Hyco Microboil Smart MS3W Specification sheet

Product Instruction Manual
Microboil Smart
Wall Mounted Boiling Water Heater
MS3W, MS3SS
MS6W, MS6SS
MS10W, MS10SS
v23.11.1

Overview
Thank you for purchasing a Microboil Smart wall mounted boiling water heater. Available
in 3, 6 and 10 litre capacities, it will provide hot water for making tea and coee in the work
place.
Please read and follow these instructions to ensure that installation and operation are as
simple and safe as possible.
This appliance is intended to be used in household and similar applications such as:
– sta kitchen areas in shops, oces and other working environments;
– farm houses;
– by clients in hotels, motels and other residential type environments;
– bed and breakfast type environments.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Parts of this appliance – especially the vent pipe and tap– can become very hot in
use and can also generate steam. Consider and avoid the risk of injury to people or
damage to property when installing the appliance.
The appliance should only be installed and maintained by a competent person in
accordance with any local electrical and plumbing regulations.
Do not install the appliance if there is any sign of damage to the supply cable.
Do not locate the appliance where the consequences of a water leak could be
unusually serious.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualied persons in order to avoid a hazard.
The appliance must be permanently connected to the electrical supply through an
appropriately rated isolating switch with a contact separation in all poles.
Only connect the appliance to an electrical supply that meets the specication
detailed on the rating label.
Important Safety Points
2

This appliance must be earthed.
This appliance is intended to be permanently connected to the water mains and
should not be connected by a detachable hose-set.
Only connect this appliance to a water supply that meets the min/max pressures
specied in the specications section of this manual.
Do not confuse the vent and the inlet pipes – serious damage may result.
Any plastic pipework or ttings connected to the vent pipe must be rated to 100°C
minimum.
Failure to comply with the venting requirements detailed in these instructions may
cause permanent damage to the appliance and will invalidate the warranty.
Cleaning and user maintenance shall not be made by children without supervision.
Children shall not play with the appliance.
Isolate the appliance from the electrical supply before performing any maintenance
task.
Ensure the appliance has cooled down before performing any maintenance task.
The appliance should be drained if it will be switched o and unattended for any
length of time, particularly during the colder months of the year where a possibility
of freezing temperatures exists.
For installations in areas with hard water, consider scale reduction lters to
minimise the need for future descaling.
3

1. Installation
4
1(a) Remove the Cover
• The cover is attached to the back frame by means of two screws at the base and top
of the appliance (see Diagram 1).
1(b) Select Mounting Position
Ensure the mounting surface is suitable for the weight of the appliance when full.
Parts of this appliance – especially the vent pipe and tap – can become very hot
and also could generate steam. Consider and avoid the risk of injury to people or
damage to property when installing the appliance.
Do not locate the appliance where the consequences of a water leak would be
unusually serious.
Diagram 1
• The appliance must be installed in a frost free environment. Frost damage is not
covered by the warranty.
• Ensure there is a wholesome water supply connection to the appliance with isolating
valve to facilitate future maintenance.
• Position the appliance bearing in mind it will contain scalding water.

• Units are typically mounted above a draining board or drip tray in a kitchen or similar
setting. The tap height should be convenient for both the operator and such that
visual contact is maintained with the liquid level of any vessel being lled.
• Ensure adequate clearance is left above the appliance to access the cover screws
using a screwdriver in order to remove the cover for servicing. Ensure there is
sucient clearence under the drain for a bucket or similar container.
5
Ensure there are no hidden cables or pipework before commencing any drilling.
1(c) Secure to Wall
• Mark positions of the keyhole slots, drill and plug the holes (see Diagram 2).
• Hang the appliance on the two screws and mark the two mounting holes in the
bottom of the appliance. Remove the appliance from the wall, drill and plug the two
holes. Rehang the appliance on the top two screws and screw the appliance to the
wall.
Diagram 2

2. Plumbing Connection
This appliance is intended to be permanently connected to the water mains and
should not be connected by a detachable hose-set.
Only connect this appliance to a water supply that meets the min/max pressures
specied in the specications section of this manual.
Any plastic pipework or ttings connected to the vent pipe must be rated to 100°C
minimum.
The appliance should only be used with the tap provided. Do not attempt to
change or modify in any way.
Do not confuse the vent and the inlet pipes – serious damage may result.
The appliance will malfunction if steam cannot easily escape via the vent pipe.
Failure to comply with the venting requirements detailed in these instructions may
cause permanent damage to the appliance and will invalidate the warranty.
• If incoming water pressure is above 1MPa (10 bar), a pressure reducing valve (not
supplied) must be tted.
• The appliance has movable inlet and vent connections. This allows the appliance
to be retrotted to previously installed pipe work. The height from the mounting
surface and the distance between the pipes can be adjusted by loosening the screws
and moving to the required position (see Diagram 3).
• The appliance can be installed with concealed or exposed plumbing connections.
Cold water pipes must be ushed before connection to the inlet.
26 - 42 mm
36 - 48 mm
WALL
Diagram 3
6

• All models will take 15mm pipe by means of compression ttings.
• Connect the cold water supply to the inlet connection below the solenoid valve (see
Diagram 4).
7
Diagram 4
Solenoid valve
• For the vent connection it is important that the vent pipe installation adheres to the
following specication;
- Falls continuously.
- Has a maximum total length of 400mm before any air gap.
- Is open to the atmosphere (no blockages).
- All ttings must be rated for continuous operation at a minimum of 100°C.
• The vent pipe can be more than 400mm long but if it is, a tundish or other air gap
device must be tted within the 400mm distance to the appliance (see Diagram 5).

8
3. Retting the Cover and Installing the Tap
• Slide the cover back over the appliance, taking care not to trap the vent tube at the
side of the appliance. Then secure with the 4 cover screws (see Diagram 1).
• Press the tap stem into the tank outlet, whilst holding the tap vertically so the tap
outlet points downward (see Diagram 6). Tighten the securing nut using a spanner
(see Diagram 7). Take care to not scratch the chrome.
• Ensure the tap is tight and correctly orientated. The stem and outlet of the tap are hot
when in use.
Diagram 6 Diagram 7
Diagram 5

4. Electrical Connection
The appliance must be permanently connected to the electrical supply through an
appropriately rated isolating switch with a contact separation in all poles
Only connect the appliance to an electrical supply that meets the specication
detailed on the rating label.
This appliance must be earthed.
The appliance should only be installed and maintained by a competent person in
accordance with any local electrical and plumbing regulations.
Ensure a water supply is present prior to turning on the electrical supply.
9
• Electrical connection should be made via a 13A switched fuse spur.
• Make connections as below;
- Green/Yellow earth wire to terminal marked
- Brown live wire to the terminal marked‘L’
- Blue neutral wire to the terminal marked ‘N’

10
5. Commissioning (rst power on)
• Ensure water supply is on.
• Switch power on.
• Automatic commissioning will then commence under the control of the electronic
circuit board. The (automatic) stages in commissioning are as follows:
• At rst power on, the water tank will completely ll with cold water through the
solenoid valve. This will take approximately 5 - 20 minutes depending on capacity of
the appliance.
• When the electronic level sensor detects that the tank is full of water, the heating
element is switched on.
• The status ring on the base of the tap stem will indicate the appliance is heating (red).
• When the water has reached operating temperature the commissioning phase ends
and the appliance switches to normal operating mode. The heating phase will take
approximately 5 - 20 minutes depending on capacity of the appliance.
• The status ring will now indicate the appliance is ready to use (green).
• In operating mode, the electronic circuit board optimises boiling water availability.
The circuit board prioritises heating over lling, adding cold water only when the
contents of the tank are already at operating temperature.
6. Operation
Parts of this appliance – especially the vent pipe and tap– can become very hot in
use and can also generate steam. Consider and avoid the risk of injury to people or
damage to property when installing the appliance.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance.

7. Smart Technology
11
• The Microboil Smart is tted with a two way tap.
• For instant boiling water for cups of tea and coee gently pull the top of the tap
forward. Boiling water will ow until the tap handle is released. This mode of
operation gives precision control for safe lling.
• To ll larger items such as caetieres, tea pots or pans, rotate the tap 180 degrees and
gently pull down until the tap handle locks into a horizontal position. Boiling water
will ow until the tap is returned to the vertical position.
Action Status Ring Caution Indicator
Filling None Pulsing
Initial heating Red Solid
Ready Green Solid
Sleep mode None Solid
Permanent fault Flashing red Solid
Temporary fault Flashing green Solid
• The appliance incorporates Smart Technology which increases energy eciency.
• Sophisticated electronic algorithms learn and predict boiling water usage so the
appliance is on when you need it and o when you don’t (sleep mode).
• No time is wasted programming or reprogramming a timer as algorithms are
constantly updating if your usage pattern changes.
Status Ring
• A status ring on the base of the tap stem indicates ready or heating (green/ red). It
also indicates when the appliance is in sleep mode.
Caution Indicator
• The caution indicator is a highly visible warning alerting users the appliance contains
boiling water. This indicator will slowly blink while the appliance is lling the rst
time. It also indicates the appliance has mains power.
See troubleshooting (section 13) for more fault information.

8. Cleaning and Maintenance
The appliance should only be installed and maintained by a competent person in
accordance with any local electrical and plumbing regulations.
Cleaning and maintenance shall not be made by children without supervision.
Do not use abrasive or corrosive chemicals to clean this appliance.
Use a soft damp cloth when cleaning the cover, avoid excessive use of liquids.
It is recommended that the appliance is inspected periodically for signs of scale
build up in the tank and around the element. Damage resulting from scale build
up is not covered by the warranty.
Always switch electrical power o if the water supply needs to be disconnected
for more than a few minutes. Failure to do so can damage the solenoid valve.
• Periodically (at least every 6 months) remove internal lime-scale build up using a
standard domestic kettle de-scaling compound. Access to the tank and water level
probe are gained from a black plastic screw cap at the top of the tank under the top
section of insulation. The cap is accessed by removing the plastic locking clip and
pulling the insulation up and forward (see Diagrams 8 and 9).
Diagram 8
12

• To aid de-scaling, the appliance has a drain plug which can be found on the
underside of the water tank behind the bottom insulation. This is accessed by
removing the plastic clips and pulling the insulation down and forward (see Diagrams
10 and 11).
Diagram 9
Diagram 10
Diagram 11
13

14
For some retro t installations where existing pipe work is to be used but the inlet and
vent is reversed, it is possible to switch the inlet and vent connections on the appliance to
suit. To reverse the inlet and vent positions the procedure is as follows.
• With the cover removed, unscrew the brass reducer connected to the solenoid valve.
• Unscrew the compression nut and olive and remove the brass nut securing the vent
connection part.
• Unscrew the 2 screws securing the solenoid valve and disconnect the wiring from the
solenoid valve. Once done remove the tube for the solenoid valve and then remove
the solenoid.
• Remove the tube from the top of the plastic vent temperature sensor housing and
unplug the thermistor connector from the top of the PCB.
• Remove the plastic vent temperature housing by pressing in the circular lock tab, this
can be done with a small screwdriver.
• The back plate has two mounting brackets but only one is folded up. The folded-up
bracket needs to be folded at and the bracket that was at needs bending up to 90
degrees.
• Ret the plastic vent temperature housing by pressing it down onto the newly folded
up bracket, this will snap into position. At the same time the brass section should be
slotted through the appropriate hole on its respective mounting bracket.
• Reconnect the thermistor connector at the top of the PCB making sure the wiring is
not tangled round the inlet and vent tubes.
• Ret the vent tube to the top of the plastic vent temperature housing and secure
with a cable tie. This tube must not be kinked or twisted in any way.
• Ret the brass securing nut to the thread on the vent connection and then ret the
compression olive and nut.
9. Advanced Information
The appliance should only be installed and maintained by a competent person in
accordance with any local electrical and plumbing regulations.
Always switch electrical power o if the water supply needs to be disconnected
for more than a few minutes. Failure to do so can damage the solenoid valve.
Reversing the Inlet and Vent Positions

15
The switches must only be used with the appliance isolated from the mains
electricity.
Control Board Settings
It is possible for the user to congure some aspects of the appliance’s behaviour. These
changes can be made by means of the switches located at the top right of the control
board inside the appliance.
Pattern Recognition
While the pattern recognition algorithm predicts usage with a high degree of accuracy
this feature may not be suitable for everyone’s needs, for example, if usage is highly
sporadic. The appliance is supplied with pattern recognition ON as default (see Diagram
13). To turn OFF slide to reverse the switch position, however this is the less energy
ecient option.
Calibration
Calibration ensures that boiling point is accurate depending on any given atmospheric
pressure, altitude and calibration drift in the thermistor and other components. As default
the appliance is supplied programmed to calibrate only when powered on (see Diagram
12). This means when the appliance is in sleep mode and therefore saving energy it will
not wake up and perform an auto calibration which is very wasteful of energy. Powering
on and o will always cause a recalibration. However, it is possible to change so the
appliance will calibrate once a week by sliding the switch to its reverse position.
• Place the solenoid through the remaining hole in the mounting bracket next to the
vent and secure with the two screws.
• Ret the brass reducer to the solenoid valve, it is best practice to renew the bre
washer when retting.
• Ret the inlet tube securing with a cable tie and ret the solenoid wires ensuring it
does not kink any tubing.
Diagram 12
Calibrate
only on power on
Diagram 13
Pattern recognition
set to on

10. Spare Parts Diagram
1
2
3
4
5
6
7
11
8
9
10
16

11. Spare Parts List
Diagram
Reference
Part Code Description
1 MS_GASKET_V1 Microboil Smart gasket
2 MS_ELEMENT_V1 Microboil Smart element
3 MS_TAPSET_V1 Microboil Smart full tap
4 MS_TAPHANDLE_V1 Microboil Smart tap handle
5 MS_TAPSILICONE_V1 Microboil Smart tap silicone
6 MS_CUTOUT_V1 Microboil Smart thermal cut out
7 MS_SOLENOID_V1 Microboil Smart solenoid valve
8 MS_PCB_V1 Microboil Smart PCB
9 MS_TANKCAP_V1 Microboil Smart tank cap
10 MS_LEVELPROBE_V1
MS10_LEVELPROBE_V1
Microboil Smart level probe for 3 and 6 L model
Microboil Smart level probe for 10 L model
11 MS_THERMISTOR_V1 Microboil Smart thermistor
17

12. Specication
Model MS3W/SS MS6W/SS MS10W/SS
Power 2.84 kW 2.84 kW 2.84 kW
Initial draw o (Cups/Mugs)* 18/12 36/24 62/42
Heat up time 6 mins 12 mins 20 mins
Recovery rate (Cups/hr) 176 176 176
Voltage 230 V~ 230 V~ 230 V~
Frequency 50 Hz 50 Hz 50 Hz
Min working pressure 0.1 MPa (1 bar) 0.1 MPa (1 bar) 0.1 MPa (1 bar)
Max working pressure 1 MPa (10 bar) 1 MPa (10 bar) 1 MPa (10 bar)
Ambient operating temperature 5 - 30 °C 5 - 30 °C 5 - 30 °C
Capacity 3 L 6 L 10 L
Finish W - White
SS - Stainless Steel
W - White
SS - Stainless Steel
W - White
SS - Stainless Steel
Dimensions (h x w x d) 453 x 303 x 193 mm 490 x 323 x 228 mm 578 x 370 x 250 mm
Weight empty 8.0 kg 9.9 kg 12.3 kg
Weight full 11.4 kg 16.4 kg 23.0 kg
Approvals CE, UKCA CE, UKCA CE, UKCA
*initial draw o based on 167ml cup and 250ml mug
18

14. Guarantee and Service Policy
If you experience a problem with this product you should rst contact our service
department on 01924 225 200 before taking any further action. Experience has shown
that issues can often be resolved without the need to return or uninstall the product.
15. Contact Us
13. Troubleshooting
Problem Solution
Tap splutters/ dispenses slowly Check the vent pipe is not obstructed and clear if
necessary
Excessive steam coming from the vent Switch o and on to force a recalibration
Water ows from the vent Check the water level probe under the cap for scale
Status ring ashing green Allow the product to cool and switch o and on.
Check water is supplied to the product.
Status ring ashing red Check connections to the temperature sensors
No lights Check electricity supply and the thermal cut out
No water dispensed Check water is supplied to the product
No water dispensed/ reduced ow Check lter for blockages, if clear replace lter
Water isn’t hot enough Switch o and on to force a recalibration
19
This product is covered by a standard parts or replacement warranty for a period of 1
year from the date of purchase. If there is a manufacturing defect within the warranty
period hyco will in its sole discretion replace, repair or refund any faulty unit. Incorrect
installation, frost damage, the consequences of limescale deposits or failure to follow
correct operating and maintenance instructions are excluded. Consequential costs
such as labour charges or damage to ttings and surroundings are expressly excluded.

Hyco Manufacturing Ltd
Normandy Court
Express Way
Castleford, WF10 5NR T 01924 225 200
E [e-mail]
hyco.co.uk
INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE
WITH THE EUROPEAN DIRECTIVE 2012/19/EU.
At the end of its working life this equipment must not be disposed of as household
waste. It must be taken to a local authority waste collection centre or to a dealer
providing this service. Disposing of electrical and electronic equipment separately
enables its components to be recovered and recycled to obtain signicant savings
in energy and resources. In order to underline the duty to dispose of this equipment
separately, the product is marked with a crossed out dustbin.
