XD-750C
DIGITAL DRUM
USER
’
S MANUAL
CAUTION
Any changes or modifications in construction of this device which are not expressly approved by
the party responsible for compliance could void the user’s authority to operate the equipment.
WARNING
When using electrical products, basic safety precautions should always be followed, including the
following:
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
Also, this equipment has been tested and found to comply with the limits for following standard:
EN55022-2006
EN55024:1998/+A1:2001/+A2:2003
EN55013:2001/+A1:2003/+A3:2006
EN55020:2007
EN61000-3-2:2006
EN61000-3-3:1995/+A1:2001/+A2:2003
These limits are designed to provide reasonable protection against harmful interference in a resi-
dential installation. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION
direct sunlight (near a window),
high temperatures (near a heat source,
outside, or in a car during the daytime),
excessive humidity,
excessive dust,
strong vibration.
The drum contains digital circuitry and may
cause interference if placed too close to radio
or television receivers. If interference occurs,
move the drum further away from the affected
equipment.
POWER
Turn the power switch off when the drum is
not in use.
To avoid damage to the drum and other
devices to which it is connected, turn the
power switches of all related devices off
prior to connection or disconnection of
audio cables.
Turn the power off if the main cable is
damaged or the instrument is spattered with
liquid.
Do not switch the unit on and off in quick
succession, this places an undue load on
the electronic components.
Unplug the AC power cord during an
electrical storm.
Avoid plugging the AC adaptor into the
same AC outlet as appliances with high
power consumption, such as electric
heaters or ovens.
SERVICE AND MODIFICATION
This product should be serviced by qualified
service personnel when,
the power supply cord or the plug has been
damaged,
liquid has been spattered into the unit or it has
been exposed to rain,
the instrument does not appear to operate
normally or exhibits a marked change in
performance,
the instrument has been dropped or the
cabinet has been damaged.
Do not attempt to open the unit or make any
change in the circuits or parts of the unit.
HANDLING AND TRANSPORT
Never apply excessive force to the controls,
connectors, pads or other parts of the
instrument.
Always unplug cables by gripping the plug
firmly, not by pulling on the cable.
Physical shocks caused by dropping,
bumping, or placing heavy objects on the
instrument can result in scratches and/or
more serious damage.
Carefully check the amplifier volume control
before stating to play. Excessive volume can
cause permanent hearing loss.
CLEANING
Clean the unit with a dry or light-wet soft cloth.
Do not use paint thinner or petrochemical
based polishes.
LOCATION
Do not expose the drum to the following condi-
tions to avoid deformation, discoloration, or more
serious damage,
TAKING CARE OF YOUR DRUM
!
!DO NOT ATTEMPT TO OPEN THE UNIT OR MAKE ANY CHANGE IN THE CIRCUITS OR
PARTS OF THE UNIT.
CONTENTS TABLE
INSTALLATION
SOUND MODULE
PLAYIN PAD
BEFORE START PERFORMANCE
BASIC OPERATION
SETUP
DRUM KIT EDIT
SPECIFICATIONS
APPENDIX
20
20
2
20
1
INSTALLATION
CRASH1
CRASH2
RIDE
TOM1
TOM2
TOM3
SNARE
HI-HAT
KICK
2
INSTALLATION
This is the view of all separated parts. Match each part to its number and set up
the drums according to the diagram on next page.
RACK INSTALLATION - 1
④
⑤⑥
②
①
③
③③
⑥
⑥
⑤⑤②
④
①
①
1.Stretch the drum rack according to the
picture and install both legs①. Take off the
rubber foot on middle left leg, and insert the
snare bracing-rod into it. After that put the
rubber foot back on. Make sure the drum
rack stand upright and then fasten wing
nuts.
2.Install crash connector clamps⑥ on middle
legs.Then insert crash stands③ to their
clamps. Fasten their wing nuts.
3.Insert Ride stand② to its clamp.Fasten its
wing nut.
4.Insert hex rod sleeves⑤ to pad clamps on
the drum rack.
5.Insert hex rods④ into hex rod sleeves⑤.
6.Adjust all parts to a comfortable position
when playing seated. Make sure all parts are
fasten tight and then install drum pads
according to next page.
④④
④
⑤
⑤
4
INSTALLATION
RACK INSTALLATION - 3
This diagram shows the completely installed drum rack.
Please check the rack with part numbers before you start pad installation.
③③
⑥
⑥
⑤⑤②
④
⑤
①
①
⑤
④④
④
5
INSTALLATION
1. Align holes in the support stand ① and pad ②,
then insert bolts and fasten with drum key(attached).
2. Insert tongue ③ of the kick stand into slot of the
pedal .
3.Adjust to a suitable position, and then fasten the
wing nut on the kick pedal.
Kick Installation
1. Align holes in the sound module and the model mount then insert
screws and fasten it.
2. Insert rod of the model mount into the clamp, then tighten the wing nut.
Sound module Installation
Finalizing the Installation
After install all components, fine adjust the arm, clamps and rods to the
best position you desire.
Electronic Connection
Connect the trigger connector cable plug to the bottom of the sound
module, and then connect all cable heads according to their name tags.
2
3
1. Remove the wing nut, washer and felt pad from the top of the rod.
3. Adjust the pad position then re-tighten the wing nut.
Cymbal Installation
COMPONENTS INSTALLATION
2. Put the cymbal pad into the rod, then place back parts removed in the
step 1. Fasten the wing nut but not too tightly. It allows the pad a little bit
wobbling like real acoustic cymbal.
2
1
3
1. Adjust the support hex rod to suitable position.
2. Loosen the bottom wing nut of the pad and insert it to the support hex rod. Push
the wing nut up a little bit and shake the pad to insert it successfully.
3. Fasten the bottom wing nut after the pad is adjusted to the suitable position
Snare & Tom pad Installation
1
INSTALLATION
6
COMPONENTS INSTALLATION
①
②
③
②
④
⑤
1.Insert Felt② to the Base①,align the socket to the
stopper underneath Cymbal③,and then insert Fixing
Base① to Cymbal③
2.Install Felt②,Round Nut④ on the Base① according
to the picture
3.Fix the Head⑤ to the Base①
HiHat Installation
1. Open HiHat Stand Legs① to suitable position and
make it standfirm.
2. Insert Thin Rod② into screw thread on the Bottom
Stand according to dashed line here, and rotate it
clockwise to fasten it.
3. Place Hollow Rod③ outside Rod②, and insert it into
Bottom Stand.
4. Insert HiHat Cymbal Tray④ onto Thin Rod② and place
it aboveHollow Rod③
5. Adjust Hollow Rod③ to suitable height and fasten
it. Insert HiHat Cymbal onto Thin Rod②. Make sure there is
enough space between the Cymbal and Tray④, and then
fasten the screw on Cymbal.
Note: If there is not enough space between Cymbal
and Tray④, the HiHat control function will be very short in
range or even notresponding.
①
②
③
④
⑤
