C6X-EP
Technical Data Sheet
P/N 0480158_C
NSF®Certified
March 2008
We reserve the right to change or revise specifications
and product design in connection with any feature of
our products. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
Item Part # Description Wiring Item #
FAN ASSEMBLIES
4 Ft, 8 Ft & 12 Ft
A. 12W Standard Fan Assembly (1)
0047000 Fan Motor, Evaporator
(MO.4410103)
0461805 Fan Blade (FB.4780446)
12W Energy Efficient Fan Assembly (1)
0477655 Fan Motor, Evaporator
(MO.4410546)
0461805 Fan Blade (FB.4780446)
6 Ft Only
A. 7W Standard Fan Assembly (1)
0058698 Fan Motor, Evaporator
(MO.4410102)
0142780 Fan Blade (FB.0142780)
7W Energy Efficient Fan Assembly (1)
0477654 Fan Motor, Evaporator
(MO.4410545)
0142780 Fan Blade (FB.0142780)
Item Part # Description Wiring Item #
THERMOSTATS
B. Optional Adjustable Refrigeration Thermostat (2)
LAMPS. BALLASTS, LED FIXTURES AND POWER SUPPLY
C. Ballast, Electronic (3)
0480130 2 lamps (BA.4481676)
0480131 3 lamps (BA.4481654)
0480132 4 lamps (BA.4481677)
D. Fluorescent Lamp (4)
Replace with like fixtures
E. 0501213 Power Supply (EP.4481861) (5)
F. LED Fixture (6)
Replace with like fixtures
©2008 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
Note: Revision C changes ballast (Page 1); adds optional LED lighting (Pages 1, 3, 4, 8); adds capacity and weight (Page 5).

2 of 9 C6X-EP Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Engineering
Plan Views
Dimensions shown as in. and (mm).
Convertible
09-2005
NOTE: Case-to-Case Electrical Connections
are made IN FRONT OF SPLASHGUARD.
4 3/4 (120)
Splashguard
31 5/8
(804)
42
(1064)
A
41 1/2
(1054)
3 In.
(77 mm)
Required
Air Gap
Refrigeration
Outlet
Electrical
Stub Up Area
6 x 6
(152x152) Waste Outlet
Waste Outlet
FRONT
26 1/4
(665)
B
D
8(203)
4 1/2 (115)
12 1/8 (307)
41 1/2
(1054)
43 7/8
(1114)
C
Wireway
4 3/4 (120)
26 1/2
(673)
4 1/4 (108)
24
(612)
33 1/2
(851)
Electrical
Field
Connection
30 1/4
(768)
C6X
4 ft 6 ft 8 ft 12 ft
General
(A) Case Length (without ends or partitions) 48 3/8(1229) 72 3/8(1838) 96 3/8(2448) 144 1/2(3670)
(Each end and insulated partition adds 1 1/2 in. (38 mm) to case line up.)
Maximum O/S dimension of case back to front
(includes bumper) 42 (1064) 42 (1064) 42 (1064) 42 (1064)
Back of case to front of splashguard 33 1/2 (851) 33 1/2 (851) 33 1/2 (851) 33 1/2 (851)
Back of case to O/S edge of front leg 30 1/4 (768) 30 1/4 (768) 30 1/4 (768) 30 1/4 (768)
Distance between edges of external legs and center legs NA 29 1/2 (750) 41 1/2 (1054) 41 1/2 (1054)
Distance between edges of center legs NA NA NA 43 7/8 (1114)
Distance between front legs and splashguard 2 3/4(70) 2 3/4(70) 2 3/4(70) 2 3/4(70)
Electrical Service (Electrical Field Wiring connection point)
(B) RH End of case to center of stub up area 36 1/4 (921) 60 1/4 (1530) 84 1/4 (2140) 132 3/8 (3363)
Back of case to center of stub up area 24 (612) 24 (612) 24 (612) 24 (612)
Length of electrical wireway 26 1/2 (673) 26 1/2 (673) 26 1/2 (673) 26 1/2 (673)
(C) RH End of case to LH end of wireway 42 1/8 (1070) 66 1/8 (1680) 90 1/8 (2289) 138 1/4 (3511)
Waste Outlets (One each end)
(D) RH End of case to the center of LH waste outlet 36 1/4 (921) 60 1/4 (1530) 84 1/4 (2140) 132 3/8 (3363)
RH End of case to the center of RH waste outlet 12 1/8 (307) 12 1/8 (307) 12 1/8 (307) 12 1/8 (307)
Back O/S of case to center of waste outlets 31 5/8 (804) 31 5/8 (804) 31 5/8 (804) 31 5/8 (804)
Schedule 40 PVC drip pipe 1 1/4(32) 1 1/4(32) 1 1/4(32) 1 1/4(32)
Refrigeration Outlet
Back of case to center of refrigeration outlet 26 1/4 (665) 26 1/4 (665) 26 1/4 (665) 26 1/4 (665)
RH end of case to center of refrigeration outlet 8 (203) 8 (203) 8 (203) 8 (203)
PHYSICAL DATA
Merchandiser Drip Pipe (in.) 1 1/4
Merchandiser Liquid Line (in.) 3/8
Merchandiser Suction Line (in.) 7/8
Wireway

REFRIGERATION DATA
Note: This data is based on store temperature and
humidity that does not exceed 75°F and 55% R.H.
C6X-EP DAIRY/DELI/PRODUCE†
UNLIT LIT
Discharge Air (°F) 33 31
Evaporator (°F) 28 26
Unit Sizing (°F) 26 24
†For red meat application, lower evaporator
temperature and unit sizing 3°F. increase Btu 5%.
Btu/hr/ft — Unlit Shelves
C6X-EP‡‡ Parallel Conventional
UNLIT 1405 1465
‡‡ Add 10 Btu/hr/ft per shelf row for LED fixtures.
Add 20 Btu/hr/ft per shelf row for fluorescent lamps.
DEFROST DATA
C6X-EP
Frequency Hrs 12
Defrost Water (lb/ft/day) 10.5
(± 15% based on case configuration and product
loading).
OFFTIME C6X-EP
TIME (minutes) 30
ELECTRIC OR GAS Not Recommended
CONVENTIONAL CONTROLS
Low Pressure Backup Control
CI/CO*
C6X-EP DAIRY/DELI/PRODUCE††
Temp (°F) 19°F / 9°F
Indoor Unit Only, Pressure Defrost
Termination* 48°F
*Use a Temperature Pressure Chart to determine
PSIG conversions.
††For red meat application, reduce low pressure
backup control by 3°F.
Estimated Charge (lb)** C6X-EP
4 ft 1.9
6 ft 2.6
8 ft 3.7
12 ft 5.1
**This is an average for all refrigerant types.
Actual refrigerant charge may vary by
approximately half a pound.
3 of 9
P/N 0480158_C HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
31 5/8 (804)
4 3/4 (120)
30 1/4 (768)
42 (1064)
33 1/2 (851)
30 1/4
(768)
42
(1064)
56 1/2
(1435)
FAN
C
O
I
L
C6X-EP
21 1/4
(540)
3 In. (77 mm)
Required
Air Gap
87 3/8
(2219)
7 1/4 (183)
23 5/8
(600)
3 5/8
(92)
26 1/4 (665)
Refrigeration
Outlet
4 7/8
(123)
Electrical
Case to Case
Connections 17 1/8
(436)
67 1/8
(1704)
Impact Excel C6X-EP
Dairy/Delicatessen/Produce
Dimensions shown as in. and (mm).
Multi-deck, 6 Display Levels
NSF Certification
This merchandiser model is manufactured to meet ANSI/NSF
(National Sanitation Foundation) Standard #7 requirements for
construction, materials & cleanability.

Electrical Data
4 ft 6 ft 8 ft 12 ft
Number of Fans—12W 2 — 4 6
Number of Fans—7W — 4 — —
Amperes Watts
Evaporator Fan 4 ft 6 ft 8 ft 12 ft 4 ft 6 ft 8 ft 12 ft
120V 60Hz Standard 1.30 2.00 2.60 3.90 100 156 200 300
120V 50Hz Standard 1.50 2.20 3.00 4.50 114 168 228 342
230V 60Hz Export 0.66 1.00 1.32 1.98 100 156 200 300
230V 50Hz Export 0.76 1.12 1.52 2.28 114 168 228 342
120V 60Hz Energy Efficient 0.60 0.76 1.20 1.80 36 56 72 108
230V 60Hz Energy Efficient 0.30 0.40 0.60 0.90 36 56 72 108
Minimum Circuit Ampacity
120V 60Hz Standard 1.50 2.20 2.80 4.10
120V 50Hz Standard 1.70 2.40 3.20 4.70
230V 60Hz Export 0.86 1.20 1.52 2.18
230V 50Hz Export 0.96 1.32 1.72 2.48
120V 60Hz Energy Efficient 0.80 0.96 1.40 2.00
230V 60Hz Energy Efficient 0.50 0.60 0.80 1.10
Maximum Over Current Protection 120V 20 20 20 20
Maximum Over Current Protection 230V 15 15 15 15
Standard Lighting (T-8 Fluorescent)
1 Row Canopy 0.26 0.51 0.51 0.77 30 59 59 85
Optional Lighting (T-8 Fluorescent)
Additional 1 Row Canopy 0.26 0.51 0.51 0.77 30 59 59 85
Additional 2 Row Canopy 0.51 1.02 1.02 1.54 59 118 118 170
Additional 3 Row Canopy 0.77 1.53 1.53 2.31 89 177 177 255
1 Row Rail Light 0.26 0.51 0.51 0.77 30 59 59 85
Optional Shelf Lighting (T-8 Fluorescent)
1 Row of Shelves 0.26 0.51 0.51 0.77 30 59 59 85
2 Rows of Shelves 0.51 1.02 1.02 1.54 59 118 118 170
3 Rows of Shelves 0.77 1.53 1.53 2.31 89 177 177 255
4 Rows of Shelves 1.02 2.04 2.04 3.08 118 236 236 340
5 Rows of Shelves 1.28 2.55 2.55 3.85 148 295 295 425
6 Rows of Shelves 1.53 3.06 3.06 4.62 177 354 354 510
Optional Always*Bright LED Lighting
1 Row of Shelves 0.15 0.19 0.26 0.38 18 23 31 45
2 Rows of Shelves 0.26 0.34 0.47 0.67 31 41 56 80
3 Rows of Shelves 0.38 0.53 0.74 1.11 45 63 89 133
4 Rows of Shelves 0.47 0.68 0.93 1.40 56 82 112 168
5 Rows of Shelves 0.57 0.83 1.13 1.69 68 99 136 203
6 Rows of Shelves 0.67 0.96 1.33 2.00 80 115 160 240
120V Lighting Circuit Total = Standard Lighting + Total Optional Lighting + Optional Shelf Lighting
230V Lighting Circuit Total = Multiply 120V Lighting Circuit Total by 0.52
4 of 9 C6X-EP Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Impact Excel C6X-EP
Dairy/Delicatessen/Produce

ESTIMATED SHIPPING WEIGHT 5
Case Solid End
4 ft 6 ft 8 ft 12 ft (each)
lb (kg) 600 (272) 1000 (454) 1200 (544) 1900 (862) 100 (45)
5Actual weights will vary according to optional kits included.
5 of 9P/N 0480158_C HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
Impact Excel C6X-EP
Dairy/Delicatessen/Produce
Product Data
ARI Refrigerated Volume 1 (Cu Ft/Ft) 12.81 ft3/ft (1.19 m3/m)
Recommended Usable Cube 2 (Cu Ft/Ft) 9.79 ft3 /ft (0.91 m3 /m)
ARI Total Display Area 3 (Sq Ft/Ft) 4.92 ft2/ft (1.50 m2 /m)
Shelf Area 4(Sq Ft/Ft) 11.73 ft2/ft (3.58 m2 /m)
1Computed using ARI 1200 standard methodology: Refrigerated Volume, ft3[m3]/Unit of Length, ft [m]
2ARI Refrigerated Volume less shelving and other unusable space: Refrigerated Volume/Unit of Length, ft3/ft [m3/m]
3Computed using ARI 1200 standard methodology: Total Display Area, ft2[m2]/Unit of Length, ft [m]
4Shelf surface area is composed of bottom deck plus standard shelf complement, as shown in the Hussmann
Product Reference Guide. The standard shelf complement for this model is (5) rows of 22-inch shelves.eparately from
fans.

C6X-EP Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
6 of 9
Refrigeration
Thermostat
2
To
Condensing
Unit
}
Li
g
ht Blue
2, 4 & 6 Fans
120V NEUTRAL
BROWN BAND
120V POWER
Fans 1
BROWN BAND
4 ft
6 ft
8 ft
12 ft
4
4
3
3
3
4
4
4
4
4
4
Optional
Two Row
Canopy
Optional
Three Row
Canopy
Connector
4
BL
W
BL
W
G
R
BL
W
B
R
RR
BL BL
R
BL
R
RR
BL
BL
R
BL
R
RR
B
B
Orange or Tan Band
Standard Lighting 1 Row Canopy
Optional Lighting 2 Row Canopy
3 Row Canopy
4
344
Connector
W
B
BL
BL
R
BL
R
RR
Optional Lighting 1 Row Rail
B
4 ft 6 ft or 8 ft 12 ft
4 ft 6 ft or 8 ft 12 ft
R = Red Y = Yellow G = Green BL = Blue B = Black W = White
= 120V POWER = 120V NEUTRAL = FIELD GROUND
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS
= CASE GROUND
Fan Wiring
Offtime Defrost
Light Circuits

7 of 9P/N 0480158_C HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
4
R
BL
4
R
BL
BL
R
BL
R
4
R
BL
BL
3
4
4
4
B
W
BL
BL
R
BL
BL
BL
W
R
W
R
B
R
3
B
BL
BL
BL
R
R
R
R
4
R
BL
4
R
BL
BL
R
BL
R
4
R
BL
BL
R = Red Y = Yellow G = Green BL = Blue B = Black W = White
= 120V POWER = 120V NEUTRAL = FIELD GROUND
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS
= CASE GROUND
Optional Shelf Harness and Light Circuits for
Six Rows of Shelves
4 ft case
Connector
3
4
4
4
B
W
Connector
6 ft or 8 ft case
12 ft case
BL
BL
R
BL
BL
BL
W
R
W
R
B
R
3
B
BL
BL
BL
R
R
R
R
4
R
BL
4
R
BL
BL
R
BL
R
4
R
BL
BL
3
4
4
4
B
W
BL
BL
R
BL
BL
BL
W
R
W
R
B
R
3
B
BL
BL
BL
R
R
R
R
Optional Shelf Lighting
Fluorescent Fixtures

C6X-EP Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
8 of 9
4 ft case
6 ft or 8 ft case
12 ft case
R
BL
R
BL 6
6
RBL
5
B
W
W
BL
R
G
Connector
Connector
B
W
B
W
B
W
R
BL
R
BL 6
6
R
BL
R
BL
R
BL 6
6
RBL
R
BL
BL
BL
(TYP)
Shelf Light
Plug & Receptacle
R = Red G = Green BL = Blue B = Black W = White
= 120V POWER = 120V NEUTRAL = FIELD GROUND
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS
= CASE GROUND
Optional Shelf Harness and LED Light Circuits for
Two Rows of Shelves
R
R
B
Optional Shelf Lighting
LED Fixtures

9 of 9P/N 0480158_C HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
R
BL
R
BL
R
BL
R
BL
R
BL
R
BL
R
BL 6
6
6
6
6
6
6
RBL
5
B
B
W
W
BL
R
G
4 ft case
6 ft or 8 ft case
12 ft case
(TYP)
Shelf Light
Plug & Receptacle
B
Connector
R
BL
R
BL
R
BL
R
BL
R
BL
R
BL
R
BL 6
6
6
6
6
6
6
RBL
5
B
B
W
W
BL
R
R
BL
R
BL
R
BL
R
BL
R
BL
R
BL
R
BL 6
6
6
6
6
6
6
RBL
5
B
B
W
W
BL
R
R = Red G = Green BL = Blue B = Black W = White
= 120V POWER = 120V NEUTRAL = FIELD GROUND
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
CIRCLED NUMBERS = PARTS LIST ITEM NUMBERS
= CASE GROUND
W
Connector
Optional Shelf Harness and LED Light Circuits for
3, 4, 5, 6 & 7 Rows of Shelves
Optional Shelf Lighting
LED Fixtures
