Husqvarna SG13 Guide

S E R V I C E
Spare parts
Ersatzteile
Pièces détachées
Reserve onderdelen
Repuestos
Reservdelar
I0500034
IPL, SG13, 2005-02, 544 06 05-01
12
SG13
544 06 05-01
968 99 92-39
Manual no. 539109259 Rev. 01

DECK ASSEMBLY
12
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
34
35 36
37
38
10
19
23
23
12
11
12
11
20
10
31
9
33

DECK ASSEMBLY
ITEM PART NO. QTY.DESCRIPTION
1........ 539 10 93-16........1........ DECK
2........ 540 02 02-21........2........ BRACKET, KIT (INCLUDES ONE BRACKET &
HARDWARE)
3........ 539 10 93-21........1........ HANDLE, LOWER
4........ 539 02 00-24........1........ BRAKE, CALIPER
5........ 539 10 86-49........1........ BRACKET, HANDLE POSTIONING
6........ 539 02 00-82........2........ PIN, HANDLE ADJUSTMENT
7........ 539 10 92-83........1........ FENDER
8........ 539 99 05-63........4........ HCS 3/8-16 X 1, GR5
9........ 539 99 05-46........8........ NUT 3/8-16, CENTER LOCK
10...... 539 99 05-17........9........ WASHER, 3/8, FLAT
11...... 539 97 69-34........14...... HCS 5/16-18 X 3/4, GR5
12...... 539 99 01-84........14...... NUT 5/16-18, CENTER LOCK
13...... 539 02 00-94........1........ DEFLECTOR, NEOPRENE, REAR
14...... 539 20 07-81........1........ STRAP, DEFLECTOR
15...... 539 02 00-84........1........ DEFLECTOR, SIDE, NEOPRENE
16...... 539 02 00-74........1........ WHEEL W/DISC, 12” SNOW HOG
17...... 539 02 00-85........1........ AXLE
18...... 540 02 00-25........1........ WHEEL, 12” SNOW HOG
19...... 539 02 00-28........2........ SET COLLAR, 3/4” BORE
20...... 539 99 07-61........3........ NUT 1/4-20, CENTER LOCK
21...... 539 10 02-66........1........ HCS 1/4-20 X 1 1/4, GR5
22...... 539 99 00-52........2........ LOCKWASHER, 1/4
23...... 539 99 05-98........6........ WASHER, 1/4, FLAT
24...... 539 99 05-80........2........ HCS 1/4-20 X 3/4, GR5
25...... 539 10 93-89........2........ HCS 3/8-16 X 3 1/2, GR5
26...... 539 99 01-30........2........ NUT 3/8-16
27...... 539 02 00-20........1........ CLUTCH, CENTRIFUGAL, 2-GROOVE
.......... 539 1107-62 ........1........ KIT,SNAP RINGS & BEARINGS (NOT SHOWN)
.......... 539 1107-63 ........1........ KIT,CLUTCH SHOES & SPRINGS (NOT SHOWN)
28...... 539 91 70-33........1........ KEY, 1/4 SQ X 2 1/2”
29...... 539 99 01-64........1........ HCS 3/8-24 X 1 1/2, GR5
30...... 539 00 04-27........1........ WASHER 1/2, FLAT
31...... 539 99 01-18 ........5........ LOCK WASHER, 3/8
32...... 539 99 03-65........2........ COTTER PIN
33...... 539 99 02-50........2........ WASHER 1/2, SAE FLAT
34...... 539 99 09-23........4........ RHSNB 3/8-16 X 1 3/4, GR5
35...... 539 02 00-92........1........ DEFLECTOR, EXHAUST
36...... 539 10 84-95........3........ SCREW #8-32 X 3/8, SELF TAP, PHIL
37...... 539 99 06-92........9........ WASHER 5/16, FLAT
38...... 539 02 00-34........2........ SPRING, COMPRESSION

UPPER HANDLE BAR
1
2
3
4
5
6
7
8
9
10
11
12 13
14
15 16
17
18
19
20
21
22
23
24
9
15
25
27
26
25
25
28
29
30
31
32
33
34
22
22

UPPER HANDLE BAR
ITEM PART NO. QTY.DESCRIPTION
1........ 539 10 99-51........1........ HANDLE W/DECAL, UPPER
2........ 539 10 26-78........1........ PLATE, TAPPED
3........ 539 02 00-17........1........ SWITCH, NC PLUNGER TYPE
4........ 539 02 00-16........1........ SWITCH, TOGGLE
5........ 539 02 00-41........1........ BOOT,TOGGLE SWITCH
6........ 539 10 87-92........2........ NUT 5/16, PUSH CAP
7........ 540 02 02-01........1........ BAIL KIT (ALSO INCLUDES ITEM 6 & 23)
8........ 539 10 73-60........2........ LOCKWASHER 5/16
9........ 539 10 85-35........4........ SCREW #10-24 X 3/4, SLTD RD
10...... 539 10 86-47........1........ HANDLE, POSITION ADJ.
11...... 539 10 90-89........1........ RIVET, SNAP-MALE HALF
12...... 539 10 90-90........1........ RIVET,SNAP-FEMALE HALF
13...... 539 10 29-98........1........ WASHER, FRICTION
14...... 539 97 69-34........1........ HCS 5/16-18 X 3/4, GR5
15...... 539 99 01-84........2........ NUT 5/16C, CENTER LOCK
16...... 539 10 92-79........1........ BUSHING
17...... 539 97 69-38........1........ HCS 5/16-18 X 2 1/4, GR5
18...... 539 10 89-95........1........ HANDLE, WHEEL BRAKE
19...... 539 10 89-96........1........ GRIP, PARK BRAKE
20...... 539 02 00-23........1........ THROTTLE CONTROL W/KNOB
21...... 539 97 69-77........2........ NUT #10-24, NYLOC
22...... 539 99 03-65........4........ COTTER PIN
23...... 539 02 00-35........1........ SPRING
24...... 539 1108-65 ........1........ GRIP, BLACK VINYL
25...... 539 99 05-17........11...... WASHER 3/8, FLAT
26...... 539 99 05-88........4........ HCS 3/8-16 X 2, GR5
27...... 539 99 05-46........4........ NUT 3/8C, CENTER LOCK
28...... 539 10 89-92........1........ ROD, PARK BRAKE
29...... 539 97 64-81........1........ YOKE, 3/8F
30...... 539 10 01-02........1........ SPRING, COMPRESSION
31...... 539 10 89-75........1........ PIN, CLEVIS 1/4 X 7/8
32...... 539 97 69-88........1........ PIN, HAIR, 5/64 X 1 7/16
33...... 539 10 86-48........1........ ROD, POSITION ADJUSTMENT
34...... 539 99 01-88........2........ WASHER 5/16, SAE FLAT

1
2
3
4
5
6
8
9
10
11
12
13
14 15
16
17
7
5
5
6
BELT COVER

BELT COVER
ITEM PART NO. QTY.DESCRIPTION
1........ 539 91 02-10........1........ KEY 1/4 SQ X 2
2........ 539 1114-01 ........1........ PULLEY, TAPERLOCK, 2V
3........ 540 02 02-13........1........ BELTGUARD BACK
4........ 539 10 82-13........1........ PLATE, COVER
5........ 539 99 06-92........14...... WASHER 5/16, FLAT
6........ 539 99 01-84........6........ NUT 5/16C, CENTER LOCK
7........ 539 10 83-98........4........ HCS 5/16-24 X 1, GR5
8........ 539 10 85-05........1........ HCS 3/8-16 X 5 1/2, GR5
9........ 539 99 05-17........1........ WASHER 3/8 FLAT
10...... 539 99 01-87........4........ LOCKWASHER 3/8
11...... 539 10 93-32........3........ NUT 3/8-16, JAM
12...... 539 20 07-51........1........ V-BELT, “B” SECT. SET OF 2
13...... 540 02 02-12........1........ COVER, BELTGUARD
14...... 539 99 01-18 ........3........ LOCKWASHER 3/8
15...... 539 10 87-46........3........ NUT 3/8-16, ACORN
16...... 539 02 00-89........1........ DEFLECTOR, NEOPRENE, LEFT SIDE
17...... 539 97 69-34........4........ HCS 5/16-18 X 3/4, GR5

SHROUD AND BLADE ASSEMBLY
1
2
3
4
5
6
7
8
9
10

SHROUD AND BLADE ASSEMBLY
ITEM PART NO. QTY.DESCRIPTION
1........ 540 02 02-25........1........ KIT, CUTTING WHEEL SHROUD (includes)
................................................... SHROUD W/DECAL
................................................... BOLT, 3/8-16 X 1 (4 EA)
................................................... LOCKWASHER 3/8 (4 EA)
................................................... WASHER 3/8, FLAT(4 EA)
2........ 539 02 02-26........1........ BEARING, FLANGE (includes)
................................................... BEARING (1 EA)
................................................... BOLT3/8-16 X 1 3/4 (4 EA)
................................................... NUT 3/8, LOCK (4 EA)
3........ 539 02 02-27........1........ CUTTING WHEEL ASSEMBLY(NO TEETH)
4........ 539 02 02-28........1........ COMPLET SET OF CUTTING TEETH (includes)
................................................... COUNTER BORE POCKET (4 EA)
................................................... THREADED POCKETS (4 EA)
................................................... LEFT TOOTH (4 EA)
................................................... RIGHT TOOTH (4 EA)
................................................... SOCKET HEAD SCREWS (8 EA)
5........ 539 02 02-29........1........ RIGHT TOOTH
6........ 539 02 02-30........1........ LEFT TOOTH
7........ 539 02 02-31........1........ COUNTER BORE POCKET
8........ 539 02 02-32........1........ THREADED POCKET
9........ 539 02 02-33........1........ SOCKET HEAD SCREW (2 EA)
................................................... TWO SCREWS ARE REQUIRED PER POCKET
10...... 539 20 07-52........1........ CUTTING TEETH, COMPLETE (includes)
................................................... RIGHT TOOTH (4 EA)
................................................... LEFT TOOTH (4 EA)
.......... 539 1101-44 ........1........ ALLEN WRENCH, 1/2” X 8” (NOT SHOWN)

DECALS
1
2
3
4
5
6
7
8
9
10
11
13
12
14
15

DECALS
ITEM PART NO. QTY.DESCRIPTION
1........ 539 1110-46 ........1........ DECAL, LOGO HUSQVARNA
2........ 539 1110-44 ........1........ DECAL, CROWN
3........ 539 20 08-30........1........ DECAL, ON/OFF
4........ 539 10 89-87........1........ DECAL, HANDLE ADJUSTMENT
5........ 539 10 57-43........1........ DECAL, NO STEP
6........ 539 1110-60 ........1........ DECAL, SG13A STUMP GRINDER
7........ 539 10 18-81........1........ DECAL, PROP 65
8........ 539 00 83-69........1........ DECAL, DANGER FOOT
9........ 539 20 08-29........1........ DECAL, THROTTLE
10...... 540 20 01-26........1........ DECAL, EAR AND EYE WARNING
11...... 540 20 00-27........1........ DECAL, CAUTION LIST
12...... 539 10 97-02........1........ DECAL, CE968999239
13...... 539 10 50-71........1........ DECAL, NASCAR
14...... 539 20 07-62........1........ DECAL, 107DBA SOUND POWER
15...... 539 1105-90 ........1........ DECAL, OPN STUMP GRINDER

WIRING DIAGRAM
ENGINE ON/OFF
SWITCH
(DISCONNECTED)
COLOR CODE:
Y - YELLOW
B - BLACK
SPARK
PLUG
TRANSISTOR
IGNITION
MODULE
OIL LEVEL
GUARD
ENGINE HARNESS
109299
CONSOLE HARNESS
109298
ON/OFF
SWITCH
SAFETY
SWITCH
Y
B
B
B
Y
B
Y
B
Y
B
Y
B
