HYBREX GDS-1280N User manual

GDS-1280N
1280 Ports
Enterprise Class
Communication System
Installation Manual

- 2 -
Issue 1.1 – June 2007
Notification
Notification is hereby given that Auto Telecom Company Ltd. reserves the right to modify, change, update or
revise this document from time to time as required without the prior obligation to notify any person, company or
organization. Further, Auto Telecom makes no warranty or representation, either express or implied, with respect
to merchantability, or fitness of its products for a particular purpose.
◎2007 Auto Telecom Company Ltd.
This document or any parts thereof are not to be reproduced or transmitted in any form or by any means,
electronic or mechanical, including photocopying, recording, or information storage and retrieval systems for any
purpose whatsoever without the express written permission of Auto Telecom Company Ltd.

IMPORTANT SAFETY INSTRUCTIONS
Installation Safety Precautions:
1. Never install telephone wiring during a lightning storm.
2. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.
3. Never touch un-insulated telephone wires or terminals unless the telephone line has been
disconnected at the network interface.
4. Use caution when installing or modifying telephone lines.
The HYBREX GDS-1280 utilizes a 3 pin grounding power supply cord. This cord is not to be attached to
any building surfaces. When using your telephone equipment, basic safety precautions should always be followed to reduce
the risk of fire, electric shock and injury to persons, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instruction marked on the
product.
3. Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water, for example, near a
bath tub, wash bowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool.
5. Do not place this product on an unstable cart, stand, or
table. The product may fall, causing serious damage
to the product.
6. Slots and openings in the cabinet and the back or
bottom are provided for ventilation, to protect it from
overheating, these openings must not be blocked or
covered. The openings should never be blocked by
placing the product on the bed, sofa, rug, or other
similar surface. This product should never be placed
near or over a radiator or heat register. This product
should not be placed in a built-in installation unless
proper ventilation is provided.
7. This product should be operated only from the type of
power source indicated on the marking label. If you
are not sure of the type of power supply to your home
or office, consult your dealer or local power company.
8. The socket-outlet shall be installed near the equipment
and shall be easily accessible.
9. This product is equipped with a three wire grounding
type plug, this plug will only fit into a grounding type
power outlet. This is a safety feature. If you are
unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the grounding type plug.
10. Do not allow anything to rest on the power cord. Do
not locate this product where the cord will be damaged
by persons walking on it.
11. Do not overload wall outlets and extension cords as
this can result in the risk of fire or electric shock.
12. Never push objects of any kind into this product
through cabinet slots as they may touch dangerous
voltage points or short out parts that could result in a
risk of fire or electric shock. Never spill liquid of any
kind on the product.
13. To reduce the risk of electric shock, do not
disassemble this product, but take it to a qualified
service man when some service or repair work is
required. Opening or removing covers may expose
you to dangerous voltages or other risks. Incorrect
reassemble can cause electric shock when the
appliance is subsequently used.
14. Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
A. When the power supply cord or plug is damaged or
frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by
following the operating instructions. Adjust only
those control, that are covered by the operating
instructions because improper adjustment of other
controls may result in damage and will often require
extensive work by a qualified technician to restore
the product to normal operation.
E. If the product has been dropped or the cabinet has
been damaged.
F. If the product exhibits a distinct change in
performance.
15. Avoid using a telephone (other than a cordless type)
during an electrical storm. There may be a remote
risk of electric shock from lightning.
16. Do not use the telephone to report a gas leak in the
vicinity of the leak.
-------------------------------------------------------
SAVE THESE INSTRUCTIONS

iv
Issue 1.1 – June 2007
HYBREX GDS-1280
Enterprise Class Communication System
General Description - Installation
Table of Contents
NOTIFICATION................................................................................................................................................................- 2 -
IMPORTANT SAFETY INSTRUCTIONS .....................................................................................................................- 3 -
INSTALLATION SAFETY PRECAUTIONS:................................................................................................................ - 3 -
GENERAL DESCRIPTION - INTRODUCTION................................................................................................................1
FCC RULES AND REGULATION.......................................................................................................................................1
FCC REGISTRATION NUMBER ................................................................................................................................................1
RINGER EQUIVALENCE NUMBER ............................................................................................................................................1
RINGER EQUIVALENCE 0.3B............................................................................................................................................1
NOTIFICATION OF THE TELEPHONE COMPANY........................................................................................................................1
DIRECT CONNECTION TO A PARTY-LINE OR COIN OPERATED TELEPHONE LINE IS PROHIBITED.............................................1
INCIDENCE OF HARM TO THE TELEPHONE LINES ....................................................................................................................1
COMPATIBILITY OF THE TELEPHONE NETWORK AND TERMINAL EQUIPMENT.........................................................................2
RADIO FREQUENCY INTERFERENCE........................................................................................................................................2
CTR 21 (98/482/EC) DECLARATION NETWORK COMPATIBILITY.........................................................................2
ISDN INSTALLATION..........................................................................................................................................................2
KEY HIGHLIGHTS OF THE GDS-1280.............................................................................................................................3
EASY INSTALLATION ..............................................................................................................................................................3
BENEFITS................................................................................................................................................................................3
FLEXIBILITY OF SYSTEM APPLICATIONS.................................................................................................................................4
VARIED EXTENSION ALTERNATIVES.......................................................................................................................................4
LIQUID CRYSTAL DISPLAY .....................................................................................................................................................4
TYPE OF PHONES ....................................................................................................................................................................5
TYPE OF PHONES ....................................................................................................................................................................6
MECHANICAL SPECIFICATIONS (KEY SERVICE UNIT).............................................................................................................7
ENVIRONMENTAL SPECIFICATIONS.........................................................................................................................................7
FEATURES..............................................................................................................................................................................8
SYSTEM FEATURES.................................................................................................................................................................8
STATION FEATURES................................................................................................................................................................9
OPTIONAL FEATURES..............................................................................................................................................................9
PARTS & PERIPHERALS...................................................................................................................................................10
SYSTEM MODULES................................................................................................................................................................10
STANDARD PERIPHERAL CARD.............................................................................................................................................10
OPTIONAL CARDS.................................................................................................................................................................10
SYSTEM INSTALLATION - INTRODUCTION..............................................................................................................11
KEY SERVICE UNIT - GENERAL INTRODUCTION...................................................................................................12
LOCATION.............................................................................................................................................................................13

Choosing the Right Environment..................................................................................................................................... 13
INSTALLATION CHECKLIST................................................................................................................................................... 13
EQUIPMENT REQUIREMENTS....................................................................................................................................... 14
INSTALLATION .................................................................................................................................................................. 15
CABINET CABLING AND CONNECTION................................................................................................................................... 15
DIP Switch Adjustment.................................................................................................................................................... 19
POWER SUPPLY VOLTAGE OPTIONS FOR THE UNIT............................................................................................ 21
POWER ON AND OPERATIONAL TEST (IMPORTANT)........................................................................................... 21
OPERATIONAL TESTS (IMPORTANT) ..................................................................................................................................... 21
STANDARD CARD INTRODUCTION ........................................................................................................................................ 22
G2-MBU16 (Front) ......................................................................................................................................................... 22
G2-MBU16 (Back)........................................................................................................................................................... 22
G2-MPU16...................................................................................................................................................................... 23
G2-MHU16...................................................................................................................................................................... 24
G2-MXU16...................................................................................................................................................................... 25
G2-PSU16 ....................................................................................................................................................................... 26
G2-MEUN16 ................................................................................................................................................................... 27

GDS-1280N - General Description
1
General Description - Introduction
The General Description section contains an easy to understand overview of the HYBREX®GDS-1280
Enterprise Communication System. It is the intent of this document to provide both technical and non technical
readers with information pertaining to the system building blocks, capabilities, key highlights, electrical, physical
and environmental characteristics of the HYBREX GDS-1280 Enterprise Class Communication System.
FCC Rules and Regulation
In compliance with the requirements of Part 68 of the Federal Communications Commission Rules and
Regulations for connection of terminal system equipment to the telephone network and for your convenience, the
following information is presented.
FCC Registration Number
The HYBREX GDS-1280 is registered with the FCC in a dual registration capacity enabling the system to
operate as a key system only or as a hybrid system. The FCC Registration Numbers are US: 3A7MF03BGDS-
600 for key systems registration and US: 3A7KF03BGDS-600 for hybrid operation.
Ringer Equivalence Number
Ringer Equivalence 0.3B.
Notification of the Telephone Company
Customers connecting terminal equipment to the telephone network shall, upon request of the
Telephone Company, inform the Telephone Company of the particular line(s) to which such
connection is made, the FCC registration number and ringer equivalence number (REN) of the
registered terminal equipment.
The REN is useful to determine the quantity of devices you may connect to your telephone line
and still have all of those devices ring when your telephone number is called. In most, but not
all areas, the sum of the REN's of all devices connected to one line should not exceed five
(5.0). To be certain of the number of devices you may connect to your line, as determined by
the REN, you should contact your local telephone company to determine the maximum REN
for your calling area.
This equipment is capable of providing users access to Interstate providers of operator
services through the use of access codes. Modification of this equipment by call aggregators to
block access dialing codes is a violation of the Telephone Operator Consumers Act of 1990.
Direct Connection to a Party-Line or Coin Operated Telephone Line is Prohibited.
Incidence of Harm to the Telephone Lines
Should terminal equipment cause harm to the Telephone Network, the Telephone Company shall, where
practical, notify the customer that service may be temporarily discontinued. However, where prior notice is not
practical, the Telephone Company may temporarily discontinue service, if such action is reasonable in the
circumstances. In case of such un-notified temporary discontinuance of service, the Telephone Company shall:
(a) Promptly notify the customer of such temporary discontinuance of service.
(b) Afford the customer the opportunity to correct the situation which gave rise to the temporary
discontinuance.
(c) Inform the customer of the right to bring a complaint to the FCC pursuant to the procedures set
out in Subpart E of Part 68 of FCC Telephone Equipment Rules.

2
Compatibility of the Telephone Network and Terminal Equipment.
(a) Availability of telephone interface information.
Technical information concerning interface parameters and specifications not specified in FCC
Rules, including the number of Ringers which may be connected to a particular line, which is
needed to permit Terminal Equipment to operate in a manner compatible with Telephone
Company communications facilities, shall be provided by the Telephone Company upon
customer's request.
(b) Changes in Telephone Company Communications Facilities, Equipment, Operations and
Procedures.
The Telephone Company may make changes in its communications facilities, equipment, operations or
procedures where such action is reasonably required in the operation of its business and is not inconsistent with
the rules and regulations in FCC Part 68 of the FCC Rules and Regulations. If such changes can be reasonably
expected to render any customer Terminal Equipment incompatible with Telephone Company Communications
Facilities, or require modification or alteration of such Terminal Equipment, or otherwise materially affect its use
or performance, the customer shall be given adequate notice in writing to allow the customer an opportunity to
maintain uninterrupted service.
Radio Frequency Interference
This equipment generates and uses radio frequency energy and if not installed and used properly and in strict
accordance with the manufacturer's instructions, may cause interference to radio and television reception. It has
been type-tested and found to comply with the limits for a Class A computing device in accordance with the
specification in Subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against
such interference in a residential installation. However, this is no guarantee that interference will not occur in a
particular installation. If this equipment does cause interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
Re-orient the receiving antenna.
Relocate the equipment with respect to the receiver.
Move the equipment away from the receiver.
Plug the equipment into a different outlet so that equipment and receiver are on different branch
circuits.
CTR 21 (98/482/EC) Declaration Network Compatibility
CTR 21 (98/482/EC) Declaration Network Compatibility, the equipment has been approved in accordance with
Council Decision 98/482/EC for pan-European single terminal connection to the public switched telephone
network (PSTN). However, due to differences between the individual PSTNs provided in different countries, the
approval does not, of itself, give an unconditional assurance of successful operation on every PSTN network
termination point. In the event of problem, you should contact your equipment supplier in the first instance.’
ISDN Installation
For the ISDN unit (G2-SIU/G2-PIU), GDS-1280 only offers ISDN S/T interface connection behind NT1 device. It
could not be connected to “U” interface directly.

GDS-1280N - General Description
3
Description
Today’s large enterprises need reliable, flexible, remotely accessible, easy-to-manage voice communications
solutions. The GDS Enterprise Class Communication System is exactly the answer. The GDS Enterprise Class
Communication System is an integrated, interactive solution for medium-sized businesses, large corporations,
chained hotels and hospitals. The solution combines traditional telephone functions with support for IP-enabled
telephony communication to provide an effective and complete communications solution for cost-conscious
companies on the cutting edge.
GDS1280 - An Expansion of GDS 600
Key highlights of the GDS-1280
Easy Installation
•“Factory Ready” - All GDS-1280 Telephone systems are "ready to go" right out of the box. A well thought
out default database is factory installed on each system which meets the needs for most installations. This
alleviates hours of on site time, minimizing installation costs for both dealer and customer.
Benefits
•High scalability, with support for up to 1,280 ports
•Protection of existing investments through easy upgrades of existing GDS 600 systems
•Easy to manage, deploy and maintain
•Protects investment for large and medium-sized companies.

4
•Provides midsize companies with the same advanced features as larger companies, without needing
dedicated, high-level technical resources and staff.
•Uninterruptible operation thanks to redundant control units in the central system.（Optional）
•Boosts employee productivity and customer interaction by delivering full services to all staff members at all
locations.
Flexibility of System Applications
Unlike other conventional systems in the GDS-1280 size range, the installer will find an unprecedented range of
customer database programmability. In "system parameters" there are extensive options for various timing
settings related to features. An array of parameters are programmable for signaling options on outside lines and
internal single line telephone sets. The installer may Enable/Disable many system wide features. And in class
of service, there are over 20 options for each station providing maximum flexibility for nearly any application.
Varied Extension Alternatives
You can connect an ISDN Modem, ISDN phone, proprietary HYBREX DK series Keyphone, Access Control
Phone (ACP), Door Phone and conventional industry standard single line sets – Modem, Answering Machine,
Cordless phone, etc.
Liquid Crystal Display
The DK1, DK2, DK3, DK6 Series Telephone Model DK1-21 / DK2-21 is equipped with a large, easy to read LCD
display. The LCD is 32 characters total, comprised of 2 rows by 16 characters each.
The DK2 Series Telephone Model DK2-21 is equipped with a large, easy to read LCD display. The LCD is 64
characters total, comprised of 4 rows by 16 characters each.
This LCD provides an invaluable tool for simplifying the use of the telephone by identifying the calling extension
by name, outside lines by name and self prompting displays for feature access. Station feature usage is made
simple with the help of the LCD display. Continuous prompting information is displayed during calls so that
users know what to do and when to do it.
32-character LCD Display shows:
•Time •Last number dialed
•Dialed telephone number •The status of operation/function
•Voice Mail Messages •Absent messages
•CO Line Names •Speed Dial Directory
•Last Number Redial •Calling Party Number and Name
•Speed dial number •Input data during system data entry

GDS-1280N - General Description
5
HYBREX Telephone Model
DK1-21
DK2-21

6
Type of Phones
Model Description
DK1-21 Multifunction Key Telephone. Includes 32 character LCD display,
speakerphone, handsfree, headset jack, 20 dual color keys and 14 function
keys for feature access, DSS, CO Lines and speed dial.
DK2-21 Multifunction Key Telephone. Includes 64 character LCD display,
speakerphone, handsfree, headset jack, 22 dual color keys and 17 function
keys for feature access, DSS, CO Lines and speed dial.
MAXIMUM LOOP RESISTANCE/IMPEDANCE
Key Telephone 26 AWG / 200 m
24 AWG / 300 m
Single Line telephone 26 AWG / 1000 m
22 AWG / 3000 m
Doorphone 24 AWG / 300 m
Music Source Input Impedance 600 ohms
Maximum Input 0.775 VRMS
INTERNAL RELAY CONTACTS
Type SPST
Rating 1 AMP, 24VDC
Function Door Switch, Music on Hold, etc
CABLE REQUIREMENTS
CO/PABX Line Twisted 1 Pair (2 wires)
ISDN BRI Twisted 2 Pair (4 wires)
ISDN PRI Twisted 2 Pair (4 wires)
DK1/DK2/DK3/DK6/ACP Digital Key
Telephone
Twisted 1 Pair (2 wires)
Doorphone Twisted 1 Pair (2 wires)
Door Switch Twisted 1 Pair (2 wires)
External Sensor Twisted 1 Pair (2 wires)
External Music Source Twisted 1 Pair (2 wires)
Single Line Telephone Twisted 1 Pair (2 wires)

GDS-1280N - General Description
7
Mechanical Specifications (Key Service Unit)
CABINET DIMENSIONS
438 mm W 411 mm D 107 mm H
17.2” 16.2" 4.2”
WEIGHT 15 Kg
33 lbs
Environmental Specifications
OPERATING CONDITIONS STORAGE
CONDITIONS
Temperature 0º to 45º C -40º to 66º C
(32º to 113º F) (-40º to 150º F)
Humidity 10 to 95% relative 10 to 95% relative
Non-condensing non-condensing

8
Features
System Features
Account Code Capability
Attendant Console Assignment
Attendant Overflow
Automatic Line Access
Automatic Line Search
Automatic Ringdown
Automatic Wake-up
Battery Charger
Behind PABX Operation
Centrex Operation
Class Of Service
CO Line Groups
CO Line Hunting
CO Line Name Programming
CO Line Ring Types
Linear
Common Audible
Circular
Hunt
Console Assignment
Day/Night Service
Manual/Automatic Switch
Dial 9 Group
Direct In Line
Dial By Name
Dial Mode Selection(DP/DTMF)
Dial Pulse to DTMF Conversion
Distinctive Ringing
DTMF Signaling
Dual Port Capability
End to End Signaling
Easy Installation and Operation
Flash (Programmable)
Flash Memory Backup Memory
Flexible Expansion
Flexible Ringing Assignment
Flexible Key Group Assignment
Flexible Number Plan 2,3 or 4 Digit
Flexible Time Format 12/24 Hour
Forced Account Code Assignment
Intercom
Intercom Single Digit Assignment
Intercom Ring / Voice Select
Intercom Dialing Restriction
ISDN
Call Charge Metering Information
Caller Identification
Direct Inward Dialing
Call Forward Internal / External
Call Waiting
MSN (Multiple Subscriber Number)
Sub-addressing
User to User Signaling
Host PABX Access
Hot line
Line Group Assignment
Loud Bell Assignment
Multiple Attendant Consoles
Multiple Trunk Groups
Night Transfer
On Call Programming
Paging
Internal
Zone
Meet Me
Password Assignment
DISA
System programming
Toll Override
Pause
Pick Up Groups
Power Fail Transfer
Security Code
Single Digit Dialing
Station Group Assignment
Station Hunting
Station Lock
System Speed Dial and Personal Speed Dial
System Date & Time Setting
System Time-Reminder Service
Telephone Directory
Toll Control
Day / Night
Tone to pulse dialing
Trunk Queuing
Trunk to trunk connections
Uniform Call Distribution
Voice Mail Compatibility

GDS-1280 - General Description
9
Station Features
Advisory Messages
System
Personal
Access to System Programming
Account Code Capability
Auto Hold
Auto Hold Recall
Automatic Call Back
Automatic Answer-Intercom
Automatic Line Access
Automatic Redial
Automatic Volume Increase
Brokers Call
Call Duration Timer (LCD Phones)
Call Waiting
Call Forwarding
All Calls
Busy
No Answer
Busy / No Answer
External
Call Pickup
Call Split
Call Transfer
Calling Name Display (LCD Phones)
Calling Number Display (LCD Phones)
Camp On
Chain Dialing
Conference
Dial By Name (LCD Phones)
Dial Access to Attendant
Direct Station Selection
Doorphone Access
Do Not Disturb (DND)
Dual Color LED
Duration Time Display (LCD Phones)
Executive Override (Barge-In)
External Call Forwarding
Flash (Open Loop Timed Flash)
Hands-free Answer Back
Hearing Aid Compatibility
Headset Compatibility
Hold (Exclusive / System)
Hold Recall
I Hold Indication
I Use Indication
Intercom
Intercom ring / voice interchange
Intercom Step Call
Intercom Voice Announce
Last Number Redial
Message Waiting
Multi-Language Display
On Hook Dialing
Prime Line Select
Privacy
Privacy Release
Private Line
Pulse/Tone Conversion
Ring Frequency Selection
Ringing Line Preference
Saved Number Redial
Speed Dialing
Station Lock / Unlock
Station Monitor
Store Speed Dial/DSS Number
Timed Reminder Service
System
Station
Toll Restriction Override
Trunk Queuing
Volume Control
Handset
Speaker
Ringer
Optional Features
Access Control Phone
Automated Attendant
Battery Backup (System)
Direct Inward System Access (DISA)
Door phone / Door Latch
Dual Port Operation
External Music Source
Music On Hold
Relay Control
RS232
Security Sensor/Door Open Indication
Station Message Detail Record (SMDR)
Voice Mail

10 Issue 1.1 March, 2016
Parts & Peripherals
System Modules
Model Description
G2-MMD1280 Master Device for 1280 Port System - Single Processor, Single Power
Supply.
G2-MMD1280RP
(not available yet)
Redundancy Pack for G2-MMD1280, including G2-MPU16 Single
Master Process Unit for 1280 port System, G2-PWU16 Single Power
Supply for G2-MMD1280 Master Device
The system module includes the following cards
G2-PSU16 Power Supply Unit
G2-MBU16 Mother Board
G2-MHU16 Main HDLC (Data Exchange) Unit
G2-MXU16 Main PCM (Voice Exchange) Unit
G2-MPU16 Main CPU Unit
Standard Peripheral Card
Model Description
G2-MEU16 Main Expansion Unit
Optional Cards
Model Description
G2-PSU16 Power Supply Unit (Option for Redundant Power)
G2-MPU16 Main CPU Unit (Option for Redundant Central Control )

System Installation - Introduction
This section provides directions for installing the system and optional equipment.
The installation must be performed by qualified service personnel.
Main components of the system are:
NOTE: Please follow the directions step by step.
The GDS-1280 system should be installed in strict accordance with this manual.
Key Service Unit, which includes:
•Power Supply Unit (G2-PSU16)
•Mother Board (G2-MBU16)
•Main HDLC Unit (G2-MHU16 )
•Main Exchange Unit (G2-MXU16)
•CPU Unit (G2-MPU16)
Standard Peripheral Card
•Main Expansion Unit (G2-MEU16): 2 pcs are
included.
(
To be installed in Cabinet 1 and 9
)
Optional Cards:
•CPU Unit (G2- MPU16) for redundant central
control
•Power Supply Unit (G2-PSU16) for redundant
power supply

Key Service Unit - General Introduction
Front Panel of G2-MPUN16
Description:
1. LAN：LAN port
2. RS232：RS232 port
3. LAN：LED of LAN connection
4. PLL Normal：LED of PLL in normal status
5. PLL Lock：LED of PLL locked
6. CPU 1：LED of CPU 1
7. CPU 2：LED of CPU 2
8. Normal：Jump of normal status setting
9. Default：Jump setting of default setting
10. Stop : Shutdown MMD1280
11. Reset : Restart MMD1280
12. Next G2-MPUN16 for CPU redundancy (Optional)
Front Panel of G2-MXUN16 and G2-MHUN16
1. Port numbers for PCM：An illustration for PCM port numbers
16 ports for PCM：for connection to PCM
2. Port numbers for HDLC：An illustration for HDLC port numbers
16 ports for HDLC：for connection to HDLC
1 2 3 4 5 6 7 8 9 10 11 12

Rear Side of MMD1280 (Power)
Location
Choosing the Right Environment
•System should be installed in a clean, dry, secure location. This location must have adequate ventilation,
and a temperature from 0 ℃to 45℃(32℉to 113℉), with 10% to 95% non-condensing relative humidity. DO
NOT install the equipment near sources of static electricity, excessive vibration, or water. Avoid direct
sunlight.
Installation Checklist
INSTALLATION REQUIREMENTS VERIFICATION
MOUNTING SURFACE Flat surface with adequate space for main cabinet,
power supply, wiring and optional Battery Backup
cabinet.
AC LINE AC line should be dedicated exclusively to the system.
POWER OUTLET Power Outlet must be a
3-wire grounded outlet plug, having parallel blades
and ground pin.
Input power Line capacity requirements - 10 amperes.
SURGE PROTECTION A Surge Protector is recommended on the dedicated
AC line.
VENTILATION AND TEMPERATURE Humidity: 10% to 95% relative non-condensing
Temperature:32℉to 113℉(0 ℃to 45 ℃).
EARTH GROUND A proper ground connection. (14 AWG)
SERVICEABILITY Lighting conditions and working space adequate for
future service. 30cm distance between the rack and the
wall is recommended.
AC/DC
S
witch
AC/DC
Switch
AC IN AC IN
48 VDC IN
For Batter
y
Power Redundancy
(Optional)
○
For Grounding

Equipment Requirements
•Unpack, Check and Verify Equipment - Unpack the telephone equipment boxes and verify the contents in
accordance with the packing list provided. If any discrepancies are noticed, please contact Auto Telecom or
Authorized Dealers.
•Damaged Boxes - If you notice any damage to the packages, please notify both the shipper and Auto
Telecom or Authorized Dealers at once.
•List of parts included in master device box:
•Master Device for 1280 Port System - Single Processor, Single Power Supply.
•2 pcs of G2-MEUN16 cards
•16 cables for PCM connection ( 3 meters long, red color )
•16 cables for HDLC connection ( 3 meters long, blue color )
•Installation Guide
•8 screws
•2 pcs of 19"rack mount kit
•Label Sticker of Numbers ( 5 sets of number 1 - 16 )
