THE HUSTLER BAC-VAC™ CATCHER
The 9-bushel fiberglass hopper empties from the driver’s seat and
features a flow-through venting system which provides superior
air movement and yet directs the dust down and away from the
operator providing a cleaner,more pleasant working environ-
ment.Fiberglass hopper is corrosion resistant and light in weight.
Plastic rear-door cover bounces back upon impact and is a further
weight saver.Blower and hopper can be added and removed in
just seconds so you can go from catching to side discharge in very
short order.
The BAC-VAC catcher fits on Mini Z and Super Mini Z models with
44”or 52”side-discharge decks and Hustler Z and Super Z models
with 52”,60”or 72”side-discharge decks.And,now Hustler Z XR-7
and Super Z XR-7 models with 54”,60”, 66”or 72”XR-7 Decks
SPECIFICATIONS
Capacity: 9 bushels
Dimensions: Mini Z and Super Mini Z
Overall Height: 53 in
Overall Length: 98 in
Overall Width: w/44 in deck: 56 in w/52 in deck: 64 in
Dimensions: Hustler Z and Super Z
Overall Height: 51 in
Overall Length: 104 in
Overall Width: w/52 in deck:65 in, w/60 in deck:71 in,w/72 in deck:82 in
Hopper Weight: 150 lbs.
Blower Assembly Weight: 75 lbs.
Blower Housing: .134 in thick abrasion resistant steel side wall;
.179 in thick steel top and bottom
Blower Impeller: .179 in thick abrasion resistant steel impeller blades;
.179 in thick backing plate
Blower Transfer Chute: .187 in thick polyethylene (black)
Blower Type: 11 in diameter,V-belt driven (“B”section)
Delivery Tube: Clear 6 in I.D.heavy-duty flexible polyvinyl-chloride tube
Hopper: .15 in thick reinforced fiberglass supported by steel frame
Hopper Rear Door Cover: .15 in thick polyethylene (black).
Specifications subject to change without notice.
Form No. 78 8158 6-06
Hustler Turf Equipment • Hesston, Kansas 67062 • 1-800-395-4757
For more information online : hustlerturf.com
Easy on, easy off — convert from catch
to side discharge in seconds!
