Hussmann impact Excel C2X-LGE Instruction Manual

HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
B
F
A
D
E
C
F
E
F
P/N 0398676C
Merchandisers
®
Note: Changed items have been underlined.
C2-XLGE
Technical Data Sheet
P/N 0398676C
NSF®Certified
February 2006
We reserve the right to change or revise specifications
and product design in connection with any feature of
our products. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
Item Part # Description Wiring Item #
FAN ASSEMBLIES AND THERMOSTATS
A. 6W Fan Assembly (1)
0058698 Fan Motor, Evaporator
0142780 Fan Blade
embossing toward motor
B. 0311588 Standard Non-adjustable (2)
Defrost Thermostat
C. 0137880 Optional Adjustable (3)
Refrigeration Thermostat
Item Part # Description Wiring Item #
HEATERS
D. Canopy Anti-Sweat Heater (4)
NA 4 ft
0109417 6 ft
0109417 8 ft
0109418 12 ft
LAMPS AND BALLASTS
E. Ballast, Electronic (5)
0376409 2 lamps
0376410 3 lamps
F. Fluorescent Lamp (6)
Replace with like fixtures
Revision C corrects statistical data on Page 3.

2 of 8 C2-XLGE Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Engineering
Plan Views
B
C
72 1/4(1835)
Elec. Waste Outlet
4
(102)
34 5/8
(881)
46 1/2
(1182)
38 7/8
(98 6)
29 1/4
(743)
30 5/8
(778)
D
27 5/8
(703)
Refrig.
A
Water Seal
(see note)
C2XLGE
73/4(199)
Skid/ External Base
Front
Dimensions shown as inches and (mm).
Dairy / Delicatessen
Precut & Packaged
Produce
05-2003
4 ft 6 ft 8 ft 12 ft
General
(A) Case Length (without ends or partitions) 48 1/4(1226) 72 3/8(1838) 96 3/8(2448) 144 1/2(3670)
(Each end and insulated partition adds 1 1/2 in. (38 mm) to case line up.)
Maximum O/S dimension of case
back to front (includes bumper) 46 1/2(1182) 46 1/2(1182) 46 1/2(1182) 46 1/2(1182)
Back of case to front of splashguard 38 7/8 (986) 38 7/8 (986) 38 7/8 (986) 38 7/8 (986)
Back of case to O/S edge of front skid rail 29 1/4 (743) 29 1/4 (743) 29 1/4 (743) 29 1/4 (743)
Width of skid rail 4 1/2 (114) 4 1/2 (114) 4 1/2 (114) 4 1/2 (114)
RH end of case to outside edge of external support 5 1/2(140) 5 1/2(140) 5 1/2(140) 5 1/2(140)
Distance between edges of external and center supports NA 31 1/8 (790) 40 5/8 (1032) 40 5/8 (1032)
Distance between edges of center supports 41 1/4 (1048) NA NA 44 (1118)
Stub-up area between front skid rail and splashguard 7 3/4 (199) 7 3/4 (199) 7 3/4 (199) 7 3/4 (199)
Electrical Service (Electrical Field Wiring connection point)
(B) RH End of case to center of farthest knockout 38 1/4 (972) 64 3/8 (1635) 88 3/8 (2245) 136 1/2 (3467)
Back O/S of case to center of knockout 34 5/8 (881) 34 5/8 (881) 34 5/8 (881) 34 5/8 (881)
Length of electrical raceway 16 1/8 (410) 34 1/2 (876) 35 5/8 (903) 35 5/8 (903)
Waste Outlet
(C) RH End of case to the center of waste outlet 24 1/8 (613) 24 1/8 (613) 24 1/8 (613) 72 1/4 (1835)
LH End of case to the center of waste outlet 24 1/8 (613) 48 1/4 (1226) 72 1/4 (1835) 72 1/4 (1835)
Water Seal
Edge of water seal to center of waste outlet 4 (102) 4 (102) 4 (102) 4 (102)
Outside diameter of the drip pipe 1 1/2 (38) 1 1/2 (38) 1 1/2 (38) 1 1/2 (38)
NNoottee::Water seal outlet must clear front skid rail.
Refrigeration Outlet
Back of case to center of refrigeration outlet 30 5/8 (778) 30 5/8 (778) 30 5/8 (778) 30 5/8 (778)
(D) RH end of case to center of refrigeration outlet 9 (230) 9 (230) 9 (230) 9 (230)

REFRIGERATION DATA
Note: This data is based on store temperature
and humidity that does not exceed 75°F and
55% R.H.
C2-XLGE
Discharge Air (°F) 29
Evaporator (°F) 21
Unit Sizing (°F) 19
Btu/hr/ft* C2-XLGE
Parallel 1080
Conventional 1155
*For all refrigeration equipment other than
Hussmann, use conventional Btu values.
DEFROST DATA
C2-XLGE
Frequency (hr) 6
Defrost Water (lb/ft/day) 7
(± 15% based on case configuration and
product loading).
OFFTIME C2-XLGE
Temp Term (°F)48°F
Failsafe (minutes) 30
ELECTRIC OR GAS Not Recommended
Standard Defrost Thermostat
Close on rise: close 48°F — open 33°F
CONVENTIONAL CONTROLS
Low Pressure Backup Control
C2-XLGE
CI/CO** 17°F / 7°F
Indoor Unit Only, Pressure Defrost
Termination** 48°F
**Use a Temperature Pressure Chart to
determine PSIG conversions.
PHYSICAL DATA
Merchandiser Drip Pipe (in.) 1 1/2
Merchandiser Liquid Line (in.) 3/8
Merchandiser Suction Line (in.) 7/8
Estimated Charge (lb)***
4 ft 1.3
6 ft 1.8
8 ft 2.3
12 ft 3.3
***This is an average for all refrigerant types.
Actual refrigerant charge may vary by
approximately half a pound.
3 of 8
P/N 0398676C HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
6 1/8
(155)
(Note:* Optional Accessory Items)
19
(483)
3 3/4
(95)
(Note*)
12
(305)
(Note*)
18
(457)
C2XLGE
36 3/4
(933)
55 1/8
(1400)
18
(457)
(Note*)
(Note*)
(Note*)
30 1/8
(766)
FAN
C
O
I
L
26
(661)
7 3/4
(199)
5 3/8
(136)
27 5/8(703)
29 1/4(743)
30 5/8(778)
34 5/8(881)
38 7/8(986)
46 1/2(1182)
14 1/8
(359)
Dimensions shown as inches and (mm).
Multi-deck, 4 Display Levels
NSF Certification
These merchandisers are manufactured to meet ANSI /National
Sanitation Foundation (NSF ®) Standard #7 requirements.
Impact C2-XLGE
Dairy / Delicatessen
Precut & Packaged Produce
C2-XLGE

4 of 8 C2-XLGE Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Impact C2-XLGE
Dairy / Delicatessen
Precut & Packaged Produce
Electrical Data
4 ft 6 ft 8 ft 12 ft
Number of Fans 1 2 2 3
Amperes Watts
4 ft 6 ft 8 ft 12 ft 4 ft 6 ft 8 ft 12 ft
Evaporator Fan
120V 60Hz Standard 0.51 1.00 1.00 1.50 38 78 78 117
120V 50Hz Standard 0.55 1.10 1.10 1.65 42 84 84 126
230V 60Hz Export 0.25 0.50 0.50 0.75 40 80 80 120
230V 50Hz Export 0.28 0.56 0.56 0.84 44 88 88 132
120V 60Hz Energy Efficient 0.26 0.52 0.52 0.78 18 36 36 54
230V 60Hz Energy Efficient NA
Canopy Anti-sweat Heaters NA 0.75 0.75 1.00 45 90 90 120
Minimum Circuit Ampacity
120V 60Hz Standard 0.71 1.95 1.95 2.70
120V 50Hz Standard 0.75 2.05 2.05 2.85
230V 60Hz Export 0.45 1.45 1.45 1.95
230V 50Hz Export 0.48 1.51 1.51 2.04
120V 60Hz Energy Efficient 0.46 1.47 1.47 1.98
230V 60Hz Energy Efficient NA
Maximum Over Current Protection 120V 20 20 20 20
Maximum Over Current Protection 230V 15 15 15 15
Standard Lighting
1 Row Canopy 0.26 0.51 0.51 0.77 30 59 59 85
Optional Lighting
Additional 1 Row Canopy 0.26 0.51 0.51 0.77 30 59 59 85
Additional 2 Row Canopy 0.51 1.02 1.02 1.54 59 118 118 170
1 Row Rail Light 0.26 0.51 0.51 0.77 30 59 59 85
1 Row Ledge Light 0.26 0.51 0.51 0.77 30 59 59 85
Optional Shelf Lighting
1 Row Shelf Receptacle 0.26 0.51 0.51 0.77 30 59 59 85
2 Row Shelf Receptacle 0.51 1.02 1.02 1.53 59 118 118 177
115V Lighting Circuit Total = Standard Lighting + Total Optional Lighting + Optional Shelf Lighting
230V Lighting Circuit Total = Multiply 115V Lighting Circuit Total by 0.52

5 of 8P/N 0398676C HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Defrost
Termination
Thermostat Refrigeration
Thermostat
Dark Blue
3
}
Light Blue
2
To
Condensing
Unit
Grayed components in 12 foot models only.
R = Red Y = Yellow G = Green BL = Blue B = Black W = White
= 120V POWER = 120V NEUTRAL = Field GROUND
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS
Fan Wiring
Offtime Defrost
120V NEUTRAL
BROWN BAND
120V POWER
Fans 1
BROWN BAND
1, 2 & 3 Fans
4 ft
6 ft
8 ft
12 ft
= Case GROUND
Connector
Connector
G
Connector
Connector Connector
Connector Connector
Optional Shelf Harness and Light Circuits
for One Row of Shelves
120 V
Power
B
W
G
B
BL
BL
BL G
G
RR
BL BL G
W
BL
Shelf Harness
Shelf Light Circuits
BL
G
R
6
5
W
BL R
6
BL R
G
G
R
R
R
G
Shelf Lighting
G G
R
BL
6
BL
Connector
Connector
B
Purple BAND 4
120V Power
Purple BAND
120V Neutral
Anti-Sweat Heater
G
Canopy
Anti-Sweat Heater

6 of 8 C2-XLGE Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Standard Lighting 1 Row Canopy or Optional 1 Row Rail
Light Circuits
Optional Lighting 2 Rows Canopy
120V NEUTRAL
ORANGE OR TAN BAND
W
Light
Switch
120V POWER
ORANGE OR TAN
BAND
B
B
WBL
R
R
BL
BL
5
BL
R
R
BL
BL
5
66
6
6
66
120V NEUTRAL
ORANGE OR TAN BAND
W
Light
Switch
120V POWER
ORANGE OR TAN
BAND
B
BL
R
R
BL
BL
5
66
R
R
6
Grayed components in 12 foot models only.
R = Red Y = Yellow G = Green BL = Blue B = Black W = White
= 120V POWER = 120V NEUTRAL
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS
R

7 of 8P/N 0398676C HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
SHELF CONFIGURATION
This merchandiser is designed for
one, two or three shelves.
The depth of the shelf used in the
top eight (8) shelf hole locations
is critical to case performance.
If a shelf is placed in one of the
top eight (8) locations it must
comply with the angle/depth
requirements listed below.
Maximum Shelf
Shelf Angle Depth
0 º 12 in.
15 º 14 in.
or less
30 º 18 in.
or less
45 º 18 in.
or less
NOTE: Shelves placed in the
lower positions may be up to
18 in. deep when positioned
at a 0 º angle.
Top Eight (8)
Shelf Hole
Locations
18 in.
18 in.
14 in.
12 in.
0°
15°
30°
45°
Angle
Maximum
Shelf
Size
18 in.
0°
Impact C2-XLGE
Dairy / Delicatessen
Precut & Packaged Produce

C2-XLGE Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
8 of 8
Impact C2-XLGE
Dairy / Delicatessen
Precut & Packaged Produce
Screws
Screws
Ballast
Foil-covered
Anti-sweat
Heater
Canopy
Canopy
Anti-Sweat Heater Wires
with Purple Markers
Electrical
Wireway
CANOPY AND SHELF LAMP BALLAST
The ballast for the canopy and shelf lamps is
located behind the canopy on the left-hand end
(when facing case) of the merchandiser.
To access the ballast:
1. Remove screws at bottom edge of canopy and
rear of top panel.
2. Remove the canopy by pulling it forward.
3. Remove the top panel by lifting it up.
4. Service or replace ballasts as required.
5. Reassemble items as they were originally
installed.
NOTE: Rail lamp ballast is located behind the
lower front panel.
CANOPY ANTI-SWEAT HEATER
The canopy anti-sweat heater location is shown
below. Connections are in the electrical wireway.
