HXM HD-010C User manual

HD-010CDIGITALDRUM
USER SMANUAL

CAUTION
Any changes or modifications inconstruction ofthisdevice which arenot expresslyapproved by
thepartyresponsibleforcompliance couldvoidtheuser sauthoritytooperatethe equipment.
WARNING
When using electricalproducts,basicsafetyprecautions shouldalways be followed,including the
following:
NOTE:Thisequipment hasbeen testedandfound tocomplywiththe limitsforaClassBdigital
device,pursuanttoPart 15 of the FCC Rules.
Also, thisequipment hasbeentestedand found tocomplywiththelimitsfor followingstandard:
EN55022-2006
EN55024:1998/+A1:2001/+A2:2003
EN55013:2001/+A1:2003/+A3:2006
EN55020:2007
EN61000-3-2:2006
EN61000-3-3:1995/+A1:2001/+A2:2003
Theselimitsaredesignedtoprovide reasonableprotectionagainstharmfulinterferenceinaresi-
dentialinstallation.Thisequipment generates, uses, andcanradiateradiofrequencyenergyand,if
not installedandusedinaccordancewiththeinstructions, maycauseharmfulinterference toradio
communications. However, thereisno guaranteethatinterference will not occurinaparticular
installation.Ifthisequipmentdoes cause harmfulinterferencetoradioor televisionreception,which
canbedeterminedbyturningtheequipment offand on, theuserisencouragedtotrytocorrectthe
interferencebyoneormoreofthefollowingmeasures:
-Reorientorrelocatethe receiving antenna.
-Increase the separationbetween theequipmentand receiver.
-Connectthe equipment intoan outlet onacircuitdifferent fromthattowhichthe receiveris
connected.
-Consult thedealer oran experiencedradio/TV technician for help.
CAUTION

TAKINGCAREOFYOURDRUM
wdirect sunlight(nearawindow),
whightemperatures(nearaheatsource,
outside,orinacarduring thedaytime),
wexcessivehumidity,
wexcessivedust,
wstrongvibration.
wThedrumcontainsdigitalcircuitryand
maycauseinterferenceifplacedtoo
closetoradioortelevisionreceivers.If
interferenceoccurs,movethedrum
furtherawayfromthe affected
equipment.
POWER
wTurnthepowerswitchoffwhenthe
drumisnotinuse.
wToavoiddamagetothedrumandother
devicestowhichitisconnected,turn
thepowerswitchesofallrelated de-
vicesoffpriortoconnectionordiscon-
nection ofaudiocables.
wTurnthepoweroffifthemaincableis
damagedortheinstrumentisspattered
withliquid.
wDonot switchthe uniton andoffinquick
succession, thisplacesan undue load
ontheelectroniccomponents.
wUnplug the ACpowercordduringan
electricalstorm.
wAvoidplugging the ACadaptorintothe
sameACoutlet asapplianceswithhigh
powerconsumption,suchaselectric
heatersorovens.
SERVICE AND MODIFICATION
Thisproductshouldbeserviced byqualified
servicepersonnelwhen,
wthe powersupplycordortheplughas
been damaged,
wliquidhasbeenspattered intothe unitorit
hasbeenexposed torain,
wtheinstrumentdoesnotappeartooperate
normallyorexhibitsamarkedchangein
performance,
wtheinstrumenthasbeendroppedorthe
cabinethasbeen damaged.
wDonotattempttoopen theunitormake
anychangeinthecircuitsorpartsof the
unit.
HANDLINGAND TRANSPORT
wNeverapplyexcessiveforcetothe
controls,connectors,padsorotherparts
ofthe instrument.
wAlways unplug cablesbygripping the plug
firmly,notbypullingon the cable.
wPhysicalshocks causedbydropping,
bumping, orplacingheavy objectson the
instrumentcanresultinscratchesand/or
moreseriousdamage.
wCarefullycheck the amplifiervolume
controlbeforestatingtoplay.Excessive
volumecan causepermanent hearing
loss.
CLEANING
wCleantheunit withadryorlight-wet soft
cloth.Donot usepaint thinnerorpetro-
chemicalbased polishes.
LOCATION
Donot exposethedrumtothe following condi-
tionstoavoiddeformation,discoloration,or
moreseriousdamage,
DO NOTATTEMPTTOOPEN THEUNITOR MAKE ANYCHANGEINTHECIRCUITS OR
PARTS OFTHEUNIT.
!

CONTENTS TABLE
INSTALLATION .........................1
SOUNDMODULE ..........................5
ControlPanel..............................5
Back Panel.................................6
PLAYINPAD ....................................7
VOLUMECONTROL ....................................8
DRUMKIT .......................................9
SONG ...............................10
DemoSong .....................................10
UserSong ................................11
METRONOME ........................12
Metronome...........................12
Tempo ..................................12
DRUMKITEDIT ..........................13
Selectkitforediting ..................13
Enterthe EditMode .....................14
Selectpart toedit .....................14
Selectparametertoedit..........14
Edit theparameter.................15
Editanotherparameterorpart......15
Editotherparameterinthecurrentpart..15
Editanotherpart.......................15
Completethe edit...................16
STRIKINGCOUNT ..................17
SETUP .............................18
AccompanimentVolume........18
Percussion VolumeforDemoPlay...18
MasterTune .......................18
CountSesitivity..................18
Local.........................18
Equalizer...........................19
AdvancedParameter.........19
Sesitivity..................20
Headroom.......................20
TriggerCorve ...........................20
CrossTalk...........................21
Hi-Hatpedalsetup ................21
Reset............................23
RECORD ......................................24
Preparing..........................24
Record............................24
PlaybackUserSong...............25
Erase UserSong ..................25
MIDI &USB ............................26
KITLIST .........................28
VOICELIST ............................29
SPECIFICATIONS ..................32

INSTALLATION
Thediagramshowscompletedrum kitafterinstallation.
Each drumpad, cymbal pad andHi-Hatcontrol pedalhasitspart numberunderneaththepart name
foryour referenceininstallation.The partnumberisprintedinpart packingbox.
Poweradaptorandconnection cables arenotshowninthediagram.
*KICKPEDALISOPTIONALACCESORY
CRASH1
B-12Cymbal-edg CRASH2
B-12Cymbal-edg
RIDE
B-14Cymbal-edg-Bell
HI-HAT
A-8Hi-Hat
TOM1
B-8Tom
TOM2
B-8Tom
TOM3
B-8Tom
TOM4
B-8Tom
SOUND MODULE
HD-010B
SNARE
B-8Snare
HI-HATCONTROLPEDAL
B-HH Ctrl
KICK
B-8Kick
KICKPEDAL
P-6B KickPedal
RACKSYSTEM
RACKC
1

Youcan findall componentsinpackage.
AllpipeswithclampkitattachedareinRACKSYSTEMbox,exceptright,left lagand snarearm
without clampkit, which isinCLAMPbox.
Take off all partsfrompackage.Insert pipesintorelevantclampasshowninthedaigram, fastenwing
nuttosecurethem.
INSTALLATION
These clamps areinthe CLAMPbox
Wing nut
RACKINSTALLATION-1
2

INSTALLATION
Pleasenote:Hi-Hatrodis different
fromride/crashrod.
RACKINSTALLATION-2
1Loosen wing nutsinthe clamp,
adjustthepositionofthearmand
legs,then tighten the wing nuts
2 Loosen wing nut in the
clamp.Movethecross
beamto properlocation,
then tighten the wingnuts
3Loosen wing nutsin
the clamp. Rotate the L-
Rodand cymbalsupport
rod to properposition, then
tightenthewing nuts
Adjustarm,legandcrossbeamtoproperposition.InsertL-rods andcymbalsupport rodsintorel-
evantclampasshowninthe diagram, thenadjust theirpositions.
3

INSTALLATION
1. Alignholesinthesupportandstand2
then insertboltsandfastenwithattached
2.Insert tongue4ofthe kick standintoslotof
thepedal
3.Align holesinthe tongueandthepedal,then
insert boltsand fastenwithattachedkey..
1
Kick Installation
1. Align holes inthe sound moduleand the modelmountthen insert
screwsand fastenit.
2. Insertrodofthemodelmountintotheclamp,thentightenthe wing
nut.
Sound module Installation
Please refertothe SOUNDMODULEChapterforelectronicconnection.
Electronic Connection
P-6B
4
Finalizing the Installation
Afterinstallallcomponents,fineadjust the arm,clampsandrods to
thebestposition youdesire.
2
1
3
3
2
3
11.Remove thewing nut,
washer and felt pad from the
topoftherod.
3.Loosen the side wing nut,
adjustthe angleoftherod
then re-tighten the wing nut.
1.Remove thewing nut,
washer and felt pad from the
topoftherod.
3. Loosen theside wing nut,
adjusttheangleoftherod
thenre-tightenthewingnut.
1.Loosen the wingnut,
place the snareon the
snareinstallation snare
L-Rod.
2.Putthe Hi-Hatintothe
rod,thenplacebackparts
removedinthestep 1.Re-
tightenthewingnut.
2. Adjust the angleand height ofthe
snarepadthentightenthewingnut.
Hi-Hat Installation
Crash and Ride Installation
Snare Installation
1.Loosen the wingnut,
placethe tompad on
theinstallationL-Rod.
2.Adjustthe angleand
heightofthetompad
thentightenthe wing
nut.
Tom Installation
COMPONENTSINSTALLATION
2.Putthe cymbalpad intothe
rod,then placebackpartsre-
movedinthestet1.Fasten
thewingnutbutnottootightly.
It allowsthe padalittlebitwob-
blinglikerealacoustic
cymbal.
4.Loosenthewingnutonthe
clamp,adjustthe heightofthe
rod thenre-tighten the wing
nut.
4.Loosen the wing nuton the
clamp,adjusttheheightof
therod then re-tighten the
wingnut.
4
2
1
3
4
4

(1) LCDDisplay: Information displaysuchasKitnumber and name,Song nameetc.
(2) KITButton: Enter the Drum kitscreen and select kit
(3) SONG Button: Enterthe Song mode toplay demoorUsersongs
(4) SequencerButtons: RecordButton,Pressit toenter the recordwindow
Play/StopButton
ThePlay/Stop buttonisusedinbothSongandRecordoperations.Pleaserefer torelevantchap-
tersfordetailedinformation.
(5) COUNTButton: Enter the Count mode totest howfastyou can strike
(6) CLICK Button: Metronomeswitch andedit
(7) TEMPOButton: Changemetronometempo
(8)DATA+/- Knob: Rotatetheknobtochangedataforall operations.The knobiswithpush
switch,whenpush the knobdown,the switch will be on.Pressthe knob downthen rotateit to
adjustmastervolumeinthe KitSelectionandSongwindow.Pushingdowntheknob can function
as ENTERbutton.
(9) ENTER Button: Confirm your operating
(10)EXITButton: Exit totheprevious window or returntothe Kit Selection window
(11) SETUPButton: EntertheSetupmodeand setparameters
(12)EDITButton: EntertheKit Editmodeandeditparameters
(13)MODE Button: Change Demoplaying mode
(14)PadSelectButtons: Selectapadand itspart foredit intheEdit mode.Thesearedual-
functionbuttons.IntheKitSelectmode,they areused forkit quick selection.
SOUND MODULE
CONTROLPANEL
1
10
11
13
12
143
5
2
8
6
7
4
9
5

BACK PANEL
SOUNDMODULE
1
2
3
4
6
7
8
5
910
(1)PowerSwitch: TurnOn/Offthe sound module
Note:Whenyouturnthepower off, donotturnit onimmediately.Waitat least five secondstoturn
the poweron so that the electroniccircuitscan properlyreset.
(2)PowerInJack: Plug inthe DC cableoftheattachedadaptor
(3) USB Jack: The USB connectorallowsyou toconnect the drumdirectlytoyourcomputer s
USB port.The USB interface iscompatiblewithWindowsXP/Vista,Windows7and MAC. The
computer will recognize the drumas AudioDevice. Pleasesee the MIDI &USBchapterof this
manualfordetails
(4) MIDI Jack: MIDIjacks allowcommunication withother productsequippedwithMIDI
interfaces.Please see theMIDI&USB chapterof thismanualfordetails
(5) HeadphoneJack: Thedrumhasstereo headphonejack.You can play intotal silence without
disturbing othersintheroom bypluggingaset ofheadphones intothe jack.
(6)HeadphoneVolumeKnob: Rotateit toadjustthe headphone volume
(7)LineInJack: LineInstereo audioinput jackwillmixthesuppliedsignal withtheinternaldrum
sound. It can be used tohook up itemssuch as CD players,MP3player etc.
(8)LineOutJack: Thereisnobuilt-inspeakerinthe drum. LineOutstereo audiooutputsupplies
thedrumoutputsignal toexternal amplification,suchas homestereo,PA systemorotherstand
alone amplifiers. If you connectwithexternalmono system,useL/MONO outputandstereo/mono
adapterisrecommended.
(9) PadTriggerConnector: Eachpad and Hi-Hat controlpedalhaslabeled cable. All cablesare
merged intoasingleconnector.Pluginthe cableintojack ofcorrespondingcomponent, Then,plugin
theconnectorhere.
(10)Expanded Pad TriggerJack: Plug inthe cableofthe Tom4intothe AUX1and the Ride intothe
AUX2.
6

Playing CymbalBell
Strikethebell atthelarge ridecymbal make
symbal bell sound.
PLAYINPAD
TURNONTHE POWER
(1) Adjustvolumeof externalaudiodevice
connected withthedrumtolowerlevel.
(2) Press the POWER button whiledon t strike
pad orpress theHi-Hatcontrol pedal.
(3) Turnon external devices connected.
(4)Strike padandadjustthevolumetoproper
level.
PLAYINGPADS Playing SnareDrum
Strikethe central position (head) ofthepad to
make headsound,strikethe rim of thepad to
make rimsound.Therearetworimportions with
differentrimsound.Also,thereisamarkon the
padtoindicatetheportion.
Playing Cymbal
Strike thecentral position(bow)of the cymbal
tomake cymbal bowsound,strike the edgeof
thecymbal tomakeedgeshotsound.
Cymbal Choke
Strike acymbal, itssound will sustain. Then
squeezetheedge portiontomutethesound.
Please notethattheHi-Hathas no choke
feature.
Bow
All pads have striking force sensitivityfeature.
Strikethe padhardertomakehighervolume
andstrikethepad softer tomake lower
volume.
Playing TomDrum
Strikethe central position (head) ofthepad to
make headsound,strikethe rim of thepad to
makerimsound.
Playing Kick Drum
Press the Kick drum pedaltomake kick
drumsound.
Head
Ri
m2
Rim1
M
a
r
k
Head
Rim
Edge
PlayingHi-Hat
(1) Strike the Hi-Hatpad withoutpressingthe Hi-
Hat controlpedal tomakeopen Hi-Hat sound.
(2)Strike theHi-Hat padwithfullypressingthe
Hi-Hat control pedaltomake close Hi-Hat sound.
(3)Strike the Hi-Hat padwhilepressing theHi-
Hatcontrolpedal graduallytomake consecutive
open toclose Hi-Hatsound.
(4)Press theHi-Hat pedaldownquicklytomake
Hi-Hatpedal sound.
7

VOLUME CONTROL
MASTERVOLUME
Inthe Kitand Song window, pushtheDATAknobto
enterthe MasterVolumecontrol window.The current
volumelevelwill beblinking. Rotatethe DATA knobto
change the mastervolumeranged0- 127.Press the
EXITbutton, orafterabout5secondswithoutany
adjustment, itwill returntothepreviouswindow.
HEADPHONEVOLUME
Adjustthe headpnonevolumebyrotatingtheHEAD-
PHONEVOLUMEknob inthe back panel.
MasterVolume
115
MastervolumeVolumeindicator
+
8

Insomeotheroperation modes, you may press
theKITbuttontoenterthekitselect operation
mode.
PRESETKIT
Thepresetkitnumberisranged01 -55.
RotatetheDataknobtoselect akit youdesire.
Rotatetheknob clockwisetoincrease the kit
numberand anticlockwise todecrease the kit
number.Allpresetkitnumberandnamearelisted
intheAppendixKITLIST.
Note: Normally,strikingthe drumpad makes
singlesound.WhenyouplaytheTomrimorKick
withKit22/23/24/25/26,an additionalvoicewill
be addedtothe basicdrumsound.The additional
sound iscomposed inasequencerforthese spe-
cifickits.Eachtimeyouplaythepad,theaddi-
tionalsound will change insequence.
USERKIT
You can createyourownuserkitbyeditfunction.
ClicktheKITbuttonrepeatedlywillswitchthe
PresetKitand UserKitselection.The UserKit
numberis56 -90;the UserKitnameisUserKit01
- UserKit30.
RotatetheDataknob toselectan userkit you
desireinthe samewayabove.
Thefactorysettingfor allUserKitsisthe same
as presetkit 01.You couldcall them evenif you
don tcreateyourownuserkit.Ofcourse,you
couldreplace itby editing.Please see <EDIT>
Chapterinthismanualfordetails.
QUICKSELECTION
Inthe Kitmode,tenpad selection buttons arede-
fined asquick kitselectionbuttons.Each one is
assigned toamostcommon use kit.Simplypress
abutton toselect kit directly.Thedefault quick
selectionassignmentislisted intheAppendix
<KITLIST>.
Afteryouselectakit,youcanassignit toaquick
KIT 01
Standard
DRUM KIT
Kitnumber
Kitname
Kit56
UserKit01
UserKitname
Thereare55presetdrumkitsand 35UserKits.Thekit iscombinationofdifferentinstrumentvoice
assigned toeach pad which hasunitarystyleforperformance. All thekitsareforyour choice. Any
kit couldbe edited and saved as yourownUser Kit.
Afterpoweronand displayinitial information,it llenterthekitselectionmodeautomaticallywhilethe
KITbuttonindicatorwill lightup.The kitnumber anditsnamewillbe displayed.
Kitnumber
selection button by pressing and holding down
theKITbuttonthenpressingapadbutton.
Yourassignmentisnonvolatileeventhe
powerturnsoff.
Note: These buttonsaredual-func-
tion buttons.When use themas
quick kitselectbuttons, theindica-
toroftheEDITbutton must beoff,
Please see <EDIT>Chapterinthis
manualfordetails.
1
2
3
5
6
7
8
9
10
4
+
+
9

+
Press the SONG button and itsindicator will
lightsup.The songwindowwill appear. Thereare
twotypes of song: Demonstration song and User
Song which isrecorded by yourself.
1. DEMO SONG
(1) Select and Play Demo Song
Therearemany demosongsbuiltin.The name
and number ofdemosong, playingstatus,tempo
and timesignatureappear on the display.Rotate
the DATE knob tochoose asong.
Thenpressthebuttontostartplay;thebutton
indicatorlightsup.
When the demosongisplaying,pressthe
button againtostopthe playing, the indicator
turns off.
(2) Demo Song Playing Mode
Therearefourmodes toplaysong:
PLAY 1- Playing selected song once
REPEAT1- Playing selected song repeatedly
PLAY ALL- Play all songs
REPEATALL - Playing all songs repeatedly
Pressthe SONGbutton twice toenterthe play
modewindow. RotatetheDATEknobtochange
theplayingmode.
Thescreenwill turnback totheprevious window
automaticallyafterabout3seconds, orpressthe
EXITbuttontoexitimmediately.
(3) Practice with Demo Song
You may practice your ownperformance withthe
demosong.
Therearethreepracticemodes foryourchoice:
FULL -Whenpress thebutton,youwillhear
completesong
DRUM ONLY- When pressthe button, you
will hear drumsoundonly.It helpsyoutogetidea
howtoperformdrum.
DRUM MUTE - Whenpress the button,you
willhearbackgroundmusicwithoutdrumsound.
Then, you can play drumsby yourself.
Press the MODEbuttonrepeatedlytochange the
practice mode.
Thescreenwill turnback totheprevious window
automaticallyafterabout3seconds, orpressthe
EXITbuttontoexitimmediately.
Tip: Volumeofdrumand background musicis
adjustable.Pleaserefertothe Chapter<SETUP>
formoreinformation.
SONG 1002/4
01BaiaoDe2
Demo SongNumber
PlayingstatusTempo
PLAY MODE
PLAYALL
Thecurrent playing mode
SONG
Song Name
SONG u102 4/4
28TangoDance
Demo SongNumber
Playing statusTempo TimeSignature
Song Name
PLAYPART
DRUM MUTE
Thecurrentpracticemode
TimeSignature
10

SONG
UserSong01
Usersongname
Playingstatus
2.USER SONG
Youcanrecordyourperformanceandsaveit as
Usersong.When select songby the DATE knob,
afterthe lastpresetdemosong, thenextsong fol-
lowedwill be the firstUsersong.HD-010Ccan
record15User songs.
Tip: You may rotatethe the DATE knob
anticlockwise toreach User Songfaster.
Thedisplaywill showsongnameandplayingstatus.
If thereisno usersongrecorded,itwill show
“*Free*”.
Thewayofthe Usersong playingisthesameas
Demosongplaying.The playing mode isalsoavail-
ableforUsersong.
SONG
+
11

+
+
+
CLICK 0964/4
ON
Tempo
On/Off status
CLICK
VOLUME
Parameter
METRONOME
1.METRONOME
Press theCLICK button toswitch the metronome
On/Offwhilethecurrent tempo,timesignatureand
On/Off status will bedisplayed.After about5
seconds, thiswindowwill exit automatically.
Inthe metronomewindow, pressthe ENTER
buttonorpushdowntheDateknobtoenterthe
metronomesetting window.Thereare3parameters
canbeedited,theyaremetronomevolume,time
signatureandmetronomesound.Rotatethe
DATA knobtochoose aparameter toeditthen
press the [ENTER]toconfirm. The parametersare
listedbelow.
RotatetheDATAknobtochangethe setting as
listed below. PresstheEXITbutton toexit the
andbacktothemetronomeparameterselect
window;press theEXITbutton againtoexitthe
metronomewindow.
Timesignature
CLICK
VOLUME 102
Parameter Setting
Metronome Parameters:
VOLUME-Metronomevolumeranged0-127,thedefault settingis100
TIMESIGNATURE-1-12/2, 1-12/4,1-12/8,1-12/16, Thedefaultsetting is4/4
SOUND- Metronomesound,ENG representsEnglish,CHNrepresentsChinese,METrepresents
click sound. The default settingisMET
2. TEMPO
Pressthe TEMPO button,thecurrent tempovalue
willblink. Rotatethe DATAknobtochangethe
temporanged40-260. Thedefault is96.
Afterabout 3seconds,it will returntotheprevi-
ous window automatically.
TEMPO096
NOTE: PushtheDataknob as abuttoncan
implementthesamefunctionaspressthe
ENTERbutton inmanyoccasions.Thisisan
easierwaytoenteryoursetting.Inthis
manual, press the[ENTER] meanspress
eithertheENTERbutton or theDATAknob.
12

Thisfeaturemakes itpossibletochange thecurrentlyselected drumkitsetting.Inthisway, you
may createyour owndrum kit and save it as UserKit.
Theeditprocedureisthesameforeveryparameter, afteryouarefamiliarwiththeoperation of
voice assignment; it ll beeasytoeditotherparameters.
Thefollowing section isthe editproceduretakingexamplehowtochange voicefor apad.
1. Selectkit forediting
Selectakitfor editinginthesameway explained inthe DRUMKITchapter. Thedisplayshowsthe
kitnumberand kitname.
KIT 01
Standard
Adrum kit consistsof drumpads, cymbalspads and Hi-Hatpedalphysically, which generatesound
indifferentway such as by striking headorrimofdrumpad,striking cymbal bowor edge, press-
ingHi-Hatpedal. Wecall the sourcetogeneratesoundasPart, forexample, thepart generating
sound by striking the headofTom1padisdisplayedonthescreenasTom1,thepart generating
soundbyHi-Hat control pedalisdisplayedon thescreenas Pedal Hi-Hat etc.The detailed
descriptionislisted inTable1below.
Each parthas multiparameterstodetermine itssound characteristics such as voice, volume,
reverblevelandpanetc.TheseparametersarelistedInTable2.
Theedit featureistoset parameterforeach part,partlyorforallpartsinakit. Obviously,assigning
voice tothe part ismostimpotant function.Thisdrumhas totally492 voices canbe selectand
assigned withthisfunction.
Snare-R2-Rim2ofSnare
Crash-HeadofCrash
Crash-R-EdgeofCrash
Ride -HeadofRide
Ride-R-EdgeofRide
OpenHiHat-Hi-Hat open
CloseHiHat-Hi-Hatclose
PedalHiHat-Hi-HatPedal
Kick -Kick
DRUMKIT EDIT
Tom1-HeadofTom1
Snare-R1-Rim1ofSnare
Snare-Headof Snare
Crash2 -Head ofexpended Crash
Crash2-R-Edge ofexpended Crash
Ride-B-BellofRide
!
Table1
Tom1-R-RimofTom1
Tom2-HeadofTom2
Tom2-R-RimofTom2
Tom3-HeadofTom3
Tom3-R-RimofTom3
Tom4-HeadofexpendedTom
Tom4-R-Rim ofexpendedTom
13

+
Snare-R2
VOICE Snare-s1
1
Snare-R2
VOICE
Parametername
PartName (SnareRim2)
Snarepad
EditMode
2.EntertheEditMode
PressEDITbuttontoengagetheedit mode.Theindi-
catorwill lightup.
3.Selectpart toedit
Pressapad selection button toselectapad.Some
pads have twoor moreparts, for example, the snare
havehead, rim1andrim2parts. Thedefaultpartfora
padishead orbow.
Pressthe padselection button repeatedlyand the part
will switchwithinvalidpartsone by one.Forexample,
pressthe SNARE button once,the partisSnare
(Head);press theSNARE buttontwice,thepart
changes toSnare-R1;pressthe SNARE button again,
the part will changetoSnare-R2. The part namewill
apear onthefirst row ofthedisplay.Pleaserefer to
Table1fordetails.
UsetheEXPANDbuttontoselectTom4
and the Ride. Press the EXPAND buttonrepeatedly,
the part namewill changeone by oneuntil thepart
you desireappears.Please refertoTable1fordetails.
Or,simplystrikethe properportionof apadwithnor-
malstrenthtoselectthepartdirectly.SelecttheHi-
Hatcontrolpedal bypressingitdowntothebottom.
4.Selectparametertoedit
Thecurrentparameterisblinking.RotatetheDataknob
toselectaparametertoedit. Inthisexample,select
VOICE.
Press the ENTER button orpushdowntheDateknob
toconfirm youchoice.The currentvalue/contentsof
thisparameterwill blink.
NOTE: PushtheDataknob as abutton can
implementthesamefunctionas press theENTER
buttoninmanyoccasions.Thisisaneasierway
toenteryoursetting.Inthismanual,press the
[ENTER] meanspresseithertheENTER buttonor
theDATAknob.
Parametertoedit
PartName (SnareRim2)
DRUMKIT EDIT
Snare
VOICE
PartName (Snarehead)
Tom4-R
VOICE
PartName (Tom4Rim)
!Note:
14

5.Edit theparameter
RotatetheDataknob tochangevalue/contentsof
the parameter. Inthisexample,you ll change voice
assignedtoSnare-R2.Anyparameterhasitsown
range toset. Forexample,thereare492 voices
canbeselectedtoassigntoapart,referringto
AppendixVOICE LIST.
Note: When you editthe voice forthe Tomrim or
KickwithKit 22/23/24/25/26,theadditionalvoice
inthesequencerwill not bechanged.
Snare-R2
VOICE Snare-S2
Parametername
PartName (Rim2 forSnare)
parameter
6. Edit anotherparameterorpart
Now,the firstparameter(the VOICEinthis
example)editingforaselected part isfinished.You
maycontinuetoeditotherparametersfor thispart
orchangepart toedit.
(1) Edit other parameter in the current part
Pressthe EXITbutton,the screen will back tothe parametr selection windowwiththeparameter
nameblinking.Then,selectapart by rotating the DATA knob.Then,editparametersinthe sameway
above.
Parameterscan beeditedarelisted below:
Snare-R2
VOLUME 110
Parametertoedit
PartName (Rim2 forSnare)
DRUMKIT EDIT
Table2
(2) Edit another part
Press the oneofthe padselection button and itsindicatorwill lightup.The partnamewill display on
the screen. The current parametertoedit will keep no change. Inthisway,you couldedit the same
parameter (itisVoiceinthisexample)for each part.Press the samebutton repeatedlytoswitch to
anotherpart,ifnecessary.
Or, simplystrike the proper portioninthe realpad toselectthepartdirectly.
Thedrumkitstill keepsnochange inall operationsabove.
+
+
PARAMETER
DESCRIPTION
EDITRANGE
VOICE Voice assigned tothepart 1 –492
VOLUME Volumeofthepart
0~127,127 referstothehighest
volume
PAN Stereo panofthe part -64~63,0referstocentreposition, -64to
the mostleftand 63 tothe mostright
position
PITCH Pitch ofthepart -10~10,0referstostandardpitch,-10to
the
lowestand 10tothehighest pitch
REVERB Reverbeffect levelofthepart0~127,127 referstothehighest level
15

+
7.Completetheedit
Afterfinish allediting forthe currentdrumkit, no mat-
ter singleor multiplepart/parameter, you cantermi-
natetheedit.
PresstheEXITbutton repeatedlyuntil “SaveSetups
to ”on the screen.Then, you have twochoices:
(1)Saveedited drumkitas yourownuserkit:Rotate
theDateknobtoselectanuserkit numberranged
56 UserKit01 to90UserKit35.Press [ENTE]to
confirm. Theeditedresultsaresaved as desiredUser
kitthen exitthe editmodeandreturntothe Kit window.
Theuserkit settingisnonvolatileeventhe powerturns
off.
(2) Press theEXITbutton toexit the edit modeand
returntotheKit window.Alltheeditedresultswillbe
discarded.
SaveSetupsto
58UserKit03
Select a Userkit to save
youreditresults
SaveSetupsto
56UserKit01
DRUMKIT EDIT
16
