Page 20 Friday, November 28, 2014 9:06 AM
